Sencor SCP 5414GY Double-hotplate induction cooker User Manual

SCP 5414GY

DOUBLE INDUCTION COOKTOP

Translation of the original manual

SCP 5414GY

8 9 10

4 5 73 6

- 1 -

03/2025

2025, .

Double Induction Cooktop

User Manual

Important Safety Instructions

READ CAREFULLY AND STORE FOR FUTURE USE.

• This appliance may be used by children 8 years of age

and older and by persons with physical, sensory or mental

impairments or by inexperienced persons, if they are

properly supervised or have been informed about how to

use of the product in asafe manner and understand the

potential dangers.

• Children must not play with the appliance.

• Cleaning and maintenance must not be carried out by

children unless they are older than 8 years of age and

under supervision.

• Children younger than 8 years of age must be kept away

from the appliance and its power cord.

• If the power cord is damaged, have it replaced in

aprofessional service centre to prevent the risk of injury.

Never use the appliance if the power cord is damaged.

• Metal objects such as knives, forks, spoons or lids should

not be placed on the hotplate as they may heat up.

CAUTION:

Hot surface. The temperature of accessible surfaces

may be higher if the appliance is in operation.

- 2 -

03/2025

2025, .

WARNING:

If the surface of the appliance is cracked, switch it off

to prevent possible electric shock.

CAUTION:

This appliance is not designed to be controlled using

an external timer switch or aremote control.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Additional important safety instructions foruse of the appliance

• This appliance is designed for household use only. It is also suitable for personal non-commercial use in spaces such as:

– staff kitchens in stores, offices and other workplaces;

– recreational objects, chalets, cottages;

– hotel or motel rooms andother living areas;

– Bed & Breakfast facilities.

• Do not use the appliance in outdoor or industry environment.

• Never use the appliance for any purposes other than intended.

• Before connecting the appliance to apower socket, check that the nameplate rated voltage matches the voltage of the power socket the appliance is

to be connected to. Connect the appliance only to aproperly earthed socket. Do not use an extension cord. Before use, fully extend the power cord.

• Only use the appliance on flat, dry, clean, stable and fire-resistant surface. Do not use the appliance on metal surfaces, such as on the kitchen sink

drainage board.

• Do not place the appliance on or near table edge, electric or gas stove or other sources of heat.

• Do not use the appliance on asurface which is heat-sensitive or covered with table cloth, paper or other flammable material, in the vicinity of

curtains or other flammable or heat-sensitive materials.

• During operation there needs to be sufficient area for air circulation above the appliance and around it. Asafety distance of at least 50cm and 10cm

must be observed over the hotplate in the main heat radiation direction and in other directions around the appliance respectively.

• During operation, the appliance must be placed on the kitchen unit countertop with no cabinet or overhanging shelf over itself.

• Do not place any objects on the appliance.

• Do not place credit cards, watches or radios in the vicinity of the appliance, so that they are not damaged by the magnetic field generated by the

operation of the induction cooker.

• Do not cover or block the ventilation openings of the appliance.

• Not not use the appliance without any pot or pan put on the hotplate. During operation, regularly check the food status.

• Use only cooking pots or pans suitable for induction heating.

• Always make sure that the pot or pan is placed correctly on the hotplate.

• The dish handles should be in asafe position to prevent getting caught on and overturning the dishes.

• Liquids or meals may not be heated in closed containers, such as cans, as an explosion could result.

• Take special care if oil or fat is used for cooking. If fat or oil is heated to ahigh temperature, it may catch fire.

• When handling hot dishes containing hot food or liquids, take special care to prevent burning or scalding.

• Use oven mitts when handling hot dishes.

• The appliance must not be left unattended while in operation or connected to apower socket.

• Keep in mind that the hotplate will still radiate some residual heat for awhile after use. Take care not to touch the hot surface of the appliance.

• After use, always switch the appliance off using the on/off button and disconnect the appliance'spower cord from the power socket. Take this action

also if the appliance is to be left unattended, unused or before cleaning, maintenance, moving or storage.

