Guangdong Chiyang Scent Technology A974-b Aroma Diffuser User Manual

物料编码：503011085

图纸版本：B1.0

第1⻚，共2⻚

Aromadiﬀuser

① ② ③

④

02Installationstep

03Functionalanalysis

1.Takeoutthediffuserhead；

2.Twistoffthebottle；

3.Fillthebottlewithessentialoil；

4.Putthediffuserheadbackinthemachine.

01Specification

ManualPoweradapter

BottlecapBottle

√

√Button

04SmartAppInstructions

Ifyouforgetyourpassword,holddowntheOn/Offbuttonfor5seconds,

Restorefactorysettings,passwordis8888

Wheretogettheapp:

Pleasesearchfor“ ScentMarketing"inGoogleplayorAPPstore.

Note:

MakesurethatthelocationfunctionofBluetoothandmobilephoneisenabled.

A974_005B3D8

A1_000ED BA

A315_B9B 5E

AAA

2G/3G/4G/5G

①

③②

④

⑤

⑥

1.Openthescentmarketing

appandselectBluetooth.

2.Select your device. 3.Enterthedefaultpassword

8888andpressLogin.

4.OntheDeviceControl

page;Youcanchange

yourdevicenameand

labelinformationof

yourscentdiﬀuser.

5.Diﬀerentschedules

bypressingthe"+"

button.Todeletea

schedule,swipeleft.

6.Pressthetogglebutton

toturnon/oﬀany

schedule.

⑦

⑨

⑧

⑩

8.Selectthedaysofthe

weekyouwantyour

diﬀusertorun(alldays

arepre-selected).

7.Onthe"Workingperiod

setting"page，Setthe

hoursofthedayyouwant

yourdiﬀusertorunby

scrollingthe"Startworking

time"and"Stopworking

time".

9.Press"+"or"-"to

increaseordecrease

thepresetintensity

grades(1-5.Seechart

fordetails.

11.Pressthe"Save"button

toupdatetheSettings.

12.Tap"Calibrate"tocalibrate

consumption.Itisadvised

tocalibrateafterworking

foratleast10days.Please

measuretheremainingoil

ofthebottleﬁrstbefore

startingcalibrating.Enter

thecurrentessentialoil

volume,thenclick

"Conﬁrm"toupdatethe

consumptionandremaining

daysautomatically.

13.Changethedefaultpassword

bypressingonthe"About"

tab,inthe"Devicecontrol".

Thenewpassword

Conﬁrm

15.Enteranewfour-digit

password,thenclick

"Conﬁrm".

PCBVersion：V2.00

Equipment version：V1.0

APPversion：V4.2.9

14.Pressthe"Password

Change"toaccessthe

passwordchangepage.

√

10.Check()theCustom

boxtocreateacustom

intensityandscrollthe

" " "SprayTime and

PauseTime ."

Input password

(factory default password is 8888)

Remember password

NOTE:Pressthe"Save"

buttonatthetopright

cornerofthescreen

aftereachchange.

Select version

Bluetooth version

Wifi version

Device

Device control

Set

About

Working period setting

SaveSave

Name:

Label:

Consumption: ml1.58

Aroma oils: ml150

Remaining: Day166

Calibrate

Start working time

Stop working time

Repeat

Grad e

Cust om

Work Ti me( s)

Stop Time(s)

Mon

Tue

Thur

Fri

Sat Sun

AAA

Device control

Set

About

Save

Name:

Label:

Consumption: ml1.58

Aroma oils: ml150

Remaining: Day166

Calibrate

Co nﬁr m

Last ti me : 150ml

Aroma oils: ml145

Pleaseenterthecurrentamount

ofaromaoils

Device control

Save

Set

About

PasswordChange

Grade:1

Every day

00:00-23:59

23:58-00:01

Every day

Grade:1

Every day

00:00-23:59

23:58-00:01

Every day

Grade:1

lftheQRcodecannotbescanned,

pleasesearchfor"ScentMarketing"

inGoogleplayorAPPstore.

Androidsystem

IOSsystem

Size

φ103*293mm

Bottle

120ml

WorkingPower

55㎡/165m³/5800ft³

Coverage

0.66kg

N.W.

