2
Table of Contents
Getting started
3 Device layout and functions
9 Turning the Chromebook on and off
11 Using networks
Basics
12 Keyboard
14 Touchpad
16 SIM or USIM card (nano-SIM card)
tray (LTE models only)
17 Mobile data (LTE models only)
18 Memory card slot
20 Wireless LAN
21 Security slot
Settings & Upgrade
22 Display brightness
23 Volume
24 Battery
Usage notices
27 Precautions for using the device
31 Ergonomic tips
34 Safety precautions
42 How to find the standby power
consumption information for this
product
Appendix
43 Product specifications
44 Important safety information
46 Replacement parts and accessories
48 Regulatory compliance statements
55 WEEE symbol information
57 Samsung package Take-Back
program (USA only)
3
Getting started
Device layout and functions
Leaving the screen idle for extended periods may result in afterimages (screen
burn-in) or ghosting. Turn off the screen when you are not using the Chromebook.
•
Features or options may differ depending on the model.
•
The items marked as optional may not be provided or may be provided in
different locations.
•
Since some storage space is reserved for system recovery and operations, the
available storage space may be less than the actual capacity.
Front view
▶
For 14 inch models
LTE antenna
Display
LTE antenna
Microphone
Front camera
Front camera
indicator light
Power button
Keyboard
Touchpad
Getting started
4
▶
For 11 inch models
LTE antenna
Display
LTE antenna
Microphone
Front camera
Front camera
indicator light
Power button
Keyboard
Touchpad
<Device layout and functions: Front view>
Name Description
Front camera indicator
light
This indicates the front camera operating status.
Microphone You can use the built-in microphone.
LTE antenna (LTE
models only)
Transmits and receives radio waves.
Front camera
Using this camera, you can take still pictures and record
video.
Display The screen’s images are displayed here.
Power button Turns the Chromebook on and off.
Keyboard Enter text or control Chromebook functions.
Touchpad
•
Moves the cursor and selects options.
•
Functions as a mouse.
Getting started
5
Right view
▶
For 14 inch models
USB 3.2 port
USB Type-C port
Security slot
SIM card tray
<Device layout and functions: Right view>
Name Description
SIM card tray (LTE
models only)
Insert the SIM or USIM card.
USB Type-C port
Connect the adapter to charge the Chromebook. You
can also use or charge USB Type-C devices. Also, you can
connect external display devices.
USB 3.2 port
Connect various accessories, such as a mouse, camera, or
keyboard.
Security slot
Secure the Chromebook by connecting an optional lock
and cable to it.
▶
For 11 inch models
Earpiece/Head
set jack
SIM card tray
Security slot
Getting started
6
<Device layout and functions: Right view>
Name Description
SIM card tray (LTE
models only)
Insert the SIM or USIM card.
Earpiece/Headset jack
Connect an earpiece or a headset to the Chromebook to
listen to audio.
Security slot
Secure the Chromebook by connecting an optional lock
and cable to it.
Left view
▶
For 14 inch models
Operating status
LED
Memory card slot
USB Type-C port
Earpiece/Headset jack
<Device layout and functions: Left view>
Name Description
USB Type-C port
Connect the adapter to charge the Chromebook. You
can also use or charge USB Type-C devices. Also, you can
connect external display devices.
Operating status LED Shows the operating status of the Chromebook.
Earpiece/Headset jack
Connect an earpiece or a headset to the Chromebook to
listen to audio.
Memory card slot Insert a memory card into the slot.
Getting started
7
▶
For 11 inch models
USB Type-C port
Memory card slot
USB 3.2 port
Operating status LED
<Device layout and functions: Left view>
Name Description
USB 3.2 port
Connect various accessories, such as a mouse, camera, or
keyboard.
USB Type-C port
Connect the adapter to charge the Chromebook. You
can also use or charge USB Type-C devices. Also, you can
connect external display devices.
Operating status LED Shows the operating status of the Chromebook.
Memory card slot Insert a memory card into the slot.
The charging feature of the USB Type-C port
•
It may take longer to charge the battery when charging a connected device.
•
The battery power level may be reduced when charging a connected device while
the Chromebook is powered by the battery.
•
The charging status of the connected device is not displayed on the Chromebook.
•
This charging feature may not be available on some devices.
•
When the Chromebook is turned off, the device connected to the USB Type-C port is
not charged.
Getting started
8
Bottom view
▶
For 14 inch models
Internal battery
Speaker
Speaker
▶
For 11 inch models
Internal battery
Speaker
Speaker
<Device layout and functions: Bottom view>
Name Description
Internal battery
Provides power to the Chromebook when not connected to
an adapter.
Speaker Sound is emitted from the speakers.
If the bottom of the Chromebook is replaced, the model name, serial number, and
some logos will no longer be present. For more information, contact the Samsung
Service Center to request assistance.
Getting started
9
Turning the Chromebook on and off
Fully charge the battery using the supplied adapter before using the Chromebook
for the first time.
Turning the Chromebook on
1 Before turning on the Chromebook, check that the battery is charged and charge it if
necessary.
2 Open the display panel. The Chromebook automatically turns on.
If the Chromebook does not turn on automatically, press the Power button.
Getting started
10
Turning the Chromebook off
Using screen buttons
1 Select the status area on the shelf.
2 Select the Power icon ( ).
Save all data before turning off the Chromebook.
Using the Power button
Press and hold the Power button for about 2 seconds and select
Power off
to shut down
the device.
To shut down the device when the system has frozen unexpectedly, press and hold the
Power button for at least 8 seconds.
Controlling the power of the device
You can adjust the settings for the selected power options.
Tap the status area on the shelf, tap the Settings icon (
) to open the Settings window,
and then tap
Device
→
Power
to select the power options.
<Power options>
Status Power options
If the display panel is
closed
•
Signed-in state: Enters power saving mode
•
Signed-out state: The Chromebook is turned off
If there is no input for a
predetermined period of
time
•
Signed-in state: Enters power saving mode
•
Signed-out state: The Chromebook is turned off
If the Power button is
pressed and held
•
Signed-in state: The power menu appears
•
Signed-out state: The power menu appears
If the screen is locked in power saving mode
Tap the touchpad or press any key to turn the screen on and enter the password to
unlock the screen.
Getting started
11
Using networks
You can use networks, such as a Wi-Fi, Bluetooth or mobile network.
Select the status area on the shelf and select the icon of the desired network to turn it
on.
When not using the network, select the icon to turn it off.
Some features may not be available depending on the model.
12
Basics
Keyboard
Hot keys and function keys are discussed in the following sections.
•
The keyboard image may differ from the actual keyboard.
•
The keyboard may differ depending on your country. The following mainly
describes the hot keys and function keys.
