User Manual
AINT8900FD
Integrated Refrigerator
AINT8900FDI
Please read this manual before using the product!
Dear Valued Customer,
We wish you to get the best results from your product that has been
manufactured meticulously at modern plants and tested with detailed
quality control checks.
For this reason, we recommend that you read this user manual
thoroughly before starting the product.
If you hand over the product to someone else, please remember
to give the user manual as well.
This manual will help you use your appliance in a fast and safe way.
•
Please read this user manual carefully before installing and using the product.
•
Always follow the applicable safety instructions.
•
Keep the user manual in an easily accessible place for further use.
•
Please read all the other documents provided with the product.
Please keep in mind that this manual may apply to several product models.
This manual expressly indicates the differences between various models
A
Risk of injury and property damage.
B
Risk of electric shock.
C
Important information and useful hints.
Packaging materials of this product has been
manufactured from recyclable materials in
accordance with the National Environment
Regulations.
1ImportantInstructions RegardingSafetyand Environment
This chapter contains safety information that will help you avoid the risk
personal injury or property damage. Failure to follow these instructions shall
render any product warranty void.
1.1
General Safety
•
This product can be used by children at age 8 and above and those people
who have limited physical, sensory or mental capabilities and people
who lack experience and information on the condition that they have been
given the instructions about the safe use of the product,
they are supervised and the risks have been eliminated.
Children should not play with the product.
Cleaning and care should not be performed by children unless
they are supervised by an adult.
•
Unplug the product if you encounter a failure during use.
•
If the product malfunctions, it must not be operated until repaired
by the authorized service provider. Risk of electric shock!
•
Plug the product into a grounded socket protected by a fuse
that corresponds to the value on its nameplate.
Have a qualified electrician ground the product.
Our company cannot be held responsible for damages resulting
from the failure to use the product with a grounded socket pursuant
to local regulations.
•
Unplug the product when not in use.
•
Never wash the product by spreading or
pouring water onto it! Risk of electric shock!
•
Never touch the plug with wet hands!
•
Never unplug the product by pulling the cable.
Always pull the plug by holding the socket
•
Do not plug the refrigerator if the wall socket is loose.
•
Never connect your refrigerator to energy saving devices.
•
Such systems are harmful to your product.
•
Unplug the product during installation, care, cleaning and repairing procedures.
•
Always have the Authorized Service Provider install the product and
establish its electrical connections.
The manufacturer cannot be held responsible for damages caused
by procedures performed by unauthorized persons.
•
Do not eat cone ice cream or ice cubes immediately after you take them
out of the freezer compartment! This may cause frostbite in your mouth!
•
Do not touch frozen food with wet hands! They may stick to your hand!
•
Do not put bottled or canned liquid beverages in the freezer compartment.
They may burst!
1ImportantInstructions RegardingSafetyand Environment
•
Never use steam or steam cleaners to clean or defrost the refrigerator.
Steam gets into contact with the live parts in your refrigerator,
causing short circuit or electric shock!
•
"
DANGER
– Risk of fire or explosion. Flammable refrigerant used. Do not use
mechanical devices to defrost refrigerator.
Do not puncture refrigerant tubing.
•
Never use the parts in your refrigerator such as the door and drawer
as a means of support or step.
This may cause the product to tip over or damage the parts of it.
•
Do not damage the parts where the refrigerant is circulating with drilling
or cutting tools.
The refrigerant that might blow out when the gas channels of
the evaporator, pipe extensions or surface coatings are punctured causes
skin irritations and eye injuries.
•
Do not cover or block the ventilation holes in your refrigerator with any object.
•
Place the beverage with higher proofs tightly closed and vertically.
•
Do not use gaseous sprays near the product since there is the risk or
fire or explosion!
•
Flammable items or products that contain flammable gases (e.g. spray)
as well as explosive materials should never be kept in the appliance.
•
Do not place vessels filled with liquid onto the product. Splashing water
on an electrical part may cause electric chock or the risk of fire.
•
Do not store items that need precise temperature adjustment
(such as vaccines, heat-sensitive medication, science materials etc.)
in the refrigerator.
•
If you are not going to use the product for a long time, unplug it
and remove the food in it.
•
If there is a blue light on the refrigerator, do not look at this light with optical tools.
•
Exposing the product to rain, snow, sun or wind is dangerous in terms of
electrical safety.
•
In products with mechanical control (thermostat), wait for 5 minutes
to plug in the product again after unplugging.
•
Do not overload the refrigerator. Objects in the refrigerator may fall down
when the door is opened, causing injury or damage.
