Refrigerator
User manual
Free Standing Appliance
Untitled-1 1 2023-04-07 5:17:55
English2
Contents
Contents
Safety information 3
Important safety symbols and precautions 6
Severe warning signs for transportation and site 7
Critical installation warnings 7
Installation cautions 11
Critical usage warnings 12
Usage cautions 17
Cleaning cautions 19
Critical disposal warnings 21
Additional tips for proper usage 22
Saving Energy Tips 24
This appliance is intended to be used in household and similar applications such as 25
Instructions about the WEEE 25
Installation 26
Refrigerator at a glance 26
Step-by-step installation 28
Operations 33
Main panel 33
SmartThings (applicable models only) 37
Special features 40
Maintenance 45
Handle and care 45
Cleaning 47
Replacement 48
Troubleshooting 49
General 49
Do you hear abnormal sounds from the refrigerator? 51
SmartThings (applicable models only) 53
Open Source Announcement 54
Untitled-1 2 2023-04-07 5:17:55
English 3
Safety information
• Before using your new Samsung Refrigerator, please read
this manual thoroughly to ensure that you know how to
operate the features and functions that your new appliance
offers safely and efciently.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory, or
mental capabilities, or those who lack experience and
knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person
responsible for their safety.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without
supervision.
• Warnings and Important Safety Instructions in this manual
do not cover all possible conditions and situations that
may occur.
It is your responsibility to use common sense, caution,
and care when installing, maintaining, and operating your
appliance.
Safety information
Untitled-1 3 2023-04-07 5:17:55
Safety information
English4
Safety information
• Because these following operating instructions cover
various models, the characteristics of your refrigerator
may differ slightly from those described in this manual and
not all warning signs may be applicable. If you have any
questions or concerns, contact your nearest service center
or nd help and information online at www.samsung.com.
• R-600a or R-134a is used as a refrigerant. Check the
compressor label on the rear of the appliance or the rating
label inside the fridge to see which refrigerant is used for
your refrigerator. When this product contains ammable
gas (Refrigerant R-600a), contact your local authority in
regard to safe disposal of this product.
• In order to avoid the creation of a ammable gas-air
mixture if a leak in the refrigerating circuit occurs, the size
of the room in which the appliance may be sited depends
on the amount of refrigerant used.
• Never start up an appliance showing any signs of damage.
If in doubt, consult your dealer. The room must be 1 m³
in size for every 8 g of R-600a refrigerant inside the
appliance. The amount of refrigerant in your particular
appliance is shown on the identication plate inside the
appliance.
• Refrigerant squirting out of the pipes could ignite or cause
an eye injury. When refrigerant leaks from the pipe, avoid
any naked ames and move anything ammable away
from the product and ventilate the room immediately.
- Failing to do so may result in re or explosion.
• It is hazardous for anyone other than an Authorized
Service Person to service this appliance.
Untitled-1 4 2023-04-07 5:17:55
English 5
Safety information
• Do not store explosive substances such as aerosol cans
with a ammable propellant in this appliance.
• To avoid contamination of food, please respect the
following instructions:
- Opening the door for long periods can cause a
signicant increase of the temperature in the
compartments of the appliance.
- Clean regularly surfaces that can come in contact with
food and accessible drainage systems.
- Clean water tanks if they have not been used for 48 h;
ush the water system connected to a water supply if
water has not been drawn for 5 days.
- Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
- Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making icecream and
making ice cubes.
- One-, two- and three-star compartments are not suitable
for the freezing of fresh food.
- If the refrigerating appliance is left empty for long
periods, switch off, defrost, clean, dry, and leave the
door open to prevent mould developing within the
appliance.
• It is hazardous for anyone other than an Authorized
Service Person to service this appliance. In Queensland
– the authorized Service Person MUST hold a Gas Work
Authorization or Licence for hydrocarbon refrigerants, to
carry out Servicing or repairs which involve the removal of
covers. (For Australia only)
Untitled-1 5 2023-04-07 5:17:55
Safety information
English6
Safety information
WARNING; Risk of re / ammable materials
Important safety symbols and precautions
Please follow all safety instructions in this manual. This
manual uses the following safety symbols.
WARNING
Hazards or unsafe practices that may result in severe personal
injury, property damage, and/or death.
CAUTION
Hazards or unsafe practices that may result in severe personal
injury and/or property damage.
NOTE
Useful information that helps users understand or benet
from the refrigerator.
These warning signs are here to prevent injury to you and
others.
Please follow them carefully.
After reading this section, keep it in a safe place for future
reference.
Untitled-1 6 2023-04-07 5:17:55
English 7
Safety information
Severe warning signs for transportation and site
WARNING
• When transporting and installing the appliance, care should
be taken to ensure that no parts of the refrigerating circuit
are damaged.
- Refrigerant leaking from the pipe work could ignite
or cause an eye injury. If a leak is detected, avoid any
naked ames or potential sources of ignition and air
the room in which the appliance is standing for several
minutes.
- This appliance contains a small amount of isobutane
refrigerant (R-600a), a natural gas with high
environmental compatibility that is, however, also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no parts
of the refrigerating circuit are damaged.
Critical installation warnings
WARNING
• Do not install the refrigerator in a damp location or place
where it may come in contact with water.
- Deteriorated insulation on electrical parts may cause an
electric shock or re.
• Do not place this refrigerator in direct sunlight or expose it
to the heat from stoves, room heaters, or other appliances.
Untitled-1 7 2023-04-07 5:17:55
Safety information
English8
Safety information
• Do not plug several appliances into the same multiple
power strip. The refrigerator should always be plugged
into its own individual electrical outlet which has a voltage
rating that matches the voltage listed on the refrigerator’s
rating plate.
- This provides the best performance and also prevents
overloading of house wiring circuits, which could cause
a re hazard from overheated wires.
• If the wall socket is loose, do not insert the power plug.
- There is a risk of electric shock of re.
• Do not use a power cord that has cracks or abrasion
damage along its length or at either end.
• Do not bend the power cord excessively or place heavy
objects on it.
• Do not pull or excessively bend the power cord.
• Do not twist or tie the power cord.
• Do not hook the power cord over a metal object, place a
heavy object on the power cord, insert the power cord
between objects, or push the power cord into the space
behind the appliance.
• When moving the refrigerator, be careful not to roll over or
damage the power cord.
- This may result in an electric shock or re.
• Never unplug your refrigerator by pulling on the power
cord. Always grip the plug rmly and pull straight out from
the outlet.
