MRU07M4BSL
MRU07M4BWW
Upright Freezer
SINGLE DOOR SERIES
USER MANUAL
Warning notices: Before using this product, please read this manual carefully and keep it for future reference.
The design and specifications are subject to change without prior notice for product improvement.
Consult with your dealer or manufacturer for details.
The diagram above is just for reference. Please take the appearance of the actual product as the standard.
01
THANK YOU LETTER
Thank you for choosing Midea! Before using your new Midea product, please read
this manual thoroughly to ensure that you know how to operate the features and
functions that your new appliance oers in a safe way.
CONTENTS
THANK YOU LETTER
------------------------------------------- 01
SPECIFICATIONS
------------------------------------------------ 02
PRODUCT OVERVIEW
----------------------------------------- 03
PRODUCT INSTALLATION
------------------------------------ 04
OPERATION INSTRUCTIONS
--------------------------------- 10
CLEANING AND MAINTENANCE
---------------------------- 11
TROUBLESHOOTING
------------------------------------------- 12
02
SPECIFICATIONS
Product model MRU07M4BSL/MRU07M4BWW
Volume 7.1cu.ft.(200L)
Rated Voltage AC115V
Rated Frequency 60Hz
Rated Current 1.5A
Refrigerant R600a
Amount 2.47oz(70g)
Overall Dimension (W x D x H) 21.7 x 22.4 x 50 in(55.0 x 57.0 x 127.0 cm)
03
PRODUCT OVERVIEW
Names of components
1
Thermostat knob
2
Glass shelf
3
Drawer (optional)
5
Door
4
Leveling foot
ATTENTION
on the physical
product or statement by the distributor
04
PRODUCT INSTALLATION
Install Instruction
Finding a suitable location
• This freezer is designed to be free standing only, and should not be recessed or
built-in.
• The freezer should be placed in a well-ventilated indoor place; the ground shall be
• Keep away from heat and avoid direct sunlight. Do not place the freezer in moist or
watery places to prevent rust or reduction of insulating eect.
Dimensions and Clearances
• Too small of a distance from adjacent items may result in the degradation of
freezing capability and increased electricity costs. Allow over 100 mm of clearance
from each adjacent wall when installing the appliance.
Providing a proper power supply
• Check your local power source. This freezer requires a
AC115 V, 60 Hz
power
supply.
• Use a receptacle that accepts the grounding prong. The power cord is equipped
with a 3-prong (grounding) plug which mates with a standard 3-prong (grounding)
wall outlet to minimize the possibility of electric shock hazard from this freezer.
CAUTION
The freezer should always be plugged into its own individual electrical outlet which
has a voltage rating that matches the rating plate.
Never unplug your freezer by pulling on the power cord. Always grip the plug
Start to use
• The freezer shall stay in an upright position for half an hour before connecting
• The freezer shall run 2 to 3 hours before loading fresh or frozen foods; the freezer
shall run for more than 4 hours in summer in advance considering that the ambient
temperature is high.
05
Space requirement diagram (when the door is open and when the door is closed)
B B
A
C
D
E
135 °
Width
Overall
Height
Depth
Depth
doors open
135
o
Width
doors open
135
o
A B C D E
550 1270 570 990 860
Notice: All dimensions in mm
06
Door right-left change (optional)
more convenient to reverse the position of the door.
CAUTION
CAUTION: To avoid injury to yourself or your property, we recommend that
someone assist you during the door reversal process.
