2
Table of Contents
Getting started
3 Device layout and functions
8 Turning the Chromebook on and off
Basics
10 Keyboard
12 Touchpad
14 Wireless LAN
15 Memory card slot
16 External display
Settings
18 Display brightness
19 Volume
20 Battery
Usage notices
23 Precautions for using the device
27 Ergonomic tips
30 Safety precautions
Appendix
38 Product specifications
39 Important safety information
41 Replacement parts and accessories
43 Regulatory compliance statements
49 WEEE symbol information
51 Samsung package Take-Back
program (USA only)
52 TCO Certified
3
Getting started
Device layout and functions
Leaving the screen idle for extended periods may result in afterimages (screen
burn-in) or ghosting. Turn off the screen, or turn on the screen saver or power
saving mode when you are not using the Chromebook.
•
Features or options may differ depending on the model.
•
The items marked as optional may not be provided or may be provided in
different locations.
•
Since some space on the storage device is reserved for system recovery and
operations, the available space on the storage device may be less than the
actual capacity.
Front view
Microphone
Display
Numeric keypad
Front camera
Ambient light
sensor
Front camera
indicator light
Power button
Keyboard
Touchpad
Getting started
4
<Device layout and functions: Front view>
Name Description
Microphone
You can use the voice recording or video call features
through the built-in microphone.
Ambient light sensor
•
Recognizes the brightness of the environment where
you use the Chromebook.
•
When the surroundings become dark, the keyboard
backlight turns on.
•
When the surroundings become bright, the keyboard
backlight turns off.
Do not cover the ambient light sensor.
Front camera
Using this camera, you can take still pictures and record
video.
Front camera indicator
light
This indicates the front camera operating status.
Display The screen's images are displayed here.
Power button Turns the Chromebook on and off.
Numeric keypad Enter numbers.
Keyboard Enter text or control Chromebook functions.
Touchpad
•
Moves the cursor and selects options.
•
Functions as a mouse.
Getting started
5
Right view
Earpiece/Head
set jack
USB 3.2 port
Memory card slot
<Device layout and functions: Right view>
Name Description
Memory card slot Insert a memory card into the slot.
USB 3.2 port
Connect various accessories, such as a mouse, camera, or
keyboard.
Earpiece/Headset jack
Connect an earpiece or a headset to the Chromebook to
listen to audio.
Left view
Power LED
HDMI port
USB Type-C port
Getting started
6
<Device layout and functions: Left view>
Name Description
HDMI port Use to connect an HDMI cable to an external device.
USB Type-C port
•
Connect the supplied adapter to charge the
Chromebook.
•
Connect and charge a USB Type-C device, or connect to
an external display device.
Power LED
Shows the operating status of the Chromebook.
•
Red: Charging
•
Green: Fully charged
•
Blue: Turned on
The charging feature of the USB Type-C port
Charging the Chromebook
Connect an external power supply (sold separately) to the USB Type-C port to use it as
the auxiliary power or charge the Chromebook.
Use an external power supply (sold separately) with a rating level higher than 45 W (20 V,
2.25 A) that supports USB Type-C.
Charging a USB Type-C device
Connect and charge your USB Type-C device by connecting it to the USB Type-C port.
•
It may take longer to charge the battery when charging a connected device.
•
The battery power level may be reduced when charging a connected device
while the Chromebook is powered by the battery.
•
The charging status of the connected device is not displayed on the
Chromebook.
•
This charging feature may not be available on some devices.
•
When the Chromebook is turned off, the device connected to the USB Type-C
port is not charged.
Getting started
7
Bottom view
Fan vents
Internal battery
Speaker
Speaker
<Device layout and functions: Bottom view>
Name Description
Fan vents
•
Sucks in outside air and discharges heat generated
inside the Chromebook through these holes.
•
If the vents are blocked the Chromebook may overheat.
Avoid blocking the vents as this may be dangerous.
Internal battery
Provides power to the Chromebook when not connected to
an adapter.
Speaker Sound is emitted from the speakers.
•
If the case at the bottom of the device is replaced, the laser-carved model
name, serial number, and various logos will not be displayed anymore. For more
information, contact a Samsung Service Center.
•
Remove all of the protective papers from the rubber feet at the bottom of the
Chromebook before use.
Getting started
8
Turning the Chromebook on and off
Fully charge the battery using the supplied adapter before using the Chromebook
for the first time.
Turning the Chromebook on
1 Before turning on the Chromebook, check that the battery is charged and charge it if
necessary.
2 Open the display panel. The Chromebook automatically turns on.
If the Chromebook does not turn on automatically, press the Power button.
Turning the Chromebook off
Using screen buttons
1 Select the status area on the shelf.
2 Select the Power icon ( )
→
Shut down
.
Save all data before turning off the Chromebook.
Getting started
9
Using the Power button
Press and hold the Power button for about 2 seconds and select
Shut down
to shut down
the device.
To shut down the device when the system has frozen unexpectedly, press and hold the
Power button for at least 8 seconds.
Controlling the power of the device
You can adjust the settings for the selected power options.
Select the status area on the shelf, select the Settings icon (
) to open the Settings
window, and then select
System preferences
→
Power
to select the power options.
If the screen is locked in power saving mode
Tap the touchpad or press any key to turn the screen on and enter the password to
unlock the screen.
10
Basics
Keyboard
Hot keys and function keys are discussed in the following sections.
•
The keyboard image may differ from the actual keyboard.
•
The keyboard may differ depending on your country. The following mainly
describes the hot keys and function keys.
Hot key functions
Here is an overview of the hot keys on the top row of the keyboard.
<Hot key functions>
Keys Description
Go to the previous page in your browser history.
Reload your current page.
Hide the tabs and switch to full-screen mode.
Enter overview mode, which shows all windows.
Take a screenshot or record the screen.
Decrease screen brightness.
Increase screen brightness.
Decrease the keyboard backlight's brightness.
Increase the keyboard backlight's brightness.
Turn on the dictation feature.
Check the accessibility features.
Basics
11
Keys Description
Pause and resume playback.
Mutes the sound.
In mute mode, press the key to unmute the sound.
Decrease the volume.
Increase the volume.
Shift key
Hold the
shift
key down to enter upper case letters.
Search for keyboard shortcuts
Press the following keys at the same time to check the keyboard shortcuts supported in
Chrome OS.
Launcher key
Press the Launcher key to launch the Launcher.
To change the Launcher key to another key, select the status area on the shelf, select the
Settings icon (
)
→
Device
→
Keyboard and inputs
→
Customize keyboard keys
, and
select the function you want.
