Models: KKF140C
KKF140MB
KKF140SS
COMPONENT LIST QTY
1 - Faucet Body 1
2 - Connector 1
3 - Spray Head 1
4 - Weight 1
5 - Rubber Washer 1
6 - Metal Washer 2
1
INSTALLATION GUIDE
Karran USA Tel: 866.452.7726 www.karran.com [email protected]
Standerton
7 - Mounng Hardware 1
8 - Screws 2
4
3
2
1-3/8” to 1-1/2”
8-1/2”
11-3/8”
18-3/4”
3-1/8”
7-3/4”
5
4
7
6
1 - Handle
2 - Screw
3 - Cover
4 - Nut
5 - Cartridge
6 - Faucet Body
7 - Connector
8 - Spray Head
9 - Weight
10 - Rubber Washer
11 - Metal Washer
12 - Mounng Hardware
13 - Screws
