VI-H460W Network Indoor Staon
User Manual
Legal Informaon
About this Document
●
This Document includes instrucons for using and managing the Product. Pictures, charts,
images and all other
informaon hereinaer are for descripon and explanaon only.
●
The
informaon contained in the Document is subject to change, without noce, due to
rmware updates or other reasons. Please nd the latest version of the Document at the
Hikvision website ( hps://www.hikvision.com ). Unless otherwise agreed, Hangzhou Hikvision
Digital Technology Co., Ltd. or its aliates (hereinaer referred to as "Hikvision") makes no
warranes, express or implied.
●
Please use the Document with the guidance and assistance of professionals trained in
supporng the Product.
About this Product
This product can only enjoy the aer-sales service support in the country or region where the
purchase is made.
Acknowledgment of Intellectual Property Rights
●
Hikvision owns the copyrights and/or patents related to the technology embodied in the
Products described in this Document, which may include licenses obtained from third pares.
●
Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part
of this Document may be excerpted, copied, translated, or modied in whole or in part by any
means without
wrien permission.
●
and other Hikvision's trademarks and logos are the properes of Hikvision in various
jurisdicons.
●
Other trademarks and logos menoned are the properes of their respecve owners.
LEGAL DISCLAIMER
●
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS DOCUMENT AND THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.
IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
VI-H460W Network Indoor Staon User Manual
i
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
●
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
●
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
●
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE
LATTER PREVAILS.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
VI-H460W Network Indoor Staon User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
VI-H460W Network Indoor Staon User Manual
iii
Regulatory Informaon
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated
collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include
leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the
baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two
condions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence.
L'exploitaon est autorisée aux deux condions suivantes :
1. l'appareil ne doit pas produire de brouillage, et
2.
l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est suscepble d'en compromere le fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmier by Industry Canada. To reduce
potenal radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communicaon.
VI-H460W Network Indoor Staon User Manual
iv
Conformément à la réglementaon d'Industrie Canada, le présent émeeur radio peut fonconner
avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émeeur par
Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intenon des
autres
ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une
communicaon sasfaisante.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
Cet équipement doit être installé et
ulisé à une distance minimale de 20 cm entre le radiateur et
votre corps.
If a power adapter is provided in the device package, use the provided adapter only. If no power
adapter is provided, ensure the power adapter or other power supply complies with Limited Power
Source. Refer to the product label for the power supply output parameters.
VI-H460W Network Indoor Staon User Manual
v
Contents
Chapter 1 Acvaon ................................................................................................................... 1
1.1 Acvate Indoor Staon .......................................................................................................... 1
1.2 Acvate via Guarding Vision .................................................................................................. 2
Chapter 2 Conguraon on Device ............................................................................................. 3
2.1 Quick Operaon (For Normal Device) .................................................................................... 3
2.2 Basic Sengs ......................................................................................................................... 9
2.2.1 Set Indoor Staon Network Parameters ..................................................................... 10
2.2.2 Set Linked Device IP .................................................................................................... 11
2.2.3 Set Wi-Fi ...................................................................................................................... 12
2.2.4 Set Indoor
Staon No. ................................................................................................. 13
2.2.5 SIP Sengs .................................................................................................................. 15
2.2.6 Add Camera ................................................................................................................ 16
2.2.7 Zone and Alarm
Sengs ............................................................................................. 17
2.3 Password Sengs ................................................................................................................ 19
2.3.1 Change Admin Password ............................................................................................. 19
2.3.2 Security
Sengs .......................................................................................................... 20
2.3.3 Modify Arm/Disarm Password .................................................................................... 20
2.3.4 Modify Unlock/Duress Code ....................................................................................... 22
2.4 Synchronize Time ................................................................................................................. 23
2.5 Sound
Sengs ..................................................................................................................... 23
2.5.1 Call
Sengs ................................................................................................................. 24
2.5.2 Volume Sengs .......................................................................................................... 26
2.6 App Sengs ......................................................................................................................... 26
2.6.1 Link to the Mobile Client ............................................................................................. 26
2.6.2 Unlink the Account ..................................................................................................... 27
2.7 System
Sengs .................................................................................................................... 27
VI-H460W Network Indoor Staon User Manual
vi
2.8 Output Sengs .................................................................................................................... 29
2.9 Device Informaon .............................................................................................................. 30
Chapter 3 Other
Operaons on Device ..................................................................................... 31
3.1 Leave Message ..................................................................................................................... 31
3.2 Call Sengs .......................................................................................................................... 31
3.2.1 Add Contact ................................................................................................................ 31
3.2.2 Call Resident ............................................................................................................... 32
3.2.3 Call Indoor Extension/Indoor Staon .......................................................................... 33
3.2.4 Receive Call ................................................................................................................. 33
3.2.5 View Call Logs ............................................................................................................. 33
3.3 Live View .............................................................................................................................. 34
3.4 Arming Mode Sengs ......................................................................................................... 35
3.5 Arm/Disarm ......................................................................................................................... 36
3.5.1 Arm Room ................................................................................................................... 37
3.5.2 Disarm Room .............................................................................................................. 37
3.6 Call Elevator ......................................................................................................................... 38
3.7 Relay
Sengs ....................................................................................................................... 39
3.8 Informaon Management .................................................................................................... 39
Chapter 4 Remote Operaon via Client Soware ...................................................................... 41
4.1 Device Management ............................................................................................................ 41
4.1.1 Add Video Intercom Devices ....................................................................................... 41
4.1.2 Modify Network
Informaon ...................................................................................... 43
4.2 System
Conguraon ........................................................................................................... 44
4.3 Remote Conguraon .......................................................................................................... 44
4.3.1 System ......................................................................................................................... 44
4.3.2 Video Intercom ........................................................................................................... 50
4.3.3 Network ...................................................................................................................... 60
4.4 Call Indoor
Staon via Client Soware ................................................................................ 64
VI-H460W Network Indoor Staon User Manual
vii
4.5 Receive Call from Indoor Staon/Door Staon .................................................................... 65
4.6 View Live Video of Door Staon and Outer Door Staon .................................................... 66
4.7 View Call Logs ...................................................................................................................... 67
4.8 Release
Noce ..................................................................................................................... 67
4.9 Search Video Intercom Informaon ..................................................................................... 70
4.9.1 Search Call Logs ........................................................................................................... 70
4.9.2 Search Noce .............................................................................................................. 72
VI-H460W Network Indoor Staon User Manual
viii
Chapter 1 Acvaon
1.1 Acvate Indoor Staon
You can congure and operate the indoor staon aer creang a password for the device
acvaon.
Steps
1.
Power on the device. It will enter the acvaon page.
Figure 1-1 Acvaon Page
2.
Create a password and conrm it.
Note
You can click to enable or disable password reveal.
3.
Tap OK to acvate the indoor staon.
Note
We highly recommend you to create a strong password of your own choosing (using a minimum
of 8 characters, including at least three kinds of following categories: upper case leers, lower
case leers, numbers, and special characters) in order to increase the security of your product.
And we recommend you change your password regularly, especially in the high security system,
changing the password monthly or weekly can beer protect your product.
Aer device acvaon, the wizard page will pop up.
VI-H460W Network Indoor Staon User Manual
1
1.2 Acvate via Guarding Vision
You can only congure and operate the indoor staon aer creang a password for the device
acvaon.
Before You Start
Default parameters of indoor staon are as follows:
●
Default IP Address: 192.0.0.64.
●
Default Port No.: 8000.
●
Default User Name: admin.
Steps
1.
Run the client
soware, enter Device Management, check the Online Device area.
2.
Select an inacvated device and click the Acvate.
3.
Create a password, and
conrm the password.
