Hikvision DS-KH9570-WTE1/S 9 Series Indoor Station User Manual

10 Inch Android Indoor Staon and Scenario

Control Panel

User Manual

Legal Informaon

About this Document

●

This Document includes instrucons for using and managing the Product. Pictures, charts,

images and all other

informaon hereinaer are for descripon and explanaon only.

●

The

informaon contained in the Document is subject to change, without noce, due to

rmware updates or other reasons. Please nd the latest version of the Document at the

Hikvision website ( hps://www.hikvision.com ). Unless otherwise agreed, Hangzhou Hikvision

Digital Technology Co., Ltd. or its aliates (hereinaer referred to as "Hikvision") makes no

warranes, express or implied.

●

Please use the Document with the guidance and assistance of professionals trained in

supporng the Product.

About this Product

●

This product can only enjoy the aer-sales service support in the country or region where the

purchase is made.

●

If the product you choose is a video product, please scan the following QR code to obtain the

"Iniaves on the Use of Video Products", and read it carefully.

Acknowledgment of Intellectual Property Rights

●

Hikvision owns the copyrights and/or patents related to the technology embodied in the

Products described in this Document, which may include licenses obtained from third pares.

●

Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part

of this Document may be excerpted, copied, translated, or modied in whole or in part by any

means without

wrien permission.

●

and other Hikvision’s trademarks and logos are the properes of Hikvision in

various

jurisdicons.

●

Other trademarks and logos menoned are the properes of their respecve owners.

LEGAL DISCLAIMER

●

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS DOCUMENT AND THE

PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS

IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR

FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.

IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,

INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF

BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR

LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING

NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE

PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR

LOSS.

●

YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY

RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,

PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,

VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE

TIMELY TECHNICAL SUPPORT IF REQUIRED.

●

YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE

SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.

ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT

INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF

PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY

RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE

DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR

PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT

RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF

HUMAN RIGHTS ABUSES.

●

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE

LATTER PREVAILS.

Data

Protecon

●

To protect data, the development of Hikvision Products incorporates privacy by design

principles. For example, for Products with facial

recognion features, biometrics data is stored in

your Products with encrypon method; for ngerprint Products, only ngerprint template will be

saved, which is impossible to reconstruct a

ngerprint image.

●

As a data controller/processor, you may process personal data, including collecon, storage, use,

processing, disclosure,

deleon, etc. You are advised to pay aenon to and comply with

applicable laws and regulaons related to the protecon of personal data, including without

limitaon, conducng security controls to safeguard personal data, such as, implemenng

reasonable administrave and physical security controls, conduct periodic reviews and the

assessments of the

eecveness of your security controls.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Symbol Convenons

The symbols that may be found in this document are dened as follows.

Symbol Descripon

Danger

Indicates a hazardous situaon which, if not avoided, will or could

result in death or serious injury.

Cauon

Indicates a potenally hazardous situaon which, if not avoided, could

result in equipment damage, data loss, performance degradaon, or

unexpected results.

Note

Provides addional informaon to emphasize or supplement

important points of the main text.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

iii

Regulatory Informaon

FCC Informaon

Please take aenon that changes or modicaon not expressly approved by the party responsible

for compliance could void the user's authority to operate the equipment.

FCC compliance: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable

protecon against harmful interference in a residenal installaon. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance

with the

instrucons, may cause harmful interference to radio communicaons. However, there is

no guarantee that interference will not occur in a parcular installaon. If this equipment does

cause harmful interference to radio or television

recepon, which can be determined by turning

the equipment o and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the

separaon between the equipment and receiver.

—Connect the equipment into an outlet on a circuit

dierent from that to which the receiver is

connected.

—Consult the dealer or an experienced radio/TV technician for help

This equipment should be installed and operated with a minimum distance 20cm between the

radiator and your body.

FCC

Condions

This device complies with part 15 of the FCC Rules. Operaon is subject to the following two

condions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired

operaon.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE"

and comply therefore with the applicable harmonized European standards listed

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve

2011/65/EU

2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed

of as unsorted municipal waste in the European Union. For proper recycling, return

this product to your local supplier upon the purchase of equivalent new equipment,

or dispose of it at designated

collecon points. For more informaon see:

www.recyclethis.info

2006/66/EC (baery direcve): This product contains a baery that cannot be

disposed of as unsorted municipal waste in the European Union. See the product

documentaon for specic baery informaon. The baery is marked with this

symbol, which may include

leering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the

baery to your supplier or to a designated

collecon point. For more informaon see:www.recyclethis.info

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.

This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to

the following two

condions:

1. this device may not cause interference, and

2. this device must accept any interference, including interference that may cause undesired

operaon of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils

radioexempts de licence.

L'exploitaon est autorisée aux deux condions suivantes :

1. l'appareil ne doit pas produire de brouillage, et

l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage

est suscepble d'en compromere le fonconnement.

Under Industry Canada regulaons, this radio transmier may only operate using an antenna of a

type and maximum (or lesser) gain approved for the transmier by Industry Canada. To reduce

potenal radio interference to other users, the antenna type and its gain should be so chosen that

the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful

communicaon.

Conformément à la réglementaon d'Industrie Canada, le présent émeeur radio peut fonconner

avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émeeur par

Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intenon des

autres ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope

rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une

communicaon sasfaisante.

This equipment should be installed and operated with a minimum distance 20cm between the

radiator and your body.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Cet équipement doit être installé et ulisé à une distance minimale de 20 cm entre le radiateur et

votre corps.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Contents

Chapter 1 About this Manual ...................................................................................................... 1

Chapter 2 Wake Up the Device ................................................................................................... 2

Chapter 3 Main Page Introducon .............................................................................................. 3

Chapter 4 Operaon via PC Web ................................................................................................. 8

4.1 Login ...................................................................................................................................... 8

4.2 Forget Password ..................................................................................................................... 8

4.3 Overview ................................................................................................................................ 8

4.4 Download Web Plug-In .......................................................................................................... 9

4.5 Help ........................................................................................................................................ 9

4.5.1 Open Source

Soware Licenses .................................................................................... 9

4.5.2 View Online Help Document ......................................................................................... 9

4.6 Modify Password ................................................................................................................. 10

4.7 Logout .................................................................................................................................. 10

4.8 Quick

Operaon via Web Browser ....................................................................................... 10

4.8.1 Select Language .......................................................................................................... 10

4.8.2 Time

Sengs ............................................................................................................... 10

4.8.3 No. and System Network ............................................................................................ 11

4.9 Device Management ............................................................................................................ 12

4.10 Camera Management ........................................................................................................ 13

4.11 Access Control Management ............................................................................................. 13

4.11.1 Password

Sengs ..................................................................................................... 13

4.12 Call Sengs ........................................................................................................................ 14

4.12.1 Set Device No. via Web ............................................................................................. 14

4.12.2

Congure Video Intercom Network Parameters via Web Browser ........................... 16

4.12.3 Set Ringtone .............................................................................................................. 17

4.12.4 Call Sengs ............................................................................................................... 17

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

vii

4.13 System Conguraon ......................................................................................................... 18

4.13.1 View Device Informaon via PC Web ........................................................................ 18

4.13.2 Set Time .................................................................................................................... 18

4.13.3 Change Administrator's Password ............................................................................. 19

4.13.4 View Device Arming/Disarming

Informaon via PC Web ......................................... 20

4.13.5 Network Sengs ....................................................................................................... 20

4.13.6 Set Video and Audio Parameters via PC Web ........................................................... 24

4.13.7 Event Conguraon .................................................................................................. 25

4.13.8 Access Conguraon ................................................................................................. 25

4.14 System and Maintenance ................................................................................................... 28

4.14.1 Reboot ...................................................................................................................... 28

4.14.2 Upgrade .................................................................................................................... 29

4.14.3

Restoraon ................................................................................................................ 30

4.14.4 Export Device Parameters via PC Web ...................................................................... 30

4.14.5 Import Device Parameters via PC Web ..................................................................... 30

4.14.6 Device Debugging ..................................................................................................... 30

4.14.7 Log Query .................................................................................................................. 32

4.14.8 Security Management ............................................................................................... 32

4.14.9

Cercate Management ........................................................................................... 32

Chapter 5 Local

Operaon ........................................................................................................ 34

5.1 Quick Operaon ................................................................................................................... 34

5.2 Basic Sengs ....................................................................................................................... 48

5.3 Set Wi-Fi ............................................................................................................................... 48

5.4 Auto Unlock ......................................................................................................................... 49

5.5 Device

Informaon .............................................................................................................. 50

5.6 Call

Sengs .......................................................................................................................... 50

5.7 Custom the Lockscreen Background .................................................................................... 52

5.8 Synchronize Time ................................................................................................................. 53

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

viii

5.9 App Sengs ......................................................................................................................... 54

5.9.1 Link to the Mobile Client ............................................................................................. 54

5.9.2 Unlink the Account ..................................................................................................... 54

5.10 Sound

Sengs ................................................................................................................... 55

5.10.1 Call Sengs ............................................................................................................... 55

5.10.2 Volume Sengs ........................................................................................................ 57

5.11 Set Bluetooth ..................................................................................................................... 57

5.12 Advanced Sengs .............................................................................................................. 58

5.12.1 Set Linked Device IP .................................................................................................. 58

5.12.2 Door Lock Display Sengs ........................................................................................ 58

5.12.3 SIP Sengs ................................................................................................................ 59

5.12.4 Set Indoor Staon Network Parameters ................................................................... 59

5.12.5 Set Indoor

Staon No. ............................................................................................... 60

5.12.6 Add Camera .............................................................................................................. 61

5.12.7 Password

Sengs ..................................................................................................... 61

5.12.8 System Sengs ......................................................................................................... 64

5.13 Arming Mode

Sengs ....................................................................................................... 66

5.14 Smart Home ....................................................................................................................... 67

5.14.1 Smart Home-Device .................................................................................................. 67

5.14.2 Set Scene ................................................................................................................... 68

Chapter 6 Other

Operaons on Device ..................................................................................... 72

6.1 Call Sengs .......................................................................................................................... 72

6.1.1 SIP

Sengs .................................................................................................................. 72

6.1.2 Add Contact ................................................................................................................ 72

6.1.3 Call Resident ............................................................................................................... 73

6.1.4 Call Indoor Extension/Indoor

Staon .......................................................................... 74

6.1.5 Receive Call ................................................................................................................. 75

6.1.6 View Call Logs ............................................................................................................. 75

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

6.2 Live View .............................................................................................................................. 76

6.3 Arm/Disarm ......................................................................................................................... 77

6.3.1 Arm Room ................................................................................................................... 77

6.3.2 Disarm Your Room ...................................................................................................... 78

6.4 The Third-Party App

Sengs ............................................................................................... 78

6.4.1 Install the App ............................................................................................................. 78

6.5 Message Management ........................................................................................................ 80

6.6 Mode Introducon ............................................................................................................... 83

6.7 Add shortcuts ....................................................................................................................... 83

6.8 Unlock Door ......................................................................................................................... 84

Chapter 7 Client Soware Conguraon ................................................................................... 86

7.1 Device Management ............................................................................................................ 86

7.1.1 Add Video Intercom Devices ....................................................................................... 86

7.1.2 Modify Network Informaon ...................................................................................... 88

7.2 System Conguraon ........................................................................................................... 89

7.3 Remote Conguraon .......................................................................................................... 89

7.3.1 System ......................................................................................................................... 89

7.3.2 Video Intercom ........................................................................................................... 94

7.3.3 Network .................................................................................................................... 100

7.4 Call Indoor

Staon via Client Soware .............................................................................. 103

7.5 Receive Call from Indoor Staon/Door Staon .................................................................. 104

7.6 View Live Video of Door Staon and Outer Door Staon .................................................. 105

7.7 View Call Logs .................................................................................................................... 106

7.8 Release

Noce ................................................................................................................... 106

7.9 Search Video Intercom Informaon ................................................................................... 109

7.9.1 Search Call Logs ......................................................................................................... 109

7.9.2 Search

Noce ............................................................................................................ 111

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Chapter 1 About this Manual

Get the manual and related soware from or the ocial website (hp://www.hikvision.com).

