Owner’s Manual
KP90
ELECTRONIC DRUM PAD
EN
2
The model number, serial number, power requirements, etc., may be found on or near the name plate, which is at the bottom of the unit.
You should note this serial number in the space provided below and retain this manual as a permanent record of your purchase to aid
identification in the event of theft.
Model No.
Serial No.
Die Nummer des Modells, die Seriennummer, der Leistungsbedarf usw. sind auf dem Typenschild, das sich auf der
Unterseite des Geräts befindet, oder in der Nähe davon angegeben. Sie sollten diese Seriennummer an der unten vor-
gesehenen Stelle eintragen und dieses Handbuch als dauerhaften Beleg für Ihren Kauf aufbewahren, um im Fall eines
Diebstahls die Identifikation zu erleichtern.
Modell Nr.
Seriennr.
Le numéro de modèle, le numéro de série, l'alimentation requise, etc., se trouvent sur ou près de la plaque signalétique du produit, située
dans la partie inférieure de l'unité. Notez le numéro de série dans l'espace fourni ci-dessous et conservez ce manuel en tant que preuve
permanente de votre achat afin de faciliter l'identification du produit en cas de vol.
N° de modèle
N° de série
O número de modelo, número de série, requisitos de energia, etc. podem ser encontrados na placa de nome, que está na parte inferior
da unidade. Anote-o no espaço reservado abaixo e guarde este manual como registro de compra permanente para auxiliar na identifica-
ção do produto em caso de roubo.
N° do modelo
N° de série
本产品的型号、序列号、电源要求等规格可能标在铭牌上或铭牌附近，铭牌位于本机底部。请将该序列号
填写到下方的横线上，并妥善保存本说明书，以便在产品被盗时作为永久购买凭证使用。
型号名称
序列号
㑔谝䈌谝⹗꧆ⱱꧏ姳璢鞴銻⮛亥儗遫糌䈕鼨氳ꉿ擀┕䡝ꡭ鲥䋧閲䖼㵫䈌谝鋘ꍖ㏇┖亡狞氫谊┾⟋槴
儗鐁伺傴⢢憡姧╦頇鞙鋘ꍖ♓➘㏇儗遫糌鹁玭侈樧⢢閂⮯鞴銻✳榫
㑔谝
䈌谝
機種名(品番)、製造番号(シリアルナンバー )、電源条件などの情報は、製品の底面にある銘板または銘板付近に表示されて
います。製品を紛失した場合などでもご自身のものを特定していただけるよう、機種名と製造番号については以下の欄にご
記入のうえ、大切に保管していただくことをお勧めします。
機種名
製造番号
3
(weee_eu_en_02)
(weee_eu_de_02)
(weee_eu_fr_02)
(weee_eu_pt_02a)
Information for users on collection and disposal of old equipment:
This symbol on the products, packaging, and/or accompanying documents means that used electrical and electronic products should
not be mixed with general household waste.
For proper treatment, recovery and recycling of old products, please take them to applicable collection points, in accordance with
your national legislation.
By disposing of these products correctly, you will help to save valuable resources and prevent any potential negative effects on
human health and the environment which could otherwise arise from inappropriate waste handling.
For more information about collection and recycling of old products, please contact your local municipality, your waste disposal ser-
vice or the point of sale where you purchased the items.
For business users in the European Union:
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
Information on Disposal in other Countries outside the European Union:
This symbol is only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer
and ask for the correct method of disposal.
Verbraucherinformation zur Sammlung und Entsorgung alter Elektrogeräte
Befindet sich dieses Symbol auf den Produkten, der Verpackung und/oder beiliegenden Unterlagen, so sollten benutzte elektrische
Geräte nicht mit dem normalen Haushaltsabfall entsorgt werden.
In Übereinstimmung mit Ihren nationalen Bestimmungen bringen Sie alte Geräte bitte zur fachgerechten Entsorgung, Wiederaufbe-
reitung und Wiederverwendung zu den entsprechenden Sammelstellen.
Durch die fachgerechte Entsorgung der Elektrogeräte helfen Sie, wertvolle Ressourcen zu schützen, und verhindern mögliche nega-
tive Auswirkungen auf die menschliche Gesundheit und die Umwelt, die andernfalls durch unsachgerechte Müllentsorgung auftreten
könnten.