Cauon
●
The password should be 8 to 16 characters.
●
The password should contain at least 2 of the following types: digits, lowercase leers,
uppercase leers and special characters.
●
Do not contain following characters in the password: the user name, 123, admin
(case-
insensive),
4 or more connuously increasing or decreasing digits, or 4 or more consecuvely
repeated characters.
●
The password strength of the device can be
automacally checked. In order to increase the
security of your product, we highly recommend you change the password of your own
choosing. And we recommend you change your password regularly, especially in the high
security system, changing the password monthly or weekly can
beer protect your product.
Proper
conguraon of all passwords and other security sengs is the responsibility of the
service provider and/or end-user.
4.
Click OK to acvate the device.
VI-H460W Network Indoor Staon User Manual
2
Chapter 2 Conguraon on Device
2.1 Quick Operaon (For Normal Device)
Aer device acvaon, the wizard page will pop up. The descripon is for other indoor staons.
Steps
1.
Choose language and tap Next.
Figure 2-1 Language Sengs
2.
Set password reset methods and tap Next.
-
Bind an email address. If you forget your admin password, you can reset the password via the
reserved email address.
-
Tap Change to Security Queson to select security quesons and enter the answers. If you
forget your admin password, you can reset the password via answering the quesons.
VI-H460W Network Indoor Staon User Manual
3
Figure 2-2 Password Reset Methods
3.
Set network parameters and tap Next.
-
Edit Local IP, Subnet Mask and Gateway parameters manually.
-
Enable Auto Get IP address, the device will get network parameters
automacally.
Figure 2-3 Network Parameters
VI-H460W Network Indoor Staon User Manual
4
4.
Congure the indoor staon.
1) Select Device Type as Indoor Staon or Indoor Extension.
2) Set Floor No..
3) Set Room No..
4) Congure advanced sengs. Set Comminity No., Building No. and Unit No.
5) Set
Registraon Password.
6) Tap Next.
Figure 2-4 Indoor Staon Sengs
5.
Enable the Wi-Fi funcon. Select a Wi-Fi from the list and enter the Wi-Fi's password to get
connected. Tap Next.
Note
The device should support Wi-Fi.
VI-H460W Network Indoor Staon User Manual
5
Figure 2-5 Wi-Fi
6.
Set me and tap Next.
1) Select the Time Zone.
2) Tap Date Format and Time Format to set the
me format.
3) Tap Time to set
me manually.
4) Enable DST.Set the DST start me, end me and bias me.
VI-H460W Network Indoor Staon User Manual
6
Figure 2-6 Time Sengs
7.
Congure the Hik-Connect service sengs.
1) Enable Hik-Connect service.
2) Edit vericaon code or use the acvaon password by default.
3) View Hik-Connect Server Status.
4) Scan the
rst QR Code to download the APP of Hik-Connect. Scan the second QR Code to add
your device to the APP.
Aer adding the device to the APP, you can congure the device
remotely.
5) Tap Next.
VI-H460W Network Indoor Staon User Manual
7
Figure 2-7 Guarding Vision Service Sengs
8.
Link related devices and tap Next. If the device and the indoor staon are in the same LAN, the
device will be displayed in the list. Tap the device or enter the serial No. to link.
Figure 2-8 Related Device
1) Tap the door staon in the list to link.
VI-H460W Network Indoor Staon User Manual
8
Note
If the door staon is inacve, the system will pop up the dialog to acvate the door staon.
2) Edit the network parameters of the door staon manually.
3) Tap Next.
9.
Oponal: Enable Indoor Staon and link related indoor extension devices. Tap Finish. If the
indoor extension and the indoor staon are in the same LAN, the device will be displayed in the
list. Tap the device or enter the serial No. to link.
Figure 2-9 Related Device
1) Tap the indoor extension in the list to link.
Note
If the indoor extension is inacve, the system will pop up the dialog to acvate the device.
2) Edit the network parameters of the indoor extension manually.
10.
Tap Finish to save the sengs.
2.2 Basic
Sengs
Basic sengs is required before starng using the indoor staon. It is necessary to set the indoor
staon network, room No., linked devices, device me display, and so on.
VI-H460W Network Indoor Staon User Manual
9
2.2.1 Set Indoor Staon Network Parameters
Network connecon is mandatory for the use of the indoor staon. Set the network parameters
aer acvang the indoor staon. Only when the IP address of the indoor staon is in the same
network segment as other devices, it can work properly in the same system.
Steps
Note
The default IP address of the indoor staon is 192.0.0.64.
Two ways are available for you to set IP address: DHCP, and set IP address manually.
1.
Tap Sengs → → Conguraon , and enter admin (acvaon) password.
2.
Tap
to enter the network sengs page.
Figure 2-10 Network Sengs
3.
Set the network parameters.
-
Enable DHCP, and the system can assign an IP address of the indoor staon automacally.
-
Disable the DHCP funcon, and set the IP address manually. You should set the device IP
address, the gateway, the DNS address.
VI-H460W Network Indoor Staon User Manual
10
2.2.2 Set Linked Device IP
Linked network parameters refers to the network parameters of devices (like door staon,
doorphone, main staon, center, etc.), to which the indoor staon is linked. Linked devices for the
indoor staon refers to door staon, center, main staon, and doorphone.
With the private SIP protocol, intercom can be realized only when all these devices are in the same
network segment with the indoor
staon.
With the standard SIP protocol, intercom can be realized when all these devices support the
standard SIP protocol.
Steps
Note
●
The doorphone does not support adding with the standard SIP protocol.
●
Here take main door staon network sengs as example.
1.
Tap Sengs → → Conguraon → to enter the device management page.
Note
Default admin password is the acvaon password.
2.
Tap Main Door Staon to pop up the device informaon dialog.
Figure 2-12 Device Informaon
Set the parameters of the linked door
staon. Tap to set parameters of the door staon.
VI-H460W Network Indoor Staon User Manual
11
3.
Select a device to link. Edit the following parameters.
Name
You can edit the name of the device.
Language
Select a language from the drop-down list for the device.
Network
Enable Auto Get IP Address and the system will assign IP address, subnet mask, and gateway
automacally. Or edit the IP address, subnet mask, and gateway manually.
Door Lock Parameters
Aer wire the lock with the door staon, you can set name and door opening duraon
according to your needs.
Note
Up to 2 locks can be congured.
Volume Sengs
Set microphone volume and output volume.
Call Number Sengs
The call No. should be the same as the indoor staon's room No. If press the call buon of
the door staon, you can call the indoor staon directly.
Public Password
You can use the public password to open the door staon related door lock. Select the public
password type. Enter the old password and new password and then
conrm the new
password. Tap OK to save the sengs.
Restore to Default Sengs
Restore All
All parameters will be restored to the factory sengs. The system will reboot to take
eect.
Device Reboot
Reboot the device.
2.2.3 Set Wi-Fi
Some indoor
staon support Wi-Fi connecon.
Note
Parts of models support seng Wi-Fi. For details, refers to actual product.
VI-H460W Network Indoor Staon User Manual
12
Tap Sengs → to enter the Wi-Fi Sengs page. Enable Wi-Fi. Select a Wi-Fi from the list and
enter the password of the Wi-Fi, and the indoor staon can connect to the Wi-Fi.
Figure 2-13 Wi-Fi Sengs
2.2.4 Set Indoor
Staon No.
Indoor staon No. and the indoor extension No. are numbers, which can be dialed by other devices
to call the indoor staon and the indoor extension in an intercom system. The indoor staon No., is
composed of the
oor No., room No., community No., building No. and unit No.
The indoor extension No. Should be a numeric from 1 to 5.
Up to 5 indoor extensions can be set for 1 indoor
staon.
Steps
1.