• When disconnecting the appliance from the power socket, always pull the plug, not the power cord. Otherwise, you may damage the power cable

or the socket.

• Allow the appliance to fully cool down before moving, cleaning, maintenance or storage. Never move the appliance during operation, while there is

apot or apan on it or if it’snot cooled down completely.

• To prevent the risk of electric shock, do not immerse the appliance, power cable, or plug into water or any other liquid.

• Do not place heavy objects on the power cord. Make sure that the power cable does not hang over the edge of the table or touch hot surfaces or

sharp objects.

• Clean the appliance regularly after each use according to the instructions in the Cleaning and Maintenance section. Do not perform any

maintenance on the appliance other than the cleaning described in this user’smanual.

• Do not use the appliance if it malfunctions, has been dropped on the floor, immersed in water or damaged in any way. Take it to an authorised

service centre for inspection or repair.

• To prevent dangerous situations, do not repair or modify the appliance yourself. All repairs should be carried out by an authorised service centre.

Tampering with the appliance may result in the loss of your legal rights regarding faulty performance or warranty for quality.

- 3 -

03/2025

2025, .

WARNING:

People with acardiac pacemaker should only use this appliance after consulting their attending physician.

EXPLANATION OF SYMBOLS PLACED ON THE PRODUCT OR INTHE ACCOMPANYING DOCUMENTATION

The product meets all the basic requirements of the applicable EU directives.

This symbol on products or original documents means that used electric or electronic products must not be added to ordinary municipal

waste.

Product with protection class II

Electric shock protection is provided by double or heavy-duty insulation.

- 4 -

03/2025

2025, .

• Thank you for purchasing our SENCOR product; we hope it will serve

to your satisfaction.

• Prior to using this appliance, please read the user manual thoroughly,

even in cases when you are already familiar with the use of similar

types of appliances. Use the appliance only as described in this

user manual. Keep the manual for future reference. If you pass the

appliance on to another person, ensure that this user manual is

included.

• Carefully unpack the appliance and make sure not to discard any part

of the packaging material until you have removed all components

of the appliance. It is recommended that you keep the original

packaging, packing material, receipt and confirmation of the extent

of the seller'sliability or warranty certificate at least for the duration

of the legal right to file adefect claim or the quality warranty. When

transporting the appliance, we recommend repackaging it in the

original box provided by the manufacturer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF THE APPLIANCE

A1 Top hotplate

A2 Bottom hotplate

A3 Control panel

A4 Air inlet (in therear part and

on the side of the appliance)

A5 Air exhaust (on the underside

of the appliance)

A6 Rotary knob

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF THE CONTROL PANEL

B1 Top hotplate selection button

B2 Bottom hotplate selection

button

B3 Set power/temperature

number bar of the bottom

hotplate

B4 Buttons todirectly set the

power level/temperature of

the hotplate

B5 button to interrupt

operation

B6 button to switch the cooker

on/off

B7 Display (displays the

power of the hotplate, the

set temperature, the time

of automatic shutdown or

the error message codes.

If the cooker is instand-by

mode, “S” will appear on the

display.)

B8 Set power/temperature

number bar of the top hotplate

B9 button toswitch between

power andtemperature

settings

B10 button to set the timer

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BEFORE FIRST USE

• Before first use, remove the appliance and its accessories from the

packaging and discard all promotional labels and tags. Check that

neither the appliance nor any of its components is damaged.

• Wipe the surface of the appliance with aclean, slightly damp cloth.

Then wipe it dry.

Induction andSelection of Suitable Dishes

• Under the hotplate, there is an induction coil, which creates avariable

electromagnetic field when it is turned on. The induction current

produced by this field will start to heat the bottom of the pot or pan

located on the hotplate. To ensure proper operation, it is important

that the cookware used should be ferromagnetic. You can verify

this by placing asmall magnet at the bottom of the pot or pan. If the

magnet and the bottom of the pot or pan are attracted toeach other,

such cookware is ferromagnetic andtherefore suitable for use on an

induction hotplate. These are e.g. cast iron, steel, enamel, stainless

steel cookware with ferromagnetic bottoms.

