User Manual
Manual Espresso Machine with
Integrated Milk Frother
CEP 5302 B
01M-8919243200-1125-01
EN
2 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
ENGLISH 3-17
CONTENTS
Please read this user manual first!
Dear Customer,
Thank you for selecting this Beko product. We hope that you get the best results from your product, which
has been manufactured to a high quality with state-of-the-art technology. Please read this entire user
manual and all other accompanying documents carefully before using the product and keep them as a
reference for future use. If you pass on the product to someone else, please give them the user manual
as well. Please take into consideration all warnings and information in the user manual.
Explanation of symbols
The following symbols are used in the various section of this manual:
C
Important information or useful hints about usage.
A
DANGER: This warning for dangerous situations with regard to life and property.
A
WARNING: This warning indicates potentially dangerous situations.
A
CAUTION: This warning indicates the potential for material damage.
Materials are suitable for food contact
4 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
This section includes the safety instructions that
will help providing protection against personal
injury and material loss risks. Failure to follow these
instructions invalidates the granted warranty.
1.1 Danger of electric current
Danger to life by electric current!
Contact with live wires or components could lead to
serious injury or even death!
Observe the following safety precautions to avoid
electric shocks:
•
Do not use the coffee machine if the connecting
cable or mains plug are damaged.
•
Before reusing the coffee machine, the mains cable
must be renewed by a qualified electrician.
•
Do not open the housing of the coffee machine.
Danger of electric shock if live connections are
touched and/or the electrical and mechanical
configuration is changed.
1.2 Danger of burning or scalding
Parts of the coffee machine can become very hot
during operation! Dispensed drinks and escaping
steam are very hot!
Observe the following safety precautions to avoid
burning/scalding yourself and/or others:
•
Do not touch either of the metal sleeves on both
coffee spouts.
•
Avoid direct contact of the skin with escaping
steam or hot rinsing, cleaning and descaling
water.
1.3 Fundamental safety
precautions
Observe the following safety precautions to ensure
safe handling of the coffee machine:
•
Never play with packaging material. Risk of
suffocation.
•
Inspect the coffee machine for visible signs
of damage before use. Do not use a damaged
coffee machine.
•
If the supply cord is damaged, it must be replaced
by the manufacturer or its agent or similarly
qualified person in order to avoid hazard.
•
Repairs to the coffee machine must only be
carried out by an authorised specialist or by the
works customer service. Unqualified repairs can
lead to considerable danger for the user. They
will also void the warranty.
•
Repairs to the coffee machine during the
warranty period may only be carried out by
service centres authorised by the manufacturer,
otherwise the warranty will become void in the
event of subsequent damage.
•
Defective parts may only be replaced with
original spare parts. Only original spare parts
guarantee that the safety requirements are met.
•
Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the appliance in a safe way and understand the
hazards involved.
•
This appliance can be used by children aged
from 8 years and above if they have been given
supervision or instruction concerning use of the
appliance in a safe way and if they understand the
hazards involved. Cleaning and user maintenance
shall not be made by children unless they are
older than 8 and supervised. Keep the appliance
and its cord out of reach of children aged less
than 8 years.
•
Children shall not play with the appliance.
•
This appliance is intended to be used in
household and similar applications such as:
-staff kitchen areas in shops, offices and other
working environments;
-farm houses;
-by clients in hotels, motels and other residential
environments;
-bed and breakfast type environments.
•
Protect the coffee machine against the effects of
weather such as rain, frost and direct sunlight. Do
not use the coffee machine outdoors.
•
The appliance must not be immersed.
•
Do not clean the coffee machine or accessories in
a dish washer.
•
Do not pour any other liquids apart from water or
place foodstuffs into the water tank.
•
Do not fill the water tank beyond the maximum
mark (lower edge of the filling hole) (1.1 litres).
1 Important instructions for safety and environment
5 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
•
Only operate the machine when the waste
container, drip tray and the cup grate are fitted.
•
Do not pull the cable to remove the plug from the
mains socket or touch with wet hands.
•
Do not hold the coffee machine with the mains
cable.
•
Keep the appliance and its cord out of reach of
children aged less than 8 years.
•
Before removing the water tank to fill or empty it,
always turn the machine off.
•
Always place the unit on a flat, stable, heat-
resistant work surface.
•
Before brewing, the portafilter must be turned to the
right as tight as possible to prevent the portafilter
from loosening due to high pressure.
