TF200SUK Series
OWNER’S GUIDE
FAN
Actual unit may vary slightly in appearance and colour.
IMPORTANT SAFETY INSTRUCTIONS
SUITABLE FOR HOUSEHOLD USE ONLY.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY: READ ALL THESE INSTRUCTIONS BEFORE USE.
1.
Do not incinerate battery cells. Consult your local waste
authority for information regarding available recycling and/or
disposal options.
2. This appliance comes with a remote control that contains (2)
AAA batteries. Dispose of batteries properly. Always keep
batteries away from children (choke hazard). Even used
batteries can cause injury.
3. To reduce the risk of an electric shock, connect only to an
outlet provided with a Residual Current Device (RCD).
4. The fan should be used on a stable and level surface.
5. Never use this fan near pools, bathtubs, showers, basins, or
other vessels containing water.
6. Do not operate any unit with a damaged wire. Discard the unit
or return to an authorized service facility for examination
and/or repair.
7. Do not run cord under carpeting. Do not cover charge cord
with throw rugs, runners, or similar coverings. Do not route
charger cord under furniture or appliances. Keep charger cord
away from high-trac areas. Place charger in an area where the
cord will not be tripped over.
8. If the charger cord is damaged, it should be replaced.
9. This appliance is not intended for use by anyone (including
children) with reduced physical, sensory, or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
10. Children should be supervised to ensure that they DO NOT play
with the appliance.
11. Cleaning and user maintenance shall not be made by children
without supervision.
12. Prior to cleaning or other maintenance, the appliance must be
unplugged from the electrical outlet.
13. Only use Shark® branded accessories.
14. Do not use if appliance is not working as it should, or has been
dropped, damaged, left outdoors, or dropped into water.
15. Turn o all controls before plugging in or unplugging
the appliance.
16. Unplug from electrical outlet when not in use and before any
maintenance or cleaning.
17. Hand wash exterior/hard plastic/non-electronic parts with
water only. Do not immerse. Cleaning with chemicals could
damage the unit.
18. Do not attempt to repair or adjust any electrical or mechanical
functions of this appliance, as this may cause danger and void
the warranty.
19. Even used batteries may cause severe injury or death.
20. Call a local poison control center for treatment information.
21. Compatible battery type is AAA.
22. The nominal battery voltage is 3V.
23. Non-rechargeable batteries are not to be recharged.
24. Do not force discharge, recharge, disassemble, heat above
60°C, or incinerate. Doing so may result in injury due to venting,
leakage, or explosion resulting in chemical burns.
25. Ensure the batteries are installed correctly according to polarity
(+ and -).
26. Do not mix old and new batteries, dierent brands or
types of batteries, such as alkaline, carbon-zinc, or
rechargeable batteries.
27. Remove and immediately recycle or dispose of batteries from
equipment not used for an extended period of time according
to local regulations.
28. Always completely secure the battery compartment. If the
battery compartment does not close securely, stop using the
product, remove the batteries, and keep them away
from children.
WARNING: Not suitable for use with solid-state
speed controls.
BATTERY REMOVAL AND DISPOSAL
This remote control uses 2 AAA batteries. When the remote
batteries no longer have a charge, they should be removed from the
remote and recycled. DO NOT incinerate or compost the product
with its integral battery or the remote batteries. When your remote
batteries need to be replaced, dispose of them or recycle them in
accordance with local ordinances or regulations. In some areas, it
is illegal to place spent batteries in the trash or in a municipal solid
waste stream. Return spent batteries to an authorised recycling
center or to retailer for recycling. Contact your local recycling center
for information on where to drop o the spent batteries.
POWER SUPPLY SAFETY
1. Read and follow all instructions that are on the product
or provided with the product.
2. Do not use an extension cord.
3. Do not use within 3 metres of a pool or other bodies of water
and do not use in a bathroom.
READ AND SAVE THESE INSTRUCTIONS
SHARK TF200SUK SERIES PRODUCT INFORMATION
According to:
Commission Regulation (EU) 206/2012 implementing Directive 2009/125/EC of the European Parliament and of the Council with regard to
eco-design requirements for air conditioners and comfort fans.
