GAME STREAMING MIXER
USB AUDIO INTERFACE / INTERFACE AUDIO-USB /
INTERFAZ DE AUDIO USB / USB-АУДИОИНТЕРФЕЙС /
64#ꮠ갓槡ꪫ
/
64#ꮠ銻☮ꪫ
/
64#؛٭ظؔ؛ؕ٤ذ٭نؘ٭ت
ج٭نطؔ٭؝ؕغ
Safety Guide
Sicherheitshandbuch
Guide de sécurité
Guía de seguridad
Guia de Segurança
Guida alla sicurezza
Руководство по технике безопасности
㸝Ⰼ䭷⽂
㸞䭸⽂
1. IMPORTANT NOTICE: DO NOT MODIFY
THIS UNIT!
This product, when installed as indicated in the
instructions contained in this manual, meets
FCC requirements. Modifications not expressly
approved by Yamaha may void your authority,
granted by the FCC, to use the product.
2. IMPORTANT: When connecting this product
to accessories and/or another product use only
high quality shielded cables. Cable/s supplied
with this product MUST be used. Follow all
installation instructions. Failure to follow instruc-
tions could void your FCC authorization to use
this product in the USA
3. NOTE: This product has been tested and found
to comply with the requirements listed in FCC
Regulations, Part 15 for Class “B” digital
devices. Compliance with these requirements
provides a reasonable level of assurance that
your use of this product in a residential environ-
ment will not result in harmful interference with
other electronic devices. This equipment gener-
ates/uses radio frequencies and, if not installed
and used according to the instructions found in
the users manual, may cause interference harm-
ful to the operation of other electronic devices.
Compliance with FCC regulations does not guar-
antee that interference will not occur in all instal-
lations. If this product is found to be the source
of interference, which can be determined by
turning the unit “OFF” and “ON”, please try to
eliminate the problem by using one of the follow-
ing measures:
- Relocate either this product or the device that
is being affected by the interference.
- Utilize power outlets that are on different
branch (circuit breaker or fuse) circuits or
install AC line filter/s.
- In the case of radio or TV interference, relo-
cate/reorient the antenna. If the antenna lead-
in is 300 ohm ribbon lead, change the lead-in
to co-axial type cable.
If these corrective measures do not produce sat-
isfactory results, please contact the local retailer
authorized to distribute this type of product. If
you cannot locate the appropriate retailer,
please contact Yamaha Corporation of America,
6600 Orangethorpe Ave., Buena Park,
CA90620, USA.
The above statements apply ONLY to those
products distributed by Yamaha Corporation of
America or its subsidiaries.
(529-M04 FCC class B YCA 01)
FCC INFORMATION (U.S.A.)
* This applies only to products distributed by Yamaha Corporation of America. (FCC SDoC)
COMPLIANCE INFORMATION STATEMENT
(Supplierʼs declaration of conformity procedure)
Responsible Party : Yamaha Corporation of America
Address : 6600 Orangethorpe Ave., Buena Park, Calif. 90620
Telephone : 714-522-9011
Type of Equipment : USB AUDIO INTERFACE
Model Name : ZG01, ZG01 PACK
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received including interference that may cause undesired
operation.
* This applies only to products distributed by Yamaha Corporation of America. (Ser.No)
IMPORTANT
Please record the serial number of this unit in the space below.
Model
Serial No.
The serial number is located on the bottom or rear of the unit. Retain this Owner’s Manual in a safe
place for future reference.
ZG01 Safety Guide
2
SAFETY PRECAUTIONS
ZG01 Safety Guide
3
EN
SAFETY
PRECAUTIONS
Please read these precautions carefully before
proceeding.
Be sure to follow the
instructions
Please carefully read and observe the following
precautions to avoid harm to people or damage to your
personal property.
After reading this document thoroughly, please retain it
in a location that anyone using the product can access
at any time.
These precautions alert you to the possibility
of death or serious injury to yourself or others.
Power supply
• Use the voltage specified for this product.
Using an incorrect voltage may result in fire, electrical
shock or damage to the product.
Do not disassemble
• Do not modify or disassemble this product.
Otherwise, fire, electrical shock, injury or damage to
the product may be caused.
Water warning
• Do not use this product in damp or wet conditions,
such as a bathroom or rainy outdoor location.