Similar problems may arise if any object is placed onto the product.
•
If the product has a door handle, do not pull the handle
when re-locating the product. The handle might be loose.
•
Be careful not to jam your hand or any other body part in the moving parts
of the refrigerator.
•
Do not put your hand or any other foreign materials into the ice machine
while it is operating.
1ImportantInstructions RegardingSafetyand Environment
1.2
Intended Use
•
This product has been designed for domestic use. It is not suitable
for commercial use and it must not be used out of its intended use.
•
It must be used only for storing food.
•
The manufacturer will not take any responsibility for damages resulting
from improper use or transport.
•
Original spare parts will be available for 10 years after the purchase date
of the product.
1.3
Children's Safety
•
“CAUTION - To Prevent A Child From Being Entrapped, Keep Out Of Reach Of
Children And Not In The Vicinity Of Freezer (Or Refrigerator).”
•
If there is a lock on the door of the product, the key should be kept
out of the reach of children.
•
Do not let children play with the product.
A
WARNING:
Risk of child entrapment. Before you throw away your
old refrigerator or freezer:
•
Take off the doors.
•
* Leave the shelves in place so that children may not
easily climb inside.
1.4
Compliance with the WEEE Directive and Disposing the Waste Product:
This product conforms to the EU WEE Directive (2012/19 EU).
This product bears a classification symbol for waste electrical and
electronic equipment (WEEE).
This product has been manufactured from high quality parts and materials
which can be reused and are suitable for recycling.
Therefore, do not dispose the product with normal domestic waste or
other waste at the end of its service life.
Take it to a collection center for recycling electrical and
electronic equipment.
Please consult local authorities to learn about the locations
of such collection center.
1ImportantInstructions RegardingSafetyand Environment
1.5
Compliance with the RoHS Directive:
The unit you have purchased conforms to the EU RoHS Directive (2011/65/AB).
It does not contain harmful or prohibited materials specified in the Directive.
1.6
Packaging Information
•
Packaging materials of the product have been manufactured from recyclable
materials in accordance with our National Environment Regulations.
•
Do not dispose the packaging materials with normal domestic waste
or other types of waste.
•
Take these materials to a recycling point designated by local authorities
A
DANGER:
Risk of Fire or Explosion:
•
This product uses flammable refrigerant.
•
Do not use mechanical devices to defrost
the refrigerator.
•
Do not use chemicals for cleaning.
•
Do not pierce the refrigerant pipe.
•
If the refrigerant pipe is pierced, it must be repaired
only by licensed service personnel.
•
Please consult the repair/user manual
before cleaning the product.
All safety instructions must be followed.
•
Dispose the product according to federal or
local regulations
1.7
Hydrocarbon (HC) Warning
•
If your product's cooling system contains R-600a.
This gas is flammable.
Therefore, pay attention not to damage the cooling system or
the piping during use and transportation.
•
If damaged, keep the product away from potential fire sources that
may cause it to catch fire and ventilate the room where the product is placed.
1ImportantInstructions RegardingSafetyand Environment
C
If the product is damaged and if you see gas leak,
please keep away from the gas. It may cause frostbite
when it gets into contact with the skin. (including R134
C
Ignore this warning if the cooling system of your product
contains R134a.
C
Type of gas used in the product is stated on the type
plate which is on the left wall inside the refrigerator.
A
WARNING:
Never throw the product into fire for disposal.
1.8
For Products with a Water Dispenser/Ice Machine
•
Operating pressure for cold water inlet is between 1-5.5 bars.
If the water pressure exceeds 80 psi (5.5 bars), install a pressure limiting
valve to your mains system.
•
If the mains pressure is lower than 1 bar, you can use an auxiliary pump
to compensate the low pressure.
•
If you do not know how to check the water pressure,
please consult a professional plumber.
•
If there is a risk of water impact in your installation, always use
a water impact protection equipment in that installation.
•
Please consult professional plumbers if you are not sure if there is
water impact in your installation.
•
Do not make installation on the hot water inlet.
•
Take the necessary measures against the freezing risk of the hoses.
•
The water temperature operating range must be 0.6°C (33°F) minimum
and 38°C (100°F) maximum.
A
WARNING:
Never connect the product to a cold water mains with a
pressure of 5.5 bars (80 psi) and above
2Refrigerator Components List
9
10
1.
Water filter (if applicable)
2.Lower drawer
3.
Middle drawer
4.
Upper drawer
5.Ice box
6.Crisper
7. Body shelf (adjustable height)
8.Control display
9.
Door bin
10.