- Damage to the cord may cause a short-circuit, re, and/
or electric shock.
• Do not store explosive substances such as aerosol cans
with a ammable propellant in this appliance.
Untitled-1 8 2023-04-07 5:17:55
English 9
Safety information
• Do not install this appliance near a heater or inammable
material.
• Do not install this appliance in a location where gas may
leak.
- This may result in an electric shock or re.
• This refrigerator must be properly located and installed in
accordance with the instructions in this manual before you
use it.
• Connect the power plug in the proper position with the
cord hanging down.
- If you connect the power plug upside down, the wire
can get cut off and cause a re or electric shock.
• Make sure that the power plug is not crushed or damaged
by the back of the refrigerator.
• Keep the packing materials out of reach of children.
- There is a risk of death from suffocation if a child puts
the packing materials on his or her head.
• The appliance must be positioned so that the plug is
accessible after installation.
- Failing to do so may result in an electric shock or re
due to electric leakage.
• Do not install this appliance in a humid, oily or dusty
location, in a location exposed to direct sunlight and water
(rain drops).
- Deteriorated insulation of electrical parts may cause an
electric shock or re.
• If any dust or water is in the refrigerator, pull out power
plug and contact your Samsung Electronics service center.
- Otherwise there is a risk of re.
Untitled-1 9 2023-04-07 5:17:55
Safety information
English10
Safety information
• Do not stand on top of the appliance or place objects (such
as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the appliance.
- This may result in an electric shock, re, problems with
the product, or injury.
• You need to remove all the protective plastic lm before
you initially plug the product in.
• Children should be supervised to ensure that they do not
play with the snap rings used for door adjustment or the
water tube clips.
- There is risk of death by suffocation if a child swallows
a snap ring or water tube clip. Keep the snap rings and
water tube clips out of children’s reach.
• The refrigerator must be safely grounded.
- Always make sure that you have grounded the
refrigerator before attempting to investigate or repair
any part of the appliance. Power leakages can cause
severe electric shock.
• Never use gas pipes, telephone lines, or other potential
lightning attractors as an electrical ground.
- You must ground the refrigerator to prevent any power
leakages or electric shocks caused by current leakage
from the refrigerator.
- This may result in an electric shock, re, explosion, or
problems with the product.
• Plug the power plug into the wall socket rmly. Do not use
a damaged power plug, damaged power cord, or loose wall
socket.
- This may result in an electric shock or re.
Untitled-1 10 2023-04-07 5:17:55
English 11
Safety information
• If the power cord is damaged, have it replaced
immediately by the manufacturer or one of its service
agents.
• The fuse on the refrigerator must be changed by a
qualied technician or service company.
- Failing to do so may result in an electric shock or
personal injury.
• When positioning the appliance, ensure the supply cord is
not trapped or damaged.
• Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
Installation cautions
CAUTION
• Allow sufcient space around the refrigerator and install it
on a at surface.
- Keep the ventilation space in the appliance enclosure or
mounting structure clear of obstructions.
• Allow the appliance to stand for 2 hours before loading
foods after installation and turning on.
• We strongly recommend you have a qualied technician or
service company install the refrigerator.
- Failing to do so may result in an electric shock, re,
explosion, problems with the product, or injury.
• Overload on any one door may fell the refrigerator,
causing physical injury.
Untitled-1 11 2023-04-07 5:17:55
Safety information
English12
Safety information
Critical usage warnings
WARNING
• Do not insert the power plug into a wall socket with wet
hands.
- This may result in an electric shock.
• Do not store articles on the top of the appliance.
- When you open or close the door, the articles may fall
and cause personal injury and/or material damage.
• Do not insert hands, feet or metal objects (such as
chopsticks, etc.) into the bottom or the back of the
refrigerator.
- This may result in an electric shock or injury.
- Any sharp edges may cause a personal injury.
• Do not touch the inside walls of the freezer or products
stored in the freezer with wet hands.
- This may cause frostbite.
• Do not put a container lled with water on the refrigerator.
- If spilled, there is a risk of re or electric shock.
• Do not keep volatile or ammable objects or substances
(benzene, thinner, propane gas, alcohol, ether, LP gas, and
other such products) in the refrigerator.
- This refrigerator is for storing food only.
- This may result in re or explosion.
• Children should be supervised to ensure that they do not
play with the appliance.
- Keep ngers out of “pinch point” areas. Clearances
between the doors and cabinet are necessarily small. Be
careful when you open the doors if children are in the
area.
Untitled-1 12 2023-04-07 5:17:55
English 13
Safety information
• Do not let children hang on the door or door bins. A
serious injury may occur.
• Do not let children go inside the refrigerator. They could
become trapped.
• Do not insert your hands into the bottom area under the
appliance.
- Any sharp edges may cause personal injury.
• Do not store pharmaceutical products, scientic materials,
or temperature sensitive products in the refrigerator.
- Products that require strict temperature controls must
not be stored in the refrigerator.
• Do not place or use electrical appliance inside
the refrigerator/freezer, unless they are of a type
recommended by the manufacturer.
• If you smell pharmaceutical or smoke, pull out power plug
immediately and contact your Samsung Electronics service
center.
• If any dust or water is in Refrigerator, pull out power plug
and contact your Samsung Electronics service center.
- Otherwise there is a risk of re.
• Do not let children step on a drawer.
- The drawer may break and cause them to slip.
• Do not leave the doors of the refrigerator open while the
refrigerator is unattended and do not let children enter
inside the refrigerator.
• Do not allow babies or children go inside the drawer.
- It can cause death from suffocation by entrapment or
personal injury.
Untitled-1 13 2023-04-07 5:17:56
Safety information
English14
Safety information
• Do not overll the refrigerator with food.
- When you open the door, an item may fall out and
cause personal injury or material damage.
• Do not spray volatile material such as insecticide onto the
surface of the appliance.
- As well as being harmful to humans, it may also result
in an electric shock, re, or problems with the product.
• Do not use or place any substances sensitive to
temperature such as ammable sprays, ammable objects,
dry ice, medicine, or chemicals near or inside of the
refrigerator.
• Do not use a hair dryer to dry the inside of the
refrigerator. Do not place a lighted candle in the
refrigerator for removing bad odours.
- This may result in an electric shock or re.
• Do not stand on top of the appliance or place objects (such
as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the appliance. This may
result in an electric shock, re, problems with the product,
or injury. Do not put a container lled with water on the
appliance.