List of tools to be provided by the user
Cross screwdriver
Thin-blade screwdriver
Masking tape
Parts to be used for door reverse
SN PART
amount
note
1 Right upper hinge 1 Pre-installed on the refrigerator, removed
when the door is reversed, and kept for future
use
2 Upper right hinge cover 1
3 Hole cover 1
Pre-installed on the refrigerator, still used
when door is reversed
4 Stopper 1
5 Stopper Lower hinge 1
6 Leveling foot 1
7 Left upper hinge 1
In the attached plastic bag, take them out for
use when door is reversed
8 Upper left hinge cover 1
STEP
1. Remove all food from door shelves. Fix the door by tapes.
2.
right hinge, and remove the upper right hinge, please keep the door vertical in
whole process for avoiding falling down;
The upper hinge coverHinge hole cap
07
3. Remove the door;
4. Dismantle the door stopper, and install it on other side;
5. Dismantle the lower hinge and leveling foot;
6. Install the lower hinge and leveling foot on lower left side of cabinet;
Hinge
Leveling foot
Hinge
Leveling foot
7. Put the door on lower hinge vertically, and validate the gas tightness of door
gasket, take out the spare upper left hinge and hinge cover from accessory
hinge cover , and cover the hinge hole cap on upper right side.
08
Leveling feet
To avoid vibration, the unit must be leveled.
The front should be slightly higher than the rear to aid in door closing.
Leveling screws can be turned easily by tipping the cabinet slightly.
Turn the leveling screws counterclockwise
to raise the unit, clockwise to
lower it.
Moving the appliance
1. Remove all food from inside the appliance.
2.
ook at the rear or
on top of the appliance.
3. Tape parts such as shelves and the door handle to prevent from falling o
while moving the appliance.
4. Move the appliance with more than two people carefully. When transporting
the appliance over a long distance, keep the appliance upright.
5. After installing the appliance, connect the power plug into a socket out to
switch on the appliance.
ATTENTION
Precautions before operation:
Before making changes the refrigerator must be disconnected from power.
precautions should be taken to prevent any personal injury.
09
Tips for energy saving
• Do not place the appliance near cookers, radiators or other heat sources. If the
ambient temperature is high, the compressor will run more frequently and for
longer, resulting in increased energy consumption.
•
ppliance, on the sides
of the appliance and at the back of the appliance. Never cover ventilation openings.
• Please also observe the spacing dimensions in the chapter „Installation“.
• The arrangement of drawers, shelves and racks as shown in the illustration oers the
s far as possible. All
drawers and shelves should remain in the appliance to keep the temperature stable
and save energy.
• To obtain a larger storage space (e.g. for large refrigerated/frozen goods), the
middle drawers can be removed. The top and bottom drawers and shelves should
be removed last if necessary.
•
s to optimal energy
use. Therefore, avoid empty or half-empty compartments.
• Allow warm food to cool before placing it in the refrigerator/freezer. Food that has
• Allow frozen food to defrost in the refrigerator. The coldness of the frozen food
reduces the energy consumption in the refrigerator compartment and thus increases
• oss. Opening the door
• The door seals of your appliance must be perfectly intact so that the doors close
properly and energy consumption is not increased unnecessarily.
10
OPERATION INSTRUCTIONS
Control Panel
• After the upright freezer is powered on, when the temperature control knob
rotates clockwise, the temperature in the freezer will gradually decrease, and
when it rotates counterclockwise, the temperature will gradually increase; when
knob is adjusted within the scope of “COOLING”, the box is refrigerator, when
knob is adjusted within the scope of “FREEZING”, the box is frozen.
• “OFF” file indicates stop.
• When selecting the refrigeration function, it is recommended that the
temperature control knob be set in the middle of the refrigeration icon area.
During refrigeration, there may be water drops on the inner wall of the liner,
which is normal and the refrigerator can be used normally.
ATTENTION
Tips on storing food
• The low temperature of upright freezer may keep food fresh for a long time
and it is mainly used to store frozen foods and making ice.
•
balls and other foods not to be consumed in short term.
• Chunks of meat are preferably to be divided into small pieces for easy access.
Please be noted food shall be consumed within the shelf time.
defrost it manually under the following two conditions. Defrosting water shall be
treated outside the cabinet, and the space inside shall be cleaned.
1. When the machine is in freezing mode for a long time, the inner wall of
defrosting, clean the inner wall and then power on to continue using the
machine.
