User Manual
PTC Fan Heater
PSHCD12M4BV
WARNING NOTICE:
Before using this product, please read this manual carefully and keep
it for future reference. For additional support, please call
customer service at 1-866-646-4332.
Please read this manual carefully and keep it for future reference.
Thanks for Choosing
PELONIS!
Your support means the world to us.
We hope you enjoy our product as
much as we did creating it.
Contents
Important Instructions
Product Overview
01
03
Operating Instructions
04
06
07
07
Troubleshooting
Cleaning And Maintenance
Speci cations
Service and Support
One (1) Year Limited Warranty
08
09
This heater is hot when in use. To avoid burns, do not let bare skin
touch hot surfaces. If provided, always use handles when moving this
heater. Keep combustible materials such as furniture, pillows,
bedding, papers, clothes and curtains at least 3 feet (0.9m) from the
front of the heater and keep them away from the sides and rear.
Always unplug the heater when not in use.
1.
2.
WARNING
IMPORTANT INSTRUCTIONS
When using electrical heaters, basic precautions should always be
and hyperthermia, including the following:
READ ALL INSTRUCTIONS
BEFORE USING THE HEATER.
Read all instructions before using heater.
Extreme caution is necessary when any heater is used by or near
children or invalids, and whenever the heater is left operating and
unattended.
CAUTION: This unit has a polarized plug (one blade is wider than the
DO NOT attempt to defeat this safety feature. To do so could result in
an electric shock hazard.
CAUTION: It is normal for the plug to feel warm to the touch; however,
to replace a loose or worn outlet.
CAUTION: Always plug heaters directly into a wall outlet/receptacle.
Never use with an extension cord or reloadable power tap
(outlet/power strip).
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT AND FULLY INSERT.
1.
2.
3.
4.
5.
6.
CAUTION
Do not operate any heater with a damaged cord or plug or after the
heater malfunctions, has been dropped or damaged in any manner.
Discard heater or return heater to authorized service facility for
examination, electrical or mechanical adjustment, or repair.
Do not use the heater outdoors.
This heater is not intended for use in bathroom, laundry areas and
similar moist indoor locations. Never locate heater where it may fall
into a bathtub or other water container.
Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
be tripped over.
This heater draws 10 amps during operation. To prevent overloading a
circuit, do not plug the heater into a circuit that already has other
appliances plugged in.
from outlet. Never pull by the cord.
Do not insert or allow foreign objects to enter any ventilation or
to the heater.
manner. Do not use on soft surfaces, like a bed, where openings may
become blocked.
A heater has hot and arcing or sparking parts inside. Do not use it in
Use this heater only as described in this manual. Any other use not
injury to persons.
The output of this heater may vary and its temperature may become
intense enough to burn exposed skin. Use of this heater is not
recommended for persons with reduced sensitivity to heat or an
inability to react to avoid burns.
Hyperthermia can result in death. Symptoms of hyperthermia include
high body temperature, headache, nausea, vomiting, tiredness,
dizziness, fainting, and rapid pulse. If you begin to experience
medical attention.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
To avoid excessive room temperatures which can cause
hyperthermia: DO NOT leave product running unattended in a
sensory, or mental capabilities.
15.
[Note]
All the pictures in this manual are for explanation purposes only. Any discrepancy between the
real object and the illustration in the drawing shall be subject to the real model.
SAVE THESE INSTRUCTIONS
Product Overview
Inlet Air Grille
/Filter
Outlet Air Grille
Push Button
Controls
Thermostat
Control
Operating Instructions
Check Before Turning on the Machine
Check for any damage to the power cord.
Before connecting the heater to the power source, ensure the heater is positioned on
1.
2.
3.
orientated either vertically or horizontally as depicted below.
1.
2.
Place the Unit on a Flat, Stable Surface
In order to avoid overheating, do not cover the heater.
WARNING
HorizontalVertical
This product can operate normally in either of the following two orientations. If the
unit is knocked over and stops functioning, please return to one of these orientations
and power back on.
Push-Button Description
Control Panel
High Heat
High Heat
Temperature Control
will illuminate amber, and the unit will provide low heat output at
To increase the heat output, depress the High Heat switch after the
unit has been powered On. The High Heat switch light will illuminate
amber, and the unit will provide high heat output at 1200 W. Press the
High Heat switch again to cycle back to low heat output.
