INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
1
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
REMOVAL/INSTALL OF WINDOW REGULATOR (741-010)
Honda Odyssey 1999–2004
General Tech Tips:
• Use painter’s tape rather than duct tape to secure window. It’s less likely to damage paint or leave
sticky residue.
• A plastic pry tool is useful. It will not easily damage delicate trim like a screwdriver or metal pry bar.
• The replacement regulator should have a liberal amount of grease on slide area. If there is not much grease
present, white lithium grease works well to lubricate the slide area.
• Aftermarket window tinting can cause the window to travel slower and put additional strain on the window
regulator assembly.
• Window run channels should be cleaned and lubricated before installation of a new window regulator
assembly. Silicone spray works well.
PLEASE WEAR
SAFETY GLASSES!
Tools required for removal
and installation of window regulator
and motor assembly:
• Silicone spray lubricant
• Trim panel removal tool
• Pick
• Saddle cup assembly, tape, or wedge
to hold window in place
• Flat-blade screwdriver
or plastic pry tool
• 10mm socket or driver
• Phillips screwdriver
• Grease pencil or marker
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
2
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
Removal Instructions
STEP 2: Using your Phillips head screwdriver,
remove the screw and set aside.
STEP 1: Remove cap located behind the
driver’s side interior door handle, exposing
a Phillips head screw.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
3
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 3: Remove cap in the door cup with
your pick, exposing a Phillips head screw.
STEP 4: Remove Phillips head screw using
your Phillips screwdriver and set screw aside.
STEP 5: Using your non-marring pry tool,
pry at the rear of the inner door handle.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
4
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 6: Once you have the rear pried
slightly, push the whole handle assembly
toward the front of the vehicle. When the
assembly has been carefully removed,
remove the door rod clip and remove the
clip from the assembly.
STEP 7: Remove the door lock switch
connector and set assembly aside.
STEP 8: Using your non-marring pry tool, lift
up the rear of the door cup assembly.
Pull the entire assembly to the rear of the
vehicle, exposing the harness clips. Remove
both harness clips and set assembly aside.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
5
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 9: Using your non marring pry tool,
remove the speaker cover .
STEP 10: Using your Phillips screwdriver,
remove the screw at the front of the panel.
STEP 11: Remove the three (3) Phillips head
screws that hold the speaker to the panel.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
6
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 12: Remove the harness clip from the
speaker and set the speaker aside.
STEP 13: Remove the plastic cover
from the front of the door using your
non-marring pry tool.
STEP 14: Using your non-marring pry tool,
pry around the edge of the door panel to
separate the door panel from the door.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
7
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 15: When lifting the door panel o
of the door, some pressure on the door lock
knob may be needed to get the panel
o completely.
STEP 16: Carefully remove the clips securing
the vapor barrier to the door skin using
your pick.
STEP 17: Feed the clips through
the vapor barrier.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
8
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 18: Remove the two Phillips head
screws that secure the door panel bracket
above the vapor barrier.
STEP 19: Align the glass mounts to the
proper height for bolt removal through
the two holes in the door skin. Plugging
the window switch assembly back into the
harness will be necessary to move the glass.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
9
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 20: Remove the two (2) 10mm bolts
and then secure the glass with a saddle cup
assembly, painters tape, or wedge.
STEP 21: Remove the motor harness clip.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
10
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 22: Loosen the two (2) 10mm bolts
and remove the top 10mm bolt so the motor
is free to move. Remove the four (4) 10mm
bolts holding the regulator to the door skin.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
11
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 23: Unplug the harness clip as shown
to make room for regulator removal.
STEP 24: Remove the window regulator
assembly through the main access hole.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
12
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
Installation Instructions
STEP 1: Place the window regulator
assembly through the main access hole.
STEP 2: Plug the harness clip in as shown.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
13
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 3: Tighten the two (2) 10mm bolts.
Tighten the four (4) 10mm bolts holding the
regulator to the door skin.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
14
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 5: Attach the two (2) 10mm bolts
and then remove the saddle cup assembly,
painters tape, or wedge that was holding
the glass in place.
STEP 4: Attach the motor harness clip.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
15
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 7: Attach the two Phillips head screws
that secure the door panel bracket above
the vapor barrier.
STEP 6: Align the glass mounts to the proper
height for bolt attachment through the two
holes in the door skin. Plugging the window
switch assembly back into the harness may
be necessary to move the glass.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
16
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 10: Attach the door panel to the
door. When replacing the door panel, some
pressure on the door lock knob may be
needed to get the panel on completely.
STEP 9: Carefully attach the clips securing the vapor barrier to the door skin.
STEP 8: Feed the clips through
the vapor barrier.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
17
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 12: Attach the harness clip
to the speaker.
STEP 11: Attach the plastic cover
to the front of the door.
STEP 13: Attach the three (3) Phillips head
screws that hold the speaker to the panel.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
18
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 15: Attach the speaker cover.
STEP 14: Using your Phillips screwdriver,
attach the screw at the front of the panel.
STEP 16: Attach both harness clips to
the door cup assembly, and replace the
assembly in the door.
INSTALL/REMOVAL INSTRUCTIONS: WINDOW REGULATOR
741-010
Disclaimer:
Even though every attempt is made to ensure this information is complete and accurate, it is impossible to account for all possible circumstances or situations. Please consult with a quali ed auto technician
before attempting to perform any work you are not quali ed to do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor Vehicle Safety Standards by the National Highway Tra c Safety
Administration). Be sure that your work is performed in accordance with such standards and that you do not disable any motor vehicle safety feature.
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain speci c service procedures for this part. If you do not have
a service manual or lack the skill to install this part, it is recommended that you seek the services of a quali ed technician. Pay special
attention to all cautions and warnings included in the shop manual. Read and follow all instructions carefully.
19
©2013 Dorman Products, Inc.
No reproductions in whole or in part without prior written approval.
STEP 17: Attach the door lock switch connector and the door rod clip to the door handle
assembly. Replace assembly in door.
STEP 18: Attach Phillips head screw in door
cup, using your Phillips screwdriver. Replace
cap covering the screw.
STEP 19: Using your Phillips head
screwdriver, attach the screw behind the
door handle, and replace cap covering
the screw.
We appreciate your opinions regarding this product!
Please call our Technical Assistant with any challenges or suggestions
regarding the installation or operation of this product.
1-800-523-2492
STEP 20: Verify that all of the interior door trim panel attaching hardware is secure and
that the window regulator is operating properly.
