GOLF CART TRAILER HITCH
Read all instructions before using the golf
cart trailer hitch.
INSTALLATION INSTRUCTIONS
PRODUCT
PRODUCT
GUIDE
GUIDE
4-8x40mm hex bolt
4-10x20mm flatwasher
4-8x25mm hexbolt
4-8x15mm flatwasher
TOOLS NEEDED:
13mm socket
TRAILER HITCH
Using 8x25mm hardware provided, attach brackets to
hitch using the inside holes. Bracket should face each
other as shown.
Attach grab bar and trailer hitch to footplate as shown,
and tighten.
Attach receiver with pin clip to complete installation.
Using 8x40mm hardware, attach trailer hitch to footrest
as shown.
If installing this product with a Madjax Saftey Grab bar,
you will not use the mounting brackets from STEP 1.
Attach hitch to grab bar using 4 bolts as shown. Hand
tighten bolts until all 4 bolts are in place.Then tighten
completely.