Gallon door bin (adjustable height)
May not be available in all models
C
Figures in this user manual are schematic and may not
match the product exactly. If your product does not have
the relevant parts, the information applies to other
models.
8
7
6
5
4
3
2
1
3DisplayPanelSetUp Instructions
May not be available in all models
C
Figures in this user manual are schematic and may not
match the product exactly. If your product does not have
the relevant parts, the information applies to other
models.
3 DisplayPanel Set Up Instructions
SW1--selector button；SW2--function button；
SW3--power button ；SW4--temperature button
1.
Switching function
In the OFF state, press and hold the Power Button for 3 seconds, the
display will light up and enter the ON state;
In power-on state, non-locked mode, press and hold the power button
for 3 seconds, the display goes o ffand enters the power-o ffstate;
2.
Temperature setting function
Under the non-locked state, short operation of the “selection button ” to
select the corresponding temperature zone: reefer->Chiller->frozen-
>reefer 。。。。。。
At the same time, the digital tube flashes to show the set temperature of the
corresponding temperature zone, and the set temperature can be changed
”.
3.
Function Setting
Non-locked state, short operation “function
within 5 seconds by short operation of the “Temperature button
Refrigeration setting range: 2 ~ 8°C ;Chiller setting range: -1~3°C ;
Freezing setting range: -15~-25°C ;
No key operation within 5 seconds, the setting takes effect.
button ”, select the
corresponding function: Quick Cooling ->Holiday ->Quick Freezing -
> ECO ->Sabbath ->Ice-making ->Quick Cooling 。。。。。。
At the same time, the corresponding function icon flashes, and the
corresponding function is determined within 5 seconds by short operation of
the “ selection button ” .
->Quick Cooling (Refrigeration runs at 2 degrees for 24 hours and then exits
Quick Cooling and returns to the previous setting)
->Holiday (Refrigeration runs at 17 degrees, freezing runs at -18 degrees)
->Quick Freeze (Freezing runs at -25 degrees for 24 hours and then exits
Quick Freeze and returns to the previous setting)
->ECO (Refrigerate at 6 degrees, Freeze at -16 degrees)
->Sabbath (only the lights and sound are all off, the rest of the refrigerator
runs normally according to the default settings)
->Ice making (the icon of ice maker lights up to turn on the ice maker to make
ice automatically, the icon of ice maker goes out to stop making ice)
->Open door alarm: the door continues to open for 1 minute, start to alarm
all the time until the door is closed, manually touching any one of the
buttons will be canceled, and the alarm will be activated again after 1
minute.
SW2 SW1
SW3 SW4
3 DisplayPanel Set Up Instructions
4 Locked Unlocked
In the locked state, press and hold the SW1-“Select” key for 3 seconds to
enter the non-locked state，Lock icon off;
In the non-locked state, press and hold the SW1-“Select” key for 3 seconds to
enter the locked state，Lock icon display lit ;
5 key combination
->Operate the “function button ” + “temperature button ” at the same
time for 5 seconds to enter the forced frost mode;Refrigeration set
temperature blinking, frosting exit, then return to the original state
->Simultaneously operate the “function button ” + “Select button” for
5 seconds to enter the commercial mode ;at 5 °F (-15 °C) automatically，
Commercial icon light, only the compressor does not work, do not report
faults, without memory function
->Simultaneous operation of SW3-“Function” key + SW4-
“Temperature ” key for 3 seconds to enter Fahrenheit conversion
->WATER FILTER REPLACEMENT: The water filter symbol flashes to
prompt the user to replace the water filter. The set replacement time is 180
days，After the replacement is completed, press and hold SW1 (SELECT)
+ SW3 (POWER) at the same time for 3 seconds to reset.
6 Fault display
This appliance has ‘fault display & alarm’ function. Once the sensors got
fault, there are alarms displayed on the temperature displaying, the
appliance still cools but professional service engineer should be called and
check the appliance.
F1 – Sensor of reefer defrosting zone
C1 – Sensor of chiller zone
C2– Sensor of chiller defrosting zone
F4 – Sensor of freezer compartment
F5 – Sensor of freezer defrosting
F6 – Sensor of Ambient Temperature
1E – Refrigeration fan failure
2E – Freezer fan failure
3E – Condensing fan failure
CE – Malfunction of communications
dR – Open the door timeout
4BeforeUsingthe Refrigerator
3.1
Thingsto do for energy saving
A
Connecting your refrigerator to systems that save
energy is dangerous as they may cause damage on the
product.
•
Do not leave the doors of your refrigerator open for a long time.
•
Do not put hot food or drinks in your refrigerator.