Product Model

Indoor Staon DS-KH9570-WTE1/Surface

Scenario Control Panel DS-KC9570-VWTE1/Surface

Scenario Control Panel DS-KC9570-WTE1/Surface

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Chapter 2 Wake Up the Device

You should wake up the device from the standby mode to enter the main page.

When you enable lock screen, you should draw the

paern/ enter pin to unlock the device.

Steps

Touch the screen to wake up the deivce.

Draw the

paern/ enter the pin to unlock the device.

Note

●

Tap Admin Password. Then you can also choose to use admin password to unlock the device.

●

Tap Sengs → Advanced Sengs and enter admin password, then you can silde to disable

Lock Screen..

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Chapter 3 Main Page Introducon

Wake up the device. Refers to Wake Up the Device for details.

Main Page Introducon

On the home page of the device, you can slide down from the upper-le corner to view

nocaon, or slide down from the upper-right corner to view Wi-Fi, Bluetooth Status, turn on/o

Do Not Disturb and Sildent Mode or adjust screen brightness, ringtone volume and call volume.

Figure 3-1 Main Page 1

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 3-2 Main Page 2

Note

Dierent models may have dierent main page. Please refer to your actual device for details.

Main Page

You can tap corresponding models on the main page to perform acons such as call resident/

room, view messages, live view remotely, download apps, arm or disarm the device etc..

Stay Mode

Tap to

to add acons you want the device to perform when you tap Stay Mode.

Note

There are three types of acons you can add inlcuding Acon, Delay and Scene.

For more details about these three types of acons, you can refer to the examples on your

actal devives.

Away Mode

Tap to add acons you want the device to perform when you tap Away Mode.

Note

There are three types of acons you can add inlcuding Acon, Delay and Scene.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

For more details about these three types of acons, you can refer to the examples on your

actal devives.

Sleeping Mode

Tap to add acons you want the device to perform when you tap Sleeping Mode.

Note

There are three types of acons you can add inlcuding Acon, Delay and Scene.

For more details about these three types of acons, you can refer to the examples on your

actal devives.

Scene Shortcut

Tap to add manual scene shortcuts.

Note

It's recommended to add manual scene rst before you perform this acon. So you can

directly select already added scenes cards from the list.

Overview

Tap to enter the overview page.

Here you can view how many rooms, devices and scenes have been added to this device.

Note

You can also tap the message icon at the upper-right corner to view alarm event record and

unlock record.

Tap + icon to add room/device/scene.

Call Page

Tap to enter the call page.

Here you can view live view, call rooms/center, and select rooms to speak to.

Note

Tap at the upper-right corner to enter the page of capture log.

Tap at the upper-right corner to enter the page of video intercom sengs.

Applicaon Center

Tap to enter applicaon center.

Then you can tap + to install new applicaon.

Note

●

You many need a TF card to complete this step.

The TF card slot is at the le boom of the device.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

For more detailed informaon, please tap ? at the pop-up dialog box on your device. Then

you would see detailed introducon about intallaon methods and a picture that shows the

where the TF Card Slot is.

●

Tap

at the upper-right corner, enter admin password to enter the page of advanced

sengs.

Sengs

Tap to enter the page of video intercom sengs.

Note

There are some other shortcuts to visit this page. You can refer to the notes above for reference.

Lock the Screen

Tap to lock the screen.

Shortcut Control Center

Slide dwon from the upper-right corner of the screen, you can set the device easily.

Figure 3-3 Control Center

Do Not Disturb

Tap to enable or disable the Do Not Disturb funcon.

Wi-Fi

Tap to enable or disable the Wi-Fi funcon, and you can connect to wireless network.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Silent Mode

Tap to enable/disable silent mode.

Note

When enabled silent mode, you won't be able to adjust ring volume.

If you slide to adjust ring volume, silent mode will be automacally o.

Bluetooth

Tap to enable/disable bluetooth.

Adjust Brightness

Slide to adjust the brightness of the screen.

Adjust Device Volume

Slide to adjust the volume of the device.

Adjust Ring Volume

Slide to adjust the volume of the ring.

Note

When enabled silent mode, you won't be able to adjust ring volume.

If you slide to adjust ring volume, silent mode will be automacally o.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Chapter 4 Operaon via PC Web

4.1 Login

You can login via the web browser or the remote conguraon of the client soware.

Note

Make sure the device is acvated.

Enter the device IP address in the address bar of the web browser and press Enter to enter the

Enter the device user name and the password. Click Login.

Conguraon of Client Soware

Download and open the client soware. Aer adding the device, click to enter the Conguraon

page.

4.2 Forget Password

If you forget the password when logging in, you can change the password by email address or

security

quesons. Only some models support this funcon.

On the login page, click Forget Password.

Select

Vericaon Mode.

Security Queson Vericaon

Answer the security quesons.

E-mail Vericaon

1. Export the QR code and send it to pw_rec[email protected] as aachment.

2. You will receive a vericaon code within 5 minutes in your reserved email.

3. Enter the vericaon code into the vericaon code eld to verify your idencaon.

Click Next, create a new password and conrm it.

4.3 Overview

You can view linked device, network status and basic

informaon. You can also click on related

parameters to

congure.

Funcon Descripons:

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Link Device

You can check if the device is working properly. You can also see indoor staon, online and

oine device numbers.

Click View More to view the detailed component status. It will lead you to Device Management

page.

Network Status

You can view the network

connecon status.

Note

Click on Wired Network, Hik-Connect or VoIP to congure.

Basic Informaon

You can view the model, serial No. and rmware version.

Note

Click on related parameters to check detailed informaon.

4.4 Download Web Plug-In

Both non-Plug-in live view and live view aer downing plug-in are available. For beer live view,

downloading plug-in for live view is recommended.

Click

→ Download Web Pug-In to download the pulg-in to the local.

4.5 Help

4.5.1 Open Source Soware Licenses

You can view open source soware licenses.

Click

→ Open Source Soware Statement on the upper-right corner to view the licenses.

4.5.2 View Online Help Document

You can view the help document for Web conguraon.

Click → Online Document on the upper right of the Web page to view the document.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

4.6 Modify Password

Steps

Click admin → Modify Password .

Enter the admin password and new password, and then conrm your new password.

Click Save to complete the

sengs. Click Cancel to discard the sengs.

4.7 Logout

Log out the account.

Click admin → Logout → OK to logout.

4.8 Quick

Operaon via Web Browser

4.8.1 Select Language

You can select a language for the device system.

Click

in the top right of the web page to enter the Device Language Sengs page. You can

select a language for the device system from the drop-down list.

By default, the system language is English.

Note

Aer you change the system language, the device will reboot automacally.

4.8.2 Time Sengs

Click in the top right of the web page to enter the wizard page. Aer seng device language,

you can click Next to enter the Time

Sengs page.

Time Zone

Select the device located me zone from the drop-down list.

Time Sync.

NTP

You should set the NTP server's IP address, port No., and interval.

Manual

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

By default, the device me should be synchronized manually. You can set the device me

manually or check Sync. with Computer Time to synchronize the device me with the

computer's me.

Server Address/NTP Port/Interval

You can set the server address, NTP port, and interval.

DST

You can view the DST start me, end me and bias me.

Click Next to save the sengs and go to the next parameter. Or click Skip to skip me sengs.

4.8.3 No. and System Network

Steps

Click

in the top right of the web page to enter the wizard page. Aer previous sengs, you

can click Next to enter the No. and Network System Network sengs page.

Set the device type.

Note

●

If set the device type as Indoor Staon, you can set the Floor No., Room No., Community

No., Building No., Unit No..

●

If set the device type as Indoor Staon, you can set Extension No..

Device Type

The device can be used as a indoor

staon or indoor extension. Select a device type from the

drop-down list.

Room No.

Set the device's room No. Range from 1 to 9999.

Community No.

Set the device community No. Range from 1 to 9.

Building No.

Set the device building No. Range from 1 to 999.

Unit No.

Set the device unit No. Range from 1 to 99.

Floor No.

Set the device installed oor No. Range from 0 to 999.

Set the video intercom network parameters.

Registraon Password

Set the registraon password of the main staon for communicaon. Set the registraon

password of the main staon for communicaon.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Main Door Staon IP

Enter the main door staon's IP address that used for communicaon.

Main Staon IP

Enter the main staon's IP address that used for communicaon.

Private Server IP

Refers to the SIP server IP. Enter the main staon's IP address that used for communicaon.

At this me the main staon is used as a SIP server. Other intercom devices should registered

to this server address to realize communicaon.

Doorphone IP Address

Used for communicaon between the indoor staon and the doo phone.

Center IP Address

Used to connect to the central management server, enabling remote management, alarm

informaon upload.

Click Complete to save the

sengs aer the conguraon.

4.9 Device Management

Device management includes adding device, eding device, and deleng device, and so on.

Click Device Management → Device Management → Device Management to enter this page.

Figure 4-1 Device Management

●

Click +Add to add device.

You need to enter basic informaon including device password, registraon password and serial

No., network parameters including IP address, IPv4 subnet mask, IPv4 default gateway and port,

and extension No.

●

You can also click Import or Export to import/export the devices in batch.

Note

You can import the devices in batch via the excel. You can also download the template on the

website.

●

Click to edit device.

You can edit basic

informaon including device password, registraon password and serial No.,

network parameters including IP address, IPv4 subnet mask, IPv4 default gateway and port, and

extension No.

Click Save to save the changes.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

4.10 Camera Management

You can add, edit or delete the cameras through the camera management operaon.