- If spilled, there is a risk of re or electric shock.
• Do not use mechanical devices or any other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Never stare directly at the UV LED lamp for long periods of
time.
- This may result in eye strain due to the ultraviolet rays.
Untitled-1 14 2023-04-07 5:17:56
English 15
Safety information
• Do not put fridge shelf in upside down. Shelf stopper could
not work.
- It may cause a personal injury because of glass shelf
drop.
• If a gas leak is detected, avoid any naked ames or
potential sources of ignition, and air the room in which the
appliance is standing for several minutes.
- Do not touch the appliance or power cord.
- Do not use a ventilating fan.
- A spark may result in explosion or re.
• Use only the LED Lamps provided by the manufacturer or
its service agents.
• Bottles should be stored tightly together so that they do
not fall out.
• This product is intended only for the storage of food in a
domestic environment.
• Do not attempt to repair, disassemble, or modify the
refrigerator yourself.
- Unauthorized modications can cause safety problems.
To reverse an unauthorized modication, we will charge
the full cost of parts and labor.
• Do not use any fuse (such as cooper, steel wire, etc.) other
than a standard fuse.
• If your refrigerator needs to be repaired or reinstalled,
contact your nearest service center.
- Failing to do so may result in an electric shock, re,
problems with the product, or injury.
• If the interior or exterior LED lamp has gone out, contact
your nearest service center.
Untitled-1 15 2023-04-07 5:17:56
Safety information
English16
Safety information
• If the refrigerator emits a burning smell or smoke, unplug
the refrigerator immediately and contact your Samsung
Electronics service center.
- Failing to do so may result in an electric or re hazards.
• Pull the power plug out of the socket before changing the
interior lamps of the refrigerator.
- Otherwise, there is a risk of electric shock.
• If you experience difculty changing a non-LED light,
contact a Samsung service center.
• If the product is equipped with LED lamps, do not
disassemble the Lamp Covers and LED lamps yourself.
- Contact a Samsung service center.
• Plug the power plug into the wall socket rmly.
• Do not use a damaged power plug, damaged power cord or
loose wall socket.
- This may result in an electric shock or re.
Untitled-1 16 2023-04-07 5:17:56
English 17
Safety information
Usage cautions
CAUTION
• Do not re-freeze frozen foods that have thawed
completely. Do not place carbonated or zzy drinks in
the freezer compartment. Do not put bottles or glass
containers in the freezer.
- When the contents freeze, the glass may break and
cause personal injury.
• To get the best performance from the product:
- Do not place food too close to the vents at the rear of
the refrigerator as this can obstruct free air circulation
in the refrigerator compartment.
- Wrap food up properly or place it in airtight containers
before putting it into the refrigerator.
- Please observe maximum storage times and expiration
dates of frozen goods.
• Do not place glass or bottles or carbonated beverages into
the freezer.
- The container may freeze and break, and this may
result in injury.
• Do not place carbonated or zzy drinks in the freezer
compartment. Do not put bottles or glass containers in the
freezer.
- When the contents freeze, the glass may break and
cause personal injury and property damage.
Untitled-1 17 2023-04-07 5:17:56
Safety information
English18
Safety information
• Service Warranty and Modication.
- Any changes or modications performed by a 3rd
party on this nished appliance are not covered
under Samsung warranty service, nor is Samsung
responsible for safety issues that result from 3rd party
modications.
• Do not block the air vents inside the refrigerator.
- If the air vents are blocked, especially with a plastic
bag, the refrigerator can be over cooled. If a cooling
period lasts too long, the water lter may break and
cause water leakage.
• Wipe excess moisture from the inside and leave the doors
open.
- Otherwise, odor and mold may develop.
• If the refrigerator is disconnected from the power supply,
you should wait for at least ve minutes before plugging it
back in.
• When the refrigerator got wet by water, pull out the power
plug and contact your Samsung Electronics service center.
• Do not strike or apply excessive force to any glass surface.
- Broken glass may result in a personal injury and/or
property damage.
• Be careful that your ngers are not caught in.
• The lamps in the freezer and refrigerator can be turned off
if the doors of the freezer and refrigerator are left open
for 2 seconds or longer.
- The lamps will turn back on when the doors are closed
and opened again.
Untitled-1 18 2023-04-07 5:17:56
English 19
Safety information
• If the refrigerator is ooded, make sure to contact your
nearest service center.
- There is a risk of electric shock or re.
• Do not keep vegetable oil in your refrigerator’s door bins.
The oil can solidify, making it foul-tasting and difcult to
use. In addition, the open container can leak and the leaked
oil can cause the door bin to crack. After opening an oil
container, it is best to keep the container in a cool and
shaded place such as a cupboard or pantry.
- Examples of vegetable oil: olive oil, corn oil, grape-seed
oil, etc.
Cleaning cautions
CAUTION
• Do not spray water directly on the inside or outside the
refrigerator.
- There is a risk of re or electric shock.
• Do not use a hair dryer to dry the inside of the
refrigerator.
• Do not place a lighted candle in the refrigerator to remove
bad odors.
- This may result in an electric shock or re.
• Do not spray cleaning products directly on the display.
- Printed letters on the display may come off.
• If any foreign substance such as water has entered the
appliance, unplug the power plug and contact your nearest
service center.
- Failing to do so may result in an electric shock or re.
Untitled-1 19 2023-04-07 5:17:56
Safety information
English20
Safety information
• Use a clean, dry cloth to remove any foreign matter or dust
from the power plug blades. Do not use a wet or damp
cloth when cleaning the plug.
- Otherwise, there is a risk of re or electric shock.
• Do not clean the appliance by spraying water directly onto
it.
• Do not use benzene, thinner, or Clorox, Chloride for
cleaning.
- They may damage the surface of the appliance and may
cause a re.
• Before cleaning or performing maintenance, unplug the
appliance from the wall socket.
- Failing to do so may result in an electric shock or re.
• Use a clean sponge or soft cloth and a mild detergent in
warm water to clean the refrigerator.
• Do not use abrasive or harsh cleansers such as window
sprays, scouring cleansers, ammable uids, muriatic
acid, cleaning waxes, concentrated detergents, bleaches,
or cleansers containing petroleum products on exterior
surfaces (doors and cabinet), plastic parts, door and interior
liners, and gaskets.
- These can scratch or damage the material.
• Do not clean glass shelves or covers with warm water
when they are cold. Glass shelves and covers may break if
exposed to sudden temperature changes or impacts such
as bumping or dropping.