•
Do not overload the refrigerator. Cooling capacity will fall
when the air circulation in the refrigerator is hindered.
•
Do not place the refrigerator in places subject to direct sunlight.
Install the product at least 30 cm away from heat sources such as hobs,
ovens, heater units and stoves and at least 5 cm away from electrical ovens.
•
Pay attention to store your food in refrigerator in closed containers.
•
You can remove the drawer shelf of the freezer compartment to fill
the freezer compartment with maximum amount of food.
The given energy consumption value of the refrigerator has been determined
with the freezer compartment shelf or the drawer removed and the refrigerator
filled with maximum amount of food.
There is no harm in using a shelf or drawer according to the shapes and
sizes of food to be frozen.
•
Thawing the frozen foods in the fridge compartment both saves energy
and reserves the quality of the foods
C
Temperature of the room where your refrigerator is
located should at least be 10ºC/50°F. Operating your
refrigerator under cooler conditions is not recommended
with regard to its efficiency
C
inside of your refrigerator must be cleaned thoroughly.
C
If two coolers are to be installed side by side, there
should be at least 4 cm distance between them
3.2
Recommendations About the Fresh Food Compartment
•
Make sure that the food does not touch the temperature sensor
in fresh food compartment. To allow the fresh food compartment
to keep its ideal storage temperature, the sensor must not be hindered by food.
•
Do not place hot foods or beverages inside the product.
4BeforeUsingthe Refrigerator
3.3
Initial use
Before using the product, make sure that all preparations have been made
in accordance with the instructions given in the "Important instructions
regarding safety and environment" and "Installation Instruction" chapters.
•
Clean the interior of the refrigerator as recommended in the “Maintenance
and cleaning” section. Before you start the refrigerator, make sure
that the interior is dry.
•
Plug the refrigerator in a grounded socket. The interior illumination is lit
when the door of the refrigerator is opened.
•
Operate the refrigerator for 6 hours without placing any food in it and
do not open its door unless it is necessary
C
You will hear a noise when the compressor starts up.
The liquids and gases sealed within the refrigeration
system may also give r ise to noise, even i f the
compressor is not running and this is quite normal.
C
Front edges of the refrigerator may feel warm.
This is normal.
These areas are designed to be warm
to avoid condensation.
5Operatingthe product
5.1
Dual Cooling System
Your refrigerator is equipped with two separate cooling systems
to cool the fresh food compartment and freezer compartment.
Thus, the air and odor in the fresh food compartment and
the frozen food compartment do not get mixed.
Thanks to these two separate cooling systems, cooling speed is much higher
than that of other refrigerators. Also additional power saving is provided
since the defrosting is performed separately.
5.2
Freezing Fresh Food
Wrap the foods or place them in a covered container before putting them
in the refrigerator.
•
Hot foods and beverages must cool down to the room temperature
before you put them in the refrigerator.
•
The foodstuff that you want to freeze must be fresh and in good quality.
•
Divided the food into portions according to your family's daily or
meal based consumption needs.
•
Pack the foods in an airtight manner to prevent them from drying even if
they are going to be stored for a short time.
•
Materials to be used for packaging must be tear-proof and resistant
to cold, humidity, odor, oils and acids and they must also be airtight.
Moreover, they must be well closed and they must be made
from easy-to-use materials that are suitable for deep-freezers.
•
Frozen food must be used immediately after they are thawed
and they should never be refrozen.
•
Do not freeze too large quantities of food at one time.
The quality of the food is best preserved when it is frozen right through
to the core as quickly as possible.
•
Placing warm food into the freezer compartment causes the cooling system
to operate continuously until the food is frozen solid.
5.3
Recommendations for Storing Frozen Food
•
Frozen foods you purchase must be stored according to the conditions and
temperature determined by the food manufacturer.
•
Note the following to ensure that the high quality achieved
by the frozen food manufacturer and the food retailer is maintained:
1.
Put packages in the freezer as quickly as possible after purchase.
2.
Make sure that the content of the package is labeled and dated.
3.
Check whether the "Use By" or "Best Before" date
on the packaging is expired or not.
5Operatingthe product
5.4
Placing the food
Freezer compartment
shelves
Various frozen food such as meat, fish,
ice cream, vegetables etc.
Egg tray
Eggs
Fridge compartment
shelves
Food in pans, covered plates and closed
containers
Door shelves of fridge
compartment
Small and packaged foods or beverages
(such as milk, fruit juice, beer and etc.)
Crisper
Vegetables and fruits
Special fridge
compartment
Delicatessen products
(cheese, butter, salami etc.)
