Confirming the Package Contents
The following items are included in the package. If something is
missing please contact the retail outlet at which you purchased the
product.
You may not be able to achieve the full performance of this camera with the
included memory card.
g
a
b
de
h
Camera AA-size Alkaline
Batteries (×2)
Memory Card
(32 MB)
Interface Cable
IFC-400PCU
AV Cable
AVC-DC300
Wrist Strap
WS-800
European
Warranty System
(EWS) Booklet
Canon Digital
Camera Solution
Disk
c
f
i
User Guides
• Getting Started Guide
• Canon Digital Camera
Manuals Disk
Let’s Get Started!
1
Let’s Get Started!
This guide is divided into the following two sections.
This section explains how to prepare the camera for use and the
basics of shooting, viewing and printing images. Start out by
familiarizing yourself with the camera and mastering the basics.
Once you have mastered the basics, use the camera’s many features
to shoot more challenging photos. Details on using each function are
described in this section, including how to connect the camera to a
television to view images.
First...
Next...
p. 9
Learning More
p. 39
Getting Started
Adobe Reader is required to view the PDF Manuals.
http://www.adobe.com
The PDF Manuals are included in the supplied CD-ROM.
Table of Contents
2
Table of Contents
Items marked with a are lists or charts that summarize camera functions
or procedures.
Please Read . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Components Guide 40
Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Basic Operations 44
Menus and Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Information Displayed on the LCD Monitor and Menus . . . 46
Using the LCD Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Commonly Used Shooting Functions 56
Using the Optical Zoom . . . . . . . . . . . . . . . . . . . . . . 56
Using the Digital Zoom/ Digital Tele-Converter . . . . . . . . . 56
Using the Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Shooting Close-ups (Macro) . . . . . . . . . . . . . . . . . . . . . 61
Using the Self-Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Changing the Recording Pixels (Still Images) . . . . . . . . . . 64
Learning More . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Shooting Still Images
( Mode) . . . . . . . . . . . . . . . . . . 15
Viewing Still Images . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Erasing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Embedding the Date in the Image Data . . . . . . . . . . . 22
Shooting Movies
( Standard Mode). . . . . . . . . . . . . . . 24
Viewing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Downloading Images to a Computer . . . . . . . . . . . . . 27
System Map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Table of Contents
3
Changing the Compression (Still Images) . . . . . . . . . . . . . 65
Setting the Image Stabilizer Function . . . . . . . . . . . . . . . . 66
Adjusting the ISO Speed . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Shooting Using the Mode Dial 69
Mode Dial. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Shooting Modes for Specific Scenes . . . . . . . . . . . . . . . . . 70
Program AE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Setting the Shutter Speed . . . . . . . . . . . . . . . . . . . . . . 74
Setting the Aperture. . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Manually Setting the Shutter Speed and Aperture . . . 78
Movie Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Advanced Shooting Functions 84
Continuous Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Setting the Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Checking the Focus and Peoples’ Expressions. . . . . . . . . 88
Selecting an AF Frame Mode . . . . . . . . . . . . . . . . . . . . . . 92
Selecting a Subject to Focus On
(Face Select and Track). . . . . . . . . . . . . . . . . . . . . . . . . 94
Shooting Hard-to-Focus Subjects
(Focus Lock, Manual Focus, Safety MF) . . . . . . . . . . . . 96
Adjusting the Exposure Compensation. . . . . . . . . . . . . 99
Switching between Metering Modes . . . . . . . . . . . . . . . . 100
Adjusting the Tone (White Balance) . . . . . . . . . . . . . . . . 101
Shooting in a My Colors Mode. . . . . . . . . . . . . . . . . . . . . 104
Setting the Display Overlays . . . . . . . . . . . . . . . . . . . . . . 106
Categorizing Images Automatically (Auto Category) . . . . 107
Registering Settings to the Button . . . . . . . . . . . . 108
Playback/Erasing 110
Viewing Magnified Images . . . . . . . . . . . . . . . . . . . . . 110
Viewing Images in Sets of Nine (Index Playback) . . . 111
Check the Focus and Facial Expressions of Subjects
(Focus Check Display) . . . . . . . . . . . . . . . . . . . . . . . . . 112
Jumping to Images . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Organizing Images by Category (My Category). . . . . . . . 116
Table of Contents
4
Viewing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Rotating Images in the Display . . . . . . . . . . . . . . . . . . . . 119
Playback with Transition Effects . . . . . . . . . . . . . . . . . . . 120
Automated Playback (Slide Shows). . . . . . . . . . . . . . . . . 121
Red-Eye Correction Function. . . . . . . . . . . . . . . . . . . . . . 122
Changing the Recording Pixel (Resize) . . . . . . . . . . . . . . 127
Attaching Sound Memos to Images . . . . . . . . . . . . . . . . . 129
Protecting Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Erasing All Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Print Settings/Transfer Settings 133
Setting the DPOF Print Settings . . . . . . . . . . . . . . . . . . . 133
Setting the DPOF Transfer Settings . . . . . . . . . . . . . . . . 137
Configuring the Camera 139
Power Saving Function . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Formatting Memory Cards . . . . . . . . . . . . . . . . . . . . . . . . 141
Resetting the File Number . . . . . . . . . . . . . . . . . . . . . . . . 142
Creating an Image Destination (Folder). . . . . . . . . . . . . . 144
Setting the Auto Rotate Function . . . . . . . . . . . . . . . . . . . 146
Resetting Settings to Their Default Values . . . . . . . . . . . 147
Connecting to a TV 148
Shooting/Playback Using a TV . . . . . . . . . . . . . . . . . . . . 148
Troubleshooting 150
List of Messages 161
Appendix 165
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
Preventing Malfunctions. . . . . . . . . . . . . . . . . . . . . . . . . . 171
Using the Power Kits (Sold Separately). . . . . . . . . . . . . . 174
Using the Lenses (Sold Separately) . . . . . . . . . . . . . . . . 178
Using an Externally Mounted Flash (Sold Separately) . . 182
Replacing the Date Battery . . . . . . . . . . . . . . . . . . . . . . . 184
Camera Care and Maintenance. . . . . . . . . . . . . . . . . . . . 186
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Table of Contents
5
Index 197
Functions Available in Each Shooting Mode 201
Symbol Conventions in this Guide
About this Guide
: This mark denotes issues that may affect the camera’s
operation.
: This mark denotes additional topics that complement the basic
operating procedures.
Explanations in this guide are based on the camera’s default settings
at time of purchase.
Specifications are subject to change without prior notice. As a result,
the illustrations and screenshots used in this guide may differ from the
actual camera.
You can use SD memory cards, SDHC (SD High Capacity) memory
cards, MultiMediaCards, MMCplus cards and HC MMCplus cards in
this camera. These memory cards are collectively referred to as
memory cards in this guide.
60
Using the Flash
Available Shooting Modesp.201
1
Press the button.
Mode switch position:
Shooting ( )
/
Playback ( )
Some functions may not be available in certain shooting modes.
If there is no notation to that effect, the function may be used in all modes.
Please Read
6
Please Read
Test Shots
Before you try to photograph important subjects, we highly recommend
that you shoot several trial images to confirm that the camera is
operating and being operated correctly.
Please note that Canon Inc., its subsidiaries and affiliates, and its
distributors are not liable for any consequential damages arising from
any malfunction of a camera or accessory, including memory cards,
that results in the failure of an image to be recorded or to be recorded
in a way that is machine readable.
Warning Against Copyright Infringement
Please note that Canon digital cameras are intended for personal use
and should never be used in a manner that infringes upon or
contravenes international or domestic copyright laws and regulations.
Please be advised that in certain cases the copying of images from
performances, exhibitions, or commercial properties by means of a
camera or other device may contravene copyright or other legal rights
even if the image was shot for personal use.
Warranty Limitations
For information on your camera’s warranty, please refer to the Canon
European Warranty System (EWS) Booklet supplied with your camera.
For Canon Customer Support contacts, please see the European
Warranty System (EWS) Booklet.
Please Read
7
Video Format
Please set the camera’s video signal format to the one used in your
region before using it with a TV monitor (p. 148).
Language Setting
Please see Setting the Display Language (p. 14) to change the
language setting.
Camera Body Temperature
If your camera is used for prolonged periods, the camera body
may become warm. Please be aware of this and take care when
operating the camera for an extended period.
About the LCD Monitor
The LCD monitor is produced with extremely high-precision
manufacturing techniques. More than 99.99% of the pixels
operate to specification. Less than 0.01% of the pixels may
occasionally misfire or appear as red or black dots. This has no
effect on the recorded image and does not constitute a
malfunction.
8
Preparations
10
Getting Started
Preparations
1.
Slide the battery cover lock (a) and hold it open while
sliding the cover (b) and opening it (c).
2. Install two batteries.
Installing the batteries
Slide
the cover (b).
Open the cover (c).
b
c
a
Battery Cover Lock
Positive end (+)
Insert the two
supplied AA-size
alkaline batteries.
Negative end (–)
Preparations
11
Getting Started
3. Insert the memory card until it clicks into place.
4. Close the cover (
d
), and press downward as you slide
it until it clicks into place (e).
Ensure that the memory card is correctly oriented before
inserting it in the camera. Inserting it backward may cause the
camera to fail to recognize the memory card or to malfunction.
Front
• Confirm that the write protect tab is
unlocked (only SD and SDHC
memory cards).
• Check the card for the correct
orientation.
Write Protect Tab
(Only SD and SDHC memory cards)
d
e
Preparations
12
Getting Started
To Remove the Batteries
Open the cover and remove the batteries.
To Remove the Memory Card
Use a finger to push the memory card in until you hear a click, then
release it.
Take care that you do not drop the batteries.
Use the wrist strap to avoid dropping the camera during use.
Preparations
13
Getting Started
The Date/Time settings menu will appear the first time the power is
turned on.
1. Press the ON/OFF button.
2. Select the month, day, year and
time, and the display order.
1. Use the or button to select
an option.
2. Use the or button to set the
value.
3. Press the button.
To Change a Previously Set Date/Time
Use the following procedures to display the Date/Time settings
window, and then perform Steps 2 and 3 above.
1. Press the button.
2. Use the or button to select
the (Set up) menu.
3. Use the or button to select
[Date/Time].
4. Press the button.
Setting the Date and Time
Buttons
ON/OFF button
Button
Button
Preparations
14
Getting Started
You can change the language displayed in the LCD monitor menus
and messages.
1. Set the mode switch to (playback).
2. Hold down the button and press the button.
3. Use the or button to select a language.
4. Press the button.
The date/time setting screen will appear when the capacity of
the lithium date/time battery is depleted (p. 184).
Setting the Display Language
Button
Mode Switch
Button
Buttons
Shooting Still Images
15
Getting Started
Shooting Still Images
1. Press the ON/OFF button.
• The start-up sound will play and the start-up image will display in
the LCD monitor.
• Pressing the ON/OFF button again turns the power off.
2. Select a shooting mode.
1. Set the mode switch to
(shooting).
2. Set the shooting mode dial to
.
3. Aim the camera at the subject.
4. Press the shutter button lightly (halfway) to focus.
• When the camera focuses, it beeps twice and the indicator lights.
Avoiding Camera Shake
Keep your arms tight against your body
while holding the camera firmly by the
sides. Using a tripod is also effective.
( Mode)
Shutter Button
ON/OFF button
Mode Dial
Button
Mode Switch
Indicators
Shooting Still Images
16
Getting Started
5. Press the shutter button fully (all the way) to shoot.
• The shutter sound will play once and the image will record.
• Recorded images are displayed on the LCD monitor for
approximately 2 seconds immediately after shooting (Rec.
Review). You can shoot by pressing the shutter button even
when an image is being displayed.
• If you hold the shutter button down after a shot, the image will
continue to display.
• The indicator will blink green and the file will record to the
memory card.
To Shoot Images in Focus
The camera automatically sets the focus when you press the shutter
button halfway*.
* The shutter button has a two-stage action. Pressing it down to the first stage is
referred as “pressing halfway”.
Mute Setting
When you hold down the DISP. button while turning on the
camera, the mute setting will be set to [On]. You can change
the setting in [Mute] in the Set up menu (p. 52).
IncorrectCorrect
Press halfway to
set the focus
An AF frame will
display in green on
the LCD monitor at
the point of focus.
Press fully
Shooting Preparations
Complete: lights green
(orange when the flash will fire)
Recording:
blinks green
Just pressing
fully
AF Frame
Beep,
beep…
Shooting Still Images
17
Getting Started
Shooting in Easy Mode
This camera features a shooting mode, Easy mode, that
automatically selects all camera settings except the flash. This mode
is ideal for first time camera users, or users who do not make many
settings. You can select whether or not to use the flash with the
button, allowing you to take images even where flash photography is
prohibited.
1. Set the mode dial to (Easy mode).
2. Aim the camera at the subject.
3. Press the shutter button halfway to focus.
4. Press the shutter button fully to shoot.
No settings, other than flash settings, can be made in Easy
mode. Even if you press the MENU or FUNC./SET button, no
menu will display.
Viewing Still Images
18
Getting Started
Viewing Still Images
1.
Press the ON/OFF button.
2. Set the mode switch to (playback).
3. Use the or button to display the image you wish
to view.
• Use the button to move to the
previous image and the button to
move to the next image.
• The images advance more quickly if
you keep the button pressed, but they
will appear coarse.
z In the menu, you can set [Resume] to either [Last seen]*
or [Last shot] (p. 51). (* Default setting)
z If you select [Last seen], the last image viewed will display
(Resume Playback).
z The following actions will display the most recent image
regardless of the [Resume] settings.
Shooting an image, changing the memory card, or editing an
image on the memory card using a computer.
Mode Switch
Buttons
ON/OFF button
Erasing
19
Getting Started
Erasing
1. Set the mode switch to (playback).
2. Use the or button to select an image to erase and
press the button.
3. Confirm that [Erase] is selected
and press the button.
To exit instead of erasing, select
[Cancel].
Please note that erased images cannot be recovered. Exercise
adequate caution before erasing an image.
Buttons
Button
Mode Switch
Button
Printing
20
Getting Started
Printing
1.
Connect the camera to a direct print compatible printer.
• Open the terminal cover and plug the interface cable in all the
way.
• See the printer’s user guide for connection instructions.
• Since this camera uses a standard protocol (PictBridge), you can
use it with other PictBridge-compliant printers in addition to
Canon-brand printers.
For detail, see the Direct Print User Guide.
2. Turn on the printer.
3. Set the mode switch to (playback) and press the
ON/OFF button.
• The button will light blue.
4. Use the or button to select an image to print and
press the button.
• The button will blink blue and printing will start.
Button
Terminal Cover
Mode Switch
DIGITAL Terminal
Buttons
Printing
21
Getting Started
Printing from a Print List
You can add images directly to a print list by merely pressing the
button immediately after shooting or playing back an image.
You can then print the images from the print list easily, when
connecting the camera to a printer.
Add to the Print List
1. Press the button (still images only).
2. Add to the print list.
1. Use the or button to select
the number of print copies.
2. Use the or button to select
[Add].
3. Press the button.
• To remove an image from the print
list, press the button again, use the or button to
select [Remove] and press the FUNC./SET button.
Printing Images in a Print List
This explanation is based on the use of a Canon SELPHY ES series
or SELPHY CP series printer.
1. Connect the camera to the printer.
2. Print the image.
1. Use the or button to select
[Print now].
• You can use the or button
to confirm the images added to
the print list.
2. Press the button.
• Printing will start.
• If printing is halted and resumed,
printing will start from the next image in the queue.
Number of copies to print
Embedding the Date in the Image Data
22
Getting Started
Embedding the Date in the Image Data
This section explains how to embed date information on images as
they are recorded (Date Stamp).
• The date stamp cannot be deleted from the image data once it has
been embedded. Ensure that the camera’s date/time is set correctly
beforehand (p. 13).
• The image size is fixed to the 2M (1600 × 1200) setting and the
compression to Fine (appropriate for printing L-size or postcard-size
prints.)
1. Press the ON/OFF button.
2. Select a shooting mode.
1. Set the mode switch to (shooting).
2. Set the mode dial to .
• You can also make this setting in other shooting modes
(except Easy and movie modes).
Button
Buttons
Mode Switch
Button
Mode Dial
Embedding the Date in the Image Data
23
Getting Started
3. Select (Date Stamp).
1. Press the button.
2. Use the or button to select
.
3. Use the or to select .
• The area that will not print displays
in gray.
• Press the button to switch to
[Date & Time] with the or
button.
You can use the following methods to imprint the date on images
lacking imprinted date stamps.
• Set with the camera’s Digital Print Order Format (DPOF) function.
Set [Date] option to [On] in [Print Settings] in the (Print) menu.
• Connect the camera to a printer and imprint the date.
See the Direct Print User Guide.
• Insert a memory card into the printer and imprint the date.
See your printer user guide.
• Use the supplied software.
See the Software Starter Guide.
Shooting Movies
24
Getting Started
Shooting Movies
1. Press the ON/OFF button.
2. Select a shooting mode.
1. Set the mode switch to
(shooting).
2. Set the mode dial to (Movie).
3. Use the or button to select
(Standard).
3. Aim the camera at the subject.
z Do not touch the microphone while
recording.
z Do not press any buttons other than the
shutter button. The sound that buttons
make will be recorded in the movie.
( Standard Mode)
Shutter Button
ON/OFF button
Indicators
Mode Dial
Mode Switch
Buttons
Microphone
Shooting Movies
25
Getting Started
4. Press the shutter button halfway
to focus.
• When the camera focuses, it beeps
twice and the indicator lights green.
• The exposure, focus and white
balance are automatically set.
5. Press the shutter button fully to
shoot.
• Press the shutter button fully to shoot.
• During the recording, the elapsed
recording time and [zRec.] will
display in the LCD monitor.
6. Press the shutter button fully
again to stop recording.
• The indicator will blink green and the
data will be recorded onto the memory
card.
• Recording will stop automatically
when the maximum recording time
elapses, or the built-in memory or memory card become full.
Shooting Preparations
Complete: lights green
Elapsed Time
Recording: blinks green
Viewing Movies
26
Getting Started
Viewing Movies
1.
Press the ON/OFF button.
2. Set the mode switch to (playback).
3. Use the or button to display a movie and press
the button.
• Images with a icon are movies.
4. Use the or button to select (Play) and press the
button.
• The movie will start playing.
• If you press the FUNC./SET button
during playback, you can pause and
restart the movie.
• You can adjust the playback volume
with the or button.
Buttons
Mode Switch
Button
ON/OFF button
Downloading Images to a Computer
27
Getting Started
Downloading Images to a Computer
We recommend to use the supplied software.
Items to Prepare
• Camera and computer
• Canon Digital Camera Solution Disk supplied with the camera
• Interface cable supplied with the camera
System Requirements
Please install the software on a computer meeting the following
minimum requirements.
Windows
Macintosh
OS Windows Vista
Windows XP Service Pack 2
Windows 2000 Service Pack 4
Computer Model The above OS should be pre-installed on computers with built-
in USB ports.
CPU Windows Vista : Pentium 1.3 GHz or higher
Windows XP / Windows 2000 : Pentium 500 MHz or higher
RAM Windows Vista : 512 MB or more
Windows XP / Windows 2000 : 256 MB or more
Interface USB
Free Hard Disk
Space
• Canon Utilities
- ZoomBrowser EX : 200 MB or more
- PhotoStitch : 40 MB or more
• Canon Camera TWAIN Driver : 25 MB or more
Display 1,024 × 768 pixels/High Color (16 bit) or better
OS Mac OS X (v10.3 – v10.4)
Computer Model The above OS should be pre-installed on computers with built-
in USB ports.
CPU PowerPC G3/G4/G5 or Intel Processor
RAM RAM 256 MB or more
Interface USB
Free Hard Disk
Space
• Canon Utilities
- ImageBrowser : 300MB or more
- PhotoStitch : 50 MB or more
Display 1,024 × 768 pixels/ 32,000 Colors or better
Downloading Images to a Computer
28
Getting Started
1. Installing the software.
Windows
1. Place the Canon Digital Camera Solution Disk in the
computer’s CD-ROM drive.
2. Click [Easy Installation].
Follow the onscreen messages to
proceed with the installation.
3. Click [Restart] or [Finish] once the
installation is complete.
When the installation is finished,
[Restart] or [Finish] will display. Click
the button that appears.
4. Remove the CD-ROM from the
drive when your normal desktop screen appears.
Macintosh
Double-click the icon in the CD-
ROM window. When the installer panel
appears, click [Install]. Follow the
onscreen instructions to proceed.
Preparing to Download Images
With Windows 2000, ensure that you install the software first
before connecting the camera to the computer.
Downloading Images to a Computer
29
Getting Started
2. Connecting the camera to a computer.
1. Connect the supplied interface cable to the computer’s
USB port and to the camera’s DIGITAL terminal.
Open the camera’s terminal cover and insert the interface cable
all the way into the connector.
3. Preparing to download images to the computer.
1. Set the mode switch to
(playback) to turn the camera on.
If the Digital Signature Not Found window appears, click [Yes].