Tap
Sengs → → Conguraon → to enter the indoor staon No. sengs page.
Note
Default admin password is the acvaon password.
VI-H460W Network Indoor Staon User Manual
13
Figure 2-14 Set Indoor Staon No.
2.
Select Indoor Staon to set the room informaon, live view duraon, SIP parameters and
password.
Room
Informaon
You can set room name, oor No., and room No. Tap Advanced Sengs to set community
No., building No. and unit No. if you need.
Note
●
Community No., building No., and unit No. can be omied if there is no such informaon.
●
If there are two indoor staons that are in the same building, and should call each other,
enter the the room No. directly to call.
●
If there are two indoor
staons that are in two buildings, and should call each other, enter
the building No. and the room No. to call. For examle, call 1-405 to call room 405 in
building 1.
Live View Duraon
You can set the duraon of live view.
SIP Sengs
You can set SIP parameters. For more details, please refer to: SIP Sengs
Password Sengs
You can set unlock password and duress code.
3.
Select Indoor Extension to set the room
informaon, live view duraon, registraon password
and enable SIP 1.0 according to your needs.
VI-H460W Network Indoor Staon User Manual
14
Room Informaon
You can set room name and No. Tap Advanced to set the community No., building No., and
unit No. if you need.
When calling the indoor staon and the two devices are in the same building, you can call the
room No. directly.
If
Live View
Duraon
You can set the duraon of live view.
Registraon Password
You can create a new SIP registraon password.
Enable SIP 1.0
You can enable SIP 1.0 protocol according to your needs.
2.2.5 SIP
Sengs
Devices can communicate with each other via SIP protocol. You create set the SIP register
password, enable standard SIP and set VOIP account.
Steps
1.
Tap
Sengs → → Conguraon , and enter admin (acvaon) password.
2.
Tap SIP Sengs in Local Informaon Page.
Figure 2-15 SIP Sengs
VI-H460W Network Indoor Staon User Manual
15
3.
Set SIP registraon password.
1) Tap Registraon Password.
2) Create a new SIP registraon password and conrm the password.
3) Tap OK.
4.
Oponal: Enable Compable with SIP 1.0 Indoor Staon and the indoor staon (SIP 2.0) can be
compable with SIP 1.0 indoor staon.
5.
Oponal: Enable standard SIP and you can access to the third party devices.
1) Slide to Enable Standard SIP.
2) Tap VOIP Account
Sengs and congure the account informaon, including the user name,
the phone number, the registered user name, the password, the domain, the port No., and
the
expiraon date.
Figure 2-16 VOIP Account Sengs
Note
Up to 32 characters are allowed in the user name.
2.2.6 Add Camera
Steps
1.
Tap Sengs → → Conguraon , and enter admin (acvaon) password.
2.
Tap
to enter the device management page.
3.
Tap + to pop up the dialog box.
4.
Select a protocol to add the camera.
-
Select HIK Protocol and you can add the camera depended on the HIK protocol.
VI-H460W Network Indoor Staon User Manual
16
Enter the device name, IP address, user name and the password of the camera. Edit port No.
and channel No.
Exit the page to save the sengs.
-
Select Open Network Video Interface to add the camera.
Enter the device name, IP address, user name and the password of the camera.
Exit the page to save the sengs.
2.2.7 Zone and Alarm Sengs
Zone Sengs
You can set the zone type, alarm type and delay me and other parameters of 8 zones.
Before You Start
Tap Sengs → → Shortcut Sengs , and enable Alarm.
Steps
Note
Arming status page and zone sengs page are hidden by default. You should enable alarm funcon
rst.
1.
Tap Sengs → → Zone Sengs to enter the zone sengs page.
Figure 2-17 Zone Sengs
VI-H460W Network Indoor Staon User Manual
17
2.
Press a zone to pop up the zone eding dialogue box.
3.
Set the zone type, alarm type, status of arming status, entering delay, and exing delay.
4.
Tap OK to save the sengs.
Note
●
7 zone types are selectable: Panic Buon, Door Magnec, Smoke Detector, Acve Infrared,
Passive Infrared, Gas Detector, and Doorbell.
●
3 alarm types are selectable: 24h Alarm, Instant Alarm, and Delay Alarm.
Set the alarm type as 24h alarm, and the zone will be armed for 24h.
Set the alarm type as instant alarm, and the zone will alarm once it's triggered.
Set the alarm type as delay alarm, and you should set the entering delay
duraon and exing
delay duraon.
●
Both the entering delay
duraon and the exing delay duraon are from 30s to 60s.
●
For Gas Detector, Smoke Detector and doorbell, the alarm type is set as default 24h alarm.
The alarm type of them can not be changed.
Arming Mode Sengs
4 arming modes can be congured: stay mode, away mode, sleeping mode and custom mode.
Before You Start
Tap Sengs → → Shortcut Sengs to enable Alarm.
Steps
Note
On the home page, the arming status funcon and zone sengs funcon are hidden by default.
You should enable the alarm funcon rst.
1.
Back to the home page, tap Sengs → → Scene Sengs to enter the arming mode sengs
page.
2.
Tap Stay Mode, Away Mode, Sleeping Mode, or Custom to enter the page.
VI-H460W Network Indoor Staon User Manual
18
Figure 2-18 Arming Mode Sengs
3.
Arm the selected zone.
Note
●
Zones are congurable on the arming mode page.
●
24H alarm zone including smoke detector zone and gas detector zone will be triggered even if
they are disabled.
●
Arming mode
sengs should be congured with the sengs of arming status on the user
page of the device.
2.3 Password Sengs
2.3.1 Change Admin Password
If you forget admin (acvaon) password when entering Conguraon page, you can change it via
vericaon code from Email.
Before You Start
The Email address has been registered aer acvaon. Refers to Security Sengs .
VI-H460W Network Indoor Staon User Manual
19
Steps
1.
Tap Sengs → → Conguraon , to enter the Admin Password page.
2.
Tap Forgot Password.
3.
Download the APP of Guarding Vision and run Guarding Vision client
soware.
4.
Scan the QR code via Guarding Vision.
5.
Open the E-mail to get the
vericaon code.
6.
Tap Next, and enter the vericaon code from the E-mail.
7.
Tap Next, and create the new password.
Note
The new password is used for admin login, remote SDK login, SSH login, and Web login.
2.3.2 Security Sengs
If you forgot the admin password, you can change your password via the reserved email address or
the security
quesons.
Steps
1.
Tap
Sengs → → Conguraon , and enter the admin (acvaon) password to enter the
local informaon page. Tap → Security Sengs to enter security seng page.
2.
Tap Email Address. Enter or edit the address.
3.
Tap Security
Queson. Select quesons and enter the answers.
4.
Aer the sengs, you can reset your password via the reserved email address or via answering
quesons.
2.3.3 Modify Arm/Disarm Password
You can create and edit the arm/disarm password of the indoor staon.
Steps
1.
Tap
Sengs → → Password to enter the sengs page.
VI-H460W Network Indoor Staon User Manual
20
Figure 2-19 Arm/Disarm Password Sengs
2.
Create the indoor staon's arm/disarm password. You should enter the arm/disarm password to
enable or disable the funcon.
Figure 2-20 Create Password
VI-H460W Network Indoor Staon User Manual
21
3.
When you slide to disable Scene Password, there is no needs to enter password during scene
mode switching.
2.3.4 Modify Unlock/Duress Code
You can create and edit the duress code and unlock password of the indoor staon.
Steps
1.
Tap Sengs → → Conguraon , and enter admin (acvaon) password.
2.
Tap Password.
Figure 2-21 Unlock and Duress Code Sengs Page
3.
Tap Unlock Password or Duress Code to pop up the password sengs dialog box.
