4K Zoom Video Microscope
CE210T Series
Option A
Option B (integrated with 15.6-inch display)
Option C (integrated with 15.6-inch
display & Android system)
Polarizing component XY moving stage Universal ball head Extension column
Product Advantages
Equipped with a Sony IMX678 1.8” sensor, accurate color repro-
duction and ultra-low latency;
Camera automatically adapts to 4K & 1080p display inputs;
Supports PC software KoPa Capture Pro.
Ultra-bright LED(＞20,000 hours lifespan);
Precision brightness & mode adjustment via software-control;
Independent brightness control for each lighting zone;
Seamless switching between ring lighting and near-coaxial lighting;
High CRI ≥87, 6500K color temperature – reduces eye strain during
prolonged use.
No external power adapter needed – clean & net
4K P60，dual output via HDMI 2.0 + USB 2.0
Software-control four-zone ring lighting +
near-coaxial lighting
Integrated cable management (combines power
supply+ USB output into a single cable)
Extendable crossbar + extension columns (supports multi-level expan-
sion) for flexible workspace adjustment.
Low-profile design with large working distance
5
WD=120ｍｍ
The CE210T positions the display at the optimal viewing angle (centered at eye
level), ensuring long-term comfort and reduced fatigue during extended use.
up to 360mm+
275ｍｍ
250ｍｍ
24 inch display
24 inch display
Lighting control through software
DC 5V 2A
DC 5V 2A
248mm
（Standard） （Vertical expansion option）
（Reference Image 1）
（Reference Image 2）
Lightweight:approx.2.4kg
Seamless switching between auto/manual depth stacking and focus
modes,intuitive interface for immediate user proficiency;
Precision Optical Components,extinction ratio 1000:1,adjustable
brightness/darkness
Overexposure Suppression Technology
All-in-One Design - Microscope and Android OS combined in a single
device (Option C exclusive),includes office software for immediate
documentation; PC-Free operation,eliminates computer costs and desk
clutter.
All-in-One Design (Option C Exclusive)
Integrated Android OS – No PC required
Depth stacking,manual focus/single autofocus/
continuous autofocus,calibration-free measurement
at fixed magnification
1
3
2
3
3
3
图像分辨率：1280×720
12.7mm
-1.0mm
0mm
Live preview Instant depth-stacked image
Matrix Grid Measurement
18 Built-in Measurement Tools for Fast, Precise Analysis;
Polarizer
Analyzer
12.7mm
-1.0mm
11mm
MF
AF
12.7mm
-1.0mm
8mm
MF
AF
12.7mm
-1.0mm
11mm
MF
AF
manual focus
single autofocus
continuous autofocus
周长：18.85μm
面积：28.27μm²
半径：3μm
周长：25.13μm
面积：50.27μm²
半径：4μm
周长：21.98μm
面积：38.48μm²
半径：3.5μm
Horizontal：
27
2
Line Width：
Color：
3
1
Vertical：
Tolerance Line：
Display Tolerance Line
Horizontal：
0
Vertical：
0
Number of Grids
Grid Settings
Nueneric Attribute
Horizontal：
0 0
Vertical：
Grid Interval
Tolerance Line Attribute
Grid Line Attribute
um um
± ±
Horizontal： Vertical：
um um
Horizontal： Vertical：
1
Line Width：
Color：
1
Horizontal： Vertical：
Horizontal： Vertical：
Fixed magnification
adjustment knob
USB2.0 interface: can be connected
to the mouse, keyboard, U disk
Power switch
Polarizer(Optional)
Four-zone ring lighting
Near-coaxial lighting
Analyzer(Optional)
Fine adjustment knob: 15mm up
and down
HDMI output
Power supply and
USB output cable
Field of view (mm) (L*W)
26.5*14.9（0.3X）
4.2*2.4（1.8X）
Working distance (WD)
120mm
Near-coaxial lighting Four-zone ring lighting