If the heater overheats due to abnormal conditions or incorrect operation, the
After the heater cools down, you must unplug it and then plug it back in to restart
and resume normal use.
position, and it will resume normal operation.
Safety Protection
A. Overheating Protection:
B. Tip-over Protection:
Description
• Adjust the thermostat control knob clockwise to the highest
position (MAX) before turning on the heater. Allow the heater
to operate and warm up the room.
• When the desired temperature/comfort level is reached,
lower the temperature setting by turning the thermostat
control knob counterclockwise until the heater stops
operating (and an audible "click" is heard).
NOTE:
maintains the preset temperature. To prevent the unit from
towards MAX.
Temperature Control Knob (Thermostat)
Knob
Model
PSHCD12M4BV
Power Supply
120 V~, 60 Hz
Rated Power (High Heat)
1200 W
Rated Power Range
High
1200 W
Low
700 W
Troubleshooting
the following list. If the reason the product does not operate or does not operate
properly is not included in the following list, the product may have failed. At this time, it
is recommended to send the product to the dealer for treatment.
Problem
After the power is
engaged, the machine
does not work.
Check whether the plug is properly
inserted into the receptacle.
• The plug may not be
properly inserted into the
receptacle.
The machine
suddenly stops
during heating.
Make sure the appliance is
product has cooled, reinsert the
plug into the receptacle and
• The temperature exceeds
the threshold of the
Cause Solution
Cleaning And Maintenance
It is recommended that the heater be cleaned at least one time during the operating
season in order to provide the optimum level of performance. ALWAYS TURN THE
POWER SWITCH OFF AND UNPLUG THE HEATER BEFORE CLEANING. Be sure to save
• Turn the heater “OFF”, unplug it and wait for the heater to cool down.
• Use a dry cloth to clean only external surfaces of the heater.
• Do not use any cleaning agents or detergents.
• Never immerse the heater in water.
• Pack the heater in the original carton and store it in a cool and dry place.
• Any other maintenance shall be performed by an authorized service agent.
This heater cannot achieve accurate temperature control of the environment, and thus cannot
be used as an insulation device for storage environment, items, animals and plants.
WARNING
In the event of a warranty claim, questions, comments or if service is required for
this product, please contact us at the following:
For your records, staple your sales receipt to this manual and record the following:
Service and Support
Toll Free: 1-866-646-4332
For questions or comments,please write to:
300 Kimball Drive
Parsippany, NJ 07054
Email: customersupport@pelonis.com
Step 1 Step 2
Register on PELONIS US
website by scanning the QR code
Email to
OR
OR
Product Registration Card
Take a photo of purchase receipt
nty rights.
• Please read all instructions before attempting to use this product.
• Misuse, negligence, physical damage or accidents.
• Lack of maintenance (see instructions for proper maintenance).
• Repair by any unauthorized party during the warranty period.
• Damage caused by connection to an improper input voltage (see specification label
on your product).
One (1) Year Limited Warranty
Midea America Corp. warrants as limited herein to the original purchaser of retail that
each new product, shall be free of defects in material and workmanship for a period of
one (1) year from the date of delivery. This one (1) year warranty is limited to the heating
elements, motor and electric control circuit board. The date of delivery establishes the
warranty period, should service be required.
Midea America Corp. makes no further warranties or representations, express or implied
except those contained herein. No representative or dealer is authorized to assume any
other liability regarding the product. The duration of the implied warranty granted under
State law, including warranties of merchantability and fitness for particular purpose are
limited in duration should the duration of the express warranty grant it hereunder. Midea
America Corp. shall in no event be liable for direct, indirect, special or consequential
damages.
Some states do not allow limitations on how long an implied warranty lasts, and/or the
above limitations or exclusion may not apply to you. This warranty gives you specific
legal rights and you may have other rights which vary from state to state.
If the product fails or malfunctions due to a defect in materials or workmanship within
one (1) year from the date of original retail purchase, the consumer shall return the
product, postage prepaid, along with proof of purchase, to Midea America Corp. for
repair or replacement. Midea America Corp. reserves the right to inspect the claimed
defective part or parts to determine if the defect or malfunction complaint is covered by
this warranty. Midea America Corp. shall, within sixty (60) days after receipt of the
product, at its option, repair and/or replace the defective part or parts free of charge.
This warranty shall only cover defects arising from normal usage. Midea America Corp.
assumes no responsibility whatsoever if the product should fail during the warranty
period by reason of:
