MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
This marking indicates that this
product should not be disposed
of with other household wastes.
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read
these instructions carefully before starting the installation and keep this manual handy for future
reference. If you have any another query, please contact our dealer or local vendor from whom
you have purchased the product. They are trained and ready to serve you at the best. The warran-
ty is valid for 3 years from the date of purchase. The warranty does not apply to damage caused
by incorrect installation or abnormal wear and tear. The company gives no warranty against
damage to any surface due to incorrect removal and installation of the product. The products are
suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the war-
ranty. This product is warranted for manufacturing defects only.
LED SOLAR WALL LIGHT WITH SENSOR
INSTRUCTION MANUAL
LED SOLAR WALL LIGHT WITH SENSOR
COLOR
CHANGING
3-IN-1
Lumens
Model VT-11025CCT
SKU 24096, 24097
300lm
Power 2.5W
LEDs SMD2835 x 24PCS
Battery DC 3.7V, Lithium, 18650, 1200mAh, 4.44Wh
Solar Panel Mono, DC 0.7W, 5V
Color Temeperatur CCT (6000K, 4000K, 3000K)
Sensor <6m, 120°, PIR Sensor
Beam Angle 120° x 60°
Charging Time 5 Hours Strong Sunshine to Fully Charge
Working Time 50 Hours Max.
Installation Height
2-4 Mtrs
Body Type ABS+PC
Dimension 75.6*137.6*94.8mm
Lighting Area 30m
2
2 Optional
Work Modes
Mode A: 100% Detected + 3% Dim
Mode B: 100% Detected + O
TECHNICAL DATA
WARRRANTY
1. This is a solar-powered lamp. Please install it in a location that receives sucient sunlight.
2. The lamp charges via solar energy during the day and automatically lights up at night.
3. The lamp will continue to charge during the day even when switched o.
4. Lighting duration may vary based on sunlight exposure and selected working mode.
5. Equipped with overcharge and over-discharge protection for enhanced safety and dura-
bility.
6. The lamp contains a built-in rechargeable battery, which is replaceable.
7. Do not disassemble the lamp unless you are a qualified professional.
8. Do not dispose of the battery with household waste, as it may cause an explosion risk.
Lamp automatically lights up at night, it will turn to full brightness when motion is
detected within 6m, then dims to 3% brightness aer 10 seconds of no motion.
Lamp automatically lights up at night, it will turn to full brightness when motion is
detected within 6m, then turns o aer 10 seconds of no motion.
ON/OFF/SWITCH WORK MODE
TWO OPTIONAL WORKING MODES
SWITCH CCT
* Press the button 1st time, lamp flashes once and enters Mode A.
* Press the button 2nd time, lamp flashes twice and enters Mode B.
* Press the button 3rd time, lamp flashes three times and then turns o.
* Press and hold the button for 3 seconds to switch the CCT.
* Color temperature can be switched in any work mode.
* CCT Switch includes a memory function.
MODE A
MODE B
120° 120°120°
120° 120°120°
4 TRANSFORMABLE SHAPES
1
2
3
4
PACKAGE CONTENT
INSTALLATION INSTRUCTIONS
INSTALLATION A: WALL MOUNT WITH SCREWS
1. Please use the measure card to mark the holes.
2. Drill 2 holes with a diameter of 6mm and a depth of 30mm.
3. Fix the expansion plugs into the holes, fix the screws into the expansion plugs,
allow the screws to protrude slightly by about 3-5mm.
4. Rotate the solar panel and led module separately to set required shape.
5. Press the button on the lamp to turn it on and select required work mode and CCT.
6. Hang the lamp on the screws and fix it in place.
1*Lamp
2*Screws 1*User Manual 1*Measure Card2*Cable Ties
49mm
φ6mm
Depth
30mm
Ø6mm
49mm
Solar Panel
180° Rotatable
LED Module
180° Rotatable
1
3
5 6
4
2
INSTALLATION B: FIX WITH CABLE TIES
BATTERY REPLACEMENT INSTRUCTIONS
1. Select a suitable installation location according to the size of the cable ties.
2. Pass the two cable ties through the holes in the direction of the arrows.
3. Lock the cable ties.
L=500mm
5-140mm
1
3
2
1. Remove the Rear Cover Screws
2. Disconnect the Battery Terminal &
Remove the Cover
3. Replace the Battery
V-TAC UK LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT
SUPPORT@VTACEXPORTS.COM V-TAC, 5A TUNGSTEN PARK, DOWNS ROAD, WITNEY, OXFORDSHIRE, OX29 0AX
V-TAC WEST EUROPE LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
[email protected] FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC WEST EUROPE LTD. GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
• This product contains battery type "Secondary" (rechargeable).
• Electrical and electronic equipment that has become waste is known as old equip-
ment/device. Old devices must not be disposed of with other household waste.
• Owners of old devices at the end of its service life must return the device by taking them
to the collection points set up by public waste disposal authorities or distributors. This
return does not entail any costs for you.
• Owners of old devices have an obligation to remove accessible batteries / rechargeable
batteries as well as non-destructively removable lamps from the old device prior to return.
This does not apply if old devices are being prepared for reuse with the participation of a
public law firm.
• Battery removal warning: The battery contained in this product must be removed only by
professional personnel only. The battery must never be removed by the end user, if not
removed correctly it could damage the battery which could cause fire.
• Batteries removed from an old electronic device should be disposed of separately. This
return of battery does not entail any costs for you and the user is obliged to return the
battery.
• Please make sure that this product is not powered on when removing the battery. Fire
hazard! Avoid short-circuiting the contacts of a detached battery. Do not incinerate the
battery. Please handle the battery with Caution!
• If electrical appliances or batteries are disposed of in landfills or dumps, hazardous sub-
stances can leak into the groundwater and get into the food chain, damaging your health
and well-being.
• The symbol of "Crossed rubbish bins "indicates that this product should not be disposed
of with other household wastes and must be collected separately from unsorted municipal
waste at the end of its service life.
• Please use the link below to view the online directory of the collection and return
points:https://www.ear-system.de/ear-verzeichnis/sammel-und-ruecknahmestellen
IMPORTANT NOTES
SOLAR PANEL MAINTENANCE & WARNING
• Do not use solvents, petrol, etc. Otherwise the light will be damaged.
• Clean the light with a dry, lint-free cloth.
• Check the solar panel for dirt regularly. If dirt or is present remove it to
guarantee flawless function of the product.
• Especially during the winter, keep the product free from snow and ice.
• Confirm installation direction is correct (solar panel should be at top)
• Confirm no objects blocking the solar panel to receive sunlight
• Keep away from the fire.
• Don’t immerse in the water
