3
5
APP SET UP
Step 1: Download our app
Open the App Store or Google Play Store. Search for The Magic Scent
Pro . Download and install the app.
Alternativley, scan the QR code below.
Step 2: Pair the app with your diffuser
Turn on the Bluetooth or WiFi on your phone. Open TheMagic Scent Pro app and
select Bluetooth or WiFi mode.
Go to My Devices and nd Smart.A5 (ensure your phone is nearby the diuser).
Select the device and ent5er the default password: 1234
The app should now be paird with your diuser
Step 4: Work Time Settings
Click ‘’Set Up’’ on the main interface to congure the device’s working schedule.
You can set up to ve working periods per day.
After adjusting the settings, click ’’Save’’ to apply the changes.
Step 3: Monitor and Control the Device
Using the app, you can adjust settings, and turn it on or o.
1
Turning the fan ON and OFF
Press the button to switch the fan on or o.
The fan light comes on when the fan is running.
Proper Installation & Usage
Ensure the installation area is safe, stable, and level.
Install in a well-ventilated space and set the system to military
time.
Do not block the sprayer with your hand or any object while in
operation.
Avoid spilling water or any conductive/corrosive liquids on or inside
the device.
In extreme weather conditions, disconnect the power for safety.
This diuser is designed exclusively for fragrance oils
-
Do not add water!
For the best fragrance performance, we recommend
using The Magic Scent aroma oils.
Power On/Off
Press and hold the button to to turn the device on or o.
You hear one beep when it turns on and two beeps when it turns o.
Atomizing / Frequency
Press the button briey to change the working level.
Each press moves to the next level (MIN, LOW, MED, HIGH, MAX).
Step 1: Download the App
Download The Magic Scent Pro app from the App Store or Google Play.
Make sure you select the correct app.
Step 2: Create an Account
Register by entering your name, username, and password.
• Your password must contain at least 1 number
• Minimum 6 characters
3. Add a Device
Open the app and tap the “+” icon to add a new device.
4. Choose Connection Type
Select either Bluetooth or Wi-Fi.
5. If You Select Wi-Fi
Enter your Wi-Fi username and password.
Note: The Wi-Fi name must be typed exactly as it appears (including spaces,
lowercase/uppercase letters, and numbers). Any dierence will prevent the
connection.
6. Wait for Connection Signals
After adding the device:
• You will hear one beep, which means that the device is found
• Wait up to 30 seconds
• You will hear three beeps, which means that the device has successfully
connected.
Then tap Refresh in the app. Your device should now show as ONLINE.
7. Select Your Device
Tap on your device to open its controls. You can adjust all settings here and
rename the device (useful if you have multiple diusers).
8. Save Your Settings
After adjusting your settings, tap SAVE.
Then go back using the top-left arrow.
When you open the device again, you should see your updated settings applied.
Great job! Your device is now connected. Sit back, relax, and enjoy your new
scent experience.
Lights
Atomizing light: on when the device is making mist
Fan light: on when the fan runs
Wi-Fi light: on when connected to Wi-Fi
Bluetooth light: on when connected to Bluetooth.
4
When you control the device from the app,
it is in app mode.
When you set the level or run time using
the buttons, it is in button mode
Restore to factory settings
With the device on, press and hold the button and the button together
until you hear ve beeps. The device is now reset to factory settings.
There are ve working levels.
Each shows the atomizing time and the pause time,
in seconds:
MIN = 30 / 120 LOW = 60 / 120 MED = 60 / 60
HIGH = 120 / 30 MAX = 300 / 30
The TMS 100 Pro is engineered to use up to 50% less
fragrance oil than other diffusers while maintaining the
same powerful scent output. Its innovative cold-air
diffusion technology maximises efficiency for a
longer-lasting and more sustainable scent experience.
Oil Level Sensor
When your oil runs low, the sensor detects it, and once it drops below 10%, the
app prompts you to rell your scent.
3
MANUAL SET UP
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
FCC WARNING
Any Changes or modications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
8
(305) 697-7171
www.themagicscent.com
DOWNLOAD A DIGITAL COPY OF
THIS MANUAL
Distributed by The Magic Scent LLC
Scent Diuser TMS 100 Pro
USER MANUAL
Exceptional. Simple. Safe. Powerful.
