User Manua
168-P16-REMOTE
l
01 Product Info
JCHR35W28 Hand-held 6-channel remote with vane adjustment
02 Buttons
a. FrontHand-held 6-channel remote with vane adjustment
b. BackBattery compartment
03 Parameters
Battery Type: AA battery × 2Working Temperature: -10°C – 50°CRadio Frequency:
433.92MHz ±100kHzTransmit Distance: ≥30m indoor
04 Caution!
1. The transmitter should not be exposed to moisture or impact, so as not to affect its
life.
2. During use, when the remote control distance is significantly shorter or less sensitive,
please check whether the battery needs to be replaced.
3. When the battery voltage is too low, orange LED flickers when you press button,
indicating to replace battery.
4. Please properly dispose of used batteries according to the local garbage classification
and recycling policy.
05 Instructions
a. Child-lock (Prohibit dual-key operation)
Press P1 or P2 for 10sRepeat ×3Dual-key operation activated
Note: When dual-key operation prohibited, limit setting and other programming
functions are not allowed.
b. Number of Channels Setting
Wen all LEDs are lit, that is channel 0 (All channels move together).
c. Vane Adjustment
Scroll 1 notch: vanes go up or down 1 notchScroll n notches: raise or lower the vanes by
n steps
d. Other operations
Please refer to the motor operation instruction
06 FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:(1) This device may not cause harmful interference, and(2) This device
must accept any interference received, including interference that may cause undesired
operation.
Warning:Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