NOTE DESCRIPTION SYMBOL VALUE UNIT
Maximum
Flow Rate
F 43.42 m3/min
Fan Power
Input
P 90 W
Service Value SV
0.51
(m3/min)/W
Standy Power
Consumption
P
SB
0.27
W
Horizontal
Fan Sound
Power Level
L
wa 62.2 dB(A)
Vertical
Fan Sound
Power Level
L
wa 62.2 dB(A)
Maximum
Air Velocity
c 2.3 m/s
Measurement
standard for
service value
IEC 60879
Batteries (2x)
Remote
Includes:
SETTING UP YOUR FAN
Please be sure to read and save the warnings on other side prior to using your unit.
1. Remove base from packaging,
place on an even surface.
2. Use assembly stickers to
align the red arrow printed
on the Pole with the red
arrow printed on the Base.
Twist the Pole clockwise
to lock it into the Base.
Remove tape after assembly
has been completed.
3. Remove tape and cardboard
from Pole. Line up the printed
red circle on the Blade with
the red circle on the inner
Pole. Press the Blade firmly
into the Pole until it clicks
into place. Remove all
assembly tape on Base and
Pole.
QUICK START GUIDE
2 31
FEATURES
CUSTOMISABILITY
Power On
Press button on base or remote
Press to turn the unit on or o.
Fan Speeds
Press and hold button on base
or press on remote
Press the fan icon on the remote or hold down the power button on the unit to switch between fan speeds 1-10.
LED lights will indicate selected fan speed.
Specialty Modes
Remote only
Setting 1: Sleep Mode. For 8 hours the fan will adjust to the best setting for ambient noise, whilst dimming lights and
muting chimes
.
Setting 2: BreezeBoost Mode. Fan will create high speed airflow above speed setting 10.
Setting 3: NaturalBreeze Mode. Fan will create varying airflow patterns to simulate natural wind.
Setting 4: O.
Oscillation
Remote only
Timer
Remote only
Setting 1: 1 Hour
Setting 2: 2 Hours
Setting 3: 4 Hours
Setting 4: 8 Hours
Setting 5: 12 Hours
Press the
timer icon on the remote to switch between timer
settings of 1-12 hours. LED lights will indicate how many hours the
timer is set for.
LEDs will switch o after 20 seconds. To check how long is left
on the timer, press the
timer icon and LED lights will appear.
Horizontal Angle Adjust
Remote only
Press the angle adjust arrows on the remote to change the horizontal angle of the fan from a distance.
TO DISABLE CHIME: Hold down the timer
and oscillation
buttons on the remote at the same time for 3
seconds to disable chiming. Repeat to re-enable.
CARRYING POSITION: Recommended carrying position is to use the handle on the base while simultaneously
supporting the pole.
PIVOT: Manually adjust
the fan blade left
or right to increase
horizontal coverage.
TILT: Manually rotate
the blades to increase
horizontal coverage.
TELESCOPE: Manually adjust
the height of the fan up or
down.
Magnetically store REMOTE
on back of the fan.
DUST DEFENCE panel protects
the interior of the unit.
Base &
Base Plate
Pole
and
Blade
(1x)
Blade
(1x)
B
B
A
C
A
CB
Press the oscillation icon on the remote to toggle oscillation. LED
lights will change when oscillation has been selected.
If you’d like
to oscillate the unit when it is horizontal, make sure to place it in a
location where it will not hit any walls or objects.
Setting 1: 45 degrees
Setting 2: 90 degrees
Setting 3: 180 degrees
REMOTE
FAN SPEEDS
• Before first use, insert 2 AAA batteries.
• To replace the battery in the remote,
use 2 AAA batteries.
See “MAINTENANCE” for battery
replacement instructions.
IF YOU PURCHASE A REPLACEMENT
REMOTE: you must pair the remote to
the unit. To do this, press power on the
unit for 5 seconds when in
standby mode. Then press the fan
speed up arrow on the remote.
Changing the FAN SPEED will increase or decrease the airflow of the fan. All models have 10 speeds. For
speeds 6 to 10, all 5 lights will flash before showing additional LEDs to correspond to the current speed.
Press the fan speed arrows on the remote or hold down the power button on the base to switch between
fan speeds 1-10.
UI Display
UI will flash for 20 seconds to allow for pairing. If paired, the unit
will enter fan speed 1 and the UI will show the corresponding
LEDs. If not paired within 20 seconds the LEDs will switch o and
the unit will enter standby mode.