Hot key functions
Here is an overview of the hot keys on the top row of the keyboard.
<Hot key functions>
Keys Description
Go to the previous page in your browser history.
Go to the next page in your browser history.
Reload your current page.
Hide the tabs and switch to full-screen mode.
Enter overview mode, which shows all windows.
Decrease screen brightness.
Increase screen brightness.
Mutes the sound.
In mute mode, press the key to unmute the sound.
Decrease the volume.
Increase the volume.
Basics
13
Shift key
Hold the
shift
key down to enter upper case letters.
Search for keyboard shortcuts
Press the following keys at the same time to check the keyboard shortcuts supported in
Chrome OS.
Search key
The Search key is located where the Caps Lock key is originally placed on a traditional
keyboard.
Press the Search key to launch the Launcher.
To change the Search key to the Caps Lock key, select the status area on the shelf, select
the Settings icon (
)
→
Device
→
Keyboard
, and switch the function to caps lock.
Basics
14
Touchpad
Use the touchpad to move the cursor or select an item.
•
Use the touchpad only with fingers. The touchpad will not recognize actions of
other objects.
•
Images and the touchpad layout may differ depending on the model.
Basic touchpad functions
•
Moving: To move the cursor, move a finger on the touchpad.
•
Clicking: Tap the touchpad.
Tap
•
Double-clicking: Double tap the touchpad.
Tap-tap
Basics
15
•
Right-clicking: Press the touchpad with two fingers simultaneously.
Tap
•
Dragging: To move an icon or an app to a desired location, press and hold it and then
drag it to the target position.
Press and hold the
touchpad
Move
Adjusting the touchpad settings
If the touchpad is too sensitive, adjust its reaction speed.
1 Select the status area on the shelf.
2 Select the Settings icon ( ) to open the Settings window.
3 Tap
Device
→
Mouse and touchpad
and adjust the
Touchpad speed
adjustment bar.
Basics
16
SIM or USIM card (nano-SIM card) tray (LTE
models only)
Insert the SIM or USIM card.
•
Use only a nano-SIM card (sold separately).
•
Use caution not to lose or let others use the SIM or USIM card. Samsung is not
responsible for any damages or inconveniences caused by lost or stolen cards.
•
It is only for data network. The calling feature is not supported.
•
Some services that require a network connection may not be available
depending on the service provider.
Installing the SIM or USIM card
1 Insert the ejection pin into the hole on the tray to loosen the tray.
Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may
be damaged.
2 Pull out the tray gently from the tray slot.
Be careful to not hurt your fingertip while pulling out the tray.
3 Place the SIM or USIM card on the tray with the gold-coloured contacts facing
downwards.
Basics
17
4 Gently press the SIM or USIM card into the tray to secure it and insert the tray back
into the tray slot.
2
1
Mobile data (LTE models only)
You can insert the SIM or USIM card so you can access the internet using your mobile
data connection.
You may incur additional charges when using a mobile network.
Turning the mobile data on
1 Select the status area on the shelf.
2 Select the network.
3 Tap the
Mobile data
switch to activate it.
Mobile data will be connected.
Basics
18
Turning the mobile data off
To save battery power, turn off the mobile data when not in use.
1 Select the status area on the shelf.
2 Select the network.
3 Tap the
Mobile data
switch to deactivate it.
Mobile data will be disconnected.
Memory card slot
Use a memory card to transfer data to other devices. You can use data stored on your
device, such as digital cameras, phones, or tablets, on your Chromebook, or you can take
your saved data to another device.
Memory cards are sold separately.
This Chromebook supports the following types of memory cards.
<Supported memory card type>
Abbreviation Description
micro SD micro Secure Digital
micro SDHC micro Secure Digital High Capacity
micro SDXC micro Secure Digital eXtended Capacity
•
Some memory cards may not be fully compatible with the Chromebook. Using
an incompatible card may damage the Chromebook or the memory card, or
corrupt the data stored in it.
•
Use caution to insert the memory card in the indicated direction.
•
Store the card separately to prevent losing the card when moving the
Chromebook.
•
Memory card speeds vary.
Basics
19
Inserting a memory card
If a memory card adapter or an unnecessary card is inserted in the memory card slot,
remove it. Then insert a memory card into the slot in the indicated direction.
Removing a memory card
When you push the card, it clicks and disengages from the memory card slot. Grasp the
end of the card and pull it out of the slot.
•
Available data formats depend on the current version of the Chrome OS.
•
Data on the card can be saved in the
Downloads
folder under
My files
.
•
The maximum file size will vary depending on Chrome OS.
Basics
20
Wireless LAN
Connect the Chromebook to a wireless network to use the internet.
The pictures in this manual may differ from the actual product depending on the
wireless LAN device model.
About Access Point (AP)
An Access Point (AP) is a network device that bridges wired and wireless LANs and
corresponds to a wireless hub in a wired network. Multiple devices can be connected to
an AP.
Connecting to a Wi-Fi network
1 Select the status area on the shelf.
2 Select the network icon (
) to activate the Wi-Fi network feature.
The available Wi-Fi list will appear.
3 Select a network from the list of detected wireless networks.
4 Enter a password, if necessary, and select
Connect
.
Once the Chromebook has been connected to a wireless network, it will attempt to
connect to it automatically when it is available. If you require a network password,
contact the system administrator.
•
If the Wi-Fi network is successfully connected, the network icon ( ) will be
displayed on the shelf.
•
If the Wi-Fi network is not properly connected, the network icon ( ) will be
displayed on the shelf.
•
The white part of the network icon on the shelf represents the signal strength of
the Wi-Fi network.
Basics
21
Security slot
You can secure the Chromebook by connecting a lock and cable to the security slot.
Tie the lock and cable to a fixed object and install the other end of the cable to the
security slot.
To use this feature, you must purchase a lock and cable (sold separately) and use a
Nano Lock from Kensington. If you use a lock other than a Nano lock, it cannot be
guaranteed to work properly. Your product may differ from the one shown above.
For more information, refer to your lock’s manual.
22
Settings & Upgrade
Display brightness
Adjust the display brightness to reduce eye strain and save power.
Controlling brightness using the keyboard
•
Adjust the display brightness by pressing the key to decrease brightness or
the key to increase brightness.
•
Whenever you press the or key, the display brightness will be adjusted
by one level.
Controlling brightness using the shelf
1 Select the status area on the shelf.
2 Drag the adjustment bar to the desired brightness.
Brightness
adjustment bar
Instructions for Cleaning the display
Clean the display panel with a soft cloth lightly moistened with Chromebook
cleansing detergent moving in one direction.
Cleaning the display panel with excessive force can damage the display.
Settings & Upgrade
23
Volume
Adjust the system volume or sound volume when playing music or video.