6
HVAC SYSTEM INSTALLATION GUIDE
Scan the QR code for detailed
setup videos and additional
guidance.
The Magic Scent – TMS 100 Pro Nebulizing Scent Diuser
Proper installation ensures optimal performance and safety when
connecting your TMS 100 Pro to an HVAC system. Follow the steps below:
Installation Steps
1. Connect the Hose
Attach the exible hose (provided) to the atomizer outlet of the diuser.
2. Position Correctly
Insert the hose vertically in a straight line into the HVAC duct.
The connection point should be at the air outlet on top of the HVAC unit,
leading directly into the duct.
3. Limit Hose Length
The hose length must not exceed 3 feet to ensure proper diusion.
4. Set HVAC Controls
Adjust the HVAC system to FAN ON mode to enable consistent fragrance
distribution through the ventilation system.
5. Disconnecting the Hose
To remove, press the black release section of the nozzle and gently detach
the hose.
ACTIVATE YOUR 2-YEAR EXTENDED WARRANTY!
The TMS 100 Pro Nebulizing Aroma Diffuser comes with
a 2-Year Extended Warranty for defects in materials
and workmanship.
Scan the QR code or register your product at
https://themagicscent.com/pages/amazon-extended
-warranty
FAULT INSPECTION – TROUBLESHOOTING
AFTER-SALES PREMIUM SERVICE SUPPORT
If you need assistance with your new The Magic Scent product and cannot nd information
in the manual or our online videos, please don’t hesitate to contact us — we’re here to
help!
info@themagicscent.com
(305) 697-7171
1. Check whether the device is powered on or not.
2. Check whether the pump is working or not, and whether the
nozzle is blocked or not.
3. Check whether the essential oil in the bottle has run out or not,
and whether the pipe falls o or not.
NO SCENT
1. Check whether the pump falls out or not and reinstall it.
2. Check whether the mist outlet is blocked or not.
3. Check whether the pump has low airow and pressure.
UNUSUAL
NOISE
1. Oil leakage inside the machine: Check whether the aroma oil
bottle is tightened.
2. Check whether there is blockage in the mist outlet.
OIL LEAKAGE
7
FAULT INSPECTION – TROUBLESHOOTING CAUTION
ATTENTION
Please read all instructions before assembling and using your diuser.
WARNING
When using electrical appliances, basic precautions should always be followed to reduce
the risk of re, electric shock, property damage, and injury, including the following:
INSTALLING
Use this appliance only as described in this manual. Any other use is not recommended by
the manufacturer and may cause re, electric shock, property damage, or injury to a
person.
To avoid re or shock hazards, plug the appliance directly into a safe electrical outlet. DO
NOT plug in the cord with wet hands.
Keep the cord out of heavy trac areas.
DO NOT operate any appliance with a damaged cord or plug, after the appliance
malfunctions, or if it has been dropped or damaged in any manner.
DO NOT use the diuser in a high temperature or wet environment.
DO NOT allow the mist outlets to face the wall directly. Install the diuser in a ventilated
and adequate space.
NEVER place the diuser in an area where it is accessible to children.
DO NOT operate the diuser without rst turning o the unit. Failure to heed this warning
may cause personal injury. NEVER tilt, move, or attempt to empty the unit while operating.
DO NOT block the air outlet while the unit is running.
Always place the diuser on a rm, at, level surface. NEVER place it on a rug or carpet, or
on a nished oor that may be damaged by exposure to water or moisture.
DO NOT use inammable, explosive, corrosive, and other hazardous solvents with the
diuser. DO NOT spill water or corrosive liquid on the diuser surface.
Suggested average daily usage time should not exceed 14 hours.
Shut down the unit in an extreme weather environment.
This diffuser should only be used with fragrance oil
without adding water. For a better performance of the
aroma in the environment, we recommend using only
The Magic Scent aromas.
TO AVOID CASUALTIES AND PROPERTY LOSS, PLEASE ALWAYS
FOLLOW THE INSTRUCTIONS AS BELOW.
