WR-336M
Internet Radio
User Manual
Please read this user manual carefully before using the receiver.
Podcas
D ial Select
Home
Location of Controls ................................4-6
Remote control .........................................7
Before you start ....................................... 8
1.Getting started .....................................8
2.Setting up network (Scan & Select) ............9
Entering password for your wireless network..10
4.Overview of features and functions...12-13
5.Internet Radio ................................14-18
6.Podcasts operation ...............................19
7.FM Radio ...........................................20
8.Media Centre .................................21-22
9.BT playback .......................................23
10.Alarm Setting ................................24-25
11.Timer Setting ......................................26
12.Sleep Timer Setting ............................26
13.Configuration ................................27-32
14.Remote control via PC/Smart phone
....................................................33-34
15.Manage my favourite via PC/Smart phone
.....................................................35-36
16.Trouble Shooting ........................37-38
Helpful Tips ............................................40
Technical Specification ............................41
In the box ...............................................42
Contents
3.Setting up network (WPS) ...........................11
- 3 -
- 4 -
Location of Controls
Home
1
6
7
2
5
8
3
4
9
10
11
12
13 14
Podcast
Dial Select
DC IN 5V
U SB Playback
- 5 -
2.
3.
Press and hold to preset a particular station
Press to recall the favourite list
4. ►
Right cursor/Enter edit menu under Favourite list
/View the big clock & radio info under playing screen
5. ◄
Location of Controls
Podcast
Access Podcast menu
1 .
Press it briefly to wake the radio or turn the radio to
sleep mode.
FM mode: press and hold to skip to previous preset
Back to previous menu/left cursor
6 . Preset button 1-4
Preset the four dedicated favourite stations
Press and hold to preset
Press it briefly to recall
Podcast mode: the button 3/4 serves the
7 . Speaker
8 . Color screen 2.4"
9 . Dial/Select
Rotate to scroll along, up/down on the menu / push to
confirm / select menu options / push to stop or resume
playback of radio channel / push to pause or resume
on media playback.
skip forward and backward along the episode playback
9 . Dial/Select
10 .
/ Home
Rotate to adjust the volume level.
Push the knob to return Home menu.
Internet radio/USB/BT: turn the knob to skip to the next or
previous station/track.
FM: turn the knob to manual tune the frequency.
11. DC power input jack 5V
12 . USB port for audio playback
13. Stereo headphone jack 3.5 mm
14. Telescopic antenna
- 6 -
- 7 -
16. ▼: Cursor down
Remote Control
17. Vol+: Volume up
18. Vol-: Volume down
19. EQ: Equalizer
20. : Next station on the list/manual tune on FM/next
22. Dimmer: Access the Dimmer menu to adjust the
4 . : Preset the current playing station
to Favorite
5 . ▲ : Cursor up
6 . : Cursor left/back to previous menu
10. : Home
7 . : Alarm setting
8 . : Sleep timer
9 . Mode : Switch between radio modes
manual tune on FM/ previous track
on BT/USB/Media Centre
12. : Access network info of the radio
11. : Previous station on the list/
internet radio
13 . : Recall the favorite list
14 . O K : confirm button
15 . ► : Cursor right/BT mode: press and hold
to disconnect the paired device
1 . : Toggle between Standby
and operation.
2 . : Mute
3 . 0-9 : Input index number on the list /
input characters for WiFi password
display or return to Now Playing screen.
brightness of the display
23. Info: Toggle to cycle through the station's info, the big clock
track of USB/ BT/Media Center
21 . : Play/pause for BT/Media center/USB; play/stop for
- 8 -
Please ensure the following is ready:
You have a broadband internet connection. A wireless
broadband router is connected to the internet
successfully. The radio supports Wireless B, G and N
connection (Wireless N router can also be used with the
setting on B or G). You know the Wired Equivalent Privacy
(WEP) or Wi-Fi Protected Access (WPA) data encryption
code/password. You need to key in the correct code when
the radio is connected to the wireless router for network
connection. If you do not know the code/password, please
contact the person/technician who set up the
router/network for you. The radio works via 2.4GHz
Wireless network connection (Wi-Fi connection) only.
Before you start
n
m
,
n
m
,
n
n
m
,
n
s
e
f
1
.
1
f
n
k
h
j
f
k
s
h
e
j
f
1. Getting started
The radio is powered via a 5 volts 1 amp mains adapter
(included). Connects the power adapter to the DC IN jack at
the rear side of the radio device. The radio will power on.