Controlling volume using the keyboard
•
Adjust the volume by pressing the key to turn down the volume or the
key to turn up the volume.
•
Whenever you press the or key, the volume will be adjusted by one
level.
•
Mute the sound by pressing the key. In mute mode, press the key to
unmute the sound.
Controlling volume using the button
Press the Volume button on the left side of the Chromebook to adjust the volume.
Controlling volume using the shelf
1 Select the status area on the shelf.
2 Drag the adjustment bar to the desired volume.
Volume adjustment
bar
Settings & Upgrade
24
Battery
Fully charge the battery using the adapter before using the Chromebook for the first
time.
•
Use only Samsung-approved adapters, batteries, and cables. If you use
unapproved adapters, the battery cannot be charged or it may explode or
damage the Chromebook.
•
Incorrectly connecting the adapter may cause serious damage to the
Chromebook.
•
To safely remove or replace the battery, it is recommended to take the
Chromebook to a Samsung Service Center. You will be charged for this service if
the repair is not covered under warranty.
•
You can use the Chromebook while it is charging, but the battery charging time
may increase. If the battery temperature rises too much, the charging may stop
as a safety measure.
To restore the battery power after cutting it, connect the adapter.
Charging the battery
Fully charge the battery using the supplied adapter before using the Chromebook
for the first time, or when the Chromebook is completely discharged.
1 Connect the adapter to the USB Type-C port of the Chromebook. You can use the USB
Type-C ports on either side of the Chromebook.
Settings & Upgrade
25
2 Plug the adapter into an electric socket.
If the battery is fully discharged, the Chromebook will not turn on immediately
with the adapter. A minimum level of battery power will be charged slowly for
safety while the Power LED blinks red. You can turn on the Chromebook after the
Power LED stops blinking.
3 When the battery is fully charged, the power LED turns green. Disconnect the adapter
from the Chromebook.
<Status of operating status LED>
Power LED Status
Blinks red Pre-charging
Red Charging
Green Fully charged
Blue Turned on
4 Unplug the adapter from the electric socket.
Do not allow the adapter to make contact with your skin for a long time. A
low-temperature burn may result.
Settings & Upgrade
26
Battery status
View the current remaining battery power on the shelf.
Battery usage time
Batteries are replaceable items and over time the battery’s capacity to hold a charge and
its power level is reduced. If a battery can only hold its charge for half of the time that it
could when new, it is recommended to purchase a new, replacement battery.
27
Usage notices
Precautions for using the device
•
This user manual is specially designed to detail the Chromebook’s functions and
features.
•
The user manual supplied with the Chromebook may vary depending on the model.
•
Please read this manual before using the Chromebook to ensure safe and proper
use.
•
Optional accessories, some devices, and software referred to in this manual may
not be provided or may not be subject to upgrades. Note that the Chromebook
environment referred to in the user manual may not be the same as your
environment.
•
Available features and additional services may vary depending on the Chromebook
or operating system.
•
This user manual describes procedures for using the touchpad, mouse and touch
screen. Instructions for using the touch screen are for models with the touch screen
feature.
•
Images and screenshots are those of the representative model of the series and may
differ in appearance from the actual product.
•
Content may differ from the final product and is subject to change without
prior notice. For the latest version of the manual, refer to the Samsung website,
www.samsung.com.
Instructional icons and expressions
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to the Chromebook or other
equipment
Note: notes, usage tips, or additional information
Usage notices
28
To service your Chromebook
For inquiries about the Chrome operating system or applications, visit
www.google.com/support/chromeos.
If you have a problem while using the Chromebook hardware, please contact our
Samsung Service Center below or visit www.samsung.com/sec/support/guarantee.do.
If you replace or upgrade the hardware yourself, the Chrome operating system will not
be automatically updated and the product will not work properly.
Copyright
Copyright © 2025 Samsung Electronics Co., Ltd.
This manual is protected under international copyright laws.
No part of this manual may be reproduced, distributed, translated, or transmitted in any
form or by any means, electronic or mechanical, including photocopying, recording, or
storing in any information storage and retrieval system.
Chromebook specifications or the contents of this manual may be changed without prior
notice if the Chromebook’s functions are upgraded.
Trademarks
•
Samsung and the Samsung logo are trademarks or registered trademarks of
Samsung Electronics Co., Ltd.
•
Bluetooth
®
is a registered trademark of Bluetooth SIG, Inc. worldwide.
•
Wi-Fi
®
, Wi-Fi Direct
™
, Wi-Fi CERTIFIED
™
, and the Wi-Fi logo are registered
trademarks of the Wi-Fi Alliance.
•
All other trademarks and copyrights are the property of their respective owners.
Usage notices
29
Chrome OS Software License
The software included in this product contains copyrighted software that is licensed
under the GPL/LGPL.
You may obtain the complete Corresponding Source code from website:
http://git.chromium.org/gitweb/
This offer is valid to anyone in receipt of this information.
Energy Star (USA only)
As an ENERGY STAR
®
Partner, Samsung has determined that this Product meets the
ENERGY STAR Guidelines for energy efficiency. The ENERGY STAR Program has reduced
greenhouse gas emissions and saved energy through voluntary labeling. Samsung is
a proud ENERGY STAR Partner and commits to meet the guidelines for this product to
be ENERGY STAR certified. By selecting an ENERGY STAR certified product, you reduce
greenhouse emissions, save energy, and can lower operating cost. For more information,
see http://www.energystar.gov/.
•
The Power Management setting of this product has been enabled by default and has
various timing settings (of up to 300 minutes for energy saving. In case you don't
want the power management setting enabled, select "Never").
•
To change this in Settings, go to the System menu > Power & sleep menu > Screen/
Sleep timeout option.
This product can be awakened from sleep mode by pressing the Power button.
Usage notices
30
Operating system and software support
If a problem occurs because of the reinstallation of other operating systems (OS) or a
previous version of an OS pre-installed on this Chromebook, or a software that does
not support the OS, the company will not provide technical support, a replacement or
refund, and if our service engineer visits you because of this problem, a service charge
will be applied.
Performance Restrictions
Online games and some games (3D, 2D) may not be supported and Full HD video and
some high bit rate HD video playback may be slow and stutter on this Chromebook.
Product capacity representation
Memory Capacity Representation
The memory capacity reported in the Chrome OS is less than the actual capacity of
memory. This is because BIOS or a video adapter uses a portion of memory or claims it
for further use.
For example, for 1 GB (= 1,024 MB) memory installed, OS (Windows, Chrome, etc.) may
report the capacity as 1,022 MB or less.
Usage notices
31
Ergonomic tips
Maintaining proper posture during Chromebook use is very important to prevent
physical injury. Improper or prolonged keyboard use may result in repetitive strain
injury. Viewing the monitor screen for extended periods of time may result in eye strain.
