PARTYCON BOOST
EN User Manual Bluetooth Speaker PARTYCON BOOST
CZ
Uživatelská příručka BTreproduktor PARTYCON BOOST
SK
Používateľská príručka BTreproduktor PARTYCON BOOST
HU
Felhasználói kézikönyv PARTYCON BOOST BT hangszóró
PL
Podręcznik użytkownika Głośnik BT PARTYCON BOOST
EN – 2
PACKAGE CONTENTS
1× BT Speaker PARTYCON BOOST
1× Remote Control
1× Wireless Microphone
1× FM Antenna
1× Power Cable
1× User Manual
BT SPEAKER DESCRIPTION
EN – 3
Front Side of PARTYCON BOOST
A Tweeter speaker (L – left audio channel, R – right audio channel)
B Wideband speaker (L – left audio channel, R – right audio channel)
C Bottom of the BT speaker (wheels for easy movement)
D LED effects (L – left LED effect, R – right LED effect, F – full front LED effect)
E Remote control sensor
Top Side of PARTYCON BOOST
F Design elements of the BT speaker
G Handle for easy carrying (1 – rear handle, 2 – front handle)
I Smart device holder
1 Volume control knob for guitar input
2 Track/Album repeat button when playing from USB and memory card
– 1x press – track repeat
– 2x press – album repeat
– 3x press – function off
3 Volume control knob for microphone input (common control for wired and wireless microphone)
4 ECHO control knob for microphone input (common control for wired and wireless microphone)
5 REC button – microphone recording control on USB / memory card
– 1x short press to start recording "START RECORDING"
– 1x short press to stop recording
– 1x long press during recording playback deletes the recording file
6 Volume control knob for BT speaker
– volume down (turn to the left)
– volume up (turn to the right)
7 Light effects button
– 1x short press – change LED effect
– 1x long press – turn off LED effect
8 EQ button – change equalizer (two preset equalizers)
9 TWS button
– 1x short press – function enabled
– 1x short press – function disabled
10 Mute button in music playback
11 Bluetooth button
– 1x short press
– switch from another audio source to BT source
– 1x long/short press
– disconnect BT speaker from connected mobile device
12 “M” button – change source (Bluetooth, FM, AUX- IN, USB, memory card)
13 PLAY/PAUSE button
– 1x short press
– start playback (music playback mode)
– 1x short press
– pause playback (music playback mode)
– 1x long press
– search available FM stations and store them in memory (FM mode)
14 Battery status LED indicator (approximate)
15 Function on LED indicator
EN – 4
16 Previous track button
– 1x short press
– go to the previous track (music playback mode)
– go to the previous FM station (FM mode)
– 1x long press
– rewind track (music playback mode)
– search FM stations downwards (FM mode)
17 Next track button
– 1x short press
– go to the next track (music playback mode)
– go to the next FM station (FM mode)
– 1x long press
– fast-forward track (music playback mode)
– search FM stations upwards (FM mode)
Back Side of PARTYCON BOOST
18 Guitar jack input (6.3 mm)
19 USB – for mobile device charging 5 V; 1 A
20 Charging status LED indicator
– red LED BT speaker is charging
– green LED BT speaker is fully charged
21 AUX-IN mini jack audio input (3.5 mm)
22 Memory card slot – micro
23 USB-A for playback from memory device
24 Jack microphone input (6.3 mm)
25 SWITCH
I – BT speaker power on battery
0 – off
II – BT speaker power on from AC 100 ~ 240 V; 50/60 Hz
26 Input for FM antenna
27 Power/charging from AC 100 ~ 240 V; 50/60 Hz
Wireless Microphone
28 Sound sensor
29 LED indicator (on/off)
30 ON/OFF button
31 Compartment for 2x AA 1.5 V batteries (not included)
Remote Control
32 REC button – microphone recording control on USB / memory card
– 1x short press to start recording "START RECORDING"
– 1x short press to stop recording
– 1x long press during recording playback deletes the recording file
33 PLAY/PAUSE button
34 Previous track button
35 EQ button – change equalizer
36 Mute button in music playback
37 Microphone volume down button
38 ECHO level down button
39 Track/Album repeat button when playing from USB and memory card
40 Change LED effect of BT speaker
41 Increase volume button
42 Next track button
EN – 5
43 Decrease volume button
44 Change source button (Bluetooth, FM, AUX-IN, USB, memory card)
45 Music mute button when microphone is active
46 Microphone volume up button
47 ECHO level up button
48 Compartment for 2x AAA 1.5 V batteries (not included)
PUTTING INTO OPERATION
Before first use, thoroughly read the safety instructions in this user manual.