Press the [ ] button briefly to turn it to Standby. Press it
again to wake the radio. On the remote control, press the
[ ] button to turn the radio to standby/sleep.
- 9 -
• Setting up the radio for the first time will prompt you to select
your preferred language and the time zone. Next, configure
the network following the wizard. Choose Yes to start.
• There are two ways to search the wifi networks:
"Scan & Select" or via "WPS button".
Refer to the chapter in the next page for the instructions on
how to enter the password.
An "Association Complete" will pop up if the connection is
successful. The Wifi signal bar will appear on the top left of the
display.
2. Setting up network (Scan & Select)
• Choose "Scan & Select", it will start scanning the network
availalbe. Choose your network and press [OK] to confirm. If
your wifi network has a password protected, it will ask you to
enter the passphrase/ password.
Note: The password is case sensitive, please consult with the
one who setup your network if you don't know the password.
Scan & Select
- 10 -
Button 1: 1 ! @#$%^&*()_+[]{};:'”\|,./<>?
Button 2: 2ABCabc
Button 3: 3DEFdef
Button 4: 4GHIghi
Button 5: 5JKLjkl
Button 6: 6MNOmno
Button 7:7PQRSpqrs
Button 8: 8TUVtuv
Button 9:9WXYZwxyz
Button 0: 0
Alternatively, use the and button to select the character,
press [OK] to input the next one. When done, move the cursor
to the mark, and press OK to confirm.
When the entries are
done, move the cursor to
this mark and press OK
to confirm.
Using control buttons on the radio unit
Rotate the [Dial/Select] knob to scroll through the
characters, highlight it and push the [Dial/Select] knob to
input the next one. When done, scroll to the mark and
push the [Dial/Select] knob to complete the entry.
Note: The password is case sensitive.
Entering password for your wireless network
Using Remote control
On the alpha-numeric keypad, press the button repeatedly to cycle
through the characters assigned to each button (see the list below).
Press [OK] to input the next one.
- 11 -
the radio near to the WiFi router for the
setup. Select the "WPS button" option on the radio, press
OK on the remote, or push the [Dial/Select] knob on the
radio unit to confirm.
Meanwhile, press the WPS button on the Wifi router, it will
start connecting with the radio. Once the connection is
made, it will display "Association complete".
WPS button
If your wifi router has a WPS button, you can choose the
"WPS button" option to quickly connect to the wifi
network.
Suggest to place
3. Setting up network (WPS)
Wi-Fi
signal bar
- 12 -
Press [ ] to enter the Home menu. Scroll by rotating the
[Dial/Select] knob or the [ ◄ / ► ] button on remote:
My Favorite ― To show the list of favorite stations which
have been assigned to the presets. There are up to 150
presets available.
Internet Radio ― Start exploring the worldwide
internet radio stations and music here.
Media Centre ― You can browse and stream music from
your network via UPnP or DLNA Compatible devices.
USB ― Plays USB audio.
FM Radio ― Receive ordinary FM radio stations in your
local area (no internet connection required).
BT ― BT playback, to play audio stream (receive) from
another BT enabled device after pairing/connected each
other.
Alarm ― Alarm clock. Two alarm settings available.
Timer ― To count down from a specified time with alarm.
Sleep Timer ― Enable the timer to turn the radio off after
the selected time elapsed.
4. Overview of features and functions
Podcasts ― Here you can access thousands of
Podcast channels, to subscribe or listen again any time.
- 13 -
Digital style Analog style
History
16
Mon4:
19 pm
Configuration ― More options/settings available to
personalize as you desire.
Clock style
Change the clock graphic between digital- or analog
styles under Configuration> Date & Time> Set clock style.
4. Overview of features and functions
- 14 -
On the Home menu, choose Internet Radio and you will
find the options below:
Skytune
Select Skytune to start enjoying thousands of radio
stations over the world. You can filter your search by
Region, Music genre and talks.
The Local Radio let you access quickly the stations
available in your local area through internet connection.
Note - You can change the Local Radio area under
Configuration> Local radio.
When you scroll along the list of Globe All and want to
quickly reach to a certain point of the long list, input the
index number on the remote control to quickly jump to that
point. For example, on the remote control, input 28 and
press OK, it will highlight the station no. 28.