•
Serious injury may result from misuse. To protect
against a fire, electric shock or personal injury,
do not immerse cord, electric plugs, heating
base in water or other liquids. Do not operate
any appliance with a damaged cord or plug,
after the appliance malfunctions, or is dropped
or damaged in any manner. Please contact the
manufacturer or his customer service.
•
Heating element surface is subject to residual
heat after use, do not touch the hot surface, use
the handle or the button. Always keep hands
out of container and machine while in use and
afterward to reduce the risk of injury to persons.
•
Coffee-maker shall not be placed in a cabinet
when in use.
•
Cleaning: Do not place the appliance in water
or other liquids. Clean the housing only with a
sponge/cloth moistened in warm, soapy water.
Do not use harsh, abrasive cleaners. See chapter
6 for detailed cleaning instructions.
1.4 Intended use
The manual espresso machine Beko is intended for
use in homes and similar applications, for instance
in staff kitchens, shops, offices and similar areas
or by customers in bed & breakfast, hotels, motels
and other living accommodation. This coffee
machine is not intended for commercial use. The
machine is only intended for preparing coffee and
heating milk and water. Any other use other than
previously stated is considered as improper use.
Danger resulting from improper use!
If not used for its intended purpose or used in any
other way, the coffee machine may be or become a
source of danger.
A
• Therefore, the coffee machine
may only be used for its
intended purpose.
• Observe the procedures
described in this user manual.
No claims of any kind will be accepted for damage
or injury resulting from use of the coffee machine
for other than its intended purpose.
The risk has to be borne solely by the machine
owner.
1.5 Limitation of liability
All technical information, data and instructions
on installation, operation and maintenance of
the coffee machine contained in these operating
instructions represent the current status at the
time of printing and are based on the best possible
knowledge gained by experience and knowhow.
No claims can be derived from the information,
illustrations and descriptions in this user manual.
The manufacturer assumes no liability for damage
or injury resulting from failure to observe the user
manual, use for other than the intended purpose,
unprofessional repairs, unauthorised modifications
or use of non-approved spare parts.
1 Important instructions for safety and environment
6 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
1.6 Compliance with the WEEE
Directive and Disposing of the
Waste Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classification
symbol for waste electrical and electronic
equipment (WEEE).
This symbol indicates that this product
shall not be disposed with other
household waste at the end of its
service life. The used device must be
returned to an offical collection point for
the recycling of electrical and electronic
devices. To find these collection points, please
contact your local authority or retailer where the
product was purchased. Each household performs
an important role in the restoring and recycling of
old appliances. The appropriate disposal of used
appliance helps prevent potential negative
consequences for the environment and human
health.
1.7 Compliance with RoHS
Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
1.8 Package information
The packaging materials of the product
were manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials together
with domestic or other waste. Take them to the
packaging materials collection points designated
by local authorities
1 Important instructions for safety and environment
7 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
All declared values on the product and on the printed leaflets are picked up after laboratory measurements performed ac-
cording to related standarts. These values may differ upon usage and ambient conditions.
2 Overview & Control panel
1. Control panel
2. Portafilter
3. Drip tray grid
4. Floater
5. Drip tray
6. Water tank lid
7. Water tank
8. Steam/Hot Water Control Knob
9. Milk frother
10. Milk frother Cover
11. Single espresso basket
12. Double espresso basket
13. Coffee Scoop / Tamper
1
6
7
8
9
10
11
12
13
2
3
4
5
1
2
3
4 5
2.1 Control Panel
1
Pre-heating indicator
2
On/off & cancel button
3
General error
4
Cleaning and descaling
button
5
Steam button
8 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
3 Technical data
Power supply: 220-240 V~, 50-60 Hz
Power: 1376 - 1628 W
The right to make technical and design changes is
reserved.
All declared values on the product and on the
printed leaflets were obtained from laboratory
measurements performed according to the relevant
standards. These values may differ depending on
usage and ambient conditions.
Product Dimensions:
14,4 cm (Width) x 30,8 cm (Height) x 42,3 cm (Depth)
[Depth w/out portafilter 32,5 cm]
Weight: 3.85±0.5kg
Cable Length: >90 cm
Basket Capacities
Single: 8g
Double: 15g
Drip Tray Capacity: Up to 0.2 L
Water Tank Capacity: 1.1±5%L
Machine Pre-heating time: <55s
Volume of coffee (Default settings):
Espresso: 30-55ml
Double: 65-95ml
This button " " will light up as orange when machine needs descaling.
• If knob is in wrong position during machine turn on or if maximum frothing duration is
reached; the red error led will blink with the steam which means steam control knob (9)
should be rotated towards closed position.