If liquid spills into the product, fire, electrical shock or
damage to the product may be caused.
Fire warning
• Do not handle open flames near this product.
Otherwise, fire may be caused.
Hearing loss
• If you plan to connect this product to any other
devices, first turn off the power to all devices.
Otherwise, hearing loss, electrical shock or damage
to the product may be caused.
• Before turning on the power to or using this product,
set the volume level to minimum. Before turning off
the power to this product, set the volume levels of this
product and all connected devices to minimum.
Otherwise, hearing loss or damage to the product
may be caused.
• Do not use headphones for a long period of time at a
high volume or uncomfortable level.
Otherwise, hearing loss may be caused. If you
experience any hearing abnormality, consult a
physician.
These precautions alert you to the possibility
of physical injury to yourself or others.
Installation
• Do not place this product in an unstable position or a
location subject to vibration.
Otherwise, the product may fall or tip over, resulting
in injuries or damage to the product.
• Do not block the heat dissipation of this product
when installing it.
- Do not cover the product with a cloth or table cloth.
- Do not install the product on a carpet or rug.
- Make sure that the top surface faces up. Do not
install the product on its sides or upside down.
- Do not use the product in a confined, poorly-
ventilated location.
Inadequate ventilation may result in overheating
inside the product, possibly causing damage and fire
or malfunction.
Make sure that there is adequate space around the
product at least 5 cm above, 1 cm at the sides and
5 cm behind.
• Contact the following customer center for
inspection or repair.
- The store you purchased the product
- Yamaha dealer
• This product is intended for use as a general
household device. Do not use it in any field or
activity requiring a high degree of reliability in
relation to human lives or valuable assets.
• Please note that Yamaha cannot accept any
liability for any losses resulting from improper
use or unauthorized modification of the product.
WARNING
CAUTION
Precautions for use
ZG01 Safety Guide
4
EN
• Before moving this product, be sure to remove all
connected cables.
Otherwise, the cables might be caught by a foot or
hand, and the product may fall or tip over, resulting in
injuries or damage to the product.
Connections
• If you plan to connect external devices, first read the
owner’s manual for each device, and connect them in
accordance with the instructions.
If you do not follow the instructions correctly, injury
or damage to the product may be caused.
Handling
• Do not apply the following excessive force to this
product.
- Resting your weight on this product
- Placing heavy objects on this product
- Applying excessive force to the buttons, switches, or
I/O connectors
Otherwise, injury or damage to the product may be
caused.
• Do not pull connected cables.
Otherwise, the product may fall or tip over, resulting
in injuries or damage to the product.
Precautions for use
NOTICE
Follow the precautions below to avoid malfunction and
damage to this product and to prevent the loss of data.
Power supply
• If you plan not to use this product for a long period of
time, disconnect the USB cable from this product.
Even when the [P] (Standby/On) switch is turned off,
a small amount of current still flows through this
product.
• Never insert or remove a USB cable with wet hands.
Installation
• Depending on the environment in which you use the
product, a phone, radio or TV may generate noise. In
that case, change the product location or orientation,
or the surrounding environment.
• Do not install this product in a place subject to:
- Direct sunlight
- Extremely high or low temperatures
- Excessive dust
Otherwise, malfunction or damage to the product
may be caused.
• Do not install this product in a place where
condensation can form due to rapid, drastic changes
in ambient temperature. Using the product while
condensation is present may cause damage to the
product. If there is a reason to believe that
condensation might have occurred on or in this
product, leave it for several hours without turning on
the power. You can start using the product when the
condensation has completely dried.
Handling
• Do not place any vinyl, plastic or rubber products on
this product. Otherwise, the panel may be discolored
or deteriorate.
• Do not drop this product or apply any strong impact
to the product.
Otherwise, damage to the product may be caused.
• Do not drop a foreign object, such as a piece of metal
or paper, into any gap on this product.
Otherwise, damage to the product may be caused.
Maintenance
• Use a dry, soft cloth to clean this product. Do not use
benzine, thinner, detergent or chemical rag to clean
the surface of the product. Otherwise, the surface
may be discolored or deteriorate.