2. When the freezing mode is switched to the refrigeration mode, the
temperature inside the cabinet will rise. In order to avoid a large amount of
11
CLEANING AND MAINTENANCE
Defrosting
Upright freezer shall be manually defrosted.
Disconnect the plug from the wall socket, open the door and remove all the food
to a cool place.
It is recommended to remove the frost by a plastic scraper, or let the temperature
rise naturally until the frost melts. Then wipe away the remaining ice and water,
and plug in socket for switching on the freezer.
ATTENTION
Soft towels or sponge dipped in water and non-corrosive neutral detergents are suggested
cloth. Open the
door for natural drying before the power is turned on. Do not use hard brushes, clean steel
balls, wire brushes, abrasives, such as toothpastes, organic solvents (such as alcohol, acetone,
banana oil, etc.), boiling water, acid or alkaline items clean refrigerator considering that this
may damage the fridge surface and interior.
CAUTION
Other mechanical devices or other means shall not be used to accelerate
except those recommended by the manufacturer. Do not damage the
refrigerant circuit.
Stop using
Power failure:
In case of power failure, even if it is in summer, foods inside the appliance can be
kept for several hours; during the power failure, the times of door opening shall
be reduced, and no more fresh food shall be put into the appliance.
Long-time nonuse:
The appliance shall be unplugged and then cleaned; then the doors are left open
to prevent odor.
Moving:
partitions, vegetable holder, freezing chamber drawers and etc. with tape, and
tighten the leveling feet; close the doors and seal them with tape. During moving,
the appliance shall not be laid upside down or horizontally, or be vibrated; the
inclination during movement shall be no more than 45°.
ATTENTION
The appliance shall run continuously once it is started. Generally, the operation of the
appliance shall not be nterrupted; otherwise the service life may be impaired.
Foods can be preserved for a couple of hours even in summer in case of power failure; it is
recommended to reduce the frequency of opening door.
12
TROUBLESHOOTING
The following simple issues can be handled by the user. Please call the after-sale
service department if the issues are not solved.
Problem Possible reason
Failed operation
• Check whether the appliance is connected to power or
whether the plug is in well contact
• Check whether the voltage is too low
• Check whether there is a power failure or partial circuits have
tripped
Odor
• Odorous foods shall be tightly wrapped
• Check whether there is any rotten food
• Clean the inside of the refrigerator
Long-time operation
of the compressor
• Long operation of the refrigerator is normal in summer
• when the ambient temperature is high It is not suggestible
having too much food in the appliance at the same time
• Food shall get cool before being put into the appliance
• The doors are opened too frequently
Light fails to get lit
• Check whether the refrigerator is connected to power supply
and whether the illuminating light is damaged
• Have the light replaced by a specialist
Door can not be
properly closed
• The door is stuck by food packages Too much food is placed
• The upright freezer is not placed properly.
Loud noises
•
is placed stably
• Check whether accessories are placed at proper locations
13
Problem Possible reason
Door seal fails to be
tight
• Remove foreign matters on the door seal
• Heat the door seal and then cool it for restoration (or blow it
with an electrical drier or use a hot towel for heating)
• There is too much food in the chamber or food stored
contains too much water,resulting in heavy defrosting
• The doors are not closed properly, resulting in frosting due to
entry of air and increased water due to defrosting
Hot housing
• Heat dissipation of the built-in condenser via the housing,
which is normal When housing becomes hot due to high
ambient temperature, storage of too much food or shutdown
of the compressor is shut down, provide sound ventilation to
facilitate heat dissipation
Surface
condensation
• Condensation on the exterior surface and door seals of the
refrigerator is normal when the ambient humidity is too high.
Just wipe the condensate with a clean towel.
Abnormal noise
• Buzz: The compressor may produce buzzes during operation,
and the buzzes are loud particularly upon start or stop. This is
normal.
•
produce creak, which is normal.