Basics
12
Touchpad
Use the touchpad to move the cursor or select an item.
•
Use the touchpad only with fingers. The touchpad will not recognize actions of
other objects.
•
Images and the touchpad layout may differ depending on the model.
Basic touchpad functions
•
Moving: To move the cursor, move a finger on the touchpad.
•
Clicking: Tap the touchpad or press the touchpad button.
Tap Click
•
Double-clicking: Double tap the touchpad or press the touchpad button twice.
Tap-tap Click-click
•
Right-clicking: Press the touchpad with two fingers simultaneously.
Tap
Basics
13
•
Dragging: To move an icon or an app to a desired location, press and hold it and then
drag it to the target position with the touchpad button pressed.
Press and hold the
touchpad button
Move
Gesture functions
•
Swiping: To scroll up, down, left or right to a desired location, swipe with two fingers
on the touchpad.
•
Pinching: To zoom in, spread two fingers apart on the touchpad. Pinch to zoom out.
Adjusting the touchpad settings
If the touchpad is too sensitive, adjust its reaction speed.
1 Select the status area on the shelf.
2 Select the Settings icon ( ) to open the Settings window.
3 Select
Device
→
Touchpad
and adjust the
Touchpad speed
adjustment bar.
Basics
14
Wireless LAN
Connect the Chromebook to a wireless network to use the internet.
The pictures in this guide may differ from the actual product depending on the
wireless LAN device model.
About Access Point (AP)
An Access Point (AP) is a network device that bridges wired and wireless LANs and
corresponds to a wireless hub in a wired network. Multiple devices can be connected to
an AP.
Connecting to a Wi-Fi network
1 Select the status area on the shelf and select the Manage Wi-Fi connections icon ( )
on the Wi-Fi option.
2 Select a network from the list of detected wireless networks.
3 Enter a password, if necessary, and select
Connect
.
Once the Chromebook has been connected to a wireless network, it will attempt to
connect to it automatically when it is available. If you require a network password,
contact the system administrator.
•
If the Wi-Fi network is successfully connected, the network icon ( ) will be
displayed on the shelf.
•
If the Wi-Fi network is not properly connected, the network icon ( ) will be
displayed on the shelf.
•
The white part of the network icon on the shelf represents the signal strength of
the Wi-Fi network.
Basics
15
Memory card slot
Use a memory card to transfer data to other devices.
Memory cards are sold separately.
This Chromebook supports the following types of memory cards.
<Supported memory card type>
Abbreviation Description
micro SD micro Secure Digital
micro SDHC micro Secure Digital High Capacity
micro SDXC micro Secure Digital eXtended Capacity
•
Some memory cards may not be fully compatible with the Chromebook. Using
an incompatible card may damage the Chromebook, the memory card, or the
data stored in it.
•
Use caution to insert the memory card in the indicated direction.
•
Store the card separately to prevent losing the card when moving the
Chromebook.
•
Memory card speeds vary.
Inserting a memory card
If a memory card adapter or an unnecessary card is inserted in the memory card slot,
remove it. Then insert a memory card into the slot in the indicated direction.
Basics
16
Removing a memory card
When you push the card, it clicks and disengages from the memory card slot. Grasp the
end of the card and pull it out of the slot.
•
Available data formats depend on the current version of the Chrome OS.
•
Data on the card can be saved in the
Downloads
folder under
My files
.
•
The maximum file size will vary depending on Chrome OS.
External display
Connecting the Chromebook to an external display device can be useful for
presentations or when watching a movie. The cables and adapters required to connect
an external display are sold separately. The Chromebook supports HDMI cables and USB
Type-C display cables.
USB Type-C display cable HDMI cable
Check the available ports on the display device to ensure that it is compatible with
the Chromebook.
Basics
17
Connecting to a display
1 Connect the cable to the HDMI port or the USB Type-C port of the Chromebook.
2 Connect the other end of the cable to the external display.
•
When using a USB Type-C display cable
USB Type-C port HDMI port
•
When using an HDMI cable
HDMI port HDMI port
3 Connect the power cord to the external display.
4 Turn on the display and change its display mode to one that supports an external
input.
The Chromebook screen will be extended to the external display.
You can change to a mirroring mode to show the same screen on both the
Chromebook and the external display.
Select the status area on the shelf, select the Settings icon (
)
→
Device
→
Display
, and then select the
Mirror Built-in display
switch to turn it on.
18
Settings
Display brightness
Adjust the display brightness to reduce eye strain and save power.
Controlling brightness using the keyboard
•
Adjust the display brightness by pressing the key to decrease brightness or the
key to increase brightness.
•
Whenever you press the or key, the display brightness will be adjusted by
one level.
Controlling brightness using the shelf
1 Select the status area on the shelf.
2 Drag the adjustment bar to the desired brightness.
Brightness
adjustment bar
Instructions for Cleaning the display
Clean the display panel with a soft cloth lightly moistened with Chromebook
cleansing detergent moving in one direction.
Cleaning the display panel with excessive force can damage the display.
Settings
19
Volume
Adjust the system volume or sound volume when playing music or video.
Controlling volume using the keyboard
•
Adjust the volume by pressing the key to turn down the volume or the key
to turn up the volume.
•
Whenever you press the or key, the volume will be adjusted by one level.
•
Mute the sound by pressing the key. In mute mode, press the key to
unmute the sound.
Controlling volume using the shelf
1 Select the status area on the shelf.
2 Drag the adjustment bar to the desired volume.
Volume adjustment
bar
Settings
20
Battery
Fully charge the battery using the supplied adapter before using the Chromebook for the
first time, or when the Chromebook is completely discharged.
•
Use only Samsung-approved adapters, batteries, and cables. Unapproved
adapters or cables can cause the battery to explode or damage the Chromebook.
•
Incorrectly connecting the adapter may cause serious damage to the
Chromebook.
•
To safely remove or replace the battery, it is recommended to take the
Chromebook to a Samsung Service Center. You will be charged for this service if
the repair is not covered under warranty.
•
You can use the Chromebook while it is charging, but the battery charging time
may increase. If the battery temperature rises too much, the charging may stop
as a safety measure.
•
To restore the battery power after cutting it, connect the adapter.
•
When you connect the adapter to a multiport adapter to charge the
Chromebook, the charging speed message may appear, but the Chromebook will
be charged normally.
•
If many devices are connected to the multiport adapter, the Chromebook may
not be charged or the charging time may increase. In this case, connect the
adapter directly to the Chromebook.
•
When the adapter is directly connected to the Chromebook, the charging speed
message will not appear.