Before first use of the BT speaker, it is recommended to fully charge the batteries.
On the back side of the BT speaker, you will find a switch to power on the BT speaker.
I – BT speaker power on battery
0 – off
II – BT speaker power on from AC 100 ~ 240 V; 50/60 Hz
Switch to the "on" position and wait until the BT speaker greets you with an acoustic signal.
Warning: The "I" battery-powered mode is not suitable for listening to loud and dynamic music. If you
require maximum performance from the BT speaker, it is recommended to listen in "II" mode powered
from the mains.
TRANSPORT AND POSITIONING OF THE BT SPEAKER /
SMART DEVICE HOLDER
– Use handles "G1" and "G2" located on the top of the BT speaker for transportation.
– Use the wheels on the bottom of the BT speaker "C" for easier movement. Hold the BT speaker
by handle "G1" and tilt it towards the rear. Pull the BT speaker. After moving, place the BT speaker
steadily on the rubber feet.
– The speaker offers 1 positioning option. The correct position side is equipped with rubber feet on the
bottom of the BT speaker "C".
– The smart device holder is located at the top of the BT speaker "I". Before placing your smart device
in the holder, ensure it fits securely and will not fall out. When playing music at higher volumes, the
BT speaker may vibrate, causing your smart device to fall out of the holder.
Note: Always position the device so that it does not endanger the health of persons in the vicinity or
cause damage to property.
PAIRING DEVICES VIA BLUETOOTH
Turn on the BT speaker and search for its Bluetooth name “PARTYCON BOOST” in the device to be
paired, then start the pairing process. If you are requested to enter a pairing code while your device
and the BT speaker are pairing, use the code: “0000”. To disconnect the paired device, end the pairing
session on your mobile device or long-press the Bluetooth button. Disconnection will be indicated by an
acoustic signal.
Note: To ensure a stable Bluetooth connection, maintain a distance of up to 10 metres between the BT
speaker and the connected device.
EN – 6
TWS FEATURE
If you purchase another Bluetooth speaker (“PARTYCON BOOST”), you can pair them together for
optimal stereo sound. First, make sure your device is not connected to any of the BT speakers. Turn
both BT speakers on, press and hold the TWS button, and wait for the BT speakers to pair automatically.
Successful pairing will be accompanied by an acoustic signal. Then connect your mobile device to one of
the BT speakers.
Changing the volume level using the volume control knobs will automatically affect both paired BT
speakers. To exit TWS mode, press and hold the TWS button on one of the BT speakers until you hear
the acoustic signal indicating successful disconnection.
Warning: The TWS feature is only available in the Bluetooth mode. It is not possible to pair devices with
a different type of BT speaker with TWS feature or within different product editions with different Bluetooth
names.
AUDIO AUX IN
The BT speaker is equipped with a 3.5 mm Jack. Switch the input source "M" to AUX-IN mode and
connect your device to the BT speaker using an audio cable. First connect the audio connector to your
device and then to the BT speaker jack.
Note: Before connecting your device and the BT speaker, make sure that the output signal from your
device is at a minimum level (minimum output volume). This will prevent the BT speaker from damage.
When the audio cable is connected, the BT speaker does not meet the water ingress protection class.
Note: In this mode, not all functions of the BT speaker are available. The Bluetooth function is not active if
the audio jack is connected to the BT speaker.
