INSTRUCTION MANUAL
SOLAR LED WALL LIGHT
CCT CHANGEABLE
INTRODUCTION & WARRANTY
TECHNICAL DATA
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 3 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to
incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
MODEL VT-11148CCT
SKU 24153
SOLAR PANEL
DC: 5V, 2.3W
Monocrystal
LUMENS 120 lm
BEAM ANGLE 84°
NET WEIGHT 446g
DIMENSION
190x100x220mm
BATTERY CHARGING TIME WORKING TIME
DC: 3.7V, 1800mAh, Li-Ion 6-8 Hours 10-12 Hours
Cet appareil,
ses accessoires,
piles et cordons
se recyclent
SOLAR LED WALL LIGHT
CCT CHANGEABLE
INSTALLATION INSTRUCTIONS
WARNING
1.
starting the installation.
2. Installation should be done by certified electrician.
3. The light source of this luminaire is not replace-
able; when the light source reaches its end of life
the whole luminaire shall be replaced.
This marking indicates that this
product should not be disposed
of with other household wastes.
• Screw the light fixture onto the wall.
• Remote control the lighting switch and color temperature.
• The lights are on at night and o during the day.
3
1 2
B
A
C
AUTOMATIC LIGHTING FEATURE
Ensure the switch is set to the ON position. The light will automatically illuminate at
OFF
The insulation sheet should
be pulled out before use
ON
Day White/3200K
White/5000K
OFF
Timer 4H
Timer 8H
DIM +
Timer 2H
Timer 6H
DIM AUTO
DIM
Warm White/2700K
REMOTE CONTROL SAFETY INSTRUCTIONS
• Before using this product, make sure that all parts are configured correctly
according to the instructions in the attached instruction.
• The product should not be used by persons under 5 years of age without
supervision by a parent or guardian.
• Ensure that the power batteries (included) are configured correctly and
have the appropriate parameters as specified by the manufacturer.
REMOTE INSTRUCTIONS
SOLAR PANEL MAINTENANCE & WARNING
IMPORTANT NOTES
Do not use solvents, petrol, etc. Otherwise the light will be damaged.
•
Clean the light with a dry, lint-free cloth.
•
Check the solar panel for dirt regularly. If dirt or is present remove it to guarantee
flawless function of the product.
•
Especially during the winter, keep the product free from snow and ice.
•
Keep away from the fire.
•
•
Don’t immerse in the water.
• This product contains battery type “Secondary” (rechargeable).
• Electrical and electronic equipment that has become waste is known as old equipment/device. Old devices
must not be disposed of with other household waste.
• Owners of old devices at the end of its service life must return the device by taking them to the collection points
set up by public waste disposal authorities or distributors. This return does not entail any costs for you.
• Owners of old devices have an obligation to remove accessible batteries / rechargeable batteries as well as
non-destructively removable lamps from the old device prior to return. This does not apply if old devices are
being prepared for reuse with the participation of a public law firm.
• Battery removal warning: The battery contained in this product must be removed only by professional personnel
only. The battery must never be removed by the end user, if not removed corr
ectly it could damage the battery
which could cause fire.
• Batteries removed from an old electronic device should be disposed of separately. This return of battery does
not entail any costs for you and the user is obliged to return the battery.
• Please make sure that this product is not powered on when removing the battery. Fire hazard! Avoid short-cir-
cuiting the contacts of a detached battery. Do not incinerate the battery. Please handle the battery with Caution!
• If electrical appliances or batteries are disposed of in landfills or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your health and well-being.
• The symbol of “Crossed rubbish bins “indicates that this product should not be disposed of with other house-
hold wastes and must be collected separately from unsorted municipal waste at the end of its service life.
• Please use the link below to view the online directory of the collection and return points:https://www.ear-system.
de/ear-verzeichnis/sammel-und-ruecknahmestellen