Unlock Password
Create the indoor
staon's unlock password. If the device has connected to a lock, enter the
password to unlock.
Duress Code
When you are hijacked and forced to open the door, you can enter the duress code. An alarm
will be triggered to
nofy the management center secretly.
Note
The duress code and the unlock password cannot be the same.
4.
Create a new password and conrm it.
5.
Tap OK to save the sengs.
VI-H460W Network Indoor Staon User Manual
22
2.4 Synchronize Time
Steps
1.
Tap Sengs → → Time and Date to enter the me synchronizaon page.
2.
Tap Date Format and Time Format to set the me format.
3.
Oponal: Tap Time to set me manually.
4.
Tap Sync Time.
Figure 2-22 Time Synchronizaon
1) Select the Time Zone.
2) Enable Enable NTP.
3) Set the synchronizing interval, enter the IP address/domain of NTP server and port No.
Note
●
The default unit of synchronizing interval is minute.
●
The me zone can be congured as well if the NTP is not enabled.
2.5 Sound Sengs
Set the ringtone sound, the volume, and the auto answer.
VI-H460W Network Indoor Staon User Manual
23
2.5.1 Call Sengs
You can set the ringtone, ring duraon, call forwarding me on call sengs page.
Steps
1.
Tap Sengs → to enter the call sengs page.
Figure 2-23 Call Sengs
2.
Set corresponding parameters.
Ringtone
There are 3 ringtones by default, and you can custom and import at most 4 ringtones via
Batch
Conguraon Tool or Guarding Version Client Soware.
Ringtone Duraon: The maximum duraon of indoor staon when it is called without being
accepted. Ringtone
duraon ranges from 30 s to 60 s.
Calling Duraon
The call will end automacally when the actual calling duraon is longer than the congured
one. Calling duraon ranges from 30 s to 60 s.
Call Forwarding Duraon
The ring duraon limit beyond which the call is automacally forwarded to the mobile phone
designated by the resident. Call forwarding ranges from 0 s to 20 s.
Other
Sengs
You can set the Do Not Disturb and Auto-answer funcons.
VI-H460W Network Indoor Staon User Manual
24
Auto-answer
Enable Auto-answer. Aer enabling, the call from door staon/villa door staon will be
answered by the indoor staon automacally. The caller from door staon/villa door
staon can leave voice messages. Aer the message is le, you can check it from Message
on the main page of the device.
Figure 2-24 Main Page
Note
Before enabling Auto-answer, the funcon of Leave Message needs to be enabled. Tap
Sengs → → to enter the shortcut sengs page. Eanble Leave Message and go back to
calling sengs page to enable Auto-answer.
Do Not Disturb Device
Select All and all devices will not disturb this device. Select Indoor Staon and all indoor
staon will not disturb this device.
Do Not Disturb
Set the do not disturb schedule. Select Close and the do not disturb funcon will not be
enabled. Select All Day and this device will not be disturbed all day. Select Schedule and
you can set the do not disturb
me duraon. Within the congured me, this device will
not be disturbed.
VI-H460W Network Indoor Staon User Manual
25
Note
Indoor extension does not support the ring duraon sengs, call forwarding sengs, or auto-
answer funcon.
2.5.2 Volume Sengs
Set the microphone volume, prompt sound volume, call volume, and enable touch sound.
Steps
1.
Tap
Sengs → → Volume Sengs to enter the volume sengs page.
2.
Set the microphone volume, prompt sound volume, and the call volume. You can also enable
Touch Sound to turn on the key sound.
2.6 App
Sengs
The device support adding to Guarding Vision and conguraon remotely via the client.
2.6.1 Link to the Mobile Client
Download and link to the mobile client, and you can congure the parameters of the device
remotely via mobile client.
Steps
1.
Tap
Sengs → → Conguraon and enter the admin (acvaon) password to enter the
sengs page.
2.
Tap
to enter the system maintenance page.
3.
Tap Guarding Vision Service Sengs.
4.
Enable Enable Guarding Vision Service.
5.
Edit LBS server and
Vericaon Code.
Note
●
Vericaon code is used to add the device to mobile client.
●
You can tap to enable or disable vericaon code reveal.
6.
View the service status on the page.
7.
Oponal: Scan the QR code on the screen.
Note
●
Scan the le QR code on the screen to download Guarding Vision.
●
Scan the right QR code on the screen to add the device to the mobile client.
VI-H460W Network Indoor Staon User Manual
26
2.6.2 Unlink the Account
Remove the account from the mobile client.
Steps
1.
Tap Sengs → → Conguraon , and enter the admin (acvaon) password.
2.
Tap
to enter the system maintenance page.
3.
Tap Unlink App Account, and follow the steps on the page.
2.7 System Sengs
You can format or install TF card, clear the screen, view the version informaon of the indoor
staon and reboot the system on the sengs page.
General
Sengs
Tap Sengs → to enter the general sengs page.
Figure 2-26 General Sengs Page
Time and Date
Set the displayed me and date format, current me. Tap Sync Time and enable NTP to
synchronize the device
me. You can also enable DST and set the DST start me, end me and
bias.
VI-H460W Network Indoor Staon User Manual
27
Note
●
Make sure your device is connected with the network or the NTP funcon will not available.
●
For details, see Synchronize Time .
System Language
Tap System Language to change the system language.
Note
The indoor staon supports 19 languages.
Brightness Adjustment
Tap + or - to adjust the screen brightness.
Clean Screen
Enable Clear Screen and the screen will be locked for 30s. And you can clear the screen within
the me duraon.
Note
●
Aer enabling Clear Screen funcon, press and hold the Unlock key to exit the clear screen
mode.
●
The device without unlock key will exit the clear screen mode automacally when the me is
out.
TF Card
Tap TF Card to view the TF card and you can also format the TF card.
Reboot
Tap Sengs → to enter the advanced sengs page.
Tap Reboot Device to reboot the deivce immediately.
System Maintenance
Tap Sengs → → Conguraon , and enter the admin (acvaon) password.
Tap to enter the system maintenance page.
Upgrade
Tap Upgrade to get the upgrade package online and reboot
automacally.
Restore
Restore Default Sengs
Tap Restore Default Sengs to restore parameters except network parameters and
acvaon password to factory sengs. And the system will reboot automacally.
Restore All
VI-H460W Network Indoor Staon User Manual
28
Tap Restore All to restore all parameters to factory sengs and the system will reboot
automacally.
Wizard
Tap Wizard and set the language, network, indoor staon type, device No., and select a device
according to the wizard. Refers to Quick Operaon (For Normal Device) for the details.
Preference
Tap Sengs → to enter the preference page.
Shortcut
Sengs
Enable call elevator, alarm, call management center, or leave message and the icon will be
displayed on the home page.
Zone Sengs
Note
Only when enable Alarm in the shortcut sengs, can the Zone Sengs displayed on the
Preference page.
Set the zone parameters. For details, see Zone Sengs .
Scene Sengs
Note
Only when enable Alarm in the shortcut sengs, can the Scene Sengs displayed on the
Preference page.
Set the scene parameters, including the stay mode, the away mode, the sleeping mode, or
customize the scene. For details, see Arming Mode Sengs .
2.8 Output
Sengs
You can set and control the connected output devices via the output sengs page. You can change
the relay' name, and open
duraon. You can also set to display the relay buon on the main page
or not.
Steps
1.
Tap Sengs → → Output Sengs .
Note
●
Supports up to 2 relays.
●
If no relays displayed on the page, the device may not support the funcon.
2.
Select a relay and set the parameters.
Name
VI-H460W Network Indoor Staon User Manual
29
You can change the relay's name.
Note
1 to 32 characters are allowed. Supports uppercase leers, lowercase leers, numerics, and
special characters.