Click Device Management → Device Management → Camera to enter this page.

Click +Add to add camera.

Figure 4-2 Add Camera

4.11 Access Control Management

4.11.1 Password Sengs

Click Access Control → Password Sengs to enter the page.

Click Add to add password.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 4-3 Add Password

Select password type from the dropdown list. You can set your password type as arming/disarming

password, householder unlocking password or duress code.

Click Save to save the

sengs.

4.12 Call

Sengs

4.12.1 Set Device No. via Web

The device can be used as an indoor staon or indoor extension. You should set the device No.

before usage.

Click Video Intercom → Call

Sengs → Device No. .

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 4-4 Device No. Sengs

If set the device type as Indoor Staon, you can set the Floor No., Room No., Community No.,

Building No., and Unit No.

Device Type

The device can be used as an indooor

staon or indoor extension. Select a device type from the

drop-down list.

Note

If you change the device type, you should reboot the device.

Floor No.

Set the device installed

oor No., ranges from 0 to 999.

Room No.

Set the device room No.

Note

●

If you change the No., you should reboot the device.

●

Room No. ranges from 1 to 9999.

Community No.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Set the device community No., ranges from 1 to 9.

Building No.

Set the device building No., ranges from 1 to 999.

Unit No.

Set the device unit No., ranges from 1 to 99.

Note

If you change the No., you should reboot the device.

Click Save to save the sengs aer the conguraon.

If set the device type as Indoor Extension, you can set Extension No..

Extension No.

If you select indoor extension as the device type, you should enter a number between 1 and 16.

Note

If you change the No., you should reboot the device.

4.12.2 Congure Video Intercom Network Parameters via Web Browser

You can set the registraon password, main staon IP and private server IP etc. to your actual

needs.

Click Video Intercom → Call

Sengs → Video Intercom Network to enter the sengs page.

Registraon Password

Set the

registraon password of the main staon for communicaon. Set the registraon

password of the main staon for communicaon.

Main Door Staon IP

Enter the main door staon's IP address that used for communicaon.

Main Staon IP

Enter the main staon's IP address that used for communicaon.

Private Server IP

Refers to the SIP server IP. Enter the main staon's IP address that used for communicaon. At

this

me the main staon is used as a SIP server. Other intercom devices should registered to

this server address to realize communicaon.

Doorphone IP Address

Used for communicaon between the indoor staon and the doo phone.

Center IP Address

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Used to connect to the central management server, enabling remote management, alarm

informaon upload.

Figure 4-5 Video Intercom Network

Aer conguraon, you can achieve communicaon between access control devices and video

intercom door staon, indoor staon, main staon, plaorms, etc.

Click Save.

4.12.3 Set Ringtone

You can add ringtone on ringtone sengs interface.

Steps

Click Video Intercom → Call

Sengs → Ringtone Sengs .

Click +Add to import ringtone les.

Swipe to enable the selected ringtone.

Note

There are 3 ringtones by default.

Supported le type: wav. The le size cannot exceed 300 KB.

4.12.4 Call Sengs

Set the max. ring duraon, live view me and call forwarding me.

Go to Video Intercom → Call Sengs → Call Sengs .

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 4-6 Call Sengs

Enter Max. Ring Duraon ranges from 30 to 60s.

Enter Max. Live View Time ranges from 10 to 1800s.

Enter Call Forwarding

me ranges from 0 to 20s.

Click Save.

4.13 System

Conguraon

4.13.1 View Device Informaon via PC Web

View the device name, language, model, serial No., version, available cameras, and device capacity,

etc.

Click System and Maintenance → System

Conguraon → System → System Sengs → Basic

Informaon to enter the conguraon page.

You can view the device name, language, model, serial No., version, available cameras, and device

capacity, etc.

Click Upgrade in the Firmware Version, you can go to the upgrade page to upgrade the device.

4.13.2 Set Time

Set the device's me zone, synchronizaon mode, server address, NTP port, and interval. You can

also set the device DST Bias.

Click System and Maintenance → System

Conguraon → System → System Sengs → Time

Sengs .

Click Save to save the sengs aer the conguraon.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Time Zone

Select the device located me zone from the drop-down list.

Time Sync.

NTP

You should set the NTP server's IP address, port No., and interval.

Manual

By default, the device

me should be synchronized manually. You can set the device me

manually or check Sync. with Computer Time to synchronize the device me with the

computer's me.

Server Address Type/Server Address/NTP Port/Interval

You can set the server address type, server address, NTP port, and interval.

DST

Side to enable DST, then you can choose the start me, end me and DST Bias.

Figure 4-7 DST

Click Save to complete.

4.13.3 Change Administrator's Password

Steps

Click System and Maintenance → System Conguraon → System → User Management →

User Management .

Click

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Enter the old password and create a new password.

Conrm the new password.

Click Save.

Cauon

The password strength of the device can be automacally checked. We highly recommend you

change the password of your own choosing (using a minimum of 8 characters, including at least

three kinds of following categories: upper case leers, lower case leers, numbers, and special

characters) in order to increase the security of your product. And we recommend you change

your password regularly, especially in the high security system, changing the password monthly

or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

service provider and/or end-user.

4.13.4 View Device Arming/Disarming Informaon via PC Web

View device arming type and arming IP address.

Go to System and Maintenance → System Conguraon → System → User Management →

Arming/Disarming

Informaon .

You can view the device arming/disarming informaon. Click Refresh to refresh the page.

4.13.5 Network

Sengs

Set Basic Network Parameters via PC Web

Click System and Maintenance → System Conguraon → Network → Network Sengs →

TCP/IP .

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 4-8 TCP/IP Sengs Page

Set the parameters and click Save to save the sengs.

DHCP

If uncheck the funcon, you should set the IPv4 address, IPv4 subnet mask, IPv4 default

gateway, Preferred IPV4 DNS Server and Alternave IPV4 DNS Server manually.

If you check the

funcon, the system will allocate the parameters above automacally.

IPv6

If you check the funcon, the system will support IPv6.

Users with IPv6 support can directly access services via IPv6, avoiding delays caused by IPv4

congeson or cross-ISP transions.

DNS Server

Set the preferred DNS server and the Alternate DNS server according to your actual need.

Set Port via PC Web

Go to

System and Maintenance → System Conguraon → Network → Network Service .

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Enable/Disable HTTP

Enable the HTTP funcon to improve the broswer's vising security.

Go to System and Maintenance → System

Conguraon → Network → Network Service →

HTTP(S) .

ClickSave aer parameters are congured.

HTTP Port

When you log in with a browser, you need to add the modied port number aer the address.

For example, when the HTTP port number is changed to 81, you need to enter hp://

192.0.0.65

：81 when you log in with a browser.

HTTPS Port

Set the HTTPS port for vising browser. But cercaon is required.

View RTSP Port via PC Web

The RTSP port is the port of real-me streaming protocol.

Go to System and Maintenance → System

Conguraon → Network → Network Service → RTSP .

View the Port.

Enable SDK Service

Aer enabling SDK service, the device can be connected to the SDK server.

Click System and Maintenance → System Conguraon → Network → Device Access → SDK

Server to enter the

sengs page.

Enter Server Port.

Click Save to enable the

sengs.

Plaorm

Access via PC Web

Plaorm access provides you an opon to manage the devices via plaorm.

Steps

Click Sengs → Advanced Sengs → Plaorm Access to enter the sengs page.

Slide to enable Cloud Service.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 4-9 Cloud Service

Enter the vericaon code.

Click View to view device QR code. Scan the QR code to bind the account.

Note

8 to 32 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use a

combinaon of no less than 8 leers or numbers.

Click Save to enable the sengs.

VoIP Account

Sengs

You can realize voice call by network.

Steps

Go to System and Maintenance → System Conguraon → Network → Device Access → VoIP.

Enable VoIP Gateway.

Set Register User Name、

Registraon Password、Server IP Address、Server Port、Expiry

Time、Register Status、Number、Display User Name.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 4-10 VoIP Account Sengs

Registraon Password

Enter the registraon password for communicaon via SIP server. The registraon password

for the SIP server is congured usually in the main staon’s SIP sengs.

Server IP Address

Enter the main staon’s IP address that used for VoIP communicaon. At this me the main

staon is used as a SIP server. Other intercom devices should registered to this server address

to realize communicaon.

Number / Display User Name

The device displayed call number and user name.

Click Save.

4.13.6 Set Video and Audio Parameters via PC Web

Congure Audio Parameters via PC Web

You can set device volume.

Go to System and Maintenance → System

Conguraon → Video/Audio → Audio.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 4-11 Audio

Set audio encoding according to your actual needs.

Output volume and speak volume ranges from 0 to 10.

Tap Save.

4.13.7 Event

Conguraon

Click System and Maintenance → System Conguraon → Event → Event Conguraon .

You can slide to enable Door Unlock Record based on your actual needs.

Note

Once enabled, all door unlocking events will be recorded.

Alarm Sengs via PC Web

Steps

Click System and Maintenance → System

Conguraon → Event → Event Conguraon →

Tampering Alarm .

Silde to Enable Tampering Alarm according to your needs.

Note

When tamper buon is loosen, the alarm will be triggered.

4.13.8 Access Conguraon

Set RS-485 Parameters via PC Web

You can set the RS-485 parameters including baud rate, data bit, stop bit etc.

Click System and Maintenance → System

Conguraon → Access Conguraon → RS-485 .

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Check Enable, and set the parameters.

Figure 4-12 Serial Port Parameters

Click Save to save the sengs aer the conguraon.

Baud Rate

Congure data transfer rate.

Data Bit

Congure the number of bits to send data.

Stop Bit

Select the end point for one frame of data.

Parity

Select the serial

communicaon error detecon principle. You can choose to detect that the

number of 1 of the data bits and check digits is odd or even, or that there is no check digit.

Conguring

Event Sengs

Steps

Click System and Maintenance → System Conguraon → Event → Event Conguraon to

enter this page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 4-13 Event Conguraon Interface

Enable Door Unlock Record and Tampering Alarm according to actual needs.

Click Save to save the

sengs.

Incoming Call Linkage

Steps

Click System and Maintenance → System

Conguraon → Event → Event Detecon →

Incoming Call Linkage . to enter conguraon the page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 4-14 Incoming Call Linkage

Enable Incoming Call Linkage and Linked Alarm Output.

Check to select alarm output. Click Save.

When the calling incoming, the alarm you linked will be triggered.

4.14 System and Maintenance

4.14.1 Reboot

You can choose to reboot device manually or automacally.

Click System and Maintenance → Maintenance → Restart to enter the sengs page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 4-15 Reboot

Click Restart to reboot the device manually.

Slide to enable Reboot

Automacally. Set Reboong Time and click Save.

4.14.2 Upgrade

Upgrade Locally via PC Web

You can upgrade the device locally.