Untitled-1 20 2023-04-07 5:17:56
English 21
Safety information
Critical disposal warnings
WARNING
• Please dispose of the packaging material from this product
in an environmentally friendly manner.
• Ensure that none of the pipes on the back of the
refrigerator are damaged prior to disposal.
• R-600a or R-134a is used as a refrigerant. Check the
compressor label on the rear of the appliance or the rating
label inside the fridge to see which refrigerant is used for
your refrigerator. If this refrigerator contains ammable
gas (Refrigerant R-600a), contact your local authority in
regard to safe disposal of this product.
• When disposing of this refrigerator, remove the door/
door seals and door latch so that small children or
animals cannot become trapped inside. Children should
be supervised to ensure that they do not play with the
appliance. If trapped inside, a child may get hurt or
suffocate to death.
• Cyclopentane is used in the insulation. The gases in the
insulation material require a special disposal procedure.
Please contact your local authorities in regard to the
environmentally safe disposal of this product.
• Keep all packaging materials well out of the reach of
children, as packaging materials can be dangerous to
children.
- If a child places a bag over his or her head, the child
could suffocate.
Untitled-1 21 2023-04-07 5:17:56
Safety information
English22
Safety information
• DANGER: Risk of child entrapment. Before you throw away
your old refrigerator or freezer:
- Take off the doors.
- Leave the shelves in place so that children may not
easily climb inside.
Additional tips for proper usage
• In the event of a power failure, call the local ofce of your
electric company and ask how long the failure is going to
last.
- Most power failures that are corrected in an hour or two
will not affect your refrigerator temperatures. However,
you should minimize the number of door openings
while the power is off.
- Should the power failure last more than 24 hours,
remove and discard all frozen food.
• The refrigerator might not operate consistently (frozen
contents can thaw or temperatures can become too
warm in the frozen food compartment) if sited for an
extended period of time in a location where ambient air
temperatures are constantly below the temperatures for
which the appliance is designed.
• In case of particular foods, keeping it under refrigeration
can have a bad effect on preservation due to its properties.
• Your appliance is frost free, which means there is no need
to manually defrost your appliance. This will be carried out
automatically.
Untitled-1 22 2023-04-07 5:17:56
English 23
Safety information
• Temperature rise during defrosting complies with ISO
requirements. If you want to prevent an undue rise in the
temperature of frozen food while the appliance defrosts,
wrap the frozen food in several layers of newspaper.
• Do not re-freeze frozen foods that have thawed
completely.
• The temperature of two star section (sections) or
compartment (compartments) which have two star symbol
( ) is slightly higher than other freezer compartment
(compartments).
The two star section (sections) or compartment
(compartments) is (are) based on the instruction and/or the
condition as delivered.
Untitled-1 23 2023-04-07 5:17:56
Safety information
English24
Safety information
Saving Energy Tips
• Install the appliance in a cool, dry room with adequate
ventilation. Ensure that it is not exposed to direct sunlight
and never put it near a direct source of heat (a radiator, for
example).
• Not to block any vents and grilles is recommended for
energy efciency.
• Allow warm food to cool down before placing it in the
appliance.
• Put frozen food in the refrigerator to thaw. You can then
use the low temperatures of the frozen products to cool
food in the refrigerator.
• Do not keep the door of the refrigerator open for too long
when putting food in or taking food out. The shorter the
time the door is open, the less frost build-up you’ll have in
the freezer.
• It is recommended to install the refrigerator with clearance
to the back and sides. This will help reduce power
consumption and keep your energy bills lower.
• For the most efcient use of energy, please keep the all
inner ttings such as baskets, drawers, shelves on the
position supplied by manufacturer.
Untitled-1 24 2023-04-07 5:17:56
English 25
Safety information
This appliance is intended to be used in household
and similar applications such as
• staff kitchen areas in shops, ofces and other working
environments;
• farm houses and by clients in hotels, motels and other
residential type environments;
• bed and breakfast type environments;
• catering and similar non-retail applications.
Instructions about the WEEE
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the
product and its electronic accessories (e.g. charger, headset, USB cable)
should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate these items
from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased
this product, or their local government ofce, for details of where and
how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
For information on Samsung’s environmental commitments
and product regulatory obligations, e.g. REACH, WEEE or
Batteries, visit our sustainability page available via
www.samsung.com
(For products sold in European countries and in the UK only)
Untitled-1 25 2023-04-07 5:17:56
English26
Installation
Follow these instructions carefully to ensure a proper installation of this refrigerator and to
prevent accidents before using it.
WARNING
• Use the refrigerator only for its intended purpose as described in this manual.
• Any servicing must be performed by a qualied technician.
• Dispose of the product packaging material in compliance with local regulations.
Refrigerator at a glance
NOTE
The actual image and provided parts of the refrigerator may differ, depending on the
model and the country.
Auto Ice Maker model Dispenser model
11
02
01
04
10
13
07
12
03
09
08
05
12
13
10
05
07
06
09
08
03
Installation
Untitled-1 26 2023-04-07 5:17:56
English 27
Installation
01 Auto Ice Maker *** 02 Ice bucket ***
03 Freezer door bin 04 Optimal Fresh Zone *
05 Main panel (Analogue - Freezer) * 06 Water tank for Dispenser **
07 Main panel (Digital - Fridge) * 08 Main panel (Analogue - Fridge) *
09 Fridge door bin 10 Multi Tray *
11 Water tank for Auto Ice Maker *** 12 Active Fresh Filter *
13 Vegetable drawer
* applicable models only
** Dispenser models only
*** Auto Ice Maker models only
To secure more room for storage in the freezer compartment
Remove one or more optional accessories such as shelf (or shelves), twist ice maker(s),
ice storage bin(s), ice bucket(s) and their supports, all of which can be removed manually
without a tool.
• These optional accessories do not affect thermal and mechanical performance.
• A declared storage volume of the freezer is based on the nonexistence of those optional
accessories.
• For best energy efciency, make sure all shelves and drawers are placed in their
original position.
Load limit indicator (applicable models only)
The refrigerator has a load limit indicator
on the top right side of the freezer
compartment.
CAUTION
• Do not put or keep food items over the
load limit indicator. Otherwise, energy
efciency may be affected.
