Lift-Away with
Anti Hair Wrap Plus
and
Anti-Odour Technology
Upright Vacuum
NZ700 Series
OWNER’S GUIDE
sharkclean.co.uk
3
sharkclean.co.uk
2
CONTENTS
Important Safety Instructions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Getting to Know Your Shark®
Lift-Away � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
Assembly � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
Power Cord � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
Anti-Odour Technology � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
Settings � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 12
Brushroll Indicator Light � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 12
Whole Home Cleaning � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
Settings � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
Headlight Indicator Lights � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
Cleaning Modes � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 14
Emptying the Dust Cup � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 14
Cleaning the Filters � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
Maintenance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16
Checking for Blockages � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 17
Available accessories � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 18
Troubleshooting Guide � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 19
Guarantee Terms and Conditions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 20
This marking indicates that this product should not be disposed of with
other household wastes throughout the UK. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material sources. To return
your used device, please use the return and collection systems or contact
the retailer where this product was purchased. They can take this product
for environmentally safe recycling.
TECHNICAL SPECIFICATIONS
Voltage: 220-240V~, 50-60Hz
Watts: 700W
TIP: You can find
the model and serial
numbers on the QR
code label located on
the back of your unit.
RECORD THIS INFORMATION
Model Number: ������������������������������
Serial Number �������������������������������
Date Code: ����������������������������������
Date of Purchase (Keep receipt): ����������������
Store of Purchase: ����������������������������
REGISTER YOUR PURCHASE
TO BENEFIT FROM YOUR PRODUCT'S EXTENDED
GUARANTEE, SIMPLY REGISTER YOUR PURCHASE
AT:
sharkclean.co.uk/register-guarantee
0800 862 0453
Scan QR code using mobile device
THANK YOU
for purchasing the Shark Lift-Away Anti Hair Wrap Plus with Anti-Odour
Technology Upright Vacuum
PLEASE READ CAREFULLY
AND KEEP FOR FUTURE REFERENCE�
This instruction manual is designed to help you get
a complete understanding of your new Shark®
Lift-Away Anti Hair Wrap Plus with Anti-Odour
Technology Upright Vacuum�
If you have any questions, please call the customer
service line on 0800 862 0453�
Benefits of registering your product and creating
an account:
• Get easier, faster product support and access to
guarantee information
• Access troubleshooting and product care instructions
• Be among the first to know about exclusive product
promotions
Please note, products purchased directly from Shark®
are automatically registered.
sharkclean.co.uk
5
sharkclean.co.uk
4
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, INJURY,
OR PROPERTY DAMAGE:
WARNING: Children should be
supervised to ensure that they do
not play with this vacuum cleaner.
GENERAL WARNINGS
1 Inspect power cord and plug for any
damage before use. DO NOT use vacuum
cleaner with a damaged cord or plug. Turn
o all controls before plugging in or unplug-
ging the vacuum cleaner. Store your vacuum
cleaner with the power cord secured around
the two cord hooks. To minimise the risk of
power cord damage, do not allow the
motorised brushroll to ingest the cord. If this
occurs, immediately shut o power to the
vacuum and remove the cord.
2 Your vacuum cleaner consists of a
motorised floorhead, wand, hose, and/or
vacuum pod. This device contains electrical
connections, electrical wiring, and moving
parts that potentially present risk to
the user.
3 Use only identical replacement parts.
4 Carefully observe and follow the instructions
provided below to avoid improper use of the
vacuum cleaner. DO NOT use the vacuum
for any purpose other than those described
in this manual.
5 Before use, carefully inspect all parts for
any damage. DO NOT use if any parts are
damaged.
6 The use of an extension cord is NOT
recommended.
7 CAUTION: This vacuum cleaner contains
electrical connections and no serviceable
parts.
USE WARNINGS
8 This vacuum cleaner can be used by
persons with reduced physical, sensory or
mental capabilities or lack of experience and
knowledge if they have been given super-
vision or instruction concerning use of the
vacuum cleaner in a safe way and under-
stand the hazards involved.
9 Do not allow the vacuum cleaner to be
used by children. Keep the vacuum cleaner
and its cord out of reach of children. Do not
allow to be used as a toy.
Close supervision is necessary when used
near children.
CLEANING AND USE
10 Always turn o the vacuum cleaner before
connecting or disconnecting any motorised
floorheads or other accessories.