Therefore, please follow these guidelines carefully when setting up and using the
Chromebook.
Back and neck
•
Use an adjustable chair with firm, comfortable support.
•
Adjust the height of your chair so that thighs are horizontal to the floor and feet are
flat on the floor.
•
The back of the chair should support the lower back. Adjust the backrest to fit your
body properly.
•
Sit back fully in your chair and straighten the back and neck. Avoid leaning forward
or craning your neck toward the Chromebook screen.
•
Avoid using the Chromebook while lying down or on your lap. If the Chromebook’s
temperature increases, there is a danger of burn injury.
•
The instructions in this manual have been prepared so that they can be applied
to the range of needs of general users. If the user is not included in the range,
the recommendations should be applied according to the user’s needs.
•
Images may differ from actual products.
Arms and hands
•
When using the keyboard and touchpad, the shoulders should be relaxed. The upper
arm and forearm should form an angle that is slightly greater than a right angle,
with the wrist and hand in almost a straight line.
•
Use a light touch when typing or using the touchpad and keep the hands and fingers
relaxed. Avoid rolling the thumbs under your palms or supporting the wrists on the
desk while typing.
•
Use an external keyboard and mouse when using the Chromebook for long periods.
When using an external keyboard and mouse, position the devices at the same
height as the Chromebook and within comfortable reach.
Usage notices
32
Eye position and display illumination
•
Position the screen at least 50 cm away from your eyes.
•
Adjust the height of the screen so that its top edge is equal to or just below the level
of your eyes.
•
Avoid setting the screen’s brightness settings excessively high.
•
Keep the screen clean.
•
If wearing glasses, clean them before using the Chromebook.
•
When referring to printed content while typing, use a static paper holder to hold the
paper at about the same height as the monitor.
Hearing and volume control
•
Ensure that the volume is not too loud before using a headset or earphones.
Excessive exposure to loud sounds can cause hearing damage.
•
Always turn the volume down before plugging the earphones into an audio source
and use only the minimum volume setting necessary to hear your conversation or
music.
•
Avoid using earphones for long periods of time.
•
Default audio settings can be changed by software and driver updates without your
knowledge. Always recheck equalizer and volume settings before listening to audio.
•
To prevent possible hearing damage, do not listen at high volume levels for long
periods.
Usage notices
33
Operating conditions
•
Take at least a 10 minute break every hour.
•
Avoid using the Chromebook in dark locations. Use the Chromebook with as much
ambient light as you would when reading a book.
•
Indirect illumination is recommended. Use a curtain to prevent reflections and glare
on the screen.
•
While operating a Chromebook and talking on a phone, use a headset. Using the
Chromebook while holding a phone on your shoulder or with your neck may lead to
muscle strain or injury.
•
Keep frequently used items within reach.
•
Only use the Chromebook within the temperature and humidity ranges specified in
this manual.
Use caution when exposed to flashing lights.
•
While using your Chromebook, leave some lights on in the room and do not hold the
screen too close to your eyes.
•
Seizures or blackouts can occur when you are exposed to flashing lights while
watching videos or playing Flash-based games for extended periods. If you feel any
discomfort, stop using the Chromebook immediately.
•
If anyone related to you has experienced seizures or blackouts while using a similar
product, consult a physician before using the Chromebook.
•
If you feel discomfort, such as a muscle spasm, or disoriented, stop using the
Chromebook immediately and consult a physician.
•
To prevent eye strain, take frequent breaks while using the Chromebook.
Reduce the risk of repetitive motion injuries.
When you repetitively perform actions, such as pressing keys, drawing characters on
a touch screen with your fingers, or playing games, you may experience occasional
discomfort in your hands, neck, shoulders, or other parts of your body. When using your
Chromebook for extended periods, hold the Chromebook with a relaxed grip, press the
keys lightly, and take frequent breaks. If you continue to have discomfort during or after
such use, stop using the Chromebook and consult a physician.
Usage notices
34
Safety precautions
For your safety and security and to prevent damage, carefully read the following safety
instructions. This ’Safety precautions’ relate to Chromebook use. Some of the content
may not be applicable to your Chromebook.
•
Since this is commonly applied to Samsung Chromebooks, some pictures may
differ from actual products.
•
The product mentioned in this guide refers to all items supplied with the
Chromebook including the battery, the adapter, and all other Samsung-provided
accessories.
Warning
Failure to follow the instructions marked with this symbol may result in physical injury
or fatality.
Power related
Handle the power cord with care.
•
Do not touch with wet hands.
•
Do not use a damaged power cord.
•
Do not overload a multi-outlet or an extension cord beyond the specified voltage/
current capacity.
•
Correctly insert the plug into the outlet.
•
Do not unplug the power cord by pulling on the cable.
•
Unplug the wall-mount adapter (integrated plug and power adapter) from the wall
outlet while holding the body and pulling it in the direction of the arrow.
Failure to do so may result in electric shock or fire.
Connect the power cord to the adapter firmly.
An improper connection may result in a fire.
Use the approved adapter or cable included in the product box.
If you use the unapproved adapter or cable, it cause the damage or malfunction of the
Chromebook.
Usage notices
35
Use only properly earthed electric sockets or extension cords.
Unearthed electric sockets or extension cords may cause electric shock. Any connection
to unearthed electric sockets or extension cords may produce an electric field from a
current leak.
If water or other substances enter the product, disconnect the power cord and contact
a Samsung Service Center. For Chromebooks that are supplied with an optional
removable battery, disconnect the battery.
Failure to do so may result in electric shock or fire caused by a Chromebook malfunction.
Do not let dust accumulate on the power cord or the electric socket. Regularly wipe the
power cord and the electric socket with a dry cloth.
Failure to do so may result in electric shock or fire.
Do not bend or damage the power cord or the adapter with a heavy or sharp-edged
object.
A damaged cable or cord may result in electric shock or fire.
Keep the battery, adapter, and power cord away from infants, children, and pets.
Failure to do so may result in electric shock or damage.
Battery usage related
Use manufacturer-approved batteries, adapters, accessories, and supplies.
•
Using generic batteries or adapters may shorten the life of your product or cause
the Chromebook to malfunction. They may also cause a fire or cause the battery to
explode.
•
Use only Samsung-approved battery and adapter specifically designed for your
device. Incompatible battery and adapter can cause serious injuries or damage to
your device.
•
Samsung cannot be responsible for the user’s safety when using accessories or
supplies that are not approved by Samsung.
Take care to not allow metal objects such as a key or clip to touch the battery terminals
(metal parts).
This may cause excessive current and result in fire, burns, or damage to the battery.
