MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
FIG. NOTES
2 A clean, dry surface is essential for proper performance for
any adhesive system. The area intended for application of any
adhesive label or nameplate must be prepared by cleaning with
isopropyl alcohol. The solvent is to be applied with a clean, lint
free applicator and the surface allowed to dry before applying
the label or nameplate.
SERVICE PARTS LIST
BULLETIN NO.
PN0011551
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
REVISED BULLETIN
DATE
Jan. 2026
Rechargeable Clip Light
WIRING INSTRUCTION
CATALOG NO. 2014R SERIAL NO. R81A
NAMEPLATE SPECIFICATIONS: INPUT: 5 V 3A Contains 3 Wh Li-Ion
1
2
3
4
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 22-68-2014 USB-C Cover (1)
2 12-20-0691 Service Nameplate (1)
3 42-70-2014 Bottom Clip Assembly (1)
4 42-44-1211 USB-C to USB-C Cable (Optional) (1)