5.5
Operating
temperature
Freezer
Fridge
Remarks
-18°C / 0°F
4°C / 39°F
This is the recommended normal setting.
-20
°
C / -4
°
F
3
°
C / 37
°
F
These settings are recommended
when the ambient temperature is
above 30°C/86°F.
Quick
Freeze
4
°
C / 39
°
F
Use when you wish to freeze your food in
a short time. Your refrigerator will return to
its previous mode when the process is
over.
-24
°
C / -12
°
F
2
°
C / 35
°
F
Use these settings if you think that your
fridge compartment is not cold enough
because of the hot ambient conditions
or frequent opening and closing of the
door.
-18
°
C / 0
°
F or
colder
Quick
Fridge
Use this function when you place too much
into the fridge compartment or when you
need to cool your food quickly. It is
recommended that you activate Quick
Fridge function 4-8 hours before placing
the food
Recommended Operating Temperature:
Fridge: 4°C / 39°F , Freezer: - 18°C / 0°F
5Operatingthe product
5.6
Door bin
To remove, lift up the door bin
and then pull out straight.
5.7
Glass shelves
To remove a shelf
-
Fully open the corresponding door.
-
Hold the front of the shelf, and then gently lift up and slide out.
To reinsert
-
hold the shelf at an angle so the front is higher than the back,
and then insert the top hook into the top shelf notch.
-
Put down the front slightly.
IMPORTANT NOTE:
Use care when handling glass shelves
to prevent breakage or scratching the interior.
A
ATTENTION:
Glass shelves must be unloaded.
A
ATTENTION:
You must wait for the glass shelves
to reach room temperature before immersing
them in water for cleaning.
A
ATTENTION:
The door may not be closed if the door shelves are
positioned at the same level as glass shelves. Make
sure than the door is closed after placing the shelves.
5Operatingthe product
5.8
Crisper compartment
To remove the crisper
-
Pull the crisper until it stops.
-
Slightly unclip the front section of the drawer and take it out completely.
To install the crisper
-
Pull the rails completely.
-
Place the gap at the rear corners of the crisper to the detail located
at the rear corners of the rails.
-
Push the crisper slowly down until you feel it clip front onto the rails.
C
Make sure that the details at the right and left-hand
sides are fixed when installing the crisper.
C
Never leave the vegetables in their plastic bags in the
crisper. If they are left in their plastic bags they will rot
in a short period of time.
The crisper compartment preserves the humidity of your vegetables,
allowing you to store them for a long time without having to keep
them in their bags.
If you do not prefer the vegetables to get into contact with other vegetables
due to hygienic reasons, you can use perforated paper, foam or a similar
material instead of plastic bags.
While the vegetables are being replaced, their specific weights should be
taken into consideration.
Heavy and hard vegetables must be placed at the bottom of the crisper
and light and soft vegetables must be on the upper part.
Pears, kiwis, tomatoes, cucumbers, apricots, peaches, broccolis, lettuces,
cabbages, parsley and spinach are fruits and vegetables
that emit ethylene gas.
Do not place them into the same crisper with other fruits and vegetables.
The ethylene gas emitted by these foods cause other fruits and vegetables to
ripen sooner and to rot in a shorter span of time.
Do not remove the main body of the crisper from the refrigerator separately
unless you have to do so.
5Operatingthe product
5.9
Special fridge compartment
You can control the temperature in this section to store your food
such as fish, meat, vegetables and delicatessen products for a longtime.
C
Removal/installation procedures of the special fridge
compartment are same as that of the crisper.
5.10
Freezer
Crisper
The freezer compartment store your foods at a temperature
between -24°C and -18°C to keep them fresh for a long time.
To remove the crisper
-
Open the freezer door until itstops.
-
Unscrew drawer fixing screw and take it out carefully..
To install the crisper
-
Open the freezer door until itstops.
-
The crisper slowly down and screw drawer fixing bolt.
6Careand Cleaning
Service life of the product will extend and frequently encountered problems
will decrease if the product is cleaned periodically.
Never use gasoline, benzene or similar substances for cleaning purposes.
Never use any sharp abrasive instruments, soap, household cleaners,
detergent or wax polish for cleaning.
Dissolve one teaspoon of carbonate in half liter of water Soak a cloth in the
solution and wring it thoroughly. Wipe the interior of the refrigerator with this
cloth and the dry thoroughly.
Make sure that no water enters the lamp housing or other electrical parts.
If you will not use the refrigerator for a long time, unplug it, remove all food
inside, clean it and leave the door ajar.
Check regularly that the door gaskets are clean. If not, clean them.