Remain Open
Enable the funcon, the relay remains open.
Disabled the
funcon, and you can set the remain open duraon.
Note
●
By default, the funcon is disabled.
●
1 to 180 s are available to set.
Hide on Main Page
Enable the funcon and the relay buon will be displayed on the main page. You can control
the relay status manually on the main page.
Disabled the
funcon and the relay buon will no be displayed on the main page.
2.9 Device
Informaon
View the device informaon, including the version, model, serial No. and open source disclaimer.
Steps
1.
Tap Sengs → → Device Informaon to enter the Device Informaon page.
2.
View the device version, model, and serial No.
3.
Oponal: Tap Open Source Disclaimer to view the OSS statement.
VI-H460W Network Indoor Staon User Manual
30
Chapter 3 Other Operaons on Device
3.1 Leave Message
You can set leave message, and view the messages.
Tap Sengs → → Shortcut Sengs , and enable Leave Message.
Set Leave Message Time as 1 day, 7 days or 30 days.
Tap Message → to view the visitor messages.
Note
Up to 200 messages, noces, and capture pictures can be stored (with TF card inserted).
3.2 Call Sengs
3.2.1 Add Contact
Steps
1.
Tap Call → to enter the contact list page.
Figure 3-1 Contact List
2.
Tap to pop up the contact adding dialog.
VI-H460W Network Indoor Staon User Manual
31
3.
Enter contact informaon.
●
If you adopt private SIP protocol, enter the contact name and the room No.
●
If you adopt standard SIP protocol, enter the contact name and the phone number of VOIP
account.
4.
Tap OK to save the sengs.
Note
Up to 200 contacts can be added.
5.
Oponal: Tap the call buon or the edit buon to call and edit the contact. Hold a piece of the
contact and tap Delete to delete the contact. Or tap Clear to clear all contacts in the list.
3.2.2 Call Resident
Steps
Note
Only when the Call Management Center funcon is enabled, should the call center buon be
displayed. For details, see the conguraon guide.
1.
Tap Call → to enter the residents calling page.
Figure 3-2 Call Resident
2.
Enter the calling number.
●
When you adopt private SIP protocol, the calling number format should be x-x-x-xxx. For
example, the calling number of Community 1, Building 2, Unit 3, and Room 405 is 1-2-3-405.
VI-H460W Network Indoor Staon User Manual
32
Note
○
Community No., building No., and unit No. can be omied if there is no such informaon.
○
If there are two indoor staons that are in the same building, and should call each other,
enter the the room No. directly to call.
○
If there are two indoor
staons that are in two buildings, and should call each other, enter
the building No. and the room No. to call. For examle, call 1-405 to call room 405 in building
1.
●
When you adopt standard SIP protocol, the calling number should be the phone number of
VOIP account.
3.
Tap the call buon to start an audiovisual call.
Note
When you adopt standard SIP protocol, you should tap VoIP to make the call.
3.2.3 Call Indoor Extension/Indoor Staon
Tap Call on the main page to enter the calling page.
If you install indoor
staon and indoor extensions at home, you can call the indoor extension via
your indoor staon, and vice versa.
Enter 【0-indoor extension No.】 on the indoor
staon to start calling.
Enter 【0-0】 to call the indoor staon from the indoor extension.
3.2.4 Receive Call
The indoor staon and indoor extension can receive calls from the door staon and the main
staon.
On the call from door staon interface, there are 2 unlock buons: Unlock 1, and Unlock 2. When
you tap Unlock 1, the building gate will open by default, and when you tap Unlock 2, the door
connected to the door
staon with the secure control door unit will open.
Tap the capture buon to capture the live view picture when speaking with the door staon. And
prompts "Captured" will display on the screen.
3.2.5 View Call Logs
Steps
1.
Tap Call →
to enter the call log page.
VI-H460W Network Indoor Staon User Manual
33
Figure 3-3 Call Logs
2.
Tap a piece of call logs in the list to call back.
Note
●
Indoor extension does not support this funcon.
●
The indoor staon saves call logs from door staon, outer door staon, management center
and other indoor staons.
●
Hold a piece of call logs to open the call logs handling menu. Tap Delete to delete the piece of
call logs. Tap Clear to delete all pieces of call logs.
3.3 Live View
On the live view page, you can view the live video of added door staon and network camera.
Steps
Note
●
Make sure the network camera or door staon is well-connected.
●
Make sure the indoor extension and the indoor staon are well-connected.
1.
Tap Live View to enter the live view page.
VI-H460W Network Indoor Staon User Manual
34
Figure 3-4 Live View
2.
Tap to enter the live view page of door staon.
Note
●
On the Call from Door Staon page, there are 2 unlock buons: Unlock 1, and Unlock 2. When
you tap Unlock 1, the building gate will open by default. When you tap Unlock 2, the door
staon connected door will open.
●
On the Call from Door
Staon page, there are 1 capture buon. You can tap the buon to
capture the picture via door
staon.
3.
Tap to enter the live view page of network cameras.
3.4 Arming Mode
Sengs
4 arming modes can be congured: stay mode, away mode, sleeping mode and custom mode.
Before You Start
Tap Sengs → → Shortcut Sengs to enable Alarm.
Steps
Note
On the home page, the arming status funcon and zone sengs funcon are hidden by default.
You should enable the alarm funcon rst.
VI-H460W Network Indoor Staon User Manual
35
1.
Back to the home page, tap Sengs → → Scene Sengs to enter the arming mode sengs
page.
2.
Tap Stay Mode, Away Mode, Sleeping Mode, or Custom to enter the page.
Figure 3-5 Arming Mode Sengs
3.
Arm the selected zone.
Note
●
Zones are congurable on the arming mode page.
●
24H alarm zone including smoke detector zone and gas detector zone will be triggered even if
they are disabled.
●
Arming mode
sengs should be congured with the sengs of arming status on the user
page of the device.
3.5 Arm/Disarm
The indoor staon has four kinds of scene modes: sleeping mode, stay mode, away mode, and
custom mode. You can arm or disarm your room in each scene mode manually. The selected scene
mode will be displayed on the main page of the indoor
staon.
Note
You should create an Arm/Disarm Password rst.
VI-H460W Network Indoor Staon User Manual
36
3.5.1 Arm Room
Steps
1.
Tap
→ One-Push to Arm to enable the scene.
2.
Tap to enter the scene page.
Figure 3-6 Arm Sengs page
3.
Select Stay, Away, Sleeping or Custom.
4.
Enter the arm/disarm password to enable the scene.
5.
Tap OK.
3.5.2 Disarm Room
Steps
1.
Tap
→ One-Push to Disarm to disarm.
VI-H460W Network Indoor Staon User Manual
37
Figure 3-7 Disarm Room
2.
Enter the arm/disarm password.
3.
Tap OK.
3.6 Call Elevator
The indoor staon supports calling the elevator.
Before You Start
Enable call elevator via Guarding Vision Client Soware.
Steps
1.
Tap Sengs → → Shortcut Sengs to enable Call Elevator.
VI-H460W Network Indoor Staon User Manual
38
Figure 3-8 Call Elevator
2.
Tap on the home page of the indoor staon to start calling the elevator.
3.
When the device communicates with door staon, tap unlock icon to start calling the elevator.
3.7 Relay
Sengs
Aer you set the output parameters and display the relay buon on the main page, you can
control the relay manually.
Steps
1.
Tap
Sengs → → Output Sengs and disable Hide on Main Page funcon.
2.
Back to the main page and tap .
3.
Select a relay to enable or disable, the control device will start/stop working.
3.8
Informaon Management
You can view public noce, visitor message, alarm log and capture log on informaon management
page.