Settings
21
Charging the battery
1 Connect the adapter to the USB Type-C port of the Chromebook.
2 Plug the adapter into an electric socket.
If the battery is fully discharged, the Chromebook will not turn on immediately
with the adapter. A minimum level of battery power will be charged slowly for
safety while the Power LED blinks red. You can turn on the Chromebook after the
Power LED stops blinking.
Settings
22
3 When the battery is fully charged, the power LED turns green. Disconnect the adapter
from the Chromebook.
<Status of operating status LED>
Power LED Status
Blinks red Pre-charging
Red Charging
Green Fully charged
Blue Turned on
4 Unplug the adapter from the electric socket.
Do not allow the adapter to make contact with your skin for a long time. A
low-temperature burn may result.
Battery status
Check the current remaining battery power on the shelf.
Battery usage time
Batteries are replaceable items and over time the battery's capacity to hold a charge and
its power level is reduced. If a battery can only hold its charge for half of the time that it
could when new, it is recommended to purchase a new, replacement battery.
23
Usage notices
Precautions for using the device
•
This user guide is specially designed to detail the Chromebook's functions and
features.
•
The user guide supplied with the Chromebook may vary depending on the model.
•
Please read this guide when using the Chromebook to ensure safe and proper use.
•
Optional accessories, some devices, and software referred to in this guide may
not be provided or may not be subject to upgrades. Note that the Chromebook
environment referred to in the user guide may not be the same as your environment.
•
Available features and additional services may vary depending on the Chromebook
or operating system.
•
This user guide describes procedures for using the touchpad, mouse and touch
screen. Instructions for using the touch screen are for models with the touch screen
feature.
•
Images and screenshots are those of the representative model of the series and may
differ in appearance from the actual product.
•
Content may differ from the final product and is subject to change without
prior notice. For the latest version of the guide, refer to the Samsung website,
www.samsung.com.
Instructional icons and expressions
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to the Chromebook or other
equipment
Note: notes, usage tips, or additional information
Usage notices
24
To service your Chromebook
For inquiries about the Chrome operating system or apps, visit
www.google.com/support/chromeos.
If you have a problem while using the Chromebook hardware, please contact our
Samsung Service Center below or visit www.samsung.com/sec/support/guarantee.do.
If you replace or upgrade the hardware yourself, the Chrome operating system will not
be automatically updated and the product will not work properly.
Copyright
Copyright © 2025 Samsung Electronics Co., Ltd.
This guide is protected under international copyright laws.
No part of this guide may be reproduced, distributed, translated, or transmitted in any
form or by any means, electronic or mechanical, including photocopying, recording, or
storing in any information storage and retrieval system.
Chromebook specifications or the contents of this guide may be changed without prior
notice if the Chromebook's functions are upgraded.
Trademarks
•
Samsung and the Samsung logo are trademarks or registered trademarks of
Samsung Electronics Co., Ltd.
•
Bluetooth
®
is a registered trademark of Bluetooth SIG, Inc. worldwide.
•
Wi-Fi
®
, Wi-Fi Direct
™
, Wi-Fi CERTIFIED
™
, and the Wi-Fi logo are registered
trademarks of the Wi-Fi Alliance.
•
HDMI, the HDMI logo, and the term High Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
•
All other trademarks and copyrights are the property of their respective owners.
Usage notices
25
Chrome OS Software License
The software included in this product contains copyrighted software that is licensed
under the GPL/LGPL.
You may obtain the complete Corresponding Source code from website:
http://git.chromium.org/gitweb/
This offer is valid to anyone in receipt of this information.
Energy Star (USA only)
As an ENERGY STAR
®
Partner, Samsung has determined that this Product meets the
ENERGY STAR Guidelines for energy efficiency. The ENERGY STAR Program has reduced
greenhouse gas emissions and saved energy through voluntary labeling. Samsung is
a proud ENERGY STAR Partner and commits to meet the guidelines for this product to
be ENERGY STAR certified. By selecting an ENERGY STAR certified product, you reduce
greenhouse emissions, save energy, and can lower operating cost. For more information,
see http://www.energystar.gov/.
•
The Power Management setting of this product has been enabled by default and has
various timing settings (of up to 300 minutes for energy saving. In case you don't
want the power management setting enabled, select "Never").
•
To change this in Settings, go to the System menu > Power & sleep menu > Screen/
Sleep timeout option.
This product can be awakened from sleep mode by pressing the Power button.
Usage notices
26
Operating system and software support
If a problem occurs because of the reinstallation of other operating systems (OS) or a
previous version of an OS pre-installed on this Chromebook, or a software that does
not support the OS, the company will not provide technical support, a replacement or
refund, and if our service engineer visits you because of this problem, a service charge
will be applied.
Performance Restrictions
Online games and some games (3D, 2D) may not be supported and Full HD video and
some high bit rate HD video playback may be slow and stutter on this Chromebook.
Product capacity representation
Memory Capacity Representation
The memory capacity reported in the Chrome OS is less than the actual capacity of
memory. This is because BIOS or a video adapter uses a portion of memory or claims it
for further use.
For example, for 1 GB (= 1,024 MB) memory installed, OS (Windows, Chrome, etc.) may
report the capacity as 1,022 MB or less.
Usage notices
27
Ergonomic tips
Maintaining proper posture during Chromebook use is very important to prevent
physical injury. Improper or prolonged keyboard use may result in repetitive strain
injury. Viewing the monitor screen for extended periods of time may result in eye strain.
Therefore, please follow these guidelines carefully when setting up and using the
Chromebook.
Back and neck
•
Use an adjustable chair with firm, comfortable support.
•
Adjust the height of your chair so that thighs are horizontal to the floor and feet are
flat on the floor.
•
The back of the chair should support the lower back. Adjust the backrest to fit your
body properly.
•
Sit back fully in your chair and straighten the back and neck. Avoid leaning forward
or craning your neck toward the Chromebook screen.
•
Avoid using the Chromebook while lying down or on your lap. If the Chromebook's
temperature increases, there is a danger of burn injury.
•
The instructions in this guide have been prepared so that they can be applied to
the range of needs of general users. If the user is not included in the range, the
recommendations should be applied according to the user's needs.
•
Images may differ from actual products.
Arms and hands
•
When using the keyboard and touchpad, the shoulders should be relaxed. The upper
arm and forearm should form an angle that is slightly greater than a right angle,
with the wrist and hand in almost a straight line.
•
Use a light touch when typing or using the touchpad and keep the hands and fingers
relaxed. Avoid rolling the thumbs under your palms or supporting the wrists on the
desk while typing.
•
Use an external keyboard and mouse when using the Chromebook for long periods.
