This is the main product document for model VT-61018CCT.

The file format is pdf, 4 pages, you can download this manual here .

background
LED BACKLIT RECESSED PANEL
TECHNICAL DATA
INTRODUCTION & WARRANTY
WARNING
INSTRUCTION MANUAL
'This product contains a light source of energy eciency class <F/E>', where <F/E> shall be replaced by the
energy eciency class of the contained light source.
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions careful-
ly before starting the installation and keep this manual handy for future reference. If you have any another query, please
contact our dealer or local vendor from whom you have purchased the product. They are trained and ready to serve you
at the best. The warranty is valid for 6 years from the date of purchase. The warranty does not apply to damage caused
by incorrect installation or abnormal wear and tear. The company gives no warranty against damage to any surface due
to incorrect removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of
product for 24 Hours a day would void the warranty. This product is warranted for manufacturing defects only.
Please make sure to turn o the power before starting the installation.
Installation must be performed by a certified person.
If the external flexible cable or cord of this luminaire is damaged, it shall be
exclusively replaced by the manufacturer or his service agent or a similar
qualified person in order to avoid a hazard.
Method of attachment of the cable or cord such that any replacement can only
be made by the manufacturer, his service agent or similar qualifed person.
For Indoor use only
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC
EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
6
6 YEAR
WARRANTY*
COLOR
CHANGING
3-IN-1
VT-61006CCT
VT-61012CCT
VT-61018CCT
VT-61024CCT
78586
78616
78646
78676
VT-61006CCT
VT-61012CCT
VT-61018CCT
VT-61024CCT
104806
104836
104866
104896
MODEL SKU WATTS
LUMENS
BODY
TYPE
TOTAL
CURRENT
INPUT
VOLTAGE
CRI
LIFE
SPAN
[HOURS]
ON/OFF
CYCLE
[TIMES]
SHAPE
DIMENSION
(LxWxH)
BEAM
ANGLE
IP
RATING
6W
120°
>80
IP20
AC:220-240
50/60Hz
AC:220-240
50/60Hz
AC:220-240
50/60Hz
AC:220-240
50/60Hz
36mA
71mA
103mA
160mA
>15000 120.5x28.4mm
170.8x28.4mm
220.8x28.9mm
296x29.1mm
120.5x120.5x28.4mm
170.8x170.8x28.8mm
220.4x220.4x28.8mm
295x295x28.6mm
30,000
>1500030,000
>1500030,000
>1500030,000
ROUND
SQUARE
Plastic
120°
>80
IP20
Plastic
120°
>80
IP20
Plastic
120°
>80
IP20
Plastic
12W
18W
24W
630 Lm
1320 Lm
1980 Lm
2640 Lm
6W
120°
>80
IP20
AC:220-240
50/60Hz
AC:220-240
50/60Hz
AC:220-240
50/60Hz
AC:220-240
50/60Hz
36mA
71mA
103mA
160mA
>1500030,000
>1500030,000
>1500030,000
>1500030,000
Plastic
120°
>80
IP20
Plastic
120°
>80
IP20
Plastic
120°
>80
IP20
Plastic
12W
18W
24W
630 Lm
1320 Lm
1980 Lm
2640 Lm
background
3W
ROUND PANEL
Ø80
(77-82mm)
Ø105
(105-110mm)
Ø150
(145-150mm)
Ø195
(190-200mm)
Ø270
(265-275mm)
6W 12W 18W 24W
INSTALLATION
HOLE SIZE
RECESSED PANEL INSTALLATION DIAGRAM
ATTENTION!
USAGE GUIDELINES/MAINTENANCE
MOUNTING
Do not look directly at the LED light beam. Operate the product only with the rated voltage or within the specified
voltage range. Do not use the product if the protective cover is damaged. Avoid using the product in adverse condi-
tions such as dust, water, moisture, vibrations, explosive atmospheres, or chemical fumes. Strong electromagnetic
interference may aect product performance.
All maintenance must be performed only aer disconnecting the power supply and allowing the product to cool.
Clean with a so, dry cloth only—do not use chemical cleaners. Do not cover the product, and ensure adequate
airflow, as the unit may reach high operating temperatures.
Read the manual before installation. Installation must be performed by a qualified electrician. Exercise caution: the
product has a protective contact/terminal, and failure to connect it may result in electric shock. Refer to the mounting
diagram for guidance. Ensure proper mechanical fastening and electrical connection before first use.
This marking indicates that this
product should not be disposed
of with other household wastes.
Replaceable (LED only)
light source by a professional
Caution, risk of electric shock.
1. Cut a ceiling opening using an appropriate tool, matching the specified
cut-out dimensions.
2. Switch OFF the power supply before proceeding.
3. Connect the AC input wires securely to the terminal block.
4. Adjust the color temperature using the CCT switch.
5. Hold both clips against the light, insert it into the ceiling hole, and
let the springs secure it in place.
6. Switch on the power and test the light.
background
3W
SQUARE PANEL
80x80
(75-80mm)
105x105
(105-110mm)
150x150
(145-150mm)
195x19
(190-200mm)
270x270
(265-275mm)
6W 12W 18W 24W
INSTALLATION
HOLE SIZE
DISASSEMBLY DIAGRAM
(For Market surveillance team only)
1. Cut a ceiling opening using an appropriate tool, matching the specified
cut-out dimensions.
2. Switch OFF the power supply before proceeding.
3. Connect the AC input wires securely to the terminal block.
4. Adjust the color temperature using the CCT switch.
5. Hold both clips against the light, insert it into the ceiling hole, and
let the springs secure it in place.
1. Power o the power, tap the
center of the diusion plate
with a pointed tool, and
remove the damaged plate.
3. If there is no hot-melt column in
the lamp body, or if it has not been
fused, proceed without adjustment. If
the hot-melt column has been fused
to secure the aluminum substrate, cut
the fused section at the hot-melt
point using diagonal pliers.
2. Disconnect the power wire
from the plug terminal.
6. Switch on the power and test the light.
background
V-TAC UK LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT
[email protected] V-TAC, 5A TUNGSTEN PARK, DOWNS ROAD, WITNEY, OXFORDSHIRE, OX29 0AX
V-TAC WEST EUROPE LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
[email protected] FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC WEST EUROPE LTD. GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
4. Push the buckle outward to
release and remove the aluminum
substrate pressing strip from the
bayonet. This step applies only to
the 24W panel light; other models
do not require it.
5. Push the buckle outward to
release the aluminum
substrate, then remove the
light source board.
6. Insert a two-core cable
(18–22 AWG) into the plug-in
terminal, then connect the
external power supply for
testing.
Note: Light source removal will void the warranty.
