★APP download and installation operation
Register New Account and Login★
Battery camera switch operation★
Automatic configuration | Wireless network ★
●Bluetooth pairing for internet connectivity
●How to Install 4G Traffic Card
●(4G Camera) Network Connection
●Guide> Purchase 4G Data
●To set up mobile tracking
●To set up dual-light perimeter alarm
●Set the humanoid warning alarm function
01
02
03
04/05
06/07
08
09/10
11
12
13
14
Please follow the method on pages 1-5 with "★" stars to match first.
operation
>08<
1. When pairing for the first time, please insert the prepared SIM
into the device and power it on; insert the SIM card according to
(Fig. 14), and wait for the device to prompt
"Network Connected Successfully";
2. If it fails to prompt "Network Connected Successfully", please
restore the factory settings or check whether there is a problem
with the SIM card;
Kind reminder:
If the inserted cellular traffic card cannot be used, please contact
the purchasing dealer to determine the frequency band of the
device's use.
Note:
Plug tutorial, only for 4G cameras that require a plug, no need to
operate the built-in traffic card;
TF Card
Reset
4G Card
How to Install 4G Traffic Card
TF Ca rd
Rese t
4G Ca rd
RESET
Fig.14
>07<
Fig.12 Fig.13
4. After Scanning the code,set the password according to the
prompt,and and proceed to the next step
5. After paring,newly added camera will be showed in the list,
connecting successfully(Fig.12)
6.C lick to view,operate,and make settings (Fig.13)
+
Device
Mobile Storage
Me
Cloud
Smart Device
...
Smart Cameracnnh
Online
Share
Settings
Smart Alarm
Events
Setti ngs
Monit or
Video Playback
Inter com
Snaps hot
Steering control
Picture quality switch
Cloud Storage
Light Control
Automatic tracking
switch
Screen Switching
Multiple pictures
Horizontal scr
een flip
Video recording
Camera_314a
55.02KB/S
Cloud Playback
Auto Tracking
2022-06-12 11:14:12
CAM01
FHD
Purchase cloud storage to
upload alarm recordings to cloud!
Local Record
Night Vision & Alarm
Set Light Alarm
Event recording to the microSD card after
you have inserted a microSD card
Purchase
(WiFi Camera) Bluetooth Connection
There are Differences Between Pictures and Products,
Please Refer To Actual Ones
V2023-3.0
WiFi/4G
Smart Camera
iC See
*nstallation of SIM Card is only applicable
for the “Self-insert SIM Card” version.
No action is needed for devices with
built-in SIM card
>01<
>02<
Scan The ‘QR Code’
To Download
Method One
You Can Use Any ‘Scan’ Program To Scan The ‘QR Code’ Below
To Download The APP.
1. Open APP ‘iCSee’,click ‘Sign Up’,and sign up a new account
with your phone number/email(Fig.3)
2. After registering successfully,enter the username/email and
password you just registered to login.
3. You can also use WeChat,Facebook,Line or ‘Visitor Login’
to login in the APP.
Please Click ‘Regular Download’,Neither ‘Safe Download’ Nor
‘High-Speed Download’
Method Two
iOS System: Search in APP Store (Fig.1 )‘iCSee’
Android System: Search in APP market(Fig.2 ) ‘iCSee’
Fig.2[Android System]
Fig.3
Note For Android Syetem
Fig.1 [iOS System]
iC See
iC See
30.09/M
iC See
iC See
x
Login
Sign Up
Login
China mainland
+86 >
18923895909
**********
Username
Password
Forget Password?
Visitor Login
WeC ha t
Fac ebook
Sign Up
WeChat
Facebook
Visitor Login
APP Download and Lnstallation
Register New Account and Login
1. The paired mobile phone must be connected to your router WiFi
network; (Only 2.4GHZ is Supported)
Click the '+' sign (Fig. 9) on the upper right corner of the APP Home 2.
screen to enter the automatic device search interface When using the
current device, please click (Fig.10) to proceed to the next "Confirm"
step and set the router password Code;
3. To ‘Router Setting’ interface to choose the WiFi Router and enter the
password (Fig.11),Click to enter ‘Scan Code Pairing ‘Confirm’
instruction’ interface.