When using an external keyboard and mouse, position the devices at the same
height as the Chromebook and within comfortable reach.
Usage notices
28
Eye position and display illumination
•
Position the screen at least 50 cm away from your eyes.
•
Adjust the height of the screen so that its top edge is equal to or just below the level
of your eyes.
•
Avoid setting the screen's brightness settings excessively high.
•
Keep the screen clean.
•
If wearing glasses, clean them before using the Chromebook.
•
When referring to printed content while typing, use a static paper holder to hold the
paper at about the same height as the monitor.
Hearing and volume control
•
Ensure that the volume is not too loud before using a headset or headphones.
Excessive exposure to loud sounds can cause hearing damage.
•
Always turn the volume down before plugging the headphones into an audio source
and use only the minimum volume setting necessary to hear your conversation or
music.
•
Avoid using headphones for long periods of time.
•
Default audio settings can be changed by software and driver updates without your
knowledge. Always recheck equalizer and volume settings before listening to audio.
•
To prevent possible hearing damage, do not listen at high volume levels for long
periods.
Usage notices
29
Operating conditions
•
Take at least a 10 minute break every hour.
•
Avoid using the Chromebook in dark locations. Use the Chromebook with as much
ambient light as you would when reading a book.
•
Indirect illumination is recommended. Use a curtain to prevent reflections and glare
on the screen.
•
While operating a Chromebook and talking on a phone, use a headset. Using the
Chromebook while holding a phone on your shoulder or with your neck may lead to
muscle strain or injury.
•
Keep frequently used items within reach.
•
Only use the Chromebook within the temperature and humidity ranges specified in
this guide.
Use caution when exposed to flashing lights.
•
While using your Chromebook, leave some lights on in the room and do not hold the
screen too close to your eyes.
•
Seizures or blackouts can occur when you are exposed to flashing lights while
watching videos or playing Flash-based games for extended periods. If you feel any
discomfort, stop using the Chromebook immediately.
•
If anyone related to you has experienced seizures or blackouts while using a similar
product, consult a physician before using the Chromebook.
•
If you feel discomfort, such as a muscle spasm, or disoriented, stop using the
Chromebook immediately and consult a physician.
•
To prevent eye strain, take frequent breaks while using the Chromebook.
Reduce the risk of repetitive motion injuries.
When you repetitively perform actions, such as pressing keys, drawing characters on a
touch screen, or playing games, you may experience occasional discomfort in your hands,
neck, shoulders, or other parts of your body. When using your Chromebook for extended
periods, hold the Chromebook with a relaxed grip, press the keys lightly, and take
frequent breaks. If you continue to have discomfort during or after such use, stop using
the Chromebook and consult a physician.
Usage notices
30
Safety precautions
For your safety and security and to prevent damage, carefully read the following safety
instructions. This 'Safety precautions' relate to Chromebook use. Some of the content
may not be applicable to your Chromebook.
•
Since this is commonly applied to Samsung Chromebooks, some pictures may
differ from actual products.
•
The product mentioned in this guide refers to all items supplied with the
Chromebook including the battery, the adapter, and all other Samsung-provided
accessories.
Warning
Failure to follow the instructions marked with this symbol may result in physical injury
or fatality.
Power related
Handle the power cord with care.
•
Do not touch with wet hands.
•
Do not use a damaged power cord.
•
Do not overload a multi-outlet or an extension cord beyond the specified voltage/
current capacity.
•
Correctly insert the plug into the outlet.
•
Do not unplug the power cord by pulling on the cable.
•
Unplug the wall-mount adapter (integrated plug and power adapter) from the wall
outlet while holding the body and pulling it in the direction of the arrow.
Failure to do so may result in electric shock or fire.
Connect the power cord to the adapter firmly.
An improper connection may result in a fire.
Use the approved adapter or cable included in the product box.
If you use the unapproved adapter or cable, it cause the damage or malfunction of the
Chromebook.
Usage notices
31
Use only properly earthed electric sockets or extension cords.
Unearthed electric sockets or extension cords may cause electric shock. Any connection
to unearthed electric sockets or extension cords may produce an electric field from a
current leak.
If water or other substances enter the product, disconnect the power cord and contact
a Samsung Service Center. For Chromebooks that are supplied with an optional
removable battery, disconnect the battery.
Failure to do so may result in electric shock or fire caused by a Chromebook malfunction.
Prevent dust from accumulating on the power cord or the electric socket. Regularly
wipe the power cord and the electric socket with a dry cloth.
Failure to do so may result in electric shock or fire.
Do not bend or damage the power cord or the adapter with a heavy or sharp-edged
object.
A damaged cable or cord may result in electric shock or fire.
Keep the battery, adapter, and power cord away from infants, children, and pets.
Failure to do so may result in electric shock or damage.
Battery usage related
Use manufacturer-approved batteries, adapters, accessories, and supplies.
•
Using generic batteries or adapters may shorten the life of your product or cause
the Chromebook to malfunction. They may also cause a fire or cause the battery to
explode.
•
Use only Samsung-approved battery and adapter specifically designed for your
device. Incompatible battery and adapter can cause serious injuries or damage to
your device.
•
Samsung cannot be responsible for the user's safety when using accessories or
supplies that are not approved by Samsung.
Take care to not allow metal objects such as a key or clip to touch the battery terminals
(metal parts).
This may cause excessive current and result in fire, burns, or damage to the battery.
If the Chromebook or the Chromebook battery leaks, emits strange odors, or swells,
immediately stop using the Chromebook and contact a Samsung Service Center.
Failure to do so may result in an explosion or fire.
Usage notices
32
Replace a run-down battery with a new, Samsung-approved battery.
Dispose of worn-out batteries properly.
•
There is a danger of fire or explosion.
•
The battery disposal method may differ depending on your country and region.
Dispose of the used battery in an appropriate way.
When removing the real time clock (RTC) battery, keep it away from infants and
children.
If a child swallows the battery, the child may suffocate. If this happens, immediately
contact a doctor.
Do not throw or disassemble the battery and do not put it into water.
There is a danger of injury, fire or explosion.
Charge the battery according to the instructions in the guide.
Failure to do so may cause an explosion or fire.
Usage related
Do not use the Chromebook on heated floors or electric pads, or on beds, blankets, or
cushions that block the ventilation of the Chromebook.
A blocked vent causes the Chromebook to overheat, resulting in an explosion, fire, burns,
or Chromebook malfunction.
Do not use the Chromebook in hot or humid locations, such as a bathroom, sauna, or
inside a car during summer.
Failure to do so may result in Chromebook malfunction or electric shock.