If the Chromebook or the Chromebook battery leaks, emits strange odors, or swells,
immediately stop using the Chromebook and contact a Samsung Service Center.
Failure to do so may result in an explosion or fire.
Usage notices
36
Replace a run-down battery with a new, Samsung-approved battery.
Dispose of worn-out batteries properly.
•
There is a danger of fire or explosion.
•
The battery disposal method may differ depending on your country and region.
Dispose of the used battery in an appropriate way.
When removing the real time clock (RTC) battery, keep it away from infants and
children.
If a child swallows the battery, the child may suffocate. If this happens, immediately
contact a doctor.
Do not throw or disassemble the battery and do not put it into water.
There is a danger of injury, fire or explosion.
Charge the battery according to the instructions in the manual.
Failure to do so may cause an explosion or fire.
Usage related
Do not use the Chromebook on heated floors or electric pads, or on beds, blankets, or
cushions that block the ventilation of the Chromebook.
A blocked vent causes the Chromebook to overheat, resulting in an explosion, fire, burns,
or Chromebook malfunction.
Do not use the Chromebook in hot or humid locations, such as a bathroom, sauna, or
inside a car during summer.
Failure to do so may result in Chromebook malfunction or electric shock.
The Chromebook can be used in locations with an ambient temperature of 10 °C to 35 °C
and a relative humidity of 20 % to 80 %RH.
To avoid suffocation, keep the plastic bag away from infants and children.
Putting a plastic bag over the head may result in suffocation.
Never heat the Chromebook (or the battery) or put the Chromebook (or the battery) into
a fire or microwave.
Failure to do so may result in an explosion or fire.
Usage notices
37
Before cleaning the Chromebook, disconnect all the cables that are connected to the
Chromebook. For Chromebooks that are supplied with an optional removable battery,
disconnect the battery.
Failure to do so may result in electric shock or fire.
Keep the Chromebook away from water or liquid.
Water or liquid entering the Chromebook may short-circuit the Chromebook, resulting in
electric shock or fire.
If the Chromebook is dropped or broken, disconnect the power cord and contact
a Samsung Service Center. For Chromebooks that are supplied with an optional
removable battery, disconnect the battery.
Using a broken Chromebook may result in electric shock or fire.
Do not touch the Chromebook’s surface or the vents for extended periods while the
Chromebook is on.
Contact with the vent or the surface extended periods may result in low-temperature
burns, such as redness on the skin.
Do not carry your device in your back pockets.
•
The device may be damaged, explode, or result in a fire if too much pressure is
applied to it.
•
You may be injured if you are bumped or fall.
Caution
Failure to follow instructions marked with this symbol may result in minor physical
injury or damage to the Chromebook.
Installation related
Do not block the ports (holes), vents, etc., of the product and do not insert objects.
Damage to a component within the Chromebook may cause electric shock or fire.
When using the Chromebook on its side, ensure the vents are clear and facing upwards.
Failure to do so, may cause the internal temperature of the Chromebook to rise and the
Chromebook to malfunction or halt.
Keep the Chromebook’s vents at least 15 cm away from walls and other objects.
Failure to do so may result in physical injury.
Usage notices
38
Do not place or use the Chromebook on slanted or vibrating surfaces.
Failure to do so may result in Chromebook malfunction or damage.
Do not place heavy objects on the product.
This may cause a problem with the Chromebook. In addition, the object may fall and
cause injury or damage the Chromebook.
Properly shut down, disconnect and secure the Chromebook cables before moving it.
Failure to do so may damage the Chromebook or cause someone to trip over a loose
cable.
Usage related
Do not use the pen for unintended purposes, such as poking the body, like eyes or ears,
and do not put it in your mouth.
Doing so may result in physical injury.
Do not place a candle, lit cigar, etc., over or on the product.
There is a danger of fire.
Make sure to have the product tested by a safety service engineer after repairing the
product.
Using a repaired product without testing it for safety may cause an electric shock or fire.
In case of lightning, immediately turn the system off, then disconnect the power cord
from the wall outlet and phone line from modem.
There is a danger of electric shock or fire.
Connect only permitted devices to the connectors or ports of the Chromebook.
Failure to do so may result in an electric shock or fire.
Close the display panel only after checking if the Chromebook is turned off.
The temperature may rise and it may cause deformation of the product.
Do not drop or hit the Chromebook against anything.
Failure to do so may result in physical injury or Chromebook malfunction.
When handling Chromebook parts, follow the instructions on the manual supplied with
the parts.
Failure to do so may result in damage to the product.
Usage notices
39
If the product emits smoke or there is a burning smell, disconnect the power plug from
the wall outlet and contact a Samsung Service Center immediately. For Chromebooks
that are supplied with an optional removable battery, disconnect the battery.
There is a danger of fire.
Do not store your device near or in heaters, microwaves, hot cooking equipment, or high
pressure containers.
•
The battery may leak.
•
Your device may overheat and cause a fire.
Do not insert your fingers into the ports (holes), card slot, or vents.
There is a danger of injury or electric shock.
Use recommended Chromebook cleansing solutions when cleaning the product and
only use the Chromebook when it is completely dry.
Failure to do so may result in electric shock or fire.
Do not use the product if it is cracked or broken.
Broken glass or acrylic could cause injury to your hands and face. Take the device to a
Samsung Service Center to have it repaired.
When using wireless communication (LAN, Bluetooth, etc.) always follow applicable
instructions. For example, airlines and hospitals have strict requirements.
Avoid exposing a drive to magnetic fields. Security devices with magnetic fields include
airport walk-through devices and security wands. The airport security devices that
check carry-on luggage use X-rays instead of magnetism and will not damage a drive.
Keep the Chromebook away from magnetic material.
•
Magnetic materials may cause Chromebook malfunction or cause the battery to
discharge.
•
To avoid damaging the Chromebook or magnetic stripe cards, such as credit cards,
keep magnetic stripe cards away from the Chromebook.
Usage notices
40
Do not use your Chromebook in a hospital or on an aircraft that can be interfered with by
radio frequency.
•
Avoid using your Chromebook within a 15 cm range of a pacemaker, if possible, as
your Chromebook can interfere with the pacemaker.
•
To minimize possible interference with a pacemaker, use your Chromebook only on
the side of your body that is opposite the pacemaker.
•
If you use medical equipment, contact the equipment manufacturer before using
your Chromebook to determine whether or not the equipment will be affected by
radio frequencies emitted by the Chromebook.
•
When in a hospital, turn off your Chromebook and follow all hospital regulations.
Radio frequencies emitted from the Chromebook may affect medical equipment.
Upgrade Related
Do not attempt to upgrade the Chromebook, unless you are qualified. Otherwise,
contact a Samsung Service Center or an authorized technician.