Click System and Maintenance → Maintenance → Upgrade to enter the

sengs page.

Select an upgrade type from the drop-down list. Click and select the upgrade le from your

local PC. Click Upgrade to start upgrading.

Online Upgrading via PC Web

You can upgrade the device online.

Click System and Maintenance → Maintenance → Upgarde to enter the

sengs page.

ClickCheck for Updatesto check whether there is updated versions.

If the device is connected to the network and added to Hik-Connect App, you can tap Device

Upgrade → Online Upgrade on device for upgrading when there is an updated version in Hik-

Connect App.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

4.14.3 Restoraon

Restore to Factory Sengs via Web Browser

You can restore device to factory sengs.

Click System and Maintenance → Maintenance → Backup and Reset to enter the sengs page.

Click Restore All, all parameters will be restored to the factory sengs. You should acvate the

device before usage.

Restore to Default

Sengs via PC Web

You can restore device to default sengs.

Click System and Maintenance → Maintenance → Backup and Reset to enter the sengs page.

Click Restore, the device will restore to the default sengs, except for the device IP address and

the user informaon.

4.14.4 Export Device Parameters via PC Web

Export device parameters.

Go to System and Maintenance → Maintenance → Backup and Reset .

Backup

Click Export to export device parameters.

Note

Export device parameters and import those parameters to other devices.

4.14.5 Import Device Parameters via PC Web

Import the conguraon parameters.

Go to System and Maintenance → Maintenance → Backup and Reset .

Import

Cong File

Click and select a le from local PC. Click Import.

4.14.6 Device Debugging

You can set device debugging parameters.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Enable/Disable SSH via Web Browser

You can enable SSH to perform remote debugging.

Click System and Maintenance → Maintenance → Device Debugging → Log for Debugging.

Enable SSH

SSH is used for remote debugging. When you don’t need to use this service, it’s recommended

to disable SSH to improve security.

Ping Network

You can check the plaorm network is normal or not via ping test.

Steps

Click System and Maintenance → Maintenance → Device Debugging → Log for Debugging to

enter the

sengs page.

Enter target host address (IP address).

Click Ping Network.

Set ADB Remote Control

You can set ADB remote control.

Steps

Go to System and Maintenance → Maintenance → Device Debugging .

Enable ADB Remote Control.

Note

ADB remote control can be enabled aer developer mode is enabled.

Print Device Log via PC Web

You can print out the device log.

Click System and Maintenance → Maintenance → Device Debugging → Log for Debugging to

enter the

sengs page.

ClickExport to print out the device log.

Capture Network Packet via PC Web

Set the capture packet duraon and size and start caputre. You can view the log and debug

according to the capture result.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Go to System and Maintenance → Maintenance → Device Debugging → Log for Debugging .

Set Capture Packet Duraon,Capture Packet Size, and click Start Capture.

4.14.7 Log Query

You can search and view the device logs.

Go to Maintenance and Security → Maintenance → Security Audit Log .

Set the major and minor type of the log type. Set the start me and end me for searching, and

click Search.

The results will be displayed below, which including the No.,

me, the major type the minor type,

the channel No., the local/remote user

informaon, the remote host IP, etc.

4.14.8 Security Management

Set security level when login the PC web.

Go to System and Maintenance → Safe → Security Service .

Security Mode

High security level when logging in and verify user

informaon.

Compable Mode

Compable with old user vericaon method.

Click Save.

4.14.9

Cercate Management

It helps to manage the server/client cercates and CA cercate.

Note

The funcon is only supported by certain device models.

Create and Import Self-signed Cercate

Steps

Go to System and Maintenance → Safe →

Cercate Management .

In the Cercate Files area, select a Cercate Type from the drop-down list.

Click Create.

Input

cercate informaon.

Click OK to save and install the cercate.

The created cercate is displayed in the Cercate Details area.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

The cercate will be saved automacally.

Download the cercate and save it to an asking le in the local computer.

Send the asking le to a cercaon authority for signature.

Import the signed

cercate.

1) Select a cercate type in the Import Key area, and select a cercate from the local, and

click Import.

2) Select a

cercate type in the Import Communicaon Cercate area, and select a cercate

from the local, and click Import.

Import Other Authorized Cercate

If you already has an authorized cercate (not created by the device), you can import it to the

device directly.

Steps

Go to System and Maintenance → Safe → Cercate Management .

In the Import Key and Import

Communicaon Cercate areas, select cercate type and

upload cercate.

Click Import.

Import CA

Cercate

Before You Start

Prepare a CA cercate in advance.

Steps

Go to System and Maintenance → Safe → Cercate Management .

Create an ID in the Import CA

Cercate area.

Note

The input cercate ID cannot be the same as the exisng ones.

Upload a cercate le from the local.

Click Import.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Chapter 5 Local Operaon

5.1 Quick Operaon

Aer device acvaon, the wizard page will pop up. The descripon is for other indoor staons.

Steps

Choose language and tap Next.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-1 Language Sengs

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Note

There are two pages of language opons to choose from. Slide le/right to change pages.

Set Lock Screen Paern/ Password and tap Next.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-2 Lock Screen Paern/ Password

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Lock Screen Paern: Draw paern password on the screen. You should connect at least 4

points.

Lock Screen Password: Enter a 6-digit password.

Set network parameters and tap Next.

Edit Manually. Congure IP Address, Subnet Mask and Gateway manually.

Enable DHCP, the device will get network parameters automacally.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-3 Network Parameters

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Congure the indoor staon.

1) Select Device Type as Indoor Staon or Indoor Extension.

2) Set Room No..

Note

If select as Indoor Extension, you only need to need to congure Extension No.

3) Congure advanced sengs. Set Comminity No., Building No., Floor No. and Unit No.

4) Set Time Zoneand Time and Date

5) Silde to enable Capture according to your need. If enabled, the device will capture and save

the records when receive calls.

6) Tap Next.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Enable WLAN and select a Wi-Fi from the list to link.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-5 Wi-Fi

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Link related devices and tap Next. If the device and the indoor staon are in the same LAN, the

device will be displayed in the list. Tap the device or enter the serial No. to link. Auto Search

Door Staon is enabled by default.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-6 Related Device

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

1) Tap the door staon in the list to link.

2) Tap Next.

Oponal: Enable Link to Indoor Extension and link related indoor extension devices. Tap Next. If

the indoor extension and the indoor

staon are in the same LAN, the device will be displayed in

the list. Tap the device or enter the serial No. to link.

1) Tap the indoor extension in the list to link.

2) Edit the network parameters of the indoor extension manually.

Congure the Hik-Connect service sengs.

1) Enable Hik-Connect Service.

2) Edit vericaon code or use the acvaon password by default.

3) View Hik-Connect Server Status.

4) Scan the

rst QR Code to download the APP of Hik-Connect. Scan the second QR Code to add

your device to the APP. Aer adding the device to the APP, you can congure the device

remotely.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-7 Cloud Service Sengs

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Please wait for a short peroid when pairing. If suceed, a 'Congured' nocaon will pop up on

the screen aer the pairing process nished.

5.2 Basic Sengs

You can adjust me and date, change language, change paerns or add new things to control

center here.

Tap Sengs → General Sengs to enter this page.

Time and Date

You can set the displayed me and date format, current me. You can also tap Sync Time and

enable NTP to synchronize the device

me.

Note

●

Make sure your device is connected with the network or the NTP funcon will not available.

●

For details, see Synchronize Time .

Select Language

Tap Language to change the system language.

Note

The indoor staon supports 35 languages.

Paern Sengs

You can slide to enable Gesture Navigaon or Three Buon Navigaon based on your need.

●

Gesture Navigaon

Swipe up from the boom of the screen to return to the home page. Swipe from the le

or right edge to the opposite side to go back to the previous page.

●

Three Buon Navigaon

Use the buon at the boom of the screen to go back to the previous page, the home

page or switch

applicaons.

Control Center

Swipe from the upper-right corner of the screen towards the boom to open Control Center.

You can tap + to add new shortcuts (Call Elevator, Emergency Alarm or Call Center) to Control

Center.

5.3 Set Wi-Fi

Set Wi-Fi connecon.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Tap Sengs → Wi-Fi Sengs . Enable Wi-Fi, and the indoor staon will search available Wi-Fi

automacally.

Note

The Wi-Fi IP can be changed.

Select an Wi-Fi and connect.

5.4 Auto Unlock

Enter a short descripon of your task here (oponal).

Steps

You can enable Auto Unlock Door When Call in Sengs → Video Intercom → Call Sengs →

Auto Unlock .

Figure 5-8 Auto Unlock

Then you can choose which lock to operate auto unlock and congure the auto unlock door

period.

Tap OK to save your conguraons.

Note

Once enabled, the indoor staon will unlock automacally when receiving call from the main

staon.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

5.5 Device Informaon

View the device informaon, including the version, model, serial No. and open source disclaimer.

Steps

Tap

Sengs → Device Informaon to enter the Device Informaon page.

View the device name, model, serial No and LAN IP.

5.6 Call Sengs

You can congure call sengs, live view sengs and contact in the blocklist.

Tap Video Intercom → Call

Sengs to enter the page.

Figure 5-9 Call Seng-1

Change Voice

You can enable Change Voice in preference.

Then you can choose to use your original voice, or change your voice to clown sound or uncle

sound.

Once enabled, you can see it on all video intercom pages.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Note

You can click the icon on your page to change voice.

Call Forwarding Sengs

Enable the funcon and if the call rings for the congured me, it will forward to the congured

rst, second, and third devices by sequence.

You can

congure Call Forwarding Time. Once exceed the congured me, the call will be

transferred to the congured devices.

Auto Unlock Door When Call

You can enable Auto Unlock.

Then you can choose which lock to operate auto unlock and

congure the auto unlock door

period.

Tap OK to save your conguraons.

Note

Once enabled, the indoor staon will unlock automacally when receiving call from the main

staon.

Do Not Disturb Sengs

You can slide to enable Do Not Disturb Sengs. Then you can choose Do Not Disturb Device.

You can also slide to enable Do Not Disturb All Day.

Note

If enabled, you won't receive any nocaons or calls all day.

Message

Slide to enable Message.

Then you can set the Message Retenon Time.

Note

You can slide to enable Auto Answer based on your need. When another terminal calls this

device and the calling device is set to auto answer, you can set the auto answer me. Aer the

set me ends, this device will automacally answer.

Records will be

automacally deleted once exceeded the retenon me.

Auto Capture

Slide to enable Auto Capture. Then you can set the Captured Picture Retenon Time.

Note

You can set the retenon me as 1 day, 7 days or 30 days.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

If enabled, the device will automacally capture a picture once receive a call.

Records will be automacally deleted once exceeded the retenon me.

Live View Sengs

Tap Video Intercom → Live View Sengs to enter the page.