Für weitere Informationen zum Sammeln und Wiederaufbereiten alter Elektrogeräte kontaktieren Sie bitte Ihre örtliche Stadt- oder
Gemeindeverwaltung, Ihren Abfallentsorgungsdienst oder die Verkaufsstelle der Artikel.
Information für geschäftliche Anwender in der Europäischen Union:
Wenn Sie Elektrogeräte ausrangieren möchten, kontaktieren Sie bitte Ihren Händler oder Zulieferer für weitere Informationen.
Entsorgungsinformation für Länder außerhalb der Europäischen Union:
Dieses Symbol gilt nur innerhalb der Europäischen Union. Wenn Sie solche Artikel ausrangieren möchten, kontaktieren Sie bitte Ihre
örtlichen Behörden oder Ihren Händler und fragen Sie nach der sachgerechten Entsorgungsmethode.
Informations concernant la collecte et le traitement des déchets d’équipements électriques et électroniques
Le symbole sur les produits, l'emballage et/ou les documents joints signifie que les produits électriques ou électroniques usagés ne
doivent pas être mélangés avec les déchets domestiques habituels.
Pour un traitement, une récupération et un recyclage appropriés des déchets d’équipements électriques et électroniques, veuillez les
déposer aux points de collecte prévus à cet effet, conformément à la réglementation nationale.
En vous débarrassant correctement des déchets d’équipements électriques et électroniques, vous contribuerez à la sauvegarde de
précieuses ressources et à la prévention de potentiels effets négatifs sur la santé humaine qui pourraient advenir lors d'un traitement
inapproprié des déchets.
Pour plus d'informations à propos de la collecte et du recyclage des déchets d’équipements électriques et électroniques, veuillez
contacter votre municipalité, votre service de traitement des déchets ou le point de vente où vous avez acheté les produits.
Pour les professionnels dans l'Union européenne :
Si vous souhaitez vous débarrasser des déchets d’équipements électriques et électroniques, veuillez contacter votre vendeur ou
fournisseur pour plus d'informations.
Informations sur la mise au rebut dans d'autres pays en dehors de l'Union européenne :
Ce symbole est seulement valable dans l'Union européenne. Si vous souhaitez vous débarrasser de déchets d’équipements élec-
triques et électroniques, veuillez contacter les autorités locales ou votre fournisseur et demander la méthode de traitement appropriée.
Informações para os utilizadores relativas à recolha e eliminação de equipamentos usados
Este símbolo, presente em produtos, embalagens e/ou incluído na documentação associada, indica que os produtos elétricos e ele-
trónicos usados não devem ser eliminados juntamente com os resíduos domésticos em geral.
O procedimento correto consiste no tratamento, recuperação e reciclagem de produtos usados, pelo que deve proceder à respetiva
entrega nos pontos de recolha adequados, em conformidade com a legislação nacional em vigor.
A eliminação destes produtos de forma adequada permite poupar recursos valiosos e evitar potenciais efeitos prejudiciais para a
saúde pública e para o ambiente, associados ao processamento incorreto dos resíduos.
Para mais informações relativas à recolha e reciclagem de produtos usados, contacte as autoridades locais, o serviço de eliminação
de resíduos ou o ponto de venda onde foram adquiridos os itens relevantes.
Informações para utilizadores empresariais na União Europeia:
Para proceder à eliminação de equipamento elétrico e eletrónico, contacte o seu revendedor ou fornecedor para obter informações
adicionais.
Informações relativas à eliminação em países não pertencentes à União Europeia:
Este símbolo é válido exclusivamente na União Europeia. Caso pretenda eliminar este tipo de itens, contacte as autoridades locais
ou o seu revendedor e informe-se acerca do procedimento correto para proceder à respetiva eliminação.
4
MEMO
5
English
The purpose of the precautions detailed below is to ensure that this product is used safely without fear either of accidental
injury to you or other people or of damage to property. As a means, furthermore, of indicating the severity and immediacy
of any risk of injury or damage associated with incorrect operation, these precautions are classified as either WARNING or
CAUTION. The instructions presented together with precautions are extremely important in terms of ensuring safety, and
therefore, they should be fully observed.
*: After reading this Owner’s Manual, ensure that it is kept in a safe, convenient location for future reference.
NOTICE
• Do not expose the product to rain, use it near water or in damp or wet conditions, or place on it any containers (such as
vases, bottles or glasses) containing liquids which might spill into any openings. Doing so can result in possibility cause
malfunction or damage to the product.