11 DO NOT handle plug or vacuum cleaner
with wet hands.
12 DO NOT use without filters in place.
13 Only use Shark® branded filters and
accessories. Damage caused by the use of
non-Shark® parts may not be covered by
your guarantee.
14 DO NOT damage the power cord:
a) DO NOT pull or carry vacuum cleaner
by the cord or use the cord as a handle.
b) DO NOT unplug by pulling on cord.
Grasp the plug, not the cord.
c) DO NOT run the vacuum cleaner
over the power cord, close a door on
the cord, pull the cord around sharp
corners, or leave the cord near heated
surfaces.
15 DO NOT put any objects into floorhead or
accessory openings. DO NOT use with any
opening blocked; keep free of dust, lint, hair,
and anything that may reduce airflow.
16 DO NOT use if floorhead or accessory
airflow is restricted. If the air paths or the
motorised floor floorhead become blocked,
turn the vacuum cleaner o and unplug
from electrical socket. Remove all obstruc-
tions before you plug in and turn on the unit
again.
17 Keep floorhead and all vacuum openings
away from hair, face, fingers, uncovered feet,
or loose clothing.
18 DO NOT use if vacuum cleaner is not
working as it should, or has been dropped,
damaged, left outdoors, or dropped into water.
19 If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similar qualified persons in order to
avoid a hazard.
20 Use extra care when cleaning on stairs.
21 DO NOT leave the vacuum cleaner
unattended while plugged in.
22 When powered on, keep the vacuum cleaner
in motion over the carpet surface at all
times to avoid damaging the carpet fibres.
23 DO NOT place vacuum cleaner on unstable
surfaces such as chairs or tables.
24 DO NOT use to pick up:
a) Liquids
b) Large objects
c) Hard or sharp objects (glass, nails,
screws, or coins)
d) Large quantities of dust (drywall dust,
fireplace ash, or embers). DO NOT use
as an attachment to power tools for
dust collection.
e) Smoking or burning objects (hot coals,
cigarette butts, or matches)
f) Flammable or combustible materials
(lighter fluid, petrol, or kerosene)
g) Toxic materials (chlorine bleach,
ammonia, or drain cleaner)
25 DO NOT use in the following areas:
a) Poorly lit areas
b) Wet or damp surfaces
c) Outdoor areas
d) Spaces that are enclosed and may
contain explosive or toxic fumes or
vapours (lighter fluid, petrol, kerosene,
paint, paint thinners, mothproofing
substances, or flammable dust)
26 Turn o all controls before plugging
in or unplugging the vacuum.
27 Unplug from electrical socket when not in
use and before any maintenance or cleaning.
28 To clean: wipe down the unit with water
only. Washing with cleaning chemicals could
damage the unit.
29 During cleaning or routine maintenance,
DO NOT cut anything other than hair, fibres,
or string wrapped around the brushroll.
30 Allow all filters to air-dry completely before
replacing in the vacuum to prevent liquid
from being drawn into electrical parts.
31 Make sure the dust cup and all filters
are in place after routine maintenance.
32 Secure the power cord around the two cord
hooks during storage.
33 Observe the following when interacting with
the Anti-Odour Technology cartridge:
a) DO NOT attempt to disassemble
Anti-Odour Technology cartridge.
b) Avoid direct contact with the fragrance
pod in the cartridge.
c) DO NOT directly inhale from the
Anti-Odour Technology cartridge.
d) Keep away from children and pets.
e) Keep away from heat, sparks and open
fires.
f) DO NOT place in direct sunlight.
FRAGRANCE CARTRIDGE FIRST AID
a) Avoid contact with fabrics and finished
surfaces.
b) Eye contact: Remove contact lenses if
present. Rinse continuously with water
for several minutes.
c) Skin contact: Wash hands thoroughly
after handling. If irritation or rash
develops, seek medical advice/attention.
d) Inhalation: Move person to fresh air if
they are experiencing any respiratory
symptoms. If symptoms persist, seek
medical advice/attention.
e) Ingestion: DO NOT induce vomiting.