Tap Message on the home page to enter the
informaon management page. (Here takes the alarm
log page as an example.)
VI-H460W Network Indoor Staon User Manual
39
Figure 3-9 Alarm Logs
Delete a Log: Hold the item, you can delete it.
Clear Logs: Hold the item, you can clear all logs.
See Details: Hold a alarm log, you can see the alarm details.
Note
Indoor extension only supports alarm log and capture log.
VI-H460W Network Indoor Staon User Manual
40
Chapter 4 Remote Operaon via Client Soware
4.1 Device Management
Device management includes device acvaon, adding device, eding device, and deleng device,
and so on.
Aer running the Guarding Version, video intercom devices should be added to the client soware
for remote conguraon and management.
4.1.1 Add Video Intercom Devices
Steps
Note
●
You can add at most 512 indoor staons and main staons in total to the client, and add at most
16 door staons to the client.
●
For video intercom devices, you are required to create the password to acvate them before
they can be added to the
soware and work properly.
●
You can add online video intercom devices, and add them manually. Here take adding online
video intercom devices as example.
1.
Click Maintenance and Management → Device Management to enter the device management
page.
2.
Click the Device tap.
3.
Click Add to add the device to the client.
VI-H460W Network Indoor Staon User Manual
41
Figure 4-1 Add the Device
4.
Oponal: Click Online Device, the acve online devices in the same local subnet with the client
soware will be displayed on the Online Device area.
VI-H460W Network Indoor Staon User Manual
42
Note
To add online devices to the soware, you are required to change the device IP address to the
same subnet with your computer rst.
1) You can click Refresh Every 60s to refresh the informaon of the online devices.
2) Select the devices to be added from the list.
3) Click Add to Client to add the device to the client.
5.
Input the required
informaon.
Nickname
Edit a name for the device as you want.
Address
Input the device's IP address. The IP address of the device is obtained automacally in this
adding mode.
Port
Input the device port No. The default value is 8000.
User Name
Input the device user name. By default, the user name is admin.
Password
Input the device password.
6.
Oponal: You can check the checkbox Export to Group to create a group by the device name. All
the channels of the device will be imported to the corresponding group by default.
The client also provides a method to add the
oine devices. Check the checkbox Add Oine
Device, input the required informaon and the device channel number and alarm input number,
and then click Add. When the oine device comes online, the soware will connect it
automacally.
Note
●
Add Mulple Online Devices: If you want to add mulple online devices to the client soware,
click and hold Ctrl key to select mulple devices, and click Add to Client to open the device
adding dialog box. In the pop-up message box, enter the user name and password for the
devices to be added.
●
Add All the Online Devices: If you want to add all the online devices to the client soware,
click Add All and click OK in the pop-up message box. Then enter the user name and password
for the devices to be added.
4.1.2 Modify Network Informaon
Select the device from the device list, click , and then you can modify the network informaon
of the selected device.
VI-H460W Network Indoor Staon User Manual
43
Note
You should enter the admin password of the device in the Password eld of the pop-up window to
modify the parameters.
4.2 System Conguraon
You can congure the video intercom parameters accordingly.
Steps
1.
Click Maintenance and Management → System Conguraon → ACS & Video Intercom to
enter the system
conguraon page.
2.
Enter the required informaon.
Ringtone
Click ... and select the audio le from the local path for the ringtone of indoor staon.
Oponally, you can click for a tesng of the audio le.
Ringtone Duraon
Enter ringtone duraon, ranging from 15 seconds to 60 seconds.
Max. Speaking
Duraon with Indoor Staon
Enter the maximum duraon of speaking with the indoor staon, ranging from 120 seconds
to 600 seconds.
Max. Speaking Duraon with Door Staon
Enter the maximum duraon of speaking with the door staon, ranging from 90 seconds to
120 seconds.
Max. Speaking
Duraon with Access Control Device
Enter the maximum duraon of speaking with the access control device, ranging from 90
seconds to 120 seconds.
3.
Click Save to enable the
sengs.
4.
Oponal: Click Default to restore the default parameters.
4.3 Remote
Conguraon
In the device list area, select a device and click to enter the remote conguraon page.
4.3.1 System
Click System on the remote conguraon page to display the device informaon: Device
Informaon, General, Time, System Maintenance, User, RS-485, and Security.
VI-H460W Network Indoor Staon User Manual
44
Device Informaon
Click Device Informaon to enter device basic informaon page. You can view basic informaon
(the device type, and serial No.), and version informaon of the device.
Figure 4-2 Device
Informaon
General
Click General to enter device general parameters sengs page. You can view and edit the device
name and device ID, and select overwrite record
le.
Figure 4-3 General
Time
Click
Time to enter the device me sengs page.
VI-H460W Network Indoor Staon User Manual
45
Figure 4-4 Time Sengs Page
Select Time Zone, Enable NTP, Enable DST, or SDK Synchronizaon. Click Save to save the me
sengs.
●
Time Zone: Select a me zone from the drop-down list menu.
●
NTP: Click Enable NTP, and enter the server address, NTP port, and
synchronizaon interval.
Note
The default port No. is 123.
●
DST: Click Enable DST, and set the start
me, end me, and bias.
●
SDK Synchronizaon: Click Synchronizaon, and the system will synchronize the data to the SDK.
System Maintenance
Click
System Maintenance to enter the page.
VI-H460W Network Indoor Staon User Manual
46
Figure 4-5 System Maintenance
●
Reboot: Click Reboot and the system reboot dialog box pops up. Click Yes to reboot the system.
●
Restore Default Sengs: Click Restore Default Sengs to restore the default parameters. All
default
sengs, excluding network parameters, will be restored.
●
Restore All: Click Restore All to restore all parameters of device and reset the device to inacve
status.
Note
all default sengs, including network parameters, will be restored. The device will be reset to
inacvated status.
●
Import Conguraon File: Click Import Conguraon File and the import le window pops up.
Select the path of remote
conguraon les. Click Open to import the remote conguraon le.
The conguraon le is imported and the device will reboot automacally.
●
Export
Conguraon File: Click Export Conguraon File and the export le window pops up.
Select the saving path of remote conguraon les and click Save to export the conguraon
le.
●
Remote Upgrade: Click ... to select the upgrade le and click Upgrade to remote upgrade the
device. The process of remote upgrade will be displayed in the process bar.
●
Language: Select a language, and click Save to change the device system language.
VI-H460W Network Indoor Staon User Manual
47
Note
○
The device supports 19 languages: English, French, Brazilian Portuguese, Spanish, Russian,
German, Italian, Polish, Arabic, Turkish, Vietnamese, Ukrainian, Hungarian, Dutch, Romanian,
Czech, Bulgarian, Croaan, Serbian.
○
Reboong the device is required aer you change the system language.
User
Click User to enter the user informaon eding page.
Select the user to edit and click Edit to enter the user parameter page.
Figure 4-6 User Page
Note
●
The new password and conrm password should be idencal.
●
Aer eding the password of device, click refresh buon from the device list, the added device
will not be there. You should add the device again with new password to operate the remote
conguraon.
VI-H460W Network Indoor Staon User Manual
48
RS-485
Click RS485 to enter the RS-485 sengs page. You can view and edit the RS-485 parameters of the
device.
Figure 4-7 RS-485 Sengs
Note
For indoor staon and main staon, there are 3 choices for the working mode: transparent
channel, disable, and custom.
Security
Click Security to enter the page. You can enable SSH or enable HTTPS on this page.
Click Save aer conguraon.
VI-H460W Network Indoor Staon User Manual
49
Figure 4-8 Security
4.3.2 Video Intercom
Click Video Intercom on the remote conguraon page to enter the video intercom parameters
sengs: Time Parameters, Password, Zone Conguraon, IP Camera Informaon, Volume Input
and Output Conguraon, Ring, Arming Informaon, Calling Linkage, Relay, and SIP No.