The USB driver will automatically finish installing onto the
computer when you attach the camera and open a connection.
DIGITAL TerminalUSB Port
Interface Cable
Downloading Images to a Computer
30
Getting Started
4. Open the CameraWindow.
Windows
Select [Canon CameraWindow] and
click [OK].
CameraWindow appears.
Macintosh
The CameraWindow will appear when you establish a connection
between the camera and computer. If it fails to appear, click the
[CameraWindow] icon on the Dock (the bar which appears at the
bottom of the desktop).
Preparations for downloading images are now finished. Please
proceed to the Downloading Images Using the Camera section
(p. 31) (except Windows 2000).
If the window above does not appear, click the [Start] menu
and select [All Programs] or [Programs], followed by [Canon
Utilities], [CameraWindow], [CameraWindow] and
[CameraWindow].
z Refer to the Software Starter Guide for details on
downloading images using the computer.
z With Windows 2000, you can download images using the
computer.
Downloading Images to a Computer
31
Getting Started
Use this method to download images using camera operations (except
Windows 2000).
1. Confirm that the Direct Transfer menu is displayed on
the camera’s LCD monitor.
• The button will light blue.
•Press the MENU button if the Direct
Transfer menu fails to appear.
2. Press the button.
• Images not previously downloaded will download to the
computer.
Downloading Images Using the Camera
(Direct Transfer)
Install the software before downloading images via the direct
transfer method for the first time (p. 28).
Buttons
Button
Button
Button
Direct Transfer Menu
Downloading Images to a Computer
32
Getting Started
You can also use the following options in the Direct Transfer menu to
set the method for downloading images.
All Images/New Images/DPOF Trans. Images
1. Use the or button to select , or and press
the button.
• The images will download. The
button will blink blue while
downloading is in progress.
• The display will return to the Direct
Transfer menu when the download is
complete.
• Pressing the FUNC./SET button will
cancel a download in progress.
Select & Transfer/Wallpaper
1. Use the or button to select or press the
button (or button).
All Images Transfers and saves all images to the computer.
New Images
Transfers and saves to the computer only the
images that have not been previously
transferred.
DPOF Trans.
Images
Transfers and saves to the computer only the
images with DPOF Transfer Order settings.
Select & Transfer
Transfers and saves single images to the
computer as you view and select them.
Wallpaper
Transfers and saves single images to the
computer as you view and select them. The
transferred images display as the background on
the computer desktop.
Downloading Images to a Computer
33
Getting Started
2. Use the or button to select images to download
and press the button.
• The images will download. The
button will blink blue while
downloading is in progress.
3. Press the button after
downloading finishes.
• You will return to the Direct Transfer
menu.
Click [×] at the bottom right of the window to close CameraWindow, the
downloaded images will display on the computer.
By default, the downloaded images are saved into folders according to
their shooting dates.
Only JPEG images can be downloaded as wallpaper for a
computer.
The option selected with the button is retained even
when the camera’s power is turned off. The previous setting will
be in effect the next time the Direct Transfer menu is displayed.
The image selection screen will appear directly when the
[Select & Transfer] or the [Wallpaper] option was last selected.
Windows Macintosh
ZoomBrowser EX ImageBrowser
System Map
34
Getting Started
System Map
Wrist Strap
WS-800
Supplied with Camera
Interface Cable
IFC-400PCU*
1
Memory Card (32 MB)
Canon Digital Camera
Solution Disk
AV Cable AVC-DC300*
1
AC Adapter Kit
ACK800
Battery and Charger Kit
CBK4-300
*
4
Battery Charger CB-5AH/CB-
5AHE
AA-size NiMH batteries NB-3AH
(×4)
• NiMH Battery NB4-300 (set of 4
AA-size) also available
separately.
• Two batteries are used for this
camera.
Compact Power Adapter
CA-PS800
Power Cord
AA-size Alkaline
Batteries (×2)
System Map
35
Getting Started
USB Port
PC Card Slot
Direct Interface Cable*
2
USB Card
Reader
PCMCIA Adapter
(PC Card Adapter)
SD Memory Card*
5
• SDC-128M
• SDC-512MSH
Compact Photo
Printers*
2
*
3
(SELPHY series)
Inkjet Printers*
2
TV/Video
Video IN Terminal
Audio IN Terminal
*1 Also available for purchase separately.
*2 See the user guide supplied with the inkjet printer for more information on the
printer and interface cables.
*3 This camera can also be connected to the Card Photo Printer CP-10/CP-100/
CP-200/CP-300.
*4 Battery Charger CB-2LT/CB-2LTE may also be used.
*5 Not sold in some regions.
Windows/Macintosh
High-Power Flash
HF-DC1
Wide Converter
WC-DC52
Tele-converter
TC-DC52A
Close-up Lens
250D (52mm)
Conversion Lens
Adapter
LA-DC52G
Canon brand Direct
Print Compatible
Printers
System Map
36
Getting Started
The following camera accessories are sold separately.
Some accessories are not sold in some regions, or may no longer be
available.
Lenses, Lens Adapter
• Conversion Lens Adapter LA-DC52G
This adapter is required for mounting the wide converter and
teleconverter to the camera.
• Wide Converter WC-DC52
Converts the focal distance of the body lens by a factor of
approximately 0.7x when attached.
• Tele-converter TC-DC52A
Converts the focal distance of the body lens by a factor of
approximately 1.75x when attached.
• Close-up Lens 250D (52mm)
Close-up shots can be taken when the distance from the front of the
lens to the subject is 4 to 17 cm (1.6 to 6.7 in.) at maximum telephoto.
Flash
• High-Power Flash HF-DC1
This attachable supplementary flash can be used to capture
photographic subjects that are too distant for the built-in flash to
illuminate.
Power Supplies
• AC Adapter Kit ACK800
This kit lets you power the camera from any standard household
power outlet. Recommended to power a camera for an extended
period of time or when connecting to a computer.
(Cannot be used to charge the camera batteries.)
Optional Accessories
System Map
37
Getting Started
• Battery and Charger Kit CBK4-300
This dedicated battery charger kit includes both a charger unit and
four rechargeable AA-size NiMH (nickel metal hydride) batteries.
Convenient when taking or playing back large numbers of images.
You can also purchase NiMH Battery NB4-300, a set of four
rechargeable AA-size NiMH batteries separately.
Other Accessories
• SD Memory Card
SD memory cards are used to store images recorded by the camera.
Canon brand cards are available in 128 MB and 512 MB capacities.
• Interface Cable IFC-400PCU
Use this cable to connect the camera to a computer, Compact Photo
Printer (SELPHY series), or to a inkjet printer (refer to your inkjet
printer user guide).
• AV Cable AVC-DC300
Use this cable to connect the camera to a TV set.
Use of genuine Canon accessories is recommended.
This product is designed to achieve excellent performance when used with genuine
Canon accessories. Canon shall not be liable for any damage to this product and/or
accidents such as fire, etc., caused by the malfunction of non-genuine Canon
accessories (e.g., a leakage and/or explosion of a battery pack). Please note that this
warranty does not apply to repairs arising out of the malfunction of non-genuine
Canon accessories, although you may request such repairs on a chargeable basis.
System Map
38
Getting Started
Canon offers the following separately sold printers for use with the
camera. You can produce photo quality prints quickly and easily by
connecting them to the camera with a single cable and operating the
camera’s controls.
• Compact Photo Printers (SELPHY series)
• Inkjet Printers
For more information, visit your nearest Canon retailer.
Direct Print Compatible Printers
39
Learning More
40
Components Guide
Front View
a Microphone (pp. 24, 129)
b AF-assist Beam (p. 50)
c Red-Eye Reduction Lamp (p. 86)
d Self-Timer Lamp (p. 62)
e Viewfinder Window (p. 41)
f Flash (p. 60)
g Terminal Cover
h Ring (p. 179)
i Lens
j Ring Release Button (p. 179)
k A/V OUT (Audio/Video output) Terminal (p. 148)
l DIGITAL Terminal (p. 29)
m DC IN (Power Input) Terminal (p. 177)
Components Guide
41
Back View
a LCD Monitor (p. 54)
b Viewfinder
c Speaker
d Wrist Strap Mount (p. 12)
e Memory Card Slot / Battery Cover Lock (p. 10)
f Memory Card Slot / Battery Cover (p. 10)
g Tripod Socket
Using the Viewfinder
The viewfinder can be used to conserve power by turning the LCD
monitor off (p. 54) while shooting.
The LCD monitor may be covered with a thin plastic film for
protection against scratches during shipment. If so, remove the
film before using the camera.
42
Controls
a Indicators (p. 43)
b ON/OFF button (p. 15)
c Mode Dial (pp. 15, 69)
d Zoom Lever (pp. 56, 110)
Shooting: (Wide Angle)/ (Telephoto)
Playback: (Index)/ (Magnify)
e Shutter Button (p. 15)
f Mode Switch (p. 18)
g (Exposure)/ (Single Image Erase) Button (pp. 19, 99)
h (Print/Share) Button (pp. 20, 31, 108)
i FUNC./SET (Function/Set) Button (p. 44)
j MENU Button (p. 45)
k DISP. (Display) Button (p. 54)
l Button
m (Jump)/ (Flash)/ Button (pp. 60, 114)
n Button
o (Macro)/ (Manual Focus)/ Button (pp. 61, 96)
Components Guide
43
The camera indicators will light or blink under the following conditions.
• Upper Indicator
Green : Ready to shoot (camera beeps twice)/when
connected to a computer/when display off
Blinking Green : Camera starting up/Image recording/reading/
erasing/transferring (when connected to a
computer or printer)
Orange : Ready to shoot (flash on)
Blinking Orange : Ready to shoot (camera shake warning/charging
the flash)
• Lower Indicator
Yellow: Macro mode/Manual focus mode/AF lock mode
Blinking Yellow: Focusing difficulty (camera beeps once)
Indicators
Never do the following while the indicator blinks green. These
actions may corrupt image data.
- Shake or jolt the camera.
- Shut off the power, or open the memory card slot/battery
cover.
44
Basic Operations
Settings for the shooting or playback modes or such camera settings
as the print settings, date/time and sounds are set using the FUNC.
menu or the Rec., Play, Print or Set up menu.
FUNC. Menu ( Button)
This menu sets many of the common shooting functions.
Menus and Settings
1
Set the mode switch to (shooting) and turn
on the camera.
2
Press the button.
3
Use the or button to select a menu item.
Some items may not be selectable in some shooting modes.
4
Use the or button to select an option for
the menu item.
• You can select further options with the DISP. button for some
options.
• After selecting an option, you can press the shutter button to
shoot immediately. After shooting, the menu will appear again,
allowing you to adjust the settings easily.
5
Press the button.
• This example shows the FUNC.
menu in mode.
12
34
5
45
Basic Operations
Rec., Play, Print and Set up Menu ( Button)
Convenient settings for shooting, playback or printing can be set with
these menus.
1
Press the button.
2
Use the or button to switch between
menus.
• You can also use the zoom lever to switch between menus.
• The following menus are displayed.
Shooting: Rec./ Set up
Playback: Play/ Print/ Set up
3
Use the or button to select a menu item.
• Some items may not be selectable in some shooting modes.
4
Use the or button to select an option.
Menu items followed by an ellipsis (...) can only be set after
pressing the FUNC./SET button to display the next menu. Press
the FUNC./SET button again to confirm the setting and press the
MENU button to return the menu screen.
5
Press the button.
• This example shows the Rec. menu in mode.
You can switch
between menus with
the or button.
(Set up) Menu
(Rec.) Menu
1
2
34
5
46
Shooting Mode
Information Displayed on the LCD
Monitor and Menus
Available Shooting Modes p. 201
Information Displayed Setting Method
a
ISO Speed or Recording Pixels, etc.
FUNC./SET
button (FUNC. menu)
b
Display Overlays MENU button (Rec. menu)
c
Digital Tele-Converter ( 1.6x/
2.0x)/Digital Zoom Factor/
Safety Zoom ( )
MENU button (Rec. menu)
d
Flash ( ) button
e
Red-Eye Corr. ( ) MENU button ([Flash Settings]
menu in the Rec. menu)
f
Auto Rotate ( ) MENU button (Rec. menu)
g
Shooting Mode Mode dial
h
Camera Shake
()
MENU button (Rec. menu)
i
Create Folder ( ) MENU button (Setup menu)
j
Macro ( ) button
Manual Focus ( ) button
k
Exposure Compensation (
…
) button
Camera Shake ( )
(p. 152)
a
b
f
Recordable Shots (Stills)/
Remaining Time/Elapsed Time
(Movies)
i
h
g
Spot AE Point Frame/
AF Frame
j
e
dc
Shutter Speed,
Aperture Value
Exposure Level Indicator
(p. 78)
k
47
Basic Operations
Playback Mode (Detailed)
The following information may also be displayed with some images.
About the Battery Charge Indicator
When the battery charge is low, will blink in red in the LCD
monitor. Change the battery as soon as possible if you intend to use
the camera for an extended period of time.
Information Displayed Setting Method
l
Print List button,
MENU button (Print menu)
m
Red-Eye Correction Function/
Resized image ( )
Image with Sound Memo ( )
Protection Status ( )
MENU button (Play menu)
n
Compression (Still Images)/Recording
Pixels (Still Images), Movie ( )
FUNC./SET button
(FUNC. menu)
o
Auto Category ( ) MENU button (Rec. menu)
My Category ( ) MENU button (Play menu)
A file in a format other than the WAVE format is attached.
JPEG image not conforming to Design rule for Camera File System
Standards.
RAW image
Unrecognized data type
m
Shooting Date/Time
Low Battery
Displayed image number/
Total number of images
Folder Number-File
Number
Shooting information
Histogram
o
n
l
48
Shooting Mode
Information for images shot on other cameras may not display
correctly.
Histogram Function
The histogram is a graph that allows you to check the brightness of
an image. The greater the bias toward the left in the graph, the darker
the image. The greater the bias toward the right, the brighter the
image. By using the exposure compensation function, you can
correct the image brightness before shooting (p. 99).
Item Options
Reference
Page
Still Image
pp. 15, 69
Movie pp. 24, 80
Sample Histograms
Balanced ImageDark Image Bright Image
49
Basic Operations
FUNC. Menu
Rec. Menu
Menu Item Options
Reference
Page
ISO Speed p. 68
White Balance p. 101
Drive Mode pp. 84, 62
My Colors p. 104
Flash Exposure
Compensation/Flash Output
p. 86
Metering Mode p. 100
Compression p. 65
Recording Pixels
(Still Image)
( when
not imprinting date)
p. 64
Recording Pixels (Movie) p. 83
Menu Item Options
Reference
Page
AF Frame
p. 92
/// /
///
Face Detect*/AiAF/Center
/ / / Center*/Face Detect/AiAF
AF-Point Zoom On/Off* p. 88
Digital Zoom
p. 56
(Still Image) Standard*/Off/1.6x/2.0x
(Movies) Standard*/Off (In standard movie mode
only)
* Default setting
50
Flash Settings Flash Mode Auto*/Manual
p. 86
Flash Exp. Comp –2 to 0* to +2
Flash Output Minimum*/
Medium/Maximum
Red-Eye Corr. On/Off*
Red-Eye Lamp On*/Off
Safety FE On*/Off
MF-Point Zoom On*/Off p. 97
Safety MF On*/Off p. 98
AF-assist Beam On*/Off p. 40
Review Off/ 2* sec. to 10 sec./Hold p. 16
Review Info Off*/Detailed/Focus Check p. 88
Auto Category On*/Off p. 107
Disp. Overlay
p. 106(Still image) Off*/Grid Lines/3:2 Guide/Both
(Movie) Off*/Grid Lines
IS Mode
p. 66(Still image) Continuous*/Shoot Only/Panning/Off
(Movie) Continuous*/Off
Converter Off*/ WC-DC52 /TC-DC52A/250D p. 181
Set button * p. 108
Menu Item Options
Reference
Page
51
Basic Operations
Play Menu
Print Menu
Menu Item
Reference
Page
Slide Show p. 121
My Category p. 116
Red-Eye Correction p. 122
Resize p. 127
Sound Memo p. 129
Protect p. 131
Rotate p. 119
Erase all p. 132
Transfer Order p. 137
Resume p. 18
Transition p. 120
Menu Item Summary
Reference
Page
Print Displays the print menu. –
Select Image &
Qty.
Configures print settings for individual
images as you view them.
p. 135
Select All Images Configures print settings for all images.
Clear All Selections Removes all print settings from images.
Print Settings Sets the print style. p. 133
52
Set up Menu
Menu Item Options Summary/Reference Page
Mute On/Off* Set to [On] to silence all operation
sounds.
(Except for when the memory card slot/
battery cover is opened during
recording.)
Volume Off/ 1 / 2*/ 3 / 4 / 5 Adjusts the volume of the start-up
sound, operation sound, selftimer
sound, shutter sound and playback
sound. The volume cannot be
adjusted if [Mute] is set to [On].
Start-up Vol. Adjusts the volume of the start-up
sound when the camera is turned
on.
Operation
Vol.
Adjusts the volume of the operation
sound that beeps when any button
other than the shutter button is
pressed.
Selftimer
Vol.
Adjusts the volume of the selftimer
sound played 2 sec. before the
shutter is released.
Shutter
Volume
Adjusts the volume of the sound
played when the shutter releases.
The shutter sound does not play
when a movie is recording.
Playback Vol. Adjusts the volume of movie
sounds or sound memos.
Start-up Image On*/Off Sets whether or not the Start-up
Image appears when the camera is
powered on.
Power Saving
p. 139
Auto Power
Down
On*/Off
Display Off 10 sec./20 sec./30
sec./1 min.*/ 2 min./
3 min.
Date/Time p. 13
* Default setting
53
Basic Operations
Print Method
The connection method with the printer can be changed for printing. Although it is
normally not necessary to change the setting, select when borderless printing an
image shot in (Widescreen) mode on wide size paper using Canon compact photo
printer SELPHY CP750/CP740/CP730/CP720/CP710/CP510/CP520. As this setting
will be stored to memory even when the power is turned off, to print using an image size
other than , return the mode to [Auto] (however, the connection method cannot be
changed while connected to a printer).
Format You can also select a low level
format (p. 141).
File Numbering Continuous*/
Auto Reset
p. 142
Create Folder
p. 144
Create New
Folder
Check mark (On)/
No check mark (Off)
Auto Create Off*/Daily/Monday-
Sunday/Monthly
(Creation time also
can be set)
Auto Rotate On*/Off p. 146
Distance Units m/cm*/
ft/in
Sets the units for the zoom bar and
MF indicator distance unit (p. 97).
Lens Retract 1 minute*/0
seconds
Sets the lens retraction timing
when switching from shooting
mode to playback mode.
Language p. 14
Video System NTSC/PAL p. 148
Print Method Auto*/ See below.
Reset All p. 147
Menu Item Options Summary/Reference Page
54
Switching LCD Monitor Display Modes
Each press of the DISP. button, changes the display mode of the LCD
monitor. See Information Displayed on the LCD Monitor and Menus for
details (p. 46).
The following are the screens that display when shooting in
mode.
Shooting Mode
Playback Mode or Rec. Review (Right After Shooting)
Using the LCD Monitor
No Information Information View
Off
No Information Standard Display*
* Playback mode only
Focus Check*
* Still image only
Detailed Display
55
Basic Operations
z The LCD monitor will not switch to the detailed display or
focus check display in magnified display (p. 110), or index
playback mode (p. 111).
z Overexposure Warning
In the following cases, overexposed portions of the image
blink.
- When reviewing an image right after shooting in the LCD
monitor (detailed display)
- When using the detailed display mode of the playback
mode
Night Display
When shooting at dusk or during the evening when the dark
surroundings make it difficult to view the LCD monitor, the camera’s
“night view” option* displays the subject brightly in the LCD monitor.
This will allow you to compose a shot even in dark environments (this
setting cannot be turned off).
* Although noise may appear and the movement of the subject shown on the LCD
monitor may appear somewhat jagged, there is no effect on the recorded image.
The brightness of the image displayed in the monitor, and the brightness of the
actual image recorded will be different.
56
Commonly Used Shooting Functions
The zoom can be adjusted from 35 - 140 mm (focal length) in 35mm
film equivalent terms. The zoom bar appears when you press the zoom
lever.
You can combine digital zoom with optical zoom when shooting.
The available shooting characteristics and focal lengths (35mm film
equivalent) are as follows.
Using the Optical Zoom
1
Press the zoom lever
toward or .
• Telephoto: Zooms in on the
subject.
• Wide Angle: Zooms out from the
subject.
Using the Digital Zoom/
Digital Tele-Converter
Available Shooting Modes p. 201
Selection Focal Length Shooting Characteristics
Standard 35 – 560 mm
Enables shooting at zoom factors of up to
16x with digital and optical zoom combined.
Off 35 – 140 mm Enables shooting without digital zoom.
1.6x 56 – 224 mm
Digital zoom is fixed at the selected zoom
factor, and the focal length shifts to
maximum telephoto.