The Chromebook can be used in locations with an ambient temperature of 10 °C to 35 °C
and a relative humidity of 20% to 80%RH.
To avoid suffocation, keep the plastic bag away from infants and children.
Putting a plastic bag over the head may result in suffocation.
Never heat the Chromebook (or the battery) or put the Chromebook (or the battery) into
a fire or microwave.
Failure to do so may result in an explosion or fire.
Usage notices
33
Before cleaning the Chromebook, disconnect all the cables that are connected to the
Chromebook. For Chromebooks that are supplied with an optional removable battery,
disconnect the battery.
Failure to do so may result in electric shock or fire.
Keep the Chromebook away from water or liquid.
Water or liquid entering the Chromebook may short-circuit the Chromebook, resulting in
electric shock or fire.
If the Chromebook is dropped or broken, disconnect the power cord and contact
a Samsung Service Center. For Chromebooks that are supplied with an optional
removable battery, disconnect the battery.
Using a broken Chromebook may result in electric shock or fire.
Do not touch the Chromebook's surface or the vents for extended periods while the
Chromebook is on.
Contact with the vent or the surface for extended periods may result in low-temperature
burns, such as redness on the skin.
Do not carry your device in your back pockets.
•
The device may be damaged, explode, or result in a fire if too much pressure is
applied to it.
•
You may be injured if you are bumped or fall.
Caution
Failure to follow instructions marked with this symbol may result in minor physical
injury or damage to the Chromebook.
Installation related
Do not block the ports (holes), vents, etc., of the product and do not insert objects.
Damage to a component within the Chromebook may cause electric shock or fire.
When using the Chromebook on its side, ensure the vents are clear and facing upwards.
Failure to do so, may cause the internal temperature of the Chromebook to rise and the
Chromebook to malfunction or halt.
Keep the Chromebook's vents at least 15 cm away from walls and other objects.
Failure to do so may result in physical injury.
Usage notices
34
Do not place or use the Chromebook on slanted or vibrating surfaces.
Failure to do so may result in Chromebook malfunction or damage.
Do not place heavy objects on the product.
This may cause a problem with the Chromebook. In addition, the object may fall and
cause injury or damage the Chromebook.
Properly shut down, disconnect and secure the Chromebook cables before moving it.
Failure to do so may damage the Chromebook or cause someone to trip over a loose
cable.
Usage related
Do not use the pen for unintended purposes, such as poking the body, like eyes or ears,
and do not put it in your mouth.
Doing so may result in physical injury.
Do not place a candle, lit cigar, etc., over or on the product.
There is a danger of fire.
Make sure to have the product tested by a safety service engineer after repairing the
product.
Using a repaired product without testing it for safety may cause an electric shock or fire.
In case of lightning, immediately turn the system off, then disconnect the power cord
from the wall outlet and phone line from modem.
There is a danger of electric shock or fire.
Connect only permitted devices to the connectors or ports of the Chromebook.
Failure to do so may result in an electric shock or fire.
Close the display panel only after checking if the Chromebook is turned off.
The temperature may rise and it may cause deformation of the product.
Do not drop or hit the Chromebook against anything.
Failure to do so may result in physical injury or Chromebook malfunction.
When handling Chromebook parts, follow the instructions on the manual supplied with
the parts.
Failure to do so may result in damage to the product.
Usage notices
35
If the product emits smoke or there is a burning smell, disconnect the adapter from the
wall outlet and contact a Samsung Service Center immediately. For Chromebooks that
are supplied with an optional removable battery, disconnect the battery.
There is a danger of fire.
Do not store your device near or in heaters, microwaves, hot cooking equipment, or high
pressure containers.
•
The battery may leak.
•
Your device may overheat and cause a fire.
Do not insert your fingers into the ports (holes), card slot, or vents.
There is a danger of injury or electric shock.
Use recommended Chromebook cleansing solutions when cleaning the product and
only use the Chromebook when it is completely dry.
Failure to do so may result in electric shock or fire.
Do not use the product if it is cracked or broken.
Broken glass or acrylic could cause injury to your hands and face. Take the device to a
Samsung Service Center to have it repaired.
When using wireless communication (LAN, Bluetooth, etc.) always follow applicable
instructions. For example, airlines and hospitals have strict requirements.
Avoid exposing a drive to magnetic fields. Security devices with magnetic fields include
airport walk-through devices and security wands. The airport security devices that
check carry-on luggage use X-rays instead of magnetism and will not damage a drive.
Keep the Chromebook away from magnetic material.
•
Magnetic materials may cause Chromebook malfunction or cause the battery to
discharge.
•
To avoid damaging the Chromebook or magnetic stripe cards, such as credit cards,
keep magnetic stripe cards away from the Chromebook.
Usage notices
36
Do not use your Chromebook in a hospital or on an aircraft that can be interfered with by
radio frequency.
•
Avoid using your Chromebook within a 15 cm range of a pacemaker, if possible, as
your Chromebook can interfere with the pacemaker.
•
To minimize possible interference with a pacemaker, use your Chromebook only on
the side of your body that is opposite the pacemaker.
•
If you use medical equipment, contact the equipment manufacturer before using
your Chromebook to determine whether or not the equipment will be affected by
radio frequencies emitted by the Chromebook.
•
When in a hospital, turn off your Chromebook and follow all hospital regulations.
Radio frequencies emitted from the Chromebook may affect medical equipment.
Upgrade Related
Do not attempt to upgrade the Chromebook, unless you are qualified. Otherwise,
contact a Samsung Service Center or an authorized technician.
When you upgrade permitted devices, according to the guide, follow the specified
instructions in the guide to upgrade them. Do not disassemble any other parts by
yourself.
Failure to do so may result in Chromebook malfunction, electric shock, or fire.
Take care when touching the product or parts.
The Chromebook may be damaged or you may be injured.
Do not disassemble the power supply unit in any circumstances.
Failure to do so may result in electric shock, fire, or an explosion.
Shut down the Chromebook and disconnect all cables before disassembling the
Chromebook. For Chromebooks that are supplied with an optional removable battery,
disconnect the battery.
Failure to do so may cause electric shock.
Make sure to close the Chromebook cover before connecting the power after a
reassembly.
There is a danger of electric shock if your body touches an internal part.
Never disassemble or repair the product by yourself.
There is danger of an accident. Use an authorized Samsung Service Center.
Usage notices
37
To connect a device that is not manufactured or authorized by Samsung, enquire at a
Samsung Service Center before connecting the device.
There is a danger of damaging the product.
Storage and movement related
Do not store the Chromebook in an enclosed space, such as a Chromebook bag, while it
is running.
