top shelf
acorn nut
washer
end panel
assemblies
Step 2:
Attach end panel assemblies to top shelf.
• Position end panel
assemblies as shown.
• On one end, align
all studding
underneath top
shelf with holes
on top of end
assembly.
• Fasten washers and acorn nuts
onto studs as shown.
• Repeat on remaining end.
ASSEMBLY INSTRUCTIONS
Buffet Shelf for Hot Food Table
EG9891 Revised 02/24
CAUTION
INSPECT CONTENTS IMMEDIATELY AND FILE CLAIM WITH DELIVERING
CARRIER FOR ANY DAMAGE. SAVE YOUR BOX AND ALL PACKING MATERIALS.
YOU ARE RESPONSIBLE FOR DAMAGE TO YOUR UNIT IF RETURNED IMPROPERLY PACKED.
Step 1:
Assemble front sneeze guard
and top shelf.
(To assemble, turn upside-down.)
• Position top flange of sneeze
guard INSIDE top shelf.
• Align holes, and secure with #10
washers and #10-32x1/2˝ screws
as shown.
(continued on back page)
acorn nut
stud
(x3)
washer
On each end of top shelf:
• 3 studs along inner side
• 2 studs on underside of top.
end panel
assembly
top shelf
(underside)
washer
sneeze
guard
sneeze
guard
top shelf
(underside)
top flange of
sneeze guard
screw
(SIDE VIEW,
UPSIDE DOWN)
sneeze
guard
top shelf
top shelf
hardware
in place
Before assembly, make sure front tabs
are facing OUTWARDS.
INSTRUCTION SHEET
#377166
Eagle Foodservice Equipment, Eagle MHC, and SpecFAB
®
are divisions of Eagle Group. ©2024 by the Eagle Group
• 100 Industrial Boulevard, Clayton, Delaware 19938-8903 U.S.A.
• Phone: 302/653-3000 • 800/441-8440 • Fax: 302/653-2065
• www.eaglegrp.com • www.eaglemhc.com
buffet shelf
screws
(from hot
food table)
hot food table
front panel
thumb screw
thumb screw
end panel
assembly (right)
end panel
assembly (left)
ASSEMBLY INSTRUCTIONS
Buffet Shelf for Hot Food Table
Step 4:
Attach buffet shelf to Eagle Group
hot food table.
Mount onto hot food table with sneeze guard
facing CUSTOMER’S SIDE of table.
• Remove the two frontmost screws on each end
of hot food table.
• Place buffet shelf onto hot food table.
• Line up holes on buffet shelf with holes on table.
• Replace screws into original holes.
• Secure with thumb screws.
• Tighten all hardware.
To clean all clear panels:
• Wash with mild soap or detergent and with plenty of lukewarm water. Dry with soft cloth or chamois.
• Do NOT use window-cleaning sprays, scouring compounds, acetone, gasoline, benzene, carbon tetrachloride or lacquer thinner.
(End)
Step 3:
Secure front sneeze guard to front tab of
each end panel assembly.
front tabs
For buffet shelves with sneeze guard on both
sides, repeat Steps 1 - 3 on remaining side.