Search
Instead of browsing the radio station list, you can input a
5. Internet Radio
12:01am
Internet Radio 1/3
< Skytune >
Search(Skytune) >
History >
12:01am
Skytune 1/5
< Globe Most Popular >
Local Radio >
Globe All >
Globe By Genre >
- 15 -
few characters of the desired station to filter out / short list
the stations.
History
The radio memorizes the stations you have listened up to
99 stations. If you have listened more than 99 stations, it
will supersede the first station that you have listened.
Start playing internet radio
When a radio station starts playing, more radio
information can be displayed. Press the [ ► ] button on
the radio device in the state of the playing screen below,
or press the [INFO] button on the remote control:
Every time you press the [ ► ] button (or press the [INFO]
button on the remote control), it will toggle between the
big clock and the radio channel information:
My Favorite
This is to show the list of your Favorite stations which
5. Internet Radio
- 16 -
5. Internet Radio
have been assigned to the presets.
Preset a station
When a radio station is playing, press the [ ] button on
the remote control or press and hold the [ ] on the unit,
you will see the icon appears as below. It means the
station is added to the Favorite list.
The new added station will always show in the last item on
the Favorite list. You can store up to 150 presets.
There are 4 preset buttons on the radio device (1-4) to
preset 4 dedicated stations which are stored separately
from the list of My Favourite. Whenever you want to
change any of the 4 dedicated stations, press and hold the
numeric button (1-4) on the radio device to override it.
Recall a station
Press the [ ] button on the remote control or press the
[ ] briefly on the radio unit to recall the list of presets, or
navigate to My Favourite on the main menu and select it
to confirm.
Create new categories - making a custom favorite lists
There are two selectable items in the My Favorite list as
below, All Favorites and Uncategorized.
Preset icon
- 17 -
5. Internet Radio
You can create different categories to save the favorites
and name it as desired, for example "Morning mix", "My
Jazz", "After work"...etc. to help organize the favorites better.
In My Favorite page, press [►], the "Create Category" menu
will appear:
Press the [ ► ] button
Press OK, enter the name of
category, e.g. My Jazz
My favourite 2/2
11:30am
All favourites 3
Uncategorized 3
My favourite 2/2
11:30am
All favourites 3
Uncategorized 3
Edit 1/1
12:48am
Create catogory
My favourite 3/3
11:30am
All favourites 3
Uncategorized 3
My Jazz
- 18 -
5. Internet Radio
Highlight the station to move
category, press [ ► ] button
Choose "Move to category",
it will display the list and select
the one you want to move it to.
e.g., "My Jazz", then press OK.
The station is now moved to "
My Jazz" folder.
Edit 1/2
12:48am
Move to
Delete
My favourite 3/3
11:30am
All favourites
3Uncategorized
2 My Jazz
Once a category is created, you can assign the favorite
stations to the category as desired. The "Uncategorized"
folder gathers the stations that are not yet assigned to
any custom categories. To move stations to the desired
category, navigate to the "Uncategorized" folder, choose
the station to move and select "move to category".
Highlight the desired category you want to move it to, and
push [Dial/Select] on the radio device or press [OK] on
the remote to confirm. You will find the selected station is
moved to the new category. You can always move the
station from one to another.
12:48am
My favourite 1/3
< 101 SMOOTH JAZZ
FM 106.30 MHZ
FM 98.90 MHz
- 19 -
6. Podcasts operation
On the Home screen, select "Podcasts" and press OK to
confirm. You will find the following options:
Listen again ─ You can always add a particular episode to
"Listen again" to repeat on listening or continue the unfinished
part.
To save the episode to "Listen again", press the Preset button
on the radio unit when it's playing, or the button on the
remote. It will be added to the "Listen again" menu. To remove
it from Listen again, highlight the episode and press the
button to edit.
Subscribed ─ Subscribe your favourite Podcast for easy access
to listen to the latest episode.
To subscribe a Podcast, highlight the Podcast and press
the right arrow button , then select Subscribe.
To remove the subscription, highlight the podcast and press
the right arrow button to edit.
History ─ the previous listened episodes of the Podcasts.
Browse ─ To browse the list of Podcasts available
Search ─ Search the Podcast by keywords
Search history ─ the list of previous search records.
Note: The episode will resume to play from where it left off.
When an episode is playing, you can always skip forward /
backward by "press and hold" the buttons, press
these buttons briefly will skip to next / previous episode.
Push the [Dial/Select] knob or the on the remote to
pause the playback.