>06<
Fig.9 Fig.10 Fig.11
Router Setting
Confirm
2.4Ghz 5Ghz
Failed to connect to WiFi?
WiFi
Password
*Sele ct a Wi-Fi wit h stable and strong signal ,fill in the
correct Wi-Fi pas sword .
Smart Device
+
Click”+”button to add device
Device
Mobile Storage
Me
Cloud
Add Device
Search the devices
Add device manually
WiF i Camer a
WiFi
VIOT S ta ti on
DVR /NVR
Sha red wit h me
4G Ca mera
4G
Discover below devices
Other ways to pair and add device
+
Found devices waiting to be added:1
Camera 317B
Cancel Confirm
(WiFi Camera) Bluetooth Connection
Note:
▲Please power on the camera first before the configuration.
▲Select the "Bluetooth" distribution mode, please turn on the "Bluetooth
mode" switch of the phone first, and then pair and connect;
1. The paired mobile phone must be connected to your router WiFi
network; (Only 2.4GHZ is Supported)
2. Click the ‘+’ Sign(Fig.4) in the upper right corner of main APP
interface,click ‘WiFi Camera’(Fig.5) and follow the device voice
prompt(Click ‘Next’).
3. To ‘Router Setting’ interface to choose the WiFi Router and enter
the password (Fig.6),Click ‘ ’ to enter ‘Scan Code Pairing Confirm
instruction’ interface.
Note: Please power on the camera first before the configuration
>04< >05<
Fig.4 Fig.5 Fig.6 Fig.7
Fig.8
4. After Scanning the code,set the password according to the
prompt,and and proceed to the next step
5. After paring,newly added camera will be showed in the list,
connecting successfully(Fig.7)
6.C lick to view,operate,and make settings (Fig.8)
Add Device
Search the devices
Add device manually
WiF i Camer a
WiFi
VIOT St atio n
DVR /NVR
Sha red wit h me
4G Ca mera
4G
Discover below devices
Other ways to pair and add device
+
Smart Device
+
Click”+”button to add device
Device
Mobi le Storage
Me
Cloud
+
Device
Mobile Storage
Me
Cloud
Smart Device
...
Smart Cameracnnh
Online
Share
Settings
Smart Alarm
Events
Setti ngs
Monit or
Video Playback
Inter com
Snaps hot
Steering control
Picture quality switch
Cloud Storage
Light Control
Automatic tracking
switch
Screen Switching
Multiple pictures
Horizontal scr
een flip
Video recording
Camera_314a
55.02KB/S
Cloud Playback
Auto Tracking
2022-06-12 11:14:12
CAM01
FHD
Purchase cloud storage to
upload alarm recordings to cloud!
Local Record
Night Vision & Alarm
Set Light Alarm
Event recording to the microSD card after
you have inserted a microSD card
Purchase
Router Setting
Confirm
2.4Ghz 5Ghz
Failed to connect to WiFi?
WiFi
Password
*Sele ct a Wi-Fi wit h stable and strong si gnal,fill in th e
correct Wi-Fi pas sword .
WiF i Camer a
WiFi
(WiFi Camera) WiFi Connection
2.4Ghz 5Ghz
*Only 2.4GHZ is Supported
*Bluetooth pairing mode is only supported for
gun-ball integrated cameras.
>03<
●Before pairing, please turn on the power button of the device. Once
you hear the camera say it indicates a successful "Start quick setup,"
wake-up and you can proceed to the next step.
●Please know clearly interface and buttons of cameras before
using.
Solar Panel Charging Indicator Diagram
Power Switch Location for TQ2/TQ3/TQ5
Battery camera switch operation
Solar energy
[optional]
Solar panel inter face
D
C5V
O
F
F
/
O
N
Solar charging por t
type-c 5V charging por t
Power switch
button
D
C
5V
O
FF
/O
N
>10<>09<
Fig.20 Fig.21
3. Please download and install APP first.login the APP and make sure the
mobile phone network is normal
4. Click the on the upper right corner of the APP main interface ‘+’
(Fig.15),click on (Fig.16),according to the camera voice ‘4G Camera’
prompts,following the steps to scan the label on the 4G camera QR
Code(Fig.17/Fig.19), then next step, (Fig.18)’Add device’
5. After the configuration is successful,fill in the password,confirm,save,
then to next step.
