WARRANTY DATE CODE
REFERENCE GUIDE
Warranty. hunter.direct/warranty
http://hunter.direct/warranty
All products currently under warranty have been included. If you do not see the product
you’re looking for it may no longer under warranty. http://hunter.direct/discontinued
STATEMENT OF WARRANTY Hunter Residential & Commercial Irrigation
Hunter Industries Incorporated (“Hunter”) warrants the following products to be free of defects in materials or workmanship under normal use in landscape
irrigation applications for the specied period of time outlined below from the original date of manufacture:
ONE
YEAR
ROTORS
SRM
MICRO
Micro Sprays
TWO
YEARS
ROTORS
PGP®-ADJ, PGJ
CONTROLLERS
Eco Logic, XC Hybrid, X-Core® and Pro-C®
Families, ROAM, NODE, WVP, WVC, PSR
SPRAYS
PS Ultra Family
SENSORS
ET System
NOZZLES
Spray Nozzles, PCN, PCB, AFB, MSBN
MICRO
ACZ, PCZ, RZWS, Point Source Emitters
VALVES
PGV Family, PSR
ACCESSORIES
HCV, SJ, FLEXsg, HSBE Family, SpotShot
THREE
YEARS
CONTROLLERS
ROAM XL
MP ROTATOR®
All
FIVE
YEARS
ROTORS
PGP Ultra, I-20, I-25, I-40, and I-90
CENTRAL
IMMS® Central Control Products
SPRAYS
Pro-Spray®, PRS30, and PRS40 Families
SENSORS
Clik Sensors, Solar-Sync®, Flow-Sync®, MWS
VALVES
HQ, ICV, IBV, Accu-Sync®
MICRO
ICZ and PLD Tubing, Eco-Mat®, Eco-Wrap™
CONTROLLERS
I-Core®/DUAL® and ACC controller Families, ICD and Dual Decoder Products, ICR Remotes
Warranty. hunter.direct/warranty
ROTORS
PGJ, PGM, SRM I-20-SS, I-25, I-40 I-90
Date code is located on the bottom of the riser, removed
from body.
(yr/mo)
Warranty Period: 1 and 2 years
Date code is located on the bottom of the riser, removed
from body.
(yr/mo)
Warranty Period: 5 years
Date code is located on the lower diameter of the riser.
(mo/yr)
Warranty Period: 5 years
PGP®-ADJ, PGP Ultra, I-20 Plastic PGP Ultra, I-20 PRB
Date code is located on the nozzle housing.
(yr/mo)
Warranty Period: 2 and 5 years
Date code is located on the bottom of the body.
(yr/mo)
Warranty Period: 5 years
Bottom of riser Bottom of riser
Nozzle Bottom of body
Lower diameter
of riser
Warranty. hunter.direct/warranty
SPRAYS & MP ROTATOR
®
PS Ultra PRS30 PRS40
Date code is located in the ridges of the cap.
(mo/yr)
Warranty Period: 2 years
Date code is located on the body cap.
(mo/yr)
Warranty Period: 5 years
Date code is located on the body cap.
(mo/yr)
Warranty Period: 5 years
PROS-00 Pro-Spray® MP Rotator
Date code is located on the lower diameter of the riser.
(mo/yr)
Warranty Period: 5 years
Date code is located on the body cap.
(q/yr)
Warranty Period: 5 years
Date code is located under the screen.
(mo/dy/yr)
Warranty Period: 3 years
Ridge of cap Cap Cap
CapLower riser Under screen
Warranty. hunter.direct/warranty
VALVES
1" PGV 1½", 2" PGV PGV-JT
Date code is located on top of the bonnet.
(mo/yr)
Warranty Period: 2 years
Date code is located on top of the bonnet.
(mo/yr)
Warranty Period: 2 years
Date code is located on the side of the inlet.
(mo/yr)
Warranty Period: 2 years
ICV Solenoid
Date code is located on top of the bonnet.
(mo/yr)
Warranty Period: 5 years
Date code is located on the top.
(yr/wk)
Warranty Period: 5 years
PGV-ASV
Date code located in the bonnet groove.
(mo/yr)
Warranty Period: 2 years
Bonnet groove
Top of bonnet
Top of bonnet
Top
Top of bonnet Side of inlet
Warranty. hunter.direct/warranty
VALVES
Accu-Sync® HCV
Date code on lower diameter near the thread end.
