PLEASE NOTE: There are 3 inch leg
extensions shipped with the machine,
but not installed. Their use is op�onal,
but highly recommended for ease of
cleaning under the unit. Also, though
the machine is 33” to the top of the
bean hoppers, sufficient room must
be allowed to add beans to them.
Recommend minimum of 3”.
Signature Printed Name Date
installation checklist
Quick Reference Specications
Dimensions: 33”(H)X 23.0”(L)X 43.4”(W - 2 Fridges - 1 on each side)
Weight: 233.0 lbs (full)
Electrical Requirements: Volts: 208-240/Watts: 8700/Amps: 50
Each Fridge - 110V/15 amps
Plumbing Requirements: Flow: 30GPH (minimum) Pressure: 20psi (mini-
mum) Hardness: 3 GPG (maximum) Fitting: 1/2” NPT Male w/shut off
Drainage Requirements: Open gravity drain of 1.25” ID (min) within 4 feet
of machine.
The following information will assist you in preparing your location for the installation of your equipment.
Please make sure everything is prepared to these specifications prior to scheduling your installation. Once
everything is complete, check the appropriate boxes and sign the bottom of the form.
208-240V/50AMP/8700WATT
Dedicated 50 AMP Plug within 4
feet of installation location.
PLEASE NOTE: The machine will
not be supplied with a Cord Cap
(Male plug). The outlet to the
right is one possible type.
Access to open gravity drain no smaller than
1.25” ID (Inner Diameter). Drain MUST be
within 4 feet of the machine for proper
drainage.
*Machine must be supplied with a minimum of 30 Gallons per hour @ 20 PSI.
*Example of appropriate supply fitting, see example at left - 1/2” NPT Male w/shut off.
*If water hardness levels exceed 3 GPG (Grains per Gallon) a water softener MUST be installed.
Exceeding these levels will void the manufacturer’s warranty. (Check appropriate box below)
I have tested the water hardness and it is 3 GPG or less (see above).
I already have a suitable water softener and its output is 3 GPG or less (see above).
I have tested the water hardness level and it is written above. Please supply me
with the appropriate water softener at time of installation.
from
espresso
COUNTER SPACE REQUIREMENTS: CONFIRMED – 2.5” ACCESS HOLE IS IN PLACE - add 10” width per fridge
WATER REQUIREMENTS : CONFIRMED - WATER HARDNESS LEVEL ________________GPG
ELECTRICAL REQUIREMENTS: CONFIRMED DRAINAGE REQUIREMENTS: CONFIRMED
By signing below, I am confirming that all installation requirements have been met. I also understand that if all
the requirements have not been met, I may be subject to additional installation and travel charges beyond the
original estimate.
MODEL
Tango STLC Duo
SUPER AUTOMATIC TWO GROUP - 1Step Milk
PRODUCT CODE : TDSTLC