- 20 -
To receive the ordinary FM stations (no internet
connection is required), place the radio close to the
window and extend the antenna as far as it can go to get
the best reception. You may need to adjust the direction of
the antenna to improve reception.
On the Home menu, scroll to FM Radio or use the [Mode]
button on remote to switch to FM Radio. Confirm by
pushing [Dial/Select] knob or press [OK] on the remote.
It will ask whether you want to Scan FM Station. Press
[OK] to start scanning and it will show the progress on the
number of channels are found. When it is done, it will
automatically save the found channels on presets and
display the list for your action.
You can select the channel and start listening to it.
Whenever you want to add to My Favourite, press the
[ ] button on remote or press and hold the [ ] button
on the unit, and it will add to the favourite list.
Always press the [ ◄ ] button to return to the Preset list.
Note: When it is playing FM radio, press the [ ► ] button
on the radio to view more radio information, each time you
press the [ ► ] button, it will display various information at
a time such as radio frequency and big clock display (or
press the [INFO] on the remote).
7. FM Radio
Manual Tune
To manual tune the frequency, rotate the [Dial/Select]
knob on the radio device or press the [ / ] button on
remote to fine tune the frequency.
- 21 -
The device supports UPnP and is DLNA-compatible. This
provides the opportunity to stream music from your
network. However, this requires you to have a compatible
device in your network that can function as a server. This
can be e.g., a network hard drive or a conventional PC
with e.g., Windows 8 via which access to the shared folder
or media sharing is permitted. The folders can then be
browsed and played on the radio.
Note: Please make sure your computer laptop is on the
same Wi-Fi network as the Radio before you start using
this function.
Music streaming
• Once the UPnP/DLNA compatible server is configure to
share media files with your radio, you can start music
streaming.
• On the main menu, select Media Centre and choose
UPnP.
• It may take a few seconds for the radio to complete the
scan for available UPnP servers. If no UPnP servers are
found, it will show Empty List.
• After a successful scan is done, select your UPnP server.
• The radio will show the media categories available from
the UPnP server, e.g. 'Music', 'Playlists' etc.
• Choose the media files that you wish to play. You can set
the mode of playback under Configuration > Playback
setup.
My Playlist
You can make your own playlist for the UPnP music files.
Choose and highlight the song you want to add to playlist,
press and hold the [ ] button on the radio device or
press the [ ] preset button on remote, until the sign
8. Media Centre
- 22 -
8. Media Centre
appears. The song will be added to My playlist.
Clear My Playlist
Remove all songs in "My Playlist" to allow a new playlist to
be prepared.
Note: If you have DLNA compatible servers available,
follow the steps described above to browse the audio files
from DLNA compatible device on the radio to play.
- 23 -
Before transmission between your BT device and the
radio is possible, both devices must be coupled. This
process is called "pairing". The radio is served as a
receiver, to receive music stream to play on the radio.
If you have already coupled to a BT device before, this
connection will be restored automatically when both
devices are in range and BT operation has been selected
on the radio. "Pairing" does not have to be repeated. This
function may need to be activated in your BT device,
however.
• Push the Home button to display the selection menu for
the different operating modes.
• Select the BT streaming and confirm.
• Switch your BT device to which you want to connect the
radio on and activate the pairing mode here. The device
scans for BT devices in the reception range.
• When the radio is found, your bluetooth device shows its
name WR-336M-XXXX (the XXXX is an identification
code for your radio unit).
• Select the radio at your BT device.
• Start playback on your BT device.
• Playback now takes place using the radio.
9. BT playback
- 24 -
• Choose Alarm from the Home menu or press the
[Alarm] button on the remote control.
• Select either Alarm 1 or Alarm 2, choose Turn on to
activate the Alarm.
• Follow the alarm wizard instructions to set the alarm.
• The wizard will guide you through the settings below:
Time - Set the time for the alarm
Sound - You can choose Wake to Tone, My Favourite
as the alarm source.
Repeat - You can schedule the alarm as you desire:
Everyday, Once or multiple days.
Alarm Volume - Adjust the volume of the alarm as you
like by rotating the [Dial/Select] knob
or [▲/▼] button on remote.
Alarm duration - Set the duration of the alarm from the
preset options ranging from 30 to
180 minutes. The radio will be
turned to standby when the selected
duration of time is due.
• After the above settings are completed, press the [◄]
button to exit and make sure the Alarm is turned on. You
will see the Alarm icon appeared on the display if it is
activated.