This enables a faster shutter speed and
less chance of camera shake than a shot
taken at the same angle of view with
[Standard] or [Off].
2.0x 70 – 280 mm
57
Commonly Used Shooting Functions
About the Safety Zoom
Depending on the number of recording pixels set, you can shift from
optical zoom to digital zoom without pausing up to a factor where the
image quality does not deteriorate (Safety Zoom). displays when
reaching the maximum zoom factor without image deterioration.
Pressing the zoom lever toward again allows you to zoom even
further (not available in ).
Depending on the number of recording pixels set, the Safety Zoom
zone varies as follows.
z The digital zoom cannot be used when the LCD monitor is
turned off.
z The digital zoom cannot be used in (Date Stamp) or
(Widescreen) modes.
Safety Zoom Factor
: zone without deterioration : zone with deterioration
Recording pixels
Optical zoom
Digital zoom
58
Shooting with the Digital Zoom
1
Select [Digital Zoom].
1. Press the button.
2. In the menu, use the or
button to select [Digital Zoom].
2
Make settings.
1. Use the or button to select
[Standard].
2. Press the button.
3
Press the zoom lever toward
and shoot.
• The combined digital and optical
zoom setting will display in the LCD
monitor.
• The image may appear coarse
depending upon the selected
recording pixels (the zoom factor appears in blue).
• Press the zoom lever toward to zoom out.
59
Commonly Used Shooting Functions
Shooting with the Digital Tele-Converter
The digital tele-converter feature uses digital zoom to achieve the
effects of a tele-converter (a lens used in telephoto shooting).
1
Select [Digital Zoom].
1. Press the button.
2. In the menu, use the or
button to select [Digital Zoom].
2
Make settings.
1. Use the or button to select
[1.6x] or [2.0x].
2. Press the button.
3
Adjust the angle of view
with the zoom lever and
shoot.
• and the zoom factor appear on the
LCD monitor.
• The image may appear coarse
depending upon the selected
recording pixels (the icon and the zoom factor appear in
blue).
60
Using the Flash
Available Shooting Modes p. 201
1
Press the button.
1. Use the or button to select the
flash settings.
: [Off]
: [On]
: [Auto]
• You can configure detailed settings for the flash when you press
the MENU button while this screen is displayed (p. 86).
You are recommended to shoot with the camera attached to a
tripod or other device if the camera shake warning icon ( )
appears.
61
Commonly Used Shooting Functions
Use this mode to shoot close-ups of flowers or small items. The image
area at the minimum shooting distance from the end of the lens to the
subject (5 cm) (2.0 in.) is 59 × 44 mm (2.3 × 1.7 in.).
To Cancel the Macro Mode:
Press the button and use the or button to select
(Normal).
Shooting Close-ups (Macro)
Available Shooting Modes p. 201
1
Press the button.
1. Use the or button to select
.
z Use the LCD monitor to compose close-ups in macro mode
since images composed with the viewfinder may be off
center.
z Using the flash in macro mode may cause image edges to
darken.
62
You can set the time delay and the numbers of shots you wish to take
in advance.
Using the Self-Timer
Available Shooting Modes p. 201
10 sec. Self-Timer: The shutter releases 10 seconds after the shutter
button is pressed.
• 2 seconds before the shutter releases, the self-timer sound beeps
quickly and the lamp will speed up.
2 sec. Self-Timer: The shutter releases 2 seconds after the shutter
button is pressed.
• The self-timer sound beeps quickly and the self-timer lamp blinks
when the shutter button is pressed and the shutter releases 2
seconds later.
Custom Timer: You can change the delay time (0 – 10, 15, 20, 30
sec.) and number of shots (1 – 10).
• When a delay time of over 2 seconds is set for the [Delay] option,
the self-timer sound beeps quickly 2 seconds before the shutter
releases. If multiple shots have been specified for the [Shots]
option, the sound will play for the first shot only.
1
Select the self-timer mode.
1. Press the button.
2. Use the or button to select
(Drive Mode) and the or button
to change the self-timer mode.
• When is selected, pressing the
DISP. button will allow you to set
the delay and number shots (p. 63).
3. Press the button.
63
Commonly Used Shooting Functions
To Cancel the Self-Timer:
Follow Step 1 to select .
Changing the Delay Time and Number of Shots ( )
2
Shoot.
• When you press the shutter button fully, the self-timer lamp will
blink.*
* When [Red-Eye Lamp] is set to [On] in [Flash Settings] in the Rec. menu, the
self-timer lamp will light 2 seconds before the flash fires (p. 86).
1
Select .
1. Press the button.
2. Use the or button to select
(Drive Mode) and the or button
to select .
3. Press the button.
2
Make settings.
1. Use the or button to select
[Delay] or [Shots] and the or
button to change the settings.
2. Press the button.
3. Press the button.
If the [Shots] option is set to 2 or more shots, the following
occurs.
- The exposure and white balance are locked at the settings
selected for the first shot.
- If the flash is used, the interval between shots lengthens.
- The interval between shots may lengthen when the built-in
memory of the camera fills.
- Shooting will automatically cease if the memory card
becomes full.
64
Approximate Values for Recording Pixels
: Approximate recording pixel numbers are shown. (M is short for megapixels.)
* Paper sizes vary according to region.
Changing the Recording Pixels
(Still Images)
Available Shooting Modes p. 201
1
Select the recording pixels.
1. Press the button.
2. Use the or button to select
and the or button to change
the recording pixels.
3. Press the button.
Recording Pixels Purpose*
Large
8M 3264 × 2448
High
Low
Printing to about A3-size
297 × 420 mm (11.7 × 16.5 in.)
Medium 1
5M 2592 × 1944
Printing to about A4-size
210 × 297 mm (8.3 × 11.7 in.)
Printing to about Letter-size
216 × 279 mm (8.5 × 11 in.)
Medium 2
3M 2048 × 1536
Printing to about A5-size
148 × 210 mm (6 × 8.3 in.)
Medium 3
2M 1600 × 1200
Printing postcard-size prints
148 × 100 mm (6 × 4 in.)
Printing L-size prints
119 × 89 mm (4.7 × 3.5 in.)
Small
0.3M
640 × 480
Sending images as e-mail
attachments or shoot more images.
Date Stamp
2M 1600 × 1200
Printing date-stamped images (p. 22), in
L-size or postcard-size (you can check
the print area at a 3:2 aspect ratio as
you shoot).
Widescreen
3264 × 1832
Printing on wide size paper (you can check
the composition at a 16:9 aspect ratio.
Areas that will not be recorded appear on
the LCD monitor as a black border.)
65
Commonly Used Shooting Functions
Approximate Values for Compression Settings
z
See Memory Cards and Estimated Capacities (p. 192)
z See Image Data Sizes (Estimated) (p. 193)
Changing the Compression (Still Images)
Available Shooting Modes p. 201
1
Select a compression
setting.
1. Press the button.
2. Use the or button to select
and the or button to change
the option.
3. Press the button.
Compression Purpose
Superfine High Quality
Normal
Shoot higher quality images.
Fine Shoot normal quality images.
Normal Shoot more images.
z
See Memory Cards and Estimated Capacities (p. 192)
z See Image Data Sizes (Estimated) (p. 193)
66
The lens-shift type image stabilizer function allows you to minimize the
camera shake effect (blurred images) when you shoot distant subjects
that have been magnified or when you shoot in dark conditions without
a flash.
Setting the Image Stabilizer Function
Available Shooting Modes p. 201
Continuous
You can check the effect of the IS mode on image blur on the
LCD monitor since the IS mode runs continually. This makes
it easier to compose images and focus on subjects.
Shoot Only
Shoot Only IS mode is only activated when the shutter button
is pressed. When set to [Continuous], some blurring may
occur depending on the subjects. In Shoot Only mode,
subjects can be taken without concern for any unnatural
movement that may appear on the LCD monitor.
Panning
This option only stabilizes the effect of up and down camera
motions on the image. This option is recommended for
shooting objects moving horizontally.
1
Select [IS Mode].
1. Press the button.
2. In the menu, use the or
button to select [IS Mode].
2
Make settings.
1. Use the or button to select the
image stabilizer settings.
2. Press the button.
67
Commonly Used Shooting Functions
The Icons on the LCD Monitor
[Off] [Continuous] [Shoot Only] [Panning]
[Converter] setting
in Rec. menu
Reference
Page
None –
WC-DC52,
TC-DC52A, 250D
p. 181
z Camera shake may not be fully corrected when shooting
with slow shutter speeds, such as with evening shots. Use of
a tripod is recommended.
z If camera shake is too strong, it may not be fully corrected.
z Hold the camera horizontally while [Panning] (stabilization
does not work when the camera is held vertically).
z If you shoot a movie after setting [IS Mode] to [Shoot Only]
or [Panning], the setting will change to [Continuous].
68
Raise the ISO speed to use a fast shutter speed when you wish to
reduce the effects of camera shake or avoid blurry subjects, or to turn
the flash off when shooting in a dark area.
Adjusting the ISO Speed
Available Shooting Modes p. 201
1
Adjust the ISO speed.
1. Press the button.
2. Use the or button to select
and the or button to change
the ISO speed.
• When you select (Auto) or
(High ISO Auto), the camera sets the optimal ISO speed for the
light level when shooting. As the ISO speed will automatically be
raised in dark places, shutter speed will increase, reducing
camera shake and subject blurring.
• Select to put priority on image quality.
• When you select , the camera also detects motion and sets
the optimum ISO speed. As the shutter speed becomes even
faster*, camera shake and blurred photos caused by subject
movement will be reduced even more than when shooting the
same scene in Auto.
* Noise may increase in the captured image compared to .
z The camera automatically applies noise reduction
processing when you shoot at a high ISO speed.
z If the camera is set at or , the ISO speed automatically
set by the camera will be displayed when pressing the
shutter button halfway or in playback information.
69
Shooting Using the Mode Dial
The camera automatically selects settings.
: Auto (p. 15)
: Easy (p. 17)
Image Zone
When a shooting mode appropriate for the shooting conditions is
selected, the camera automatically adjusts settings for optimal
shooting.
: Portrait : Landscape
: Night Snapshot : Kids&Pets
: Indoor
: Special Scene (p. 70)
: Night Scene : Sunset
: Foliage : Snow
: Beach : Fireworks
: Aquarium
: Movie (pp. 24, 80)
Creative Zone
You can freely select camera settings such as the exposure and
aperture value to suit your shooting purposes.
: Program AE (p. 73)
: Setting the Shutter Speed (p. 74)
: Setting the Aperture (p. 76)
: Manually Setting the Shutter Speed and Aperture (p. 78)
Mode Dial
Creative Zone
Image Zone
Shooting Using the Mode Dial
70
When a shooting mode appropriate for the shooting conditions is
selected, the camera automatically adjusts settings for optimal
shooting.
, , , , or (Special Scene)
Shooting Modes for Specific Scenes
Available Shooting Modes p. 201
1
Set the mode dial to , , , ,
or .
:
1. Use the or to select the scene
mode.
Portrait
Produces a soft effect when photographing people.
Landscape
Optimized for shooting landscape scenes which
contain both near and far subjects.
71
Shooting Using the Mode Dial
Night Snapshot
Allows you to take snapshots of people against
twilight or night backgrounds by reducing the effects
of camera shake when firmly holding the camera,
even without using a tripod.
Kids&Pets
Allows you to capture subjects that move around,
such as children and pets, without missing photo
opportunities.
Indoor
Prevents camera shake and maintains the subject’s
true color when shooting under fluorescent or
tungsten lighting.
Night Scene
Allows you to capture people against the backdrop
of an evening sky or night scene. The flash is
directed at the person and the shutter speed is slow,
so both the person and the background can be
beautifully shot.
Sunset
Allows you to shoot sunsets in vivid colors.
Foliage
Shoots trees and leaves - such as new growth,
autumn leaves or blossoms - in vivid colors.
72
Snow
Shoots without a blue tinge and without making
people appear dark against a snowy background.
Beach
Shoots without making people appear dark near
water or sand where reflected sunlight is strong.
Fireworks
Captures fireworks in the sky sharply and at optimal
exposure.
Aquarium
Selects the optimal ISO speed, white balance and
color balance to capture fish and other items in an
indoor aquarium.
z The shutter speed is slow in or mode. Always use a
tripod to avoid camera shake.
z
In
, , or
mode, the ISO speed may increase and
cause noise in the image depending on the scene being
shot.
73
Shooting Using the Mode Dial
The camera automatically sets the shutter speed and aperture value to
match the brightness of the scene. You can set the ISO speed,
exposure compensation and white balance.
Program AE
Available Shooting Modes p. 201
1
Set the mode dial to .
2
Shoot.
z When a correct exposure cannot be obtained, the shutter
speed and aperture values are shown in red on the LCD
monitor when the button is pressed halfway. Use the
following shooting methods to obtain the correct exposure
and make them show in white.
- Use the flash (p. 60)
- Adjust the ISO Speed (p. 68)
- Change the metering method (p. 100)
74
When you set the shutter speed, the camera automatically selects an
aperture value to match the brightness.
Faster shutter speeds allow you to catch an instantaneous image of a
moving subject, while slower speeds create a flowing effect and allow
you to shoot without a flash in dark areas.
Setting the Shutter Speed
Available Shooting Modes p. 201
1
Set the mode dial to .
2
Set the shutter speed.
1. Use the or button to change
the shutter speed.
3
Shoot.
• If you press the shutter button halfway and the aperture value is
shown in red, the image is underexposed (insufficient light) or
overexposed (too much light). Use the or button to adjust
the shutter speed until the aperture value shows in white.
The nature of CCDs is such that noise in the recorded image
increases at slow shutter speeds. This camera, however,
applies special processing to images shot at shutter speeds
slower than 1.3 seconds to eliminate the noise, thereby
producing high-quality images (Nevertheless, a certain amount
of processing time may be required before the next image can
be shot).
75
Shooting Using the Mode Dial
z The aperture value and shutter speed change according to
the zoom state as follows.
z The fastest shutter speed for built-in flash synchronization is
1/500 second. The camera automatically resets the shutter
speed to 1/500 second or slower, if a faster speed is
selected.
Shutter Speed Display
z The numbers in the table below indicate the shutter speed in
seconds. 1/160 indicates 1/160 second. Also, quote marks
indicate the decimal place, so that 0"3 indicates 0.3 second
and 2" indicates 2 seconds.
Aperture Value Shutter Speed (seconds)
Maximum Wide Angle
f/2.6 – 3.5 15 to 1/1250
f/4.0 – 8.0 15 to 1/2000
Maximum Telephoto
f/5.5 – 7.1 15 to 1/1250
f/8.0 15 to 1/2000
15" 13" 10" 8" 6" 5" 4" 3"2 2"5 2" 1"6 1"3 1" 0"8 0"6 0"5 0"4
0"3 1/4 1/5 1/6 1/8 1/10 1/13 1/15 1/20 1/25 1/30 1/40 1/50
1/60 1/80 1/100 1/125 1/160 1/200 1/250 1/320 1/400 1/500
1/640 1/800 1/1000 1/1250 1/1600 1/2000
76
The aperture adjusts the amount of light entering through the lens.
When you set the aperture, the camera automatically selects a shutter
speed to match the brightness.
Selecting a lower aperture value (opening the aperture) allows you to
blur the background and create a beautiful portrait.
A higher aperture value (closing the aperture) brings the entire range
from foreground to background into focus. The larger the aperture
value, the greater the range of the image brought into clear focus.
Setting the Aperture
Available Shooting Modes p. 201
1
Set the mode dial to .
2
Set the aperture value.
1. Use the or button to change
the aperture value.
3
Shoot.
• If you press the shutter button halfway and the shutter speed is
shown in red, the image is underexposed (insufficient light) or
overexposed (too much light). Use the or button to adjust
the aperture value until the shutter speed shows in white.
Some aperture values cannot be selected depending on the
zoom position (p. 75).
77
Shooting Using the Mode Dial
z The fastest shutter speed for built-in flash synchronization is
1/500 second. Even if an aperture value was previously set,
the camera may automatically change that value to match
the synchronized flash shutter speed.
Aperture Value Display
z The larger the aperture value, the smaller the lens aperture.
F2.6 F2.8 F3.2 F3.5 F4.0 F4.5 F5.0 F5.5 F5.6 F6.3 F7.1 F8.0
78
You can manually set the shutter speed and aperture to shoot images.
Manually Setting the Shutter Speed
and Aperture
Available Shooting Modes p. 201
1
Set the mode dial to .
2
Set the shutter speed and aperture value.
1. Press the button to select the shutter speed or aperture
value.
2. Use the or button to change the shutter speed or
aperture value.
3
Shoot.
• The current exposure level appears
on the right side of the exposure level
indicator, while the correct exposure
level appears in the center on the left
side of the indicator. You can check
the difference between the current
exposure level and the correct
exposure level. If the difference is
more than ±2 stops, the current
exposure level appears in red on the LCD monitor.
• When you press the shutter button halfway, the difference
between the correct exposure* and the current exposure level
appears on the LCD monitor. If the difference is more than 2
stops, “–2” or “+2” appears on the LCD monitor in red.
* The standard exposure is calculated by measuring the brightness according
to the selected metering method.
Current Exposure Level
Correct Exposure Level
Exposure Level Indicator
79
Shooting Using the Mode Dial
z If the zoom is adjusted after these values are set, the
aperture value or the shutter speed may change in
accordance with the zoom position (p. 75).
z The brightness of the LCD monitor matches the selected
shutter speed and aperture value. When you select a fast
shutter speed or shoot a subject that appears dark, set the
flash to (Flash on) to make the LCD monitor display
bright.
80
The following movie modes are available.
The recording time will differ according to the memory card used
(p. 193).
*1 When a super high-speed memory card is used, such as the recommended SDC-
512MSH.
*2 Even if the file size has not reached 4 GB, the recording is stopped when the
recording time reaches one hour. Depending on memory card capacity and data
write speed, recording may stop before the file size reaches 4 GB or the recording
time reaches one hour.
Movie Shooting
Available Shooting Modes p. 201
Standard
You can select the recording pixels and record until the memory card
is full*
1
.
The digital zoom can be used while shooting in this mode (p. 56).
• Maximum Size: 4 GB/movie
*
2
Compact
Since there are few recording pixels and also the data size is small,
this mode is convenient for sending movies as e-mail attachments or
when the memory card capacity is low.
• Maximum Clip Length: 3 minutes
1
Set the mode dial to .
2
Select a movie mode.
1. Use the or button to select a
movie mode.
81
Shooting Using the Mode Dial
3
Shoot.
• Pressing the shutter button halfway automatically sets the
exposure, focus and white balance settings.
• Pressing the shutter button fully starts recording video and
sound simultaneously.
• During shooting, the recording time and [zRec] appear on the
LCD monitor.
• Pressing the shutter button fully again stops recording.
Recording will stop automatically under the following
circumstances.
- When the maximum recording time or maximum recording
capacity is reached
- When the built-in memory or memory card becomes full
z You are recommended to use a memory card that has been
formatted in your camera to shoot movies (p. 141). The card
supplied with the camera may be used without further
formatting.
z Be careful of the following while recording.
- Try not to touch the microphone (p. 40).
- Do not press any buttons other than the shutter button.
The sound that buttons make will be recorded in the movie.
- The camera will automatically adjust the exposure and
white balance to suit the shooting conditions during a
recording. Please note, however, that the sounds made by
the camera while automatically adjusting the exposure
may also be recorded.
z The focus and optical zoom settings remain fixed for
subsequent frames at the values selected for the first frame.
82
z Adjust the zoom setting before shooting. The combined
digital and optical zoom factor will display on the LCD
monitor. When the zoom factor displays in blue, the image
will deteriorate.
z You can use digital zoom during the movie shooting in
mode only.
z QuickTime is required to play back movies (Data type: AVI/
Compression method: Motion JPEG) on a computer
(Windows 2000 only).
83
Shooting Using the Mode Dial
Changing Movie Recording Pixels/Frame Rates
You can change the recording pixels and frame rate when the movie
mode is set to (Standard). The frame rate can be set depending
on the recording pixels.
1
Select the recording
pixels.
1. Press the button.
2. Use the or button to select
and the or button to
change the recording pixels.
3. Press the button.
Movie Recording Pixels and Frame Rates
Frame rates indicate the number of frames recorded or played back
each second. The higher the frame rate, the smoother the
appearance of motion.
*1 Default setting.
*2 When priority is on movie length rather than image quality, select . You can
shoot for twice as long in this mode compared to a file of the same size shot in the
other modes.
Standard
*
1
640 × 480 recording pixels, 20 frames/sec.
*
2
640 × 480 recording pixels, 20 frames/sec. LP
320 × 240 recording pixels, 30 frames/sec.
Compact 160 × 120 recording pixels, 15 frames/sec.
z See Memory Cards and Estimated Capacities (p. 193).
z See Image Data Sizes (Estimated) (p. 193)
84
Advanced Shooting Functions
In this mode, the camera shoots continuously while the shutter button
is held down.
If you use the recommended memory card*, you can shoot
continuously (smooth continuous shooting) at a set shooting interval
until the memory card is full (p. 192).
