EN Hand Mixer
SHM 5206WH
05/2017
- 2 -
Copyright © 2017, Fast ČR, a.s.
EN
Hand Mixer
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
■
This appliance may be used by persons with physical or mental impairments or by inexperienced persons, if they are
properly supervised or have been informed about how to use the appliance in asafe manner and understand the
potential dangers.
■
Children must not use this appliance or play with it. Keep this appliance and the power cord out of reach of children.
■
The appliance is designed for household use only. It is not intended for use in locations such as:
– sta kitchens in stores, oces and other workplaces;
– hotel or motel rooms and other living areas;
– agricultural farms;
– bed and breakfast establishments.
■
This appliance is designed for mixing, kneading and whipping food. Do not use it for any other purposes than those
intended.
Warning:
Incorrect use may lead to injuries.
■
Do not use the appliance in an industrial environment or outdoors.
■
Before connecting this appliance to apower socket, make sure the rated voltage stated on its rating label corresponds
to the voltage in your power socket.
■
Do not place the appliance on an electric or gas stove or in its vicinity, on the edge of atable or on an unstable surface.
Only place the appliance on an even, dry and stable surface.
■
Only use the appliance with the original accessories that came with it.
■
Before rst use, it is necessary to thoroughly wash the removable attachments using warm water and kitchen
detergent, then rinse then with drinking water and wipe thoroughly until dry using ane wiping cloth.
■
Before turning on the appliance, always make sure that the removable attachments are properly attached to the
motor unit. Never combine various types of attachments.
■
Do not use the appliance if you have wet hands.
■
Do not cover the appliance’svents.
■
Do run the appliance without load. Incorrect use of the appliance may negatively aect its lifetime.
■
Only start the appliance after submerging the balloon whisk, beaters or kneading hooks in the container with
the ingredients. To prevent food from splashing out, keep the attachments submerged in the container with the
ingredients while the appliance is running.
■
Avoid coming into contact with the rotating parts of the appliance. While mixing, do not place hands, forks or any
other utensils into the bowl with the ingredients, and keep hair, clothing, etc. at asucient distance from the rotating
parts of the appliance. If afork or another utensil falls into the container while mixing, immediately turn o the
appliance.
■
Be especially careful when handling hot foods and liquids. Hot steam or splashing hot foods and liquids may cause
scalding. For reasons of increased safety, it is recommended to allow hot liquids and foods to cool down before mixing
them. Never mix hot foods and liquids directly in apot located on aturned on hotplate.
05/2017
- 3 -
Copyright © 2017, Fast ČR, a.s.
■
If you have just processed hot foods, the removable attachments may be hot after they are used.
■
If ingredients stick to the rotating attachments or the inside walls of the container, turn the appliance o and unplug
it from the power supply. Make sure that the rotating parts have stopped rotating and remove the attachments.
Clean the walls of the container and accessories using aplastic spatula. Then reassemble the appliance, connect it to
apower socket, and then you may continue blending.
■
Do not leave the appliance in continuous operation for longer than 10 minutes. Before turning it on again, allow it to
cool down.
■
Always turn o the appliance and disconnect it from the power socket if you will not be using it and if you will
be leaving it without supervision, before changing accessories, before assembly, disassembly, cleaning and before
moving it. Before disassembling or changing accessories that move during operation, make sure that the rotating
parts have stopped.
■
Keep the appliance clean. Clean it according to the instructions in chapter Cleaning and maintenance. Do not
submerge the motor unit and its power cord in water or any other liquid, or wash these parts under running water.
The removable attachments are intended for short term contact with food (including beverages), i.e. max. 4 hours. To
prevent damaging their surface, do not leave them submerged, for example in water for extended periods of time.
■
Ensure that the power plug contacts do not come into contact with moisture. Do not place heavy items on the power
cord. Make sure that the power cord does not hang over the edge of atable or that it is not touching ahot surface.
■
Disconnect the appliance from the power socket by pulling on the plug, never pulling on the power cord. Otherwise,
this could damage the power cord or the socket.
■
If the power cord is damaged, it must be replaced by an authorised service centre or by another similarly qualied
person, this will prevent the creation of adangerous situation. It is forbidden to use the appliance if it has adamaged
power cord.
■
Do not use the appliance when it is not functioning properly or showing any signs of damage. In order to prevent
ahazardous situation arising, do not repair the appliance yourself or modify it in any way. Have all repairs performed
at an authorised service centre. By tampering with the appliance, you risk voiding your legal rights arising from
unsatisfactory performance or quality warranty.
05/2017
- 4 -
Copyright © 2017, Fast ČR, a.s.