10. Alarm Setting
- 25 -
10. Alarm Setting
Stopping the Alarm/Activate the Snooze function
When the alarm goes off, press the [ ] to stop the alarm
or press the [Dial/Select] knob to activate the Snooze
feature.
When the Snooze is activated, the alarm is muted for 9
minutes and sounds again when the time is due. You can
repeat the process multiple times.
To stop "snoozing", press the [ ] button.
Alarm 1 is Snoozing
3:02PM
Press POWER to stop
8:58
- 26 -
You can set the timer to let the radio turns off after the
selected time elapsed in the range of 15 minutes to 180
minutes.
Press [ ] button on the remote control to set the timer.
You will see the icon appeared on the display if the timer is
set.
11. Timer Setting
Setting the Timer
The device offers the Timer function as a kitchen timer.
The time will count down from a specified time and ends
with a beeping sound. Timer settings is up to 99 hours, 59
minutes, 59 seconds. The beeping sound volume and
sound duration is adjustable from the Timer settings in
Configuration menu.
Switching off the timer
When the alarm sounds, you can turn it off by pressing the
[Dial/Select] knob on the radio device or [OK] button on
the remote control.
Alarm
S leep Timer
12. Sleep Timer Setting
- 27 -
13. Configuration
Here you will find the complete settings / options available
to configure your own radio. On the main menu, navigate
to Configuration setting. Press OK and you will see a list of
options available.
Network
• Wireless network
Remove wireless network
Add wireless network
- Scan & select - it will scan out a list of routers
around.
- WPS button - choose this option to connect your
Wi-Fi router via WPS if the router has a WPS button.
Press the WPS button on the router after selecting this
option in the radio. It will start associating to connect.
Note: Always place the radio within 2 meters of the WiFi
router to set up.
If you have already added a router and want to remove
it, choose this option.
AP: [ ]
If you have added more than one routers on the radio
and want to switch to another one, select this option to
change.
Signal
This is to show the strength of the Wi-Fi Signal of the
Wi-Fi router as received by the radio. Usually signal
levels lower than -70dBm is at weaker level and if it
affects the reception of your radio, you may need to
optimize the router location or check any problem of
the router itself.
IP
The IP is set Dynamic by default. Select to change
Fixed IP according to your network condition.
DNS
The DNS is set Dynamic by default. Select to change
<Fixed> DNS according to your network condition.
• Wireless channels
Not all of the Wi-Fi channels are available in every
country. There may be variation between different
countries. Therefore it is necessary to choose the Wi-
Fi channels to ensure the Wi- Fi performs
satisfactory.We have already set the channels
according to the requirement in different countries.
Choose your local country from the list to get the correct
channel.
• Network auto on/off
Always on: The WLAN function remains switched on
(faster access when switching from other modes of
radio).
Auto off in 15/30s: The WLAN function shuts down after
15 or 30 seconds when not in use (to save energy).
Date and Time
• Set date & time
Enter date and time manaully by selecting this option.
• IP
The IP is set Dynamic by default. Select to change
Fixed IP according to your network condition.
• DNS
The DNS is set Dynamic by default. Select to change
<Fixed> DNS according to your network condition.
13. Configuration
• Network connection test
In case there are any issues in connecting the internet
radio station, select this option to check out any failed
items of the network parameters for further diagnosis.
- 28 -
- 29 -
13. Configuration
Date and Time
• Time zone
Set the time zone to synchronize the time automatically
to the network time.
Coupled with the "set time from network" and "DST
(Daylight time saving) will be adjusted automatically if
you choose to use network time.
• Set Time Format
Choose either 12-hour or 24-hour notation you prefer.
• Set clock style
You can choose the clock display in digital form or
Analog style. The selected style will apply in Standby as
well as the big clock display in radio playback.
• Set Date Format
• DST (Day Light Saving)
Enable on/off
• Set time from network
This is designed to synchronize a device's clock with a
time server. Your radio will synchronize the time serverby
default every time it powers up and connects to Internet. You
can change to use other time server by inputting the URL
address (see below Network time server). You can choose
not to use the network time by setting "off" for this option.
• Network time server
• Set time from FM
Choose to synchronize the time with the FM broadcasts.
The accuracy depends on the broadcasting station, and may
vary by station.
It shows the default time server being used to
synchronize the radio device's clock. If you want to
set another time server, input the URL to make the
change.