Take out all items in the product to remove the door and body shelves.
Remove the door shelves by pulling them up. Slide the shelves downwards to
re-install them after cleaning.
Never use chloric cleaning agents or water to clean outer surfaces or chrome-
coated parts of the product. Chlorine causes abrasion on such metal surfaces.
6.1Avoiding Bad Odors
Materials that may cause odor are not used in the production of our
refrigerators. However, odor may be emitted if foods are stored improperly or
if the inner surface of the product is not cleaned as required.
Please consider the following to avoid this problem:
It is important that the refrigerator is kept clean.
Food residuals, stains, etc. can cause odor.
For this reason, clean your refrigerator with carbonate solved
in water every 15 days. Never use detergents or soap.
Keep your foods in closed vessels. Microorganisms emitted from vessels
without a cover may cause unpleasant odors.
Never keep expired or spoiled foods in your refrigerator.
6.2.Protecting the Plastic Surfaces
Do not put liquid oils or oil-cooked meals in your refrigerator in unsealed
containers as they damage the plastic surfaces of your refrigerator.
If oil is spilled or smeared onto the plastic surfaces, clean and
rinse the relevant part of the surface with warm water immediately.
B
WARNING Switch off the product before cleaning.
B
WARNING It is recommended to clean
the condenser every six months using gloves.
You must not use vacuum cleaners.
6Careand Cleaning
6.3
Cleaning the Inner Surface
To clean the inner surfaces and all removable parts,
wash them with a mild solution comprising soap, water and carbonate.
Rinse and dry thoroughly.
Prevent the water from contacting the lighting means and control panel.
6.4
Stainless Steel Outer Surfaces
Use a stainless steel cleaning agent that is non- abrasive and
apply it with a lint-free, soft cloth.
For polishing, wipe the surface softly with a damp microfiber cloth
and use dry wash-leather.
Always follow the strands of the stainless steel.
A
ATTENTION:
Do not use vinegar, rubbing alcohol or other
alcohol-based cleaning agents
on any of the inner surfaces.
7Trouble Shooting
Please review this list before calling the service.
This will save you time and money.
This list contains frequently encountered problems that are not results
of faulty workmanship or material use.
Your product may not have some of the features described here.
The refrigerator is not operating.
•
It may not be plugged in properly. >>> Plug in the product properly.
•
The fuse of the socket to which your refrigerator is connected
or the main fuse may have blown.
>>>Check the fuse.
The condensation on the fridge compartment
•
The door may have been opened/closed frequently.
>>>Do not open/close the refrigerator door frequently.
•
The environment may be too humid.
>>>Do not install the refrigerator at locations with a very high
level of humidity.
•
Foods containing liquid may have been placed into the refrigerator
in vessels without covers.
>>> Do not place foods containing liquid into the refrigerator
in unsealed vessels.
•
Door of the refrigerator may have been left ajar.
>>>Do not keep the doors of your refrigerator open for a long time.
The compressor is not operating.
•
Protective thermal of the compressor will blow out during sudden power
failures or plug-out plug- ins as the refrigerant pressure in the cooling system
of the refrigerator has not been balanced yet.
•
The refrigerator will start running approximately after 6 minutes.
Please call the Authorised Service Provider if the refrigerator does
not start at the end of this period.
•
The freezer is in defrosting cycle. >>>This is normal for a refrigerator
that performs full-automatic defrosting.
Defrosting cycle is performed periodically.
•
The refrigerator may not be plugged in.
>>>Make sure that the plug fits the socket.
•
Temperature settings may be incorrect.
>>>Select the correct temperature value.
•
Possible power failure.
>>>The refrigerator will start to operate normally when power restores.
7Trouble Shooting
The operation noise increases when the refrigerator is running.
Operating performance of the refrigerator may vary based
on the ambient temperature changes.
This is normal and not a fault.
Vibration or noise.
•
The floor may not be stable or level.
>>>If the refrigerator shakes when moved slightly feed to balance it.
Make sure that the floor is level and capable of carrying the refrigerator.
•
Objects placed onto the refrigerator may cause noise.
>>>Remove the objects on the refrigerator.
There are noises coming from the refrigerator like liquid
spilling or spraying.
•
Liquid and gas flows occur in accordance with the operating principles
of the refrigerator. This is normal and not a fault.
Whistle is heard from the refrigerator.
•
There are fans that are used to cool the refrigerator.
This is normal and not a fault.
Damp accumulates on the inner walls of refrigerator.
•
Hot and humid weather increases icing and condensation.
This is normal and not a fault.
•
The doors may have been opened frequently or left ajar
for a long time.