PP+Fabric

Material

A974-b

Model

Input

12V1A

Rotate

-Rotateclockwisetoadjustthetimerlevels:1H-3H-6H-Smart.

-Rotatecounterclockwisetoadjustthetimerlevels:Smart-

6H-3H-1H.

TimerFunction

-Shortpresstoturnoffandswitchcyclethroughthesettings:

G1-G2-G3-OFF.

-Longpressfor1secondtoturnon/offtheambientlight,no

matterthedevice'spowerstatus;

-Ambientlight:Orangelight.Itdefaultstoalwaysonwhenpoweredon.

12H

OFF

DCconnector

Nozzle

Grade

Timer

Rotate

Sma rt

OFF

Smart

OFF

Smart

OFF

Smart

OFF

Smart

OFF

-LongpresstheOFFfor1secondtoturntheambientlighton/off,

withoutaffectingotherlights.

Gradebutton

-Presstostartthetimermode:Setto1Hfor1hourofoperation

beforeautomaticshutoff；Setto3Hfor3hours,or6Hfor6hours,

afterwhichthedevicewillturnoffautomatically.

-BluetoothPaired:thelightremainson.

-Datareceiving:thelightflashes.

-BluetoothUnpaired:thelightisoff.

Smart APP

展开尺⼨：283*208mm，材质：128g铜版纸

签字受控:

第2⻚，共2⻚

08 Warning

10Equipmentcleaning

09Troubleshooting05Concentrationandconsumption

Note:1.Abovadataisforreferenceonly.Ifcustomersuseessential

oilswithdifferentviscosities,theoilconsumptionwillvary；



2.Forthebestdiffusioneffect,it'srecommendedtouseessential

oilswithaviscositybelow30mPa.s.Andtheoptimalworking

temperatureis25℃.

06ISEDStatement

English:Thisdevicecontainslicence-exempt

transmitter(s)/receiver(s)thatcomplywithInnovation,Science

andEconomicDevelopmentCanada’slicence-exemptRSS(s).

Operationissubjecttothefollowingtwoconditions:

(1)Thisdevicemaynotcauseinterference.

(2)Thisdevicemustacceptanyinterference,includinginterference

thatmaycauseundesiredoperationofthedevice.

ThedigitalapparatuscomplieswithCanadianCANICES-3

(B)/NMB-3(B).

French:Cetappareilcontientdesémetteurs/récepteursexemptsde

licencequisontconformesauxRSSexemptésdelicence

d'Innovation,SciencesetDéveloppementéconomiqueCanada.

L'exploitationestsoumiseauxdeuxconditionssuivantes:

(1)Cetappareilnedoitpasprovoquerd'interférences.

(2)Cetappareildoitacceptertouteinterférence,ycomprisles

interférencessusceptiblesdeprovoquerunfonctionnement

indésirabledel'appareil.

l'appareilnumériqueduciemconformecanadienpeut-3(b)/nmb

-3(b).

Thisdevicemeetstheexemptionfromtheroutineevaluationlimits

insection6.3ofRSS102andcompliancewithRSS102RFexposure,

userscanobtainCanadianinformationonRFexposureand

compliance.

cetappareilestconformeàl'exemptiondeslimitesd'évaluation

courantedanslasection6.3ducnr-102etconformitéavecrss102

del'expositionauxrf,lesutilisateurspeuventobtenirdesdonnées

canadiennessurl'expositionauxchampsrfetlaconformité.

ThisequipmentcomplieswithCanadaradiationexposurelimitsset

forthforanuncontrolledenvironment.

Cetéquipementestconformeauxlimitesd'expositionaux

rayonnementsduCanadaétabliespourunenvironnementnon

contrôlé.

Thisequipmentshouldbeinstalledandoperatedwithminimum

distance20cmbetweentheradiator&yourbody.

Cetéquipementdoitêtreinstalléetutiliséàunedistanceminimale

de20cmentreleradiateuretvotrecorps.

07FCCStatement

(1)Thisdevicemaynotcauseharmfulinterference,and

(2) this device must accept any interference received, including

interferencethatmaycauseundesiredoperation.

Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfor

a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits aredesignedto providereasonableprotection againstharmful

interference in a residential installation. This equipment generates,

usesand canradiate radiofrequency energy and,ifnot installedand

used in accordance with the instructions, may cause harmful

interferencetoradiocommunications.However,thereisnoguarantee

that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television

reception,whichcanbedeterminedbyturningtheequipmentoﬀand

on,theuserisencouragedtotrytocorrecttheinterferencebyoneor

moreofthefollowingmeasures:

-Reorientorrelocatethereceivingantenna.

-Increasetheseparationbetweentheequipmentandreceiver.

-Connecttheequipmentintoanoutletonacircuitdiﬀerentfromthat

towhichthereceiverisconnected.

-Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

FCCCaution:Anychangesormodiﬁcationsnotexpresslyapprovedby

thepartyresponsible

for compliance could void the user's authority to operate the

equipment.Thistransmitter

must not be co-located or operating in conjunction with any other

antennaortransmitter.

Notapplicable

RFExposure

ThisdevicecomplieswithFCCradiationexposurelimitssetforthforan

uncontrolled

environment. This equipment should be installed and operated with

minimumdistance20cm

betweentheradiator&yourbody.

Thisdevicecomplieswithpart15oftheFCCRules.Operationissubject

tothefollowingtwoconditions:

10s

20s

25s

220s

120s

60s

0.11

0.35

0.72

Grade

Consumption(g/h)

Worktime(s)

Stoptime(s)

3.Makesurethemachinewithoutessentialoilinside

thebottlebeforetransportation;

1.Pleasereadtheusermanualbeforeoperation&

maintenance;

2.Keepthemachinevertical,layingﬂatmaycauseoil

overﬂow;

4.Tightenoilbottlebeforeuse;



5.Cleanthemachinewithalcoholevery1-2months;



6.DoNOTmodify,disassembleorrepairthemachine.Ifany

failureoccurs,pleasecontactourtechnicalpersonnel.



Oilsprinkle

Doesnotdiﬀuse

Lowdiﬀuse

Oilspill

Abnormalnoise

Breakdown Solution

-Checkwhetherthemodeyouchosecorrectornot.

-Checkifthemachineisina"Non-Workingperiod".

-Airpumpmaybedamaged,replacewithanewone.

-Checkwhetherthetubeislooseornot.

-Theatomizingcoreisblocked,cleanwithalcohol

orchangetoanewatomizerheads.

-Checkwhetherthegasketisdamaged/looseor

missing.

-Checkwhetherthetubeislooseornotconnected.

-Checkwhetherthebottleisloose.

-Checkifthegasketintheatomizedheadisdamaged,

looseormissing.

-Theatomizedheadisdamaged:changetoanewone.

-Themachineistilledorlayingﬂat,keepthemachine

vertical.

-Theairpumpisloose,retightenthepump

-Theairpumpisdamaged:replace.

Beforeaskingtohavethemachinerepaired,pleasetrytodiagnose

theproblemfirstbyfollowingtheinstructionsbelow.

Cleaningsteps:

1.Pullouttheatomizedhead.

2.Findalargercontainerandﬁllwithindustrialalcoholup,thensoak

theatomizedheadandthebottlefor5-10mins.

3.Allowtheatomizerheadandthebottletodry.

Themachineneedstobecleanedwhentheseconditionsexist:

1.You'reabouttochangingtoanotherkindofessentialoil；

2.Theatomizationvolumebecomesweak.

Smart

OFF

Smart

OFF

11Declarationofconformity

Herby,GuangdongChiyangScentTechnologyCo.,Ltd.declaresthat

thisAromadiffuser，A974-bisincompliancewiththeessential

requirementsandotherrelevantprovisionsofDirective2014/53/EU.

InaccordancewithArticle10(2)andArticle10(10),thisproduct

allowedtobeusedinallEUmemberstates.

Guangdong Chiyang Scent Technology A974-b Aroma Diffuser

Product's Documents

User Manual

Specifications

Guangdong Chiyang Scent Technology A974-b Questions and Answers