- 30 -
13. Configuration
Language
There are numbers of language selection.
Playback Setup
This is to set the mode of media playback (USB and media
center): Repeat All, Repeat One or Shuffle.
Choose the state of the radio when power up, by connecting
the power adapter to the radio, or resume after a power cut.
The radio will return to the state as selected. 3 options below:
Standby, resume once ready (plays last-played radio mode), or
Ready to use (stays in Home menu).
Auto Power Save
The radio will automatically turn to Standby/sleep after certain
time of no signal/ not playing. There are several timer
selections available.
Dimmer
You can set the backlight level for the display as you
prefer. There are two settings: Mode and Level
Choose the FM area, scan settings and conditions.
FM Setup
Local radio
Set the local region to access quickly from the Local radio
(Skytune>Local radio).
Power-on options
• Mode ― Normal or Power Saving
Normal ― the display will stay with the same level of
brightness all the time without dim down.
Dim ― the display will dim down after 20 seconds if no
operation is made on the radio.
• Level ― Bright and Dim
Bright ― This is to adjust the level of brightness in
Normal mode.
Dim ― This is to adjust the level of brightness in Dim
mode.
- 31 -
13. Configuration
• Dimmer in Standby
The display brightness in standby mode can be adjusted
manually by turning the rotary knob [Dial/Select] or
press the ▲▼ buttons on remote.
EQ(Equaliser)
Various music genres can be set.
Buffer Time
Sometimes you may experience uneven playback of the
internet radio. This can happen if the internet connection
is slow or network congestion occurs. To help improving
the situation, you can choose longer buffer time to get a
few seconds of radio stream before beginning to play.
The default value is 2 seconds. You can choose 5/10
seconds if you prefer to have a longer buffering time.
Timer
This is to set the alarm tone volume and the duration for
the Timer function.
- 32 -
13. Configuration
Network information
View the network signal and other parameters.To access
quickly to this information, press the [ ] button on the
remote control.
When you use your PC to manage the My favorite
stations, you have to use the IP address and you can view
this info from here. Then type in the IP address
(Configuration > Network Information > IP ) to your PC's
browser input window.
System information
The model number, system MID and software version
(App version) can be found here.
Software Update
There may be software release to upgrade features of the
radio from time to time. Check the update regularly to
keep your radio up to date with the latest software.
Reset to Default
You can restore the radio to the factory's setting, it will clear
all the favorties and reset all settings to default.
- 33 -
Experience an easy way to control tuning internet radio
channels and manage your favourite list via PC or Smart
phone through the web browser.
The recommended browsers are Internet Explorer and
Chrome.
- Connect your PC or Smart phone to the same Wi-Fi
network as your radio.
- Visit www.skytune.net
- On the home page, click “Browse/Search”
- Browse or enter the name to search the radio channel, a
list of internet radio channels will be displayed.
- Click the “ ”symbol
14. Remote control via PC / Smart phone
- 34 -
- It will prompt you whether to "Add Favourite" or "Listen to
Station". Enter the IP address of your radio (e.g.
192.168.1.11):
The IP address can be located on the radio unit as follows:
* The IP address will display with other information
alternately on the top right corner of the display under
Internet radio mode
* On the remote control, press the [ ] button, choose
Network and scroll to IP to view the IP address.
* On the radio, return to the Home menu. Navigate to
Configuration > Network Information > IP
- Select "Listen to Station", click "Send" and the radio unit
will switch playing the channel and the "My Favourite"
page will pop up on the web browser.
You can then choose to add the playing station to favourite
or manage your list by other edit options. Any changes will
synchronize to the radio unit immediately.
14. Remote control via PC / Smart phone
- 35 -
15. Manage my favourite via PC / Smart phone
Input the radio's IP address to the web browser to access
the My Favorite page on PC / Smart phone, to easily
manage/edit the favorite list or add the stations as you
desired.
- 36 -
15. Manage my favourite via PC / Smart phone
You can also add the radio channel if you know the
published audio stream URL with the streaming format as
follow:
1. Audio formats: MP3, AAC, AAC+
2. Stream formats: Shoutcast, Icecast (HTTP, HTTPS)
and HLS
3. Playlist formats: PLS, M3U
4. Sampling frequency: 44.1 KHz and 48 KHz
- 37 -
16. Trouble Shooting
Problem
Cause
Solutions
• Confirm that a Wi-Fi or Ethernet
Wired connected PC can access the
internet (i.e. can browse the web)
using the same network.