Tap Live View

Duraon to edit me then tap OK to save your sengs.

Note

You can enter a number between 10 to 1800.

Blocklist

Tap Video Intercom → Contact in the Blocklist to enter the page.

You can silde to enable Blocklist.

Once enabled, the contacts in the blocklist won't be able to call the device.

If you want to add blocked contact, you can tap + at the upper-right corner. Then you can

choose from Add From Contact or Add New Blocked Contact.

Note

If you choose Add New Blocked Contact, then you will need to enter the name and call No. of

the new blocked contact manually.

You can also choose tap Add as VoIP Contact based on your actual needs.

5.7 Custom the Lockscreen Background

You can customize the lockscreen background of the device.

Steps

Tap Sengs → Custom to enter this page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-10 Custom the Lockscreen Background

Select the picture you want to set as the lock screen background.

Tap √ to switch the lock screen background.

5.8 Synchronize Time

Before You Start

Wake up the device. Refers to Wake Up the Device for details.

Steps

On the main page of the device, tap Sengs → General Sengs → Time and Date to enter the

me sengs page.

Synchronize the system

me.

Congure the Time Zone, Time Format, Set Date and Time manually.

Tap Sync Time to enable NTP.

Set the synchronizing interval, enter the IP Address/Domain Name of NTP server and port No.,

and select the

me zone.

Note

The default unit of synchronizing interval is minute.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

5.9 App Sengs

The device support adding to Hik-Connect and conguraon remotely via the client.

5.9.1 Link to the Mobile Client

Plaorm access provides you an opon to manage the devices via plaorm.

Steps

Tap Sengs → Advanced Sengs → Plaorm Access to enter the sengs page.

Slide to enable Cloud Service.

Figure 5-11 Cloud Service

Enter the vericaon code.

Oponal: Scan QR code on the screen to add the device to the mobile client.

Click Save to enable the sengs.

5.9.2 Unlink the Account

Remove the account from the mobile client.

Steps

Tap Sengs → Advanced Sengs → Plaorm Access .

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Note

You need to enter the admin (acvaon) password to enter the advanced sengs page

Tap Unlink App Account, and follow the steps on the page.

5.10 Sound Sengs

Set the ringtone sound, the volume, and the auto answer.

5.10.1 Call Sengs

You can set the ringtone, ring duraon, call forwarding me etc..

Before You Start

Wake up the device. Refers to Wake Up the Device for details.

Steps

On the main page of the device, tap

Sengs → Video Intercom → Call Sengs to enter the call

sengs page. You can also tap Video Intercom at the main page, then tap Call Sengs to enter

this page.

Figure 5-12 Call Sengs

Set corresponding parameters.

Ringtone

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

There are 3 ringtones by default, and you can custom and import at most 4 ringtones via

Batch Conguraon Tool or iVMS-4200 Client Soware.

Ringtone Duraon: The maximum duraon of indoor staon when it is called without being

accepted. Ringtone

duraon ranges from 30 s to 60 s.

Intercom Volume

Drag the bar to adjust intercom vlolume.

Voice Changer

You can change your voice when speaking. Original Voice is your own voice, Uncle Voice and

Clown Voice are two voice changers you can choose from.

Call Forwarding Sengs

The ring duraon limit beyond which the call is automacally forwarded to the mobile phone

designated by the resident. Call forwarding ranges from 0 s to 20 s.

Auto Unlock

You can choose which lock to operate auto unlock and

congure the auto unlock door period.

Tap OK to save your conguraons.

Note

Once enabled, the indoor staon will unlock automacally when receiving call from the main

staon.

Other Sengs

You can set the Do Not Disturb and Auto-answer funcons.

Message

Slide to enable Message. Then you can set the Message Retenon Time.

Messages stored in this device will be automacally deleted once exceed the set me.

Auto Answer

Enable Auto Answer. Aer enabling, the call from door staon/villa door staon will be

answered by the indoor

staon automacally. The caller from door staon/villa door

staon can leave voice messages. Aer the message is le, you can check it from Message

on the main page of the device.

Note

Before enabling Auto Answer, the funcon of Message needs to be enabled.

Do Not Disturb Device

Select All and all devices will not disturb this device. Select Indoor Staon and all indoor

staon will not disturb this device.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Note

This funcon can only help to block indoor staons in other rooms. Within the same room,

the indoor staon and extension can't be blocked.

Do Not Disturb All Day

Slide to enable and this device will not be disturbed all day.

Auto Capture

Slide to enable this

funcon. Then the device will automacally capture a picture when

receive a call.

You can also set Captured Picture Retenon Time.

Captured pictures stored in this device will be automacally deleted once exceed the set

me.

Note

Indoor Extension does not support the ring duraon sengs, or call forwarding sengs.

5.10.2 Volume Sengs

Set the microphone volume, prompt sound volume, call volume, and enable touch sound.

Steps

Tap Sengs → Sound to enter the volume sengs page.

Drag the bar to adjust Media Volume, Call & Nocaon Volume.

You can also slide to enable Touchscreen Volume.

Note

You can hear the key sound once enabled.

To carry out Sound Test. Tap Sound Test and select the device (microphone or speaker) you want

to test.

Tap OK. Then you can see a prompt. Follow the

instrucon on the screen. Say a sentence to

check if there is any sound output.

5.11 Set Bluetooth

Tap

Sengs → Bluetooth to enter the page.

Slide to enable Bluetooth.

Note

When bluetooth is enabled in the sengs, the device can be found as 9 serires scenario control

panel.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Select a bluetooth from the list to pair.

You can connect your device with other smart home devices.

5.12 Advanced Sengs

5.12.1 Set Linked Device IP

Linked network parameters refers to the network parameters of devices (like door staon,

doorphone, main staon, center, etc.), to which the indoor staon is linked. Linked devices for the

indoor staon refers to door staon, center, main staon, and doorphone.

Before You Start

Wake up the device. Refers to

Wake Up the Device for details.

Steps

Note

Here take door staon network sengs as example.

On the main page of the device, tap Sengs → Advanced Sengs → Device Conguraon to

enter the device management page.

Note

Admin password is required to enter the advanced sengs page.

Select the device as Indoor Staon or Indoor Extension.

Tap Main Door Staon to pop up the device informaon dialog.

Restore the door

staon via indoor

staon.

Tap to restore the parameters of the door

staon.

Modify the IP address of the linked

door staon.

Tap to modify the IP address of door staon.

Select the device to link. Edit the network parameters.

You can tap Main Doorphone, Center, Indoor Extension or Private SIP Server IP to congure

related informaon.

You can also tap Door Lock Display Sengs to congure which lock to be displayed at the main

page.

5.12.2 Door Lock Display

Sengs

You can congure the number of locks displayed.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Steps

On the main page of the device, tap Sengs → Advanced Sengs → Device Conguraon to

enter the device management page.

Swipe down to the

boom of the page, then you can see Door Lock Display Sengs.

Swch to choose whether to display locks on the call page or preview page and how many locks

to be displayed.

Note

●

You can choose to display one of the locks, two locks or none on the page.

●

For dierent scenarios, you can congure dierent sengs for your main door staon and sub

door staonor.

For example, if a door staon is installed in a security room or outer door, it only allows

opening one lock. If installed at a resident's entrance or inner door, it can have access to open

two locks. There are also cases in which the door staon does not connect to any locks, and

the opon to display lock at the call page is not required.

5.12.3 SIP Sengs

Devices can communicate with each other via SIP protocol. You create set the SIP register

password, and set VIOP account.

Steps

Tap Sengs → Advanced Sengs , and enter admin (acvaon) password.

Tap Video Intercom → VoIP

Sengs .

Slide to enable VOIP.

Set SIP

registraon password.

1) Tap Registraon Password.

2) Create a new SIP register

registraon password and conrm the password.

3) Tap OK.

Oponal: Congure the account informaon, including the user name, the phone number, the

registered user name, the password, the domain, the port No., and the expiraon date.

Note

Up to 32 characters are allowed in the user name.

5.12.4 Set Indoor Staon Network Parameters

Network connecon is mandatory for the use of the indoor staon. Set the network parameters

aer acvang the indoor staon. Only when the IP address of the indoor staon is in the same

network segment as other devices, it can work properly in the same system.

Before You Start

Wake up the device. Refers to Wake Up the Device for details.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Steps

Note

The default IP address of the indoor staon is 192.0.0.64.

Two ways are available for you to set IP address: DHCP, and set IP address manually.

On the main page of the device, tap

Sengs → Advanced Sengs → Ethernet Sengs to enter

the network sengs page.

Note

Admin password is required to enter the advanced sengs page.

Enable DHCP, then the indoor staon can search and get an IP address automacally.

Note

Skip the following steps if you have enabled DHCP.

Set the Local IP, Subnet Mask and Gateway manually.

Congure the DNS address according to your needs.

5.12.5 Set Indoor

Staon No.

Before You Start

Wake up the device. Refers to

Wake Up the Device for details.

Indoor staon No. and the indoor extension No. are numbers, which can be dialed by other devices

to call the indoor

staon and the indoor extension in an intercom system. The indoor staon No., is

composed of the oor No. and the room No.

The indoor extension No. should be a numeric from 1 to 15.

Up to 15 indoor extensions can be set for 1 indoor

staon.

Steps

On the home page of device, tap Sengs → Advanced Sengs → Video Intercom → Device

Conguraon to enter the indoor staon No. sengs page.

Note

Admin password is required to enter the advanced sengs page.

Congure the indoor staon and indoor extension informaon.

Select Indoor Staon as Indoor Staon Type. Tap Room Informaon to edit the Room Name,

Community No., Building No., Unit No., Floor No. and Room No.

Select Indoor Extension as Indoor Staon Type. Tap Room Informaon to edit the Room

Name and Extension No.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

5.12.6 Add Camera

Before You Start

Wake up the device. Refers to

Wake Up the Device for details.

Steps

On the main page of the device, tap Sengs → Advanced Sengs → Intellegient → Device

Management to enter the device management page.

Note

Admin password is required to enter the advanced sengs page.

Tap Network Camera to enter the Add Camera sengs page.

Tap + and select Camera to pop up the dialog box.

Tap Camera and tap + to enter the

sengs page.

Enter the device name and IP address.

Enter the port No. and channel No.

Enter the user name and password of the camera.

Tap √ to add the camera.

For Alarm Control Panel and other Smart Home devices, the adding method is similar. Just tap

the corresponding device type then tap + at the upper right corner. Enter

informaon such as

Device Name, IP Address, Hik-Connect User Name and Password.

5.12.7 Password

Sengs

Security Sengs

If you forgot the admin password, you can change your password via the reserved email address or

the security quesons.

Steps

Tap Sengs → Advanced Sengs , and enter the admin (acvaon) password. Then Tap

Password to enter the

seng page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-13 Password

Tap Password Recovery Method. You can choose Reset Password via Email or Security

Queson.