Continuous Shooting
Available Shooting Modes p. 201
*Recommended Memory Card:
Super high-speed SDC-512MSH memory card (sold separately) to
which low-level formatting (p. 141) is conducted immediately before
shooting.
• Except (Large/Super Fine) mode.
• This reflects standard shooting criteria established by Canon. Actual results may
vary according to the subject and shooting conditions.
• Even if continuous shooting suddenly stops, the memory card may not be full.
1
Select .
1. Press the button.
2. Use the or button to select
(Drive Mode) and the or to
select .
3. Press the button.
85
Advanced Shooting Functions
To Cancel Continuous Shooting:
Follow Step 1 to select .
2
Shoot.
• The camera will continue to record successive images while the
shutter button is held down.
Recording will cease when the shutter button is released.
z The interval between shots lengthens when the built-in
memory of the camera fills.
z If the flash is used, the interval between shots lengthens
because the flash must charge.
86
You can make detailed flash settings to fit the shooting conditions.
Flash Settings
Setting the Flash
Available Shooting Modes p. 201
Flash Mode In the or shooting
modes, you can control the
flash output.
–
Flash Exp.
Comp
Flash exposure compensation
can be adjusted in the range of
–2 to +2 stops in 1/3-stop
increments. You can combine
the flash exposure
compensation with the
camera’s exposure
compensation function for
balanced exposure of the
background when shooting with
a flash.
In and
shooting modes, set
[Flash Mode] to [Auto] in
advance.
Flash Output The flash output can be
controlled in three steps, up to
FULL, when shooting.
In and
shooting modes, please
set [Flash Mode] to
[Manual] in advance.
Red-Eye Corr. Automatically searches for and
corrects red eyes in the image
when the flash fires.
–
Red-Eye
Lamp
This feature reduces the effect
of light reflecting back from the
eyes and making them appear
red.
When set to [On], the
red-eye reduction lamp
lights orange before the
flash fires.
Safety FE The camera automatically
changes the shutter speed or
aperture value when the flash
fires to avoid overexposing and
blowing out the highlights in the
scene.
In and
shooting modes, set
[Flash Mode] to [Auto] in
advance.
87
Advanced Shooting Functions
Displaying and setting [Flash Settings]
About Red-Eye Correction
z When [Red-Eye Corr.] is set to [On], only the corrected
image is recorded to the memory card.
z If the area around the eyes is red, for example from using
red eye shadow, that area may also be corrected. If this
happens, set [Red-Eye Corr.] to [Off].
z Red eyes may not be automatically detected or may not be
fully corrected on some images. In either case, you can
correct images with [Red-Eye Correction] in the menu
(p. 122).
1
Select [Flash Settings].
1. Press the button.
2. In the menu, use the or
button to select [Flash Settings].
3. Press the button.
2
Make settings.
1. Use the or to select the option.
2. Use the or button to make the
setting.
3. Press the button.
3
Press the button.
z [Flash Settings] can also be displayed by pressing the
button, followed by the MENU button.
z You can also set [Flash Exp. Comp] and [Flash Output] in the
FUNC. menu (p. 49).
Example in Av mode
88
You can zoom the display of the AF frame to check focus when
shooting or right after taking a shot.
Zooming the AF Frame and Shooting
When [AF Frame] is set to [Face Detect] or [Center], the AF frame area
can be zoomed to check focus while shooting. When you want to
capture people’s expressions, set [AF Frame] to [Face Detect]. When
you want to check the focus while shooting in macro mode, set [AF
Frame] to [Center].
Checking the Focus and Peoples’
Expressions
Available Shooting Modes p. 201
1
Select [AF-Point Zoom].
1. Press the button.
2. In the menu, use the or
button to select [AF-Point Zoom].
2
Make settings.
1. Use the or button to select
[On].
2. Press the button.
89
Advanced Shooting Functions
3
Press the shutter button halfway.
• Pressing the shutter button halfway zooms a section of the
display according to the following AF Frame mode settings
(p. 92).
- [Face Detect] : the face detected as the main subject will
appear zoomed.
- [Center] : the center of the image will appear zoomed in
the LCD monitor.
4
Press the shutter button fully to shoot.
The AF frame cannot be zoomed under the following
circumstances:
- When [AF Frame] is set to [Face Detect] and a face is not
detected, or when the face is extremely large in relation to
the overall composition.
- When the camera cannot focus.
- When the digital zoom is in use.
- When the LCD monitor is off.
- When a TV is being used as the display.
90
Checking Focus Right After Shooting
(Focus Check)
Allows you to check the focus of an image taken. It is also easy to
check peoples’ expressions and look for closed eyes when shooting
because a frame the size of the face displays when AF frame mode is
set to [Face Detect] (p. 92).
You are recommended to set [Review] to [Hold] in the menu in
advance.
1
Select [Review Info].
1. Press the button.
2. In the menu, use the or
button to select [Review Info].
2
Make settings.
1. Use the or button to select
[Focus Check].
2. Press the button.
91
Advanced Shooting Functions
To Cancel the Focus Check:
Press the shutter button halfway.
3
Shoot.
• The recorded image will be displayed.
• Frames are displayed as follows.
• The orange frame can be shown at a different magnification,
moved or switched to a different frame (p. 113).
z Pressing the button while the image is displayed will
erase the image (p. 19).
z You can check the focus even during playback mode
(p. 112).
Orange frame contents
Frame color Content
Orange Displays the area of the image shown at the bottom
right.
White Displays at the focal point (AF frame).
92
The AF frame indicates the area of the composition on which the camera
focuses.
Selecting an AF Frame Mode
Available Shooting Modes p. 201
Face
Detect
The camera detects a face and sets the focus,
exposure
*1
and white balance
*2
. In addition,
the camera meters the subject so that the face
is correctly illuminated when the flash fires. If
no face is detected, the camera shoots using
[AiAF].
*1 Only in evaluative metering mode (p. 100).
*2 Only in (p. 101)
AiAF
The camera automatically selects between 9
AF frames to focus on according to the
shooting conditions.
Center
The AF frame will be fixed to center. This is
recommended when the target subject is at the
center of the composition.
1
Select [AF Frame].
1. Press the button.
2. In the menu, use the or
button to select [AF Frame].
2
Make settings.
1. Use the or button to select
[Face Detect], [AiAF] or [Center].
2. Press the button.
93
Advanced Shooting Functions
z [Face Detect] cannot be used when the LCD monitor is
turned off.
z The AF frame appears as follows when the shutter button is
pressed halfway.
- Green : In focus
- Yellow : Focusing difficulty ([Center] option)
- No AF frame : Focusing difficulty ([Face Detect] or [AiAF]
option)
Face Detect Feature
z Maximum of three AF frames will be displayed at the positions of
faces the camera recognizes. At this point, the frame the camera
judges to be the main subject appears in white while the others
appear in gray. When the shutter button is pressed halfway and
the camera focuses, up to 9 green AF frames may appear.
z The camera will shoot using [AiAF] not the [Face Detect] function if
a white frame fails to appear and only gray frames display, or if a
face is not detected.
z The camera may mistakenly identify non-human subjects as a
face.
z In certain cases, faces may not be detected.
Examples:
- If faces are at the edge of the screen, or appear extremely small,
large, dark or bright, relative to the overall composition.
- Faces turned to the side or at a diagonal, or faces with a portion
hidden.
94
Once the focus is fixed to a subject’s face, the frame can be set to
follow the subject within a certain range.
Selecting a Subject to Focus On (Face
Select and Track)
Available Shooting Modes p. 201
To use the Face Select and Track function, first configure the
following settings.
- Set [AF Frame] to [Face Detect] (p. 92).
- Register the (Face Detect) function to the button
(p. 108).
1
Select a face you wish to focus on.
1. When a face is detected, press the button.
• The camera enters face
designation mode, and the face
frame ( ) of the main subject
displays in green. Even if the
subject moves, the frame will follow
the subject within a certain range.
2. Select the person you wish to focus
on.
• When several faces have been detected, pressing the or
button will move the face frame to another subject.
• The face frame will not display when a face is not detected.
• Holding down the DISP. button will
display face frames (up to 35) of all
the detected faces (green: face of
main subject, white: detected
faces).
• Pressing the button will release
the face designation mode.
Face Frame
Face Frame
95
Advanced Shooting Functions
3. Press the button again.
• The camera exits face designation
mode, and the face frame ( ) of
the main subject will change to
white (the frame will continue to
follow the subject within a certain
range).
2
Press the shutter button halfway.
• The face frame ( ) of main subject will change into .
3
Press the shutter button fully to shoot.
In the following cases, the face select mode will be canceled.
- When turning the power back on
- Using the digital zoom
- When the button is pressed to display the menu
- When a selected face cannot be tracked for several seconds
- When the display is turned off
96
It may be difficult to focus on the following types of subjects.
• Subjects with extremely low contrast to the surroundings
• Scenes with a mixture of near and far subjects
• Subjects with extremely bright objects at the center of the
composition
• Subjects that are moving quickly
• Subjects through glass
Shooting with the Focus Lock
Shooting Hard-to-Focus Subjects (Focus
Lock, Manual Focus, Safety MF)
Available Shooting Modes p. 201
1
Aim the camera so that an object at the same
focal distance as the main subject is centered
in the viewfinder or in the AF frame displayed
on the LCD monitor.
2
Keep the shutter button pressed halfway while
you recompose the image.
3
Press the shutter button fully to shoot the
image.
z AF frames do not display in mode.
z When shooting with the focus lock using the LCD monitor,
setting [AF Frame] to [Center] (p. 92) makes shooting easier
since the camera focuses using the center AF frame only.
z Try to shoot as close to the glass as possible to reduce the
chances of light reflecting back off the glass when you shoot
a subject through glass.
97
Advanced Shooting Functions
Shooting in Manual Focus Mode
The focus can be manually set.
To Cancel the Manual Focus:
Press the MF button and use the or button to select
(Normal).
1
Turn on the LCD monitor.
2
Press the MF button.
1. Use the or button to
select .
• When the menu’s [MF-Point
Zoom] is set to [On], the portion of the
image in the AF frame will appear
magnified* (p. 50).
* The image will not appear magnified in mode, when the digital zoom is
used or when a TV is used as the display.
• Depending on the shooting mode, pressing the button will
switch between the setting items as follows:
3
Use the or button and adjust the focus.
• The MF indicator shows approximate figures. Use them as a
shooting guideline only.
, , , , , Exposure compensation/
mode/Exposure compensation/
mode/
Shutter speed/Exposure compensation/
Aperture value/Exposure compensation/
Shutter speed/Aperture value/
98
Using the Manual Focus in Combination with the Auto
Focus (Safety MF)
First, manual focus is used to roughly focus, then from that focus
position the camera automatically focuses more accurately.
1
Select [Safety MF].
1.Press the button.
2.In the menu, use the or
button to select [Safety MF].
2
Make settings.
1.Use the or button to select
[On].
2.Press the button.
3
First focus manually and then press the
shutter button halfway.
• The focus will be fine-tuned to the optimal focus.
4
To shoot, press the shutter button fully.
99
Advanced Shooting Functions
Adjust the exposure compensation to a positive value to avoid making
the subject too dark when it is backlit or shot against a bright
background. Adjust the exposure compensation to a negative value to
avoid making the subject too bright in night shots or when shot against
a dark background.
To Cancel the Exposure Compensation:
Follow step 3 to restore the compensation value to [0].
Adjusting the Exposure Compensation
Available Shooting Modes p.201
1
Turn on the LCD monitor.
2
Press the button to display the exposure
compensation bar.
3
Configure the setting.
1.Use the or button to adjust the
exposure compensation.
2.Press the button.
• Depending on the shooting mode, pressing the button will
switch between the setting items as follows:
mode/Exposure compensation
Shutter speed/Exposure compensation
Aperture value/Exposure compensation
100
Switching between Metering Modes
Available Shooting Modes p.201
Evaluative
Appropriate for standard shooting conditions,
including backlit scenes. The camera divides
images into several zones for metering. It
evaluates complex lighting conditions, such as
the position of the subject, the brightness, the
direct light, and the backlighting, and adjusts the
settings to the correct exposure for the main
subject.
Center Weighted
Avg.
Averages the light metered from the entire
frame, but gives greater weight to the subject
matter at the center.
Spot
Use when there is a large variance in brightness
between the subject and the surroundings. Sets
the exposure to suit the subject at the center of
the composition.
1
Change the metering mode.
1.Press the button.
2.Use the or button to select
and the or button to change
the option.
3.Press the button.
101
Advanced Shooting Functions
Normally, the (Auto) white balance setting selects an optimal white
balance. When the setting cannot produce natural looking colors,
change the white balance using a setting appropriate for the light
source.
Adjusting the Tone (White Balance)
Available Shooting Modes p.201
Auto Settings are automatically set by the camera.
Day Light For recording outdoors on a bright day.
Cloudy
For recording under overcast, shady or twilight skies.
Tungsten
For recording under tungsten and bulb-type 3-
wavelength fluorescent lighting.
Fluorescent
For recording under warm-white, cool-white or
warm-white (3-wavelength) fluorescent lighting.
Fluorescent H
For recording under daylight fluorescent, or daylight
fluorescent-type 3-wavelength fluorescent lighting.
Custom
For recording with the optimal white balance data
memorized in the camera from a white-colored
object, such as white paper or cloth.
1
Select a white balance
setting.
1.Press the button.
2.Use the or button to select
and the or button to change
the option.
3.Press the button.
The white balance setting cannot be adjusted when or
is selected for My Colors.
102
Using the Custom White Balance
Take a custom white balance (Custom) reading for the following
situations that are difficult for the (Auto) setting to detect
correctly.
• Shooting subjects of monotone color (such as sky, sea or forest)
• Shooting with a particular source of light (such as a mercury-vapor
lamp)
• Shooting close-ups (Macro)
1
Select .
1.Press the button.
2.Use the or button to select
and use the or button to
select .
2
Aim the camera at a piece
of white paper or cloth and
press the button.
• Ensure that the LCD monitor is
completely filled with the white
image. Please note, however, that
the center frame will not display when the digital zoom is used
or when is displayed.
• You can also use the viewfinder to take a custom white
balance reading.
3
Press the button.
103
Advanced Shooting Functions
z You are recommended to set the shooting mode to and
the exposure compensation setting to [±0] before setting a
custom white balance. The correct white balance may not
be obtained when the exposure setting is incorrect (image
appears completely black or white).
z Shoot with the same settings as when reading the white
balance data. If the settings differ, the optimal white
balance may not be set. In particular, the following should
not be changed.
-ISO speed
-Flash:
Setting the flash to or is recommended. If the
flash fires when reading the white balance data with the
flash set to , make sure that you also use the flash
when you shoot.
z The white balance data is retained even after the camera
power is turned off.
104
You can change the look of an image when it is shot.
///
Shooting in a My Colors Mode
Available Shooting Modes p.201
My Colors Off Records normally with this setting.
Vivid
Emphasizes the contrast and color saturation to
record bold colors.
Neutral
Tones down the contrast and color saturation to
record neutral hues.
Sepia Records in sepia tones.
B/W Records in black and white.
Custom Color
Use this option to adjust contrast, sharpness
and saturation before shooting.
1
Select a My Colors setting.
1.Press the button.
2.Use the or button to select
and the or button to change
the option.
3.Press the button.
105
Advanced Shooting Functions
(Setting the Custom Color Mode)
1
Select .
1.Press the button.
2.Use the or button to select
and the or button to select .
2
Adjust the setting.
1.Press the button.
2.Use the or button to select
[Contrast], [Sharpness] or
[Saturation].
3.Use the or button to adjust the
setting.
• The adjustment results show in the
LCD monitor.
• If you press the DISP. button, you will return to the screen
where you can select a My Colors mode.
4.Press the button.
• Return to the shooting screen to shoot.
Select an item Adjust
106
You can display vertical and horizontal grid lines, a 3:2 print area
guide, or both on the LCD monitor while shooting to help check the
position of your subject.
Setting the Display Overlays
Available Shooting Modes p.201
Off –
Grid Lines
Displays grid lines to divide the screen into 9 parts. Helps
confirm the vertical and horizontal positioning of the subject.
3:2 Guide
Helps confirm the print area for L-size or postcard size in 3:2
aspect ratio*. Areas outside the printable area are grayed out.
* Images are still recorded at the standard aspect ratio of 4:3.
Both Displays both the grid lines and the 3:2 guide simultaneously.
1
Select [Disp. Overlay].
1.Press the button.
2.In the menu, use the or
button to select [Disp. Overlay].
2
Make settings.
1.Use the or button to select the
option.
2.Press the button.
z Only grid lines can be configured for the or mode.
z The grid lines and 3:2 guide will not be recorded in the
image.
107
Advanced Shooting Functions
If you set Auto Category to [On], images are automatically sorted into
preset categories as they are recorded.
Categorizing Images Automatically
(Auto Category)
Available Shooting Modes p.201
People
For images shot in , or mode, or images with
faces detected when [AF Frame] is set to [Face Detect].
Scenery For images shot in , , or mode.
Events For images shot in , , , or mode.
1
Select [Auto Category].
1.Press the button.
2.In the menu, use the or
button to select [Auto Category].
2
Make settings.
1.Use the or button to select [On]
or [Off].
2.Press the button.
Movies are not automatically categorized, but they can be
categorized using the My Category function (p.116).
108
You can register a function that you often use when shooting with the
button.
To Cancel the Shortcut Button:
Select in Step 2.
Registering Settings to the Button
Available Shooting Modes p.201
Menu Item Page Menu Item Page
Not Assigned – Red-Eye Corr. p.86
Face Select and
Track
p.92
Digital
Tele-converter
p.59
ISO Speed p.68 DISP. Overlay p. 106
White Balance p. 101 Display Off p.52
Custom White
Balance
p.102
1
Select [Set button].
1.Press the button.
2.In the menu, use the or
button to select [Set button].
3.Press the button.
2
Make settings.
1.Use the , , or button to
select the function you wish to
register.
2.Press the button.
• If displays to the icon’s lower right,
you can register the function, but you cannot use it with some
shooting modes or settings even if you press the button.
• Pressing the MENU button completes the setting.
109
Advanced Shooting Functions
Using the Button
1
Press the button.
• For , and , each time that the button is pressed,
the settings of the registered functions are switched.
• For , and , the corresponding setup screen is
displayed.
• For , each press of the button records the white
balance data. Since the frame does not appear at this point,
ensure that the white paper or cloth is positioned so it appears
at the center of the LCD monitor and then press the
button. After using this function once, the white balance setting
changes to .
• For , pressing the button turns off the LCD monitor.
The next time a button is pressed, the LCD monitor will turn
back on.
110
Playback/Erasing
Please also see Viewing Still Images (p.18).
To Cancel the Magnified Display:
Press the zoom lever toward . (You can also cancel it immediately
by pressing the MENU button.)
Viewing Magnified Images
1
Press the zoom lever
toward .
• will display at the upper right
and a magnified portion of the image
will display.
• Images can be magnified up to a
factor of approximately 10x.
2
Use the , , or button to move around
the image.
• If you press the FUNC./SET button while in magnified display,
the camera switches to image advance mode and will
display. You can use the or button to advance to the next
or previous image at the same level of magnification. The image
advance mode is cancelled when you press the FUNC./SET
button again.
• You can change the magnification level with the zoom lever.
Movie frames and index playback images cannot be magnified.
Approximate location
of the displayed area
111
Playback/Erasing
To Return to Single Image Playback:
Press the zoom lever toward .
Viewing Images in Sets of Nine
(Index Playback
)
1
Press the zoom lever
toward .
• Up to nine images can be viewed at
once in index playback.
• Use the , , or button to
change the image selection.
Switching between Sets of Nine Images
The jump bar will display if you press the zoom lever toward while
in index playback and you can switch the display between sets of
nine images.
• Use the or button to move to the
previous or next set of 9 images.
• Hold the FUNC./SET button down and
press the or button to jump to the
first or last set.
To Return to Single Image Playback:
Press the zoom lever toward .
Selected Image
Movie
Jump Bar
112
Focus Check display allows you to check the focus of images taken.
Moreover, as you can change the display size and switch images, you
can easily check facial expressions and whether a subject’s eyes are
closed.
Displaying the Focus Check
Check the Focus and Facial Expressions
of Subjects (Focus Check Display)
1
Set the mode switch to
(playback).
2
Press the button several
times until the Focus Check
displays.
• Frames are displayed on the image as follows.
• The orange frames allow you to change the display size, move
the display position, and switch between display frames
(p.113).
Frame color Content
Orange Displays the range of the image displayed at bottom
right.
White The frame is displayed at a position at which the
image is in focus.
Gray Displays frames in positions where faces were
detected during playback.
113
Playback/Erasing
Changing the Display Size and Switching Frames
To Cancel Changing the Display Position:
Press the MENU button.
Switching Frames
3
Press the zoom lever
toward .
• Bottom right of the screen will be
displayed prominently and the display
size and display position can be
changed.
4
Change the setting.
• You can change the display size by
pressing the zoom lever.