When you upgrade permitted devices, according to the manual, follow the specified
instructions in the manual to upgrade them. Do not disassemble any other parts by
yourself.
Failure to do so may result in Chromebook malfunction, electric shock, or fire.
Take care when touching the product or parts.
The Chromebook may be damaged or you may be injured.
Do not disassemble the power supply unit in any circumstances.
Failure to do so may result in electric shock, fire, or an explosion.
Shut down the Chromebook and disconnect all cables before disassembling the
Chromebook. For Chromebooks that are supplied with an optional removable battery,
disconnect the battery.
Failure to do so may cause electric shock.
Make sure to close the Chromebook cover before connecting the power after a
reassembly.
There is a danger of electric shock if your body touches an internal part.
Never disassemble or repair the product by yourself.
There is danger of an accident. Use an authorized Samsung Service Center.
Usage notices
41
To connect a device that is not manufactured or authorized by Samsung, enquire at a
Samsung Service Center before connecting the device.
There is a danger of damaging the product.
Storage and movement related
Do not store the Chromebook in an enclosed space, such as a Chromebook bag, while it
is running.
Failure to do so may result in fire. Completely shut down the Chromebook before putting
the Chromebook into an enclosed space.
When carrying the Chromebook with other items, such as the adapter, mouse, books
etc., take care not to press anything against the Chromebook.
If a heavy object is pressed against the Chromebook, a white spot or stain may appear on
the display.
Do not operate or look at the Chromebook while driving a vehicle.
There is a danger of a traffic accident. Please concentrate on driving.
For long periods of inactivity or storage, discharge the battery and separate it from the
Chromebook (for external or removable battery types).
Cautions on preventing data loss (storage device (such as HDD, SSD,
eMMC) management)
Take care not to damage the data on a storage device (such as HDD, SSD, eMMC).
•
Subjecting the device to physical impacts may result in data loss.
•
Data may be lost when the Chromebook is turned off or reset by a power failure
while the storage device (such as HDD, SSD, eMMC) is operating.
•
Data may be lost and irrecoverable because of a Chromebook virus.
•
Data may be lost if the power is turned off while running an application.
•
Samsung is not liable for any loss of data on a storage device (such as HDD, SSD,
eMMC).
Usage notices
42
To prevent data loss caused by damage to a storage device (such as HDD, SSD, eMMC),
please back up the data frequently.
Clean the display screen with a soft cloth dampened with Chromebook cleansing
detergent.
Do not use excessive force. Doing so may damage the display screen.
(NP UG Rev 5.0)
How to find the standby power consumption
information for this product
•
Access www.samsung.com/global/ecodesign_energy.
•
Search using the product model number.
•
Leaving this Chromebook in an inactive state for an extended period without
turning off the display can lead to increased energy consumption.
•
This feature may not be available depending on the region, carrier, or model.
43
Appendix
Product specifications
The system specifications may differ depending on the derived model. For detailed
system specifications, refer to the product catalog.
<Product specifications>
Item Specification
Operating environment
•
Temperature: -5–40 °C for storage,
10–35 °C when operating
•
Humidity: 5–90 % for storage,
20–80 % when operating
AC/DC rating
•
Input: 100–240 VAC, 50–60 Hz
•
Output: 20 VDC, 2.25 A / 15 VDC, 3 A /9 VDC, 3 A / 5 VDC,
3 A (45 W, PDO)
20.0–3.3 VDC, 2.25 A (45 W, PPS)
PC rating 15 VDC, 3 A / 9 VDC, 3 A / 5 VDC, 3 A (45 W)
•
Optional components may not be provided or different components may be
provided depending on the model.
•
The system specifications are subject to change without notice.
•
It is not possible to add storage or replace or upgrade memory because of the
Chromebook’s design.
Appendix
44
Important safety information
Safety instructions
The system is designed and tested to meet the latest standards for safety of information
technology equipment. However, to ensure safe use of this product, it is important that
the safety instructions marked on the product and in the documentation are followed.
Always follow these instructions to help guard against personal injury and damage
to the system.
Setting up the system
•
Read and follow all instructions marked on the product and in the documentation
before operating the system. Retain all safety and operating instructions for future
use.
•
Do not use this product near water or a heat source such as a radiator.
•
Set up the system on a stable work surface.
•
The product should be operated only with the type of power source indicated on the
rating label.
•
Ensure that the electrical outlet to power the equipment is easily accessible in case
of fire or short circuit.
•
If the Chromebook has a voltage selector switch, make sure that the switch is in the
proper position for your area.
•
Openings in the Chromebook case are provided for ventilation. Do not block or cover
these openings. Make sure you provide adequate space, at least 6 inches (15 cm),
around the system for ventilation when setting up your work area. Never insert
objects of any kind into the Chromebook ventilation openings.
•
Ensure that the air vents on the bottom of the casing are clear at all times. Do not
place the Chromebook on a soft surface, doing so will block the bottom vents.
•
When using an extension cord with this system, make sure that the total power
rating on the products plugged into the extension cord does not exceed the
extension cord power rating.
•
For Chromebooks with glossy display bezels the user should consider the placement
of the Chromebook as the bezel may cause reflections from surrounding light and
bright surfaces.
Appendix
45
Care during use
•
Do not walk on the power cord or allow anything to rest on it.
•
Do not spill anything on the Chromebook or its components. The best way to avoid
spills is to not eat or drink near the Chromebook or its components.
•
Some products have a replaceable CMOS battery on the system board. There is a
danger of explosion if the CMOS battery is replaced incorrectly. Replace the battery
with the same or equivalent type recommended by the manufacturer.
Dispose of batteries according to the manufacturers instructions. If the CMOS
battery requires replacement ensure that a qualified technician performs the task.
•
When the Chromebook is turned off, a small amount of electrical current still flows
through the Chromebook.
To avoid electrical shock, always unplug all cables, remove the battery and modem
cables from the wall outlets before cleaning the system.
•
Unplug the system from the wall outlet and contact a Samsung Service Center if:
‒
The power cord or plug is damaged.
‒
Liquid has been spilled into the Chromebook.
‒
The Chromebook does not operate properly when the operating instructions are
followed.
‒
The Chromebook was dropped or the casing is damaged.
‒
The Chromebook performance changes.
Operating instructions
1 When installing and operating devices please refer to safety requirements in the user
manual.
2 Devices can be used only with the equipment specified in the technical specifications
of the devices.
3 If any smell of burning or smoke is detected from the Chromebook the unit should
be switched off and the battery removed. The unit should be checked by a qualified
technician before reuse.
Appendix
46
4 Service and repair of devices should be carried out by authorized service centers.
5 Do not allow the portable Chromebook to operate with the base resting directly
on exposed skin for extended periods of time. The surface temperature of the base
will rise during normal operation (particularly when AC Power is present). Allowing
sustained contact with exposed skin can cause discomfort or eventually a burn.
