GSPTPDW
Sample Installation
Suggested Watering Time Per Week
Bundled Kit Includes:
Installation Instructions
This watering kit will make it easy to keep your mini-gardens thriving.
Complete kit installs in minutes, requiring only a pair of scissors to cut tubing
in lengths to reach from the outside hose bibb to your containers. The tubing
pieces are joined with tees and routed to each of 4 bubblers that you stake
near the plants.
Fine-tune moisture in each container by turning the bubbler cap, adjusting
ow from 0 to 13 GPH, 0 to 3 ft watering radius. Start with lower ow and
watering duration for new plants, gradually increasing it as plants grow and
begin producing tomatoes.
Note: Maximum recommended length of tubing run from a single faucet: 33 ft.
1. Insert one end of the 1/4" Tubing (A) into the Adapter (C).
2. Screw the Adapter onto the Pressure Regulator (B), then onto the faucet.
3. Run tubing to the rst plant container and cut straight across with scissors.
4. Push the tubing onto a side barb of a Tee (D), then cut and attach another tubing
length to the center barb.
5. Extend tubing up into the center of the container and attach a Bubbler (E) to the free
end of that tubing. Stake the bubbler near the base of your plant.
6. Attach tubing to the remaining barb of the tee and run that tubing to the next
container. Repeat connection of the container tubing and bubbler.
7. Repeat for the 3rd and 4th container as needed.
Times shown are based on well composted potting soil with average
consistency and drainage.
TIP: Water in early morning or late evening when temperatures are
coolest and the sun will not dry out the soil quickly.
15 Min. – Small Container
30 Min. – Medium Container
60 Min. – Large Container
Note: The bubbler in this example is adjusted to 6 gph. The goal is
slow, deep watering for root development. Stop when water begins
to seep out of the bottom holes in the container. Repeat when the top
two inches of the soil are dry.
SMART WATERING BUNDLE FOR POTTED TOMATO PLANTS
A
A
A A
A
B
B
C
C
E
E E E E
D
D D D
(1) 1/4" Drip Irrigation Tubing – 25'
T22-050
(1) Pressure regulator; 25 PSI
HT07525PS
(1) 1/4" tubing adapter
HE025DPS
(4) 360° Adjustable Micro Bubblers with stakes
MBF4PKS
(10) 1/4" barbed tees
BT25/10PS
All you need