Untitled-1 27 2023-04-07 5:17:57
Installation
English28
Installation
Step-by-step installation
STEP 1 Select a site
Site requirements:
• Solid, level surface without carpeting or ooring that may obstruct ventilation
• Away from direct sunlight
• Adequate room for opening and closing the door
• Away from a heat source
• Room for maintenance and servicing
• Temperature range: between 10 °C and 43 °C
Clearance
See the pictures and table below for space requirements for installation.
B
C
A
Model RT31 RT35 RT38
Depth "A" 647 709 672
Width “B” 600 600 700
Height “C” 1715 1715 1715
(unit : mm)
Model RT42 RT47
Depth "A" 672 717
Width “B” 700 700
Height “C” 1785 1825
(unit : mm)
Untitled-1 28 2023-04-07 5:17:57
English 29
Installation
03
01
03
05
02
04
RT31 RT35 RT38
01 more than 50mm recommended
02 115° (Freezer) / 115° (Fridge)
03 At least 50 mm
04 850 850 1006
05 1201 1263 1311
(unit : mm)
RT42 RT47
01 more than 50 mm recommended
02 115° (Freezer) / 115° (Fridge)
03 At least 50 mm
04 1006 1006
05 1311 1356
(unit : mm)
Untitled-1 29 2023-04-07 5:17:57
Installation
English30
Installation
STEP 2 Spacing (applicable models only)
1. Open the door and locate the provided
spacers (x2).
2. Unpack both spacers and attach them
to the rear of the refrigerator as shown.
They help ventilate air to the rear wall
and save power consumption.
STEP 3 Flooring
• The surface to install the refrigerator
must support a fully loaded refrigerator
or approximately 90 kg.
• To protect the oor, put a large piece
of cardboard on each leg of the
refrigerator.
• Once the refrigerator is in its nal
position, do not move it unless
necessary to protect the oor. If you
have to, use thick paper or cloth such as
old carpets along the movement path.
Untitled-1 30 2023-04-07 5:17:57
English 31
Installation
STEP 4 Adjust the levelling feet
CAUTION
• When installed, the refrigerator must be levelled on a at, solid oor. Not levelling the
refrigerator can cause damage to the refrigerator or physical injury.
• Levelling must be performed with the refrigerator empty. Make sure no food items are
inside the refrigerator.
• For safety reasons, adjust the front a little higher than the rear. Level the refrigerator
using special screws (levellers) on the front legs. Use a at-head screwdriver to turn the
levellers.
Level the refrigerator by manually
adjusting the levelling feet. Turn the
levelling feet clockwise to lower the
position or turn anticlockwise to raise. For
safety reasons, adjust the front side a little
higher than the rear side.
A
Leave the feet at 41 mm (A) from the oor
as shown.
Untitled-1 31 2023-04-07 5:17:57
Installation
English32
Installation
STEP 5 Initial settings
By completing the following steps, the refrigerator should be fully functioning.
1. Plug the power cord into the wall socket to turn the refrigerator on.
2. Open the door, and check if the interior light lights up.
3. Set the temperature to the coldest, and wait for about an hour. Then, the freezer will be
slightly chilled, and the motor will run smoothly.
4. Wait until the refrigerator reaches the set temperature. Now the refrigerator is ready
for use.
STEP 6 Final check
When the installation is complete, conrm that:
• The refrigerator is plugged into an electrical outlet and grounded properly.
• The refrigerator is installed on a at, level surface with a reasonable clearance from the
wall or the cabinet.
• The refrigerator is level and is sitting rmly on the oor.
• The door opens and closes freely, and the interior light turns on automatically when you
open the door.
Untitled-1 32 2023-04-07 5:17:58
English 33
Operations
Main panel
Fridge - Digital
Type A Type B Type C Type D
01 02 01 02 01
03
04
02 01
03
04
02
01 Fridge 02 Power Cool / Ice On/Off (3 sec) *
03 Network connection indicator * 04 AI Energy Mode *
* applicable models only
NOTE
The temperature in the refrigerator may rise if you open the door frequently or put a large
amount of food into the refrigerator. If this happens, the all LED that display temperature
blinks until the refrigerator returns to the specied temperature settings. If the blinking
continues for an extended time, contact a local Samsung service center for technical
assistance.
• While the temperature display is blinking, an alarm may occur. To stop the alarm, tap
any button on the display.
• If you open the door while the temperature display is blinking, the internal light blinks
for about a minute.
01 Fridge
Fridge
Press Fridge to select the desired fridge temperature.
CAUTION
• Do not set the fridge temperature to the lowest in winter and
highest in summer. It may cause problems with the cooling
performance.
Operations
Untitled-1 33 2023-04-07 5:17:58
Operations
English34
Operations
02 Power Cool / Ice On/Off (3 sec)
Power Cool
Press Power Cool to activate or deactivate Power Cool.
• Power Cool speeds up the cooling process at maximum fan speed.
The fridge keeps running at full speed for several hours and then
returns to the previous temperature.
• When Power Cool activates, the Power Cool icon ( ) turns on, and
the refrigerator will speed up the cooling process for you.
• To cool large amounts of food completely, activate Power Cool at
least 24 hours in advance.
NOTE
Using Power Cool increases power consumption. Make sure you turn
it off and return to the previous temperature if you do not intend to
use it.
Ice On/Off
(Type B, C only)
Press and hold Power Cool for 3 seconds to turn the Auto Ice Maker
on or off.
• When the Auto Ice Maker is on, the ice maker icon ( ) turns on.
The Auto Ice Maker is set to on by default.
• We recommend disabling the function in the following cases:
- The ice bucket is already full of ice.
- You want to decrease power consumption.
03 Network connection (applicable models only)
You can control and monitor your refrigerator on the SmartThings app. For more
information, see the SmartThings (applicable models only) section.
NOTE
If the refrigerator is not connected to the SmartThings app, the Wi-Fi ( ) icon blinks to
alert you when opening the door. If you see the blinking Wi-Fi ( ) icon, we recommend
that you connect your refrigerator to the SmartThings app.
04 AI Energy Mode (applicable models only)
• The icon appears when the AI Energy Mode is operating. You may turn on or off the
AI Energy Mode in the SmartThings app. (applicable models only)
Turning the Wi-Fi on or off (applicable models only)
To turn the Wi-Fi on or off, press and hold Fridge for 10 seconds. The Wi-Fi ( ) icon shows
the status of the Wi- as shown below.
• Wi-Fi Off: The Wi-Fi ( ) icon blinks for 5 seconds and then turns off.