Failure to do so may result in fire. Completely shut down the Chromebook before putting
the Chromebook into an enclosed space.
When carrying the Chromebook with other items, such as the adapter, mouse, books
etc., take care not to press anything against the Chromebook.
If a heavy object is pressed against the Chromebook, a white spot or stain may appear on
the display.
Do not operate or look at the Chromebook while driving a vehicle.
There is a danger of a traffic accident. Please concentrate on driving.
For long periods of inactivity or storage, discharge the battery and separate it from the
Chromebook (for external or removable battery types).
Cautions on preventing data loss (storage device (such as HDD, SSD,
eMMC) management)
Take care not to damage the data on a storage device (such as HDD, SSD, eMMC).
•
Subjecting the device to physical impacts may result in data loss.
•
Data may be lost when the Chromebook is turned off or reset by a power failure
while the storage device (such as HDD, SSD, eMMC) is operating.
•
Data may be lost and irrecoverable because of a Chromebook virus.
•
Data may be lost if the power is turned off while running an app.
•
Samsung is not liable for any loss of data on a storage device (such as HDD, SSD,
eMMC).
To prevent data loss caused by damage to a storage device (such as HDD, SSD, eMMC),
please back up the data frequently.
Clean the display screen with a soft cloth dampened with Chromebook cleansing
detergent.
Do not use excessive force. Doing so may damage the display screen.
(NP UG Rev.5.0)
38
Appendix
Product specifications
The system specifications may differ depending on the derived model. For detailed
system specifications, refer to the product catalog.
<Product specifications>
Item Specification
Operating environment
•
Temperature: -5–40 °C for storage,
10–35 °C when operating
•
Humidity: 5–90% for storage,
20–80% when operating
AC/DC rating
•
Input: 100–240 VAC, 50–60 Hz
•
Output: (PDO) 5 V, 3 A / 9 V, 3 A / 15 V,
3 A / 20 V, 2.25 A
(PPS) 3.3–20 V, 2.25 A
PC rating 20 VDC, 2.25 A (45 W)
•
Optional components may not be provided or different components may be
provided depending on the model.
•
The system specifications are subject to change without notice.
•
For some models, it is not possible to add or replace storage or memory because
of the Chromebook's design.
Appendix
39
Important safety information
Safety instructions
The system is designed and tested to meet the latest standards for safety of information
technology equipment. However, to ensure safe use of this product, it is important that
the safety instructions marked on the product and in the documentation are followed.
Always follow these instructions to help guard against personal injury and damage
to the system.
Setting up the system
•
Read and follow all instructions marked on the product and in the documentation
before operating the system. Retain all safety and operating instructions for future
use.
•
Do not use this product near water or a heat source such as a radiator.
•
Set up the system on a stable work surface.
•
The product should be operated only with the type of power source indicated on the
rating label.
•
Ensure that the electrical outlet to power the equipment is easily accessible in case
of fire or short circuit.
•
If the Chromebook has a voltage selector switch, make sure that the switch is in the
proper position for your area.
•
Openings in the Chromebook case are provided for ventilation. Do not block or cover
these openings. Make sure you provide adequate space, at least 6 inches (15 cm),
around the system for ventilation when setting up your work area. Never insert
objects of any kind into the Chromebook ventilation openings.
•
Ensure that the fan vents at the bottom of the casing are clear at all times. Do not
place the Chromebook on a soft surface, doing so will block the bottom vents.
•
When using an extension cord with this system, make sure that the total power
rating on the products plugged into the extension cord does not exceed the
extension cord power rating.
•
For Chromebooks with glossy display bezels the user should consider the placement
of the Chromebook as the bezel may cause reflections from surrounding light and
bright surfaces.
Appendix
40
Care during use
•
Do not walk on the power cord or allow anything to rest on it.
•
Do not spill anything on the Chromebook or its components. The best way to avoid
spills is to not eat or drink near the Chromebook or its components.
•
Some products have a replaceable CMOS battery on the system board. There is a
danger of explosion if the CMOS battery is replaced incorrectly. Replace the battery
with the same or equivalent type recommended by the manufacturer.
Dispose of batteries according to the manufacturers instructions. If the CMOS
battery requires replacement ensure that a qualified technician performs the task.
•
When the Chromebook is turned off, a small amount of electrical current still flows
through the Chromebook.
To avoid electrical shock, always unplug all cables, remove the battery and modem
cables from the wall outlets before cleaning the system.
•
Unplug the system from the wall outlet and contact a Samsung Service Center if:
‒
The power cord or plug is damaged.
‒
Liquid has been spilled into the Chromebook.
‒
The Chromebook does not operate properly when the operating instructions are
followed.
‒
The Chromebook was dropped or the casing is damaged.
‒
The Chromebook performance changes.
Operating instructions
1 When installing and operating devices please refer to safety requirements in the user
guide.
2 Devices can be used only with the equipment specified in the technical specifications
of the devices.
3 If any smell of burning or smoke is detected from the Chromebook the unit should
be switched off and the battery removed. The unit should be checked by a qualified
technician before reuse.
Appendix
41
4 Service and repair of devices should be carried out by authorized service centers.
5 Do not allow the portable Chromebook to operate with the base resting directly
on exposed skin for extended periods of time. The surface temperature of the base
will rise during normal operation (particularly when AC Power is present). Allowing
sustained contact with exposed skin can cause discomfort or eventually a burn.
Replacement parts and accessories
Use only replacement parts and accessories recommended by manufacturer.
To reduce the risk of fire, use only No. 26 AWG or larger telecommunications line
cord.
Do not use this product in areas classified as hazardous. Such areas include patient
care areas of medical and dental facilities, oxygen rich environments, or industrial
areas.
Battery disposal
Do not put rechargeable batteries or products powered by non-removable
rechargeable batteries in the garbage.
Contact the Samsung Service Center for information on how to dispose of batteries that
you cannot use or recharge any longer. Follow all local regulations when disposing of old
batteries.
THERE IS RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Laser safety
All systems equipped with CD or DVD drives comply with the appropriate safety
standards, including IEC 60825-1. The laser devices in these components are classified
as "Class 1 Laser Products" under a US Department of Health and Human Services
(DHHS) Radiation Performance Standard. Should the unit ever need servicing, contact an
authorized service location.
Appendix
42
•
Laser Safety Note: Use of controls or adjustments or performance of procedures
other than those specified in this guide may result in hazardous radiation
exposure. To prevent exposure to laser beams, do not try to open the enclosure
of a CD or DVD drive.
•
Class 1M laser radiation when operating part is open. Do not view directly with
optical instruments.
•
Class 3B invisible laser radiation when open.