Time Parameters
Steps
1.
Click Time Parameters to enter me parameters sengs page.
VI-H460W Network Indoor Staon User Manual
50
Figure 4-9 Time Parameters
2.
Congure the calling duraon, live view duraon, call forwarding me, and the ringtone
duraon.
3.
Click Save.
Note
●
Calling duraon is the maximum duraon of indoor staon when it is called without being
received. The range of maximum ring duraon varies from 30s to 60s.
●
Live view duraon is the maximum me of playing live view of the indoor staon. The range of
maximum live view
me varies from 10s to 60s.
●
Call forwarding refers to the ring
duraon limit beyond which the call is automacally
forwarded to the mobile phone designated by the resident. The range of call forwarding me
varies from 0s to 20s.
●
For indoor extension, it only requires
seng the maximum live view me.
Permission Password
Click Permission Password to enter password changing page.
VI-H460W Network Indoor Staon User Manual
51
Figure 4-10 Permission Password
For indoor
staon, you can change the arm/disarm password.
Zone Alarm
Steps
1.
Click Zone Alarm to enter the zone
sengs page.
VI-H460W Network Indoor Staon User Manual
52
Figure 4-11 Zone Alarm
2.
Select Area No.
3.
Select Zone Type from the drop-down list.
4.
Select Alarm Type from the drop-down list.
5.
Set the NO/NC status.
6.
Set Entering Delay and
Exing Delay.
7.
Click Save to enable zone sengs.
Note
●
7 zone types are supported: Emergency Switch, Door Magnec Switch, Smoke Detector, Acve
IR Detector, Passive IR Detector, Combusble Gas Detector, and DoorBell Switch.
●
3 types of alarm mode are supported: Instant Alarm, 24H Alarm, and Delay Alarm.
●
When the zone type is set to be Instant Alarm, only under arming mode, the indoor
staon
will receive alarm message when the detector is triggered. Under disarming mode, it will not
receive alarm message when the detector is triggered.
VI-H460W Network Indoor Staon User Manual
53
●
When the zone type is set to be 24H Alarm, the indoor staon will receive alarm message
when the detector is triggered no maer it is under arming mode or disarming mode.
●
When the zone type is set to be Delay Alarm, only under arming mode, the indoor staon will
receive alarm message when the detector is triggered. Under disarming mode, it will not
receive alarm message when the detector is triggered.
●
Aer seng enter delay me, if OK is pressed within the enter delay me aer the alarm, the
alarm event will not be uploaded to the management center; if OK is not pressed within the
enter delay me aer the alarm, the alarm event will be uploaded to the management center.
●
The exit delay is the me between you enable the arming mode and the arming takes eect.
Network Camera Informaon
You can add, delete and edit cameras that can be added to the video intercom products, with two
ways of geng stream: direct or URL. By exporng and imporng the added device informaon,
you can edit added devices parameters in batch.
Add Camera
Steps
1.
Click IP Camera Informaon to enter IP camera informaon page.
Figure 4-12 IP Camera
Informaon
2.
Click Add to pop up the device adding dialog box.
3.
Enter corresponding informaon (device name, IP address, port No., user name, password, etc.),
and click OK.
Note
Indoor extension does not support this funcon.
Export and Import Added Device Informaon
Steps
1.
Click Export to export the added device informaon le.
2.
Edit parameters of added devices in batch in the exported le.
3.
Click Import to pop up imporng box, and open the edited added device informaon le.
VI-H460W Network Indoor Staon User Manual
54
Figure 4-13 Import Added Device Informaon
Volume
Sengs
Steps
1.
Click Volume Input/Output to enter the
conguring the volume input or output page.
VI-H460W Network Indoor Staon User Manual
55
Figure 4-14 Volume Input or Output
2.
Slide the slider to adjust the input volume, output volume and speak volume.
3.
Click Save to enable the
sengs.
Ring Import
Steps
1.
Click Ring Import to enter the ring
conguraon page.
Figure 4-15 Ring Import
2.
Click + to add the ring, and click x to delete the imported ring.
VI-H460W Network Indoor Staon User Manual
56
Note
●
The ring to be imported should be in the wav format, and the size of the ring cannot be larger
than 300k.
●
Up to 4 rings can be added.
Arming Informaon
Click Arming Informaon to enter the conguring arming informaton page and view the arming
informaon.
Figure 4-16 Arming Informaon
Click Refresh to refresh the arming informaon.
Relay
Some indoor staon devices support this funcon.
Click Relay to enter the set relay parameters page.
Select a relay and click "
" and set the relay name and output delay me. Click Save to enable
the sengs.
Click Copy to..., and select a relay you want to copy to. Click Save to enable the sengs.
SIP No.
Sengs
Steps
1.
Click SIP No.
Sengs to enter the sengs page.
VI-H460W Network Indoor Staon User Manual
57
Figure 4-17 Extension Sengs
2.
Click Add.
VI-H460W Network Indoor Staon User Manual
58
Figure 4-18 Add SIP Info
3.
Select Device Type as Indoor Extension.
VI-H460W Network Indoor Staon User Manual
59
4.
Enter the required informaon.
Serial No.
Enter the device's serial No.. The serial No. is on the rear panel of the device (A xed-length
number with 9 digits).
IP Address
Enter the device's IP address.
Gateway
Enter the device's gateway.
Subnet Mask
Enter the device's subnet mask.
Password
Enter the device password, ranging from 8 to 16 characters in length.
No.
Enter the device No., ranging from 1 to 5.
5.
Click Save to enable the
sengs.
6.
Set SIP informaon.
Click
Congure Congure serial No., IP address, gateway, subnet mask, password and No. of
the device.
Click Delete Delete the SIP Number.
Click Clear Clear all SIP numbers.
Click Refresh Refresh SIP Informaon.
4.3.3 Network
Local Network Conguraon
Steps
1.
Click Local Network Conguraon to enter the conguring the local network parameters page.
VI-H460W Network Indoor Staon User Manual
60
Figure 4-19 Local Network Conguraon
2.
Enter the Local IP Address, IP Address Subnet Mask, Gateway, Port No. and HTTP Port No.
3.
Click Save to enable the sengs.
Note
●
The default port No. is 8000.
●
Aer eding the local network parameters of device, you should add the devices to the device
list again.
SIP Server Conguraon
Steps
1.
Click SIP Server Conguraon to enter the conguring the SIP parameters page.
VI-H460W Network Indoor Staon User Manual
61
Figure 4-20 SIP Server Conguraon
2.
Click Enable.
3.
Set the parameters according to your needs.
Note
●
Up to 32 characters are allowed in the Register User Name eld.
●
Registraon password should be 1 to 16 characters in length.
●
Up to 32 characters are allowed in the Number eld.
●
The device
locaon should contain 1 to 32 characters.
●
The
registraon period should be between 15 minutes to 99 minutes.
4.
Click Save to enable the sengs.
DNS
Sengs
The indoor staon supports 2 DNS address.
Click Advanced Sengs to enter DNS address sengs page.
Edit the IP address and click Save.
VI-H460W Network Indoor Staon User Manual
62
Figure 4-21 DNS Sengs
Congure Mobile Client Connecon
Congure Guarding Vision server parameters before viewing videos via mobile client.
Before You Start
Make sure the indoor staon connects to the network.
Steps
1.
Click Guarding Vision to enter the
conguring the sengs page.
2.
Enable Guarding Vision .
Note
●
To enable Guarding Vision service, you need to create a vericaon code or change the
vericaon code.
