Smart Desktop POS Terminal
D3mini Cash Register
◆ Highly reliable design with specialized static, pulse
and surge protection
◆ Pre-configured dedicated peripheral
app
◆ Printer, Scanner, NFC all in one
◆ Various Interfaces
D3mini Smart POS Terminal
Product Picture
Physical Characteristic
Dimension
284mm(W)*273 mm(D) *84mm(H)
Color
Black
Main Screen
10.1” 800*1280
Secondary
Screen
4.99” 1280*720
Speaker
3Wotlage Mono
Interface
RJ45*1、RJ12*1、RJ11*1、DC-IN*1、Headphone*1、
USB Type-A*5
Key
Power Key(Lock screen/wake on/wake off )
Performance
OS
Android 11
CPU
RK3568, Quad-core 64-bit Cortex-A55, up to 2.0GHz
RAM
4GB LPDDR4 (optional ：2GB）
ROM
64GB EMMC (optional：32GB)
Ethernet
10M/100M Adaptive
Integrated Devices
Printer
58mm Thermal Printer
Paper width≤50mm
Print Speed:90m m/s
No Auto Cutter
NFC
Built-in NFC modu le, supports TYPE-A&B cards,
FeliCa ™(F), ISO14443, 156 93(V), 18092(NFCCIP-1).
Barcode Scanner
2D Symbologies: Aztec Code、Data Matrix Code 、
PDF417、Micro PDF417、QR Code、Micro QR Cod e
1D Symbologies： Codabar、Code 11、 Code 128、
UPC-A、UPC-E、Code 32、Code 39、Code93 、EAN-8 、
EAN-13、ISBN、ISSN、GS1 DataBar(RSS-14)、ITF5、
Matrix 2 of 5 etc.
Wireless Characteristic
WIFI
2.4G/5G Dual -Band WiFi-6
BT
Bluetooth 5.0
User Environment
Operating Temp.
0°C ~ 40°C（Non-condensing ）
Storage Temp.
-20°C ~ 50°C（Non-condensing ）
Operating
Humidity
5%RH ~ 85%RH（Non- condensing）
Storage
Humidity
10％RH ~ 95％RH（Non- condensing）
IP Level
IP52
ESD
EN61000-4-2, ±8KV air d ischarge、±4KV conductive
discharge
Accessories
Power Adapter
12V/3A（or 24V/2.5A）
Remarks:
* The d ata in this leaflet are derived from our laboratory data and differ
from the actu al d ata used. Techn ical specifi cations in th e leaflet are
subject to chang e withou t notice.
2025/7/3 V1.1
YOKO Official Website
Guangzhou Yoko Electronics Co., Ltd.
Address：3-4/F, Meihuatai Park, No.7, Environmental Protection Third Road, Xintang Town, Zengcheng District, Guangzhou City, China.
Official Contact Tel：020-8206 5617 Fax：020-82065420
Official website: www.chinayoko.com
Pictures are for reference only, appearance is based on the real thing. This description is subject to change without notice.
Our company has the right to interpret the above contents within the scope permitted by law.
FCC warning statements:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved
by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement This
equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