• We recommend that the bottom of the cookware is flat andstraight.

The minimum diameter of the bottom must be 12cm, the maximum

diameter can be up to 2cm over the edge of the hotplate. Induction

hotplate automatically adjusts to the size of the pot or pan used.

• Plug the power cord plug into apower outlet, ashort beep sounds, the

control panel lights up briefly and then “- -” flashes on the display. The

cooker has switched to standby mode.

• If, on the other hand, the magnet and the bottom of the pot or pan are

not attracted to each other, such dishes are unsuitable for use on an

induction hotplate. These are usually dishes made of copper, pure

stainless steel, aluminium, glass, wood, ceramics, stoneware, etc.

Note:

If you use inappropriate dishes or the hotplate detects that

there are no dishes on it, it will automatically turn off. This

is anormal andsafety event that will prevent damage to

the appliance.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RADIO INTERFERENCE

Using an induction cooker may cause interference with your radio,

television or similar receivers.

If this occurs, we recommend:

– redirect the radio or television antenna;

– move the cooker away from the radio, television or receiver;

– connect the power cord plug to adifferent power socket with its own

independent circuit.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

OPERATING THE APPLIANCE

• Place the appliance on akitchen worktop or table withineasy reach of

apower socket. When doing so, make sure that all safety instructions

are followed.

• Check that there are no foreign objects on the hotplate andthat the

surface is clean.

• Unwind the power cord completely and connect it to the power socket.

You will hear an audible warning, the control panel lights up briefly and

“S” appears on the display. This means that the cooker has switched

to standby mode.

Note:

The power cord must be positioned so that it does not touch

the surface of the appliance, as the appliance heats up

during operation.

Note:

Connect the device to apower socket with separate

protection. The necessary circuit breaker – 16A.

Power On/Off

Press the button to turn the cooker on. “ON” will appear on the display.

Place the cookware on the cooking surface.

Note:

If you do not set the power or temperature, the cooker will

automatically switch to stand-by mode after about 1 minute

of inactivity. “S” will appear on the display.

After use, press the button

and the cooker will turn off. “S” will appear

on the display.

Selecting aHotplate

After switching on the cooker, press the button

(B1) to select the

upper hob or (B2) to select the lower hob.

Power Setting

• After switching on the cooker and selecting the hotplate, press the

button once, the cooker will start and the display will show “P06"”.

Use the rotary knob (A6) or press the number button of the specific

power level (B4) to set the power of the hotplate. The display will show

the power setting and the number of digits on the number bar (B3 for

the lower hob or B8 for the upper hob) corresponding to the power

setting will also light up.

Double Induction Cooktop

User Manual

- 5 -

03/2025

2025, .

The smoke point is the temperature at which the so-called over-burning of

fat or oil occurs and the formation of smoke, which is avisible secondary

phenomenon of over-burning of fat or oil. Such fat or oil is not suitable for

consumption and may cause serious health problems if consumed for

along time.

Every fat or oil has its own smoke point – see table below.

Table of Common Fats andOils Used in theKitchen

Oil Smoke point

Butter (not drained) 121–149 °C

Clarified butter (ghee) 252 °C

Pork lard 188 °C

Vegetable fat 182 °C

Avocado oil, refined 271 °C

Olive oil, extra virgin 191 °C

Olive oil, extra virgin 199 °C

Rapeseed oil, refined 204 °C

Sunflower oil, unrefined 107 °C

Sunflower oil, refined 227 °C

Note:

The indicated temperatures are maximum for individual

types of fats andoils. The recommended frying

temperature of fats andoils for thermal food preparation is

in therange of 160 °C – 180 °C.

