LED BACKLIT PANEL
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instruc-
tions carefully before starting the installing and keep this manual handy for future reference. If you have any
another query, please contact our dealer or local vendor from whom you have purchased the product. They are
trained and ready to serve you at the best. The warranty is valid for 6 years from the date of purchase. The war-
ranty does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives
no warranty against damage to any surface due to incorrect removal and installation of the product. The prod-
ucts are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty.
This product is warranted for manufacturing defects only.
WARNING
1. Please make sure to turn o the power before starting the installation.
2. Installation should only be done by a certified electrician.
3. The light source of this luminaire is not replaceable; when the light
source reaches its end of life the whole luminaire shall be replaced.
4. If the external flexible cable or cord of this luminaire is damaged, it shall
be exclusively replaced by the manufacturer or his service agent or a
similar qualified person in order to avoid a hazard.
5. For Indoor use only.
TECHNICAL DATA
MODEL
VT-61045
SKU
241476, 241486
WATTS 40W
LUMENS @SPHERE360°
4800 lm
BEAM ANGLE 110°
CRI
≥80
DF
≥0.9
BODY TYPE FE + PS
LONG LIFE
50,000 Hours
OPERATION TEMPERATURE
-10 to +35°C
DIMENSION 1195x295x33mm
INPUT VOLTAGE AC:220-240V,50/60Hz
IP RATING
IP20
ON/OFF CYCLE
25,000 Times
INSTRUCTION MANUAL
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: [email protected] FOR
MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC
EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
6
6 YEAR
WARRANTY*
Using Starsense Driver
SUPER BRIGHT
LM/WATT EFFICIENCY
120
Luminaires not suitable for
covering with thermally
insulating material.
INSTALLATION INSTRUCTIONS
1. Make a hole into the ceiling 2. Fix the Panel into the Ceiling
3. Connect the cable into the terminal 4. Turn on the switch and test the Panel
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
Non-replaceable
light source
Replaceable control
gear by a professional
AC 220-240V
1 2
3 4
V-TAC UK LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT
[email protected] V-TAC, 5A TUNGSTEN PARK, DOWNS ROAD, WITNEY, OXFORDSHIRE, OX29 0AX
V-TAC WEST EUROPE LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
[email protected] FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC WEST EUROPE LTD. GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
INSTALLATION INSTRUCTIONS
Note: The panel works on DC 30-40V, please connect correctly with the conductor
before connecting the conductor to the power supply main.
1. Ensure the power is turned o before starting the installation.
2. Cut an appropriately sized hole in the ceiling.
3. Mount the panel securely into the ceiling opening.
4. Connect the DC cable from the panel to the driver.
5. Connect the AC source cable to the input side of the driver.
6. Turn on the power and test the lamp.
