INSTRUCTION MANUAL
LED FLOODLIGHT
WITH SENSOR & SOLAR PANEL
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these
instructions carefully before starting the installation and keep this manual handy for future refer-
ence. If you have any another query, please contact our dealer or local vendor from whom you have
purchased the product. They are trained and ready to serve you at the best. The warranty is valid
for 2 years from the date of purchase. The warranty does not apply to damage caused by incorrect
installation or abnormal wear and tear. The company gives no warranty against damage to any
surface due to incorrect removal and installation of the product. The products are suitable for 10-12
Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This product
is warranted for manufacturing defects only.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
[email protected] FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
SKU
MODEL
24469
1500 Lm
150 LMW
60OOK
>70
Aluminium
Mono 5V/6W, 390x340mm
3.2V, 5000mAH
VT-44048
NOTE: In order to maintain the IP protection of the product, the cable entry/gland
should be installed on the bottom side.
INSTALL THE LAMP INSTALL THE SOLAR PANEL
CONNECT WIRES
REPLACING PCB LED STEPS
(TO BE DONE BY ELECTRIACIAN PROFESSIONAL )
B-
S-
S+
B+
Step 1
Depth 60mm
Depth 60mm
Ø8mm
Ø8mm
360° Adjustable
270° Adjustable
Step 2
Step 3
2-5 Mtrs
Lamp automatically lights up at night and turns to full brightness when motion is detected
in the range ≤8Mtrs, then turns to lower brightness in 60 seconds of no motion.
Note: Light source removal will void the warranty.
Low Bright
Half Light mode
Half Light mode
Full Light mode
2/4/6 Hour regular
Open When dark then comes to sensor mode
Press OFF, Lamp flicks 3 times then turns OFF.
Open when dark then comes to full light mode.
Useless Buttons
full
1
1
P
ALWAYS
ALWAYS
M
M
Induction
Induction
2H 4H
8H
Lamp automatically lights up at night and keep selected brightness for 3H/5H/8H, aer
which or when the battery power is less than 30%, lamp turns to Auto Sensor Mode.
REMOTE CONTROL SAFETY INSTRUCTIONS
• Before using this product, make sure that all parts are configured correctly according to
the instructions in the attached instruction.
• The product should not be used by persons under 5 years of age without supervision by
a parent or guardian.
• Ensure that the power batteries are configured correctly and have the appropriate
parameters as specified by the manufacturer.
IMPORTANT NOTES
V-TAC UK LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT
[email protected] V-TAC, 5A TUNGSTEN PARK, DOWNS ROAD, WITNEY, OXFORDSHIRE, OX29 0AX
V-TAC WEST EUROPE LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
SUPPORT@V-TAC.EU FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC WEST EUROPE LTD. GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
• This product contains battery type "Secondary" (rechargeable).
• Electrical and electronic equipment that has become waste is known as old equipment/device. Old
devices must not be disposed of with other household waste.
• Owners of old devices at the end of its service life must return the device by taking them to the
collection points set up by public waste disposal authorities or distributors. This return does not
entail any costs for you.
• Owners of old devices have an obligation to remove accessible batteries / rechargeable batteries as
well as non-destructively removable lamps from the old device prior to return. This does not apply if
old devices are being prepared for reuse with the participation of a public law firm.
• Battery removal warning: The battery contained in this product must be removed only by profes-
sional personnel only. The battery must never be removed by the end user, if not removed correctly
it could damage the battery which could cause fire.
• Batteries removed from an old electronic device should be disposed of separately. This return of
battery does not entail any costs for you and the user is obliged to return the battery.
• Please make sure that this product is not powered on when removing the battery. Fire hazard! Avoid
short-circuiting the contacts of a detached battery. Do not incinerate the battery. Please handle the
battery with Caution!
• If electrical appliances or batteries are disposed of in landfills or dumps, hazardous substances can
leak into the groundwater and get into the food chain, damaging your health and well-being.
• The symbol of "Crossed rubbish bins "indicates that this product should not be disposed of with
other household wastes and must be collected separately from unsorted municipal waste at the end
of its service life.
• Please use the link below to view the online directory of the collection and return points:https://ww-
w.ear-system.de/ear-verzeichnis/sammel-und-ruecknahmestellen