• You can change the display position
by using the , , or button.
• When you press the FUNC./SET
button, the orange frame returns to its
original position. When there are multiple frames displayed, the
FUNC./SET button changes the position of the orange frame.
3
Press the button.
• When multiple in-focus frames are
displayed, or when multiple faces are
detected, the position of the orange
colored frame will change each time
the FUNC./SET button is pressed.
After you change the display size, the
orange frame will adjust to the size of the face when you switch
the position of the frame.
114
When you have many images recorded onto a memory card, it is
handy to use the search keys below to jump over images to find the
object of your search.
Jumping to Images
Jump Shot Date Jumps to the first image of each
shooting date.
Jump to My
Category
Jumps to the first image of each folder
sorted by the Auto Category (p.107) or
My Category (p. 116) functions.
Jump to Folder Displays the first image in each folder.
Jump to Movie Jumps to a movie.
Jump 10 images Jumps over 10 images at a time.
Jump 100 images Jumps over 100 images at a time.
1
In single image playback mode, press the
button.
• The camera will switch to jump search mode.
2
Use the or button to
select a search key.
• You can show/hide image
information using the DISP. button.
• When an image is not categorized,
My Category will not display.
Image Information
115
Playback/Erasing
To Return to Single Image Playback:
Press the MENU button.
3
Display the Images.
1.Press the or button.
• Pressing the MENU button cancels
the setting.
•
Press the
FUNC./SET
button to display
the movie control panel
(p.118)
when
the is selected
.
Number of images matching
search key
Location of image currently
being displayed
116
You can organize images into prepared categories. Once organized
into categories, you can jump to and display the image you want
(p.114).
Organizing Images by Category
(
My Category)
People My Category 1 – 3
Scenery To Do
Events
1
Select [My Category].
1.Press the button.
2.In the menu, use the or
button to select .
3.Press the button.
2
Make settings.
1.Use the or button to select an
image to classify.
2.Use the or button to select a
category.
3.Press the button.
• You can cancel the classification by pressing the FUNC./SET
button again.
• Press the MENU button to complete the setting.
• You can also set this in index playback.
117
Playback/Erasing
Viewing Movies
1
Display a movie.
1.Use the or button to select a
movie.
2.Press the button.
• Images with a icon are movies.
2
Play the movie.
1.Use the or button to select
.
2.Press the button.
• The movie will pause if you press
the FUNC./SET button during
playback. It will resume when you
press the button again.
• When playback ends, the movie
stops at the last frame displayed.
Press the FUNC./SET button to
display the movie control panel.
• You can switch between showing/hiding the playback progress
bar by pressing the DISP. button while playing a movie.
• If playback was halted partway through in the prior viewing
session, playback will resume from the last frame displayed.
Volume Level
(Adjust it with the or
button)
Movie Control Panel
Playback Progress Bar
Time movie was shot
118
Operating the Movie Control Panel
Exit Ends playback and returns to single image playback.
Print
An icon will display when a printer is connected. See
the Direct Print User Guide for details.
Play Play.
Slow Motion
You can use the button to slow down or the
button to speed up playback.
First Frame Displays the first frame.
Previous
Frame
Rewinds if the FUNC./SET button is held down.
Next Frame Fast Forwards if the FUNC./SET button is held down.
Last Frame Displays the last frame.
Movies cannot be played in the index playback mode.
z Use the television’s controls to adjust the volume when
playing a movie on a TV set (p.148).
z The sound cannot be played in slow motion playback.
119
Playback/Erasing
Images can be rotated clockwise 90° or 270° in the display.
Rotating
Images in the Display
1
Select [Rotate].
1.Press the button.
2.In the menu, use the or
button to select .
3.Press the button.
2
Rotate the image.
1.Use the or button to select an image to rotate.
2.Press the button.
• Cycle through the 90°/270°/original orientations with each press
of the FUNC./SET button.
• This also can be set in the index playback mode.
When images are downloaded to a computer, the orientation of
images rotated by the camera will depend upon the software
used to download the images.
As the orientation of an image is recorded, the image will be
shown in its rotated orientation the next time it is displayed.
Original 90° 270°
120
You can select the transition effect displayed when switching between
images.
Playback with Transition Effects
No transition effect.
The displayed image darkens and the next image gradually brightens
until it is displayed.
Press the button to have the previous image display from the left
and the button to have the next image display from the right.
1
Select [Transition].
1.Press the button.
2.In the menu, use the or
button to select .
2
Make settings.
1.Use the or button to select a
transition effect.
2.Press the button.
121
Playback/Erasing
Use this feature to automatically play back all of the images in the
memory card. The LCD monitor displays each image for approximately
3 seconds.
Automated Playback (Slide Shows)
No transition effect.
The new image gradually brightens as it moves upward from the
bottom.
The previous image moves to the left and the next image display
from the right.
1
Select [Slide Show].
1.Press the button.
2.In the menu, use the or
button to select .
3.Press the button.
2
Select an effect.
1.Use the or button to select an
effect and make it active.
122
You can correct red eyes in recorded images.
3
Play.
1.Press the button.
• The following functions are available during slide shows.
- Pausing/resuming the slide show: press the FUNC./SET
button.
- Fast forwarding/rewinding the slide show: press the or
button (continue to hold the button to switch between images
more rapidly).
- Stopping the slide show: press the MENU button.
In single image playback mode, you can start a slide show from
the current image displayed by holding the FUNC./SET button
while you press the button. Please note that if you do
this while the last image shot is displayed, the slide show will
start from the first image using the same date.
Red-Eye Correction
Function
Red eyes may not be automatically detected in some images
or the results may not turn out as you intended.
Werecommend that you use [New File] to save corrected
images.
Examples:
- Faces near the screen edges or faces that appear extremely
small, large, dark or bright in relation to the overall image.
- Faces turned to the side or at a diagonal, or faces with a
portion hidden.
123
Playback/Erasing
1
Select [Red-Eye Correction].
1.Press the button.
2.In the menu, use the or
button to select .
3.Press the button.
2
Select an image.
1.Use the or button to select the
image you wish to correct red eyes.
2.Press the button.
• A frame will automatically display
where red-eye is detected.
• If red-eye is not automatically detected, select [Add Frame] with
the or button and press FUNC./SET button (p.125).
• To cancel the correction frame, select [Remove Frame] and
press the FUNC./SET button (p.126).
3
Correct the image.
1.Use the or button to select
[Start].
2.Press the button.
124
4
Save the image.
1. Use the or button to select
[New File] or [Overwrite].
2. Press the button.
• [New File]: Saved as new file with a
new name. The uncorrected image is
stored. The new image is stored as the last file.
• [Overwrite]: Saved with the same file name as the uncorrected
image. The uncorrected image is erased.
• When [New File] is selected, proceed to the procedure 5.
• If you wish to continue correcting another image, repeat
operations from step 2.
5
Display the saved image.
1. Press the button.
2. Use the or button to select
[Yes].
3. Press the button.
• Selecting [No] returns to the Play
menu.
z Red-eye correction cannot be performed on movies.
z Overwriting cannot be performed on protected images.
z When there is not enough space left on the memory card,
red-eye correction cannot be performed.
z Although you can apply red-eye correction any number of
times to an image, the image quality will gradually deteriorate
with each application.
z Since the correction frame will not appear automatically on
images that have already been corrected once with the Red-
Eye Correction function, use the [Add Frame] option to
correct them.
125
Playback/Erasing
Add Correction Frame
1
Select [Add Frame].
1. Use the , , or button to
select [Add Frame].
2. Press the button.
• A green frame will display.
2
Adjust the position of the
correction frame.
1. Use the , , or button to
move the frame.
• Size of the frame can be changed
with the zoom lever.
3
Add additional correction frames.
1. Press the button.
• A correction frame is added and the frame color changes to
white.
• If you wish to add additional frames, adjust the position and
press the FUNC./SET button.
• Up to 35 additional frames can be added.
• To end the adding of correction frames, press the MENU
button.
To correctly perform red-eye correction, take note of the
following (refer to the image in step 2):
- Adjust the correction frame size so that it only surrounds
the red-eye portion to be corrected.
- When there are several subjects with red-eye, be sure to
add one correction frame per subject.
126
Removing Correction Frames
1
Select [Remove Frame].
1. Use the , , or button to
select [Remove Frame].
2. Press the button.
2
Adjust the position of the
correction frame.
1. Use the or button to select a
frame to remove.
• The selected frame will appear in
green.
3
Delete the frame.
1. Press the button.
• The selected frame will disappear.
• To continue deleting frames, repeat operations from step 2.
• When you finish deleting frames, press the MENU button.
127
Playback/Erasing
You can resave images that were recorded at high recording pixel
settings at lower settings.
Changing the Recording Pixel (Resize)
1600 × 1200 pixels
640 × 480 pixels
320 × 240 pixels
1
Select [Resize].
1. Press the button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Select an image.
1. Use the or button to select an
image to resize.
2. Press the button.
•The FUNC./SET button is not
selectable for images that cannot be
resized.
3
Select a resolution.
1. Use the or button to select a
resolution.
2. Press the button.
• If a resolution cannot be selected due
to a lack of free space on the memory
card, will display.
128
4
Save the image.
1. Use the or button to select
[OK].
2. Press the button.
• The resized image will be saved in a
new file. The original image will
remain.
• If you wish to continue resizing of another image, repeat
operations from step 2.
5
Display the saved image.
1. Press the button.
2. Use the or button to select
[Yes].
3. Press the button.
• Selecting [No] returns to the Play
menu.
and images shot in mode cannot be resized.
129
Playback/Erasing
In playback mode, you can attach sound memos (up to 1 min.) to an
image. The sound data is saved in the WAVE format.
Attaching
Sound Memos to Images
1
Select [Sound Memo].
1. Press the button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Select an image.
1. Use the or button to select an
image to which you wish to attach a
sound memo.
2. Press the button.
• The sound memo control panel will
display.
3
Record the memo.
1. Use the or button to select .
2. Press the button.
• The elapsed time and the remaining
time display.
• Pressing the FUNC./SET button
pauses the recording. Pressing it
again resumes recording.
• Up to 1 minute of recordings can be
added to any one image.
• Press the MENU button several times
to complete the setting.
Volume
(Adjust it with the or
button)
Elapsed Time/
Remaining Time
Sound Memo Panel
130
Sound Memo Panel
Use the or button to select an option and press FUNC./SET
button.
Exit Returns to the playback screen.
Record Starts recording.
Pause Pauses recording or playback.
Play Begins playback.
Erase
Erases sound memos. (Select [Erase] and in the
confirmation screen press the FUNC./SET button.)
z You cannot attach sound memos to movies.
z Sound memos for protected images cannot be erased.
131
Playback/Erasing
You can protect important images and movies from accidental erasure.
Protecting Images
1
Select [Protect].
1. Press the button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Protect an image.
1. Use the or button to select an
image to protect.
2. Press the button.
• The protection icon appears on the
lower left of image.
• Pressing the FUNC./SET button again
cancels the setting.
• If you wish to continue protecting of another image, repeat
operations.
• You can also protect images in the index playback mode.
• Press the MENU button to complete the setting.
Protection Icon
132
You can erase images from a memory card.
Erasing All Images
z Note that erased images cannot be recovered. Exercise
adequate caution before erasing an image.
z Protected images cannot be erased with this function.
1
Select [Erase all].
1. Press the button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Erase the images.
1. Use the or button to select
[OK].
2. Press the button.
• To exit instead of erasing, select
[Cancel].
Please format the memory card when you want to erase not
only image data but also all the data contained on the memory
card (p. 141).
133
Print Settings/Transfer Settings
You can select images on a memory card for printing and specify the
number of print copies in advance using the camera. The settings used
on the camera comply with the Digital Print Order Format (DPOF)
standards. This is extremely convenient for printing on a direct print
compatible printer, or for sending the images to a photo developing
service that supports DPOF.
Setting the Print Style
After setting the print style, select the images for printing. The following
settings can be selected.
* Default setting
Setting the DPOF Print Settings
z The specified print settings are also applied to the Print List
(p. 21).
z The output of some printers or photo developing services
may not reflect the specified print settings.
z Print settings cannot be set for movies.
z The icon may display for a memory card with print
settings set by a different DPOF-compliant camera. These
settings will be overwritten by those set by your camera.
Print
Type
Standard* Prints one image per page.
Index
Prints the selected images together at a
reduced size in an index format.
Both
Prints the images in both the standard and
index formats.
Date (On/Off*) Adds the date to the print.
File No. (On/Off*) Adds the file number to the print.
Clear DPOF data (On*/Off) Clears all print settings after the images print.
Print Settings/Transfer Settings
134
1
Select [Print Settings].
1. Press the button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Print Settings].
4. Press the button.
2
Make settings.
1. Use the or button to select an
option.
2. Use the or button to specify the
settings.
3. Press the button.
z The Date and File No. settings change according to the Print
Type as follows.
- [Index]:
[Date] and [File No.] cannot be set to [On] at the same time.
- [Standard] or [Both]:
[Date] and [File No.] can be set to [On] at the same time,
however, the printable information may vary between
printers.
z Images dated using (Date Stamp) (p. 22) are always
printed with the date, regardless of the [Date] setting. As a
result, some printers may print the date twice on these
images if [Date] is also set to [On].
z Dates print in the style specified in [Date/Time] in the
menu (p. 52).
135
Print Settings/Transfer Settings
Single Images
When [Print Type] (p. 133) is set to [Standard] or [Both], the number of
copies can be set.
1
Select [Select Images &
Qty.].
1. Press the button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Select Images & Qty.].
4. Press the button.
2
Select the images.
• Selection methods differ for the Print Type settings (p. 133).
Standard ( )/Both ( ):
1. Use the or button to select the
images.
2. Press the button.
3. Use the or button to select the
number of print copies (up to 99).
4. Press the button.
Index ( ):
1. Use the or button to select the
images.
2. Select and deselect with the
button.
3. Press the button.
• You can also select images in the
index playback mode.
Number of Print Copies
Index Print Selection
136
All the Images on a Memory Card
One copy of every image will be set to print.
1
Select [Select All Images].
1. Press the button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Select All Images].
4. Press the button.
2
Select [OK].
1. Use the or button to select
[OK].
2. Press the button.
z Images are printed in order according to the file number.
z A maximum of 998 images can be selected.
z When the camera is connected to a printer, the button
will light blue. At this time, press the button, confirm
that [Print] is selected, and when the FUNC./SET button is
pressed, printing will begin.
z Selecting [Clear All Selections] in Step 1 cancels all print
settings.
137
Print Settings/Transfer Settings
You can use the camera to specify settings for images before
downloading to a computer. Refer to the Software Starter Guide for
instructions on how to transfer images to your computer. The settings
used on the camera comply with the DPOF standards.
Setting the DPOF Transfer Settings
The icon may display for a memory card with transfer
settings set by a different DPOF-compliant camera. These
settings will be overwritten by those set by your camera.
1
Select [Transfer Order].
1. Press the button.
2. In the menu, use the or
button to select .
3. Press the button.
2
Select an order method.
1. Use the or button to select an
order method.
Order : Select single images.
Mark all : Select all the images on a
memory card.
2. Press the button.
• Selecting [Reset] cancels all transfer order settings.
138
Single Images
Mark all
3
Select an image to transfer.
1. Use the or button to select an
image to transfer.
2. Press the button.
•Pressing the FUNC./SET button
again deselects the setting.
• You can also select images in the
index playback mode.
3. Press the button several times to end the setting.
3
Execute the transfering
images.
1. Use the or button to select
[OK].
2. Press the button.
z Images are transferred in order according to the file number.
z A maximum of 998 images can be selected.
Transfer Selection
139
Configuring the Camera
This camera is equipped with a power saving function, which can
automatically turn off the power or LCD monitor.
Power Saving Function
Auto Power Down When set to [On], the power will shut off in the following
circumstances. Press the ON/OFF button again to
restore power.
Shooting mode: approximately 3 minutes after the last
control is accessed on the camera
Playback mode or when connected to a printer:
approximately 5 minutes after the last control is
accessed on the camera.
Display Off In shooting mode, the LCD monitor automatically turns
off after the selected time if no control is accessed,
regardless of the [Auto Power Down] setting. Press any
button other than the ON/OFF button or change the
camera orientation to turn the LCD monitor back on.
1
Select [Power Saving].
1. Press the button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Power Saving].
4. Press the button.
Configuring the Camera
140
2
Make settings.
1. Use the or button to select an
option.
2. Use the or button to make
settings.
3. Press the button.
3
Press the button.
The power saving function will not activate during a slide show
or while the camera is connected to a computer.
141
Configuring the Camera
You should always format a new memory card or one from which you
wish to erase all images and other data.
Formatting Memory Cards
Please note that formatting (initializing) a memory card erases
all data, including protected images and other file types.
1
Select [Format].
1. Press the button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Format].
4. Press the button.
2
Make settings.
1. Use the or button to select
[OK].
2. Press the button.
• To perform a low level format, use the
button to select [Low Level
Format] and the or button to
add a check mark.
• You can stop formatting a memory card when [Low Level
Format] is selected by pressing the FUNC./SET button. You can
still use a memory card without problem when formatting is
halted, but its data will be erased.
Low Level Format
We recommend you select [Low Level Format] when you think
that the recording/reading speed of a memory card has
dropped. A low level format may require 2 to 3 minutes with
some memory cards.
142
The images you shoot are automatically assigned file numbers. You
can select how the file number is assigned.
Resetting the File Number
Continuous
A number one higher than the last one recorded is assigned
to the next image. This is convenient for managing all your
images together on a computer because you avoid file name
duplication when changing folders or memory cards.*
* When a blank memory card is used. If a memory card with recorded
data is used, the 7-digit number for the last recorded folder and
image is compared with the last one on the memory card, and the
larger of the two is utilized as the basis for new images.
Auto Reset
The image and folder number are reset to the starting value
(100-0001).* This is convenient for managing images on a
folder-by-folder basis.
* When a blank memory card is used. If a memory card with recorded
data is used, the number following the 7-digit number for the last
recorded folder and image on the memory card is utilized as the
basis for new images.
1
Select [File Numbering].
1. Press the button.
2. Use the or button to select the
menu.
3. Use the or button to select
[File Numbering].
2
Make settings.
1. Use the or button to select a
file numbering setting.
2. Press the button.
143
Configuring the Camera
File and Folder Numbers
Recorded images are assigned consecutive file numbers starting with
0001 and ranging up to 9999, while folders are assigned numbers
starting with 100 and ranging up to 999. Up to 2000 images can be
saved into a single folder.
• Images may be saved to a new folder when there is insufficient free space even if the
total number of images in a folder is less than 2000 because the following types of
images are always saved together into the same folder.
• Images from continuous shooting • Self-timer images (custom)
• Images cannot be played back when the folder numbers are duplicated or image
numbers are duplicated within folders.
• Please refer to the Software Starter Guide for information regarding folder structures
or image types.
New Folder Created Memory Card Exchanged for Another
Continuous
Memory Card 1
Memory Card 1 Memory Card 2
Auto Reset
Memory Card 1 Memory Card 1 Memory Card 2
144
You can create a new folder at any time and the recorded images will
be automatically saved to that folder.
Creating a Folder the Next Time You Shoot
Creating an Image Destination (Folder)
Create New
Folder
Creates a new folder the next time you shoot images. To
create an additional folder, insert the check mark again.
Auto Create
You can also specify a date and time if you wish to create a
new folder using a shooting time after the specified date and
time.
1
Select [Create Folder].
1. Press the button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Create Folder].
4. Press the button.
2
Make settings.
1. Use the or button to check
mark [Create New Folder].
2. Press the button.
• will be displayed on the LCD
monitor when shooting. The symbol
icon will disappear from the screen when a new folder is
created.
145
Configuring the Camera
Setting the Day or Time for Automatic Folder
Creation
1
Select [Create Folder].
1. Press the button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Create Folder].
4. Press the button.
2
Make settings.
1. Use the or button to select
[Auto Create] and the or button
to select a creation date.
2. Use the or button to select
[Time] and the or button to
select a time.
3. Press the button.
• displays when the specified time arrives. The symbol will
cease to display after the new folder is created.
Up to 2000 images can be saved into one folder. A new folder
will automatically be created when you record more than that
number even if you are not creating new folders.
146
Your camera is equipped with an Intelligent Orientation sensor that
detects the orientation of an image shot with the camera held
vertically and automatically rotates it to the correct orientation when
viewing it in the LCD monitor.
Setting the Auto Rotate Function
1
Select [Auto Rotate].
1. Press the button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Auto Rotate].
2
Make settings.
1. Use the or button to select [On]
or [Off].
2. Press the button.
• When the Auto Rotate function is set
to [On] and the LCD monitor is set to
the detailed display mode in the shooting mode, (normal),
(right end is down) or (left end is down) will appear in the
display.
z This function may not operate correctly when the camera is
pointed straight up or down. Check that the arrow is
pointing in the right direction and if it is not, then set the Auto
Rotate function to [Off].
z Even if the Auto Rotate function is set to [On], the orientation
of images downloaded to a computer will depend upon the
software used to download the images.