• Avoid using or storing this product in very hot locations (i.e., in direct sunlight, in close proximity to a heater, or in a closed
vehicle) or in highly-humid locations (i.e., in a bathroom or outdoors in wet weather). Failure to observe this precaution
can lead to warping, discoloration, malfunction, or breakdown.
• Avoid cleaning this product with organic solvents, paint thinner, or alcohol as these substances can cause warping and
discoloration. Instead, we recommend that you remove dust using a soft dry cloth or wipe clean using a moist, tightly-
wrung cloth. If the product is very dirty, wipe the dirt away using a cloth moistened with a neutral detergent solution and
tightly wrung. Following this, wipe away the detergent solution using a cloth soaked in water and tightly wrung.
• When connecting and disconnecting cables, be sure to hold the plug and not the cable itself. In addition, avoid placing
heavy items on top of cables, and do not allow them to come into contact with sharp edges and the like. Failure to avoid
these precautions can to cable breakage and unintended disconnection.
INFORMATION
• The illustrations as shown in this manual are for instructional purposes only, and may appear somewhat different from
those on your product.
• The company names and product names in this manual are the trademarks or registered trademarks of their respective
companies.
PRECAUTIONS Please read carefully before Proceeding.
WARNING
Always follow the basic precautions listed below to avoid the possibility of seri-
ous injury or even death from fire or other hazards. These precautions include,
but are not limited to, the following:
• Do not put burning items, such as candles, near the unit. A burning item may fall over and cause a fire.
CAUTION
Always follow the basic precautions listed below to avoid the possibility of physi-
cal injury to you or others, or damage to the instrument or other property. These
precautions include, but are not limited to, the following:
• Assemble this product in the proper sequence by following the assembly instructions in this manual. Also, make sure to
tighten the bolts regularly. Failure to do so might result in damage to the product or even injury.
• When assembling this product (i.e., when connecting the base or a foot pedal to the body), take care to avoid squeez-
ing, crushing, or otherwise injuring fingers, feet, and other body parts.
• The tips of the anti-slip stoppers have sharp points. In order to avoid injury, therefore, special care should be taken
whenever handling these items.
• Do not setup this product on an incline, on an unstable platform, or on any other unsafe surface. If this precaution is not
observed, the product may topple over or fall, resulting in injury or equipment damage.
• Be sure to securely tighten bolts and other fasteners when setting up this product. In addition, be sure to proceed slowly
when loosening bolts. If this precaution is not observed, the product may fall or topple over, resulting in injury or equip-
ment damage.
• Whenever setting up this product, ensure that cables and the like are arranged safely. If anyone were to trip on a cable,
the product could topple over and cause injury.
• Under no circumstances should this product be disassembled or customized. Failure to observe this precaution can
result in injury or malfunction.
• Do not rest your weight on, or place heavy objects on the product, and do not use excessive force on the knob, jack or connector.
• Keep small parts out of the reach of infants. Your children may accidentally swallow them.
Yamaha cannot be held responsible for damage caused by improper use or modifications to the product.
Precautions
6
Precautions .................................................................. 5
Package Contents........................................................ 7
Specifications............................................................... 7
Assembling the KP90................................................... 8
Making Connections .................................................... 9
Adjusting the Output Level......................................... 10
Troubleshooting.......................................................... 10
Contents
7
*: If you have purchased a pad set, please refer to the “Assembly Manual” that came with it.
KP90: q KP90 main unit × 1 (a: body × 1, b: base × 1)
w Stereo phone cable × 1
e Anti-slip stoppers (incl. springs) × 2
r Owner’s Manual (this booklet) × 1
Package Contents
* Foot pedal is sold separately.
Specifications
KP90 Kick Pad
Size (assembled): 335 (w) × 299 (d) × 438 (h) mm
Weight: 4.4 kg
Sensing method: Piezoelectric trigger-sensor element × 1
Output connector: Standard stereo phone jack
Input connector: Standard mono phone jack
*: The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the
Yamaha website then download the manual file. Since specifications, equipment or separately sold accessories may not be the same
in every locale, please check with your Yamaha dealer.
q a
q b
e
w
8
1.
As shown in the illustration, remove the base attachment wing bolts q, and use them to attach the base w to the main
body e. Do not fully tighten the wing bolts in this step.
