Operang Instrucons for the
HT-Air MkII
™
Wireless
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operaon is subject to the
following two condions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operaon.
Any Changes or modicaons not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital Device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protecon against harmful interference
in a residenal installaon.
This equipment generates uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instrucons, may cause harmful
interference to radio communicaons. However, there is no guarantee that
the interference will not occur in a parcular installaon. If this equipment
does cause harmful interference to radio or television recepon, which can be
determined by turning the equipment o and on, the user is encouraged to try
and correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separaon between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This Equipment complies with FCC radiaon exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance of 20cm between the radiator (wireless transmier)
and your body.
HT-Air MkII™ Wireless
REL have acquired a sterling reputaon within the industry
for delivering great sounding, reliable wireless delivery
of the REL experience. The freedom this confers on our
customers produces several benets; it permits ultra-high
performance without the cumbersome tether of a cable,
permits careful placement without being limited by the
length of a cable and can lead to a beer sounding, less
cluered experience.
HT-Air MkII™ Wireless is our latest method of distribung
5.8 Ghz wireless and delivers .1/LFE or stereo Low Level
performance similar to our more expensive wireless
systems quickly, reliably and without the thin, non-dynamic
sound many wireless systems deliver. In part, this is
achieved by eliminang the oen very slow delivery
methods oered by o-the-shelf Bluetooth and wi-
based systems.
We, at REL, are commied to delivering the highest quality
listening experience for our customers; HT-Air MkII™ is yet
another way in which we show we are listening to you.
REL HT-Air MkII™ Wireless Transmier
1 Inputs: Use both for stereo two channel inputs, or
Right/LFE only for home theater.
2 Pair Switch: Used to pair REL HT-Air MkII™ Wireless
transmier with it’s receiver.
3 LED: Indicates whether the REL HT-Air MkII™ Wireless
transmier is paired with the receiver or not.
4 Power Adapter Socket: DC input socket that accepts a
detachable power adapter.
HT-Air MkII™ Panel Connecon Legend
2
3
41
REL HT-Air MkII™ Wireless Receiver
1 OUTPUTS: Used to connect as stereo out or the low LFE
input of a REL subwoofer.
2 Pair Switch: Used to pair REL HT-Air MkII™ Wireless
receiver with it’s transmier.
3 LED: Indicates whether the REL HT-Air MkII™ Wireless
receiver is paired with the transmier or not.
4 Power Adapter Socket: DC input socket that accepts a
detachable power adapter.
1 2
3
4
The REL HT-Air MkII™ Wireless is intended to be used with
the Serie HT or similar REL sub bass system. The transmier
and receiver will require power from an AC wall plug using
the power adapter cables supplied.
It is not possible to use the HT-Air MkII™ Wireless connecon
and a direct connecon simultaneously. Using both wired
and wireless connecons simultaneously could result in
damage and voids all warranes.
Always switch your system o before disconnecng any wires.
With the HT-Air MkII™, there are two basic ways to connect
and setup. The rst is a single channel input from the sub
out of a theater or power speaker system. In this case a
single RCA cable is needed from the source to the transmier.
Connecng Up
Theater connecon
– Connect RCA cable from Sub Out of theater processor to
LFE input of the HT-Air MkII™ transmier.
Then use the second RCA from the LFE output of the
HT-Air MkII™ receiver to the LFE input of the REL.
The second is a stereo input from a stereo preamp or powered
speaker system. You will need to use two RCA cables.
Powered Speaker connecon
– Connect RCA from L/R output of the source to the inputs
of the HT-Air MkII™.
Then use two more RCA cabels and connect from the
L/R outputs of the HT-Air MkII™ receiver to the inputs of
the REL.
Now that the HT-Air MkII™ Wireless transmier and
receiver are connected to your system, the unit will need
to be paired.
1 Make sure that the transmier AC to DC wall plug supply is
connected to an AC outlet, and that the barrel connector
is connected to the transmier.
2 Make sure that the receiver AC to DC wall plug supply is
connected to an AC outlet, and that the barrel connector
is connected to the receiver.
3 Make sure that the sub is plugged into an AC outlet using
the supplied AC cable and that the sub is turned on.
Power switch is located on the rear panel.
4 At this point the transmier and receiver should nd
each other and pair together. This will be indicated by
the “Pair” LEDs on both the transmier and control
panel staying lit (no ashing).
5 In the event that the transmier and receiver do not
automacally pair, simply exercise the momentary “Pair”
buon on the receiver unl the LED ashes.
Pairing
6 Then exercise the “Pair’ buon on the transmier.
7 When correctly paired, the LEDs on both units will stop
ashing and stay solid within 5 seconds.
Pairing is persistent and will not be lost when unplugged.
Care
The units are best maintained by using a damp (not wet)
cloth to remove dust. Do not place objects, such as drinks
on top of your REL Air transmier. Never use a dry cloth on
this nish to prevent scratches.
Technical
The HT-Air MkII™ Wireless transmier provides true REL
theater experience. This occurs with virtually zero delay
and a complete absence of compression.
Status LED Indicator
Paired Connuously on
Looking for Pair Blinks twice per second
Standby Blinks once per second
Input Connectors: Stereo RCA, LFE input uses Right
channel input only
Input Impedance: 10k ohms
Wireless Output Power: 0 dBm
Wireless Eecve Distance: 40 (12 meters) with clear line of site
Mains Input Voltage: 5V DC, 5.5mm circular connector,
posive center
Power Consumpon: 600 mWas
Dimensions (WHD): 2.75 x 2.06 x 3.25 in.,
(70 x 53 x 82.3 mm)
Finish: Black
Supplied Accessories X2 Power adapters
X2 RCA Cable: 2 meter in length
In the interest of product improvement, REL Acouscs Limited
reserves the right to alter these specicaons without noce.
HT-Air MkII™ Wireless Transmier
Notes
REL Acouscs Limited
North Road, Bridgend industrial Estate . Bridgend, CF31 3TP . United Kingdom
Telephone: +44 (0)1 656 768 777 . Fax: +44 (0) 1 656 766 093
Web: www.rel.net
