UN65M70HAFXZA photo

Installation Manual

This is the main product document for model UN65M70HAFXZA. Additionally, the document applies to other Samsung models: 198957270260, UN65M70HAFXZA

The file format is pdf, 2 pages, you can download this manual here .

background
1 Cell Image size: 277 mm
2 Cell Image size: 132 mm
3 Cell Image size: 83.666 mm
4 Cell Image size: 59.5mm
BN68-25145A-00
1
1
2
3
Unpacking and
Installation Guide
Scan this QR code
with your smart
phone to see
helpful videos.
85″
85″
43″- 55″
43″- 75″
43″- 65″
65″- 75″
Power Cable
Remote Control /
Battery (AAA) x2
Standard
Remote Control /
Battery (AAA) x2
Simple User Guide /
Remote control guide /
Regulatory Guide
75″
75″
M7*H M1EH
background
3
4 5
43M7*H
43M1EH
37.7 inches
(957.8 mm)
22.0 inches
(558.8 mm)
3.0 inches
(76.3 mm)
24.0 inches
(609.0 mm)
6.2 inches
(157.0 mm)
42.5 inches
14.8 lbs
(6.7 kg)
15.2 lbs
(6.9 kg)
50M7*H
50M1EH
43.7 inches
(1110.8 mm)
25.3 inches
(643.8 mm)
3.0 inches
(76.4 mm)
27.4 inches
(696.0 mm)
7.8 inches
(199.0 mm)
49.5 inches
18.7 lbs
(8.5 kg)
19.4 lbs
(8.8 kg)
55M7*H
55M1EH
48.2 inches
(1224.6 mm)
27.9 inches
(707.8 mm)
3.0 inches
(76.6 mm)
29.9 inches
(760.0 mm)
7.8 inches
(199.0 mm)
54.6 inches
22.0 lbs
(10.0 kg)
22.7 lbs
(10.3 kg)
65M7*H
65M1EH
56.9 inches
(1444.1 mm)
32.7 inches
(831.2 mm)
3.0 inches
(76.8 mm)
34.7 inches
(882.2 mm)
8.7 inches
(222.0 mm)
64.5 inches
31.3 lbs
(14.2 kg)
32.0 lbs
(14.5 kg)
75M7*H
75M1EH
65.7 inches
(1668.1 mm)
37.7 inches
(957.8 mm)
3.0 inches
(77.0 mm)
39.7 inches
(1007.9 mm)
11.0 inches
(280.0 mm)
74.5 inches
47.6 lbs
(21.6 kg)
48.5 lbs
(22.0 kg)
85M7*H
85M1EH
74.4 inches
(1889.9 mm)
42.7 inches
(1083.5 mm)
3.0 inches
(77.0 mm)
44.6 inches
(1132.8 mm)
12.8 inches
(326.0 mm)
84.5 inches
63.3 lbs
(28.7 kg)
64.4 lbs
(29.2 kg)
* : 0~9, A~Z
VESA
x (mm) (mm) x 4 (mm)
(inches)
(inches)
(inches)
43M7*H
43M1EH
200 x 200
23-25
+
M8 1.25 5.7 14.9 8.4
50M7*H
50M1EH
200 x 200
23-25
+
M8 1.25 8.3 17.9 9.2
55M7*H
55M1EH
200 x 200
23-25
+
M8 1.25 10.8 20.2 9.2
65M7*H
65M1EH
200 x 200
23-25
+
M8 1.25 15.7 24.5 9.2
75M7*H
75M1EH
400 x 300
10-12
+
M8 1.25 17.6 25.0 8.3
85M7*H
85M1EH
400 x 300
10-12
+
M8 1.25 22.6 29.3 8.3
* : 0~9, A~Z
: Wall-Mount Bracket
The length of the screw protruding
past the bracket must be between
10 to 12 mm, the total length of the
screw will depend on the depth of
the bracket used.
70inch
85″
85″