UI Display
Speed 1
Speed 2
Speed 3
Speed 4
Speed 5
Speed 6
Speed 7
Speed 8
Speed 9
Speed 10
When fan speed is selected, the lights will display the correct speed. For speeds 6-10,
all 5 lights will flash before displaying additional lights to show the current speed.
Recommended
Speeds
1 2 3 4 5 6 7 8 9 10
Boost
Nursery
Quiet Sleep
Working From Home
Watching TV
Ambient Noise Sleep
Cooking
Exercise
Hot Day Cool Down
Press
and
hold
Pattern
OSCILLATION
TIMER
SPECIALTY MODES
HORIZONTAL ANGLE ADJUST
Choose between OSCILLATION settings to best suit your needs. To change oscillation settings, press the button to cycle
through options on the REMOTE. To turn o oscillation, press the oscillation button until no LEDs are illuminated.
Choose between TIMER settings to best suit
your needs. Press the
Timer icon on the
remote to switch between timer settings of
1-12 hours. The LED lights will indicate how
many hours the timer is set for. The lights
will switch o after 20 seconds. To check
how long is left on the timer, press the
Timer icon again and the indicator lights will
illuminate again.
Choose between SPECIALTY MODE settings
to best suit your needs. Press the
Specialty Mode icon on the remote to toggle
through the available Specialty Modes. To
deactivate, change the fan speed by pressing
the arrows on the remote or holding down the
button on the unit.
For more information on Specialty Modes
and indicator lights, see the How-To videos
on sharkclean.co.uk.
You can use the remote control to change the horizontal angle of the fan from a distance.
Press the left or right arrows on the remote to adjust the horizontal angle.
UI Display
45 degrees
90 degrees
180 degrees
When oscillation is activated, lights will display to indicate the current angle.
UI Display
1 hour
2 hour
4 hour
8 hour
12 hour
The LED lights will indicate the timer
interval for 20 seconds, then turn o.
UI Display
Sleep Mode: All lights will flash from right
to left.
BreezeBoost Mode: All lights will flash
from left to right.
NaturalBreeze Mode: One light will flash
from left to right.
Sleep
Fan will mute chimes, dim lights, and switch to a fan speed optimised for sleep.
Sleep Mode will turn o automatically after 8 hours. To deactivate, use the Specialty
Mode button and toggle until another mode is selected or switch the unit OFF. When
switched OFF and on again, the fan returns back to last used fan setting.
BreezeBoost Fan will create a high-speed airflow above speed setting 10.
NaturalBreeze Fan will create varying airflow patterns to simulate natural wind.
MAINTENANCE
DUST DEFENCE
REPLACING THE BATTERIES IN THE REMOTE
DUST DEFENCE (CONTINUED) EXTERNAL CLEANING
• Unplug the fan before doing any cleaning or maintenance.
• We recommend cleaning the fan every 6 months, or as needed.
• We recommend changing the batteries in the remote control every 12 months, or as needed.
1. Remove the Dust Defence
panel from the unit by gently
pulling on the finger tab.
Note: the mesh filter does
not need to be removed from
the Dust Defence panel.
1. To access the batteries, push down
gently on the battery door on the back
of the remote, then slide the door
o. Remove the batteries from the
chamber and follow local ordinances
for battery disposal.
2. Insert 2 new AAA batteries into the
remote. Make sure the batteries are
installed in correct orientation as
shown in the battery chamber.
3. Slide the battery door back into place
on the back of the remote.
2. Use a vacuum cleaner on
low speed with a soft brush
attachment OR a cloth/towel
to remove debris from the
Dust Defence panel and
the internal mesh screen.
Do NOT use abrasive
chemical cleaners.
3. OPTIONAL: If debris is stuck between the mesh filter
and the Dust Defence panel, the filter can be removed
by gently pulling it out of the tabs on the panel. Rinse
the filter and the panel with room-temperature tap
water. Allow both the filter and the panel to air-dry for
12 hours before reinstalling. DO NOT use the fan when
the mesh filter is wet.
4. Replace the Dust Defence panel by inserting the tabs on
the bottom of the panel into the indents on the unit and
pushing the panel in until it clicks into place.