6. Enter the ‘Device Name’ ,and follow as the prompt to complete the
connection process
7. After paring,newly added camera will be showed in the list,connecting
successfully(Fig.20)
8. Preview the camera,prompting to purchase the traffic,and operate
other steps(Fig.21)
Device QR code
Please scan the QR code on the
device machine to add
Model: 4G intelligent human MINI ball
mm number：4MM
Serial number.
4f242830****288d
QR Code
1 2 3 4 5 6 7 8 9 3 2 1 2
+
Device
Mobile Storage
Me
Cloud
Smart Device
...
Smart Cameracnnh
Share
Settings
Smart Alarm
Events
Setti ngs
Monit or
Video Playback
Inter com
Snaps hot
Steering control
Picture quality switch
Cloud Storage
Light Control
Automatic tracking
switch
Screen Switching
Multiple pictures
Horizontal scr
een flip
Video recording
Camera_314a
55.02KB/S
Cloud Playback
Auto Tracking
2022-06-12 11:14:12
CAM01
FHD
Purchase cloud storage to
upload alarm recordings to cloud!
Local Record
Night Vision & Alarm
Set Light Alarm
Event recording to the microSD card after
you have inserted a microSD card
Purchase
(4G Camera) Network Connection
(4G Camera) Network Connection
Fig.15 Fig.16 Fig.17 Fig.18
Fig.19
Find and Scan the QR code on the label of the
camera
QR Code
Add Device
Search the devices
Add device manually
WiF i Camer a
WiFi
VIOT St ation
DVR /NVR
Sha red wit h me
4G Ca mera
4G
Discover below devices
Other ways to pair and add device
+
Smart Device
Scan to add 4G camera
+
Click”+”button to add device
Device
Mobil e Storage
Me
Cloud
Manual input to add a camera
4G Ca mera
4G
Add Devices
367 e9bd* ***24 f319b
X
Monitor
Traffic
>11<
●When the device prompts ’Network connecting successfully ’,which
mean the configuration is finished,here comes to buy 4G data,please
follow the guide(Fig.22)
Enter the ‘Date Purchase’ interface,choose the corresponding package ●
and click to purchase(Fig.23)
After the successful purchase,will automatically jump to traffic query ●
page;
Note:
If the purchase interface is not prompting,please click ‘Traffic’ in the
device list to buy(Fig.24)
Flow
No package available yet
Annual package
Traffic package
Valid in the month of opening
Free trial
1G data experience
Unlimited
traffic
￥XXX/year
Original price ￥248
4G traffic
per month
1G流量包
￥XXX/ year
￥XX/ year
￥XX/year
Original price ￥175
Original price ￥96
Original price ￥25
￥XXX/year
2G traffic
per month
1G traffic
per month
+
Device
Mobi le Storage
Me
Cloud
Smart Device
...
Smart Cameracnnh
Share
Settings
Smart Alarm
Events
Traffic
You didn’t buy traffic
packages.do you buy them
immediately?
Cancel
Confirm
+
Device
Mobile Storage
Me
Cloud
Smart Device
...
Smart Cameracnnh
Share
Settings
Smart Alarm
Events
Traffic
Traffic
Guide> Purchase 4G Data
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception,which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.-- Consult the dealer or an
experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This
equipment should be installed and operated with minimum 20cm
distance between the radiator and your body: Use only the supplied
antenna.
FCC WARNING
>12<
To set up mobile tracking
Fig.25 Fig.26
Night Vision & Alarm
Set Light Alarm
Auto Tracking
Local Record
Event recording to the microSD card after
you have inserted a microSD card
Camera_314a
55.02KB/S
2022-06-12 11:14:12
CAM01
FHD
Cancelar
Sensitivity
High
Return t o watc h posi tion
5Min
Auto Tracking
Start tracking from the current position, and it will
return to current position when finish tracking.