(mo/yr)
Warranty Period: 5 years
Date code is located on the side.
(mo/yr)
Warranty Period: 2 years
SRV
Date code is located on top of the bonnet.
(mo/yr)
Warranty Period: 2 years
Quick Coupler
Date code is located on the top of valve.
(mo/yr)
Warranty Period: 5 years
Top of valve
Lower diameter
near thread
Top of bonnetSide
Warranty. hunter.direct/warranty
SENSORS
Mini-Clik® Rain-Clik®
Date code is located on the side.
(mo/yr)
Warranty Period: 5 years
Date code is located on the side.
(mo/yr)
Warranty Period: 5 years
Wireless Rain-Clik and Receiver
Solar Sync® Wireless Solar Sync
Receiver date code is located on the back side. Sensor
date code is located on the bottom.
(mo/yr)
Warranty Period: 5 years
Date code is located on the bottom of the sensor.
(mo/yr)
Warranty Period: 5 years
Receiver date code is located on the back side. Sensor
date code is located on the bottom.
(mo/dy)
Warranty Period: 5 years
Soil-Clik®
Receiver date code is located on the back side. Sensor
date code is located on the bottom.
(mo/dy)
Warranty Period: 5 years
Back side
Bottom side
Side
Bottom side
Back side
Bottom side
Bottom Back side
Side
Warranty. hunter.direct/warranty
SENSORS
Flow-Sync® Wind-Clik®
Receiver date code is located on the back side. Sensor
date code is located on the side.
(mo/yr)
Warranty Period: 5 years
Date code is located on the side.
(mo/yr)
Warranty Period: 5 years
Mini-Weather Station
Freeze-Clik®
Date code is located on the side.
(mo/yr)
Warranty Period: 5 years
Date code is located on the bottom of sensor.
(mo/yr)
Warranty Period: 5 years
ET Sensor
Date code is located on the bottom of sensor platform.
(mo/yr)
Warranty Period: 2 years
Bottom of platform
BottomSide
Side
Back side
Side
Warranty. hunter.direct/warranty
CONTROLLERS
X-Core® Facepack XC Hybrid, X-Core® Compartment
Date code is located on the bottom of controller.
(yr/mo/dy)
Warranty Period: 2 years
Date code is located in the lower right of wire
compartment.
(mo/yr)
Warranty Period: 2 years
Bottom Lower right
in compartment
Pro-C®, PCC Compartment
Pro-C®, PCC Facepack
Date code is located in the top right wire compartment.
(mo/yr)
Warranty Period: 2 years
Date code is located on the back side.
(mo/yr)
Warranty Period: 2 years
Top right in
compartment
Back side
I-Core® Facepack I-Core® Compartment
Facepack date code is located in the battery
compartment.
(mo/dy)
Warranty Period: 5 years
Compartment date code is located in the lower right
wire compartment.
(mo/dy)
Warranty Period: 5 years
Battery
compartment
Lower right
in compartment
Warranty. hunter.direct/warranty
CONTROLLERS
DUA L® D ec o de r
Date code is located on the back side, or on the bottom.
(mo/yr)
Warranty Period: 5 years
ICD Decoders
ACC Master Module
Date code is located on the back side, above approvals
label or on the bottom.
(mo/yr)
Warranty Period: 5 years
Date code is located on top of the connection plate.
(mo/yr)
Warranty Period: 5 years
ACC Communication Modules
Date code is located on the back side.
(mo/yr)
Warranty Period: 5 years
Back side
ACC Facepack ACC Compartment
Date code is located in the battery compartment.
(mo/yr)
Warranty Period: 5 years
Date code is located in back of the wire compartment.
(mo/yr)
Warranty Period: 5 years
Battery
compartment
Back of
compartment
Top of connection
plate
Back side
Back side
Bottom side
Warranty. hunter.direct/warranty
CONTROLLERS
ADM-99
Date code is located on the back side.
(mo/yr)
Warranty Period: 5 years
ICD-HP
Date code is located on the back side.
(mo/yr)
Warranty Period: 5 years
Back side
ROAM ReceiverROAM Transmitter ROAM XL
Date code is located on the back side.
(mo/yr)
Warranty Period: 2 years
Date code is located in the battery compartment cover.