Seek medical advice/attention
IMPORTANT SAFETY INSTRUCTIONS
FOR HOUSEHOLD USE ONLY • PLEASE READ ALL INSTRUCTIONS
BEFORE USING THIS VACUUM�
IF YOU HAVE DELICATE OR WOOL CARPETS, PARTICULARLY LOOP PILE,
PLEASE TRY THE VACUUM ON A HIDDEN AREA FIRST TO ENSURE THE
SPINNING BRUSHROLLS DO NOT DAMAGE OR UNPICK CARPET FIBRES�
May cause an allergic reaction to skin if in direct contact with
contents of cartridge� Wear protective gloves if directly coming
into the contact with the cartridge material, wash skin thoroughly
after handling� Harmful if swallowed� Avoid breathing in mist or
vapours, intentional misuse and directly inhaling contents may
be dangerous� Avoid release to the environment� Very toxic to
aquatic life with long lasting eects, ensure cartridge is disposed
of correctly as general waste�
ANTI-ODOUR TECHNOLOGY
WARNING
sharkclean.co.uk
7
sharkclean.co.uk
6
WELCOME!
Congratulations
on your purchase.
Use this instruction
manual to learn about
your new vacuum’s
great features. From
assembly to use to
maintenance, you will
find it all in here.
L
N
O
MAIN UNIT
A Suction Control Slider
B Handle
C Hose
D Handle Release Button
E Power Switch
F Wand Release Button
G Wand
H Dust-Cup Release Latch
I Lift-Away Pod
J Dust-Cup Empty Buttons
K Lift-Away Pod Button
L Motorised Floor Nozzle
M Anti-Hair Wrap Plus Brushroll
N Headlights
O Brushroll Indicator Light
GETTING TO KNOW YOUR SHARK CORDED UPRIGHT VACUUM WITH
LIFT-AWAY TECHNOLOGY AND ANTI HAIR WRAP PLUS BRUSHROLL�
Wand
Release
A
B
K
E
F
I
C
D
G
H
J
M
sharkclean.co.uk
9
sharkclean.co.uk
8
ASSEMBLY ASSEMBLY
Tool Storage
Posts
Upper Cord
Hook
Lower Cord Hook
POWER CORD
For cord access, rotate upper hook
down and remove cord�
Use cord holder on the side of wand
to hold cord in place while vacuuming�
UPPER CORD HOOK CORD HOLDER
1. Place Pod down onto Nozzle.
2. Insert Wand into Pod.
3. Insert Handle into wand�
4. Attach Hose to back of pod�
5. Remove Anti-Odour Technology Dial from bag� Flip up the dial handle,
align the teal arrows, then insert the dial into the nozzle�
6. To lock and engage the dial, rotate it counterclockwise until it clicks into the desired
Odour intensity setting�
* More detailed Anti-Odour Technology assembly instructions and visuals on the
following two pages�
IMPORTANT: For proper operation, ensure all connections are securely clicked into place�
(Click)
2
(Click)
1
(Click)
3
(Click)
4
(Turn to
Click)
6
5
sharkclean.co.uk
11
sharkclean.co.uk
10
ANTI-ODOUR TECHNOLOGY
ODOUR CARTRIDGE REPLACEMENT
TECHNOLOGY SETTINGS
ANTI-ODOUR TECHNOLOGY TIPS
SETTINGS
Flip up the dial handle and rotate the Odour dial
to adjust Anti-Odour Technology intensity or to
unlock the dial for cartridge access�
Flip up the handle and rotate the dial clockwise
until the two teal arrows are aligned� Pull the
handle to remove the dial from the nozzle�
Rotate the cartridge counterclockwise
in the dial housing and pull out the
cartridge to remove it�
Align the yellow arrow on the side of the cartridge
with the yellow arrow on the side of the dial
cover, then insert the cartridge into the dial�
Rotate the cartridge clockwise to lock it in place�
Dispose of the old cartridge by
dropping it into the trash�
Remove the new Odour cartridge from the
sealed packaging� To maintain the life of
the cartridge, keep it in the sealed
packaging until you are ready to install it�
Align the teal arrow on the dial cover with
the teal arrow on the nozzle, then reinsert
the dial into the nozzle� Rotate the dial
counterclockwise until it clicks into an
intensity setting to engage� Rotate further
to change the intensity setting�
ODOUR DIAL
1. REMOVE ODOUR DIAL
FROM NOZZLE
2. REMOVE OLD ODOUR
CARTRIDGE
5. INSTALL DIAL IN NOZZLE
4. INSTALL NEW CARTRIDGE
IN DIAL
6. USED CARTRIDGE
DISPOSAL
NOTE: Odour cartridges should be replaced every
6 months for optimal Anti-Odour Technology
performance�
NOTES: • The Odour dial needs to be installed for the vacuum to function properly, with or without the Odour cartridge�
• Anti-Odour Technology eectively deOdourizes while interacting with Odours from inanimate sources�
Insertion/Removal: Rotate the Odour dial to align the teal arrows� Remove the dial to
access the Odour cartridge for removal or replacement�
Low: Rotate the dial toward the Low position to decrease the intensity to the lowest level