4
5
2
1
3
6
8
9
10
7
11
A
B C
05/2017
- 5 -
Copyright © 2017, Fast ČR, a.s.
EN
Hand Mixer
User'smanual
■ Prior to using this appliance, please read the user’smanual thoroughly, even
in cases, when one has already familiarised themselves with previous use of
similar types of appliances. Only use the appliance in the manner described
in this user’smanual. Keep this user’smanual in asafe place where it can be
easily retrieved for future use.
■ We recommend saving the original cardboard box, packaging material,
purchase receipt and responsibility statement of the vendor or warranty card
for at least the duration of the legal liability for unsatisfactory performance
or quality. In the event of transportation, we recommend that you pack the
appliance in the original box from the manufacturer.
DESCRIPTION OF THE APPLIANCE
A1 Turbo pulse switch
for setting maximum speed
A2 Power and speed setting switch
A3 Button for releasing removable
attachments
A4 Motor unit
A5 Vents
A6 Holes for attaching removable
attachments
A7 Handle
A8 Set of beaters
A9 Set of kneading hooks
A10 Balloon whisk
A11 Removable attachment storage
box
BEFORE FIRST USE
1. Remove all packaging materials, including promotional tags and labels from
the appliance and its accessories.
2. Use one hand to hold the storage box A11 and the other to grasp the motor
unit A4 by the handle A7 and take it o the box A11. Take the removable
attachments out of the box A11.
3. Thoroughly wash the storage box A11 and the removable attachments A8,
A9, and A10 that are intended to come into contact with food using warm
water and aneutral kitchen detergent. Then rinse everything with clean water
and allow it to dry naturally or dry it out thoroughly using awiping cloth. No
part of this appliance is suitable for washing in adishwasher.
Attention:
Do not rinse the motor unit A4 and its power cord under water or
submerge it in water.
INTENDED USE OF THE ATTACHMENTS
Attachment type Purpose of use
Beaters A8 Mixing and whipping
– batter dough, mashed potatoes, whipped cream,
foam from egg whites, creams, etc.
Kneading hooks A9 Kneading
– bread dough, fresh dough for pasta, pizza or
biscuits, pu dough, etc.
Balloon whisk A10 Whisking
– whipped cream, foam from egg whites, foam
creams, etc. Do not use it for mixing or kneading
dough.
ASSEMBLING AND DISASSEMBLING THE APPLIANCE
■ Before you start assembling or disassembling the appliance, check that the
switch A2 is set to position 0 (o) and that the motor unit A4 is disconnected
from the power socket and that the rotating parts have come to acomplete
stop.
■ Select attachment type A8, A9 or A10, that you wish to use and fasten
it into the holes A6 underneath the motor unit A4 (see g. B). The correct
procedure must be followed when inserting the attachments into the holes
A6. Otherwise, the attachments could come loose during operation. Insert
the beater or hook with the ring into the left hole and push it towards the
motor unit A4 until it is secured in place. In the same way, attach the other
attachment of the same type into the right hole. Insert the balloon whisk A10
only into the right hole.
Attention:
Never combine various types of accessories.
■ To remove the attachments, put the appliance into a vertical position and
stand it on an even surface. Press button A3. This will release the attachments
from the holes underneath the motor unit A4, and then it is easy to take them
out. Do not use force to remove the attachments.
Attention:
Button A3 cannot be pressed unless switch A2 is set to position 0
(turned o).
OPERATING THE APPLIANCE
1. Place the food and liquids that you wish to process into asuciently large
container.
2. Assemble the appliance according to the instructions in the chapter
Assembling and disassembling the appliance. Unwind the full length of the
power cord and connect the appliance to apower socket.
3. Submerge the attachments into the container with the ingredients, then start
the appliance by setting switch A2 to the required speed level in the range
from 1 to 5. To initially stir in the ingredients, we recommend that you rst
set alower speed and then adjust it as required. For kneading dough, use
only speed 1. To prevent the ingredients from splashing out of the container
during operation, keep the attachments submerged in the container.
Attention:
The maximum continuous operating time of the appliance is 10
minutes. Before using it again, allow the appliance to cool down for
15 minutes. When kneading heavy, thick doughs, do not leave the
appliance running for more than 5 minutes.
4. Hold down the pulse button A1 to run the appliance at maximum speed. To
prevent the appliance from overheating, do not use this button for longer
than 30 seconds.
5. After you have nished using the appliance, set switch A2 to position 0 (o)
and disconnect the power cord from the power socket. Make sure that the
rotating parts have stopped rotating. Put the appliance into avertical position
and stand it on an even surface. Remove all the used attachments and then
clean all the used parts according to the instructions in chapter Cleaning and
maintenance.