147
Configuring the Camera
When the camera is held vertically to shoot, the Intelligent
Orientation sensor judges the upper end to be “up” and the
lower end to be “down”. It then regulates the optimal white
balance, exposure and focus for vertical photography. This
function operates regardless of the on/off status of the Auto
Rotate function.
Resetting Settings to Their Default
Values
1
Select [Reset All].
1. Press the button.
2. Use the or button to select the
menu.
3. Use the or button to select
[Reset All].
4. Press the button.
2
Make settings.
1. Use the or button to select
[OK].
2. Press the button.
z Settings cannot be reset when the camera is connected to a
computer or to a printer.
z The following cannot be reset.
- The shooting mode.
- The [Date/Time], [Language] and [Video System] options
in the menu (pp. 52, 53)
- White balance data recorded with the custom white
balance function (p. 102)
148
Connecting to a TV
You can use the supplied AV cable to shoot or playback images using
a TV.
Shooting/Playback Using a TV
1
Turn off the camera and the TV.
2
Connect the AV cable to
the camera’s A/V OUT
terminal.
• Open the terminal cover and plug
the AV cable in all the way.
3
Plug the other ends of the
AV cable to the VIDEO IN
and AUDIO IN jacks on the
TV.
4
Turn on the TV and switch it to video mode.
5
Turn on the camera.
VIDEO
Yellow
Black
AUDIO
149
Connecting to a TV
z The video output signal can be switched (NTSC or PAL) to
accommodate different regional standards (p. 53). The
default setting varies between regions.
- NTSC: Japan, U.S.A., Canada, Taiwan and others
- PAL: Europe, Asia (excluding Taiwan), Oceania and others
z If the video system is set incorrectly, the camera output may
not display properly.
150
Troubleshooting
• Camera (p. 150)
• When the power is turned on (p. 151)
• LCD monitor (p. 151)
• Shooting (p. 153)
• Shooting movies (p. 157)
• Playback (p. 158)
• Battery (p. 159)
• TV monitor output (p. 159)
• Printing with a direct print compatible printer (p. 160)
Camera
Camera will not operate.
Power is not turned on. z Press the ON/OFF button (p. 42).
Memory card slot/battery
cover is open.
z Confirm that the Memory card slot/
battery cover is securely closed
(p. 11).
Batteries are loaded in the
wrong direction.
z Reload the batteries in the correct
direction (p. 10).
Batteries are not the right
type.
z Use only unused AA-size alkaline
batteries or Canon AA-size NiMH
batteries (p. 10).
Battery charge is low and
the camera will not
operate. (“Change the
batteries” message
displays).
z Replace the camera batteries with two
unused or fully charged batteries
(p. 10).
z Use the AC Adapter Kit ACK800 (sold
separately) (pp. 36, 177).
Poor contact between
camera and battery
terminals.
z Poor contact between camera and
battery terminals.
z Reload the batteries several times.
151
Troubleshooting
Sounds come from the camera interior.
The camera’s horizontal/
vertical orientation was
changed.
z The camera’s orientation mechanism
is operating. There is no malfunction.
When the power is turned on
“Card locked!” message appears.
The SD memory card’s or
SDHC memory card’s
write protect tab is set to
“Write protect”.
z When recording to, erasing from or
formatting the memory card, slide the
write protect tab upward (p. 172).
The Date/Time menu appears.
The lithium date battery
charge is depleted.
z Replace the lithium date battery
(p. 184).
The battery holder was
removed.
z The date and time settings need to be
reset since they were lost (p. 13).
LCD monitor
Nothing displays.
The LCD monitor is set
not to display.
z Press the DISP. button to turn on the
LCD monitor (p. 54).
[Power Saving] is set to
[Display Off].
z Press any button other than the
ON/OFF button or change the camera
orientation to turn the LCD monitor
back on (p. 139).
The display darkens.
The image in the LCD
monitor will darken in
strong sunlight or bright
light.
z This is a normal occurrence in devices
containing CCDs and does not
constitute a malfunction. This image
will not be recorded when shooting
still photos, but it will be recorded
when shooting movies.
152
Display flickers.
Display flickers when shot
under fluorescent lighting.
z This is not a camera malfunction
(flickering recorded in movies, but not
in still images).
A bar of light (purplish red) appears on the LCD
monitor.
Sometimes appears when
shooting a bright subject,
such as the sun or other
light source.
z This is a normal occurrence in devices
containing CCDs and does not
constitute a malfunction. This bar of
light will not be recorded when
shooting still photos, but it will be
recorded when shooting movies.
appears.
A slow shutter speed has
likely been selected
because of insufficient
lighting.
z Set the IS Mode to any setting other
than [Off] (p. 66).
z Raise the ISO speed (p. 68).
z Set the flash to any setting other than
(flash off) (p. 60).
z Set the self-timer and secure the
camera to something, such as a tripod
(p. 62).
appears.
This displays when using
a memory card that has
print settings, transfer
settings or slide show
image settings set by
other DPOF-compliant
cameras.
z These settings will be overwritten by
those set by your camera
(pp. 133, 137).
153
Troubleshooting
Noise displays./Subject’s movements are
irregular.
Camera automatically
lightened the image
displayed on the LCD
monitor to make it easier
to see when shooting in a
dark area (p. 55).
z There is no effect on the recorded
image.
Shooting
Camera will not record.
Camera is in playback
mode or connecting to a
computer/printer mode.
z Switch to Shooting mode (p. 15).
Flash is charging. z When the flash is charged, the
indicator will light orange. Shooting is
now possible (p. 43).
Memory card is full. z Insert a new memory card (p. 10).
z If required, download the images to a
computer and erase them from the
memory card to make space.
Memory card is not
formatted correctly.
z Format the memory card (p. 141).
z If reformatting does not work, the
memory card logic circuits may be
damaged. Consult the nearest Canon
Customer Support Help Desk.
SD memory card or SDHC
memory card is write
protected.
z Slide the write protect tab upward
(p. 172).
Image Seen in Viewfinder vs. Recorded Image.
Usually the recorded
image contains more of
the scene than is seen in
the viewfinder.
z Confirm the actual image size with the
LCD monitor. Use the LCD monitor
when taking close-up shots (p. 54).
154
Image is blurred or out of focus.
The camera moves when
the shutter button is
pressed.
z Confirm the procedures in
“ appears” (p. 152).
AF-assist Beam is set to
[Off].
z In dark places where it is difficult for
the camera to focus, the AF-assist
Beam will emit to assist focusing. As
the AF-assist Beam will not function
when turned off, set it [On] to activate
it (p. 50). Take care not to obstruct the
AF-assist Beam with your hand when
used.
Subject is out of focal
range.
z Shoot with the subject at the correct
focusing distance (p. 187).
z The camera may be set to an
unintended function (such as macro).
Cancel the setting.
The subject is hard to
focus on.
z Use the focus lock or manual focus to
shoot (p. 96).
Subject in recorded image is too dark.
Insufficient light for
shooting.
z Set the built-in flash to (Flash on)
(p. 60).
The subject is
underexposed because
the surroundings are too
bright.
z Set the exposure compensation to a
positive (+) setting (p. 99).
z Use the spot metering function
(p. 100).
Subject is too far away for
flash to reach.
z Shoot within correct flash range of the
subject when using the built-in flash
(p. 188).
z Raise the ISO speed and then shoot
(p. 68).
155
Troubleshooting
Subject in recorded image is too bright, or image
flashes white.
Subject is too close,
making the flash too
strong.
z Shoot within correct flash range of the
subject when using the built-in flash
(p. 188).
z Adjust the flash output with the flash
exposure compensation function
(p. 86).
z Set the safety FE to [On] (p. 86).
The subject is
overexposed because the
surroundings are too dark.
z Set the exposure compensation to a
negative (–) setting (p. 99).
z Use the spot metering function
(p. 100).
Too much light is shining
directly into the camera, or
is being reflected off the
subject.
z Change the shooting angle.
Flash is set to (Flash
on).
z Set the flash to (Flash off) (p. 60).
Image contains noise.
ISO speed is too high. z Higher ISO speeds and (High ISO
Auto) setting may increase image
noise. For higher image quality, use
as low an ISO speed as possible
(p. 68).
z In , , and mode in the
mode, the ISO speed increases
and noise can appear.
156
White dots appear on the image.
Light from the flash has
reflected off dust particles
or insects in the air. This is
particularly noticeable
when shooting using the
wide angle or when you
increase the aperture
value in the aperture
priority mode.
z This is a phenomenon that occurs
with digital cameras and does not
constitute a malfunction.
Eyes appear red.
Light is reflected back
from the eyes when the
flash is used in dark
areas.
z Shoot with [Red-Eye Lamp] in the
[Flash Settings] menu set to [On]
(p. 86). For this mode to be effective,
the subject must be looking right at
the red-eye reduction lamp. Try
asking them to look directly at the
lamp. Even better results can be
obtained by increasing the lighting in
indoor settings or approaching closer
to the subject. The shutter will not
activate for approximately 1 second
after the red-eye reduction lamp fires
in order to improve the effect.
z If you set the [Red Eye Corr.] in the
[Flash Settings] to [On], the camera
will automatically correct red eyes
while shooting and record the image
to the card (p. 86).
z You can correct red eyes in recorded
images using the [Red-Eye
Correction] (p. 122).
Continuous shooting slows down.
The memory card’s
performance has dropped.
z To enhance the continuous shooting
performance, you are recommended
to low level format the memory card in
the camera after you save all its
images to your computer (p. 141).
157
Troubleshooting
Recording images to memory card takes a long
time.
Memory card was
formatted in another
device.
z Use a memory card formatted in your
camera (p. 141).
Lens will not retract.
Memory card slot/battery
cover was opened with
power on.
z After closing the memory card slot/
battery cover, turn the power on then
back off.
Shooting movies
The recording time may not display properly or
shooting may stop unexpectedly.
The following types of
memory cards are used.
- Slow recording cards.
- Cards formatted on a
different camera or a
computer.
- Cards which have had
images recorded and
erased repeatedly.
z Although the recording time may not
display properly during shooting, the
movie will be recorded correctly on
the memory card. Recording time will
display properly if you format the
memory card in this camera
(excluding slow recording memory
cards) (p. 141).
“!” displayed on the LCD monitor in red and
shooting automatically stopped.
There is insufficient free
space in the camera’s
built-in memory.
z Try the following procedures.
- Format the card with a low level
format before filming (p. 141).
- Lower the recording pixels or frame
rate (p. 83).
- Use a high-speed memory card
(SDC-512MSH, etc.).
158
Zoom does not operate.
Zoom lever was pressed
while shooting in movie
mode.
z Operate the zoom before shooting in
movie mode (p. 56). Note the digital
zoom is available while shooting (only
in Standard movie mode).
Playback
Cannot play back.
You attempted to play
back images shot with
another camera or images
edited with a computer.
z Computer images that cannot be
played back may play back if they are
added to the camera using the
supplied software program.
File name was changed
with a computer or file
location was changed.
z Set the file name or location on the file
format/structure of the camera. (Refer
to the Software Starter Guide for
details).
Images cannot be edited.
Some images shot with another camera cannot be edited.
Movies do not play back correctly.
Movies recorded with high recording pixels may momentarily stop
playing if played on slow reading memory cards.
You may experience frame dropping and audio breakup when
playing back a movie on a computer with insufficient system
resources.
Reading images from memory card is slow.
Memory card was
formatted in another
device.
z Use a memory card formatted in your
camera (p. 141).
159
Troubleshooting
Battery
Batteries consumed quickly.
Battery is not being used
to its full capacity.
z See Battery (p. 171).
Batteries are not the right
type.
z Use only unused AA-size alkaline
batteries or Canon AA-size NiMH
batteries (p. 171).
Battery capacity drops
due to low ambient
temperatures.
z If shooting in a cold location, warm the
batteries such as by placing them in
your pocket before using them.
Battery terminals are dirty. z Wipe the terminals well with a dry
cloth before use.
z Reload the batteries several times.
If using Canon AA-size NiMH batteries
As the batteries have not
been used for over a year,
their recharging capacity
has decreased.
z Their charging performance should
return to normal after fully recharging
and depleting them over several
times.
Battery life has been
exceeded.
z Replace both batteries with new ones.
TV monitor output
Image is distorted or not showing on TV monitor.
Incorrect video system
setting.
z Set the video system to the
appropriate setting, NTSC or PAL, for
your TV (p. 53)
.
160
Printing with a direct print compatible
printer
Cannot print
The camera and printer
are not properly
connected.
z Securely connect the camera and
printer with the specified cable.
The printer power is not
turned on.
z Turn on the printer power.
The print connection
method is not correct.
z Select [Print Method] and select [Auto]
(p. 53).
161
List of Messages
The following messages may appear on the LCD monitor during
shooting or playback. Please refer to the Direct Print User Guide for
the messages that display during a printer connection.
Busy...
Image is being recorded onto the memory card, red eye correction is
being processed.
Resetting all the camera and menu settings to default.
No memory card
You turned on the camera without a memory card installed, or with a
memory card installed in the wrong orientation (p. 10).
Card locked!
The SD memory card or SDHC memory card is write protected
(p. 172).
Cannot record!
You attempted to shoot an image without a memory card installed,
with a memory card installed in the wrong orientation, or attempted
to attach a sound memo to a movie.
Memory card error
The memory card may be malfunctioning. By formatting the
malfunctioning memory card with the camera, you may be able to
continue using it (p. 141). However, if this error message appears
even when using the supplied memory card, contact your Canon
Customer Support Help Desk as there may be a problem with the
camera.
Memory card full
Memory card is full of images and no more can be recorded or
saved. In addition, no more image settings, or sounds or sound
memos can be recorded.
List of Messages
162
Naming error!
The file name could not be created because there is an image with
the same name as the folder that the camera is attempting to create,
or the highest possible file number has already been reached. In the
Set up menu, set [File Numbering] to [Auto Reset]; alternatively,
save all the images you wish to retain onto a computer, then
reformat the memory card. Please note that formatting will erase all
the existing images and other data.
Change the batteries
Battery charge is insufficient to operate the camera. Replace both
batteries immediately with unused AA-size alkaline batteries or fully
charged Canon AA-size NiMH batteries.
Also refer to Battery (p. 171).
No image.
No images recorded on memory card.
Image too large.
You attempted to play back an image larger than 5616 × 3744 pixels
or with a large data size.
Incompatible JPEG
You attempted to play back an incompatible JPEG image (edited
with a computer, etc.).
RAW
You attempted to play back a different type of RAW image.
Unidentified Image
You attempted to play back an image with corrupted data, an image
with a recording type specific to another manufacturer’s camera, or
an image that has been downloaded to a computer and altered.
Cannot magnify!
You attempted to magnify an image recorded in a different camera
or data type, an image edited with a computer, or a movie.
Cannot rotate
You attempted to rotate the image shot with a different camera or
data type, or an image edited with a computer.
163
List of Messages
Incompatible WAVE
A sound memo cannot be added to this image since the data type of
the existing sound memo is incorrect. In addition, sound cannot be
played back.
Cannot modify image
You attempted to resize or perform red eye correction on a movie or
an image recorded with another camera. Or you attempted to resize
an image already resized to or an image shot in .
Cannot assign to category
You attempted to categorize an image recorded in a different
camera.
Cannot Modify
Cannot apply red-eye correction as no red-eye is detected.
Cannot transfer!
When transferring images to your computer using the Direct
Transfer menu, you attempted to select a RAW image, an image
with corrupted data, an image taken with a different camera or data
type. You may have also attempted to select a movie when
[Wallpaper] was selected in the Direct Transfer menu.
Protected!
You attempted to erase or edit a protected image, movie or sound
memo.
Too many marks
Too many images have been marked with print settings or transfer
settings. Cannot process any more.
Cannot complete!
Could not save a part of the print or transfer settings.
Unselectable image
You attempted to set the print settings for a non-JPEG image.
164
Communication error
The computer was unable to download the image due to the large
amount of images (approx. 1000) stored on the memory card. Use a
USB card reader or a PCMCIA card adapter to download the
images.
Lens error, restart camera
An error was detected while the lens was in motion, and the power
has been automatically turned off. This error can occur if you hold
the lens while it is in motion or you operate it in a location with
excessive dust or sand in the air. Try turning the power back on, and
resume shooting or playback. If this message continues to display,
contact your Canon Customer Support Help Desk as there may be a
problem with the lens.
Exx
(xx: number) Camera detected an error. Turn the power off and then
back on, then shoot or play back. A problem exists if the error code
reappears. Note the number and contact your Canon Customer
Support Help Desk. If an error code displays directly after taking a
picture, the shot may not have been recorded. Check image in
playback mode.
165
Appendix
z Before using the camera, please ensure that you read the safety
precautions described below and in the “Safety Precautions” section.
Always ensure that the camera is operated correctly.
z The safety precautions noted on the following pages are intended to
instruct you in the safe and correct operation of the camera and its
accessories to prevent injuries or damage to yourself, other persons
and equipment.
z Equipment refers to the camera, battery, battery charger (sold
separately) and compact power adapter (sold separately).
Safety Precautions
Warnings
Equipment
z Do not point the camera at bright light sources (the sun in
bright clear skies, etc.).
• Doing so could damage the camera’s CCD.
• Doing so can damage your eyesight.
z Store this equipment out of the reach of children and infants.
• Neck strap: Placement of the strap around the child’s neck could
result in asphyxiation.
• Memory card: It may be swallowed accidentally. If this occurs,
contact a doctor immediately.
Appendix
166
z Do not attempt to disassemble or alter any part of the
equipment that is not expressly described in this guide.
z To avoid the risk of high-voltage electrical shock, do not touch
the flash portion of the camera if it has been damaged.
z Stop operating the equipment immediately if it emits smoke or
noxious fumes.
z Do not allow the equipment to come into contact with, or
become immersed in, water or other liquids. If the exterior
comes into contact with liquids or salt air, wipe it dry with a
soft, absorbent cloth.
Continued use of the equipment may result in fire or electrical shock.
Immediately turn the camera power off and remove the camera
batteries or unplug the battery charger or compact power adapter from
the power outlet. Please consult your camera distributor or the closest
Canon Customer Support Help Desk.
z Do not use substances containing alcohol, benzine, thinners
or other flammable substances to clean or maintain the
equipment.
z Do not cut, damage, alter or place heavy items on the power
cord.
z Use only recommended power accessories.
z Remove the power cord on a regular periodic basis and wipe
away the dust and dirt that collects on the plug, the exterior of
the power outlet and the surrounding area.
z Do not handle the power cord if your hands are wet.
Continued use of the equipment may result in fire or electrical shock.
167
Appendix
Battery
z Do not place the batteries near a heat source or expose it to
direct flame or heat.
z The batteries should not be immersed in water or sea water.
z Do not attempt to disassemble, alter or apply heat to the
batteries.
z Avoid dropping or subjecting the batteries to severe impacts
that could damage the casing.
z Use only recommended batteries and accessories.
Failure to follow these precautions may cause explosions or leaks,
resulting in fire, injury and damage to the surroundings. In the event
that a battery leaks and the eyes, mouth, skin or clothing contact these
substances, immediately flush with water and seek medical
assistance.
z Never use damaged batteries or batteries whose outer seal is
completely or partially missing or peeled off, as there is risk
that such batteries may leak, overheat, or burst. Always check
the seals on store-bought batteries before loading them, as
some batteries may come with defective seals. Do not use
batteries with defective seals.
Never use batteries that look like this.
Batteries with all or part of the seal (electrical insulation
sheath) peeled off.
The positive electrode (plus terminal) is flat.
The negative terminal is correctly formed (protruding from
the metal base), but the seal does not extend up over the
edge of the metal base.
168
z Disconnect the battery charger and compact power adapter
from both the camera and the power outlet after recharging or
when not in use to avoid fire and other hazards.
z Do not place anything, such as tablecloths, carpets, bedding or
cushions, on top of the battery charger while it is charging.
Leaving the units plugged in for a long period of time may cause them
to overheat and distort, resulting in fire.
z When recharging the Canon AA-size NiMH batteries, use only a
specified battery charger.
z The compact power adapter is designed for exclusive use with
this equipment. Do not use it with other products.
There is a risk of overheating and distortion which could result in fire or
electrical shock.
z Before you discard a battery, cover the terminals with tape or
other insulators to prevent direct contact with other objects.
Contact with the metallic components of other materials in waste
containers may lead to fire or explosions.
Others
z Do not trigger the flash in close proximity to human or animal
eyes. Exposure to the intense light produced by the flash may
damage eyesight.
In particular, remain at least one meter (39 inches) away from infants
when using the flash.
z Keep objects that are sensitive to magnetic fields (such as
credit cards) away from the speaker of the camera.
Such items may lose data or stop working.
z When using the optional Canon Wide Converter, Tele
Converter, Close-up Lens or Conversion Lens Adapter, be sure
to attach them firmly.
If the lens becomes loose and falls off, it may crack, and the shards of
glass may lead to cuts.