Night Vision & Alarm
Set Light Alarm
Auto Tracking
Local Record
Event recording to the microSD card after
you have inserted a microSD card
Note: Mobile tracking and smart humanoid alert can't be used at the
same time;
●Click the (Fig.25) switch button in the preview "Mobile Tracking"
interface to turn on the corresponding function;
● when it's on, as long as an object enters the camera's Motion tracking:
illumination range, camera will track the moving trajectory (Fig.26);
● set a fixed position, when the camera is operating or Watch Point:
tracking, it will automatically return to the set position after staying for a
period of time (Fig.26);
Camera_314a
55.02KB/S
2022-06-12 11:14:12
CAM01
FHD
>13<
To set up dual-light perimeter alarm
●Open the app, click on , and then click on 'iCSee' 'Real-time Playback'
the or the icon in the screen to open the alarm "Light Alarm" "Bulb"
mode settings (Fig.27)；
●Starlight Full-color: When the light is insufficient, the white light
will start, and the image will be colorful ( Fig.29);
When the light is insufficient, the infrared ●Infrared Night Vision:
light is activated and the image becomes black and white (Fig.29);
When the light is insufficient, the infrared light ●Dual-light Alert:
will be activated. When someone enters the monitoring screen, the
white light will be triggered and the image will be colorful. After a few
seconds when the person walks away, the infrared mode will be
switched on and the image will become black and white (Fig.29).
Fig.27
Camera_314a
55.02KB/S
Auto Tracking
2022-06-12 11:14:12
CAM01
FHD
Local Record
Night Vision & Alarm
Set Light Alarm
Event recording to the microSD card after
you have inserted a microSD card
Camera_314a
55.02KB/S
Auto Tracking
2022-06-12 11:14:12
CAM01
FHD
Local Record
Night Vision & Alarm
Set Light Alarm
Event recording to the microSD card after
you have inserted a microSD card
Cancelar
Light Mo de
Full Color/lnfrared Vision/Double
Light Alert
Double Light Alert
Full Col or
Infrared V is io n
Infrared V is io n
Camera_314a
55.02KB/S
Auto Tracking
2022-06-12 11:14:12
CAM01
FHD
Local Record
Night Vision & Alarm
Set Light Alarm
Event recording to the microSD card after
you have inserted a microSD card
Cancelar
Light Mo de
Full Color/lnfrared Vision/Double
Light Alert
Double Light Alert
Sensit iv it y
Light Du ra ti on
Intellig en t Al ert
High
60s
Fig.28 Fig.29
>14<
Set the humanoid warning alarm function
● Open the 'iCSee', click the device real-time playback, click on the upper
right button 'setting' (Fig.30)Enter the 'settings'-smart alarm (Fig.31),
open the interface to make related settings (Fig.32)
Function introduction:
Must be turned on to receive alarm trigger information.●Notification:
only judge and detect people to trigger an ●Humanoid detection:
alarm;(Fig.32)
When the human figure appears on the screen, the ●Show Tracking:
human figure can be tracked and reminded;
select the designated area [Warning Line],when ●Rule setting:
someone enters the divided area, the alarm can be triggered;(Fig.32)
Note: Mobile tracking and intelligent humanoid alert cannot be
enabled simultaneously.
Fig.30 Fig.31 Fig.32
14 :12
Smart Alarm
Alarm
>
Human Detection
Action
Snapshot/Record/Alarm flashing
light
Event Setting
Alarm Push
Notice the APP when event triggered
Push Settings
Do not disturb is on , this phone will not receive any
push
Do Not Disturb
Other Settings
Advanced
>
Camera_314a
55.02KB/S
Cloud Playback
Auto Tracking
2022-06-12 11:14:12
CAM01
FHD
Purchase cloud storage to
upload alarm recordings to cloud!
Local Record
Night Vision & Alarm
Set Light Alarm
Event recording to the microSD card after
you have inserted a microSD card
Purchase
14 :1 2
14 :12
Settings
Basic Settings
Camera linkage
>
>
Local Storage
Record Settings
>
>
Smart Alarm
Network Settings
>
>
Advanced Settings
>
Add to Desktop
About
>
>
+
Fig.22 Fig.23 Fig.24