• Check that a DHCP server is
available, or that you have
configured a static IP address on the
radio.
• Check that you firewall is not
blocking any outgoing ports. As a
minimum the radio needs access to
UDP and TCP ports 80,443 and
8008, DNS port 53.
Network
down
Cannot
connect
to Wi-Fi
network
Router
restricts
access to
listed MAC
addresses
Obtain the MAC address from
Configuration > Information >
Network > Wi-FiMAC and add to the
allowed equipment list on your access
point.
Note:TheradiohasseparateMAC
addressesforwiredandwireless
networks;
Insufficient
Wi-Fi signal
strength
• Check distance to router; see if a
computer can connect to the
network in this location
• Optimize the distance of the router’s
location
Unknown
encryption
method
Change encryption method on router.
The radio supports WEP, WPA, WPA2
Firewall
preventing
access
Windows Media Player:
varies — non-Microsoft firewalls
may require configuration for UPnP.
- 38 -
16. Trouble Shooting
If your radio
can connect
to the
network
successfully,
but is unable
to play
particular
stations
• The station is not broadcasting at
this time of the day (remember it
may be located in a different time
zone).
• The station has too many people
trying to attach to the radio station
server and the server capacity is not
large enough.
• The station has reached the
maximum allowed number of
simultaneous listeners.
• The update of the link is done
regularly. To get the updated list of
stations, please access from
Internet radio > Skytune. If case a
particular stream is still not working,
please contact us or Skytune to
report the case.
No sound
• Adjust the volume level and check if
it is muted.
• Please check if the power of the
external powered speaker is
switched on if the line out is in use.
Radio got
freeze or no
response
Carry out a reset as follow:
On the radio unit, press the and
Podcast buttons together and
release them, the radio will reboot.
Problem
Cause Solutions
- 39 -
1. If the Internet Radio keeps re-buffering radio
station:
The Internet Radio is streaming the data from the radio
station via your broadband connection, if there is a high
error rate on your broadband connection, or the
connection is intermittent, then it will cause the Internet
Radio to pause until the connection is re-established and
it has received enough data to start playing again.
If your Internet Radio keeps stopping, please check the
DSL modem to ensure that the Broadband line is not
suffering a high error rate or disconnections. If you are
experiencing these problems, you will need to contact
your broadband supplier.
2. What is Buffering?
When playing a stream, the Internet Radio/Media player,
downloads a small amount of the stream before it starts
playing. This is used to fill in any gaps in the stream that
may occur if the internet or the wireless network is busy.
The Internet Radio streams music data from the PC while
you are listening. If a stream gets blocked or experiences
Internet congestion while transferring it may
stop/interfere with the quality of play. If this happens,
check your internet connection speed- it must be faster
than the speed of the streams.
Helpful Tips
- 40 -
Helpful Tips
3. My radio is working but some stations cannot be
played.
The problem may be due to one or more of the
followings:
a. The radio station is no longer broadcasting.
b. The radio station has reached the maximum allowed
number of simultaneous listeners.
c. The radio station has changed the stream
arrangement and the link is no longer valid.
d. The radio station is not broadcasting at the time of the
day (not all stations are broadcasting 24 hours
throughout the day).
e. The Internet connection between your radio and the
radio station server is too slow or unstable to support
the data rate of the broadcast.
- 41 -
Remark: Specification may vary without notice
FM frequency range
8
7.5-108MHz
Telescopic antenna
Technical Specification
Model
W R-336M
Power input
5
V 1.2A
Power voltage
1 00-240V~50/60Hz
Wireless Network
I EEE802.11b/g/n
Wireless network
frequency
2412 - 2484 MHZ
Security Protocol
WEP/WPA/WPA2
Wireless
transmission power
Typical transmission power 14 dBm
(72.2 Mbps); 20 dBm (11b mode)
USB audio playback
Audio output
Stereo headphone jack 3.5 mm
Dimension
185 x 100 x 114 mm (L x D x H)
Audio input
- 42 -
* Internet Radio
* Power adapter
* Remote control (without batteries)
* User manual
WEEE and Recycling
The European laws do not allow any more the disposal
of old or defective electric or electronic devices with
the household waste. Return your product to a
municipal collection point for recycling to dispose of it.
This system is financed by the industry and ensures
environmentally responsible disposal and the
recycling of valuable raw materials.
In the box
V_130525
- 43 -