• If there is an NTC error, the red error indicator will be lit and there will be no response if any
button is pressed. Call customer service for support.
9 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
4 Preparation
4.1 First Time Use
Remove any protective films, stickers and any other packaging material from the appliance.
150mm
1
2
3
2
150mm
150mm
.
150mm
3
1
Choose a safe and stable sur-
face with an easily reachable
power supply and allow the
minimum distance from the
sides of the machines.
Fill the water tank with fresh,
cold pure water at least up to
the MIN marking and at most
up to the MAX marking. (Do not
add hot water)
Then insert tank on to the ma-
chine and the other end of the
power cord into a wall socket
with the suitable power voltage.
The power on/off button " " on
the control panel will light up.
Press that button to turn on the
machine. Put a cup right under
the brewing head and press the
cleaning button " ". The ma-
chine will sound one beep and
start cleaning. Once complet-
ed the machine will be ready to
use.
10 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
4.2 Brewing Single / Double Espresso
.
beeps
3
2
1
Place the single or double
espresso basket into the filter
holder. Fill the freshly ground
coffee powder into the fil-
ter with measuring spoon (ap-
prox. 7-14g) and use the spoon
to flatten the excess powder.
With the tamping end of the
spoon, apply around 15 kg to
push down the powder even
and firmly.
Install the portafilter under the
coffee outlet. Align it with the
unlock symbol, slide it into the
groove, and slowly rotate it to
the right to the lock symbol.
- Place a coffee cup right under
the coffee outlet.
- Press the single or double
button and a beep will sound.
- Selected coffee will start
blinking and the beverage prep-
aration will begin.
After brewing is completed, ma-
chine will sound one beep and
enter idle mode. Remove the
portafilter clockwise. Clean the
portafilter and dry it after each
use.
• Wait 5 seconds after brewing and then take out the filter. This will help remove the moving
filter easily.
• Coffee powder cannot be used after brewing.
• Use the handle extension to knock the coffee residue out while keeping the basket in place.
• To ensure your espresso stays at optimum temperature, we recommend that you preheat
your cups.
• To extract the fullest flavor from your coffee beans, we recommend using whole coffee
beans that have been freshly ground each time espresso is prepared.
• In addition to the coffee used, using fresh cold water that is free of chlorine, odors and other
impurities will help ensure the perfect espresso.
• Store your espresso grounds in an airtight container, and in a cool, dry place to retain the
flavor. Grounds should not be kept for long periods of time as the flavor will be reduced.
4 Preparation
11 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
4 Preparation
4.3 Preparing Frothy Milk for Coffee
In order to make beverages that require milk such as cappuccino, latte and more; milk frother should be
used to froth milk. Simply add frothed milk over one or two shots of espresso based on your preference.
.
Press milk frother icon and wait
for milk frother to be ready.
While milk frother is pre-heat-
ing the indicator lights will flash.
Once ready, " " will be con-
stantly lit.
Place a milk filled cup or pitcher
under the milk frother. Turn the
knob into on position and froth
until desired temperature/foam
is obtained. To stop, turn back
the knob into initial position.
Pour the hot frothy milk onto
the espresso. You can now en-
joy your coffee!
Milk frother can be rotated towards
the right for easier handling purposes.
• After using the milk frother, please clean the nozzle of milk residue by wiping the nozzle
with the wet cloth.
• The maximum duration for single use frothing is 90s.
Be aware that the cup/pitcher and milk frother can get hot during milk
frothing. Please only hold the black protector after using steam function.
• Considering the milk frothing inside the cup/pitcher, do not fill it entirely.
• Do not pull away the cup/pitcher without stopping the frothing process.
• Turn the steam knob into off position before turning off the device and do not turn the
steam knob into on position when the device the turned off.
12 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
4.4 Hot Water Function
The appliance can dispense hot water by simply turning the steam/hot water knob into "on" position in
idle stage " "
• This function can be used to heat up the cup before coffee preparation. First fill the cup with
hot water, then pour away the water and use this cup for preparing coffee.
• Americano can be made by adding hot water over espresso.
If steam is recently used, it is suggested to wait for cool-down before using hot water function.
4.5 Adjusting Height for Different Cup Size
For bigger cups, drip tray (6) can be removed and machine base can be used.
If drip dray is removed for bigger cups, it should be placed back into the machine right after
beverage preparation is completed. If drip tray is not placed back after beverage preparation,
due to internal system release, water might come to the base and would need a manual
cleaning with dry cloth.