MICROPHONE INPUT / GUITAR INPUT
The BT speaker is equipped with a jack input for connecting one microphone type Jack 6.3 mm and one
guitar type Jack 6.3 mm on the rear side of the BT speaker. After connecting the microphone or guitar, the
input is active.
Input Control
Microphone – volume level and ECHO level changes are controlled on the top of the BT speaker and on
the remote control.
Guitar input – volume level is controlled on the top of the BT speaker.
Warning: Avoid feedback by placing the microphone sufficiently far from the PARTYCON speakers.
Approaching may cause feedback, which may result in damage to the speakers or the hearing of the
person near the BT speaker.
WIRELESS MICROPHONE
One wireless microphone is included in the package. Before first use, insert batteries into the wireless
microphone. Unscrew the bottom part of the wireless microphone and insert two 1.5 V AA batteries.
Always observe the correct battery polarity.
Microphone Control
Turning the microphone on and off.
– To turn on, press and hold the "power on/off" button on the microphone.
EN – 7
LED Indicator
Red blinking LED – the microphone battery is low – charge it
White blinking indication – microphone is connecting to the BT speaker
White blinking indication – successful connection of the microphone to the BT speaker
Warning: Avoid feedback by keeping the microphone sufficiently far from the speakers of the
PARTYCON device. Approaching may cause feedback, which may result in damage to the speakers or
the hearing of the person near the system.
FM RADIO
Connect the supplied FM antenna to the appropriate input on the back of the BT speaker. Stretch the
antenna and position it for best FM reception.
Use the “M” button to switch the BT speaker to FM radio mode. Long press the „PLAY/PAUSE/FM station
search“ button to start searching the FM stations.
After finding and saving stations to the memory of the BT speaker, you can switch between found stations
by short-pressing the "next/previous station in order" button.
VOLUME CONTROL / PLAY AND PAUSE / NEXT AND
PREVIOUS TRACK
The BT speaker volume (+/-) is controlled using the control knob on the BT speaker or buttons on the
remote control. Turn the control knob to the left to decrease the volume. Turn the control knob to the
right to increase the volume. The volume adjustments do not apply to microphone volume settings.
More information about microphone volume settings can be found in the Microphone Input / Wireless
Microphone section.
Caution: Before starting to play music, make sure the volume control is not turned up to the maximum
level.
The PLAY and PAUSE button is used to play/pause music playback via BT or from USB storage device.
In FM mode, the button is used to search for available FM stations.
The next and previous track can be invoked using buttons in BT mode or when playing music from USB
storage device. In FM mode, the buttons are used to switch to the next or previous available FM station.
LIGHT EFFECTS
The BT speaker is equipped with light effects on the front "DF" and sides "DL", "DR" of the device.
Changing the light effect is done by pressing the “light effects” button, 8 light effects are preset. To turn
off the light effects, press and hold the “light effects” button. To turn on the light effects, press the “light
effects” button briefly.
PLAYBACK FROM USB / MEMORY CARD
USB Playback
Insert a USB storage device with audio content in the USB slot. Press the “M” button “change source”
briefly to switch to the USB playback mode. Music from the connected storage device will start playing
automatically. Upload your music to the storage device in the order in which it will be played by the BT
speaker. Supported playback formats are listed in the technical specification.
EN – 8
Memory Card Playback
Insert a memory card with the contacts facing the bottom of the BT speaker. After inserting the memory
card, the BT speaker will automatically play its content. If there are no files to play on the memory card,
the BT speaker will switch to the last active playback source. To remove the memory card, gently press
it into the BT speaker using your fingernail or a blunt object to release it from the slot. Then, you can
carefully remove it with your fingernails (or with tweezers). Supported playback formats are listed in the
technical specification.
Caution: Due to the variety of devices on the market, compatibility and playback support for all media are
not guaranteed. The memory devices you want to connect should be tested in advance and/or formatted
as FAT32. The playback of protected media, files or content stored inside them may fail.
VOICE RECORDING ON USB
Insert an empty USB storage device into the “for playback from memory device” USB slot. Press the
“REC” button to record your voice from the microphone to the USB storage device. The recorded audio
file will be saved on your USB storage device in the REC folder, with the latest file having the highest
number. The files created are without system values such as time and date.
