REVISED BULLETIN
SERVICE PARTS LIST
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
BULLETIN NO.
STARTING
SERIAL NO.
WIRING INSTRUCTION
DATE
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
CATALOG NO.
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 14-38-2353 Lens Assembly (1)
2 --------------- Lens w/ Overmold (1)
3 --------------- O-Ring (1)
4 12-20-2353 Service Nameplate (not shown) (1)
5 45-56-0400 Lanyard (Strap) (not shown) (1)
6 42-70-0058 Housing Clip (not shown) (1)
54-06-2380
M12™ SPOTLIGHT
2353-20
H01A
July 2015
0
00
EXAMPLE:
Component Parts (Small #) Are Included
When Ordering The Assembly (Large #).
FIG. NOTES
4 A clean, dry surface is essential for proper performance for
any adhesive system. The area intended for application of
any adhesive label or nameplate must be prepared by
cleaning with isopropyl alcohol. The solvent is to be applied
with a clean, lint free applicator and the surface allowed to
dry before applying the label or nameplate.
1
2
3
2
3
