INSTRUCTION MANUAL
120V ~50/60Hz 1200W
Model: AJ-2241A
Read this manual thoroughly before using and save it for future reference
Garment Steamers
HOUSEHOLD USE ONLY
Ningbo Aijia Electrical Appliances Co.,Ltd
Made In China
Add: No.555,East Kaifa Road,Zhouxiang Town,
Cixi City,Ningbo,Zhejiang Province,315324,China
Facebook Page: https://www.facebook.com/Reemix.Official/
1
IMPORTANT SAFETY INSTRUCTIONS
When using your appliance, basic precautions should always be followed,
including the following:
1. Read all instructions.
2. To reduce the risk of contact with hot water emitting from steam vents,
check appliance before each use by holding it away from body and operat-
ing steam button.
3. Use appliance only for its intended use.
4. To reduce the risk of electric shock, do not immerse the appliance in water
or other liquids.
5. Never yank cord to disconnect from outlet; instead, grasp plug and pull to
disconnect.
6. Do not allow cord to touch hot surfaces. Let appliance cool completely
before putting away. Loop cord loosely around appliance when storing.
7. Always disconnect appliance from electrical outlet when filling with water
or emptying, and when not in use.
8. Do not operate appliance with a damaged cord, or if the appliance has
been dropped or damaged. To reduce the risk of electric shock, do not disas-
semble or attempt to repair the appliance, take it to a qualified service
person for examination and repair. Incorrect reassembly or repair could
cause a risk of fire, electric shock, or injury to persons when the appliance is
used.
9. Close supervision is necessary for any appliance being used by or near
children. Do not leave appliance unattended while connected.
10. Burns could occur from touching hot metal parts, hot water, or steam.
Use care when you turn a steam appliance upside down ‒ there may be hot
water in the reservoir.
SAVE THESE INSTRUCTIONS
2 3
COMPONENT DIAGRAMS
1
2
3
4
9
5
6
7
8
10
1 Stainless steel panel
The power supply after heating, the temperature is high, do not touch,
so as not to burn.
3 Steam button lock
Used to turn on and off steam
5 Handle
Shake hands at
7 Water cap
Open it when adding water and cover it after filling it to prevent water
from flowing out
9 Upper shell
The temperature is high, do not touch, so as not to burn.
2 Lower shell
Used to support the heater
4 Steam button
This button is pressed down, hand can generate steam hanging ironing
machine
6 Water tank
The water tank can be filled with water to remove "MAX"
8 Button cover
The product can be stably placed on the table
10
Brush
The brush can be fastened to the whole machine to iron the clothes
lying away
4 5
Tear off before all the viscose and protective film for the first time. According to
the following instructions.
1．The product out of the packaging, accessories and separate out the attention,
to prevent the fall broke.
2．The power line plug into the socket, indicator light, about half a minute to use
steam heating.
3．To use steam, to the water tank to MAX, the maximum capacity of the water
tank is 120ml.
4．Smell may be issued for the first time, with a few times will disappear natural-
ly, please rest assured that the use of.
5．If you need to fold ironing clothes, curtains hanging inside the case, only the
vertical with a hand-held hanging ironing machine, press the button a puff of
steam steam ironing with strong, this method is very convenient.
6．Unplug the power cord after use,and the product can be folded and stored
when cooled.
Warning: do not use, or unattended, must unplug the power line!！
OPERATING INSTRUCTIONS
1. Pull plug off, disconnect the power supply
Warning: Aluminum die-cast bottom plate is very hot,scald carefully
2. Surface with a cloth to scrub the cloth products, can not be too wet, so as not
to solution into the machine.
Note: Please note when cleaning, do not let water or solution into the machine
Warning: do not put the machine into the water or other cleaning solution!
CLEANING AND MAINTENANCE
THE PERFORMANCE INDEX
Voltage:
Power:
Water tank Capacity:
Steam quantity:
120V ~50/60Hz
1200W
120ml
14-22/min
