Portable Toilet
SLCATL330
USER GUIDE
Visit Our Website
SCAN ME
serenelifehome.com
www.SereneLifeHome.com
2
ASSEMBLY & CARE INSTRUCTIONS
IMPORTANT
Before using our product, please familiarize yourself with the components.
Features:
• High-density polyethylene construction.
• Completely self-contained.
• No external connections required.
• Secure clamps and latches.
• All parts are easily replaced by end-users.
• 20L waste holding tank.
• 10L fresh water tank.
• Easy to carry and clean.
• Adult-sized seat and lid are well-constructed.
• Always ushes with clean water; no water is
re-circulated.
• Completely self-contained. No external water
or power connections.
• Freshwater capacity provides up to 50 ushes.
• Attractive matte nish conceals marks and
allows scrubbing without damage.
• Double-sealed drain valve protects against
leakage and odor.
• Heavy-duty, corrosion-resistant side latches
lock tanks together.
• Detached waste holding tank is easy to empty.
• Both tanks are single-piece construction with
no leaking seams.
• Waste level indicator tells you when to empty.
• No-splash rotating pour spout.
• Innovative T-type 3-way ush nozzle ensures
full bowl coverage.
• Upgraded piston pump works more efficiently.
• Selectable bracket can increase the height.
Parts Listing
No.
Part No. Description
1 CHH-T-009 Seat Cover
2 CHH-T-010 Seat
3
CHH-T-011 Hinge Pin
4 CHH-T-015 Piston Pump Assembly
5 CHH-T-019 Cap, Fresh Water Holding Tank
6 CHH-T-012
Fresh Water Holding Tank Assembly
7 CHH-T-021 Latch Assembly
8 CHH-T-003 Sealed C Ring
9 CHH-T-014 Slide Valve Assembly
10 CHH-T-004 Sealed D Ring
11 CHH-T-023 Cap. Rotating Pour Spout
12 CHH-T-025 Rotating Pour Spout
13 CHH-T-024 Waste Holding Tank 20L
1
2
6
8
9
12
3
5
4
7
10
11
13
www.SereneLifeHome.com
3
Register Product
Thank you for choosing SereneLife.
By registering your product, you
ensure that you receive the full
benets of our exclusive warranty
and personalized customer support.
Complete the form to access expert
support and to keep your SereneLife
purchase in perfect condition.
Serenelifehome.com/
register
ASSEMBLY & CARE INSTRUCTIONS
PREPARING FOR USE
1. Set the SLCATL330 on its front side so that the cap
on the waste holding tank is in a vertical position.
Remove the cap and add deodorizer following
instructions on the deodorizer container.
Tighten the cap rmly.
2. Set the toilet in an upright position and remove the
cap located on the right rear side of the freshwater
tank. Fill with freshwater up to the top of the fresh-
water tank. Then tighten the cap rmly.
Caution:
A. Do not add deodorizer to the top freshwater tank.
B. Avoid adding holding tank deodorizer through
the bowl. Use the cap on the bottom rear tank if
possible. Rinse off any spilled or splashed
deodorizer immediately.
C. Atmospheric pressure and temperature changes
may cause pressure buildup in the lower holding
tank. Caution should be used when rst opening
the slide valve.
USE AND OPERATION
1. Depress Flush Pump to add water to the bowl.
2. After use, pull Slide Valve handle out.
3. Depress Flush Pump again to rinse the bowl.
4. Close Slide Valve by pushing in fully.
EMPTYING WASTE HOLDING TANK
The SLCATL330 has a 20L waste holding tank.
It should be emptied when contents reach
approximately 2cm below Slide Valve, or the level
indicator turns to red.
1. Separate tanks by pulling outward on side latches,
then lifting upward on the water tank. Make sure
the slide valve is completely closed.
2. Use the molded handle to carry the holding tank.
3. Remove pour spout cap while it is pointing upward.
4. To avoid splashing, slowly pour contents out of the
tank. Add freshwater, close the cap, and shake the
tank to rinse.
5. Remove the cap and pour rinse water out of the
tank. Close the cap rmly and assemble the
freshwater tank and waste holding tank together
again.
6. Prepare for continued use by following steps 1 and
2 of “Preparing for Use”.
SAFETY INSTRUCTION
1. Handle with care.
2. Avoid exposure to direct sunlight for extended
periods.
3. Avoid high temperatures over 50°C.
4. To avoid injury, DO NOT lean against the lid when
being used.
5. Ensure the waste tank is cleaned regularly.
6. Suitable for use with any brand of portable toilet
chemicals and deodorizers.
MAINTENANCE
1. Lubricate Slide Valve seals periodically with silicone
spray or white grease lubricant.
2. The Slide Valve may be removed for cleaning or
inspection by simply unscrewing it in a counter-
clockwise direction.
3. Clean the exterior of the toilet with a mild, non-
abrasive bathroom cleaner.
STORAGE
To store our Portable Toilet when not in use:
1. Empty the top tank and waste holding tank.
2. Make sure all water is cleared from the bellows
pump by depressing the pump several times.
3. Store away from direct sunlight.
Note: A small amount of water may remain in the
top tank but will be harmless during storage.
Piston Pump
Slide Valve
Questions or Comments?
We are here to help!
Phone: 1.718.535.1800
Serenelifehome.com/ContactUs
