Xindun HP PRO-T Smart Hybrid Inverter for Sale 1Kva 1.5Kva 2Kva 3Kva 5Kva 7Kva 8Kva

Product's Documents

Below are documents related to this product, you can read online or download:

HP PRO-T Inverter User Manual - (English) Read Online | Download pdf

Main document Specification Questions and answers Relateds Products

HP PRO-T Inverter User Manual

This is the main product document for model HP PRO-T.

The file format is pdf, 14 pages, you can download this manual here .

Give Review

Oﬃcial Website

SOLAR1

SOLAR2

N L N L

AC INPUT AC OUTPUT

SOLAR1

SOLAR2

N L N L

AC INPUT AC OUTPUT

SOLAR1

SOLAR2

N L N L

AC INPUT AC OUTPUT

12345678

File type: PDF

File name: 6642183_hp-pro-t.pdf

File size: 12.55 MB

File Language: English

Pages: 14

Author: Xindun

Published: 2026-04-02

Updated: 2026-04-02

Source: Directly manufacturer

Download: Save file

Specifications

Brand: Xindun

Model: HP PRO-T

Rated Power: 1000W

Peak Power（20ms: 3000VA

Battery Voltage: 12VDC

MPPT tracking voltage range: 15V-80VDC

Rated recommended operating voltage of PV array: 15V-30VDC

Max PV Input Voltage Voc At the lowest temperature: 120VDC

PV Array Maximum Power: 840W

Rated AC input voltage: 220VAC / 230VAC / 240VAC

AC Input Voltage Range: 170VAC~280VAC （UPS mode）/ 120VAC~280VAC（INV mode）

AC Input Frequency Range: 45Hz~55Hz（50Hz，55Hz~65Hz（60Hz

Output VoltageBattery/PV Mode: 220VAC±2% / 230VAC±2% / 240VAC±2%

Output FrequencyBattery/PV Mode: 50Hz±0.5 or 60Hz±0.5

Output VoltageAC Mode: Follow input

Output FrequencyAC Mode: Follow input

Customize battery: Charging and discharging parameters of different types of batteries can be customized according to user requirements charging and discharging parameters of different types of batteries can be set through the operation panel

Maximum charging current mains + PV: 120A

Max PV Charging Current: 60A

Max AC Charging Current: 60A

Charging method: Three-stage constant current, constant voltage, floating charge

Battery low voltage protection: Factory default: 10.5VSingle battery voltage

Battery over voltage alarm: Constant charge voltage+0.8VSingle battery voltage

Battery over voltage protection: Factory default: 17VSingle battery voltage

Battery over voltage recovery voltage: Battery overvoltage protection value-1VSingle battery voltage

Overload power protection: Automatic protection battery mode, circuit breaker or insurance AC mode

Product Size（L*W*Hmm）: 355x272x91.5

Package Size（L*W*Hmm）: 443x350x187

Installation Method: Wall-Mounted

Output WaveBattery/PV Mode: Pure Sine Wave

EfficiencyAC Mode: >99%

Output waveform distortion Battery/PV Mode: ≤3%Linear load

No load lossBattery Mode: ≤1% rated power

No load lossAC Mode: ≤0.5% rated powercharger does not work in AC mode

Temperature protection: >90°CShut down output

Working Mode: Mains priority/PV priority/Battery priorityCan be set

Transfer Time: ≤10ms

Storage temperature: -15℃~60℃

Noise: ≤55dB

Humidity: 0%~95% No condensation