If damage to the floor is not a concern, connect the spurs r to the base so that the tip of the spurs dig into
the riser or floor. To prevent damage to the floor, retract the spurs r, place a mat or carpet under the KP90
and use the Velcro™ strip t, attached to the underside of the KP90’s base to prevent the KP90 from moving
during performance.
2. Attach your foot pedal to the KP90. Adjust the base’s position so that the pad surface of the KP90 is vertical when the
foot pedal is attached, and the KP90 is stable when the beater hits the pad. After the position is determined, firmly
tighten the wing bolts q to secure.
3. Adjust the position of the pedal and the length of the beater shaft so that the foot pedal’s beater y hits in the center of
the kick pad u.
The KP90 can be used with a double foot pedal (YAMAHA DFP series, etc). When using a double foot pedal,
please adjust the position of the pedal and the length of the beater y so that the space between the two
beaters is positioned in the center of the pad. [Fig. A]
Assembling the KP90
q
e
w
e
u
y
q
t
r
1
23
w
y
u
Figure A
9
Using a stereo phone cable q (included), connect the KP90’s OUTPUT jack w to an appropriate input jack on a DTX
Series drum trigger module. Be sure to connect the L-shaped end of the cable to the KP90.
• On the drum trigger module, set the corresponding pad type as a kick pad. Setting of any other pad type
may have unintended consequences such as double triggering (where a single strike produces two dis-
tinct sounds). For more details, refer to the Owner’s Manual that came with the drum trigger module.
• If using the KP90 as a standalone pad with no other pad connected to it, a mono phone cable can also be
used to make this connection to the drum trigger module.
Connecting an additional pad
The PAD INPUT jack e provided on the KP90 can be used to add an additional pad (sold separately). To do so, connect
the output connector on the additional pad to the PAD INPUT jack e using a mono or stereo phone cable.
• When connecting a drum trigger module and a KP90 having a pad connected via its PAD INPUT jack e, the
most suitable jack will depend on the type of module being used. For more details, refer to the Owner’s
Manual that came with the drum trigger module.
• When you hit a pad connected to the PAD INPUT jack e, only the main surface (head or pad on the snare/
tom pad, or bow on the hi-hat/cymbal pad) produce sound. No sound will be produced on any other sec-
tion, such as the rim or edge. In addition, special functions using the rim switch (such as choking and mut-
ing) will not supported in such a case.
Making Connections
w
q
e
ELECTRONIC DRUM PAD
10
The output level from the KP90 can be raised by turning the level adjuster q clockwise and vice-versa. Be sure to adjust
this level to best suit the strength with which you strike the pad, your desired dynamic range (i.e., the difference between
loudest and quietest volumes), and the type of DTX Series drum trigger module being used. If the level adjustment knob is
turned all the way up but the output level is still low, raise the DTX Series Drum Trigger Module’s input level using the Gain
parameter from the trigger area.
If playing fortissimo (ff) passages with the KP90 connected to a DTX Series drum trigger module, the gain level
on the module’s trigger setup screen should be adjusted to between 90% and 95% of the displayed input level.
For more details, refer to the Owner’s Manual that came with the drum trigger module. Excessively large output
levels can have unintended consequences such as a reduced dynamic range and double triggering (where a sin-
gle strike produces two distinct sounds).
No sound is produced or the volume is too low.
Ensure that the KP90 is correctly connected to a DTX Series drum trigger module using the stereo phone cable pro-
vided. (See Making Connections.)
Check the pad’s output level. If this level is too low, use the level adjuster to increase it. (See Adjusting the Output Level.)
If no sound is produced when the pad is struck softly, lower the setting of the Minimum Level parameter from the mod-
ule’s trigger area.
Check that the base’s position is adjusted so that the beater hits the center of the pad correctly. (See Assembling the
KP90.)
Two or more sounds are produced in response to a single strike (i.e., double-triggering).
Check the pad’s output level. If this level is too high, use the level adjuster to reduce it. Note that triggering of two or
more sounds occurs when the output level is excessively high due to the fact that the signal being input into the drum
trigger module remains large for a relatively long period of time. (See Adjusting the Output Level.)
For more troubleshooting tips, refer to the Owner’s Manual that came with the DTX Series drum trigger module. If
you still cannot find the information you need to resolve a problem, please contact your Yamaha dealer or the cus-
tomer support center indicated at the end of this manual for assistance.