• Wi-Fi On: The Wi-Fi ( ) icon blinks for 5 seconds and then turns on for 5 seconds.
NOTE
• You must turn on the Wi-Fi to connect the refrigerator to the SmartThings app.
• For more information, see the SmartThings (applicable models only) section.
Untitled-1 34 2023-04-07 5:17:59
English 35
Operations
Fridge - Analogue
• Turn the dial left and right to set the
desired temperature.
• Turn the dial left to raise, and turn it
right to lower the temperature.
NOTE
To ensure optimal performance, we
recommend setting the temperature to .
CAUTION
• Do not set the fridge temperature higher (1-2) when the room temperature is lower
than 10 °C, and lower (4-6) when the temperature is higher than 35 °C. It may cause
problems with the cooling performance.
Untitled-1 35 2023-04-07 5:17:59
Operations
English36
Operations
Freezer - Analogue
• To increase the temperature, slide the
temperature control to the left.
• To decrease the temperature, slide the
temperature control to the right. In
winter, slide the temperature control to
the right-most end.
To make ice in summer (above 35 °C), set
the freezer temperature to the centre.
NOTE
If the Auto Ice maker is not making enough
ice, slide the temperature control to the
right.
CAUTION
• To prevent system failure or food spoiling, do not set the temperature to the right-most
end (maximum) in summer (above 35 °C).
• Do not store glass bottles containing liquid in the freezer. Glass bottles will crack or
break into pieces when the liquid freezes.
Untitled-1 36 2023-04-07 5:17:59
English 37
Operations
SmartThings (applicable models only)
Installation
Visit the Google Play Store, Galaxy Apps, or Apple App Store and search for “SmartThings”.
Download and install the SmartThings app provided by Samsung Electronics to your smart
device.
NOTE
• The supporting software version of the SmartThings app is subject to change according
to the OS supporting policy the manufacturer provides. In addition, as for the
SmartThings app or the functions that the app supports, the new application update
policy on the existing OS version can be suspended due to usability or security reasons.
• The SmartThings app is subject to change without notice to improve usability or
performance. As the mobile phone OS version is updated every year, the SmartThings is
also updated continually according to the latest OS. If you have enquiries regarding the
items mentioned above, please contact us at [email protected]
• Recommended encryption systems include WPA/TKIP and WPA2/AES. Any newer or
non-standard Wi-Fi authentication protocols are not supported.
• Wireless networks may be affected by the surrounding wireless communication
environment.
• If your Internet service provider has registered the MAC address of your PC or modem
for identication, your Samsung Smart Refrigerator may fail to connect to the Internet.
If this happens, contact your Internet service provider for technical assistance.
• The rewall settings of your network system may prevent your Samsung Smart
Refrigerator from accessing the Internet. Contact your Internet service provider for
technical assistance. If this symptom continues, contact a local Samsung service centre
or retailer.
• To congure the wireless access point (AP) settings, see the user manual of the AP
Router.
• Samsung Smart Refrigerators support both Wi-Fi 2.4 GHz with IEEE 802.11 b/g/n and
Soft-AP protocols. (IEEE 802.11 n is recommended.)
• Unauthorized Wi-Fi wireless routers may fail to connect to applicable Samsung Smart
Refrigerators.
Untitled-1 37 2023-04-07 5:17:59
Operations
English38
Operations
Samsung account
You are required to register your Samsung account to use the app. If you don’t have a
Samsung account, follow the app’s on-screen instructions to create a free Samsung account.
Getting started
Turn on the device you want to connect, open the SmartThings app on your phone, and
then follow the instructions below.
If a pop-up appears saying that a new device has been found, tap ADD NOW.
If a pop-up doesn't appear, tap the + button, and then select the device you want to
connect from the list of available devices.
If your device isn't in the list of available devices, tap Supported Devices, select the device
type (Refrigerator), and then select the specic device model.
Follow the instructions in the app to set up your device. Once setup is complete, your
refrigerator will appear as a "card" on your Devices screen.
Refrigerator app
Integrated control
You can monitor and control your refrigerator at home and on the go.
• Tap the refrigerator icon on the SmartThings Dashboard or tap the Devices icon at the
bottom of the Dashboard, and then tap the refrigerator "card" to open the Refrigerator
page.
• Check the operation status or notications related to your refrigerator, and then change
options or settings if necessary.
NOTE
Some options or settings of the refrigerator may not be available for remote control.
Untitled-1 38 2023-04-07 5:18:00
English 39
Operations
Category Item Description
Monitoring
Fridge temperature
Displays the current temperature setting of the
fridge.
Energy monitoring
Checks the accumulated power consumption of
the refrigerator for the last 180 days.
Functions Power Cool
You can turn Power Cool on or off, and check
the current settings.
Alarms
Abnormally high
temperature
This alarm is triggered when the fridge has
abnormally high temperatures.
Door opening
This alarm is triggered if the fridge or freezer
door is open for more than 2 minutes.
AI Energy Mode
(applicable
models only)
You can turn on or off the AI Energy Mode under the Energy menu in
the SmartThings app.
You can check the status of the AI Energy Mode on the SmartThings
app.
On some models, the icon appears on the main panel to indicate
that AI Energy Mode is operating. (applicable models only)
Turning on the AI Energy Mode decreases energy consumption, but it
may also reduce the cooling performance.
Untitled-1 39 2023-04-07 5:18:00
Operations
English40
Operations
Special features
The actual image and special functions of your refrigerator may differ, depending on the
model and the country.
Ice making (applicable models only)
Twist ice maker (applicable models only)
A
1. Open the freezer door, and slide open
the ice tray.
2. Fill the tray with water up to the
maximum level (A) marked on the inner
rear of the tray.
3. Slide the tray back into position.
NOTE
The ice making time depends on your
temperature settings.
NOTE
• Make sure the ice cube storage bin is in
place under the ice tray.
• To dispense the ice cubes, turn the ice
tray handle to the right to empty half of
the ice cubes into the bin. Then, turn it
to the left to empty the other half.
• To take out the bin, pull it forward.
• Put the twist ice maker on the freezer
shelf if it does not t under the shelf.
Untitled-1 40 2023-04-07 5:18:00
English 41
Operations
Water tank for Auto Ice Maker (applicable models only)
To ll the water tank (applicable models only)
For rst-time use, clean the inner side of
the water tank and dry well.
1. Hold the handle with both hands, and
then pull forward to remove it.
A B
2. Open the lid (A) or the entire cover (B)
and ll the tank with water.