169
Appendix
Cautions
Equipment
z Be careful not to bang the camera or subject it to strong
impacts or shocks that could lead to injury or damage the
equipment when wearing or holding it by the strap.
z Be careful not to bump or strongly push the end of the lens.
The above-mentioned could lead to injury or damage the equipment.
z Be careful not to allow dust or sand into the camera when
using it at a beach or place with strong winds.
Such conditions could lead to damage.
z Do not store the equipment in humid or dusty areas.
z During shooting, do not allow metal objects (such as pins or
keys) or dirt to contact the charger terminals or plug.
Such conditions could lead to fire, electrical shock or other damage.
z Avoid using, placing or storing the equipment in places
subject to strong sunlight or high temperatures, such as the
dashboard or trunk (boot) of a car.
z Do not use the equipment in a manner that exceeds the rated
capacity of the electrical outlet or wiring accessories. Also, do
not use the equipment if the cable or plug is damaged, or if the
plug is not fully inserted into the power outlet.
z Do not use in locations with poor ventilation.
The above-mentioned can cause leakage, overheating or explosion,
resulting in fire, burns or other injuries. High temperatures may also
cause deformation of the casing.
z When not using the camera for extended periods of time,
remove the batteries from the camera or battery charger and
store the equipment in a safe place.
If the batteries are left inside the camera, damage caused by leakage
may occur.
170
Flash
z Do not operate the flash with dirt, dust or other items stuck to
the surface of the flash.
z Be careful not to cover the flash with your fingers or clothing
when shooting.
The flash may be damaged and emit smoke or noise. The resulting
heat build-up could damage the flash.
z Do not touch the surface of the flash after taking several
pictures in rapid succession.
Doing so could result in burns.
171
Appendix
Preventing Malfunctions
Camera
Avoid Strong Magnetic Fields
z Never place the camera in close proximity to electric motors or
other equipment generating strong electromagnetic fields.
Exposure to strong magnetic fields may cause malfunctions or corrupt
image data.
Avoid Condensation Related Problems
z When moving the equipment rapidly from cold to hot
temperatures, you can avoid condensation by placing the
equipment in an airtight, resealable plastic bag and letting it
adjust to temperature changes slowly before removing it from
the bag.
If condensation forms on the camera, remove the memory card and
battery, and set the camera aside in room temperature to allow the
condensation to naturally evaporate before using the camera again.
Battery
z This camera uses AA-size alkaline batteries or Canon AA-size
NiMH batteries (sold separately).
While it is possible to use AA-size nickel-cadmium batteries,
performance is unreliable and their use is not recommended.
z Since the performance of alkaline batteries may differ
according to brand, the operating time of the batteries you
purchase may not be as long as the batteries that came with
the camera.
z When using the camera under low temperature conditions or
over long periods, you are recommend to use of Canon AAsize
NiMH batteries (sold separately).
Camera operating time may shorten at low temperatures when
alkaline batteries are used. Also due to their specifications, alkaline
batteries may expire faster than NiMH batteries.
172
z Never mix unused and partially used batteries.
The partially used batteries may leak.
z Do not install the batteries with their terminals ( and )
reversed.
z Do not mix batteries of different types or from different
manufacturers.
z Before installing the batteries, wipe the battery terminals well
with a dry cloth.
If the battery terminals are soiled with oil from one’s skin or other dirt,
the number of recordable images may be considerably diminished, or
the amount of time the camera can be used may be reduced.
z At low temperatures, battery performance may be reduced and
the low battery icon ( ) may appear earlier than usual.
Under these conditions, restore the battery performance by warming it
in a pocket immediately before use.
z Do not put the batteries into a pocket together with metallic
items such as a key ring.
The batteries may be short circuited.
z When not using the camera for long periods, remove the
batteries from the camera and store them separately.
If the batteries are left inside the camera, the camera may become
damaged from battery leakage.
Memory Card
z SD Memory Card or SDHC Memory Card Write Protect Tab
Slide the
switch up.
Slide the switch
down (you can
protect the images
and other data on
the memory card).
Write Protect Tab
Writing/Erasing Possible
Writing/Erasing Impossible
173
Appendix
z Memory cards are high-precision electronic devices. Do not
bend them, apply force to them, or subject them to shocks or
vibration.
z Do not attempt to disassemble or alter the memory card.
z Do not allow dirt, water or foreign objects to contact the
terminals on the back of the memory card. Do not touch the
terminals with your hands or metal objects.
z Do not peel away the original label on the memory card or
cover it with another label or sticker.
z When writing on the memory card, do not use a pencil or
ballpoint pen. Only use a soft point pen (e.g. felt-tip pen).
z Do not use or store memory cards in the following locations.
• Locations subject to dust or sand
• Locations subject to high humidity and high temperatures
z Since some or all of the data recorded on the memory card
may be corrupted or erased by electrical noise, static
electricity, camera or memory card malfunction, making a
backup copy of important data is recommended.
z Please note that formatting (initializing) an memory card
erases all data, including protected images.
z You are recommended to use memory cards that have been
formatted in your camera.
• The memory card supplied with the camera may be used without
further formatting.
• When the camera is malfunctioning, a corrupted memory card might
be the cause. Reformatting the memory card may solve the problem.
• When a non-Canon brand memory card is malfunctioning,
reformatting it may solve the problem.
• Memory cards formatted in other cameras, computers, or peripheral
devices may not operate correctly in this camera. When that
happens, reformat the memory card with this camera.
z If formatting in the camera does not work properly, turn the
camera off and re-insert the memory card. Then turn the
camera back on and format again.
174
Using Rechargeable Batteries
(Battery and Charger Kit CBK4-300)
This kit includes a battery charger and four rechargeable AA-size
NiMH (nickel metal hydride) batteries. Charge batteries as shown
below.
• After inserting the batteries, plug the charger (CB-5AH) into an outlet,
or attach the power cord to the charger (CB-5AHE, not shown) and
plug the other end into an outlet.
• Do not insert and charge additional batteries once charging has
begun.
• The charge indicator blinks while charging, then remains lit when
charging is finished.
z Be careful when transferring or disposing of a memory card.
Formatting or erasing the data on a memory card merely
changes the file management information on the memory card
and does not ensure that its contents are completely deleted.
When disposing of a memory card, take precautions, such as
physically destroying the memory card, to prevent personal
information leaks.
Using the Power Kits (Sold Separately)
To a power outlet
4 batteries 2 batteries
To a power outlet
Charge Indicator
175
Appendix
z The CB-5AH/CB-5AHE battery charger can only be used to
charge Canon AA-size NiMH batteries NB-3AH.
z Do not mix batteries with different purchase dates or
different charge states. When recharging batteries, always
recharge both of them at the same time.
z Do not attempt to recharge fully charged batteries, as doing
so may reduce or impair battery performance. Also, do not
charge batteries for more than 24 consecutive hours.
z Do not recharge batteries in enclosed areas that tend to
retain heat.
z Do not recharge the batteries until the LCD monitor displays
the “Change the batteries” message. Repeatedly recharging
batteries before they become depleted may cause batteries
to lose capacity.
z Wipe the battery terminals well with a dry cloth in the
following situations, as the terminals may be soiled with oil
from one’s skin or other dirt:
- If the battery usage time has considerably diminished
- If the number of recordable images has considerably
diminished
- When charging the batteries (insert and remove the
batteries two or three times before charging)
- When charging completes in a space of a few minutes (the
battery charger indicator remains lit)
z You may not be able to fully charge the batteries due to their
specifications right after purchase or after long periods of
nonuse. If this happens, after fully charging them, use the
batteries until their charge is depleted. After doing this
several times, battery performance will be restored.
176
z If you store batteries for a long period of time (about 1 year),
it is recommended that you deplete the batteries in the
camera and to then store them at room temperature (0 to
30°C/32 to 90°F) in low humidity. Storing them in a fully
charged condition can shorten their lifespan or degrade their
performance.
Again, if you do not use batteries for more than 1 year, fully
charge them once a year and deplete them in the camera
before storing them.
z If the battery usage time has become considerably low
despite wiping the terminals and charging them until the
battery charger indicator remains lit, this may indicate that
the batteries have reached the end of their lifespan. Replace
them with new batteries. If you are purchasing new
batteries, look for Canon AA-size NiMH batteries.
z Leaving batteries in the camera or charger may result in
damage from battery leakage. When not in use, remove the
batteries from the camera or charger and store them in a
cool, dry location.
z It takes approximately 4 hours 40 minutes for the charger to
fully recharge the batteries after they have been depleted.
When two batteries are placed on each side of the charger,
recharging will take approximately two hours (as determined
by testing at Canon facilities).
Charge batteries in an environment where the temperature is
in the range of 0 to 35°C (32 to 95°F).
z The charging time varies according to the ambient
temperature and to the battery charge state.
z The battery charger may emit noise while charging. This is
not a malfunction.
177
Appendix
Using the AC Adapter Kit ACK800
It is best to power the camera with AC Adapter Kit ACK800 (sold
separately) when you are using it for long periods of time or connecting
it to a computer.
Turn the camera power off before connecting or disconnecting
the AC adapter.
1
Connect the power cord to
the compact power
adapter first and then plug
the other end into the
power outlet.
2
Open the terminal cover
and attach the cord to
the DC IN terminal.
Compact Power Adapter
CA-PS800
DC IN terminal
178
The camera supports use of the separately sold Wide Converter WC-
DC52, Tele-converter TC-DC52A and Close-up Lens 250D (52mm). In
order to attach these lenses, you also need to use the separately sold
Conversion Lens Adapter LA-DC52G.
Wide Converter WC-DC52
Use this converter for taking wide-angle shots. The wide converter
changes the focal length of the camera body’s lens by a factor of 0.7x
(the thread diameter is 52 mm).
Tele-converter TC-DC52A
This lens is used for taking telephoto shots. The lens changes the focal
length of the camera body’s lens by a factor of 1.75x (the thread
diameter is 52 mm).
Using the Lenses (Sold Separately)
z When attaching the wide converter, tele-converter or close-
up lens be sure to screw it on securely. If they come loose,
they may fall from the lens adapter, posing risk of injury from
shattered glass.
z Never look into the sun or into strong light through the wide
converter, tele-converter or close-up lens as this can result
in blindness or impairment of vision.
z If you use the flash when shooting with these attachments,
the outer area of the recorded image (especially lower right
corner) will come out relatively dark.
z When using the tele-converter, set the camera to maximum
telephoto. At other zoom settings, the image will appear as if
its corners have been cut off.
z When using the wide converter, please set the camera to
maximum wide angle.
z If you use the viewfinder for shooting, a portion of the view
will be blocked by these attachments. Please use the LCD
monitor.
179
Appendix
Close-up Lens 250D (52mm)
This lens makes taking macro shots easy. In the normal mode, close-
up shots can be taken when the distance from the front of the lens to
the subject is 17 to 25 cm (6.7 to 9.8 in.) at maximum telephoto.
Shooting area
Conversion Lens Adapter LA-DC52G
This is a lens adapter required for attaching the wide converter, tele-
converter and close-up lens (the thread diameter is 52 mm).
Attaching a Lens
It is not possible to attach a lens hood or filter to the wide
converter or tele-converter.
Distance from the front of the
lens to the subject
Shooting area
Max. Telephoto 17 cm (6.7 in.) 46 × 35 mm (1.8 × 1.4 in.)
1
Be sure that the camera is turned off.
2
Press the ring release button and hold it down
(
a), and turn the ring in the direction of the
arrow (b).
Ring
Ring Release Button
180
3
When the button on the camera and the
mark on the ring are aligned, lift off the
ring.
4
Align the z mark on the conversion lens adapter
with the button on the camera, and turn the
adapter in the direction of the arrows as far as
the { mark on the camera.
• To remove the conversion lens adapter, turn the adapter in the
opposite direction while holding down the ring release button.
5
Set the lens on the adapter,
and turn it in the indicated
direction to attach it
securely.
181
Appendix
Converter Settings
Settings for when shooting using [IS Mode] (p. 66) with the separately
sold Wide Converter WC-DC52, Tele-converter TC-DC52A or Close-
up Lens 250D attached.
z Completely remove all dust and dirt from conversion lenses
with a lens blower brush before use. The camera may focus
on any dirt that remains.
z Be careful when handling the lenses since it is easy to get
fingerprints on them.
z Be careful not to drop the camera or adapter when removing
the ring.
1
Select [Converter].
1. Press the button.
2. In the menu, use the or
select [Converter].
2
Make settings.
1. Use the or to select [WC-
DC52], [TC-DC52A] or [250D].
2. Press the button.
• Select the attached converter.
When you remove the converter from the camera, return the
converter setting to [None].
182
High-Power Flash HF-DC1
This flash is used to supplement the camera’s built-in flash when the
subject is too far away for proper illumination. Use the following
procedures to affix the camera and High-Power Flash to the supporting
bracket.
Please read the instructions accompanying the flash along with this
explanation.
Using an Externally Mounted Flash
(Sold Separately)
z The High-Power Flash will not fire under the following
circumstances.
- When shooting in mode
- When [Flash Mode] is on [Manual] (p. 86)
z The flash charge time will lengthen as the battery charge
gets weaker. Always set the power/mode switch to off when
you finish using the flash.
z Be careful not to touch the flash window or sensor windows
with your fingers while the flash is in use.
z The flash may fire if another flash is being used in close
proximity.
Tripod
Sockets
Bracket
(Comes with the flash)
183
Appendix
Batteries
z Charge becomes Severely Limited
If the battery usage time has considerably diminished, wipe the battery
terminals well with a dry cloth. The terminals may be dirty from
fingerprints.
z Usage in Cold Temperatures
Get a spare generic lithium battery (CR123A or DL123). You are
recommended to place the spare battery in your pocket to warm it up
before switching it for the battery in the flash.
z Non-Use over Extended Periods
Leaving batteries in the High-Power Flash could allow the battery fluid
to leak, damaging the product. Remove the batteries from the High-
Power Flash and store them in a cool, dry place.
z The High-Power Flash may not fire outdoors in daylight or
when there are no reflective items.
z For continuous shooting, although the flash fires for the first
shot, it does not fire for subsequent shots.
z Fasten the attachment screws securely so that they do not
loosen. Failure to do so may lead to the dropping of the
camera and flash resulting in damage to both.
z Before attaching the bracket to the flash, check that the
lithium battery (CR123A or DL123) is installed.
z To illuminate the subjects properly, install the flash so that it
is up against the side of the camera and parallel with the
camera’s front panel.
z A tripod can be used even when the flash is attached.
184
If the Date/Time in the Set up menu appears when the camera power
is turned on, the date battery charge is low and the date and time
settings have been lost. Please purchase a lithium coin battery
(CR1220) and replace it as follows.
Replacing the Date Battery
The date battery is preinstalled at the factory and may therefore
expire earlier than its rated lifespan after the camera has been
purchased.
Be particularly careful to keep the date batteries out of the
reach of children. Seek medical assistance immediately if a
child swallows a battery since corrosive battery fluids could
damage the stomach or intestinal wall.
1
Confirm that the camera is turned off.
2
Slide the memory card slot / battery cover lock
and open the cover.
3
Hook your nail onto the date
battery holder and lightly
pull it up.
4
Pull out the battery holder in
the direction indicated by
the arrow.
185
Appendix
5
Remove the battery by pulling it
up in the direction indicated by
the arrow.
6
Insert a new battery with
the (–) side facing up.
7
Replace the battery holder and close the
cover.
8
When the Date/Time menu appears, set the
date and time (p. 13).
After purchasing the camera and turning on the power for the
first time, although the Date/Time menu will appear, you do not
need to replace the date battery.
(–) side
186
Camera Body
Gently wipe dirt off the camera body with a soft cloth or eyeglass lens
wiper.
Lens
First use a lens blower brush to remove dust and dirt, then remove any
remaining dirt by wiping the lens lightly with a soft cloth.
Viewfinder and LCD Monitor
Use a lens blower brush to remove dust and dirt. If necessary, gently
wipe with a soft cloth or an eyeglass lens wiper to remove stubborn
dirt.
Camera Care and Maintenance
Never use thinners, benzine, detergents or water to clean the
camera. These substances may distort or damage the
equipment.
Never use organic solvents on the camera body or lens. If dirt
remains, contact the closest Canon Customer Support Help
Desk as listed on the European Warranty System (EWS)
Booklet.
Never rub or press strongly on the LCD monitor. These actions
may damage it or lead to other problems.
187
Appendix
All data is based on Canon’s standard testing methods. Subject to
change without notice.
PowerShot A590 IS (W): Max. wide angle (T): Max. telephoto
Specifications
Camera Effective Pixels : Approx. 8 million
Image Sensor : 1/2.5-inch type CCD (Total number of pixels:
Approx. 8.3 million pixels)
Lens : 5.8 (W) – 23.2 (T) mm
(35mm film equivalent: 35 (W) – 140 (T) mm)
f/2.6 (W) – f/5.5 (T)
Digital Zoom : Approx. 4.0x (Up to approx. 16x in combination
with the optical zoom)
Optical Viewfinder : Real-image zoom viewfinder
LCD Monitor : 2.5-inch type, amorphous silicon TFT color LCD,
approx. 115,000 pixels (Picture coverage 100%)
AF System : TTL autofocus/
Manual focus are available
AF frame mode: Face Detect*
1
*
2
/AiAF (9-point)/
Center
*1 AF frame can be moved and fixed to specified face.
*2 If no face is detected, AiAF (9-points) is used.
Focusing Range
(From the front of the
lens)
: Normal: 45 cm (1.5 ft.) – infinity
Macro: 5 – 45 cm (W) (2.0 in. – 1.5 ft. (W)),
30 – 45 cm (T) (12 in. – 1.5 ft.(T))
Manual focus/Easy:
5 cm (2.0 in.) – infinity (W),
30 cm (12 in.) – infinity (T)
Kids&Pets: 1 m (3.3 ft.) – infinity (W/T)
Shutter : Mechanical shutter and electronic shutter
Shutter Speeds : 1/60 – 1/2000 sec.
15 – 1/2000 sec. (Shutter speed range
throughout all shooting modes)
• Slow shutter speeds of 1.3 sec. or slower
operate with noise reduction.
188
Image Stabilization : Lens-shift type
Continuous/Shoot Only/Panning/Off
Metering System : Evaluative*
1
/Center-weighted average or Spot*
2
*1 Facial brightness is also evaluated in Face Detect AF.
*2 Fixed to center
Exposure Compensation
: ±2 stops in 1/3-stop increments
ISO Speed
(Standard Output
Sensitivity,
Recommended
Exposure Index)
: Auto*
1
, High ISO Auto*
2
, ISO 80/100/200/400/
800/1600
*1 Camera automatically sets the optimal speed
according to shooting mode and subject brightness.
*2 Camera automatically sets the optimal speed
according to shooting mode, subject brightness and
subject movement. However, the ISO speed is set
relatively higher than Auto.
White Balance : Auto*, Day Light, Cloudy, Tungsten,
Fluorescent, Fluorescent H or Custom
* The colors of faces are evaluated in Face Detect AF.
Built-in Flash : Auto, on, off
• Facial brightness is also evaluated in Face
Detect AF.
Built-in Flash Range : 30 cm – 3.5 m (12 in. – 11 ft.) (W)/
30 cm – 2.2 m (12 in. – 7.2 ft.) (T)
• Brightness of image periphery may reduce
depending on shooting distance.
Shooting Modes : Auto
Easy
Creative zone:
Program, Shutter-speed priority,
Aperture priority, Manual
Image zone:
Portrait, Landscape, Night Snapshot,
Kids&Pets, Indoor, Special Scene*
1
and
Movie*
2
*1 Night Scene, Sunset, Foliage, Snow, Beach,
Fireworks and Aquarium.
*2 Standard and Compact.
Continuous Shooting : Approx. 1.4 shots/sec.
Self-timer : Approx. 10-sec./approx. 2-sec. delay or custom
189
Appendix
Recording Media : SD memory card/SDHC memory card/
MultiMediaCard/MMCplus card/HC MMCplus
card
File Format : Design rule for camera file system and DPOF
compliant
Data Type : Still images: Exif 2.2 (JPEG)*
:
:
Movies: AVI (Image data: Motion JPEG; Audio
data: WAVE (monaural))
Sound Memo: WAVE (monaural)
* This digital camera supports Exif 2.2 (also called “Exif
Print”). Exif Print is a standard for enhancing the
communication between digital cameras and printers.
By connecting to an Exif Print-compliant printer, the
camera’s image data at the time of shooting is used
and optimized, yielding extremely high quality prints.
Compression : Superfine, Fine, Normal
Number of
Recording
Pixels
(Still images)
: Large : 3264 × 2448 pixels
Medium 1 : 2592 × 1944 pixels
Medium 2 : 2048 × 1536 pixels
Medium 3 : 1600 × 1200 pixels
Small : 640 × 480 pixels
Date Stamp : 1600 × 1200 pixels
Widescreen : 3264 × 1832 pixels
(Movies) :
:
Standard
: 640 × 480 pixels (20 frames/sec.)