when the vacuum is in use�
High: Rotate the dial toward the High position for the highest intensity level when the
vacuum is in use� This position is the recommended setting for optimal performance�
Odour Dial Must be Installed for Vacuum to Function Properly
• Remove Odour cartridge from dial if you don’t want the benefits of the Anit-Odour
Technology�
Maintenance Required
• Clean all filters as recommended under Cleaning Filters�
• Empty the dust cup before storing your vacuum�
• Replace the cartridge as recommended under Odour Cartridge Replacement�
• If wet pet messes are cleaned up, thoroughly clean the vacuum�
Fragrance Strength Over Time
• The intensity of the Anti-Odour Technology’s fragrance may diminish over time� It may
also have no noticeable fragrance at all� This is natural and does not indicate the technology
isn’t working� Follow replacement instructions to ensure continued performance�
TURN UNTIL
CLICK TO LOCK
3.REMOVE NEW
CARTRIDGE FROM CAN
sharkclean.co.uk
13
sharkclean.co.uk
12
Select surface setting:
O Power O
I Hard Floor
For hard floors and small area rugs�
II Carpet
For carpets�
NOTE: All accessories are compatible with both the wand and the handle� Included accessories will vary by model�
NOTE: For deep carpet cleaning per ASTM F608,
use setting II (Carpet) with MAX suction�
NOTE: The brushrolls spin in all modes
WHOLE-HOME CLEANING
CLEANING MODES
To engage Brushrolls, select a
surface setting, step on floor nozzle
and tilt handle back firmly�
Step on the pedal on the floor
nozzle to lift o the pod�
Press the Wand Release button
and pull up on the wand to
detach it from the pod�
Press the Handle Release button
and pull up on the handle to
detach it from the wand�
Attach an optional cleaning
accessory to handle or wand�
UPRIGHT MODE LIFT-AWAY MODE
POWER/SURFACE SWITCH
ABOVE-FLOOR—WAND
ACCESSORIES—WAND
ABOVE-FLOOR—HANDLE
ACCESSORIES—HANDLE
Wand
Release
WHOLE-HOME CLEANING
SETTINGS
The Suction Control Slider located on the
handle allows you to adjust the suction
depending on the floor type�
MIN: to reduce suction and increase
maneuverability on carpets�
MAX: to increase suction on hard floors�
SUCTION CONTROL
Solid White Lights: The brushrolls are spinning and the unit is working as it should�
Solid Red Lights: There is a jam in the brushroll area� Turn o the vacuum and unplug it,
then remove any blockages in the nozzle�
Flashing Red Lights: The motorized floor nozzle is overheating� Turn o the vacuum, unplug
it, and remove any blockages� Let the vacuum cool down for at least 60 minutes before
restarting� See Troubleshooting section for more information�
Flashing White Lights: The vacuum is operating in an environment that is either too hot or
too cold� This vacuum will only function properly in temperatures ranging from 32°F (0°C)
to 104°F (40°C)� Turn the vacuum o and adjust the room temperature�
HEADLIGHT INDICATOR LIGHTS
NOTE: For deep cleaning per ASTMF608 (embedded dirt in carpets), please set to Carpet mode�
NOTE: For maximum suction for above-floor cleaning per ASTM F558, set to Hard Floor mode�
HEADLIGHTS
The headlights will flash or turn red to
indicate issues that need attention�
sharkclean.co.uk
15
sharkclean.co.uk
14
EMPTYING THE DUST CUP
To remove the Dust Cup, slide up on the release
button located on the side of dust cup handle�
Tilt dust cup forward, then lift to remove�
To reinstall, place the bottom of the dust
cup onto the pod and then tilt until it clicks
into place�
To empty debris into the trash, press the
lower release button and the bottom of the
dust cup will drop open�
Clear debris from the Lint Screen in the dust
cup� Lift the upper release tab at the top of
the dust cup and open the lid� Gently brush
the lint screen to remove debris�
RINSE POST MOTOR FILTER
EVERY YEAR
To remove the Post Motor Filter, first pull the
tab on the bottom of the filter door, then lift
o the door� Press the tab on the side of the
Post Motor filter and pull out the filter�
To reinstall the door, align the top first, then
press in the bottom until it clicks into place�
RINSE PRE-MOTOR FILTERS
EVERY MONTH
Remove the Dust Cup, then lift out Filters�
Regularly rinse and replace the filters to maintain your vacuum's suction power and to
maximize the eectiveness of the Anti-Odour Technology.
