MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
0
00
EXAMPLE:
Component Parts (Small #)
Are Included When Ordering
The Assembly (Large #).
FIG. NOTES
6 A clean, dry surface is essential for proper performance for any
adhesive system. The area intended for application of any
adhesive label or nameplate must be prepared by cleaning
with isopropyl alcohol. The solvent is to be applied with a clean,
lint free applicator and the surface allowed to dry before applying
the label or nameplate.
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 44-04-2015 Leg Assembly (1)
2 23-44-0259 M2.5 x 9mm PT Steel Screw (4)
3 22-68-1107 Screw Cover (2)
4 22-68-2015 USB Cover (1)
5 42-44-1211 USB-C to USB-C Cable (Optional) (1)
6 12-20-2015 Service Nameplate (1)
5
2
(4x)
6
3
(2x)
4
2
3
1
SERVICE PARTS LIST
BULLETIN NO.
PN0014130
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
REVISED BULLETIN
DATE
Dec. 2025
Rechargeable Pivoting Task Light
WIRING INSTRUCTION
CATALOG NO. 2015R SERIAL NO. S02A
NAMEPLATE SPECIFICATIONS: 5 V 3 A Contains 12 Wh Li-Ion