640 × 480 pixels (20 frames/sec. LP)
: 320 × 240 pixels (30 frames/sec.)
Recording can continue until the memory full*
1
(can record up to a maximum of 4 GB one
time*
2
)
Compact: 160 × 120 pixels (15 frames/sec.)
Maximum recording length per clip: 3 min.
*1 Using super high-speed memory cards (SDC- 512
MSH recommended).
*2 Even if the file size has not reached 4 GB, the
recording is stopped when the recording time
reaches one hour. Depending on memory card
capacity and data write speed, recording may stop
before the file size reaches 4 GB or the recording
time reaches one hour.
190
Playback Modes : Playback Modes: Single (histogram
displayable), Index (9 thumbnail images),
Magnified (approx. 2x to 10x max.), Resume
Playback, Image Inspection Tool, Jump, My
Category, Movie Playback (slow motion
available), Rotate, Slide Show, Red-Eye
Correction, Resize, Sound memos (it is possible
to record and playback up to 1 min.), Protect
Direct Print : PictBridge compliant, and Canon Direct Print
and Bubble Jet Direct compatible
Interface : Hi-Speed USB (mini-B)
Audio/Video output (NTSC or PAL selectable,
monaural audio)
Communication Settings
:MTP, PTP
Power Source : 2 AA-size alkaline batteries
2 AA-size NiMH batteries NB4-300 (sold
separately) AC Adapter Kit ACK800 (sold
separately)
Operating
Temperatures
: 0 – 40 °C (32 – 104 °F)
(0 – 35 °C (32 – 95 °F) when NB-3AH is used.)
Operating Humidity : 10 – 90%
Dimensions
(excluding protrusions)
: 94.3 × 64.7 × 40.8 mm
(3.71 × 2.55 × 1.61 in.)
Weight
(camera body only)
: Approx. 175 g (6.17 oz.)
191
Appendix
Battery Capacity
z The actual figures will vary according to the shooting conditions and
settings.
z Movie data is excluded.
z At low temperatures, the battery performance may diminish and the
low battery icon may appear very rapidly. In these circumstances,
the performance can be improved by warming the battery in a pocket
before use.
Test Conditions
Number of Images Shot
Playback Time
LCD Monitor On
(Based on the CIPA
standard)
AA-size Alkaline Batteries
(included with the camera)
Approx. 200 images Approx. 9 hours
AA-size NiMH Batteries
(NB-3AH (fully charged))
Approx. 450 images Approx. 11 hours
Shooting: Normal temperature (23 °C ±2°C/73 °F ±3.6 °F), normal
relative humidity (50% ±20%), alternating wide angle end
and telephoto end shots at 30 second intervals with the flash
fired once every two shots and the camera power turned off
after every tenth shot. Power is left off for a sufficient amount
of time*, then the power is turned back on and the testing
procedure is repeated.
• A Canon-brand memory card is used.
* Until the battery returns to normal temperature
Playback: Normal temperature (23 °C ±2 °C/73 °F ±3.6 °F), normal
relative humidity (50% ±20%), continuous playback at 3
seconds per image.
See Battery (p. 171).
192
Memory Cards and Estimated Capacities
: Memory card included with the camera
This reflects standard shooting criteria established by Canon. Actual results may vary
according to the subject and shooting conditions.
Recording Pixels Compression 32 MB SDC-128M
SDC-512MSH
(Large)
3264 × 2448 pixels
835139
14 59 231
30 123 479
(Medium 1)
2592 × 1944 pixels
11 49 190
21 87 339
42 173 671
(Medium 2)
2048 × 1536 pixels
18 76 295
33 136 529
66 269 1041
(Medium 3)
1600 × 1200 pixels
30 121 471
53 217 839
102 411 1590
(Small)
640 × 480 pixels
114 460 1777
177 711 2747
278 1118 4317
(Date Stamp)
1600 × 1200 pixels
53 217 839
(Widescreen)
3264 × 1832 pixels
11 47 183
19 79 307
41 166 642
193
Appendix
Movie
: Memory card included with the camera
• Maximum movie clip length at : 3 min. The figures indicate the maximum
continuous recording time.
Image Data Sizes (Estimated)
Recording Pixels/
Frame Rate
32 MB SDC-128M
SDC-512MSH
Standard
640 × 480 pixels
20 frames/sec.
23 sec.
1 min.
36 sec.
6 min.
12 sec.
640 × 480 pixels
20 frames/sec. LP
47 sec.
3 min.
10 sec.
12 min.
16 sec.
320 × 240 pixels
30 frames/sec.
44 sec.
3 min.
1 sec.
11 min.
42 sec.
Compact
160 × 120 pixels
15 frames/sec.
3 min.
36 sec.
14 min.
29 sec.
55 min.
57 sec.
Recording Pixels
Compression
3264 × 2448 pixels 3436 KB 2060 KB 980 KB
2592 × 1944 pixels 2503 KB 1395 KB 695 KB
2048 × 1536 pixels 1602 KB 893 KB 445 KB
1600 × 1200 pixels 1002 KB 558 KB 278 KB
640 × 480 pixels 249 KB 150 KB 84 KB
1600 × 1200 pixels – 558 KB –
3264 × 1832 pixels 2601 KB 1540 KB 736 KB
Recording Pixels/Frame Rate File size
Standard
640 × 480 pixels
20 frames/sec.
1280 KB/sec.
640 × 480 pixels
20 frames/sec. LP
640 KB/sec.
320 × 240 pixels
30 frames/sec.
660 KB/sec.
Compact
160 × 120 pixels
15 frames/sec.
120 KB/sec.
194
MultiMediaCard
SD Memory Card
NiMH Battery NB-3AH
(Supplied with the separately sold NiMH Battery NB4-300 set or the
Battery and Charger Kit CBK4-300)
Interface Compatible with MultiMediaCard standards
Dimensions 32.0 × 24.0 × 1.4 mm (1.3 × 0.9 × 0.06 in.)
Weight Approx. 1.5 g (0.05 oz.)
Interface Compatible with SD memory card standards
Dimensions 32.0 × 24.0 × 2.1 mm (1.3 × 0.9 × 0.1 in.)
Weight Approx. 2 g (0.07 oz.)
Type AA-size nickel metal hydride battery
Nominal Voltage 1.2 V DC
Typical Capacity 2500 mAh (min.: 2300 mAh)
Cycle Life Approx. 300 times
Operating
Temperatures
0 – 35 °C (32 – 95 °F)
Diameter × Length 14.5mm × 50.0 mm (0.57 × 1.97 in.)
Weight Approx. 30 g (1.06 oz.)
195
Appendix
Battery Charger CB-5AH/CB-5AHE
(Supplied with the separately sold Battery and Charger Kit CBK4-300)
*1 When charging four NB-3AH batteries
*2 When charging two NB-3AH batteries loaded one on each side of the battery
charger
Compact Power Adapter CA-PS800
(Included with the separately sold AC Adapter Kit ACK800)
Wide Converter WC-DC52 (Sold Separately)
Rated Input 100 – 240 V AC (50/60 Hz)
Rated Output 565 mA
*
1
×4
, 1275 mA
*
2
×2
Charging Time Approx. 4 hours 40 min.
*
1
, Approx. 2 hours
*
2
Operating Temperatures 0 – 35 °C (32 – 95 °F)
Dimensions 65.0 × 105.0 × 27.5 mm (2.56 × 4.13 × 1.08 in.)
Weight Approx. 95 g (3.35 oz.)
Rated Input 100 – 240 V AC (50/ 60 Hz)
Rated Output 3.15 V DC, 2.0 A
Operating Temperatures 0 – 40 °C (32 – 104 °F)
Dimensions 42.6 × 104.0 × 31.4 mm (1.68 × 4.09 × 1.24 in.)
Weight Approx. 180 g (6.35 oz.) (excluding power
cord)
Magnification Approx. 0.7x
Focal Length
*
1
24.5 mm (35mm film equivalent)
Focusing Range
*
1
Approx. 21 cm (8.3 in.) – infinity (W)
*
2
Thread Diameter 52 mm standard filter thread
*
3
Dimensions Diameter × Length
58.0 × 30.5 mm (2.28 × 1.20 in.)
Weight Approx. 74 g (2.61 oz.)
196
Tele-converter TC-DC52A (Sold Separately)
Close-up Lens 250D 52 mm (Sold Separately)
Conversion Lens Adapter LA-DC52G (Sold
Separately)
(W): Max. wide angle (T): Max. telephoto
*1 When mounted on PowerShot A590 IS (Max. wide angle)
*2 From front of the mounted tele-converter.
*3 Conversion Lens Adapter LA-DC52G is required when mounted on
PowerShot A590 IS.
*4 When mounted on PowerShot A590 IS (Max. telephoto)
Magnification Approx. 1.75x
Focal Length
*
4
245 mm (35mm film equivalent)
Focusing Range
*
4
Approx. 1.4 m (4.6 ft.) – infinity (T)
*
2
Thread Diameter 52 mm standard filter thread
*
3
Dimensions Diameter × Length
55.2 × 46.7 mm (2.17 × 1.84 in.)
Weight Approx. 86 g (3.03 oz.)
Focusing Range
(from front of lens)
Normal: 17 – 25 cm (6.7 – 9.8 in.) (W/T)
Macro: 4 – 17 cm (1.6 – 6.7 in.) (W/T)
Thread Diameter 52 mm standard filter thread
*
3
Dimensions Diameter × Length
54.0 × 10.2 mm (2.13 × 0.40 in.)
Weight Approx. 55 g (1.94 oz.)
Thread Diameter 52 mm standard filter thread
Dimensions Diameter × Length
55.7 × 36.8 mm (2.19 × 1.45 in.)
Weight Approx. 14 g (0.49 oz.)
Index
197
Index
Numerics
3:2 Guide ................................. 106
A
AC Adapter Kit ACK800...........177
Accessory ..................................36
AF Frame.............................46, 92
AF-assist Beam....................40, 50
AF-Point Zoom...........................88
Aperture Value.....................76, 78
Auto Category..........................107
AUTO Mode ...............................15
Auto Rotate..............................146
B
Battery
Installing.................................10
Low Battery............................47
Battery Capacity.......................191
C
Camera Shake Warning...........154
Card
Formatting............................141
Components Guide ....................40
Compression..............................65
Computer
Connecting.............................29
Downloading Images ............. 27
System Requirements ...........27
Continuous Shooting..................84
Converter .................................181
Create Folder...........................144
D
Date and Time........................... 13
Date Battery............................. 184
Date Stamp................................ 22
Digital Tele- Converter............... 56
Digital Zoom .............................. 56
Direct Print Compatible Printers
............................................. 35, 38
Direct Transfer........................... 31
Display Language...................... 14
Display Overlays...................... 106
Distance Units ........................... 53
DPOF Print Settings ................ 133
Drive Mode .......................... 62, 84
E
Easy Mode................................. 17
Embedding the Date in the Image
Data........................................... 22
Erase all................................... 132
Erasing .............................. 19, 132
Exif Print .................................. 189
Exposure Compensation ........... 99
F
Face Detect ............................... 92
Face Select and Track............... 94
File Numbering ........................ 142
Flash
Flash Exp. Comp ................... 86
Flash Output.......................... 86
Settings.................................. 86
Shooting ................................ 60
Focus......................................... 90
focus .......................................... 92
Focus Check........................ 54, 90
Index
198
Focus Check Display ...............112
Focus Lock.................................96
Frame Rates ..............................83
G
Grid Lines.................................106
H
High-Power Flash ....................182
Histogram...................................48
I
Image Stabilizer .........................66
Index Playback.........................111
Indicators ...................................43
ISO Speed .................................68
J
Jump (Searching the Images)..114
L
LCD Monitor Display..................54
Lens
Close-up lens.......................179
Conversion Lens Adapter ....179
Tele-converter......................178
Wide Converter.................... 178
Lens Retract...............................53
Lense .......................................178
List of Messages......................161
M
Macro.........................................61
Manual Focus ............................97
Memory Cards
Estimated Capacities ...........192
Menu
FUNC. Menu..........................49
Play Menu.............................. 51
Print Menu ............................. 51
Rec. Menu ............................. 49
Set up Menu .......................... 52
Settings.................................. 44
Metering Mode......................... 100
MF-Point Zoom.................... 50, 97
Microphone................................ 24
Mode Dial .................................. 69
Movie
Shooting .......................... 24, 80
Viewing .................................. 26
Mute........................................... 52
My Category ............................ 116
My Colors ................................ 104
N
Night View ................................. 55
O
Overexposure Warning.............. 55
P
Power Kits ............................... 174
Power Saving .................... 52, 139
Pressing fully ............................. 16
Pressing halfway ....................... 15
Print List..................................... 21
Print Method .............................. 53
Print/Share Button ............. 42, 108
Printing ......................................20
Program AE............................... 73
Protect ..................................... 131
R
Rec. Review .............................. 16
Recording Pixels.................. 64, 83
Red-Eye Correction (Playback)
................................................. 122
Index
199
Red-Eye Correction (Shooting).. 86
Red-Eye Reduction....................86
Registering Settings.................108
Reset All...................................147
Resize ......................................127
Resume......................................18
Resume Playback ......................18
Review ....................................... 50
Review Info ................................90
Rotate ......................................119
S
Safety FE ...................................86
Safety MF...................................98
Safety Zoom...............................57
Self-Timer ..................................62
Shooting Mode...........................69
Functions Available.............. 201
shutter button.............................15
Shutter Speed ......................74, 78
Slide Shows .............................121
Sound Memos..........................129
Start-up Image ...........................52
System Map ...............................34
T
Telephoto...................................56
Transfer Settings (DPOF) ........137
Transition .................................120
TV Set......................................148
V
Video Output Signal.................148
Viewfinder ..................................41
Volume.......................................52
W
White Balance..........................101
Wide Angle.................................56
Wrist Strap................................. 12
200
Trademark Acknowledgments
• Microsoft, Windows Vista and the Windows Vista logo are
trademarks or registered trademarks of Microsoft Corporation in the
United States and/or other countries.
• Macintosh, the Mac logo, QuickTime and the QuickTime logo are
trademarks of Apple Inc., registered in the U.S. and other countries.
• The SDHC logo is a trademark.
Copyright © Canon Inc. 2008 All rights reserved.
Disclaimer
• While every effort has been made to ensure that the information
contained in this guide is accurate and complete, no liability can be
accepted for any errors or omissions.
• Canon reserves the right to change the specifications of the
hardware and software described herein at anytime without prior
notice.
• No part of this guide may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language in any
form, by any means, without the prior written permission of Canon.
• Canon makes no warranties for damages resulting from corrupted
or lost data due to a mistaken operation or malfunction of the
camera, the software, SD memory cards (SD cards), personal
computers, peripheral devices, or use of non-Canon SD cards.
Functions Available in Each Shooting Mode
201
Functions Available in Each Shooting Mode
Only functions with settings that change with the shooting mode are
listed here.
Shooting Mode
Function
Exposure Compensation (p. 99)
– { { { – – { {
ISO Speed (p. 68)
Auto
1)
– {{{{ – {{
High ISO Auto
–––
{{{
––
ISO 80 – 1600
{{{{
––––
White Balance (p. 101)
Auto
1)
{ { { { { { { {
Other than Auto
{ { { { – – – –
Drive Mode (pp. 84, 62)
Single Shot
{{{{{{{{
Continuous
{{{{
––
{{
Self-timer
2 sec./10 sec.
{{{{{
–
{{
Custom
{{{{{
–
{{
Custom Timer (delay, shots) (p. 63)
{ { { { { – { {
My Colors (p. 104)
{{{{ ––––
Flash Exposure Compensation (p. 86)
–
{ { {
– – – –
Flash Output Control (p. 86)
{{{
–––––
Metering System (p. 100)
Evaluative
{ { { { { { { {
Center-weighted Average
{ { { { – – – –
Spot
{ { { { – – – –
Number of Recording Pixels, Compression (still images) (pp. 64, 65)
{{{{{
–
2)
{{
Date Stamp (Date, Date & Time) (p. 22)
{ { { { {
–
{ {
Number of Recording
Pixels, Frame Rate (p. 83)
640 × 480, 20 fps / 20 fps LP
––––––––
320 × 240, 30 fps
––––––––
160 × 120, 15 fps
––––––––
Av/Tv Setting
Av (p. 76)
{ {
– – – – – –
Tv (p. 74)
{
–
{
– – – – –
Shooting Zone (p. 61)
Normal
{{{{{ –
3)
{{
Macro
{{{{{ – { –
Manual Focus (p. 97)
{ { { { – – { {
Face Select and Track (p. 94)
{{{{{
–
{{
Flash (p. 60)
Auto
– – –
{ { { { {
On
{ { { { – – { {
Off
{ { { { { { { {
LCD Monitor Setting (p. 54)
LCD Monitor (off)
{{{{{ – {{
LCD Monitor (no infomation)
{{{{{
–
{{
LCD Monitor (infomation view)
{{{{{{{{
Functions Available in Each Shooting Mode
202
{ { { { { { { { { { – –
{{{{{{{{{{{{
––––––––––––
––––––––––––
{ { { { { { { { { { { {
– – – – – – – – – – { {
{{{{{{{{{{{{
{{{{{{{{{{
––
{{{{{{{{{{{{
{{{{{{{{{{
––
{ { { { { { { { { { – –
––––––––––{{
– – – – – – – – – – – –
––––––––––––
{ { { { { { { { { { { {
– – – – – – – – – – – –
– – – – – – – – – – – –
{{{{{{{{{{
––
{ { { { { { { { { {
– –
––––––––––
{
–
––––––––––{ –
–––––––––––{
– – – – – – – – – – – –
– – – – – – – – – – – –
{{{{{{{{{{{{
{ – { – {{{{ – {{{
{ { { { { { { { – { { {
{{{{{{{{
–
{
––
{ { { { { { { {
– – – –
{ { { { { { { { – { – –
{ { { { { { { { { { – –
{{{{{{{{{{ ––
{{{{{{{{{{{{
{{{{{{{{{{{{
Functions Available in Each Shooting Mode
203
{ : Setting available or optimum value is automatically set by the camera.
– : Not available.
1) Set to optimum value depending on each shooting mode.
2) Fix to Large size of the recording pixels and fine of the compression.
3) Including macro.
4) Date stamp and Widescreen are not available.
5) Always set to on.
6) Always set to [On] when Auto Flash is selected.
7) Only available when the flash is set to [On].
8) Fix to 2 seconds.
AF Frame (p. 92)
Face Detect
{ { { { { { { {
AiAF (9-point)
{ { { { {
–
{ {
Center
{ { { { {
–
{ {
AF-Point Zoom (p. 88)
{{{{{ – {{
Digital Zoom
4)
(p. 56)
Standard
{ { { { { {
5)
{ {
Digital Tele-converter
{ { { { { – { {
Flash Settings (p. 86)
Flash Mode
Auto
–
{{{{{{{
Manual
{{{
–––––
Flash Exposure Compensation
– {{{ ––––
Flash Output
{{{ –––––
Red-Eye Correction
{{{{{
–
{{
Red-Eye Lamp
{{{{{{
5)
{{
Safety FE
–
{{{
––––
MF-Point Zoom (p. 97)
{ { { { – – { {
Safety MF (p. 98)
{{{{ ––{{
AF-assist Beam (p. 50)
{ { { { { {
6)
{ {
Review (Rec. review) (p. 50)
{{{{{
–
8)
{{
Review Info. (p. 50)
Off
{ { { { { { { {
Detailed / Focus Check
{ { { { { – { {
Auto Category (p. 107)
{{{{{{
5)
{{
Disp. Overlay (p. 106)
Grid Lines
{ { { { {
–
{ {
3:2 Guide/Both
{ { { { {
–
{ {
IS Mode (p. 66)
Continuous
{{{{{{{{
Shoot Only/Panning
{{{{{ – {{
Converter (p. 181)
{ { { { { – { {
Registering settings to the Print/Share button (p. 108)
{{{{{
–
{{
Shooting Mode
Function
Functions Available in Each Shooting Mode
204
{ { { { { { { { – { – –
{ { { { { { { {
–
{ { {
{ { { { { { { { { {
– –
{{{{{{{{{{ ––
{ { { { { { { { { { { –
{ { { { { { { { { { – –
{{{{{{{{
–
{
––
––––––––––––
––––––––––––
––––––––––––
{{{{{{{{
–
{
––
{{{{{{{{
–
{
––
––––––––––––
{ { { { { { { { – { – –
{{{{{{{{ – {{{
{ { { { { { { {
–
{
7)
{ {
{{{{{{{{{{
––
{ { { { { { { { { {
– –
{ { { { { { { { { { – –
{{{{{{{{{{{{
{ { { { { { { { { { { {
{ { { { { { { { { {
– –
{{{{{{{{{{{{
{{{{{{{{{{ ––
{ { { { { { { { { { { {
{{{{{{{{{{{{
Camera User Guide
Camera User Guide
CEL-SH5BA210 © CANON INC. 2008
ENGLISH
DIGITAL CAMERA
Ensure that you read the Safety Precautions (pp. 165 – 172).
Getting Started
P. 9
