2W & 1.5W SMD LED RECHARGEABLE CLIP
LIGHT WITH AUTO SENSOR
MODEL NO: HT02LED
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
1. SAFETY
1.1. GENERAL
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the torch.
8 DO NOT use the torch if you suspect that the battery or the torch casing is damaged.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, disassemble, modify or service the batteries.
8 DO NOT crush, puncture, short contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
2. INTRODUCTION
200/150 Lumen clip light with auto-sensor built-in. Light is designed to be clipped to the supplied headband or to a cap. Features front
directional torch and top spotlight with four settings including red light setting. Light easily ips up so you can alternate between lights
quickly. Features two magnets on the clip that enable it to be used independently as a worklight. Battery type: 3.7V Lithium-Polymer.
Supplied with USB charging cable.
3. SPECIFICATION
MODEL NO: HT02LED
Battery: 3.7V 0.5Ah Lithium-Polymer
Charging Time: 1.5hr
LED Type: SMD
Lumen Output: 200/150lm
Operating Time: 2-12hr
4. OPERATION
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY
CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE
USE.
Original Language Version
© Jack Sealey Limited
HT02LED Issue 5 (2) 12/03/24
CLIP (rear)
Cap/headband clip & magnets
SENSOR, RECEIVER &
SPOTLIGHT
ON/OFF SWITCH
& MOTION SENSOR
SWITCH
CHARGING PORT: Red/green
indicates charging status.
Flashes green when motion
sensor is activated.
FIG.1
4.1. WORK MODES
4.1.1. LED Floodlight Low Press on/o switch once and the low oodlight will illuminate.
4.1.2. LED Floodlight High Press a second time and the high oodlight will illuminate
4.1.3. LED Floodlight Red Press a third time and the Red light will illuminate.
4.1.4. LED Spotlight Press a forth time and the spotlight will Illuminate.
4.1.5. One further press will turn the light o.
4.1.6. Sensor mode, press the sensor switch, wave the hand at the sensor reception to enter the sensor mode.
Green light will ash near charging point to show it is operational. This will operate in any work mode listed above.
4.2. RECHARGING
4.2.1. Designed with USB Type C input, supplied with a USB cable which allows for quick and convenient charging.
4.2.2. Red indicator strobes when charging green indicator stays on after fully charged.
5. MAINTENANCE
5.1. Keep the torch clean by wiping with a damp cloth.
5.2. Store torch in a dry childproof area.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Original Language Version
© Jack Sealey Limited
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
HT02LED Issue 5 (2) 12/03/24
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
