BRK.Z BRACKET MOUNTING
INSTALLATION GUIDE
INSTRUCTIONS
1. Z-brackets are designed to fit into the rear channel
on supported speakers to enable easy wall
mounting.
2. After choosing an installation area (securing
brackets to wall studs is recommended), level and
mark both bracket heights, so they are level to
each other.
Figure 1: BRK.Z Brackets
3. Secure the brackets to the wall.
Figure 2: Level Brackets and Secure
4. Hang speaker on the wall and ensure that it is level
and at the appropriate height.
Figure 3: Secure Brackets
5. If the speaker is at an acceptable height/level,
then wire and hang the speaker and attach the
grille to complete the installation.
Figure 4: Hang Speaker and Level
Figure 5: Attach Grille
©2024 James by Sonance. All rights reserved. James by Sonance is a registered trademark of Dana Innovations. Due to continuous product improvement, all features and
specifications are subject to change without notice. For the latest Sonance product specification information visit our website: www.sonance.com
James by Sonance • 2185 Park Place • Minden, NV 89423 USA • 775.461.7500 10.18.2024
(Soundbar Shown)