To stop recording, press the “REC” button. Recording will stop, and the last track you recorded will start
playing. To view or play all previous tracks, insert the USB storage device into your computer. The BT
speaker is set not to interfere with the REC folder.
– During playback of the last track, pressing and holding the “REC” button will erase the last recorded
track and start playing the previous track.
Caution: Due to copyright restrictions, only sound from microphones can be recorded to the USB storage
device.
POWER BANK FEATURE
The BT speaker can serve as a power bank to charge other portable devices. Lift the protective cover of
the ports on the back of the BT speaker and connect your portable device's charging cable to the USB
port marked for charging. The charging will take place automatically as long as the BT speaker is turned
on. This is a feature that does not replace charging as effective as charging from the original charger
adapter.
CHARGING / POWERING THE BT SPEAKER
A fully charged battery provides power for several hours of operation at normal volume levels. A high
volume consumes more battery power; therefore, we recommend listening at normal volume levels.
To charge the BT speaker, connect the power/charging cable to the BT speaker and then to AC
100~240V; 50/60Hz. The charging indicator will display a red LED indication on the back. A fully charged
battery will be indicated by a green LED indication. A low battery level will be indicated by an acoustic
alert and LED indicators on the top side of the BT speaker.
Caution: To achieve maximum battery life, it is advisable to start charging the battery only after receiving
a low battery alert by an acoustic alert. Charge continuously until fully charged. If the battery's operating
time is very short, the battery life is consumed, and we recommend having the battery replaced at an
authorised service centre.
Recommendation: If the device is not to be used for an extended period of time, we recommend to fully
charge the battery once every two to three months. Store the device with a charged battery to prevent
irreversible damage to the battery (loss of capacity).
EN – 9
INGRESS PROTECTION (IPX4)
The device is waterproof, allowing you to listen to music near water. Ingress protection IPX4 –
protection against splashing water. Water splashes on the device from all angles, at a rate of 10 litres per
minute and a pressure of 80–100kN/m2 for 5 minutes.
Warning: Always remember to seal the BT speaker inputs (No. 18–27 in the “BT Speaker Description”
diagram) with the original gasket and make sure that the gasket is not damaged. Never charge/power
the device during possible contact with liquids. The device is designed for contact with clean water only
without any impurities. Avoid exposing the device to contaminated or industrially treated liquids (such as
lemonade, sea/salt water, oils, etc.).
TECHNICAL SPECIFICATIONS
PARTYCON BOOST
Party Speaker
Waterproof speaker with IPX4 protection class
Wireless microphone included
Front LED colour panel with effects
Equalizer to enhance bass
Power bank function 5 V / 1 A
Sound:
2XWSXWSRZHU:LPSHGDQFH
4 speakers (2 x 8" mid-bass, 2 x 2.5" tweeters)
Frequency response: 80 Hz–12 kHz
7RWDOKDUPRQLFGLVWRUWLRQ
Preset equalizer modes (Indoor and Outdoor)
Lighting:
Front LED colour panel
Side light effects
Option to turn off light effects
Wireless microphone
UHF frequency
Range up to 10 m
Microphone battery: 2× AA type (not included)
ECHO settings
Volume setting
Recording option on USB
Inputs:
Bluetooth Audio 5.3
Audio connector (3.5 mm stereo Jack)
2× USB (1× for playback and 1× for charging)
Memory card slot
Guitar input 6.3 mm
Microphone input 6.3 mm
EN – 10
Other:
TWS (True Wireless Stereo)
FM Radio
Built-in Rechargeable Battery: 11.1V/8A Li-ion
3OD\EDFN7LPHXSWR+RXUV9ROXPHZLWKRXW/LJKWV
Karaoke function (Echo, Volume)
Accessories: microphone, remote control, charging cable, antenna cable, user manual
Power supply: AC ~ 100–230V 50Hz/60 Hz
Dimensions: 839 x 403 x 3488 mm
Weight: 20.5 kg
Wireless Microphone Frequency 2.4 GHz
PARTYCON BOOST Version 5.3
Maximum Transmitter Power 100mW at 2.4GHz–2.4835GHz
Codec SBC
Profiles A2DP, HFP, AVRCP, HSP, OPP, HID, SPP,
PBAP, GATT, SM
FM Band range 87.5MHz–108MHz
EN – 11
INSTRUCTIONS AND INFORMATION ON THE DISPOSAL OF DISCARDED PACKAGING
MATERIALS
Take the packaging material to a collection centre for recycling.
