EG10.58 Rev. 11/23
Catalog Specification Sheet No.
EG10.58
Rice Cooker Tables
Item No.:
Project No.:
S.I.S. No.:
Specification Sheet
Rice Cooker Tables
MODELS:
T3224RCB
T3424RCB
T3224RCSB
T3424RCSB
Design and Construction Features
• 16 gauge type 430 stainless steel tabletop, with edges
turned down at 90˚ on all four sides and with cutout for
rice cooker.
• Heavy duty zinc-plated gussets.
• Available with 1
5
⁄8˝ (41mm)-diameter galvanized or stainless
steel legs.
• Adjustable high-impact plastic or stainless steel feet.
• Available with either adjustable 18 gauge galvanized or
stainless steel undershelves.
• Accommodates most popular brand cookers.
Short Form Specifications
Eagle Rice Cooker Table, model ______________. Top is 16
gauge type 430 stainless steel with all edges turned down 90˚.
Cutout in top for rice cooker. Two adjustable undershelves—
available in galvanized or stainless steel. 1
5
⁄8˝ O.D. Available
with galvanized tubular legs and high impact plastic feet, or
with stainless steel leg and stainless steel feet.
rice cooker table
shown with rice cooker
(not sold by Eagle)
Certifications / Approvals
For custom configuration or fabrication needs, contact our SpecFAB
®
Division.
Phone: 302-653-3000 • Fax: 302-653-2065 • e-mail: [email protected]
Eagle Foodservice Equipment, Eagle MHC, and SpecFAB
®
are divisions of Eagle Group. ©2023 by the Eagle Group
Spec sheets available for viewing, printing or downloading from our online literature library at our websites
EAGLE GROUP
100 Industrial Boulevard, Clayton, DE 19938-8903 USA
Phone: 302-653-3000 • 800-441-8440 • Fax: 302-653-2065
www.eaglegrp.com
www.eaglemhc.com
EAGLE GROUP
100 Industrial Boulevard, Clayton, DE 19938-8903 USA
Phone: 302-653-3000 or 800-441-8440 • Fax: 302-653-2065
www.eaglegrp.com • www.eaglemhc.com
Spec sheets available for viewing, printing or downloading from our online literature library at our websites
Although every attempt has been made to ensure the accuracy of the information provided, we cannot be held responsible for
typographical or printing errors. Information and specifications are subject to change without notice. Please confirm at time of order.
Rev. 11/23
Printed in U.S.A.
©2023 by Eagle Group
Catalog Specification Sheet No.
EG10.58
Rice Cooker Tables
Item No.:
Project No.:
S.I.S. No.:
Rice Cooker Tables
width length weight
model # in. mm in. mm lbs. kg
T3224RCB 32˝ 813 24˝ 610 53 24.0
T3424RCB 34˝ 864 24˝ 610 56 25.4
Tables with Galvanized Legs and Undershelf
With high-impact plastic feet.
width length weight
model # in. mm in. mm lbs. kg
T3224RCSB 32˝ 813 24˝ 610 53 24.0
T3424RCSB 34˝ 864 24˝ 610 56 25.4
Tables with Stainless Steel Legs, Feet, and Undershelf
FRONT VIEW SIDE VIEW
TOP VIEW
CUTOUT DIMENSIONS
width
center