4 Preparation
13 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
5 Operation and use
5.1 Adjusting the Volume of your Coffee
Setting amounts for Single & Double Espresso
1. Select the function that is to be reprogrammed. Press the appropriate button (single or double
espresso) and keep it held down. You will hear one beep. [single/double espresso programmable
amounts (min: 30/60ml, max: 50/100ml)]
2. Only let go of the button once the desired amount of coffee has passed through. You will hear two
beeps. This amount is now saved under the corresponding function.
The adjusted beverage settings will be saved to device memory for future use until resetted or
changed again.
To reset single beverage to default/factory setting:
Press and hold down any beverage and power buttons together for
more than 3 seconds to reset the selected beverage amount.
To reset all beverages to default/factory setting:
Press and hold down single and double espresso buttons together
for more than 3 seconds to reset the all beverage amount.
Standby time: The machine will automatically shut down after 29 minutes without any
operation (or after work).
5.2 Cancelling
On-off button should be pressed once to cancel any running process.
14 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
6.1 Cleaning the Milk Frother
Use the hot water function to remove any milk residue that may accumulate on the tip of the milk frother.
The milk frother cover can be detached and cleaned under water.
Clean inside the milk frother with wet cloth after each use to avoid milk
residue and ensure full frothing performance.
6.2 Cleaning/Rinsing Function
For cleaning the brewing head, place a container under the brewing head and press the cleaning button
" ". Cleaning will be completed within 16 seconds and the machine will be ready to use.
• If you do not use the machine for more than 5 consecutive days, rinse and drain the water
tank.
• Drip tray and its grid (6) (4) can be cleaned manually under clean water.
• Do not put the portafilter into the dishwasher.
6.3 Descale Function
When descaling is required, descale icon " " will light up as orange. Place a container that can hold 1.5L
under the brewing head. Pour water into the water tank until MAX level and mix with scale remover or
citric acid. Press & hold descale button " " for more than 3 seconds and you will hear two beep sounds
which indicates that the first cycle of descaling has begun. The first cycle will take around 15 minutes.
Once completed, the descale icon will turn white " ".
Empty and replace the container under the brewing head. Clean and fill water tank until MAX level with
clean water. Press & hold descale button " " for more than 3 seconds and you will hear two beep
sounds which indicates that the second cycle of descaling has begun. The second cycle will take around
6 minutes. Once all complete, the machine will go back to idle stage and will be ready to use.
To reset descale warning status:
Press and hold power and descale button together for more than
3 seconds.
• Descale is required after predefined brewing cycle.
• Resetting descaling warning status is not suggested for maintaining the best condition of
the appliance.
6 Cleaning
15 / EN
Manual Espresso Machine with Integrated Milk Frother / User Manual
7.1 Problems, possible causes and remedies
Problem Cause Remedy
Coffee runs down
the side of the
portafilter.
Portafilter (2) is not properly
inserted.
Turn the handle of the portafilter (2) further to the right.
Edge of sieve is not free of
ground coffee
Turn off the machine, remove the portafilter (2) holder and clean
the
edges of the sieve.
Screen inside brew head
is dirty.
Clean the brew head using a wet cloth and run the cleaning
function without placing the portafilter.
Very little or no
coffee flows
through the
portafilter.
No water in tank. Fill the tank with water.
The screen inside the brew
head is blocked.
Brew water through the screen without the portafilter (2)
inserted. If no water comes through, unscrew the screen, clean
and replace.
The sieve is blocked. Correction: Clean the sieve, insert into the portafilter (2) and
pump water through without coffee. If no water comes through
the sieve call Customer Service to order a replacement sieve.
Pump does not work due to
device operating with empty
water tank.
Turn on the steam/hot water knob for 2 seconds and then turn
it off. Then press the coffee program and the water pump will
work normally.
Espresso brews
out only as drops.
Coffee grounds are too fine
or packed down too firmly.
Do not tamp coffee grounds so firmly. Use a coarser grind of
coffee.
Machine blocked by cal-
cium deposits.
Descale the appliance. See page 15.
Espresso brews
too quickly.
Ground coffee is too coarse. Use a finer grind.
Not enough coffee in the
sieve.
Use more ground coffee.
No crema.
Coffee old or too dry. Use fresh coffee.
Coffee not pushed down
firmly enough. Water
pushes through the coffee
too fast.
Tamp coffee grounds more firmly. Use a finer grind.
Coffee too coarse.
Use a conical burr grinder to obtain a finer and more consistent
grind.