Replacement parts and accessories
Use only replacement parts and accessories recommended by manufacturer.
To reduce the risk of fire, use only No. 26 AWG or larger telecommunications line
cord.
Do not use this product in areas classified as hazardous. Such areas include patient
care areas of medical and dental facilities, oxygen rich environments, or industrial
areas.
Battery disposal
Do not put rechargeable batteries or products powered by non-removable
rechargeable batteries in the garbage.
Contact the Samsung Service Center for information on how to dispose of batteries that
you cannot use or recharge any longer. Follow all local regulations when disposing of old
batteries.
THERE IS RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Laser safety
All systems equipped with CD or DVD drives comply with the appropriate safety
standards, including IEC 60825-1. The laser devices in these components are classified
as “Class 1 Laser Products” under a US Department of Health and Human Services
(DHHS) Radiation Performance Standard. Should the unit ever need servicing, contact an
authorized service location.
Appendix
47
•
Laser Safety Note: Use of controls or adjustments or performance of procedures
other than those specified in this manual may result in hazardous radiation
exposure. To prevent exposure to laser beams, do not try to open the enclosure
of a CD or DVD drive.
•
Class 1M laser radiation when operating part is open. Do not view directly with
optical instruments.
•
Class 3B invisible laser radiation when open.
Avoid exposure to the beam.
Connecting and disconnecting the adapter
The socket-outlet shall be installed near the equipment and shall be easily accessible.
Do not unplug the power cord by pulling the cable only.
Power cord requirements
The power cord set (all plugs, cable and adapter plugs) you received with your
Chromebook meets the requirements for use in the country where you purchased your
equipment.
Power cord sets for use in other countries must meet the requirements of the country
where you use the Chromebook. For more information on power cord set requirements,
contact your authorized dealer, reseller, or service provider.
India only
The power cord set must have a minimum current capacity and a nominal voltage rating,
as required by country’s power system.
Appendix
48
General requirements
The requirements listed below are applicable to all countries:
•
All power cord sets must be approved by an acceptable accredited agency
responsible for evaluation in the country where the power cord set will be used.
•
The power cord set must have a minimum current capacity of 7A and a nominal
voltage rating of 125 or 250 volts AC, as required by each country’s power system
(USA only).
•
The appliance coupler must meet the mechanical configuration of an EN 60 320/
IEC 320 Standard Sheet C7 (or C5) connector, for mating with appliance inlet on the
Chromebook.
Regulatory compliance statements
Wireless guidance
(If fitted with 2.4 G band, 5 G band or 6 G band)
Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz/5 GHz/6 GHz Band, may be present (embedded) in the
Chromebook system. The following section is a general overview of considerations while
operating a wireless device.
Additional limitations, cautions, and concerns for specific countries are listed in the
specific country sections (or country group sections). The wireless devices in the system
are only qualified for use in the countries identified by the Radio Approval Marks on the
system rating label. If the country you will be using the wireless device in, is not listed,
please contact your local Radio Approval agency for requirements. Wireless devices are
closely regulated and use may not be allowed.
The RF field strength of the wireless device or devices that may be embedded in the
Chromebook are well below all international RF exposure limits as known at this time.
Because the wireless devices (which may be embedded into the Chromebook) emit
less energy than is allowed in radio frequency safety standards and recommendations,
manufacturer believes these devices are safe for use. Regardless of the power levels,
care should be taken to minimize human contact during normal operation.
Some circumstances require restrictions on wireless devices.
Examples of common restrictions are listed on the next page:
Appendix
49
•
Radio frequency wireless communication can interfere with equipment on
commercial aircraft. Current aviation regulations require wireless devices to be
turned off while traveling in an airplane.
802.11 (also known as wireless Ethernet or Wi-Fi) and Bluetooth communication
devices are examples of devices that provide wireless communication.
•
In environments where the risk of interference to other devices or services
is harmful or perceived as harmful, the option to use a wireless device may
be restricted or eliminated. Airports, hospitals, and oxygen or flammable gas
laden atmospheres are limited examples where use of wireless devices may be
restricted or eliminated. When in environments where you are uncertain of the
sanction to use wireless devices, ask the applicable authority for authorization
prior to use or turning on the wireless device.
•
Every country has different restrictions on the use of wireless devices. Since your
system is equipped with a wireless device, when traveling between countries
with your system, check with the local Radio Approval authorities prior to any
move or trip for any restrictions on the use of a wireless device in the destination
country.
•
If the system came equipped with an internal embedded wireless device, do not
operate the wireless device unless all covers and shields are in place and the
system is fully assembled.
•
Wireless devices are not user serviceable. Do not modify them in any way.
Modification to a wireless device will void the authorization to use it. Please
contact the manufacturer for service.
•
Only use drivers approved for country in which the device will be used. See the
manufacturer System Restoration Kit, or contact the manufacturer’s technical
support for additional information.
Appendix
50
United States of America and Canada
USA and Canada Safety Requirements and Notices
Do not touch or move antenna while the unit is transmitting or receiving.
Do not hold any component containing the radio such that the antenna is very close to
touching any exposed parts of the body, especially the face or eyes, while transmitting.
Do not operate the radio or attempt to transmit data unless the antenna is connected; if
not, the radio may be damaged.
Use in specific environments:
The use of wireless devices in hazardous locations is limited by the constraints posed by
the safety directors of such environments.
The use of wireless devices on airplanes is governed by the Federal Aviation
Administration (FAA) in the USA and Transport Canada Civil Aviation (TCCA) in Canada.
The use of wireless devices in hospitals is restricted to the limits set forth by each
hospital.
Explosive Device Proximity Warning
Do not operate a portable transmitter (such as a wireless network device) near
unshielded blasting caps or in an explosive environment unless the device has
been modified to be qualified for such use.
Use On Aircraft Caution
FCC, FAA, and TCCA regulations prohibit airborne operation of radio-frequency
wireless devices because their signals could interfere with critical aircraft
instruments.
Other wireless devices
Safety notices for other devices in the wireless network:
Refer to the documentation supplied with wireless Ethernet adapters or other devices in
the wireless network.
The Part 15 radio device operates on a non-interference basis with other devices
operating at this frequency. Any changes or modification to said product not
expressly approved by Intel could void the user’s authority to operate this device.
Appendix
51
Unintentional emitter per FCC Part 15
Responsible Party – U.S. Contact Information
Samsung Electronics America, Inc.
85 Challenger Road.
Ridgefield Park, NJ 07660
Phone: 1-800-SAMSUNG (726-7864)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy. If not installed and used in accordance with the instructions, it may cause
harmful interference. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
If necessary, the user should consult the dealer or an experienced radio/television
technician for additional suggestions. The user may find the following booklet helpful:
“Something About Interference.”
