InfoTag2.67 Service Manual
5
1. General
1.1 Model Specification
Model
:
InfoTag2.67
Model Description
:
InfoTag2.67 COLOUR
Dimensions (in mm)
:
Product size
-
78.01(L) X 41.21(H) X 12.85(W)
LCD Size
-
60.086mm (H) x 31.3mm (V)
LCD Resolution
-
384 x 200 dots (Dpi:162)
Weight
:
40g approx.
Power Source
:
DC Cell Button Battery 3.0V x 2
Operating Temperature
:
5 °C to + 40 °C
Humidity
:
65% Max. Non-condensing
Housing material
:
ABS plastic casing, PC battery cover
Battery Specification
:
Type
-
CR2450 (Cell Button Battery)
Nominal Voltage
-
3.0V
Life Time
-
5 years (2 update/day)
Weight
-
6.6g approx.
1.2 Operating Specification
Frequency band
:
2.402 GHz ~ 2.480 GHz
Transmit power
:
+5 dBm (max)
Receiver sensitivity
:
-90dBm (typical)
RF range
:
~ 25m to IB-3700
(*Max. up to 70m LOS)
*Note: The RF Range maybe varies in different environment.
Certification
:
CE, RCM, FCC. NCC. IC
InfoTag2.67 Service Manual
6
2. InfoTag2.67Diagram
2.1 Overall Layout and Label design
Front View
Back View
InfoTag2.67 Service Manual
7
Nameplate
Product shows approval content by default. To retrieve this content, simple power on/off the device.
InfoTag2.67 Service Manual
8
2.2 Replacement of Info Tag Battery
i. Pull off the battery cover from back of the Info Tag.
ii. Replace the new battery. (Ensure the Battery polarity is correct)
Location of Battery in Info Tag
+
Battery
Battery Cover
Info Tag
Caution: Dispose of the Battery according the Safety Guideline.
i. Avoid placing the battery in reverse polarity.
ii. Do not heat or dispose of fire. May burst or release toxic material.
iii. Do not charge.
iv. Do not short circuit.
v. Do not solder the battery directly.
vi. Do not ingest battery, Chemical Burn Hazard
vii. Keep new and used batteries away from children
viii. If the battery compartment does not close securely, stop using the product and
keep it away from children
ix. Do not solder the battery directly.
InfoTag2.67 Service Manual
9
2.3 Button Cell Specifications
2.4 ESL Attachment (Refer to ESL Attachment Catalogue)
For all information about the ESL Various Attachment type, function, installation etc. Please refer to ESL
Attachment Catalogue
http://www.digiesl.com.tw/digiesl/sys4.asp
http://www.teraoka.com.tw/digi/article.aspx?id=77
http://www.digiesl.com/
2.5 Product Handling of Info Tag
Handle product with care. Do not expose product to corrosive chemical solution, any organic solvent
acidic or alkaline. If cleaning is required, wash only water or mild soap solution.
Do not attempt to disassemble, apply force or heavy load to the product.
No user serviceable parts inside except battery
InfoTag2.67 Service Manual
10
3. Revision Records
Serial
No.
Date
Edition
Status
Description of Changes
Software
Version
Remarks
001
JAN 26
00
First Release
F013