Tap Security

Queson. Select quesons and enter the answers.

Aer the sengs, you can reset your password via the reserved email address or via answering

quesons.

Lock Screen

You can set a password to lock the screen for safety access. Next me you start up or wake up the

device, you need to enter the password to unlock the screen.

Steps

Tap

Sengs → Advanced Sengs → Password to enter the seng page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-14 Screen Lock

Select Unlock Method as Paern Lock or PIN.

1) If select Paern Lock, you need to draw a paern as your unlock-screen password. You need

to connect at least 4 dots to complete drawing a

paern lock.

2) If select PIN, you need to enter a PIN as your unlock-screen password.

Note

If you want to change the password, tap , and enter the old password rst, and enter a new

password.

If you don't want to set a lock screen password, slide to disable Lock Screen. Then you an tap to

wake up the screen.

Edit

Operaon Password

Before You Start

Wake up the device. Refers to Wake Up the Device for details.

You can edit the duress code, unlock password and arm/disarm password of the indoor

staon.

You can edit the arm/disarm password of the indoor extension.

Steps

On the main page of the device, tap Sengs → Advanced Sengs → Intelligent Control →

Access Password to enter the

sengs page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Note

Admin password is required to enter the advanced sengs page.

Tap Unlock Password, Arm/Disarm Password, or Duress Code to pop up the password sengs

dialog box.

Unlock Password

Enter the unlock password and room No. on the door

staon to open the door.

Arm/Disarm Password

Create an arm/disarm password before conguring alarm parameters.

Arm or disarm the zone for the indoor staon by entering the arm/disarm password.

Note

Arm/Disarm sengs page is hidden by default. Tap Sengs → Advanced Sengs to enable

Zone Alarm funcons, and you can edit the alarm parameters.

Duress Code

When you are hijacked and forced to open the door, you can enter the duress code. An alarm

will be triggered to nofy the management center secretly.

Note

The duress code and the unlock password cannot be the same.

Create a new password and conrm it.

Tap OK to save the sengs.

Note

Indoor Extension only supports admin password and arm/disarm password.

5.12.8 System Sengs

Brightness Adjustment

Tap Sengs → Display and Brightness to enter the seng page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-16 Brightness Adjustment

You can adjust the brightness manually by drag the dot on the bar or you can slide to enable

Automac, then the device will change the screen brightness automcally.

You can also enable One Touch Screen O.

Note

If enabled, you can see at the main page.

Tap this icon to turn o the screen.

What's more, you can set the Auto Screen Lock me. If without any operaon, the screen will be

automacally locked once exceed the set me.

View Open Source Disclaimer

Tap Sengs → Advanced Sengs → Maint. → Open Source Disclaimer to view the detail

informaons.

Note

Admin password is required to enter the advanced sengs page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Reboot the Device

Tap Sengs → Advanced Sengs → Maint. → About .

At this page, you can see detailed informaon including name, app version, system version, device

model, serial number etc..

Swipe down to the

boom of this page. Then you can choose Auto-Reboot or Reboot manually.

Restore the Device

Tap Sengs → Advanced Sengs → Maint. .

At this page, you can choose from Restore to Factory Sengs or Restore Default Parameters.

Note

The device will reboot automacally aer restoraon.

Upgrade the Device

Tap Sengs → Advanced Sengs → Maint. .

At this page, you can select from Online Upgrade or Local Upgrade.

Note

You need to enable cloud service if you want to use online upgrade.

You need to insert the TF card if you want to use local upgrade.

Apps

Tap Sengs → Advanced Sengs → Apps to enter the sengs page.

You can slide to enable Launch applicaon when approaching. Aer enabled, the selected

applicaon will be launched automatcially when approaching.

TF Card

Installaon

Tap Sengs → Advanced Sengs → Apps to enter the sengs page.

Tap TF Card Installaon. Then you can follow the instrucon to check if the TF card/ USB is

inserted.

For more details, you can tap ? to view more

informaon about how to install apps.

5.13 Arming Mode

Sengs

3 arming modes can be congured: stay mode, away mode, sleeping mode.

Before You Start

Wake up the device. Refers to Wake Up the Device for details.

Tap

Sengs → Advanced Sengs to enable Zone Alarm funcons.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Note

Admin password is required to enter the advanced sengs page.

Steps

Tap Stay, Away, Sleeping to enter the page.

Arm the selected zone.

Note

●

Zones are congurable on the arming mode page.

●

24H alarm zone including smoke detector zone, gas detector zone and doorbell zone will be

triggered even if they are disabled.

●

When the doorbell zone is triggered, the device will ring but not upload the alarm signal.

●

Arming mode sengs should be congured with the sengs of arming status on the user

page of the device.

5.14 Smart Home

5.14.1 Smart Home-Device

You can view all devices and their status.

Steps

At the main page, tap → Device to enter the page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-17 Device List

Then you can see the category, number and stauts of the device.

You can also tap OPEN, CLOSE, ON and OFF to control the devices added.

5.14.2 Set Scene

You can set manual scene or automaon scene based on your needs and add them to scene

shortcut

Steps

At the main page, tap

→ Scene to enter the page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-18 Smart Home

Tap +, select from Manual Control or Automaon.

If you select Manual Control, then you will go to the manual scene conguraon page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 5-19 Add Manual Scene

1) Enter the name of the manual scene.

2) Tap + to add acon. You can choose from Acon, Delay and Scene.

Acon

The acon you want the device to control to perform in this scene.

For example, unlock the door.

Delay

Perform an acon aer a set me.

For example, turn on the light aer 7 minutes.

Scene

Choose a scene in your list to perform.

For example, perform stay at home scene.

3) If your device control more than one system, you can tap More

Sengs and select a system

to apply to.

4) Tap √ at the upper-right corner to save your

sengs.

If you select Automaon, then you will go to the automaon scene conguraon page.

1) Enter the name of the

automaon scene.

2) Tap + to add condion. You can choose from Triggered by Device or Scheduled Plan.

If you choose Triggered by Device, then you will need to select a triggering device. If you

choose Scheduled Plan, then you will need to

congure the me and date you want this

scene to repeat performing.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Note

●

Triggered by Device for example: When the door is open, turn on the light.

●

Scheduled Plan for example: Turn on the light at 7:00 am.

3) Then tap + to add acon. You can choose from Acon, Delay and Scene.

Acon

The acon you want the device to control to perform in this scene.

For example, unlock the door.

Delay

Perform an acon aer a set me.

For example, turn on the light aer 7 minutes.

Scene

Choose a scene in your list to perform.

For example, perform stay at home scene.

4) If your device control more than one system, you can tap More Sengs and select a system

to apply to.

5) Tap √ at the upper-right corner to save your sengs.

Note

If you haven't add any manual scene, you can also tap → + to add new manual scene.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Chapter 6 Other Operaons on Device

6.1 Call Sengs

6.1.1 SIP Sengs

Devices can communicate with each other via SIP protocol. You create set the SIP register

password, and set VIOP account.

Steps

Tap

Sengs → Advanced Sengs , and enter admin (acvaon) password.

Tap Video Intercom → VoIP Sengs .

Slide to enable VOIP.

Set SIP

registraon password.

1) Tap Registraon Password.

2) Create a new SIP register registraon password and conrm the password.

3) Tap OK.

Oponal: Congure the account informaon, including the user name, the phone number, the

registered user name, the password, the domain, the port No., and the expiraon date.

Note

Up to 32 characters are allowed in the user name.

6.1.2 Add Contact

Before You Start

Wake up the device. Refers to Wake Up the Device for details.

Steps

On the main page of the device, tap Call Module or icon to enter the call page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 6-1 Call Page

Tap Contacts then tap + to pop up the contact adding dialog.

Enter the contact name and room No.

Note

If you enable the VoIP account funcons, you can tap to enable Add as VoIP contact.

Tap OK to save the sengs.

Note

Up to 200 contacts can be added.

6.1.3 Call Resident

Before You Start

Wake up the device. Refers to

Wake Up the Device for details.

Steps

On the main page of the device, tap Call Module or icon to enter the call page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 6-2 Call Page

Enter the calling number to call.

If you want to call room, the calling number format should be x-x-x-xxx. For example, the

calling number of Community 1, Building 2, Unit 3, and Room 405 is 1-2-3-405. Tap the call

buon to start an audiovisual call.

Note

The community No. can be omied.

If you want to call VoIP contact, the calling number should be the phone number of VoIP

account.

If you want to call center, tap

6.1.4 Call Indoor Extension/Indoor

Staon

If you install indoor staon and indoor extensions at home, you can call the indoor extension via

your indoor

staon, and vice versa. If you have installed more than 2 indoor extensions, you can

also call the indoor extension from the indoor extension.

Call Indoor Extension from Indoor

Staon

Enter 【0-indoor extension No.】 on the indoor staon to start calling the target indoor extension.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Call Indoor Staon from Indoor Extension

Enter 【0-0】 on the indoor extension to call the indoor staon from the indoor extension.

Call Indoor Extension from Indoor Extension

Enter 【0-indoor extension No.】 on the indoor extension to start calling the target indoor extension.

6.1.5 Receive Call

The indoor staon and indoor extension can receive calls from the door staon, the main staon or

iVMS-4200 Client.

On the call from door

staon interface, there are 2 unlock buons: Unlock 1, and Unlock 2. When

you tap Unlock 1, the building gate will open by default, and when you tap Unlock 2, the door

connected to the door

staon with the secure control door unit will open.

Tap the capture buon to capture the live view picture when speaking with the door staon. And

prompts "Captured" will display on the screen.

Indoor extension can receive calls from the door

staon and the main staon only.

6.1.6 View Call Logs

Before You Start

Wake up the device. Refers to Wake Up the Device for details.

Steps

On the main page of the device, tap Call Module or icon to enter the call page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 6-3 Call Page

Tap a piece of call logs in the list to call back.

Note

●

Indoor extension does not support this funcon.

●

The indoor staon saves call logs from door staon, outer door staon, management center

and other indoor staons.

●

Tap then swipe

le to delete call logs one by one.

●

Tap Clear Call Log at the

boom to delete all pieces of call logs.

6.2 Live View

On the live view page, you can view the live video of added door staon and network camera.

Steps

Note

●

Wake up the device. Refers to Wake Up the Device for details.

●

Make sure the network camera or door staon is well-connected.

●

Make sure the indoor extension and the indoor staon are well-connected.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

On the main page of the device, tap Live View module to enter the live view page. You can also

tap / Call Module → Live View to enter this page.

Tap Main Door Staon to enter the live view page of door staon.

Note

●

On the Call from Door Staon page, there are 2 unlock buons: Unlock 1, and Unlock 2. When

you tap Unlock 1, the building gate will open by default. When you tap Unlock 2, the door

staon connected door will open.