Standard 1/4"-20
threaded hole
Specifications
Optical magnifications
0.3-1.8X
Optical parameters
*27-inch 4K screen overall magnification: 23-140X (optical + monitor pixel array, i.e., length and
width of monitor display/actual size of object to be viewed)
*Near coaxial lamp + four-zone ring light maximum illumination: 16600Lx
127mm
108.5mm
128mm
106mm
47mm
23mm
Lightweight approx.0.8kg
Physical resolution
Image sensor
Exposure mode
Maximum resolution
ISO sensitivity
Sensor size
Pixel size
Spectral response
Exposure capability
Exposure time
White balance
Preview resolution
Power supply
A/D convertsion bit depth
Software and App
8.3MP
SONY IMX678 CMOS
Rolling Shutter
3840×2160 (8,294,400 Pixels)
Equivalent to 100-12800
1/1.8''
2μm×2μm
400-650nm
Real-time auto and manual adjustment
10μs-10s
Real-time auto and manual RB adjustment
3840×2160@60fps
DC 5V 2A
12bit
Embedded software: KoPa View；
Windows software: KoPa Capture Pro；
Power (output)
Input Voltage
Centre illuminance
Colour temperature
Adjustment method
＜3W
DC 5V
2100~5900Lx (at WD120mm)
6500K
Software control
Dimming Method
Dedicated LED control chip,
1~30 steps adjustment
16 small angle high
brightness beads
LED quantity
Power (output)
Input Voltage
Centre illuminance
Colour temperature
Adjustment method
＜5W
DC 5V
2000~12000Lx (at WD120mm)
6500K
Software control
Dimming Method
Dedicated LED control chip,
1~30 steps adjustment
40 small angle high
brightness beads
LED quantity
0-60mm
retractable
15.6-inch display specifications
Option A
Product options:
Number of Pixels
Pixel Arrangement
Colour gamut range
Number of colours displayed
Surface Finish
Surface hardness
Viewing Angle Range
Contrast Ratio
Brightness
1920(Horizontal)*1080(Vertical)
RGB vertical bar
100%（sRGB）
16.7M（8Bit）
Anti-glare
3H
Horizontal 170, Vertical 170
800：1
500cd/m2 (5-point average)
Option B (integrated with 15.6-inch display)
Recommended 24-inch or
larger 4K monitor (optional)
USB mouse HDMI cable (2 metres)
Power adapter
Accessories
USB mouse HDMI cable(40cm)
Power adapter
Accessories
Ultimate Storage Status
120mm
24 inch display
13:31 Fridays
2025/03/28
Wired mouse and keyboard
Option C (integrated with 15.6-inch display & Android system)
Deeply customised Android operating system;
Quad-core CPU + dual-core GPU，
4GB DDR4 RAM, 32GB eMMC hard drive；
Support mouse and keyboard operation, save images
and videos through USB stick
Instant Startup, zero Configuration,support HDMI
output simultaneously .
Supports the installation of third-party office software,
which can directly generate reports containing pictures
and measurement results.
Model list
Model
Category
Option A
AJ-08
Option B
BJ-08
Option C
CJ-08
CE210T
Accessories
Software interface
Desktop
APP can be installed arbitrarily
15.6-inch display specifications
Number of Pixels
Pixel Arrangement
Colour gamut range
Number of colours displayed
Surface Finish
Surface hardness
Viewing Angle Range
Contrast Ratio
Brightness
1920(Horizontal)*1080(Vertical)
RGB vertical bar
100%（sRGB）
16.7M（8Bit）
Anti-glare
3H
Horizontal 170, Vertical 170
800：1
500cd/m2 (5-point average)
Power adapter
3.Universal ball head
4.Extension column
Optional accessories
2.XY moving stage
1.Polarizing component
Installation Diagram
Installation Diagram
Installation Diagram
Effective movement range:
X=25mm
Y=25mm
Extension column: 120mm
20mm
2025.07V1.0