Adjusting the Output Level
Troubleshooting
q
Drums Limited Warranty
LIMITED WARRANTY ON YAMAHA DRUMS, HARDWARE AND ACCESSORY PRODUCTS
Thank you for selecting a YAMAHA product. YAMAHA products are designed and manufactured to provide a high level of defect-free
performance. Yamaha Corporation of America (“YAMAHA”) is proud of the experience and craftsmanship that goes into each and every
YAMAHA product. YAMAHA sells its products through a network of reputable, specially authorized dealers and is pleased to offer you, the
Original Owner, the following Limited Warranty, which applies only to products that have been (1) directly purchased from YAMAHA’s
authorized dealers in the fifty states of the USA and District of Columbia (the “Warranted Area”) and (2) used exclusively in the Warranted
Area. YAMAHA suggests that you read the Limited Warranty thoroughly, and invites you to contact your authorized YAMAHA dealer or
YAMAHA Customer Service if you have any questions.
THIS WARRANTY COVERS THE LISTED PRODUCTS AGAINST DEFECTS IN MATERIALS OR WORKMANSHIP.
Warranty Term
Duration of Warranty from Date of
Type of Product Purchase by or for the Original Owner
Acoustic Drum Shells, Finish, Drum Hardware, Freestanding Hardware, Pedals, Hardware Accessories 5 Years
Electronic Drums Modules, Pads, Accessories, Hardware, Pedals 1 Year
Coverage: YAMAHA will, at its option, repair or replace the product covered by this warranty if it becomes defective, malfunctions or
otherwise fails to conform with this warranty under normal use and service during the term of this warranty, without charge for labor or
materials. Repairs may be performed using new or refurbished parts that meet or exceed YAMAHA specifications for new parts. If
YAMAHA elects to replace the product, the replacement may be a reconditioned unit. You will be responsible for any installation or
removal charges and for any initial shipping charges if the product(s) must be shipped for warranty service. However, YAMAHA will pay
the return shipping charges to any destination within the USA if the repairs are covered by the warranty. This warranty does not cover (a)
damage, deterioration or malfunction resulting from accident, negligence, misuse, abuse, improper installation or operation or failure to
follow instructions according to the Owner’s Manual for this product; any shipment of the product (claims must be presented to the
carrier); repair or attempted repair by anyone other than YAMAHA or an authorized YAMAHA Service Center; (b) any unit which has been
altered or on which the serial number has been defaced, modified or removed; (c) normal wear and any periodic maintenance; (d)
deterioration due to perspiration, corrosive atmosphere or other external causes such as extremes in temperature or humidity; (e)
damages attributable to power line surge or related electrical abnormalities, lightning damage or acts of God; or (f) RFI/EMI (Interference/
noise) caused by improper grounding or the improper use of either certified or uncertified equipment, if applicable. Any evidence of
alteration, erasing or forgery of proof-of-purchase documents will cause this warranty to be void. This warranty covers only the Original
Owner and is not transferable.
In Order to Obtain Warranty Service: Warranty service will only be provided for defective products within the Warranted Area. Contact
your local authorized YAMAHA dealer who will advise you of the procedures to be followed. If this is not successful, contact YAMAHA at
the address, telephone number or website shown below. YAMAHA may request that you send the defective product to a local authorized
YAMAHA Servicer or authorize return of the defective product to YAMAHA for repair. If you are uncertain as to whether a dealer has been
authorized by YAMAHA, please contact YAMAHA’s Service Department at the number shown below, or check Yamaha’s website at https://
usa.yamaha.com. Product(s) shipped for service should be packed securely and must be accompanied by a detailed explanation of the
problem(s) requiring service, together with the original or a machine reproduction of the bill of sale or other dated, proof-of-purchase
document describing the product, as evidence of warranty coverage. Should any product submitted for warranty service be found
ineligible therefore, an estimate of repair cost will be furnished and the repair will be accomplished only if requested by you and upon
receipt of payment or acceptable arrangement for payment.