• By correctly setting the temperature of the cooker and warming up

the fat or oil, you also care aboutyour safety andprotect the cooker

against overheating, because asmall amount of fat or oil in the pot or

pan, combined withtoo high cooking power, can cause the cooker not

to be able to continue to transfer excessive amounts of heat, it will start

to heat up, which could lead toits irreparable damage.

• To avoid irreversible damage to the cooker due to excessive heating,

the cooker is equipped with safety thermal fuse. It activates when

the cooker should overheat andautomatically shuts it down. Error

message E5 appears on the cooker display. If this occurs, wait for

the inner fan to stop running. Then unplug the power cord from the

power socket and allow the cooker to cool sufficiently (approx. 20–30

minutes). Then plug the mains plug back into the power socket and

you will be able to use the cooker again.

Note:

The error message E5 is only awarning message anddoes

not indicate damage to the cooker. The thermal fuse only

turned off the cooker so as not to damage it or create

adangerous situation that could cause injury or injury to

persons. You can use the cooker again after it has cooled

down.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CLEANING AND MAINTENANCE

• Clean the appliance after every use. Make sure that dried food

residues or other impurities do not accumulate on it. Before cleaning,

always turn off the appliance with the

button, disconnect the

power cord from the power socket and let the appliance cool down

completely.

• Toclean the hotplate andthe surface around it, use asoft, lightly

dampened fabric. Then wipe the plate dry. Incase of heavy soiling,

use asmall amount of neutral dishwashing detergent. Remove any

detergent residue with aclean, lightly dampened cloth. Then wipe the

cleaned surface thoroughly dry.

• Do not use wire wool, thinners, abrasive cleaners, etc. to clean the

appliance. Otherwise, the appliance'sfinish may be damaged.

Warning:

To prevent the risk of electric shock, do not immerse

the appliance, power cable, or plug into water or any

other liquid.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

• Use the rotary knob to adjust the power evenduring cooking. The

adjusted power will be shown on the display. You can also adjust the

power by directly pressing the power number button.

Note:

After setting the power, the internal fan will also start. This is

normal. The fan draws hot air from the internal components

out of the cooker body.

Setting the Temperature

• After turning on the cooker, press the

button twice, the cooker

will start and “120” will appear on the display. Use the rotary knob

(A6) or press the number button of the specific temperature level

(B6) to set the temperature of the hotplate. The display will show

the set temperature and the number of digits on the number bar (B3

for the lower hob or B8 for the upper hob) corresponding to the set

temperature will also light up.

• Use the rotary knob to adjust the temperature during cooking. The

adjusted temperature is shown on the display. You can also adjust the

temperature by directly pressing the temperature number button.

Note:

After setting the power, the internal fan will also start. This is

normal. The fan draws hot air from the internal components

out of the cooker body.

Timer

The timer allows you to set atime after which the cooker turns itself off.

1. Set the desired power/temperature according to the instructions

above.

2. Press the

button and “0:00” will start flashing on the display.

3. Use the rotary knob to set the time from 0:01 to 3:00. Turn the knob

towards“+” to increase the timer time, turn the knob towards“–”

to decrease the timer time. If you need to set the timer time to

3:00 hours, after pressing the button, turn the knob once to the left

towards“–”. “3:00” will appear on the display.

4. When the value on the display stabilises, the setting is stored in

memory and the countdown starts.

5. When the set time has elapsed, ashort beep sounds, the timer

switches off and the cooker switches to standby mode. “S” will

appear on the display.

If you need to switch off the cooker earlier, press and hold the

button.

If you press the button while the rest is running, “0:00” will flash

again on the display. If you do not set any time, the countdown will be

cancelled, but the cooker will continue to run.

Note:

When the countdown is started, the display alternately

shows the set power/temperature and the countdown time.

Note:

During the countdown, you can change the power/

temperature of the hotplate as described above.

Interruption of Operation

The interruption function allows you to interrupt the operation of the

cooker without the cooker having to turn off.

1. While the cooker is inoperation, press .

2. The cooker stops running, the number bar (B7) starts flashing.

3. Press the

button to resume operation.