QUICK GUIDE TO PROCESSING INGREDIENTS
Beaters A8
Type of ingredients
or meals
Amount Processing time Recommended
speed setting
Creams approx.
600 g
approx.5 minutes level 4
Mashed potatoes max. 750 g max. 3.5 minutes level 3-4
Whipped cream max. 500 g max. 5 minutes level 5
Egg whites max. 5 egg
whites
approx. 3 minutes level 5
Batter approx.
600 g
approx. 5 minutes level 3-4
Kneading hooks A9
Type of ingredients
or meals
Amount Processing time Speed setting
Bread dough max. 500 g
of our
2× 5 minutes level 1
Dough for fresh
pasta
max. 300 g
of our
5 minutes level 1
Balloon whisk A10
Type of ingredients
or meals
Amount Processing time Recommended
speed setting
Whipped cream max. 500 g max. 5 minutes level 5
Egg whites max. 5 egg
whites
approx. 3 minutes level 5
Whipped foam approx. 600 g approx. 1 minute level 1
Note:
The above processing times are only areference.
When whipping egg whites, the container and attachments must be
perfectly clean and dry. Even asmall amount of fat may cause the egg
whites not be whipped to the desired snowy consistency.
Whipping cream should be cooled to atemperature of 6 °C prior to
being whipped.
Prior to processing them, allow the ingredients used for making various
doughs to rest at room temperature.
05/2017
- 6 -
Copyright © 2017, Fast ČR, a.s.
CLEANING AND MAINTENANCE
■ Before cleaning, make sure that the appliance is turned o, disconnected
from the power socket and that the rotating parts are not moving.
■ Thoroughly wash the removed attachments using warm water and neutral
kitchen detergent. Then rinse them with clean water and dry thoroughly
with ane wiping cloth. The removable attachments are intended for short
term contact with food (including beverages), i.e. max. 4 hours. To prevent
damaging their surface, do not leave them submerged, for example in water
for extended periods of time.
■ In the event that the storage box A11 is soiled, wash it in warm water using
aneutral kitchen detergent. Then rinse it with clean water and dry thoroughly
with ane wiping cloth.
■ To clean the outer surface of the motor unit A4, use acloth lightly dipped in
aweak detergent solution. After applying the detergent solution, wipe the
surface with acloth lightly dampened in clean water and then wipe dry.
■ No part of this appliance is suitable for washing in a dishwasher. Never
submerge the motor unit A4 or the power cord in water or in any other liquid.
■ Do not use solvents, cleaning products with an abrasive eect, etc. for
cleaning the appliance. Otherwise, the surface coat of the appliance may be
damaged.
STORAGE
■ When not using the appliance, store the attachments in the storage box A11.
Store the beaters A8 in the storage box A11 with the opposite ends facing
each other, and store the kneading hooks A9 in the same way.
■ Tilt the motor unit A4 so that its front part slides in from underneath into
the front part of the storage box A11 and then push the rear part of the
motor unit A4 towards the storage box A11 until both parts connect rmly to
each other (see g. C). When lifting the motor unit A4 by the handle A7, the
storage box A11 should remain attached to the motor unit A4. Finally, place
the appliance in aclean, dry place out of children’sreach.
TECHNICAL SPECIFICATIONS
Rated voltage range ..................................................................................................... 220−240 V
Rated frequency................................................................................................................ 50/60 Hz
Rated power input .................................................................................................................400 W
Electrical shock protection class ................................................................................................. II
Noise level ............................................................................................................................ 85 dB(A)
The declared noise emission level of the appliance is 85 dB(A), which represents
alevel Aof acoustic power with respect to areference acoustic power of 1 pW.
Explanation of technical terminology
Safety class for electrical shock protection:
Class II – Electrical shock protection is provided by double or heavy-duty
insulation.
Changes to text and technical parameters are reserved.
INSTRUCTIONS AND INFORMATION REGARDING THE
DISPOSAL OF USED PACKAGING MATERIALS
Dispose of used packaging material at a site designated for waste in your
municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that used
electric or electronic products must not be added to ordinary
municipal waste. For proper disposal, renewal and recycling hand
over these appliances to determined collection points.
Alternatively, in some European Union states or other European
countries you may return your appliances to the local retailer
when buying an equivalent new appliance.
Correct disposal of this product helps save valuable natural
resources and prevents potential negative eects on the environment and
human health, which could result from improper waste disposal. Ask your local
authorities or collection facility for more details.
In accordance with national regulations penalties may be imposed for the
incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or
supplier for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this product,
request the necessary information about the correct disposal method from the
local council or from your retailer.
This product meets all the basic requirements of EU directives
related to it.