Coffee blend not suited to
espresso coffee.
Change brand of espresso.
Not enough froth
when frothing
milk.
Milk not fresh. Use fresh milk.
Milk not suitable. Check that the milk is suitable for frothing.
Milk was too warm from
the start.
Use milk straight from the refrigerator (34°F).
Not enough milk to froth. Use more cold milk.
No steam from
milk frother.
Milk inlet hole is blocked.
See “Cleaning the Milk Frother”. If it is clear of dried milk deposits
but no steam comes out, then use the descaling function. If the
appliance is still blocked, call Customer Service.
7 Troubleshooting
EN-Additional Information for User Manual:
Technical information on the operating Low Power Modes pursuant to EU Regulation 2023/826
Mode POWER CONSUMPTION(WATT) PERIOD(MINUTES)*
Off 0,5 30
Standby - -
Standby Mode with information or status display - -
Networked Standby - -
*:The period after which the equipment reaches automatically standby mode, off mode or networked standby in minutes and rounded to the nearest minute.
55 Blanck Street, Ormeau Q 4208
P O Box 354, Ormeau Q 4208
p : 5549 3146 f : 5549 3546
ABN : 49 152 055 162
Sensitivity: Public
ORIGINAL MANUFACTURER’S WARRANTY
ADVICE FORM
BEKO COFFEE MACHINE
24 months warranty, full parts and labour warranty only.
WARRANTY CONDITIONS
The following conditions apply only in relations to the warranty expressly given on this Warranty Advice Form supplied with the product. This
warranty only applies to appliances purchased and used in Australia or New Zealand and is in addition to (and does not exclude, restrict or
modify in any way) other rights and remedies under a law to which the appliances relate, including any non-excludable statutory guarantees in
Australia and New Zealand. It applies to the original purchaser and for appliances used in domestic applications only.
1. This warranty does not apply:
(a) if the identification number attached to the appliance has been altered, rendered illegible or removed;
(b) to light globes;
(c) to paint and vitreous enamel finishes and glass;
(d) to surfaces damaged by use of aerosols or cleaners;
(e) if the appliance has been –
(i) subject to misuse, abuse, negligence, accident, fire or floods;
(ii) connected or improper, inadequate or faulty electricity, gas, water or drainage services or intake or exhaust
ducts or flues, or operated using incorrect or contaminated fuels or lubricants;
(iii) installed, maintained or operated otherwise than in accordance with the instructions furnished by Beko including the
improper use of detergents, bleaches, cleaners or other additives;
(iv) damaged by foreign objects in the appliance;
(v) serviced, repaired or altered otherwise than by Beko authorised service agents of Beko, or using other than Beko
approved replacement parts.
2. The purchaser shall be responsible for any expenses involved in making the appliances readily accessible for servicing, the purchaser
shall be responsible for any costs of transporting the appliance or parts thereof to and from the nearest Beko authorised service agent.
3. This warranty is the only expressed warranty given by Beko.
4. Beko reserves the right to determine whether or not the fault is caused by faulty workmanship or material or that any part is defective.
5. Where permitted by law, this warranty shall not apply to loss suffered through or resulting from the non-operation or the ineffective
operation of the appliance or any part of the appliance.
6. The purchaser must produce proof of the date of purchase together with this Warranty Advise Form when making a claim.
7. Subject to your statutory rights as to the merchantable quality of the product or accessory. In the event of a product or accessory being
replaced during the guarantee, the guarantee on the replacement will expire at the original date, i.e., 24 months from the original
purchase date.
8. Australia: For Appliances and services provided by Beko in Australia, Beko goods come with a guarantee by Beko that cannot be
excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the Appliance repaired or replaced if the Appliance
fails to be of acceptable quality and the failure does not amount to a major failure. ‘Acceptable quality’ and ‘major failure’ have the
same meaning as referred to in the Australian Consumer Law.
9. New Zealand: For Appliances and services provided by Beko in New Zealand, the Appliances come with a guarantee by Beko
pursuant to the provisions of the Consumer Guarantees Act, the Sales of Goods Act and the Fair Trading Act. Where the Appliance
was purchased in New Zealand for commercial purposes the Consumer Guarantee Act does not apply.
These Warranty Conditions supersedes and excludes all other representations, conditions and warranties, except those implied
by legislation previously referred to.
For Service or Spare Parts: Aust 1300 282 356 NZ 0800 692 356
Beko A&NZ Pty Ltd
55 Blanck Street , Ormeau QLD,
4208 AUSTRALIA
www.beko.com.au