[USB] and [5V DC] terminals
When connecting the computer to the [USB] connector,
make sure to observe the following points. Failing to do
so risks freezing the computer and corrupting or losing
the data. If the computer or the mixer freezes, restart
the application software or the computer OS, or turn
the mixer’s [P] (Standby/On) switch to standby and
then on again.
• Be sure to use the included USB cable.
• Before connecting the computer to the [USB]
terminal, exit from any power-saving mode of the
computer (such as suspend, sleep, standby).
• Be sure to quit any open applications and turn the
[P] switch to standby before unplugging cables from
the [USB] and [5V DC] terminals.
• Wait for six seconds or more whenever turning the
mixer’s [P] switch from standby to on or from on to
standby.
Important information
ZG01 Safety Guide
5
EN
Phantom Power
• Be sure to leave this switch off if you do not need
phantom power.
• Follow the important precautions below, in order to
prevent noise and possible damage to external
devices as well as the mixer if you turn this switch on.
- Be sure to leave this switch off when you connect a
device that does not support phantom power to the
[MIC IN] connector.
- Make sure to turn this switch off when connecting/
disconnecting a cable to/from the [MIC IN]
connector
- Minimize the volume of MIC GAIN [ ] knob and MIC
LEVEL (fader) before turning this switch on/off.
Important
information
NOTE
This section describes precautions to be observed
during use, functional restrictions, and supplemental
information that may be helpful for you.
Product features
• Yamaha continuously makes improvements and
updates to the software included in this product. You
can download the latest software from the Yamaha
website.
Nameplate of this product
Trademarks
• Microsoft and Windows are registered trademarks of
Microsoft Corporation in the United States and other
countries.
• Mac is trademark of Apple Inc. registered in the
United States and other countries.
• The instruction manual for this product is as follows.
- ZG01 Start Guide (packaged with the product)
- ZG01 Safety Guide (This document)
- ZG01 User Guide (HTML)
Contents of this document
• Unauthorized copying of this document in part or in
its entirety is prohibited.
Disposal or transfer
• If you plan to transfer ownership of this product,
include this document and the supplied accessories
along with the product.
• Follow the rules of your local authority to dispose of
this product and its accessories.
Product information, such as the model name
(product number), manufacturing number (serial
number), and power requirements, is displayed on
or in the vicinity of the nameplate on the product
(bottom panel). We recommend that you fill in the
following space with the model name and serial
number, and store this document in a safe place so
that the information will help you identify your
product in case you lose the product.
Model Name
Serial Number
Important information
ZG01 Safety Guide
6
EN
Protecting the environment
Information for users on collection and
disposal of old equipment:
This symbol on the products, packaging,
and/or accompanying documents means
that used electrical and electronic products
should not be mixed with general household
waste.
For proper treatment, recovery and recycling
of old products, please take them to
applicable collection points, in accordance
with your national legislation.
By disposing of these products correctly, you
will help to save valuable resources and
prevent any potential negative effects on
human health and the environment which
could otherwise arise from inappropriate
waste handling.
For more information about collection and
recycling of old products, please contact
your local municipality, your waste disposal
service or the point of sale where you
purchased the items.
For business users in the European Union:
If you wish to discard electrical and
electronic equipment, please contact your
dealer or supplier for further information.
Information on Disposal in other Countries
outside the European Union:
This symbol is only valid in the European
Union. If you wish to discard these items,
please contact your local authorities or
dealer and ask for the correct method of
disposal.
ZG01 Safety Guide
ZG01 Safety Guide
雅马哈乐器音响（中国）投资有限公司
上海市静安区新闸路 1818 号云和大厦 2 楼
客户服务热线：4000517700
公司网址：https://www.yamaha.com.cn
制造商：雅马哈株式会社
制造商地址：日本静冈县滨松市中区中泽町 10-1
进口商：雅马哈乐器音响（中国）投资有限公司
进口商地址：上海市静安区新闸路 1818 号云和大厦 2 楼
原产地：马来西亚
© 2022 Yamaha Corporation
Published 04/2022
2022
年
4
月 发行
MWEM-B0
Yamaha Pro Audio global website
https://www.yamahaproaudio.com/
Yamaha Downloads
https://download.yamaha.com/
VFE8680
ヤマハ株式会社
〒430-8650静岡県浜松市中区中沢町10-1