●

On the Call from Door

Staon page, there are 1 capture buon. You can tap the buon to

capture the picture via door

staon.

Tap Camera to enter the live view page of network cameras.

6.3 Arm/Disarm

The indoor staon has four kinds of scene modes: sleeping mode, stay mode, away mode, and

custom mode. You can arm or disarm your room in each scene mode manually. The selected scene

mode will be displayed on the main page of the indoor staon.

Note

You should create an Arm/Disarm Password rst.

6.3.1 Arm Room

Select the arm mode to arm your room.

Before You Start

●

Wake up the device. Refers to Wake Up the Device for details.

●

On the main page of the device, tap Sengs → Advanced Sengs → Intelligent Control →

Device Management to add the Alarm Control Panel.

●

You should create an arm/disarm password. Please refers to

Operaon Password Sengs for the

details.

Steps

On the main page of the device, tap Stay to enter the scene page.

Select Stay, Away, Sleeping or Custom.

Enter the arm/disarm password to enable the scene.

Tap OK.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Note

You can also tap → Arm to enable the scene.

6.3.2 Disarm Your Room

Before You Start

Wake up the device. Refers to Wake Up the Device for details.

Steps

On the main page of the device, tap

→ Disarm to disarm.

Enter the arm/disarm password.

Tap OK.

6.4 The Third-Party App

Sengs

6.4.1 Install the App

Install the third-party App to your device.

Steps

If you want to add new apps. Tap Applicaon Center → + . Follow the instruncons at the screen

to insert TF Card/USB.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 6-4 Applicaon Center

If you already installed apps you want. You can add them to the shorcut. Swipe le at the main

page, then tap + → Applicaon and select App.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 6-5 Add App Shortcuts

6.5 Message Management

You can view visitor message, alarm event and capture log on message page.

Wake up the device. Refers to Wake Up the Device for details.

Note

Indoor extension only supports alarm event and capture log.

Message

On the main page of the device, tap or tap Call module to enter the call page. Tap

Message to enter the message details page. You can view the message locally or that from mobile

client.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 6-6 Call Page

Details

Tap the item to view the details of the message.

Delete

Tap clear all records at the

boom of the page to delete. Or slide the item to the le to delete

the item only.

Capture Log

On the main page of the device, tap or tap Call module to enter the call page. Tap

to enter the capture Log page.

You can also tap Message module at the main page, then tap Capture Log to enter this page.

Details

Tap the item to view the details of the capture log.

Delete

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Slide the item to the le to delete the item only.

Alarm Event

Tap Message module at the main page, then tap Alarm Log to enter this page.

Details

Tap the item to view the details of the alarm event.

Delete

Slide the item to the

le to delete the item only.

Unlock Record

Tap Message module at the main page, then tap Unlock Record to enter this page.

Details

Tap the item to view the details of the unlock record.

Delete

Slide the item to the

le to delete the item only.

Delete Records Automacally

You can set the retenon me for messages and auto captures.

Figure 6-7 Retenon Time

For detailed informaon, please go to Call Sengs.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

6.6 Mode Introducon

There are 3 modes by default.

At the main page, you can see the icon of the three modes: Stay mode, away mode and sleeping

mode.

You can tap corresponding icons to set the device as certain mode.

If you want to see details

informaon or if you want to edit any of the modes, you can simply tap

the mode to enter the informaon page.

Note

You need to add acon(s) rst if you want to carry out any of the three modes.

6.7 Add shortcuts

You can add shortcut card to the desktop on your actual needs

Steps

Swipe le from the main page. Tap +.

There are 3 types of cards you can add.

Video Intercom Shortcuts

Inlcuding Live View, Call, Speak, Message, Video Intercom

Sengs, Call Elevator, Call

Management Center, SOS.

Aer adding the shortcut cards to the desktop, you can perform or have access these

modules quicklier.

Smart Home Shortcuts

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 6-8 Smart Home Shotcuts

Smart home devices inlcuding Network Camera, Alarm Control Panel, Door Staon, Light, AC

and Floor Heang, Curtain, Detector.

Scenes already exist.

Device overview, with which you can see how many devices are in

operaon or enabled.

Note

Before creang smart home shortcuts, you need to link your smart home devices with the

device rst.

Applicaon Shortcuts

Add applicaon module to the desktop.

Click the card and hold to drag the card to add it to the desktop.

6.8 Unlock Door

You can unlock the door by entering password.

Enter # + Room No. + password + # to unlock the door.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Note

●

Password contains 6 digits.

●

You're allowed to set 1 password via iVMS-4200 Client Soware or local interface.

●

The password varies according to dierent rooms.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Chapter 7 Client Soware Conguraon

7.1 Device Management

Device management includes adding device, eding device, and deleng device, and so on.

Click Device Management → Device Management → Device Management to enter this page.

Figure 7-1 Device Management

●

Click +Add to add device.

You need to enter basic informaon including device password, registraon password and serial

No., network parameters including IP address, IPv4 subnet mask, IPv4 default gateway and port,

and extension No.

●

You can also click Import or Export to import/export the devices in batch.

Note

You can import the devices in batch via the excel. You can also download the template on the

website.

●

Click to edit device.

You can edit basic informaon including device password, registraon password and serial No.,

network parameters including IP address, IPv4 subnet mask, IPv4 default gateway and port, and

extension No.

Click Save to save the changes.

7.1.1 Add Video Intercom Devices

Steps

Note

●

You can add at most 512 indoor staons and main staons in total to the client, and add at most

16 door staons to the client.

●

For video intercom devices, you are required to create the password to acvate them before

they can be added to the

soware and work properly.

●

You can add online video intercom devices, and add them manually. Here take adding online

video intercom devices as example.

Click Maintenance and Management → Device Management to enter the device management

page.

Click the Device tap.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Click Add to add the device to the client.

Figure 7-2 Add the Device

Oponal: Click Online Device, the acve online devices in the same local subnet with the client

soware will be displayed on the Online Device area.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Note

To add online devices to the soware, you are required to change the device IP address to the

same subnet with your computer rst.

1) You can click Refresh Every 60s to refresh the informaon of the online devices.

2) Select the devices to be added from the list.

3) Click Add to Client to add the device to the client.

Input the required

informaon.

Nickname

Edit a name for the device as you want.

Address

Input the device's IP address. The IP address of the device is obtained automacally in this

adding mode.

Port

Input the device port No. The default value is 8000.

User Name

Input the device user name. By default, the user name is admin.

Password

Input the device password.

Oponal: You can check the checkbox Export to Group to create a group by the device name. All

the channels of the device will be imported to the corresponding group by default.

The client also provides a method to add the

oine devices. Check the checkbox Add Oine

Device, input the required informaon and the device channel number and alarm input number,

and then click Add. When the oine device comes online, the soware will connect it

automacally.

Note

●

Add Mulple Online Devices: If you want to add mulple online devices to the client soware,

click and hold Ctrl key to select mulple devices, and click Add to Client to open the device

adding dialog box. In the pop-up message box, enter the user name and password for the

devices to be added.

●

Add All the Online Devices: If you want to add all the online devices to the client soware,

click Add All and click OK in the pop-up message box. Then enter the user name and password

for the devices to be added.

7.1.2 Modify Network Informaon

Select the device from the device list, click , and then you can modify the network informaon

of the selected device.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Note

You should enter the admin password of the device in the Password eld of the pop-up window to

modify the parameters.

7.2 System Conguraon

You can congure the video intercom parameters accordingly.

Steps

Click Maintenance and Management → System Conguraon → Acs and videoIntercom to

enter the system

conguraon page.

Enter the required informaon.

Ringtone

Click ... and select the audio le from the local path for the ringtone of indoor staon.

Oponally, you can click for a tesng of the audio le.

Max. Ring Duraon

Input the maximum duraon of the ringtone, ranging from 15 seconds to 60 seconds.

Max. Speaking

Duraon with Indoor Staon

Input the maximum duraon of speaking with the indoor staon, ranging from 120 seconds

to 600 seconds.

Max. Speaking Duraon with Door Staon

Input the maximum duraon of speaking with the door staon, ranging from 90 seconds to

120 seconds.

Click Save to save the

sengs.

7.3 Remote

Conguraon

In the device list area, select a device and click to enter the remote conguraon page.

7.3.1 System

Click System on the remote conguraon page to display the device informaon: Device

Informaon, General, Time, System Maintenance, User, and RS-485.

Device

Informaon

Click Device Informaon to enter device basic informaon page. You can view basic informaon

(the device type, and serial No.), and version informaon of the device.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 7-3 Device Informaon

General

Click General to enter device general parameters sengs page. You can view and edit the device

name and device ID.

Figure 7-4 General

Time

Click Time to enter the device me sengs page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 7-5 Synchronize Time

Select Time Zone or Enable NTP. Click Save to save the me sengs.

●

Time Zone

○

Select a me zone from the drop-down list menu.

○

Click

Synchronizaon.

●

NTP

○

Check the checkbox of Enable NTP to enable NTP.

○

Enter the server address, NTP port, and

synchronizaon interval.

Note

The default port No. is 123.

System Maintenance

Click System Maintenance to enter the page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 7-6 System Maintenance

●

Click Reboot and the system reboot dialog box pops up. Click Yes to reboot the system.

●

Click Restore Default Sengs to restore the default parameters.

●

Click Restore All to restore all parameters of device and reset the device to

inacve status.

Note

○

Click Restore Default Sengs, all default sengs, excluding network parameters, will be

restored.

○

Click Restore All, all default sengs, including network parameters, will be restored. The

device will be reset to

inacvated status.

●

Click Import Conguraon File and the import le window pops up. Select the path of remote

conguraon les. Click Open to import the remote conguraon le. The conguraon le is

imported and the device will reboot automacally.

●

Click Export Conguraon File and the export le window pops up. Select the saving path of

remote

conguraon les and click Save to export the conguraon le.

●

Click ... to select the upgrade le and click Upgrade to remote upgrade the device. The process

of remote upgrade will be displayed in the process bar.

●

Select a language, and click Save to change the device system language.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Note

●

The device supports 11 languages: English, Russian, German, Italian, French, Portuguese,

Spanish, Turkish, Arabic, Polish, and Vietnamese.

●

Reboong the device is required aer you change the system language.

User

Click User to enter the user informaon eding page.

Select the user to edit and click Modify to enter the user parameter page.

Figure 7-7 User Page

Note

●

The new password and conrm password should be idencal.

●

Aer eding the password of device, click refresh buon from the device list, the added device

will not be there. You should add the device again with new password to operate the remote

conguraon.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

RS-485

Click RS485 to enter the RS-485 sengs page. You can view and edit the RS-485 parameters of the

device.

Figure 7-8 RS-485 Sengs

Note

For indoor staon and main staon, there are 3 choices for the working mode: transparent

channel, disable, and custom.