This is available at FCC local regional offices. Our company is not responsible for any
radio or television interference caused by unauthorized modifications of this equipment
or the substitution or attachment of connecting cables and equipment other than those
specified by our company. The correction will be the responsibility of the user. Use only
shielded data cables with this system.
Appendix
52
Intentional emitter per FCC Part 15
(If fitted with 2.4 G band or 5 G band)
Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz/5 GHz Band, may be present (embedded) in the
notebook system. This section is only applicable if these devices are present. Refer to
the system label to verify the presence of wireless devices.
Wireless devices that may be in the system are only qualified for use in the United States
of America if an FCC ID number is on the system label.
This device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz
frequency range. FCC requires this product to be used indoors for the frequency range
5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile
Satellite systems. High power radars are allocated as primary users of the 5.25 to
5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with
and/or damage this device.
Operation of this device is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation of the
device.
Wireless devices are not user serviceable. Do not modify them in any way.
Modification to a wireless device will void the authorization to use it. Contact
manufacturer for service.
Health and safety information
Exposure to Radio Frequency (RF) Signals Certification Information
This product can contain an embedded radio transmitter and receiver. It is designed
and manufactured not to exceed the exposure limits for radio frequency (RF) energy set
by the Federal Communications Commission (FCC) of the U.S. government. These FCC
exposure limits are derived from the recommendations of two expert organizations, the
National Council on Radiation Protection and Measurement (NCRP) and the Institute of
Electrical and Electronics Engineers (IEEE). In both cases, the recommendations were
developed by scientific and engineering experts drawn from industry, government, and
academia after extensive reviews of the scientific literature related to the biological
effects of RF energy.
Appendix
53
Before a new model is available for sale to the public, it must be certified to the FCC that
it does not exceed the exposure limit established by the FCC. Evaluation per each model
is performed in positions and locations (such as at the bottom on the body) as required
by the FCC.
For body worn operation, this model meets the FCC RF exposure guidelines when used
with Samsung accessory designated for this product. Non-compliance with the above
restrictions may result in violation of FCC RF exposure guidelines.
RF exposure or SAR information can be viewed on-line at www.fcc.gov/oet/ea/fccid/.
This site uses this product FCC ID number on the outside of the product. Sometimes it
may be necessary to remove the battery pack to find number. Once you have the FCC
ID number for a particular product, follow the instructions on the website and it should
provide RF exposure information or values for typical or maximum SAR for particular
product.
XE345XDA model only
When using the Chromebook, a distance of at least 20 cm should be maintained
between the display, the WWAN antenna, and the user’s body.
For corresponding model only
The Specific Absorption Rate (SAR) is a measure of the rate of absorption of RF energy
by the human body expressed in units of watts per kilogram (W/kg). The FCC wireless
devices to comply with a safety limit of 1.6 watts per kilogram (1.6 W/kg).
SAR level of this device while operating can be well below the maximum value. This is
because the device is designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
Appendix
54
Manufacturer information
Samsung Electronics Co., Ltd.
129, Samsung-Ro, Yeongtong-Gu, Suwon-City, Gyeonggi-Do, 443-742, Korea
Samsung Electronics Vietnam Co., Ltd.
Khu Cong nghiep Yen Phong 1, Yen Trung, Yen Phong, Bac Ninh, Viet Nam
Tel: +84-222-369-6875
For the web or the phone number of the Samsung Service Center, see the Warranty or
contact the retailer where you purchased your product.
RTC caution
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Discard used batteries
according to the Manufacturer’s instruction.
Canada
Innovation, Science and Economic Development Statement:
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
1 This device may not cause interference.
2 This device must accept any interference, including interference that may cause
undesired operation of the device.
Industry Canada Caution
The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the
potential for harmful interference to co-channel mobile satellite systems.
Appendix
55
Innovation, Sciences et Développement économique Canada
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme
aux CNR d’Innovation, Sciences et Développement économique Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes :
1 L’appareil ne doit pas produire de brouillage.
2 L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
Avertissement:
Les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés uniquement
pour une utilisation à l’intérieur a n de réduire les risques de brouillage préjudiciable aux
systèmes de satellites mobiles utilisant les mêmes canaux.
WEEE symbol information
Correct disposal of this product (Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its
electronic accessories (for example, charger, headset, USB cable) should not be disposed
of with other household waste at the end of their working life.
To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or
their local government office, for details of where and how they can take these items for
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product and its electronic accessories should not be mixed with
other commercial wastes for disposal.
For information on Samsung’s environmental commitments and product regulatory
obligations, such as REACH, visit our sustainability page available at www.samsung.com.
Appendix
56
India only
For more information on safe disposal and recycling visit our website
www.samsung.com/in or contact our Helpline numbers - 18002668282, 180030008282.
This product is RoHS compliant.
Correct disposal of batteries in this product
(Applicable in countries with separate collection systems)
This marking on the battery, manual or packaging indicates that the batteries in this
product should not be disposed of with other household waste at the end of their
working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery
contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66.
If batteries are not properly disposed of, these substances can cause harm to human
health or the environment.
To protect natural resources and to promote material re-use, please separate batteries
from other types of waste and recycle them through your local, free battery return
system.
PO BOX 12987, DUBLIN. IE
Removing the battery (Europe only)
•
To remove the battery, contact an authorised service centre. To obtain battery
removal instructions, please visit www.samsung.com/global/ecodesign_energy.
•
For your safety, you must not attempt to remove the battery. If the battery is not
properly removed, it may lead to damage to the battery and device, cause personal
injury, and/or result in the device being unsafe.
•
Samsung does not accept liability for any damage or loss (whether in contract or
tort, including negligence) which may arise from failure to precisely follow these
warnings and instructions, other than death or personal injury caused by Samsung’s
negligence.
Appendix
57
USA only
This Perchlorate warning applies only to primary CR (Manganese Dioxide) Lithium coin
cells in the product sold or distributed ONLY in California USA.
“Perchlorate Material- special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate.”
WARNING! Never dispose of batteries in a fire because they may explode. Do not
disassemble, crush, puncture, heat, burn or reuse batteries. For more information, visit
call2recycle.org or call 1-800-822-8837. Alternatively, visit: www.samsung.com/recycling
or call 1-800-SAMSUNG.
Samsung package Take-Back program (USA
only)
In partnering with select recyclers, Samsung offers packaging take-back at no cost to
you.
Simply call the following number for the locations nearest you.
CRT Processing, LLC
(877) 278-0799
Kathy Severson – Logistics contact
For more recycling information, go to our website: www.samsung.com/recycling or call
1-800-SAMSUNG.