Child Lock

The appliance is equipped with achild lock function that allows you to

lock the control panel to prevent unwanted changes to the settings.

To activate the child lock function, press the and buttons

simultaneously until the beep sounds. Child lock indicator will light up

andcontrol buttons will not work.

To disable the child lock, press the

and buttons simultaneously

until the beep sounds. Child lock indicator will go out.

Frying

Frying is aspecific process where apowerful cooker transfers avery high

amount of heat to arelatively small amount of fat or oil. During frying, it is

very important to choose the appropriate temperature setting andheat the

fat or oil to the right temperature so as not to exceed the temperature of the

so-called smoke point.

- 6 -

03/2025

2025, .

STORAGE

• If the appliance will not be used for an extended period, unplug it

from the power socket, let it cool down, and clean it following the

instructions provided above. Before storing, make sure that the

appliance is clean and dry. Store the appliance in adry, clean, and

well-ventilated place away from extreme temperatures and out of the

reach of children or pets.

Error Messages

Error Code Cause Solution

There is no pot

or pan on the

hotplate, or you

have put unsuitable

dishes on it.

Use suitable cookware – see

“Induction andSelection of

Suitable Dishes” or “Cookware

Suitable for Cooking on

aRadiant Hob”.

Electrical failure /

short circuit

Contact an authorised service

centre.

Temperature

sensor error.

Stop using the appliance,

unplug the power cord from the

power socket and contact an

authorised service centre.

E3 or E4

The voltage in the

socket to which

the cooker is

connected is too

high or too low.

Plug the power cord plug into

a220–240 VAC power outlet.

The thermal fuse

was activated,

the cooker

turned offdue to

overheating.

Let the cooker cool down.

Check that the air inlet

andfan and air outlet are

free andunobstructed. If the

problem persists, stop using the

appliance, unplug the power

cord from the power socket and

contact an authorised service

centre.

Note:

If the problem persists, stop using the appliance, unplug

the power cord from the power socket and contact an

authorised service centre.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TECHNICAL SPECIFICATIONS

Rated voltage range ..............................................................................220–240 V~

Rated frequency ...........................................................................................50/60 Hz

Rated input .........................................................................................................3,100 W

Standby power consumption ......................................................................0.727 W

Setting the hotplate power level .......................... max. 1,800 W(top hotplate);

..................................................................................max. 1,300 W(bottom hotplate)

Hotplate temperature setting .................................60–240 °C (both hotplates)

Operating time...................................................................................... 1–180 minutes

Dimensions ................................................................................310 × 600 × 40mm

Weight .........................................................................................................................5 kg

Note:

The cooker will switch to the automatic mode immediately

after the cooker is turned off, when the display shows “S”.

Changes to text and technical parameters are reserved.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INSTRUCTIONS AND INFORMATION ON DISPOSAL OF USED

PACKAGING MATERIAL

Dispose used packaging material at the designated municipal waste

disposal site.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT

Used electrical andelectronic products must not be disposed of in

ordinary municipal waste. To enable the proper disposal and recycling

of these products, deliver them to the designated collection points.

Alternatively, in some European Union states or other European

countries the products can be returned to the local retailer when buying

an equivalent new product. By properly disposing this product, you

help preserve valuable natural resources and help to prevent potential

damage to the environment and human health resulting from improper

waste disposal. For more details, contact your local authority or nearest

collection point. Fines may be imposed for improper disposal of this type

of waste as per national regulations.

For business entities in European Union States

To dispose of electric or electronic equipment, request the necessary

information from your retailer or supplier.

Disposal in other countries outside the European Union

To dispose of this product elsewhere, request the necessary information

on the correct disposal method from local authorities or your retailer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

www.sencor.com

info@sencor.cz

Sencor SCP 5414GY Double-hotplate induction cooker

Product's Documents

User Manual

Specifications

Sencor SCP 5414GY Questions and Answers