Avoid exposure to the beam.
Connecting and disconnecting the adapter
The socket-outlet shall be installed near the equipment and shall be easily accessible.
Do not unplug the power cord by pulling the cable only.
Power cord requirements
The power cord set (all plugs, cable and adapter plugs) you received with your
Chromebook meets the requirements for use in the country where you purchased your
equipment.
Power cord sets for use in other countries must meet the requirements of the country
where you use the Chromebook. For more information on power cord set requirements,
contact your authorized dealer, reseller, or service provider.
India only
The power cord set must have a minimum current capacity and a nominal voltage rating,
as required by country's power system.
Appendix
43
General requirements
The requirements listed below are applicable to all countries:
•
All power cord sets must be approved by an acceptable accredited agency
responsible for evaluation in the country where the power cord set will be used.
•
The power cord set must have a minimum current capacity of 7 A and a nominal
voltage rating of 125 or 250 volts AC, as required by each country's power system
(USA only).
•
The appliance coupler must meet the mechanical configuration of an EN 60 320/
IEC 320 Standard Sheet C7 (or C5) connector, for mating with appliance inlet on the
Chromebook.
Regulatory compliance statements
Wireless guidance
(If fitted with 2.4 G band, 5 G band or 6 G band)
Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz/5 GHz/6 GHz Band, may be present (embedded) in the
Chromebook system. The following section is a general overview of considerations while
operating a wireless device.
Additional limitations, cautions, and concerns for specific countries are listed in the
specific country sections (or country group sections). The wireless devices in the system
are only qualified for use in the countries identified by the Radio Approval Marks on the
system rating label. If the country you will be using the wireless device in, is not listed,
please contact your local Radio Approval agency for requirements. Wireless devices are
closely regulated and use may not be allowed.
The RF field strength of the wireless device or devices that may be embedded in the
Chromebook are well below all international RF exposure limits as known at this time.
Because the wireless devices (which may be embedded into the Chromebook) emit
less energy than is allowed in radio frequency safety standards and recommendations,
manufacturer believes these devices are safe for use. Regardless of the power levels,
care should be taken to minimize human contact during normal operation.
Some circumstances require restrictions on wireless devices.
Examples of common restrictions are listed on the next page:
Appendix
44
•
Radio frequency wireless communication can interfere with equipment on
commercial aircraft. Current aviation regulations require wireless devices to be
turned off while traveling in an airplane.
802.11 (also known as wireless Ethernet or Wi-Fi) and Bluetooth communication
devices are examples of devices that provide wireless communication.
•
In environments where the risk of interference to other devices or services
is harmful or perceived as harmful, the option to use a wireless device may
be restricted or eliminated. Airports, hospitals, and oxygen or flammable gas
laden atmospheres are limited examples where use of wireless devices may be
restricted or eliminated. When in environments where you are uncertain of the
sanction to use wireless devices, ask the applicable authority for authorization
prior to use or turning on the wireless device.
•
Every country has different restrictions on the use of wireless devices. Since your
system is equipped with a wireless device, when traveling between countries
with your system, check with the local Radio Approval authorities prior to any
move or trip for any restrictions on the use of a wireless device in the destination
country.
•
If the system came equipped with an internal embedded wireless device, do not
operate the wireless device unless all covers and shields are in place and the
system is fully assembled.
•
Wireless devices are not user serviceable. Do not modify them in any way.
Modification to a wireless device will void the authorization to use it. Please
contact the manufacturer for service.
•
Only use drivers approved for country in which the device will be used. Refer
to the manufacturer System Restoration Kit, or contact the manufacturer's
technical support for additional information.
Explosive Device Proximity Warning
Do not operate a portable transmitter (such as a wireless network device) near
unshielded blasting caps or in an explosive environment unless the device has been
modified to be qualified for such use.
Appendix
45
United States of America and Canada
USA and Canada Safety Requirements and Notices
Do not touch or move antenna while the unit is transmitting or receiving.
Do not hold any component containing the radio such that the antenna is very close to
touching any exposed parts of the body, especially the face or eyes, while transmitting.
Do not operate the radio or attempt to transmit data unless the antenna is connected; if
not, the radio may be damaged.
Use in specific environments:
The use of wireless devices in hazardous locations is limited by the constraints posed by
the safety directors of such environments.
The use of wireless devices on airplanes is governed by the Federal Aviation
Administration (FAA) in the USA and Transport Canada Civil Aviation (TCCA) in Canada.
The use of wireless devices in hospitals is restricted to the limits set forth by each
hospital.
Explosive Device Proximity Warning
Do not operate a portable transmitter (such as a wireless network device) near
unshielded blasting caps or in an explosive environment unless the device has
been modified to be qualified for such use.
Use On Aircraft Caution
FCC, FAA, and TCCA regulations prohibit airborne operation of radio-frequency
wireless devices because their signals could interfere with critical aircraft
instruments.
Other wireless devices
Safety notices for other devices in the wireless network:
Refer to the documentation supplied with wireless Ethernet adapters or other devices in
the wireless network.
The Part 15 radio device operates on a non-interference basis with other devices
operating at this frequency. Any changes or modification to said product not
expressly approved by Intel could void the user's authority to operate this device.
Appendix
46
FCC Part 15 Information and Notices
Responsible Party – U.S. Contact Information
Samsung Electronics America, Inc.
85 Challenger Road.
Ridgefield Park, NJ 07660
Phone: 1-800-SAMSUNG (726-7864)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy. If not installed and used in accordance with the instructions, it may cause
harmful interference. If this equipment does cause harmful interference to radio
or TV reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
If necessary, the user should consult the dealer or an experienced radio/TV technician
for additional suggestions. The user may find the following booklet helpful: "Something
About Interference."
This is available at FCC local regional offices. Our company is not responsible for any
radio or TV interference caused by unauthorized modifications of this equipment or
the substitution or attachment of connecting cables and equipment other than those
specified by our company. The correction will be the responsibility of the user. Use only
shielded data cables with this system.
Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control of or
communications with unmanned aircraft systems.
Appendix
47
Health and safety information
Exposure to Radio Frequency (RF) Signals Certification Information
This product can contain an embedded radio transmitter and receiver. It is designed
and manufactured not to exceed the exposure limits for radio frequency (RF) energy set
by the Federal Communications Commission (FCC) of the U.S. government. These FCC
exposure limits are derived from the recommendations of two expert organizations, the
National Council on Radiation Protection and Measurement (NCRP) and the Institute of
Electrical and Electronics Engineers (IEEE). In both cases, the recommendations were
developed by scientific and engineering experts drawn from industry, government, and
academia after extensive reviews of the scientific literature related to the biological
effects of RF energy.