(mo/yr)
Warranty Period: 2 years
Date code is located in the battery compartment.
(mo/yr)
Warranty Period: 3 years
Battery
compartment
Back sideBattery
compartment
ICR
Transmitter date code is located on the back side.
Remote date code is located in the battery
compartment.
(mo/dy)
Warranty Period: 5 years
Back side
Battery
compartment
Back side
Warranty. hunter.direct/warranty
CONTROLLERS
PSR RAD-3
Date code is located on the back side.
(mo/yr)
Warranty Period: 5 years
Date code is located on the inside cover.
(mo/yr)
Warranty Period: 2 years
WVP, WVC
Date codes are located in the battery compartment.
(mo/yr)
Warranty Period: 2 years
Bottom
Bottom side
PCM, ICM, ACM Module
Date code is located on the bottom or back side.
(mo/yr)
Warranty Period: 2 and 5 years
Bottom
NODE
Date code is located in the battery compartment.
(mo/yr)
Warranty Period: 2 years
Battery
compartment
Inside cover Back side
Warranty. hunter.direct/warranty
Technical Support
Contact us for support with all Hunter and FX Luminaire products.
Both English and Spanish speaking representatives are available.
800-733-2823 | huntertechnicalsupport@hunterindustries.com
Open Mon-Fri 6:00 am – 4:00 pm PST.
Online product support
Visit our Support Library for instructional videos, owner’s manuals,
installation details, articles, and more.
www.hunterindustries.com/support
Customer Service
Our dedicated Customer Services Representatives are available for
assistance with product orders, order status, RMAs and more.
800-383-4747
Product Specialist Program
This unique training program is designed to equip you and your
customers with the knowledge to become familiar with Hunter products
at no cost to you. Many courses are now available in Spanish.
http://training.hunterindustries.com
Hunter Preferred Program
Your customers can earn points on the Hunter and FX Luminaire products
they are purchasing. Contractors and public agencies can enroll online.
http://preferred.hunterindustries.com
Questions about the program?
877-888-0167 | hunterpreferred@hunterindustries.com.
Frequently Ordered Literature
These items can be ordered through your dedicated Hunter customer
service representative using the following numbers:
Hunter Catalog LIT-600
Hunter Price List LIT-419
Hunter Spare Parts List 21-1494 download only
Product Reference Guide LIT- 6 67
Product Installation Guide INT-973
FX Luminaire Price List FXLIT-18 4
FX Luminaire Spare Parts List FXLIT-027
FX Luminaire Catalog FXLIT-183
HUNTER CUSTOMER SUPPORT
At Hunter, we’ve always believed the dierence lies in providing world-class product support to make your job easier. When you need technical help,
whether it’s to ask a quick question or to get product-specic troubleshooting assistance, you can count on Hunter to provide the best support in the
industry. Our knowledgeable experts are always available to help you.
Helping our customers succeed is what drives us. While our passion
for innovation and engineering is built into everything we do, it is our
commitment to exceptional support that we hope will keep you in
the Hunter family of customers for years to come.
Gregory R. Hunter, President of Hunter Industries
Website www.hunterindustries.com Customer Support 800-733-2823 Technical Service 800-383-4747
© 2015 Hunter Industries Incorporated
Please recycle.
LIT-501 C 11/15
USA HEADQUARTERS
1940 Diamond Street
San Marcos, California 92078, USA
TEL: 760-744-5240
MEXICO MANUFACTURING
ISO 9001:2008 Certied
Calle Nordika #8615
Tijuana, B.C., Mexico C.P., 22640
TEL: +52 664-903-1300
FAX: +52 664-903-1325
Europe
Avda. Diagonal 523, 5°- 2°
Edicio Atalaya
08029 Barcelona, Spain
TEL: +34 9-34-94-88-81
Australia
Suite 7, 202 Ferntree Gully Road
Notting Hill, Melbourne, Victoria 3168, Australia
TEL: +61 3-9562-9918
FAX: +61 3-9558-6983
Middle East
P.O. Box 2370
Amman, 11941, Jordan
TEL: +962 6-5152882
FAX: +962 6-5152992
China
B1618, Huibin Oce Bldg.
No.8, Beichen Dong Street
Beijing 100101, China
TEL/FAX: +86 10-84975146