CAUTION
Do not exceed the max line. Water
overows.
3. Reinsert the water tank and t it into
the dispenser mechanism. Make sure the
lid on the cover faces the front.
CAUTION
• Make sure the water tank ts into the shelf. Otherwise, the water tank may not operate
properly.
• Fill the tank only with potable water such as mineral or puried water. Do not use other
liquids.
• Full water tank is heavy and therefore, use caution when moving a lled tank. Physical
injury may occur if the tank is dropped.
• Do not try to disassemble the internal pump yourself. If the internal pump is damaged
or disconnected from the water tank, the Auto Ice Maker does not operate.
NOTE
If you are not using the Auto Ice Maker, you can remove the water tank for more storage
space.
Untitled-1 41 2023-04-07 5:18:00
Operations
English42
Operations
Auto Ice Maker (applicable models only)
The refrigerator has an ice maker that automatically dispenses ice.
For rst-time use
• Fill the water tank and let the ice maker
make ice for 1-2 days.
• Discard the rst 1-2 buckets of ice to
remove impurities in the water supply
system.
Diagnosis
If the Auto Ice Maker does not make ice,
remove the ice bucket and press the Test
button to check if the Auto Ice Maker
operates properly.
CAUTION
• When the Auto Ice Maker is on, the refrigerator will keep making ice even when you
remove the ice bucket. If you are not going to use the Auto Ice Maker, make sure to turn
it off.
• When the refrigerator recovers power after a power failure, the ice bucket may
contain a mix of melted and jammed ice cubes, which can prevent the ice maker from
working properly. To prevent this, make sure to empty the ice bucket before using the
refrigerator.
• Do not put ngers or any objects into the ice maker. This can cause physical injury or
property damage.
• Due to sublimation, ice stored in the freezer for a long time gets smaller and then forms
large ice chunks. Therefore, if it will be a long time before you use ice, turn the ice
maker off.
NOTE
If you are not using the Auto Ice Maker, you can remove the ice bucket for more storage
space.
Untitled-1 42 2023-04-07 5:18:00
English 43
Operations
Optimal Fresh Zone (applicable models only)
Optimal Fresh Zone is an independently controlled compartment where you can store
different items at the optimal temperature.
Hold the bottom part of the of the Optimal
Fresh Zone and pull to store or take out
items.
You can adjust the temperature of the
Optimal Fresh Zone.
• To increase the temperature, slide the
temperature control to the right.
• To decrease the temperature, slide the
temperature control to the left.
Water dispenser (applicable models only)
With the water dispenser, you can dispense water without opening the fridge door. The
water tank must be lled with potable water before use.
To ll the water tank with potable water
Open the door and locate the water tank that is located in the door bin area.
1. Hold both sides of the water tank and
lift to remove.
Untitled-1 43 2023-04-07 5:18:01
Operations
English44
Operations
2. Fill the water tank with potable water.
Remove the cap and pour water.
NOTE
Before using the water tank for the rst
time, clean the water tank thoroughly,
especially the nozzle. Regularly clean the
water tank and the nozzle.
3. Reinsert the water tank and close the
door. Make sure the water outlet of the
water tank faces forward.
1"/
06 "00
&0-"+0"/
4. Put a water glass under the water outlet
of the dispenser, and gently push the
dispenser lever to dispense water.
CAUTION
• The water dispenser is designed to dispense potable water. Fill the water tank only with
potable water. Do not ll with any other liquids.
• Do not ll the water tank excessively, which causes an overow.
• Do not try to ll the water tank without removing it from the door.
• Make sure that water tank is seated properly.
• Do not use the refrigerator without the water tank. This may reduce performance and
efciency.
• To prevent water bouncing, make sure the glass is in line with the dispenser lever.
NOTE
To secure more room, you can use the water tank to store food. In this case, remove the lid
of the tank.
Untitled-1 44 2023-04-07 5:18:01
English 45
Maintenance
Handle and care
Shelves (fridge/freezer)
To remove the shelf, hold it with both
hands and lift it to release it from the rear
hook. Then, tilt it on one side and pull it
out.
Before you insert the shelf, check the shape
of the back of the shelf. Then, insert the
shelf in the reverse order of removal.
CAUTION
• The shelf must be inserted correctly.
Do not insert it upside down or back to
front.
• Shelves are heavy, therefore be careful
when you handle them.
Vegetable drawer
Gently lift up the front of the drawer and
slide out.
Maintenance
Untitled-1 45 2023-04-07 5:18:02
Maintenance
English46
Maintenance
Vegetable shelf
Hold the vegetable shelf with both hands
and lift it to release it from the rear hook.
Then, tilt it on one side and pull it out.
Door bins
Slightly lift up and pull out the door bins.
CAUTION
To prevent accidents, empty the door bins
before removing them.
Untitled-1 46 2023-04-07 5:18:02
English 47
Maintenance
Cleaning
WARNING
• Do not use benzene, thinner, or home/car detergent such as Clorox™ for cleaning
purposes. They may damage the surface of the refrigerator and cause a re.
• Do not spray water onto the refrigerator. This may cause electric shock.
Regularly use a dry cloth to remove all foreign substances such as dust or water from the
power plug terminals and contact points.
1. Unplug the power cord of the refrigerator.
2. Use a moistened soft lint-free cloth or paper towel to clean the refrigerator’s interior
and exterior.
3. When done, use a dry cloth or paper towel to dry well.
4. Plug in the power cord of the refrigerator to turn the refrigerator on.
NOTE
If you have removed any removable parts such as shelves for cleaning, refer to the overall
layout in the Refrigerator at a glance section to make sure you have reinserted correctly.
Untitled-1 47 2023-04-07 5:18:02
Maintenance
English48
Maintenance
Replacement
Deodorizer lter (applicable models only)
A
While holding the top and bottom sides
of the lter case, unlock the lter case to
reveal the deodorizer lter (A). Replace the
lter, and then reinsert the case.
Lamps and active fresh lter
Neither lamps nor the active fresh lter is user-serviceable. Do not attempt to replace them
yourself. To replace them, contact a local Samsung service centre.
WARNING
• The lamps are not user-serviceable. Do not attempt to replace a lamp yourself. This can
cause electric shock.
Lamp (Light Source)
This product contains a light source of energy efciency class <G>.
The lamp(s) and/or control gear(s) are not user-serviceable. To replace the lamp(s) and/or
control gear(s) in the product, contact a local Samsung service centre.