DISPOSAL OF DISCARDED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on the product, accessory or packaging indicates that the product must not be
treated as ordinary household waste. Please dispose of this product in a collection centre
designated for the recycling of electrical and electronic equipment. In some EU states or
other European countries, you can return your old product to the retailer when purchasing an
equivalent new product. Proper disposal of this product helps to conserve valuable natural
resources and prevent potential negative impacts on the environment and human health that
could result from improper disposal. Further details can be obtained from local authorities or
the nearest collection centre. Failure to dispose of this type of waste properly may result in
legal penalties.
For Companies in European Union Countries
If you want to dispose of electrical or electronic equipment, request necessary information
from your retailer or supplier.
Disposal in Countries Outside the European Union
Request information regarding the proper disposal of this product from local authorities or
your retailer.
This product meets the EU requirements.
)$67ý5DVKHUHE\GHFODUHVWKDWWKHUDGLRGHYLFHW\SH3$57<&21%2267FRPSOLHVZLWK'LUHFWLYH
2014/53/EU.
For the full version of the EU Declaration of Conformity, please visit: www.sencor.com
Text, design and technical specifications are subject to change without notice; we reserve the right to
make such changes.
The original version is in Czech.
0DQXIDFWXUHU)$67ý5DV86DQLWDVXětþDQ\&]HFK5HSXEOLF
Authorised service centres: For detailed information on authorised service centres, please visit
www.sencor.com.
EN – 12
EN
Warranty conditions
Warranty card is not apart of the device packaging.
This product is warranted for the period of 24 months from the date of purchase to the end-user. Warranty
is limited to the following conditions. Warranty is referred only to the customer goods using for common
domestic use. The claim for service can be applied either at dealer’sshop where the product was bought, or
at below mentioned authorized service shops. The end-user is obligated to set up aclaim immediately when
the defects appeared but only till the end of warranty period. The end user is obligated to cooperate to certify
the claiming defects. Only completed and clean (according to hygienic standards) product will be accepted.
In case of eligible warranty claim the warranty period will be prolonged by the period from the date of claim
application till the date of taking over the product by end-user, or the date the end-user is obligated to take it
over. To obtain the service under this warranty, end-user is obligated to certify his claim with duly completed
following documents: receipt, certificate of warranty, certificate of installation.
This warranty is void especially if apply as follows:
Defects which were put on sale.
Wear-out or damage caused by common use.
The product was damaged by unprofessional or wrong installation, used in contrary to the applicable
instruction manual, used in contrary to legal enactment and common process of use or used for another
purpose which has been designed for.
The product was damaged by uncared-for or insufficient maintenance.
The product was damaged by dirt, accident of force majeure (natural disaster, fire, and flood).
Defects on functionality caused by low duality of signal, electromagnetic field interference etc.
The product was mechanically damaged (e.g. broken button, fall).
Damage caused by use of unsuitable media, fillings, expendable supplies (batteries) or by unsuitable
working conditions (e.g. high temperatures, high humidity, quakes).
Repair, modification or other failure action to the product by unauthorized person.
End-user did not prove enough his right to claim (time and place of purchase).
Data on presented documents differs from data on products.
Cases when the claiming product cannot be indentified according to the presented documents (e.g. the
serial number or the warranty seal has been damaged).
Manufacturer:
FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic
info@sencor.com
Authorized service centers:
Visit www.sencor.com for detailed information about authorized service centers.
The original version of the instructions is in the Czech language, other language versions are made by the
appropriate translation.