To clean the exterior of the fan, wipe it down with a microfiber
cloth dampened with warm, soapy water. To prevent damage,
do not use abrasive chemical cleaners or too much water.
TROUBLESHOOTING AND FREQUENTLY ASKED QUESTIONS
GENERAL USE
Why is telescoping
not working?
Remove the tape after assembly is complete.
How can I switch from
vertical orientation to
horizontal orientation?
To pivot the fan vertically or horizontally, grip one end of the fan blade
and move it to the desired location. The fan has 360 degrees of rotation.
UI / SETTINGS
Why is oscillation not
working and/or the unit
clicking when
oscillation is selected?
The fan comes with tape on the pole and the base to help in the
assembly process. Remove the tape after assembly is complete. If
oscillation is still not working after the tape has been removed, make
sure that all assembly touchpoints are correctly assembled. Twist the
pole clockwise firmly onto the base until it clicks securely into place
to verify that it is installed completely and correctly.
Where do I put
the remote?
Store the remote on the magnetic mount on the top of the pole,
on the sticker that shows an outline of the remote.
Why is my fan
changing speeds
on its own?
The fan may be in NaturalBreeze Mode, which changes automatically to
simulate natural wind. To deactivate a Specialty Mode, press the
Fan Speed icon, or the Specialty Mode button in the top right corner
of the remote.
Why is the remote
not working?
When using the remote control, make sure it is pointed directly at the
LED lights on the front of the fan.
If you purchase a replacement remote control, you must pair it with
the fan before use. To pair the remote with the fan, hold down the
Power button on the fan base for 20 seconds, or until the first and last
lights on the display illuminate, then press the Fan Speed Up arrow on
the remote.
If the remote is not working, you may need to change the batteries. See
the Replacing the Batteries in the Remote section for instructions.
Why is the
fan unsteady?
Make sure the fan has been assembled correctly and that all parts have
been completely clicked into place.
Check the connection points where the pole connects to the base.
Why are the lights dim?
The fan may be in Sleep Mode, which dims the lights. To deactivate,
press the Specialty Mode button in the top right corner of the remote
until Sleep Mode is turned o.
Why did my unit turn
o on its own?
Timer Mode may be activated. The timer will turn the fan o after 1 to
12 hours. To turn o the timer, press the
Timer button until all of the
indicator lights are turned o.
How do I disable
beeping and chiming?
Press and hold the
Timer and Oscillation buttons at the same time
for 3 seconds to disable chiming. Repeat to reactivate chiming sounds.
How do the indicator
lights on the base work?
The 5 lights on the base illuminate in dierent patterns to indicate the
status of available fan functions, including Power, Speed, Oscillation
angle, Timer, and Specialty Modes. In all cases, the lights will turn o
after 20 seconds.
MAINTENANCE
How often should I
clean the fan and the
Dust Defence filter?
We recommend cleaning the fan and the Dust Defence filter every
6 months or as needed.
@sharkhomeUK
IMPORTANT INFORMATION
REGISTER YOUR PURCHASE
sharkclean.uk/register-guarantee
Scan QR code using
mobile device
RECORD THIS INFORMATION
Model Number:
������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������
Serial Number:
��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������
Date of Purchase:
����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������
(Keep receipt)
Store of Purchase:
��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������
TECHNICAL SPECIFICATIONS
Voltage: 220-240V~ 50-60Hz / 3A
Watts: 90W
Benefits of registering your product and creating an account:
• Get easier, faster product support and access to
warranty information
• Access troubleshooting and product care instructions
• Be among the first to know about exclusive product promotions
TIP: You can find the model and serial numbers on the QR code label on the base of the fan.
BATTERY REMOVAL AND DISPOSAL
This remote control uses 2 AAA batteries. When the remote batteries no longer have a
charge, they should be removed from the remote and recycled. DO NOT incinerate or
compost the product with its integral battery or the remote batteries. When your remote
batteries need to be replaced, dispose
of them or recycle them in accordance with local ordinances or regulations.
In some areas, it is illegal to place spent batteries in the trash or in a municipal solid waste
stream. Return spent batteries to an authorised recycling center or to retailer for recycling.
Contact your local recycling center for information on where to drop o the spent batteries.
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
This Owner’s Guide is designed to help you get a complete understanding of your new Shark® fan.
