Product Manual
Label Printer
Sma
NIIMBOT N1
Package Contents
01
Sma Label Printer *1
Label Paper Roll *1 Thermal Transfer Ribbon *1
Product Manual *1
USB Type-C Cable *1
Please choose N1-compatible
thermal printing label paper for
printing.
Installation
02
Lift the open clasp upward to open the compament.
1
Fit the label paper inside with the label side facing up.
2
Open Clasp
Invalid if torn
This side faces up.
Thread the paper roll through the paper duct and make sure
the rst label paper sticks out of the tear-o slot.
3
Tauten the thermal transfer ribbon counterclockwise
according to the thermal transfer ribbon label and t it into
the compament with the label side facing down.
4
Tear-o Slot
Paper Duct
Snap the clasp down to close the cover.
5
Printer Software
03
NIIMBOT APP
Commercial Label Editing
Expe
NIIM APP
Your Home Labeling Assistant
If you have purchased this product
primarily for commercial or industrial
applications, we recommend
downloading the NIIMBOT app, which
features a wide range of indust-
specic label templates, data impo
capabilities, and batch printing
functions.
You can download the app directly
from the Google Play or Apple App
Store.
If you have purchased this product
mainly for home storage or personal
creative projects, we recommend
downloading and using the NIIM app,
which features a variety of fun and
creative icons and label templates for
household use.
You can download the app directly
from the Google Play or Apple App
Store.
03-1 Recommended App Downloads
Design & Print APP
easy to download and use
NIIMBOT
Design & Print APP
easy to download and use
NIIM
Once successfully connected, go to the Drawing Board.
3
Open the app and search for Bluetooth devices to connect to.
2
Note: If it asks for a PIN, enter 0000 or 1234 then press OK.
Connecting to Print
04
The illustrations of products, accessories, software inteaces,
etc. in this getting staed guide are illustrative in nature and for
reference only. Due to product updates and upgrades, the
physical product may dier slightly from the illustrations.
Please refer to the actual physical product in such case. The
product is subject to technical improvements without notice.
Note
8:30
NIIMBOT
Turn on Bluetooth
Once the app has downloaded, make sure your phone's
Bluetooth is turned on.
1
Note: Location permissions may need to be enabled on
Android phones.
Operation Steps
05
Function Process
Turn on
Turn o
Feed paper or
print histo
Press and hold the power button for three seconds
Press and hold the power button for three seconds
while powered on
Press the power button once while powered on
Print testing page Press the power button twice while powered on
Meaning of Indicator Lights
06
Indicator light
Blue
Blue
Blue
Red
Flashing slowly
Flashing quickly
Solid
Flashing quickly
Solid
Flashing slowly
State
Standby
Charging
Bluetooth connected
Low batte—standby
Meaning
Red
Red
Low batte—charging
Low batte and Bluetooth
connected
Specications
07
Product Label Printer Model NIIMBOT N1
Dimensions 135*90*37mm Weight 308g
Charging Time 3 - 4 hours Input
Batte
Capacity
1200mAh
Thermal Transfer
Printing
5V DC, 1A
Printing
Method
Printing
Resolution
Printing
Width
Connectivity Charge
Transmit Power
Operating
Temperature
203dpi 12mm
Bluetooth Type-C
4dBm(Maximum) 0℃ - 40℃
08
Read all instructions and warnings in this guide carefully before
using the product to ensure proper and safe use of the product
and to avoid personal inju or damage to propey.
Keep the product and accessories in a safe place that is inaccessible to
children, or only allow use under the supeision of a guardian.
Immediately disconnect the product from the power source if the
product enters water.
Immediately disconnect the product if the device malfunctions.
If you use a power adapter to charge (or power) the device, you must
purchase an adapter that is safe, compliant, and meets the standards.
Do not disassemble the product to replace the batte yourself. Incorrectly
replacing the batte can result in an explosion.
1.
2.
3.
4.
5.
*Warning
Safety Precautions
Do not disassemble the
product yourself.
No returns or exchanges will be
authorized for disassembled
products.
Do not use corrosive chemical
products or cleaners to wipe
down the product.
Do not use the product in
the vicinity of ammable
substances such as in gas
stations, fuel depots, etc.
The batte contains special protective circuit and devices. Do not
disassemble the batte as this may cause sho circuits or electrolyte
leakage. If electrolytes accidentally enter your eye, rinse immediately
with clean water and seek medical advice.
Do not expose the appliance or power adapter to high-temperature or
high-humidity environments, or put in water, to prevent sho circuits
that can cause the batte to become hot, smoke, deform, get damaged
or even explode.
Disconnect the power adapter immediately if you notice either smoke
or a smell coming from the product or the power adapter, taking care
to avoid burns.
6.
7.
8.
Please purchase the version of the product that matches your region or
count of use through the NIIMBOT ocial store or a NIIMBOT authorized
sales agent. Purchasing the product through other channels may mean you
buy a pirated product or a product not adapted to your region or count
of use which may lead to usage issues. In such cases, NIIMBOT may be
unable to provide you with fuher assistance.
*Impoant
Notice:
If the device cannot be turned on, please charge for one hour.
NIIMBOT is a brand under Wuhan Jingchen Intelligent ldentication Technology Ltd.
© 2024 NIIMBOT. All Rights Reseed.
Suppo Email : se[email protected]
Ocial Website : www.niimbot.com
Wuhan Jingchen Intelligent ldenticationTechnology Co., Ltd.
Manufacturer's Address : No. 5, Creative Workshop, Creative World,Yezhihu
West Road,Hongshan District,Wuhan, China
