LED SLIM BACKLIT PANEL
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installing and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained and
ready to serve you at the best. The warranty is valid for 3 years from the date of purchase. The warranty does not
apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no warranty
against damage to any surface due to incorrect removal and installation of the product. The products are suitable
for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This product is
warranted for manufacturing defects only.
WARNING
1. Please make sure to turn o the power before starting the installation.
2. Installation should only be done by a certified electrician.
3. The light source of this luminaire is not replaceable; when the light source reaches its end of life
the whole luminaire shall be replaced.
4. If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by
the manufacturer or his service agent or a similar qualified person in order to avoid a hazard.
5. For Indoor use only.
TECHNICAL DATA
MODEL
VT-61041
SKU
24141, 24142
WATTS 40W
LUMEN @SPHERE 360°
4800 Lm
BEAM ANGLE 110°
CRI
≥80
DF
≥0.9
BODY TYPE FE + PS
LIFE SPAN 25,000 Hours
OPERATION TEMPERATURE
-10 to +35°C
DIMENSION 595x595x18mm
INPUT VOLTAGE AC:220-240V,50/60Hz
IP RATING
IP20
ON/OFF CYCLE 12,500 Times
INSTRUCTION MANUAL
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: [email protected]
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
SUPER BRIGHT
LM/WATT EFFICIENCY
120
Luminaires not
suitable for covering
with thermally
insulating material.
INSTALLATION INSTRUCTIONS
1. Make a hole into the ceiling 2. Fix the Panel into the Ceiling
4. Turn on the switch and test the Panel
Replaceable control gear
by a professional
Non-replaceable
light source
V-TAC UK LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT
[email protected] V-TAC, 5A TUNGSTEN PARK, DOWNS ROAD, WITNEY, OXFORDSHIRE, OX29 0AX
V-TAC WEST EUROPE LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
[email protected] FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC WEST EUROPE LTD. GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
3. Wiring the DC cable of the panel to
the powersupply. And wiring the AC
source cable to the powersupply.