Rinse filters with cold water only� Allow all filters to air-dry for at least 24 hours before
reinstalling them to prevent liquid from being drawn into electronic parts�
CLEANING THE FILTERS
IMPORTANT: DO NOT use soap when cleaning the filters�
IMPORTANT: Unplug the power cord before performing any maintenance�
Empty the dust cup each time you vacuum and periodically during cleaning,
when debris in the dust cup reaches the MAX fill line�
Post-Motor
Filter
Foam
Felt
Filter
Door
sharkclean.co.uk
17
sharkclean.co.uk
16
MAINTENANCE
CHECKING FOR BLOCKAGES
Detach wand from pod and handle,
and check both ends for blockages�
Detach dust cup from vacuum
pod� Empty dust cup and remove
debris from lint screen in the top
of the dust cup�
Detach hose from handle by
pressing on the release button
at the top of the hose� Detach
the hose from the pod, and
check openings for blockages�
DUST CUP BLOCKAGES
WAND BLOCKAGES
HOSE BLOCKAGES
ANTI HAIR WRAP PLUS
If any hair is wrapped around the brushroll, continue vacuuming, using Carpet/Low Pile mode
on a bare floor surface, a low-pile carpet, or a small area rug� This will allow the self-cleaning
brushroll to remove the hair wrap and send it to the dust cup�
If you run over a hard or sharp object or notice a noise change while vacuuming, check for
blockages or objects caught in the brushroll�
If some fibers remain wrapped around the brushroll after continued use, carefully remove them�
NOZZLE MAINTENANCE
To minimize the risk of power cord damage,
DO NOT run the vacuum over the power cord�
If this occurs, immediately shut o power to
the vacuum and remove the cord from the
brushrolls or nozzle�
1. DO NOT pull or carry vacuum cleaner by
the cord or use cord as a handle�
2. DO NOT unplug by pulling on the cord�
Grasp the plug, not the cord�
3. DO NOT close the door on the cord�
4. DO NOT pull the cord around sharp
corners�
5. DO NOT leave the cord near heated
surfaces�
CORD MAINTENANCE
Detach handle from wand and
hose from the vacuum pod, and
check openings for blockages�
HANDLE/HOSE BLOCKAGE
To access the nozzle hose, pinch
the release touchpoints on the
bottom of the nozzle, then lift the
cover and clear any blockages�
NOZZLE HOSE BLOCKAGE
Detach wand from floor nozzle,
tilt nozzle neck back, and check
opening for blockages�
NOZZLE BLOCKAGE
sharkclean.co.uk
19
sharkclean.co.uk
18
TROUBLESHOOTING
Power cord caught in brushrolls or floor nozzle�
• To minimize the risk of power cord damage, DO NOT run the vacuum over the power cord�
If this occurs, immediately shut o power to the vacuum and remove the cord from the
brushrolls or nozzle�
• Inspect power cord and plug for any damage before use� DO NOT use vacuum cleaner with
a damaged cord or plug� Turn o all controls before plugging in or unplugging the vacuum
cleaner� Store your vacuum cleaner with the power cord secured around the two cord hooks�
Vacuum is not picking up debris� No suction or light suction�
• Check filters to see if they need cleaning� Follow instructions for rinsing and air-drying the
filters before reinstalling them in the vacuum�
• Dust cup may be full; empty dust cup�
• Check handle, hose, hose connections, nozzle, wand, pod, and accessories for blockages�
Clear any blockages found�
• If any string, hair, or carpet fibers are wrapped around the PowerFins brushroll, carefully
cut debris with scissors and remove from brushroll� See Nozzle Maintenance section for
more information�
Vacuum lifts area rugs�
• Make sure Power/Surface switch is set to Hard Floor (setting I)�
• Ensure the suction control slider on the handle is set to MIN�
• Suction is powerful� Take care when vacuuming area rugs or rugs with delicately sewn edges�
Brushrolls do not spin in carpet cleaning mode�
• If the headlight indicator light turns red, immediately turn o and unplug the vacuum�
Remove pod from floor nozzle and clear any blockages� Reconnect nozzle, plug in vacuum,
and turn on power�
• With the power on, recline the handle, which will automatically turn on the brushrolls�
• If this problem persists on thick carpets, move the suction control slider to MIN�
Vacuum turns o on its own or headlight indicator lights flash red�
If your vacuum overheats, the thermostat will automatically turn o the motor� Perform the
following steps to restart:
1� Turn vacuum o and unplug it�
2� Empty dust cup and clean filters� See Emptying the Dust Cup and Cleaning and Replacing
the Filters sections for more information�
3� Check for blockages in hose, wand, floor nozzle, accessories, and inlet openings�
4� Allow unit to cool for a minimum of 60 minutes�
5� Plug in vacuum and turn it on�
Vacuum is emitting air that smells bad�
• Dust cup may be full; empty dust cup� Empty dust cup after each use for optimal Anti-
Odour Technology performance�
• Check filters to see if they need cleaning� Follow instructions for rinsing and air-drying the
filters before reinstalling them�
• Check to make sure Odour cartridge is installed in the dial and the dial is installed in the
nozzle�
• Check the Anti-Odour Technology dial on the nozzle to see what setting is enabled�
• If Anti-Odour Technology dial is at any setting from Low to High and the cartridge has been
installed for 6 months or longer, consider replacing it�
• If the Odour cartridge is still emitting a scent but you dislike it, consider turning the intensity
down, or reinstall the dial in the nozzle without the cartridge�
• If the Anti-Odour Technology cartridge is not emitting a scent, consider replacing it�
For all other issues, please go to support�sharkclean.co.uk or call Customer Service 1-800-798-7398�
AVAILABLE ACCESSORIES
D
F
G
I
E
C
B
A
Crevice Tool
This slender tool oers extended reach to
access corners, baseboards, tight spaces,
and ceilings�
B
Upholstery Tool
Picks up hair, dust, and large debris from
mattresses, couches, curtains, lampshades,
and other delicate upholstered fabrics�
C
Multi-Surface Tool
A single convertible tool for cleaning tough
pet messes two ways: use the sti bristle
brush to clean stuck-on debris, or take o
the bristles to reveal an upholstery tool
perfect for removing stubborn pet hair and
large piles of debris�
D
Duster Crevice Tool
Two cleaning tools in one� The crevice tool
gives you extended reach to clean in tight
spaces, while the soft brush is ideal for
dusting delicate surfaces�
E
Pet Power Brush
The turbine brush loosens and removes
pet hair and debris from carpets, and
powerfully deep-cleans dander out of
upholstery and other surfaces�
F
Under-Appliance Wand
Clean under and behind hard-to-move
appliances and furniture with this adjustable
36” tool� Flip the extension piece over to
clean the underside of appliances�
G
Anti-Allergen Dust Brush
This brush features nylon fiber bristles
specifically designed for removing fine
dust and allergen particles from the most
delicate surfaces�
H
Pet Power Brush with Anti Hair Wrap Plus
Tackles pet hair and ground-in dirt from
above-floor areas like carpeted stairs and
upholstery, while actively removing hair
wrap as it cleans�
I
Home & Car Detail Kit
Deep-clean your car like a professional
detailer, or clean hard-to-reach areas in
your home� Micro-sized tools let you clean
around delicate objects and access the
tightest spaces like car vents and computer
keyboards�
A
H
sharkclean.co.uk
21
sharkclean.co.uk
20
When a consumer buys a product in the UK, they get the benefit of legal rights relating to the quality of the
product (your “statutory rights”). You can enforce these rights against your retailer. However, at Shark® we are
so confident about the quality of our products that we give you an additional manufacturer’s warranty of up to
five years (one year as standard, plus a further four years upon registration with Shark®). Oer valid only in
United Kingdom and Republic of Ireland. These terms and conditions relate to our manufacturer’s guarantee
only – your statutory rights are unaected.