For detailed instructions on replacing lamp(s) or control gear(s) in your product, visit the
Samsung website (http://www.samsung.com), go to Support > Support home, and then
enter the model name.
For detailed instructions on dismantling lamp(s) and/or control gear(s), simply follow the
replacement instruction reached as described above.
Untitled-1 48 2023-04-07 5:18:02
English 49
Troubleshooting
Before calling for service, review the checkpoints below. Any service calls regarding
normal situations (No Defect Cases) will be charged to users.
General
Temperature
Symptom Possible causes Solution
Fridge/freezer does
not operate.
Fridge/freezer
temperature is
warm.
• Power cord is not plugged in
properly.
• Properly plug in the power
cord.
• Temperature control is not
set correctly.
• Set the temperature lower.
• Refrigerator is located near
a heat source or direct
sunlight.
• Keep the refrigerator away
from direct sunlight or a
heat source.
• Not enough clearance
between refrigerator and
sides/rear.
• We recommend that the gap
between the refrigerator and
nearby walls (or cabinets) is
more than 50 mm.
• Vacation mode is activated. • Deactivate vacation mode.
• The refrigerator is
overloaded. Food is blocking
the refrigerator vents.
• Do not overload the
refrigerator. Do not allow
food to block ventilation.
Fridge/freezer is
over-cooling.
• Temperature control is not
set correctly.
• Set the temperature higher.
Interior wall is hot.
• Refrigerator has heat-proof
piping in the interior wall.
• To prevent condensation
from forming, the
refrigerator has heat-proof
piping in the front corners.
If the ambient temperature
rises, this equipment may
not work effectively. This is
not a system failure.
Troubleshooting
Untitled-1 49 2023-04-07 5:18:02
Troubleshooting
English50
Troubleshooting
Odours
Symptom Possible causes Solution
Refrigerator has
odours.
• Spoiled food.
• Clean the refrigerator and
remove any spoiled food.
• Food with strong odours.
• Make sure strong smelling
food is wrapped airtight.
Condensation
Symptom Possible causes Solution
Condensation forms
on the interior
walls.
• If door is left open, moisture
enters the refrigerator.
• Remove the moisture and do
not open the door for a long
time.
• Food with high moisture
content.
• Make sure food is wrapped
airtight.
Water/Ice (Auto Ice Maker models only)
Symptom Possible causes Solution
The ice maker does
not produce ice.
• The freezer room is not cold
enough.
• Make sure the cold air outlet
is not clogged.
• The wire connector of the
ice maker is not connected
properly.
• Make sure the wire
connector from the wire
housing is connected
properly.
• The water line owing to the
Ice maker is bent or kinked.
• Make sure the water line in
the rear of the refrigerator is
not bent or kinked.
Untitled-1 50 2023-04-07 5:18:02
English 51
Troubleshooting
Do you hear abnormal sounds from the refrigerator?
Before calling for service, review the checkpoints below. Any service calls related to
normal sounds will be charged to the user.
These sounds are normal.
• When starting or ending an operation, the refrigerator may make sounds similar to a
car engine igniting. As the operation stabilizes, the sounds will decrease.
Clicking!
or Chirping!
Buzzing!
• While the fan is operating, these sounds may occur. When the refrigerator reaches the
set temperature, no fan sound will occur.
SSSRRR!
Whir!
• During a defrost cycle, water may drip on the defrost heater, causing sizzling sounds.
HiSS!
Untitled-1 51 2023-04-07 5:18:03
Troubleshooting
English52
Troubleshooting
• As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing
bubbling sounds.
Bubbling!
• As the refrigerator temperature increases or decreases, plastic parts contract and
expand, creating knocking noises. These noises occur during the defrosting cycle or
when electronic parts are working.
Cracking!
• For ice maker models: When the water valve opens to ll the ice maker, buzzing sounds
may occur.
• Because of pressure equalizing when opening and closing the refrigerator door,
whooshing sounds may occur.
Untitled-1 52 2023-04-07 5:18:03
English 53
Troubleshooting
SmartThings (applicable models only)
Symptom Action
Could not nd
“SmartThings” in the
app market.
• The supporting software version of the SmartThings app is
subject to change according to the OS supporting policy the
manufacturer provides. In addition, as for the SmartThings
app or the functions that the app supports, the new
application update policy on the existing OS version can be
suspended due to usability or security reasons.
The SmartThings app
fails to operate.
• The SmartThings app is available for applicable models
only.
• The old Samsung Smart Refrigerator app cannot connect
with Samsung Smart Home models.
The SmartThings
app is installed but is
not connected to my
refrigerator.
• You must log into your Samsung account to use the app.
• Make sure that your router is operating normally.
• If the Wi-Fi icon on the refrigerator’s display is off, this
indicates that no network connection has been established
yet. In this case, use the SmartThings app to connect and
register your refrigerator to the access point (AP) of your
house.
Could not log into the
app.
• You must log into your Samsung account to use the app.
• If you don’t have a Samsung account, follow the app’s
onscreen instructions to create one.
An error message
appears when I
try to register my
refrigerator.
• Easy Connection may fail due to the distance from your
access point (AP) or electrical interference from the
surrounding environment. Wait a moment and try again.
The SmartThings app is
successfully connected
to my refrigerator but
does not run.
• Exit and restart the SmartThings app, or disconnect and
reconnect the router.
• Power off the refrigerator, and then power it on again after
1 minute.
The Wi-Fi icon is
blinking. ( )
• Connect your refrigerator with the SmartThings app before
use. When the connection is made successfully, the indicator
stops blinking.
- If you fail to make connection or don’t want to use the
app, press and hold the Fridge button for 10 seconds.
The indicator stops blinking.
Untitled-1 53 2023-04-07 5:18:03
English54
Open Source Announcement
The software included in this product contains open source software.
The following URL http://opensource.samsung.com/opensource/SMART_TP1_0/seq/0 leads
to open source license information as related to this product.
Untitled-1 54 2023-04-07 5:18:03
Memo
Untitled-1 55 2023-04-07 5:18:03
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the
SAMSUNG customer care centre.
Country Contact Center Web Site
AUSTRALIA
1300 362 603 (Other)
1300 425 299 (HHP)
www.samsung.com/au/support
NEW ZEALAND
0800 726 786 (All Product)
0800 6 726 786 (Support for Smart Mobile
Devices)
www.samsung.com/nz/support
DA68-04657B-01
Untitled-1 56 2023-04-07 5:18:03