Illustrations may dier from actual product. We are constantly striving to improve our products; therefore the specifications contained herein
are subject to change without notice.
© 2025 SharkNinja Operating LLC. SHARK is a registered trademark in the United Kingdom of SharkNinja Operating LLC.
TF200SUK�IB�A4-Online�250319
MANUFACTURER’S GUARANTEE
When a consumer buys a product in the United Kingdom, they get the benefit of legal
rights relating to the quality of the product (your “legal rights”).
You can enforce your legal rights against your retailer, including Shark if you bought your
Shark appliance from sharkclean.co.uk. However, at Shark we are
so confident about the quality of our products that we give the owner an additional, free
parts and labour manufacturer’s guarantee of up to 2 years.
A household appliance like a Shark Fan appliance constitutes a sizeable investment. Your
new machine needs to work properly for as long as possible. The guarantee it comes with
is an important consideration - and reflects how much confidence the manufacturer has in
its product and manufacturing quality.
The manufacturer’s guarantee does not aect your legal rights.
How long are new Shark machines guaranteed for?
Our manufacturer’s guarantee lasts for one year from the date of purchase as standard, or
for two years if you register your purchase with us within 28 days. There is information on
how to register below.
How do I register my Shark guarantee?
If you have purchased your Shark Fan appliance directly from sharkclean.co.uk your
guarantee is registered automatically. If you bought it from anywhere else, you can
register your guarantee online within 28 days of purchase.
• To register online, please visit sharkclean.co.uk/register-guarantee or scan the QR code
in your instruction manual.
• Keep a note of the date you purchased the machine.
IMPORTANT:
• Keep your receipt if you bought your Shark Fan appliance from anywhere except
sharkclean.co.uk. You will need it to claim under your guarantee.
• The free Shark guarantee only applies in the UK.
What are the benefits of registering my free Shark guarantee?
When you register your guarantee, you will get an extra year of cover. We’ll also have
your details to hand if we ever need to get in touch. If you further agree to receive
communications from us, you can also receive tips and advice on how to get the best out
of your Shark Fan appliance and hear the latest news about new Shark technology and
launches.
What is covered by the free Shark guarantee?
Repair or replacement (at Shark’s option) of your Shark machine, including all parts and
labour.
What is not covered by the free Shark guarantee?
• Normal wear and tear.
• Accidental damage or faults caused by negligent use or care, misuse, neglect, careless
operation or handling of the Shark appliance which is not in accordance with the Shark
Operating Manual supplied with your machine.
• Damage caused by use of the Shark appliance for anything other than normal domestic
household purposes.
• Damage caused by use of parts not assembled or installed in accordance with the
operating instructions.
• Damage caused by use of parts and accessories which are not Shark Genuine
Components
• Faulty installation (except where installed by Shark).
• Repairs or alterations carried out by parties other than Shark or its agents.
How can I claim under the free Shark guarantee?
Contact our customer service helpline on 0800 862 0453. For service hours please visit
our website. It’s free to call, and you’ll be put through to a Shark representative. You’ll also
find online support at support.sharkclean.co.uk.
The Shark representative will go through some troubleshooting with you, and if we
conclude that the item has failed, we will send you a replacement part or a returns label to
send the defective item back to us free of charge. When you have delivered the defective
product to us, we will send you a replacement.
Please remember that the item will need to be boxed when you return it to us, which can be
any suitable box; it does not have to be the original packaging.
Where can I buy genuine Shark spares and accessories?
Shark spares and accessories are developed by the same engineers who developed your
Shark Fan appliance. You’ll find a full range of Shark spares, replacement parts and
accessories for all Shark machines at sharkclean.co.uk. Please remember that damage
caused by the use of non-Shark spares may not be covered under your guarantee.
SharkNinja Europe Ltd,
1st/2nd Floor Building 3150,
Thorpe Park, Century Way,
Leeds, England, LS15 8ZB
sharkclean.co.uk
SharkNinja Germany GmbH,
Rotfeder-Ring 9,
60327 Frankfurt am Main,
Germany
sharkclean.eu
This marking indicates that this product should not be disposed with other household wastes. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material sources. To return your used device, please use the return and collection
systems or contact the retailer where this product was purchased. They can take this product for environmentally safe recycling.