>>>Do not open the door frequently. Close the doors, if open.
•
The door may have been left ajar.
>>>Close the door completely.
Humidity occurs on the outer surface of the refrigerator or
between the doors.
•
Air might be humid. This is quite normal in humid weathers.
>>>Condensation will disappear the humidity level decreases.
•
There might be external condensation at the section between
two doors of the refrigerator if you use your product rarely.
This is normal. Condensation will disappear upon frequent use.
7Trouble Shooting
There is a bad odour inside the refrigerator.
•
No regular cleaning may have been performed.
>>>Clean the inside of the refrigerator sponge, lukewarm water
or carbonated water.
•
Some vessels or packaging materials may cause the odour.
>>>Use another vessel, or packaging materials from another brand.
•
Foods may have been placed into the refrigerator in vessels
without covers. >>>Store the foods in closed vessels.
Microorganisms emitted from vessels without a cover may cause
unpleasant odors.
•
Take out expired or spoiled foods from the refrigerator.
The door cannot be closed.
•
Food packages may be preventing the door from closing.
>>> Re-locate the packages obstructing the door.
•
The refrigerator may be unstable on the floor.
>>>Adjust the refrigerator feet as requir the refrigerator in balance.
•
The floor may not be level or solid.
>>>Make sure that the floor is level and capable of carrying
the refrigerator.
Crispers are stuck.
•
Foods may be touching the upper wall of the crisper.
>>>Re-organise the foods in the crisper.
A
WARNING
If you can not eliminate the problem although
you follow the instructions in this section,
consult your dealer or the Authorized Service Provider.
Never attempt to repair a malfunctioned product.
Rev.13052022
Warranty Card
Worldwide Appliances Pty Limited
A.B.N. 45868077422
Distributed by Eurolinx pty Ltd
Ofce:
48-50 Moore Street, Leichhardt N.S.W 2040
Post:
Locked Bag 3000, Annandale, N.S.W 2038
P: 1300 694 583
WARRANTY REGISTRATION
Your ongoing satisfaction with your artusi
product is important to us. We ask that you
complete the enclosed Warranty Registration
Card and return it to us so that we have a record
of the artusi product purchased by you.
PRIVACY
Worldwide Appliances respects your
privacy and is committed to handling your
personal information in accordance with the
National Privacy Principles and the Privacy
Act 1988 (Cth). A copy of the Worldwide
Appliances Privacy Policy is available at
www.artusi.com.au. Worldwide Appliances will
not disclose any personal information set out
in the Warranty Registration Card (“Personal
Information”) without your consent unless
required by:
1. law;
2. any Worldwide Appliances related company;
3. any service provider which provide services
to artusi or assist artusi in providing services
(including repair and warranty services) to
customers. Our purpose in collecting the
Personal Information is
to keep a record of the artusi product purchased
by you, in order to provide a better warranty
service to you in the unlikely event that there is
a problem with your artusi product. Worldwide
Appliances may contact you at any one or more
of the address, email address or telephone
numbers set out in the Warranty Registration
Card. Please contact artusi on 1300 694
583 should you not wish to be contacted by
Worldwide Appliances.
WARRANTY
1. Warranty
Worldwide Appliances warrants that each artusi
product will remain, for a period of either 12
months or 24 months of warranty. All Warranties
are valid from the original date of purchase, And
warranty claims must be accompanied by the
proof of purchase.
24 months warranty products:
All Built-in Appliances – Limited to Ovens,
Gas, Induction and Electric Cooktops, and All
Rangehoods. Freestanding Cookers - Gas and
Electric Models (900mm Width).
artusi.com.au
Dishwashers - Freestanding, Fully Integrated,
Semi Integrated and built-in. All Wine coolers. All
Dryers. Freestanding Cookers - Gas and Electric
Models in 50cm, 54cm and 60cm Widths
Portable Appliances* – Benchtop Models and
Portable Gas Models
2. What is not Covered by the Warranty.
The Warranty does not apply if an artusi product
is defective by a factor other than a defect arising
in the manufacture of the artusi product, including
but not limited to:
(a) damage through misuse (including failure
to maintain, service or use with proper care),
neglect, accident or ordinary wear and tear
(including deterioration of parts and accessories
and glass breakage);
(b) use for purpose for which the artusi product
was not sold or designed;
(c) use or installation which is not in accordance
with any specied instructions for use or
installation;
(d) use or operation after a defect has occurred or
been discovered;
(e) damage through freight, transportation or
handling in transit (other than when Worldwide
Appliances is responsible);
(f) damage through exposure to chemicals, dusts,
residues, excessive voltage, heat, atmospheric
conditions or other forces or environmental
factors outside the control or Worldwide
Appliances;
(g) repair, modication or tampering by the
purchaser or any person other than Worldwide
Appliances, an employee of Worldwide
Appliances or an authorised artusi service
contractor*;
(h) use of parts, components or accessories
which have not been supplied or specically
approved by artusi.