Limitation of Implied Warranties and Exclusion of Damages: ANY IMPLIED WARRANTIES, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE SHALL BE LIMITED IN DURATION TO THE APPLICABLE PERIOD OF
TIME SET FORTH ABOVE. YAMAHA SHALL NOT BE RESPONSIBLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OR FOR
DAMAGES BASED UPON INCONVENIENCE, LOSS OF USE, DAMAGE TO ANY OTHER EQUIPMENT OR OTHER ITEMS AT THE SITE OF
USE OR INTERRUPTION OF PERFORMANCES OR ANY CONSEQUENCES. YAMAHA’S LIABILITY FOR ANY DEFECTIVE PRODUCT IS
LIMITED TO REPAIR OR REPLACEMENT OF THE PRODUCT, AT YAMAHA’S OPTION. SOME STATES DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. This Warranty gives you specific legal rights, and you may also have
other rights which vary from state to state. This is the only express warranty applicable to the product specified herein; Yamaha neither
assumes nor authorizes anyone to assume for it any other express warranty.
If you have any questions about service received or if you need assistance in locating an authorized YAMAHA Servicer, please contact:
CUSTOMER SERVICE
Yamaha Corporation of America
6600 Orangethorpe Avenue, Buena Park, California 90620-1373
Telephone: 800-854-1569 • https://usa.yamaha.com
Do not return any product to the above address without a written Return Authorization issued by YAMAHA.
Yamaha Worldwide Representative Offices
For details on the product(s), contact your nearest Yamaha
representative or the authorized distributor, found by accessing
the 2D barcode below.
English
Wenden Sie sich für nähere Informationen zu Produkten an eine
Yamaha-Vertretung oder einen autorisierten Händler in Ihrer Nähe.
Diese finden Sie mithilfe des unten abgebildeten 2D-Strichodes.
Deutsch
Pour obtenir des informations sur le ou les produits, contactez
votre représentant ou revendeur agréé Yamaha le plus proche.
Vous le trouverez à l'aide du code-barres 2D ci-dessous.
Français
Para ver información detallada sobre el producto, contacte con
su representante o distribuidor autorizado Yamaha más cercano.
Lo encontrará escaneando el siguiente código de barras 2D.
Español
Neem voor meer informatie over de producten contact op met uw
dichtstbijzijnde Yamaha-vertegenwoordiger of de geautoriseerde
distributeur, te vinden via de onderstaande 2D-barcode.
Nederlands
Para mais informações sobre o(s) produto(s), fale com seu
representante da Yamaha mais próximo ou com o distribuidor
autorizado acessando o código de barras 2D abaixo.
Português
$E\X]\VNDüV]F]HJyáRZHLQIRUPDFMHQDWHPDWSURGXNWyZ
VNRQWDNWXMVLĊ]QDMEOLĪV]\PSU]HGVWDZLFLHOHPILUP\<DPDKDOXE
autoryzowanym dystrybutorem, którego znajdziesz za
SRĞUHGQLFWZHPSRQLĪV]HJRNRGXNUHVNRZHJR'
Polski
ɑɬɨɛɵɭɡɧɚɬɶɩɨɞɪɨɛɧɟɟɨɩɪɨɞɭɤɬɟɩɪɨɞɭɤɬɚɯɫɜɹɠɢɬɟɫɶ
ɫɛɥɢɠɚɣɲɢɦɩɪɟɞɫɬɚɜɢɬɟɥɟɦɢɥɢɚɜɬɨɪɢɡɨɜɚɧɧɵɦ
ɞɢɫɬɪɢɛɶɸɬɨɪɨɦ<DPDKDɜɨɫɩɨɥɶɡɨɜɚɜɲɢɫɶɞɜɭɯɦɟɪɧɵɦ
ɲɬɪɢɯɤɨɞɨɦɧɢɠɟ
Ɋɭɫɫɤɢɣ
Om du vill ha mer information om produkterna kan du kontakta
närmaste Yamaha-representant eller auktoriserade distributör
med hjälp av 2D-streckkoden nedan.
Svenska
Hvis du vil have detaljer om produktet/produkterne, kan du kontakte den
nærmeste Yamaha-repræsentant eller autoriserede Yamaha-distributør,
som du finder ved at scanne 2D-stregkode nedenfor.
Dansk
https://manual.yamaha.com/mi/address_list/
Head Office/Manufacturer: Yamaha Corporation 10-1, Nakazawa-cho, Chuo-ku, Hamamatsu, 430-8650, Japan
Importer (European Union): Yamaha Music Europe GmbH Siemensstrasse 22-34, 25462 Rellingen, Germany
Importer (United Kingdom): Yamaha Music Europe GmbH (UK) Sherbourne Drive, Tilbrook, Milton Keynes, MK7 8BL, United Kingdom
DMI37_22m
Per dettagli sui prodotti, contattare il rappresentante Yamaha o
il distributore autorizzato più vicino, che è possibile trovare
tramite il codice a barre 2D in basso.