●
The vericaon code should be 6 to 12 leers or numbers, case sensive. You are
recommended to use a
combinaon of no less than 8 leers or numbers.
3.
Enter the Vericaon Code and conrm the vericaon code.
4.
Click OK.
5.
Enable Custom and edit Service Address.
6.
If you forget the
vericaon code, you can enable View.
7.
Click Save to enable the sengs.
8.
Oponal: Click Refresh to refresh the sengs.
Group Network
Sengs
Click Group Network Sengs to enter the group network sengs page.
VI-H460W Network Indoor Staon User Manual
63
Figure 4-22 Group Network Sengs
Device No.
Sengs
Select the device type from the drop-down list, and set the corresponding informaon.
Note
●
Device type can be set as indoor staon or indoor extension.
●
When you select indoor extension as device type, the device No. can be set from 1 to 5.
Click Save to enable the sengs.
Linked Device Network
Sengs
Enter Registraon Password and set the corresponding informaon.
Note
●
D series refers to door staon, and V series refers to villa door staon.
●
Registraon password is the password of the SIP server.
4.4 Call Indoor Staon via Client Soware
Steps
1.
On the main page, click Access Control → Video Intercom to enter the Video Intercom page.
2.
Select a resident and click
in the Call Household column to start calling the selected resident.
VI-H460W Network Indoor Staon User Manual
64
Figure 4-23 Calling Indoor Staon
3.
Aer answered, you will enter the In Call window.
●
Click
to adjust the volume of the loudspeaker.
●
Click Hang Up to hang up.
●
Click to adjust the volume of the microphone.
Note
●
One indoor staon can only connect with one client soware.
●
You can set the maximum ring duraon ranging from 15s to 60s, and the maximum speaking
duraon ranging from 120s to 600s via the Remote Conguraon of indoor staon.
4.5 Receive Call from Indoor Staon/Door Staon
Steps
1.
Select the client soware in the indoor staon or door staon page to start calling the client and
an incoming call dialog will pop up in the client
soware.
VI-H460W Network Indoor Staon User Manual
65
Figure 4-24 Incoming Call from Indoor Staon
2.
Click Answer to answer the call. Or click Hang Up to decline the call.
3.
Aer you answer the call, you will enter the In Call window.
●
Click
to adjust the volume of the loudspeaker.
●
Click Hang Up to hang up.
●
Click to adjust the volume of the microphone.
●
For door
staon, you can click to open the door remotely.
Note
●
One video intercom device can only connect with one client soware.
●
The maximum ring duraon can be set from 15s to 60s via the Remote Conguraon of the
video intercom device.
●
The maximum speaking
duraon between indoor staon and client can be set from 120s to
600s via the Remote
Conguraon of indoor staon.
●
The maximum speaking duraon between door staon and client can be set from 90s to 120s
via the Remote Conguraon of door staon.
4.6 View Live Video of Door Staon and Outer Door Staon
You can get the live view of the door staon and outer door staon in the Main View module and
control the door staon and outer door staon remotely.
In the Main View module, double-click a door
staon or outer door staon device or drag the
device to a display window to start the live view.
You can click Unlock on the menu to open the door remotely.
VI-H460W Network Indoor Staon User Manual
66
4.7 View Call Logs
You can check all the call logs, including dialed call logs, received call logs and missed call logs. You
can also directly dial via the log list and clear the logs.
Steps
1.
On the main page, click Access Control → Video Intercom to enter the Video Intercom page.
2.
Click the Call Log tab to enter the Call Log page. All the call logs will display on this page and you
can check the log
informaon, e.g., call status, start me, resident's organizaon and name,
device name and ring or speaking duraon.
Figure 4-25 Call Log
3.
Oponal: Click the icon in the Operaon column to re-dial the resident.
4.8 Release
Noce
You can create dierent types of noces and send them to the residents. Four noce types are
available, including
Adversing, Property, Alarm and Noce Informaon.
Steps
1.
On the main page, click Access Control → Video Intercom to enter the Video Intercom page.
2.
Click
Noce to enter the Release Noce page.
VI-H460W Network Indoor Staon User Manual
67
Figure 4-26 Release Noce
3.
Click Add on the le panel to create a new noce.
VI-H460W Network Indoor Staon User Manual
68
Figure 4-27 Create a Noce
4.
Edit the noce on the right panel.
1) Click ... on the Send To eld to pop up the Select Resident dialog.
2) Check the checkbox(es) to select the resident(s). Or you can check the All checkbox to select
all the added residents.
3) Click OK to save the
selecon.
4) Enter the subject on the Subject eld.
Note
Up to 63 characters are allowed in the Subject eld.
VI-H460W Network Indoor Staon User Manual
69
5) Click in the Type eld to unfold the drop-down list and select the noce type.
6) Oponal: Click View to add a local picture to the noce.
Note
Up to 6 pictures in the JPGE format can be added to one noce. And the maximum size of one
picture is 512KB.
7) Enter the noce content in the Informaon eld.
8) Oponal: You can also click Clear to clear the edited content.
Note
Up to 1023 characters are allowed in the Content eld.
5.
Click Send to send the edited noce to the selected resident(s). The sent noce informaon will
display on the le panel. You can click a noce to view the details on the right panel.
4.9 Search Video Intercom
Informaon
You can search the call logs between the Guarding Vision client soware and video intercom
devices, device unlocking logs and the sent noce informaon.
On the main page, click Access Control to enter the access control module.
In the Access Control module, click Video Intercom to enter the Video Intercom page.
4.9.1 Search Call Logs
Steps
1.
On the main page, click Access Control → Video Intercom to enter the Video Intercom page.
2.
Click Call Log to enter the Call Log page.
VI-H460W Network Indoor Staon User Manual
70
Figure 4-28 Search Call Logs
3.
Set the search condions, including call status, device type, start me and end me.
Call Status
Click to unfold the drop-down list and select the call status as Dialed, Received or Missed.
Or select All to search logs with all statuses.
Device Type
Click
to unfold the drop-down list and select the device type as Indoor Staon, Door
Staon, Outer Door Staon or Analog Indoor Staon. Or select All Devices to search logs
with all device types.
Start Time/End Time
Click
to specify the start me and end me of a me period to search the logs.
4.
Oponal: You can click Reset to reset all the congured search condions.
5.
Click Search and all the matched call logs will display on this page.
●
Check the detailed
informaon of searched call logs, such as call status, ring/speaking
duraon, device name, resident organizaon, etc.
●
Input keywords in the Search
eld to lter the desired log.
●
Click Export to export the call logs to your PC.
VI-H460W Network Indoor Staon User Manual
71
4.9.2 Search Noce
Steps
1.
On the main page, click Access Control → Video Intercom to enter the Video Intercom page.
2.
Click
Noce to enter the Noce page.
Figure 4-29 Search Noce
3.
Set the search condions, including noce type, subject, recipient, start me and end me.
Recipient
Input the recipient informaon in the Recipient eld to search the specied noce.
Subject
Input the keywords in the Subject eld to search the matched noce.
Type
Click to unfold the drop-down list and select the noce type as Adversing Informaon,
Property Informaon, Alarm Informaon or Noce Informaon. Or select All to search
noces with all types.
4.
Oponal: You can click Reset to reset all the congured search condions.
5.
Click Search and all the matched noces will display on this page.
●
Check the detailed informaon of searched noces, such as sending me, sending status, etc.
●
Input keywords in the Search
eld to lter the searching result.
VI-H460W Network Indoor Staon User Manual
72
6.
You can view and edit the noce details, check the sending failed/sent succeeded/unread users,
and resend the noce to sending failed/unread users.
7.
Oponal: Click Export to export the noces to your PC.
VI-H460W Network Indoor Staon User Manual
73
UD36151B