Before a new model is available for sale to the public, it must be certified to the FCC that
it does not exceed the exposure limit established by the FCC. Evaluation per each model
is performed in positions and locations (such as at the bottom on the body) as required
by the FCC.
For body worn operation, this model meets the FCC RF exposure guidelines when used
with Samsung accessory designated for this product. Non-compliance with the above
restrictions may result in violation of FCC RF exposure guidelines.
RF exposure or SAR information can be viewed on-line at www.fcc.gov/oet/ea/fccid/.
This site uses this product FCC ID number on the outside of the product. Sometimes it
may be necessary to remove the battery pack to find number. Once you have the FCC
ID number for a particular product, follow the instructions on the website and it should
provide RF exposure information or values for typical or maximum SAR for particular
product.
For corresponding model only
The Specific Absorption Rate (SAR) is a measure of the rate of absorption of RF energy
by the human body expressed in units of watts per kilogram (W/kg). The FCC wireless
devices to comply with a safety limit of 1.6 watts per kilogram (1.6 W/kg).
SAR level of this device while operating can be well below the maximum value. This is
because the device is designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
Appendix
48
Manufacturer information
Samsung Electronics Co., Ltd.
129, Samsung-Ro, Yeongtong-Gu, Suwon-City, Gyeonggi-Do, 16677, Korea
Samsung Electronics Vietnam Co., Ltd.
Khu Cong nghiep Yen Phong 1, Yen Trung, Yen Phong, Bac Ninh, Viet Nam
Tel: +84-222-369-6875
For the web or the phone number of the Samsung Service Center, refer to the Warranty
or contact the retailer where you purchased your product.
RTC caution
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Discard used batteries
according to the Manufacturer's instruction.
Canada
Innovation, Science and Economic Development Statement:
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada's licence-exempt RSS(s).
Operation is subject to the following two conditions:
1 This device may not cause interference.
2 This device must accept any interference, including interference that may cause
undesired operation of the device.
Industry Canada Caution
The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the
potential for harmful interference to co-channel mobile satellite systems.
Devices to operate in the 5925-7125 MHz Band shall not be used for control of or
communications with unmanned aircraft systems.
Appendix
49
Innovation, Sciences et Développement économique Canada
L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme
aux CNR d'Innovation, Sciences et Développement économique Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes :
1 L'appareil ne doit pas produire de brouillage.
2 L'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Avertissement:
Les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés uniquement
pour une utilisation à l'intérieur a n de réduire les risques de brouillage préjudiciable aux
systèmes de satellites mobiles utilisant les mêmes canaux.
Les appareils fonctionnant dans la bande 5 925-7 125 MHz ne doivent pas être utilisés
pour le contrôle ou les communications avec des systèmes d'aéronefs sans pilote.
WEEE symbol information
Correct disposal of this product (Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its
electronic accessories (for example, charger, headset, USB cable) should not be disposed
of with other household waste at the end of their working life.
To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or
their local government office, for details of where and how they can take these items for
environmentally safe recycling.
Appendix
50
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product and its electronic accessories should not be mixed with
other commercial wastes for disposal.
For information on Samsung's environmental commitments and product regulatory
obligations, such as REACH, visit our sustainability page available at www.samsung.com.
India only
For more information on safe disposal and recycling visit our website
www.samsung.com/in or contact our Helpline numbers - 18002668282, 180030008282.
This product is RoHS compliant.
Correct disposal of batteries in this product
(Applicable in countries with separate collection systems)
This marking on the battery, manual or packaging indicates that the batteries in this
product should not be disposed of with other household waste at the end of their
working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery
contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66.
If batteries are not properly disposed of, these substances can cause harm to human
health or the environment.
To protect natural resources and to promote material re-use, please separate batteries
from other types of waste and recycle them through your local, free battery return
system.
PO BOX 12987, DUBLIN. IE
Removing the battery (Europe only)
•
To remove the battery, contact an authorised service centre. To obtain battery
removal instructions, please visit www.samsung.com/global/ecodesign_energy.
•
For your safety, you must not attempt to remove the battery. If the battery is not
properly removed, it may lead to damage to the battery and device, cause personal
injury, and result in the device being unsafe.
•
Samsung does not accept liability for any damage or loss (whether in contract or
tort, including negligence) which may arise from failure to precisely follow these
warnings and instructions, other than death or personal injury caused by Samsung's
negligence.
Appendix
51
USA only
This Perchlorate warning applies only to primary CR (Manganese Dioxide) Lithium coin
cells in the product sold or distributed ONLY in California USA.
"Perchlorate Material- special handling may apply, refer to
www.dtsc.ca.gov/hazardouswaste/perchlorate."
WARNING! Never dispose of batteries in a fire because they may explode. Do not
disassemble, crush, puncture, heat, burn or reuse batteries. For more information, visit
call2recycle.org or call 1-800-822-8837. Alternatively, visit: www.samsung.com/recycling
or call 1-800-SAMSUNG.
Samsung package Take-Back program (USA only)
In partnering with select recyclers, Samsung offers packaging take-back at no cost to
you.
Simply call the following number for the locations nearest you.
CRT Processing, LLC
(877) 278-0799
Kathy Severson – Logistics contact
For more recycling information, go to our website: www.samsung.com/recycling or call
1-800-SAMSUNG.
Appendix
52
TCO Certified
A third-party certification according to ISO 14024
Toward sustainable IT products
Say hello to a more sustainable product
IT products are associated with a wide range of sustainability risks throughout their life
cycle. Human rights violations are common in the factories. Harmful substances are
used both in products and their manufacture. Products can often have a short lifespan
because of poor ergonomics, low quality and when they are not able to be repaired or
upgraded.
This product is a better choice. It meets all the criteria in TCO Certified, the world’s
most comprehensive sustainability certification for IT products. Thank you for making a
responsible product choice, that help drive progress towards a more sustainable future!
Criteria in TCO Certified have a life-cycle perspective and balance environmental and
social responsibility. Conformity is verified by independent and approved verifiers that
specialize in IT products, social responsibility or other sustainability issues. Verification
is done both before and after the certificate is issued, covering the entire validity period.
The process also includes ensuring that corrective actions are implemented in all cases
of factory non-conformities. And last but not least, to make sure that the certification
and independent verification is accurate, both TCO Certified and the verifiers are
reviewed regularly.
Want to know more?
Read information about TCO Certified, full criteria documents, news and updates at
tcocertified.com. On the website you’ll also find our Product Finder, which presents a
complete, searchable listing of certified products.