The conditions below describe the prerequisites and scope of our guarantee.
Shark
®
Guarantees
A household appliance like a vacuum cleaner constitutes a sizeable investment. Your new machine needs
to work properly for as long as possible. The guarantee it comes with is an important consideration - and
reflects how much confidence the manufacturer has in its product and manufacturing quality.
Every Shark® machine comes with a free parts and labour guarantee. Our customer service helpline
(0800 862 0453) is open from 9.00am to 6.00pm Monday - Friday. It’s free to call, and you’ll be put straight
through to a Shark® representative. You’ll also find online support at sharkclean.co.uk.
How do I register my extended Shark
®
guarantee?
If you have purchased your vacuum directly from sharkclean.co.uk your guarantee is registered automatically.
You can also register your guarantee at sharkclean.co.uk within 28 days of purchase. To save time, you’ll need
the following information about your machine:
• Date you purchased the machine (receipt or delivery note)
• Model Number
IMPORTANT
• Your guarantee will only cover your product from the date of purchase.
• Please keep your receipt at all times. Should you need to use your guarantee we will need your receipt
to verify the information you have supplied to us is correct. The inability to produce a valid receipt may
invalidate your ability to claim against your guarantee.
What are the benefits of registering my free Shark
®
guarantee?
When you register your guarantee we’ll have your details to hand if we ever need to get in touch. You can also
receive tips and advice on how to get the best out of your Shark® vacuum and hear the latest news about new
Shark
®
technology and launches.
If you register your guarantee online, you’ll get instant confirmation that we’ve received your details.
How long are new Shark
®
machines guaranteed for?
Our confidence in our design and quality control means that your new Shark® vacuum cleaner is guaranteed
for a total of up to five years (1 year plus an extended guarantee of 4 years on registration).
What is covered by the free Shark
®
guarantee?
At Shark’s discretion repair or replacement of your Shark® machine, including all parts and labour. A Shark®
guarantee is in addition to your legal rights as a consumer.
What is not covered by the free Shark
®
guarantee?
• Blockages – for details of how to unblock your vacuum cleaner, please refer to the Operating Manual.
• Normal wear and tear such as brush bar, fuse, belt etc.
• Accidental damage, faults caused by negligent use or care, misuse, neglect, careless operation or
handling of the vacuum cleaner which is not in accordance with the Shark® Operating Manual supplied
with your machine.
• Use of the vacuum cleaner for anything other than normal domestic household purposes.
• Use of parts not assembled or installed in accordance with the operating instructions.
• Use of parts and accessories which are not Shark® Genuine Components.
• Faulty installation (except where installed by Shark®).
• Repairs or alterations carried out by parties other than Shark® or its agents.
What happens when my guarantee runs out?
Shark® does not design products to last for a limited time. We do appreciate that there may be a desire for
our customers to want to repair their vacuum cleaners after the guarantee has lapsed. In this case please
contact our Freephone customer service help line and ask about our out of guarantee program,
on 0800 862 0453.
Where can I buy genuine Shark
®
spares and accessories?
Shark® spares and accessories are developed by the same engineers who developed your Shark® vacuum.
You’ll find a full range of accessories, spares and replacement parts for all Shark® machines at sharkclean.co.uk
Only use Shark® branded filters and accessories. Damage caused by use of non-Shark parts may not be
covered by your guarantee.
FIVE (5)YEAR LIMITED GUARANTEE
NOTES
© 2024 SharkNinja Operating LLC, LIFT-AWAY, POWERFINS, and SHARK are registered trademarks of SharkNinja
Operating LLC�
NZ780UKT_IB_MP_Mv1_240703
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE�
This Owner’s Guide is designed to help you get a complete understanding of your new Shark Lift-Away with
Anti-Hair Wrap Plus and Anti-Odour Technology Upright Vacuum�
Illustrations may dier from actual product� We are constantly striving to improve our products; therefore the
specifications contained herein are subject to change without notice�
SharkNinja Europe Limited,
1st/2nd Floor Building 3150,
Thorpe Park, Century Way,
Leeds, England, LS15 8ZB, UK
+44 (0)800 862 0453
www�sharkclean�co�uk
SharkNinja Germany GmbH,
Rotfeder-Ring-9,
60327 Frankfurt am Main,
Germany
www�sharkclean�eu