(i) damage to surface coatings caused by cleaning
or maintenance using products not recommended
in the artusi product handbook provided to the
purchaser upon purchase of the artusi product;
(j) damage to the base of an electric oven due to
items having been placed on the base of the oven
cavity or covering the base, such as aluminium
foil (this impedes the transfer of heat from the
element to the oven cavity and can result in
irreparable damage); or
(k) damages, dents or other cosmetic
imperfections not aecting the performance of the
artusi in respect of an artusi product purchased
as a “factory second” or from display
The Warranty does not extend to light globes
used in artusi products.
3. Domestic Use
Each artusi product is made for domestic use.
This Warranty may not extend to artusi products
used for commercial purposes.
Continued over...
Rev.13052022
DON’T FORGET TO REGISTER
YOUR WARRANTY ONLINE
NOW AT
www.eurolinx.support
TO REGISTER
YOUR WARRANTY
artusi.com.au
4. Time for Claim under the Warranty
You must make any claim under this Warranty
within twenty eight (28) days after the occurrence
of an event which gives rise to a claim pursuant
to the Warranty, by booking a service call on the
telephone number below.
5. Proof of Purchase
Customers must retain proof of purchase in order
to be eligible to make a warranty claim in respect
of an artusi product.
6. Claiming under the Warranty
Customers will bear the cost of claiming under
this Warranty unless Worldwide Appliances
determines the expenses are reasonable, in which
case the customer must claim those expenses
by providing written evidence of each expense
to Worldwide Appliances at the address on the
Warranty Registration Card.
7. Statutory Rights
(a) These terms and conditions do not aect your
statutory rights.
(b) The limitations on the Warranty set out in this
document do not exclude or limit the application
of the consumer guarantees set out in the Act or
any other equivalent or corresponding legislation
in the relevant jurisdiction where to do so would:
(i) contravene the law of the relevant jurisdiction;
or
(ii) cause any part of the Warranty to be void.
(c) Worldwide Appliances excludes indirect or
consequential loss of any kind (including, without
limitation, loss of use of the artusi product) and
(other than expressly provided for in these terms
and conditions) subject to all terms,
conditions and warranties implied by custom, the
general law, the Act or other statute.
(d) The liability of Worldwide Appliances to you
for a breach of any express or non-excludable
implied term, condition or warranty is limited at
the option of Worldwide Appliances to:
(i) replacing or repairing the defective part of the
artusi product;
(ii) paying the cost of replacing or repairing the
defective part of the artusi product;
(iii) replacing the artusi product; or
(iv) paying the cost of replacing the artusi
product.
(e) Our goods come with guarantees that cannot
be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund
for a major failure and for compensation for any
other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a
major failure.
8. Defects
Any part of an artusi product deemed to be
defective and replaced by Worldwide Appliances
is the property of Worldwide Appliances.
Worldwide Appliances reserves the right to
inspect and test artusi products in order to
determine the extent of any defect and the
validity of a claim under the Warranty.
All warranty service calls must be booked via
the customer care department. The team can
be contacted on 1 300 85 64 11 option 1 or
customercare@eurolinx.com.au
01082016
Warranty Card continued
DISCLAIMER
Worldwide Appliances PTY LTD, trading as ARTUSI, is continually seeking ways to improve the design specications, aesthetics and production
techniques of its products. As a result alterations to our products and designs take place continually. Whilst every effort is made to produce
information and literature that is up to date, this brochure should not be regarded as an infallible guide to the current specications, nor does
it constitute an offer for the sale of any particular product. Product dimensions indicated in our literature is indicative only. Actual product only
should be used to dene dimension cutouts. Distributors, and retailers are not agents of ARTUSI and are not authorised to bind ARTUSI by any
express or implied undertaking or representation.
artusi.com.au
FOLLOW US ON:
NSW & ACT (Head Ofce)
48-50 Moore Street
Leichhardt
Victoria
2r/131 Church Street
Hawthorn
QLD
Contact
head ofce
WA & NT
Contact
head ofce
Australia National Telephone Number 1300 694 583
Our showrooms opening hours in each state are available on our website
/artusi_kitchen_laundry_outdoor /au.linkedin.com/company/eurolinx-ptyltd