Italiano
3RGUREQRVWLRSURGXNWXHFK]tVNiWHRGQHMEOLåãtKR]iVWXSFH
VSROHþQRVWL<DPDKDQHERDXWRUL]RYDQpKRGLVWULEXWRUDNWHUêE\O
QDOH]HQSĜLSRXåLWt'þiURYpKRNyGXQtåH
ýHãWLQD
3RGUREQpLQIRUPiFLHRSURGXNWHRFKYiPSRVN\WQHQDMEOLåãt
]iVWXSFDVSRORþQRVWL<DPDKDDOHERDXWRUL]RYDQêGLVWULE~WRU
NWRUpKRQiMGHWHSRPRFRXQLåãLHXYHGHQpKR'þLDURYpKRNyGX
6ORYHQþLQD
A termék(ek)re vonatkozó részletekért forduljon a legközelebbi
Yamaha képviselethez vagy a hivatalos forgalmazóhoz, amelyet
az alábbi 2D vonalkód segítségével találhat meg.
Magyar
ýHåHOLWHSRGUREQHMãHLQIRUPDFLMHRL]GHONLKVHREUQLWHQD
QDMEOLåMHJD<DPDKLQHJDSUHGVWDYQLNDDOLSRREODãþHQHJD
distributerja, ki ga najdete prek 2D-kode v nadaljevanju.
6ORYHQãþLQD
/DLLHJnjWXSODãƗNXLQIRUPƗFLMXSDUL]VWUƗGƗMXPLHPVD]LQLHWLHV
DUWXYƗNR<DPDKDSƗUVWƗYLYDLSLOQYDURWRL]SODWƯWƗMXNXUX
DWUDGƯVLHWL]PDQWRMRWWƗOƗNSLHHMDPR'VYƯWUNRGX
/DWYLHãX
Ɂɚɩɨɞɪɨɛɧɨɫɬɢɨɬɧɨɫɧɨɩɪɨɞɭɤɬɚɢɬɟɫɟɫɜɴɪɠɟɬɟɫɧɚɣɛɥɢɡɤɢɹ
ɩɪɟɞɫɬɚɜɢɬɟɥɧɚ<DPDKDɢɥɢɨɬɨɪɢɡɢɪɚɧɞɢɫɬɪɢɛɭɬɨɪɤɨɣɬɨ
ɦɨɠɟɬɟɞɚɨɬɤɪɢɟɬɟɤɚɬɨɢɡɩɨɥɡɜɚɬɟ'ɛɚɪɤɨɞɚɩɨɞɨɥɭ
Ȼɴɥɝɚɪɫɤɢ
1RUơGDPLJDXWLGDXJLDXLQIRUPDFLMRVDSLHJDPLQƳLXV
NUHLSNLWơVƳDUWLPLDXVLąÄ<DPDKD³DWVWRYąDUEDƳJDOLRWąMƳ
SODWLQWRMąNXUƳUDVLWHQXVNDLWĊWROLDXSDWHLNWą'EUnjNãQLQƳNRGą
/LHWXYLǐ
Toodete kohta täpsema teabe saamiseks võtke ühendust lähima
Yamaha esindaja või autoriseeritud levitajaga, kelle leiate
allpool asuva 2D-vöötkoodi kaudu.
Eesti
hUQOHUKDNNÕQGDD\UÕQWÕODULoLQDúD÷ÕGDNL'NRGOXPRWRUD
HULúHUHNEXOXQDQVL]HHQ\DNÕQ<DPDKDWHPVLOFLVLQHYH\D\HWNLOL
ED\L\HEDúYXUXQ
Türkçe
Za detalje o proizvodima obratite se lokalnom predstavku ili
RYODãWHQRPGLVWULEXWHUXWYUWNH<DPDKDNRMHJPRåHWHSURQDüL
VNHQLUDQMHP'FUWLþQRJNRGDXQDVWDYNX
Hrvatski
3HQWUXGHWDOLLSULYLQGSURGXVHOHFRQWDFWD܊LFHOPDLDSURSLDW
reprezentant Yamaha sau distribuitorul autorizat, pe care îl
SXWH܊LJăVLDFFHVkQGFRGXOGHEDUH'GHPDLMRV
5RPkQă
©2020 Yamaha Corporation
Published 10/2025
IP-B0