7.3.2 Video Intercom

Click Video Intercom on the remote conguraon page to enter the video intercom parameters

sengs: Device Number Conguraon, Time Parameters, Password, Zone Conguraon, IP Camera

Informaon, and Volume Input and Output Conguraon, and so on.

Time Parameters

Steps

Click Time Parameters to enter me parameters sengs page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 7-9 Time Parameters

Congure the maximum ring duraon, maximum live view me, and call forwarding me.

Click Save.

Note

●

Maximum ring duraon is the maximum duraon of indoor staon when it is called without

being received. The range of maximum ring duraon varies from 30s to 60s.

●

Maximum live view me is the maximum me of playing live view of the indoor staon. The

range of maximum live view

me varies from 10s to 60s.

●

Call forwarding

me refers to the ring duraon limit beyond which the call is automacally

forwarded to the mobile phone designated by the resident. The range of call forwarding me

varies from 0s to 20s.

●

For indoor extension, it only requires

seng the maximum live view me.

Volume Input and Output

Steps

Click Volume Input/Output to enter the volume input and output page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 7-10 Volume Input and Output

Slide the slider to adjust the volume input, volume output and talk volume.

Click Save to enable the

sengs.

Ring Import

Steps

Click Ring Import to enter the ring conguraon page.

Figure 7-11 Ring Import

Click + to add the ring, and click x to delete the imported ring.

Note

●

The ring to be imported should be in the wav format, and the size of the ring cannot be larger

than 300k.

●

Up to 4 rings can be added.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Deploy Info

Click Deploy Info, you can get the deploy informaons.

Figure 7-12 Deploy Info

SIP No.

Sengs

Steps

Click SIP No. Sengs to enter the sengs page.

Figure 7-13 Extension Sengs

Click Add.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Figure 7-14 Add SIP Info

Select Device Type as Indoor Extension.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

Enter the required informaon.

Serial No.

Enter the device's serial No.. The serial No. is on the rear panel of the device (A xed-length

number with 9 digits).

IP Address

Enter the device's IP address.

Gateway

Enter the device's gateway.

Subnet Mask

Enter the device's subnet mask.

Password

Enter the device password, ranging from 8 to 16 characters in length.

No.

Enter the device No., ranging from 1 to 5.

Click Save to enable the

sengs.

Set SIP informaon.

Click

Congure Congure serial No., IP address, gateway, subnet mask, password and No. of

the device.

Click Delete Delete the SIP Number.

Click Clear Clear all SIP numbers.

Click Refresh Refresh SIP Informaon.

Intercom Protocol

Steps

Select Protocol as Private Protocol 1 or Private Protocol 2.

Click save to save the

sengs.

Custom

Buon

Steps

Click Custom

Buon to enter me parameters sengs page.

Select Key Number as 1, 2, 3 or 4 depending on which buon you would like to custom.

Congure dierent funcons for buons by selecng dierent Key Sengs.

Oponal: Select Open in Screen Display Parameters area to display icons of Call Management

Center or Call Elevator on the menu.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

7.3.3 Network

Local Network Conguraon

Steps

Click Local Network Conguraon to enter local network conguraon page.

Figure 7-15 Local Network Conguraon

Enter the local IP address, subnet mask, gateway address, and port No.

Click Save to enable the sengs.

Note

●

The default port No. is 8000.

●

Aer eding the local network parameters of device, you should add the devices to the device

list again.

SIP Sengs

Steps

Click SIP

Sengs to enter the sengs page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

100

Figure 7-16 SIP Sengs

Set the parameters according to your needs.

Click Save to enable the sengs.

DNS

Sengs

The indoor staon supports 2 DNS address.

Click Advanced Sengs to enter DNS address sengs page.

Edit the IP address and click Save.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

101

Figure 7-17 DNS Sengs

Congure

Mobile Client Connecon

Congure Hik-Connect server parameters before viewing videos via mobile client.

Before You Start

Make sure the indoor staon connects to the network.

Steps

Click Hik-Connect to enter conguraon page.

Enable Enable Hik-Connect Access.

Enable Custom and edit Service Address

Enter the

Vericaon Code.

Click Save.

Group Network

Sengs

Click Group Network Sengs to enter the group network sengs page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

102

Figure 7-18 Group Network Sengs

Device No.

Sengs

Select the device type from the drop-down list, and set the corresponding informaon.

Note

●

Device type can be set as indoor staon or indoor extension.

●

When you select indoor extension as device type, the device No. can be set from 1 to 5.

Click Save to enable the sengs.

Linked Device Network

Sengs

Enter Registraon Password and set the corresponding informaon.

Note

●

D series refers to door staon, and V series refers to villa door staon.

●

Registraon password is the password of the SIP server.

7.4 Call Indoor Staon via Client Soware

Steps

On the main page, click Access Control → Video Intercom to enter the Video Intercom page.

Select a resident and click

in the Call Household column to start calling the selected resident.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

103

Figure 7-19 Calling Indoor Staon

Aer answered, you will enter the In Call window.

●

Click

to adjust the volume of the loudspeaker.

●

Click Hang Up to hang up.

●

Click to adjust the volume of the microphone.

Note

●

One indoor staon can only connect with one client soware.

●

You can set the maximum ring duraon ranging from 15s to 60s, and the maximum speaking

duraon ranging from 120s to 600s via the Remote Conguraon of indoor staon.

7.5 Receive Call from Indoor Staon/Door Staon

Steps

Select the client soware in the indoor staon or door staon page to start calling the client and

an incoming call dialog will pop up in the client

soware.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

104

Figure 7-20 Incoming Call from Indoor Staon

Click Answer to answer the call. Or click Hang Up to decline the call.

Aer you answer the call, you will enter the In Call window.

●

Click

to adjust the volume of the loudspeaker.

●

Click Hang Up to hang up.

●

Click to adjust the volume of the microphone.

●

For door

staon, you can click to open the door remotely.

Note

●

One video intercom device can only connect with one client soware.

●

The maximum ring duraon can be set from 15s to 60s via the Remote Conguraon of the

video intercom device.

●

The maximum speaking

duraon between indoor staon and client can be set from 120s to

600s via the Remote

Conguraon of indoor staon.

●

The maximum speaking duraon between door staon and client can be set from 90s to 120s

via the Remote Conguraon of door staon.

7.6 View Live Video of Door Staon and Outer Door Staon

You can get the live view of the door staon and outer door staon in the Main View module and

control the door staon and outer door staon remotely.

In the Main View module, double-click a door

staon or outer door staon device or drag the

device to a display window to start the live view.

You can click Unlock on the menu to open the door remotely.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

105

7.7 View Call Logs

You can check all the call logs, including dialed call logs, received call logs and missed call logs. You

can also directly dial via the log list and clear the logs.

Steps

On the main page, click Access Control → Video Intercom to enter the Video Intercom page.

Click the Call Log tab to enter the Call Log page. All the call logs will display on this page and you

can check the log

informaon, e.g., call status, start me, resident's organizaon and name,

device name and ring or speaking duraon.

Figure 7-21 Call Log

Oponal: Click the icon in the Operaon column to re-dial the resident.

7.8 Release

Noce

You can create dierent types of noces and send them to the residents. Four noce types are

available, including

Adversing, Property, Alarm and Noce Informaon.

Steps

On the main page, click Access Control → Video Intercom to enter the Video Intercom page.

Click

Noce to enter the Release Noce page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

106

Figure 7-22 Release Noce

Click Add on the le panel to create a new noce.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

107

Figure 7-23 Create a Noce

Edit the noce on the right panel.

1) Click ... on the Send To eld to pop up the Select Resident dialog.

2) Check the checkbox(es) to select the resident(s). Or you can check the All checkbox to select

all the added residents.

3) Click OK to save the

selecon.

4) Enter the subject on the Subject eld.

Note

Up to 63 characters are allowed in the Subject eld.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

108

5) Click in the Type eld to unfold the drop-down list and select the noce type.

6) Oponal: Click View to add a local picture to the noce.

Note

Up to 6 pictures in the JPGE format can be added to one noce. And the maximum size of one

picture is 512KB.

7) Enter the noce content in the Informaon eld.

8) Oponal: You can also click Clear to clear the edited content.

Note

Up to 1023 characters are allowed in the Content eld.

Click Send to send the edited noce to the selected resident(s). The sent noce informaon will

display on the le panel. You can click a noce to view the details on the right panel.

7.9 Search Video Intercom

Informaon

You can search the call logs between the iVMS-4200 client soware and video intercom devices,

device unlocking logs and the sent noce informaon.

On the main page, click Access Control to enter the access control module.

In the Access Control module, click Video Intercom to enter the Video Intercom page.

7.9.1 Search Call Logs

Steps

On the main page, click Access Control → Video Intercom to enter the Video Intercom page.

Click Call Log to enter the Call Log page.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

109

Figure 7-24 Search Call Logs

Set the search condions, including call status, device type, start me and end me.

Call Status

Click to unfold the drop-down list and select the call status as Dialed, Received or Missed.

Or select All to search logs with all statuses.

Device Type

Click

to unfold the drop-down list and select the device type as Indoor Staon, Door

Staon, Outer Door Staon or Analog Indoor Staon. Or select All Devices to search logs

with all device types.

Start Time/End Time

Click

to specify the start me and end me of a me period to search the logs.

Oponal: You can click Reset to reset all the congured search condions.

Click Search and all the matched call logs will display on this page.

●

Check the detailed

informaon of searched call logs, such as call status, ring/speaking

duraon, device name, resident organizaon, etc.

●

Input keywords in the Search

eld to lter the desired log.

●

Click Export to export the call logs to your PC.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

110

7.9.2 Search Noce

Steps

On the main page, click Access Control → Video Intercom to enter the Video Intercom page.

Click

Noce to enter the Noce page.

Figure 7-25 Search Noce

Set the search condions, including noce type, subject, recipient, start me and end me.

Recipient

Input the recipient informaon in the Recipient eld to search the specied noce.

Subject

Input the keywords in the Subject eld to search the matched noce.

Type

Click to unfold the drop-down list and select the noce type as Adversing Informaon,

Property Informaon, Alarm Informaon or Noce Informaon. Or select All to search

noces with all types.

Oponal: You can click Reset to reset all the congured search condions.

Click Search and all the matched noces will display on this page.

●

Check the detailed informaon of searched noces, such as sending me, sending status, etc.

●

Input keywords in the Search

eld to lter the searching result.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

111

You can view and edit the noce details, check the sending failed/sent succeeded/unread users,

and resend the noce to sending failed/unread users.

Oponal: Click Export to export the noces to your PC.

10 Inch Android Indoor Staon and Scenario Control Panel User Manual

112

UD44917B

Hikvision DS-KH9570-WTE1/S 9 Series Indoor Station

Product's Documents

DS-KH9570-WTE1S User Manual

Specifications

Hikvision DS-KH9570-WTE1/S Questions and Answers
